HIKVISION TurboHD DS-2CC 2D9T Series User Manual

Hd 1080p ultra low-light poc camera
Hide thumbs Also See for TurboHD DS-2CC 2D9T Series:

Advertisement

Quick Links

Download this manual
DS-2CCx2D9T-xxxx
HD 1080p Ultra Low-Light
PoC Camera
User Manual

Advertisement

loading

Related Manuals for HIKVISION TurboHD DS-2CC 2D9T Series

Summary of Contents for HIKVISION TurboHD DS-2CC 2D9T Series

  • Page 1 DS-2CCx2D9T-xxxx HD 1080p Ultra Low-Light PoC Camera User Manual...
  • Page 2 Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision.
  • Page 3 SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS TO THE APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED FOR ILLEGITIMATE PURPOSES.
  • Page 4 conditions: • This device may not cause harmful interference. • This device must accept any interference received, including interference that may cause undesired operation. EU Conformity Statement This product and, if applicable, the supplied accessories too are marked with “CE” and comply therefore with the applicable harmonized European standards listed under the EMC Directive 2014/30/EU, the LVD Directive 2014/35/EU, the RoHS Directive 2011/65/EU.
  • Page 5 “Last Updated” above. What Information We Collect In order to provide HIKVISION services to you, we will ask you to provide personal information that is necessary to provide those services to you. If you do not provide your personal information, we may not be able to provide you with our products or services.
  • Page 6 • personalize your experience with our HIKVISION Services and Products; • increase the safety of our HIKVISION Services and Products – for example, for user authentication, security protection, fraud detection, filing, and backups; • perform analytics and conduct customer research;...
  • Page 7 Terms of Service. • If HIKVISION and/or all or part of our assets are ever sold or transferred, your personal information may be among the items sold or transferred. Under such circumstance, we will notify you by the e-mail address specified in your account or by means of notice on us.hikvision.com and associated Websites of (i) the identity and contact information of...
  • Page 8 100% secure. Therefore, HIKVISION cannot guarantee that your personal information is under absolute security with the existing security technology. If you have any questions about the security of our HIKVISION Services, you can contact us at the contact information below in Contact Us.
  • Page 9 Privacy Policy. Links to Other Websites We may permit others to link to the HIKVISION services or to post a link to their Website. We do not endorse these Websites and are not responsible for other Websites or their privacy practices.
  • Page 10 Our HIKVISION Services are designed and intended for adults. By using the HIKVISION Services, you represent that you are at least 18 years old, or above the equivalent minimum age in the relevant jurisdiction and understand that you must be at...
  • Page 11 • Canadian Technical Support: techsupport.ca@hikvision.com • Need Help with This Product/Product Detail feature: inside.usa@hikvision.com • A&E partner inquiries (user registration, new project support, etc.): aepartners.usa@hikvision.com • HDP partner inquiries (user registration, new partner registration, etc.): partners.usa@hikvision.com • US Hikcentral Trial Version Request: sales.usa@hikvision.com •...

  • Page 12: Specifications

    Mandatory Electrical Requirements Hikvision requires the following conditions and equipment for all of its electronic equipment: • Grounding Ensure good conductivity for all ground paths; examine ground path contact surfaces for defects, dirt, corrosion, or non- conductive coatings that may impede conductivity. Repair or clean contact surfaces as necessary to assure good metal-to- metal contact.
  • Page 13 - Maintenance > Replace after a serious electrical event (e.g., lighting blew out a transformer down the street) > Replace yearly in storm-prone areas > Replace every two years as routine maintenance Symbol Conventions The symbols that may be found in this document are defined as follows.
  • Page 14 technical specifications for detailed information. • Do not connect several devices to one power adapter as adapter overload may cause overheating or a fire hazard. • Make sure that the plug is firmly connected into the power socket. • If smoke, odor, or noise rise from the device, turn off the power at once, unplug the power cable, and then contact the service center.
  • Page 15 Cautions Make sure the power supply voltage is correct before using the camera. Do not drop the camera or subject it to physical shock. Do not touch sensor modules with fingers. If cleaning is necessary, use a clean cloth with a bit of ethanol, and wipe it gently. If the camera will not be used for an extended period, replace the lens cap to protect the sensor from dirt.
  • Page 16 Table of Contents UM DS-2CCx2D9T-xxxx 022520NA (UD02874B-A)
  • Page 17 UM DS-2CCx2D9T-xxxx 022520NA (UD02874B-A)
  • Page 18 Introduction 1.1. Product Features The camera is applicable for both indoor and outdoor conditions, and the application scenarios include road, warehouse, underground parking lot, bar, etc.. The main features are as follows: • High performance CMOS sensor • 1080p resolution •...
  • Page 19 1.2. Overview of Type I Camera Figure 1, Type I Camera 1.3. Overview of Type II Camera Figure 2, Type II Camera UM DS-2CCx2D9T-xxxx 022520NA (UD02874B-A)
  • Page 20 1.4. Overview of Type III Camera Figure 3, Type III Camera 1.5. Overview of Type IV Camera Figure 4, Type IV Camera 1.6. Overview of Type V Camera Figure 5, Type V Camera UM DS-2CCx2D9T-xxxx 022520NA (UD02874B-A)

