NextGen AIO D1104 Display
Operator Manual
01750351847 B
Customer/Partner Use
This document is property of Diebold Nixdorf and is intended for customer/partner use. A written
license agreement with Diebold Nixdorf is not required to use this material.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NextGen AIO D1104 and is the answer not in the manual?

Questions and answers

Related Manuals for DIEBOLD NIXDORF NextGen AIO D1104

Summary of Contents for DIEBOLD NIXDORF NextGen AIO D1104

  • Page 1 NextGen AIO D1104 Display Operator Manual 01750351847 B Customer/Partner Use This document is property of Diebold Nixdorf and is intended for customer/partner use. A written license agreement with Diebold Nixdorf is not required to use this material.

  • Page 2: Table Of Contents

    Preparing the display ..................8-4 8.2.3 Installing the stand ....................8-6 Connecting the display.......................8-7 9 Ergonomic Terminal Workplace ....................9-1 10 Technical Data..........................10-1 10.1 Dimensions ........................10-2 10.2 Projected Capacitive Touch Screen...................10-3 10.3 Supported resolution ......................10-3 Copyright © 2022, Diebold Nixdorf 01750351847 B...

  • Page 3: Manufacturer's Declaration And Approval

    Repair work on the devices should only be carried out by authorized and specially trained personnel. Improper repairs will lead to the loss of any guarantee and liability claims. Extension boards with electrostatically endangered components can be identified with this label. Copyright © 2022, Diebold Nixdorf 01750351847 B...
  • Page 4 File owner or brand owner further information. Warranty Diebold Nixdorf guarantees generally a warranty engagement for 12 months beginning with the date of delivery. This warranty engagement covers all those damages which occur despite a normal use of the product.
  • Page 5 There are still some parts that are not reusable. Diebold Nixdorf guarantees the environmentally safe disposal of these parts in a Recycling Center, which is certified pursuant to ISO 9001 and ISO 14001.

  • Page 6: Supplier's Declaration Of Conformity

    2 Supplier’s Declaration of Conformity Product Description: LCD Monitor Model: Display D1104, Display D1104 /pc-touch Party issuing Supplier’s Declaration of Conformity Diebold Nixdorf Singapore PTE. LTD. 30A Kallang Place, #04-01 Singapore 339213 Phone: +65 6747 3828 Responsible Party – U.S. Contact Information...

  • Page 7: Introduction

    There is also a non-touch version available. The D1104 features the unique Diebold Nixdorf PanelLink2™ interface. This allows for operation of the displays via a single cable solution. In addition, the screen also offers standard interfaces such as DVI-D and USB-C DP.

  • Page 8: About This Manual

    Same parts of this book require familiarity and experience in working with operating systems and instal- lation and configuration procedures. NOTE Notes in the manual are marked by this symbol. WARNING This symbol is used for warnings. Copyright © 2022, Diebold Nixdorf 01750351847 B...

  • Page 9: Display Overview

    The LCD TFT Panel Display is a 10.4-inch flat panel display which is absolutely flicker-free. lt is de- signed for a native resolution of 800 x 600 pixels. Application programs should use this resolution. Copyright © 2022, Diebold Nixdorf 01750351847 B...

  • Page 10: Touch Screen Per Model

    Display overview Touch screen per model Model Screen Size Touch Screen Display D1104 /pc-touch 10.4” Projected Capacitive Touch Display D1104 10.4” No Touch, Protective Glass Copyright © 2022, Diebold Nixdorf 01750351847 B...

  • Page 11: User Interfaces

    LED on; green Stanby / No video input LED on; white, dimmed bright- LED blinking; amber ness Soft-Off LED on; white, dimmed bright- LED on; amber ness No power input LED off LED off Copyright © 2022, Diebold Nixdorf 01750351847 B...
  • Page 12 When the D1104 is connected via PLINK2™ interface to a BEETLE system, the button also switches the system on or off, provided that the system supports the feature. See section Display Settings / RMT en- able/disable for details. Copyright © 2022, Diebold Nixdorf 01750351847 B...

  • Page 13: Connector Panel

    DVI-D or PLINK 2 for video/data transfer between the system and the TFT dis- play. NOTE For BEETLE systems with PLINK2 interface, a PLINK2 cable can be used to as a single wire interface to supply power, video and data signal to the display. Copyright © 2022, Diebold Nixdorf 01750351847 B...

  • Page 14: On Screen Display (Osd)

    The adjustments will be saved in each way. There are a number of parameters that can be set via the OSD menu. Please refer to the table on the next page for details. Copyright © 2022, Diebold Nixdorf 01750351847 B...

