NextGen AIO D1150 Display
Operator Manual
01750348355 C
Customer/Partner Use
This document is property of Diebold Nixdorf and is intended for customer/partner use. A written
license agreement with Diebold Nixdorf is not required to use this material.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NextGen AIO D1150 and is the answer not in the manual?

Questions and answers

Related Manuals for DIEBOLD NIXDORF NextGen AIO D1150

Summary of Contents for DIEBOLD NIXDORF NextGen AIO D1150

  • Page 1 NextGen AIO D1150 Display Operator Manual 01750348355 C Customer/Partner Use This document is property of Diebold Nixdorf and is intended for customer/partner use. A written license agreement with Diebold Nixdorf is not required to use this material.

  • Page 2: Table Of Contents

    Installing system to the stand (with cable covers) ..........8-4 Connecting the display.......................8-8 9 Ergonomic Terminal Workplace ....................9-1 10 Technical data ..........................10-1 10.1 Dimensions (mm) .......................10-2 10.2 Projected Capacitive Touch Screen...................10-3 10.3 Supported resolution ......................10-3 Copyright © 2022, Diebold Nixdorf 01750348355 C...

  • Page 3: Manufacturer's Declaration And Approval

    Repair work on the devices should only be carried out by authorized and specially trained personnel. Improper repairs will lead to the loss of any guarantee and liability claims. Extension boards with electrostatically endangered components can be identified with this label. Copyright © 2022, Diebold Nixdorf 01750348355 C...
  • Page 4 DIN VDE 0100, part 540, Appendix C2, as well as EN50174-2, §5.4.3. Warranty Diebold Nixdorf guarantees generally a warranty engagement for 12 months beginning with the date of delivery. This warranty engagement covers all those damages which occur despite a normal use of the product.
  • Page 5 There are still some parts that are not reusable. Diebold Nixdorf guarantees the environmentally safe disposal of these parts in a Recycling Center, which is certified pursuant to ISO 9001 and ISO 14001.

  • Page 6: Supplier's Declaration Of Conformity

    2 Supplier’s Declaration of Conformity Product Description: LCD Monitor Model: Display D1150, Display D1150 /pc-touch Party issuing Supplier’s Declaration of Conformity Diebold Nixdorf Singapore PTE. LTD. 30A Kallang Place, #04-01 Singapore 339213 Phone: +65 6747 3828 Responsible Party – U.S. Contact Information...

  • Page 7: Introduction

    There is also a non-touch version available. The D1150 features the unique Diebold Nixdorf PanelLink2™ interface. This allows for operation of the displays via a single cable solution. In addition, the screen also offers standard interfaces such as DVI-D and USB-C DP.

  • Page 8: About This Manual

    Same parts of this book require familiarity and experience in working with operating systems and instal- lation and configuration procedures. NOTE Notes in the manual are marked by this symbol. WARNING This symbol is used for warnings. Copyright © 2022, Diebold Nixdorf 01750348355 C...

  • Page 9: Display Overview

    1024x768 pixels. Application programs should use this resolution. Touch screen per model Model Screen Size Touch Screen Display D1150 /pc-touch 15” Projected Capacitive Touch Display D1150 15” No Touch, Protective Glass Copyright © 2022, Diebold Nixdorf 01750348355 C...

  • Page 10: User Interfaces

    LED on; green Stanby / No video input LED on; white, dimmed bright- LED blinking; amber ness Soft-Off LED on; white, dimmed bright- LED on; amber ness No power input LED off LED off Copyright © 2022, Diebold Nixdorf 01750348355 C...
  • Page 11 When the D1150 is connected via PLINK2™ interface to a BEETLE system, the button also switches the system on or off, provided that the system supports the feature. See section Display Settings / RMT en- able/disable for details. Copyright © 2022, Diebold Nixdorf 01750348355 C...

  • Page 12: Connector Panel

    USB connection to the PC system. NOTE For BEETLE systems with PLINK2 interface, a PLINK2 cable can be used to as a single wire interface to supply power, video and data signal to the display. Copyright © 2022, Diebold Nixdorf 01750348355 C...

  • Page 13: On-Screen Display (Osd)

    The adjustments will be saved in each way. There are a number of parameters that can be set via the OSD menu. Please refer to the table on the next page for details. Copyright © 2022, Diebold Nixdorf 01750348355 C...

  • Page 14: Display Settings

    The OSD can be locked by pressing and holding the menu button for approx. 6 seconds. The display shows a message on the screen that the OSD is now locked. OSD lock OSD Unlock Copyright © 2022, Diebold Nixdorf 01750348355 C...

  • Page 15: Rmt Enable/Disable

    System no reaction; Display remains off. System no reaction; Display switches off. NOTE 1 For FW 2.10 onwards. For information about the power button behavior of previous FW versions, please contact a Diebold Nixdorf sales representative. Copyright © 2022, Diebold Nixdorf 01750348355 C...