  • Page 21: Installation

    Installation 2.1. Before You Start Make sure that the device in the package is in good condition and all the assembly parts are included. Make sure that all the related equipment is powered off during the installation. Check the specification of the product for the installation environment.
  • Page 22 Figure 6, Type I Camera Drill Template Figure 7, Type II Camera Drill Template 3. Loosen the screws on the dome camera bubble to remove the bubble and black liner. 4. Attach the of type I camera back box/type II camera base plate to the ceiling and secure with supplied screws.
  • Page 23 Figure 8, Attach the Back Box/Base Plate The supplied screw package contains both self-tapping screws and expansion bolts. If the wall is concrete, expansion bolts are required to fix the camera. If the wall is wood, self-tapping screws are required. 5.
  • Page 24 Figure 9, Affix the Camera to the Ceiling 7. Connect the corresponding cables such as power cable and video cable. 8. Power on the camera to check if the image on the monitor is at an optimum angle. If not, adjust the camera according to the figure below to get an optimum angle.
  • Page 25 bubble of the dome camera to finish the installation. 2.2.2. Wall Mounting You need to purchase a wall mounting bracket separately if you use wall mounting. 1. Drill four screw holes in the wall according to the bracket holes. 2. Attach the bracket to the wall by aligning the four bracket screw holes with expansion screws on the wall.
  • Page 26 Figure 12, Attach Base Plate to Bracket 6. Route the cables through the bracket. 2.1.1 Ceiling Mounting steps 6 to 9 of to complete the Repeat installation. 2.2.3. In-Ceiling Mounting You need to purchase an in-ceiling mounting bracket separately if you use in-ceiling mounting. 1.
  • Page 27 Figure 13, In-Ceiling Mounting Bracket 5. Route the cables through the cable hole. 6. Attach the type I camera back box/type II camera base plate to the in-ceiling mounting bracket with the supplied screws. The supplied screw package contains both self-tapping screws and expansion bolts.
  • Page 28 2.2.4. In-Ceiling Mounting with Junction Box You need to purchase an in-ceiling mounting bracket separately if you use in-ceiling mounting with the junction box. Figure 15, Install the Bracket 2.1.3 In-Ceiling Mounting 1. Repeat steps 2 to 4 of the section to secure the in-ceiling mounting bracket (supplied) to the junction box.
  • Page 29 Figure 16, Affix Camera to Junction Box 2.1.1 Ceiling Mounting 4. Repeat steps 6 to 9 of the section to complete the installation. 2.2.5. Mounting with Inclined Base of Type I Camera You need to purchase an inclined base separately if mounting with an inclined base.
  • Page 30 Figure 17, Affix Inclined Base 3. Route the cables through the inclined base hole. 4. Attach the type I camera back box/type II camera base plate to the inclined base with the supplied screws. Figure 18, Affix Camera to Base 2.1.1 Ceiling Mounting 5.
  • Page 31 example in this section. Use the ceiling mounting steps as a reference for wall mounting. 1. Attach the drill template to the ceiling. 2. Drill the screw holes and cable hole (optional) on the ceiling according to the supplied drill template. Cable hole is required if using ceiling outlet to route the cable.
  • Page 32 Figure 20, Affix Camera to Ceiling 5. Connect the corresponding cables such as power cable and video cable. The supplied screw package contains both self-tapping screws and expansion bolts. If the wall is concrete, expansion bolts are required to affix the camera. If the wall is wood, self-tapping screws are required.