  • Page 15: Display Settings

    System starts booting; Display switches on by system. System starts shutdown; Display switches off when system shutdown is completed. RMT disabled System starts booting; Display switches on by system. System no reaction; Display switches off. Copyright © 2022, Diebold Nixdorf 01750351847 B...

  • Page 16: Power Button - Lock/Unlock

    NOTE 1 For FW 1.06 onwards. For information about the power button behavior of previous FW versions, please contact a Diebold Nixdorf sales representative. Power button – lock/unlock The power button is unlocked by default. The user can switch the display on and off discretely, indepen- dent of the connected host system.

  • Page 17: Touch Technologies

    Dampen the cloth slightly and then clean the screen. NOTE A wrong maintenance may cause damages to the screen, which are not covered by guarantee or warranty. Copyright © 2022, Diebold Nixdorf 01750351847 B...

  • Page 18: Initial Setup

    If damage has occurred during shipping or if the package contents do not match the delivery note, immediately inform your Diebold Nixdorf sales outlet. Transport the device only in its original packaging (to protect it against impact and shock).
  • Page 19 4. Remove the lower back cover from the stand. 1 1 1 Figure 8-2: Removing the lower back cover 5. Feed all for your interface required cables (2) through the lower opening of the stand (1). Figure 8-3: Manage cabling through the stand Copyright © 2022, Diebold Nixdorf 01750351847 B...
  • Page 20 7. Feed all for your interface required cables (2) through the opening of the lower back cover (3) and the lower opening in the stand. Figure 8-4: Manage cabling through the lower back cover Copyright © 2022, Diebold Nixdorf 01750351847 B...

  • Page 21: Preparing The Display

    – the 12V Power cable to the DC-port (1), the DVI-D cable to the DVI-port (3) and the USB-C to USB-A cable to the USB-C port (2). Figure 8-6: Attaching all cables to the display Copyright © 2022, Diebold Nixdorf 01750351847 B...
  • Page 22 Initial setup 6. Mount the cable cover (1) to the display. Figure 8-7: Mounting the cable cover Copyright © 2022, Diebold Nixdorf 01750351847 B...

  • Page 23: Installing The Stand

    2. Tighten the screws (2). Figure 8-8: Attaching the display to the stand 3. Secure the lower back cover (1) with screws (2). 2 2 2 Figure 8-9: Mounting the lower back cover to the stand Copyright © 2022, Diebold Nixdorf 01750351847 B...

  • Page 24: Connecting The Display

    NOTE When uninstalling the stand, always make sure that all cables are disconnected. Connecting the display NOTE Switch off the system and disconnect it from the mains supply before connecting the ca- bles. Copyright © 2022, Diebold Nixdorf 01750351847 B...

  • Page 25: Ergonomic Terminal Workplace

    Avoid reflective glaring caused by electric light sources. Position the screen within a preferred and permit- ted range of vision, so that you can look vertically Preferred range of vision onto the screen. Preferred range of vision Copyright © 2022, Diebold Nixdorf 01750351847 B...

  • Page 26: Technical Data

    60 °/ 70 ° top/bottom 350 cd/ m Brightness Projected Capacitive 350 cd/ m Non-Touch 700:1 Contrast Projected Capacitive 700:1 Non-Touch Backlight 4.6 W Power Typical consumption 5.8 W Maximum Copyright © 2022, Diebold Nixdorf 10-1 01750351847 B...

  • Page 27: Dimensions

    Technical Data 10.1 10.1 Dimensions Copyright © 2022, Diebold Nixdorf 10-2 01750351847 B...

  • Page 28: Projected Capacitive Touch Screen

    Vertical Sync Frequency (KHz) Frequency (Hz) 720 x 400 70Hz 31.47 70.09 640 x 480 60Hz 31.50 60.00 SVGA 800 x 600 (Native) 60Hz 37.88 60.32 1024 x 768 60Hz 48.36 60.00 Copyright © 2022, Diebold Nixdorf 10-3 01750351847 B...
  • Page 29 International Organization for Standardization Liquid Cristal Display Light Emitting Diode LVDS Low Voltage Differential Signal On Screen Display Point Of Sales SVGA Super Video Graphics Array Thin Film Transistor Technology (LCD Technol- ogy) Underwriters Laboratory (standards) Copyright © 2022, Diebold Nixdorf 01750351847 B...
  • Page 30 DIEBOLD NIXDORF, Incorporated 50 Executive Pkwy | PO Box 2520 | Hudson, OH 44236 | USA © 2022 Diebold Nixdorf, Incorporated. All Rights Reserved.
