- Page 1 Installation and Operating Guide FastStor & FastStor 22 Barcode Reader Module Document 62-0135-01 Rev B, Copyright © ADIC 1998, 1999, 2000...
-
Page 2: Table Of Contents
Table of Contents Equipment Description ... 1 FastStor Barcode Reader Module Installation ... 2 FastStor 22 Barcode Reader Module Installation ... 4 Diagnostic Menu ... 6 Barcode Function... 6 Barcode Labels ... 6... -
Page 3: Equipment Description
Equipment Description The user-installable Barcode Reader module option enables your FastStor/FastStor 22 to read cartridge information contained in a barcode label attached to each of the data cartridges. This information becomes part of the application software’s library cartridge inventory. Mounting Bracket... -
Page 4: Faststor Barcode Reader Module Installation
Reader module is installed the LOAD SLOT function of the FastStor menu will use storage slots 2 and 3 as the cartridge source locations to load slots 6 and 7. Without the Barcode Reader module installed, the LOAD SLOT function uses storage slots 1 and 2 as the source locations. - Page 5 6. Press the interface connector on the Barcode Reader module into the mating interface connector on the inside top panel. 7. Push in and tighten the thumbscrew on the Barcode Reader module bracket until it secures the Barcode Reader module to the inside top panel.
-
Page 6: Faststor 22 Barcode Reader Module Installation
You do not need any tools to install the Barcode Reader module in your FastStor 22. A thumbscrew and interface connector on the mounting bracket secure it to the right inside panel of your FastStor 22 directly to the right of the I/E Slot. Follow the installation instructions below to install the optional barcode reader module. - Page 7 7. Push in and tighten the thumbscrew on the Barcode Reader module bracket until it secures the Barcode Reader module to the inside right panel. Thumbscrew 8. Connect the FastStor 22 AC line cord to the AC source outlet. 9. Power up your FastStor 22 by pressing the POWER button. Your FastStor 22 will automatically sense the presence of the Barcode Reader module when power is applied.
-
Page 8: Diagnostic Menu
The dIAG MENU is accessed by pressing and holding first the NEXT button and then the MODE button for approximately 5 seconds. dIAG MENU will appear on the LCD. The FastStor/FastStor 22 will automatically exit the dIAG MENU and return to LdR REAdY if the keypad is idle for 30 seconds.
