Compact inverter

Advertisement

Quick Links

Compact Inverter
Single-phase 100 V series: FRN0001 to 0005C2S-6U
Thank you for purchasing our FRENIC-Mini series of inverters.
• This manual is a supplement to the FRENIC-Mini Instruction Manual (INR-SI47-1729-E,
INR-SI47-1745-E). It describes the FRENIC-Mini output ratings (Inverter types FRN_ _ _
_C2S-6U) and basic connection. For other descriptions, refer to the original manual.
• Improper handling might result in incorrect operation, a short life, or even a failure of this
product as well as the motor.
• Deliver this manual to the end user of this product. Keep this manual in a safe place until this
product is discarded.
Fuji Electric Co., Ltd.
Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com
Supplement to Single-phase 100 V Input Series
Instruction Manual
INR-SI47-1839-E

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRENIC-Mini 100 V Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Fuji Electric FRENIC-Mini 100 V Series

  • Page 1 • Deliver this manual to the end user of this product. Keep this manual in a safe place until this product is discarded. Fuji Electric Co., Ltd. INR-SI47-1839-E Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com...
  • Page 2 Chapter 2 MOUNTING AND WIRING OF THE INVERTER 2.3.2 Terminal arrangement and screw specifications (1) Arrangement of the main circuit terminals Table 2.3 Main Circuit Terminals Power Nominal Tightening Terminal supply applied motor Inverter type torque Refer to: screw size voltage (HP) (lb-in)
  • Page 3 2.3.5 Wiring for main circuit terminals and grounding terminals Inverter output terminals, U, V, W and grounding terminal ( G) 1) Connect the three wires of the three-phase motor to terminals U, V, and W, aligning phases each other. 2) Connect the grounding wire of terminals U, V, and W to the grounding terminal ( 3) If the cable from the inverter to the motor is very long, a high-frequency current may be generated by stray capacitance between the cables and result in an overcurrent trip of the inverter, an increase in leakage current, or a reduction in current indication precision.
  • Page 4 Chapter 5 FUNCTION CODES This chapter sets forth function codes whose setting ranges differ according to the input voltage for the single-phase 100 V class series (FRN-_ _ _ _C2S-6U). 5.1 Function Code Tables Change Refer Incre- Data Default Code Name Data setting range Unit...
  • Page 5 Table A Fuji Standard Motor Parameters Nominal rated Nominal rated Fuji's standard current of capacity of Nominal torque boost Power Fuji standard motor Fuji standard motor applied supply Inverter type (kW) motor voltage (HP) Function code Function code Function code F09/A05 F11/A07/E34/E37 P02/A16...
  • Page 6 Analog Output [FMA] (Voltage adjustment) Analog Output [FMA] (Function) Voltage adjustment (F30) for single-phase 100 V class series Outputting the output current in an analog format (FMA) (F31 = 2) The analog output terminal [FMA] outputs 10 V, that is, 200% of the reference current I (A), supposing the output gain selected with F30 as 100%.
  • Page 7 F43, F44 Current Limiter (Mode selection, Level) Level (F44) for single-phase 100 V class series The limiting level setting should be calculated from the current limiting level I limit based on the reference current I (A), as shown below. limit Setting (Example) Setting the current limiting level I at 4.2 A for 1 HP standard motors...
  • Page 8 Chapter 8 SPECIFICATIONS 8.1 Standard Models 8.1.4 Single-phase 100 V class series Item Specifications Type (FRN_ _ _ _C2S-6U) 0001 0002 0003 0005 Nominal applied motor (HP) *1 Rated capacity (kVA) *2 0.26 0.53 0.95 Rated voltage (V) *3 Three-phase, 200 to 240 V (with AVR function) Rated current (A) 150% of rated output current for 1 min or Overload capability...
  • Page 9 8.3 Terminal Specifications 8.3.2 Connection diagram in operation by external signal inputs * With a built-in terminating resistor switch (Note 1) Install a recommended molded case circuit breaker (MCCB) or a residual-current-operated protective device (RCD)/earth leakage circuit breaker (ELCB) (with overcurrent protection) in the primary circuit of the inverter to protect wiring.
  • Page 10 8.4 External Dimensions 8.4.1 Standard models Unit: inch [mm] Dimensions Power inch [mm] supply Inverter type voltage FRN0001C2S-6U 3.94 0.39 Single- [100] [10] FRN0002C2S-6U 3.54 phase [90] 0.98 4.53 100 V FRN0003C2S-6U [115] [25] Dimensions Power inch [mm] supply Inverter type voltage Single- 5.47...
  • Page 11 8.5 Protective Functions Alarm Name Description monitor output displays [30A,B,C] Overvoltage The inverter stops the inverter output upon During protection detecting an overvoltage condition (400 VDC for acceleration three-phase 200 V, single-phase 200 V, and During single -phase 100 V class series; 800 VDC for deceleration three -phase 400 V class series) in the DC link During running...
  • Page 12 Chapter 9 LIST OF PERIPHERAL EQUIPMENT AND OPTIONS Name of peripheral Function and application equipment Molded case MCCBs are designed to protect the power circuits between the power control circuit breaker board and inverter’s main terminals (L1/R, L2/S and L3/T for three-phase (MCCB) power, L1/L and L2/N for single-phase power) from overload or short-circuit which in turn prevents secondary disasters caused by the inverter...
  • Page 13 Chapter 10 APPLICATION OF DC REACTORS (DCRs) Since the "Japanese Guideline for Suppressing Harmonics in Home and General-purpose Appliances" issued by the Ministry of International Trade and Industry (Currently the Ministry of Economy, Trade and Industry) was revised in January 2004, the general-purpose inverters have no longer been subject to the guideline.
  • Page 14 Chapter 11 COMPLIANCE WITH STANDARDS 11.1 Compliance with UL Standards and Canadian Standards (cUL certification) 11.1.1 General Originally, the UL standards were established by Underwriters Laboratories, Inc. as private criteria for inspections/investigations pertaining to fire/accident insurance in the USA. Later, these standards were authorized as the official standards to protect operators, service personnel and the general populace from fires and other accidents in the USA.
  • Page 15 Conformity to UL standards and Canadian standards (cUL certification) (Continued) 5. Install UL certified fuses rated 600 Vac between the power supply and the inverter, referring to the table below. Required torque Wire size Ib-in (N·m) AWG or kcmil (mm Power Control circuit Control circuit...
  • Page 16 In no event will Fuji Electric Co., Ltd. be liable for any direct or indirect damages resulting from the application of the information in this manual.
