ADIC FastStor 22 Quick Start Manual

For summary of common operations
consult the KEYPAD OPERATIONS
inside the FastStor 22 door.
Selected Indicators and Controls
Buttons
Press MODE to select operations,
or to clear error condition.
Press NEXT/PREVIOUS to view
options within a selected mode.
Press SELECT to execute an
operation or to move to next menu
level.
LEDs
ALARM LED indicates error
condition.
ACTIVITY LED indicates Loader
or Drive activity.
POWER LED indicates Power
is on.
LCD
DC on LCD indicates compression
DC
mode.
WP on LCD indicates write-
WP
protected tape.
CT on LCD indicates cleaning
CT
tape loaded or drive cleaning
required.
label
Advanced Digital Information Corporation
11431 Willows Road NE Redmond, WA 98052
World-Wide Web: http: //www.adic.com
In the United States and Canada, call ADIC Technical Assistance Center
In Europe, call ADIC Technical Assistance Center
Copyright Advanced Digital Information Corporation, 1999
Document Number 62-2204-01 rev B
FastStor
FastStor 22

Quick Start

Guide
FastStor
Corporate Headquarters
TM
Telephone: (425) 881-8004
Fax: (425) 881-2296
ADIC Europe
ZAC des Basses Auges
1, rue Alfred de Vigny
Follow the steps in this guide to
78112 -Fourqueux, FRANCE
Telephone: 33 (0)1 30 87 53 00
quickly get started using your
Fax: 33 (0)1 30 87 53 01
FastStor 22
For Customer Assistance:
(ATAC) at 1-800-827-3822
(ATAC) at 00.800.9999.3822
