Operator panel
The heat system is controlled by an operator panel with a display that shows operational information. A keypad is used for user interac-
tion, that is selecting functions, navigating the menu system, and for parameter value settings. When the heat pump is turned on, the
display shows the operational mode and the water temperatures. The default setting is house heating/DHW AUTO mode. For more in-
formation about the operator panel, see description in the user manual.
C
Fig. 11: Layout of operator panel
Danfoss Heating Solutions
DHP-AT
1
2
3
4
1
C
2
3
4
Information symbols
Indicator
Power ON/OFF button
Keypad
VMGFI302
27
