- Page 1 NextGen AIO D1104 Display User Manual 01750351847A...
-
Page 2: Table Of Contents
Preparing the display ..................8-2 8.2.3 Installing the stand ....................8-3 Connecting the display.......................8-4 9 Ergonomic Terminal Workplace ....................9-1 10 Technical data ..........................10-1 10.1 Dimensions (mm) .......................10-2 10.2 Projected Capacitive Touch Screen...................10-3 10.3 Supported resolution ......................10-3 Copyright © 2021, Diebold Nixdorf 01750351847A... -
Page 3: Manufacturer's Declaration And Approval
CAN ICES-3 (A)/NMB-3 (A) Tested safety The Display D1104 /pc-touch has been awarded the cULus symbol. User information Repair work on the devices should only be carried out by authorized and specially trained personnel. Improper repairs will lead to the loss of any guarantee and liability claims. - Page 4 File owner or brand owner further information. Warranty Diebold Nixdorf guarantees generally a warranty engagement for 12 months beginning with the date of delivery. This warranty engagement covers all those damages which occur despite a normal use of the product.
- Page 5 There are still some parts that are not reusable. Diebold Nixdorf guarantees the environmentally safe disposal of these parts in a Recycling Center, which is certified pursuant to ISO 9001 and ISO 14001.
-
Page 6: Supplier's Declaration Of Conformity
2 Supplier’s Declaration of Conformity Product Description: LCD Monitor Model: Display D1104, Display D1104 /pc-touch Party issuing Supplier’s Declaration of Conformity Diebold Nixdorf Singapore PTE. LTD. 30A Kallang Place, #04-01 Singapore 339213 Phone: +65 6747 3828 Responsible Party – U.S. Contact Information... -
Page 7: Introduction
• a desk terminal. The low-energy and flicker-free color monitor of the D1104 is a LCD in TFT-technology (Thin Film Tran- sistor). Therefore, it is well suited for multimedia applications as it offers brilliant color representation, an excel- lent contrast ratio and a high display speed. -
Page 8: About This Manual
This manual informs you about everything you might need to know for the installation (software and hardware), the operation and the maintenance of your D1104. Same parts of this book require familiarity and experience in working with operating systems and instal- lation and configuration procedures. -
Page 9: Display Overview
800 x 600 pixels. Application programs should use this resolution. Touch screen per model Model Screen Size Touch Screen Display D1104 /pc-touch 10.4” Projected Capacitive Touch Display D1104 10.4” No Touch, Protective Glass Copyright © 2021, Diebold Nixdorf 01750351847A... -
Page 10: User Interfaces
If the display is manually switched off, it will not wake up automatically when the system boots. When the D1104 is connected via PLINK2™ interface to a BEETLE system, the button also switches the system on or off, provided that the system supports the feature. See section Display Settings / RMT en- able/disable for details. -
Page 11: Connector Panel
DVI-D or PLINK 2 for video/data transfer between the system and the TFT dis- play. NOTE For BEETLE systems with PLINK2 interface, a PLINK2 cable can be used to as a single wire interface to supply power, video and data signal to the display. Copyright © 2021, Diebold Nixdorf 01750351847A... -
Page 12: On Screen Display (Osd)
OSD to time-out (saves changes and exit). The adjustments will be saved in each way. There are a number of parameters that can be set via the OSD menu. Please refer to the table on the next page for details. Copyright © 2021, Diebold Nixdorf 01750351847A... -
Page 13: Display Settings
6 Display settings The D1104 display offers several settings which are available through the OSD. Below you can find a list of specific factory defaul settings that can be customized in order to suit the specific installation needs. OSD lock/unlock Per default the OSD is accessible to the end user, allowing user to make changes to the display settings. -
Page 14: Power Button - Lock/Unlock
NOTE 1 For FW 1.06 onwards. For information about the power button behavior of previous FW versions, please contact a Diebold Nixdorf sales representative. Power button – lock/unlock The power button is unlocked by default. The user can switch the display on and off discretely, indepen- dent of the connected host system. -
Page 15: Touch Technologies
Dampen the cloth slightly and then clean the screen. NOTE A wrong maintenance may cause damages to the screen, which are not covered by guar- antee or warranty. Copyright © 2021, Diebold Nixdorf 01750351847A... -
Page 16: Initial Setup
If damage has occurred during shipping or if the package contents do not match the delivery note, immediately inform your Diebold Nixdorf sales outlet. Transport the device only in its original packaging (to protect it against impact and shock). -
Page 17: Preparing The Display
Plug in cables (1) and (2). Place back the cable cover (1) at the bottom of the display. Pull the cable through the opening of the ca- ble cover. Copyright © 2021, Diebold Nixdorf 01750351847A... -
Page 18: Installing The Stand
Fit the 2 screws (that were previously tight- ened halfway through) to the two holes on the frame of the stand (1). Tighten the two Torx screws (1) to secure the display to the stand. Replace the back cover (1). Copyright © 2021, Diebold Nixdorf 01750351847A... -
Page 19: Connecting The Display
Setup is complete. NOTE When uninstalling the stand always make sure that all cables are disconnected. Connecting the display NOTE Before connecting cables switch off the system and disconnect it from the main supply. Copyright © 2021, Diebold Nixdorf 01750351847A... -
Page 20: Ergonomic Terminal Workplace
Avoid reflective glaring caused by electric light sources. Position the screen within a preferred and permit- ted range of vision, so that you can look vertically Preferred range of vision onto the screen. Preferred range of vision Copyright © 2021, Diebold Nixdorf 01750351847A... -
Page 21: Technical Data
Viewing right/left angle 60 °/ 70 ° top/bottom 350 cd/ m Brightness Projected Capacitive 350 cd/ m Non-Touch 700:1 Contrast Projected Capacitive 700:1 Non-Touch Backlight 4.6 W Power Typical consumption 5.8 W Maximum Copyright © 2021, Diebold Nixdorf 10-1 01750351847A... -
Page 22: Dimensions (Mm)
Technical data 10.1 10.1 Dimensions (mm) D1104 Copyright © 2021, Diebold Nixdorf 10-2 01750351847A... -
Page 23: Projected Capacitive Touch Screen
Horizontal Sync Vertical Sync Frequency (KHz) Frequency (Hz) 720 x 400 70Hz 31.47 70.09 640 x 480 60Hz 31.50 60.00 SVGA 800 x 600 (Native) 60Hz 37.88 60.32 1024 x 768 60Hz 48.36 60.00 Copyright © 2021, Diebold Nixdorf 10-3 01750351847A... - Page 24 Low Voltage Differential Signal On Screen Display Point Of Sales SVGA Super Video Graphics Array Thin Film Transistor Technology (LCD Tech- nology) Underwriters Laboratory (standards) Universal Serial Bus Verband Deutscher Elektrotechniker (German Electricians Association) Copyright © 2021, Diebold Nixdorf 01750351847A...
- Page 25 DIEBOLD NIXDORF 5995 Mayfair Road | North Canton, OH 44720 | United States © 2021 Diebold Nixdorf, Incorporated. All Rights Reserved.