  • Page 33 Figure 21, Internal Interface and Button 8. Power on the camera to check if the image on the monitor is at an optimum angle. If not, adjust the surveillance angle. 1) Loosen the no.1 adjusting screw to adjust the pan position [0°...
  • Page 34 Figure 22, 3-Axis Adjustment 2.3.2. Mounting with Junction Box You need to purchase a junction box separately if mounting with a junction box. 1. Attach the drill template to the wall/ceiling. 2. Drill screw holes and cable hole in the wall/ceiling according to the drill template holes.
  • Page 35 Type IIICamera Type IVCamera Figure 23, Install Junction Box 5. Route the cables through the cable hole. 6. Secure the camera with M4 × 10 screws on the junction box. Figure 24, Wall/Ceiling Mounting with Junction Box 7. Repeat steps 5 to 6 of 2.2.1 Ceiling Mounting to install the camera to complete the installation.
  • Page 36 2.4. Type V Camera Installation 2.4.1. Ceiling Mounting 1. Disassemble the turret camera by rotating the camera to align the notch to one of the marks, as shown below. Figure 25, Disassemble the Camera 2. Remove the mounting base from the camera body with a flat object, e.g., a coin.
  • Page 37 Figure 26, Drill Template 4. Attach the mounting base to the ceiling and secure with supplied screws. Figure 27, Attach Mounting Base to Ceiling The supplied screw package contains both self-tapping screws and expansion bolts. If the wall is concrete, expansion bolts are required to affix the camera.
  • Page 38 Figure 28, Secure Camera with Mounting Base 7. Power on the camera to check that the image on the monitor is at an optimum angle. If not, adjust the camera according to the figure below to get an optimum angle. 1).
  • Page 39 2.4.2. Ceiling Mounting with Junction Box You need to purchase a junction box separately if you use ceiling mounting with a junction box. 1. Disassemble the junction box from the junction box cover. 2. Attach the drill template (supplied) to where you want to fix the junction box, and drill the holes in the ceiling according to the template.
  • Page 40 camera to the junction box. 2.4.3. Wall Mounting You need to purchase a wall mounting bracket separately if you use wall mounting. 1. Drill four screw holes in the wall according to the bracket holes. 2. Attach the bracket to the wall by aligning the bracket’s four screw holes with expansion screws on the wall.
  • Page 41 Figure 33, Attach Mounting Base to Bracket 2.3.1 Ceiling Mounting steps 5 to 7 of the section to Repeat complete the installation. 2.4.4. Mounting with Inclined Base You need to purchase an inclined base separately if you mount with an inclined base. 1.
  • Page 42 Figure 34, Drill Template 3. Disassemble the inclined base with the screwdriver. 4. Install the turret camera’s mounting base to the inclined base cover with three PM4 screws. Figure 35, Install Turret Camera Mounting Base 5. Install the inclined base body to the ceiling with four PA4×25 screws, as shown below.
  • Page 43 Figure 36, Affix Inclined Base Body 6. Attach the inclined base cover to its body with supplied screws. 2.3.1 Ceiling Mounting 7. Repeat steps 5 to 7 of the section to complete the installation. Figure 37, Affix Camera to Inclined Base UM DS-2CCx2D9T-xxxx 022520NA (UD02874B-A)

  • Page 44: Menu Operation

    Menu Operation Two methods are available to call the menu. This section takes method b) as an example to start the menu operation. A. Call the menu and adjust the camera parameters with a coaxial camera controller (purchase separately). B. Call the menu with a supported DVR/TVI DVR by clicking the button on the PTZ interface or by calling preset no.
  • Page 45 Figure 39, Menu Tree UM DS-2CCx2D9T-xxxx 022520NA (UD02874B-A)