  • Page 16: Power Button - Lock/Unlock

    If the power button is locked, the user cannot manually switch the display on or off. NOTE If RMT is enabled, power button will initiate RMT signal to host system but will not switch the display off. Copyright © 2022, Diebold Nixdorf 01750348355 C...

  • Page 17: Touch Technologies

    Dampen the cloth slightly and then clean the screen. NOTE A wrong maintenance may cause damages to the screen, which are not covered by guarantee or warranty. Copyright © 2022, Diebold Nixdorf 01750348355 C...

  • Page 18: Initial Setup

    Lf damage has occurred during shipping or if the package contents do not match the delivery note, immediately inform your Diebold Nixdorf sales outlet. Transport the device only in its original packaging (to protect it against impact and shock).
  • Page 19 Installing system to the stand Fit the system on the stand while holding it in place. Tighten the 4 M4x6 countersunk screws (1) (that came with the stand) to secure the sys- tem to the stand. Copyright © 2022, Diebold Nixdorf 01750348355 C...
  • Page 20 Remove the cable cover (1). Plug the USB-C cable into the port indicated (1). Replace the cable cover. Tilt the system back to its operating position. Replace the VESA cover (1) by pushing it upwards. Copyright © 2022, Diebold Nixdorf 01750348355 C...

  • Page 21: Installing System To The Stand (With Cable Covers)

    *Observe the safety precaution mentioned on the next page when you remove the back cover of stand. WARNING To avoid damage to the back cover of the stand, be careful of how you would remove it. Copyright © 2022, Diebold Nixdorf 01750348355 C...
  • Page 22 Installing system to the stand Fit the system on the stand while holding it in place. Tighten the 4 M4x6 countersunk screws (1) (that came with the stand) to secure the sys- tem to the stand. Copyright © 2022, Diebold Nixdorf 01750348355 C...
  • Page 23 Remove the cable cover (1) at the bottom of the system display. Plug the USB-C cable into the port indicated (1). Route the cables from the connector panel in the path as illustrated (arrows). Replace the cable cover previously removed. Copyright © 2022, Diebold Nixdorf 01750348355 C...
  • Page 24 Tilt the system back to its operating position Tug the cables neatly into their respective cable channels as illustrated (arrows). NOTE The arrow paths are for illustration pur- pose only and are not meant to be ex- haustive. Copyright © 2022, Diebold Nixdorf 01750348355 C...

  • Page 25: Connecting The Display

    11. Align the back cable cover (1) with the front cable cover (2). 12. Replace back cable cover (1) by sliding it up- wards. Connecting the display NOTE Before connecting cables switch off the system and disconnect it from the main supply. Copyright © 2022, Diebold Nixdorf 01750348355 C...

  • Page 26: Ergonomic Terminal Workplace

    Avoid reflective glaring caused by electric light sources. Position the screen within a preferred and permit- ted range of vision, so that you can look vertically Preferred range of vision onto the screen. Preferred range of vision Copyright © 2022, Diebold Nixdorf 01750348355 C...

  • Page 27: Technical Data

    Horizontal angle 85 °/ 85 ° Vertical 350 cd/ m Brightness Projected Capacitive 350 cd/ m Non-Touch 1000:1 Contrast Projected Capacitive 1000:1 Non-Touch Backlight 7,8 W Power Typical consumption 13 W Maximum Copyright © 2022, Diebold Nixdorf 10-1 01750348355 C...

  • Page 28: Dimensions (Mm)

    Technical data 10.1 10.1 Dimensions (mm) D1150 with wall mount D1150 with stand Copyright © 2022, Diebold Nixdorf 10-2 01750348355 C...

  • Page 29: Projected Capacitive Touch Screen

    720 x 400 70Hz 31.467 70.080 640 x 480 60Hz 31.469 59.940 SVGA 800 x 600 60Hz 37.879 60.317 1024 x 768 (Native) 60Hz 48.363 60.004 WXGA 1280 x 720 60Hz 45.000 60.000 Copyright © 2022, Diebold Nixdorf 10-3 01750348355 C...
  • Page 30 International Organization for Standardization Liquid Cristal Display Light Emitting Diode LVDS Low Voltage Differential Signal On Screen Display Point Of Sales SVGA Super Video Graphics Array Thin Film Transistor Technology (LCD Technol- ogy) Underwriters Laboratory (standards) Copyright © 2022, Diebold Nixdorf 01750348355 C...
  • Page 31 DIEBOLD NIXDORF, Incorporated 50 Executive Pkwy | PO Box 2520 | Hudson, OH 44236 | USA © 2022 Diebold Nixdorf, Incorporated. All Rights Reserved.