  • Page 46: Smart Focus

    Camera type IV and type V do not support SMART FOCUS. 3.1. VIDEO OUT • PAL: (Phase Alternating Lines) is a color encoding system for analog television used in broadcast television systems in most countries. • NTSC: (National Television System Committee) is the analog television system that is used in most of North America, parts of South America, Myanmar, South Korea, etc.
  • Page 47 • LOW LIGHT: Applicable to environments with low light. Under this circumstance, slow shutter is ON by default to receive more light. 3.3.3. LENS The camera is equipped with a manual lens or a DC (auto iris) lens. Indoor mode and outdoor mode are available for the DC lens. Click IRIS SCAN to initialize the lens.
  • Page 48 If you select shutter as AUTO or 1/25, SENS-UP is adjustable (OFF/AUTO), and SENS-UP is disabled if any other shutter speed is selected. • AGC: A form of amplification where the camera will automatically boost the image output signal to optimize the image clarity in poor light conditions.
  • Page 49 weather or in high illumination, in which the dynamic range is lower than that in an ordinary environment, and the image always appears hazy. Enabling Defog can enhance subtle details so that the image appears clearer. Set Defog to ON to enable the function. Position, size, and the defog gradation are configurable.
  • Page 50 define the BLC area. - DEFAULT: Restore the BLC settings to the default. Figure 42, BLC • HLC (High Light Compensation): Masks strong light sources that usually flare across a scene. HLC makes it possible to see the image details that would normally be hidden. - GAIN: The HLC gain can be set to High, Middle, or Low.
  • Page 51 Figure 43, HLC • WDR (Wide Dynamic Range): Balances the brightness level of the whole image, and provide the clear image with details. - GAIN: Set the gain of WDR as high, middle, or low. The higher the gain, the clearer the image. - WDR BRIGHT: You can set the value from 0 to 60.

  • Page 52: White Balance

    3.3.6. WHITE BALANCE White balance is the camera’s white rendition function to adjust the color temperature according to the environment. It can remove unrealistic color casts in the image. MANUAL, ATW (Auto-Tracking White Balance), and AWC→SET are selectable. • Manual: Adjusts the white balance by customizing the BLUE and RED value, which range from 1 to 100.
  • Page 53 • D-EFFECT: OFF, MIRROR, V-FLIP, and ROTATE are selectable for the mirror. • OFF: The mirror function is disabled. • MIRROR: The image flips 180 degrees horizontally. • V-FLIP: The image flips 180 degrees vertically. • ROTATE: The image flips 180 degrees both horizontally and vertically.
  • Page 54 Figure 46, Motion • PRIVACY: The privacy mask allows you to cover certain areas that you don’t want to be viewed or recorded. Up to eight privacy areas are configurable. Figure 47, Privacy 1. Select a PRIVACY area. 2. Set the DISPLAY status as INV, MOSAIC, COLOR, or OFF. 3.
  • Page 55 - When the input voltage is 30 percent higher than the calibrated voltage, OVERVOLTAGE flashes on the screen. Camera type IV and type V do not support VOLTAGE DETECTION. • DEFECT: Defective pixels in digital camera CCD or CMOS image sensors fail to sense light levels correctly.
  • Page 56 3.3.9. ADJUST In the Adjust sub-menu, you can configure settings including sharpness, image quality on monitor, and LSC (lens shading compensation). Move the cursor to ADJUST and click Iris+ to enter the adjust configuration interface. Figure 49, Adjust • SHARPNESS: Determines the amount of detail an imaging system can reproduce.
  • Page 57 The current can pick up a high frequency oscillating signal from the surroundings and carry it into the camera, causing interference. To remedy this, Hikvision began including the following items with select cameras since June 2019: • Select Dual-Voltage Cameras: 24 VAC to 12 VDC power converter/filter •...
  • Page 58 4.1. Power Filter Use If your video signal displays power line interference (horizontal lines moving across the screen), install the included power filter to eliminate or minimize the interference. Place the power filter between the camera and the leads/ connectors coming out of the power supply. Figure 50, Dual-Voltage Camera Converter/Filter Figure 51, DC Camera Filter •...
  • Page 59 Cameras manufactured prior to June 2019 did not ship with a (converter)/filter. Hikvision will ship filter(s) to you free of charge, if needed. Send e-mail to Hikvision Customer Service at cust.usa@hikvision.com, provide the camera model number, serial number, place of purchase, and shipping address.
  • Page 60 UM DS-2CCx2D9T-xxxx 022520NA (UD02874B-A)
