ADIC FastStor 2 Supplementary Manual
Racking or de-racking the autoloader
Hide thumbs
Also See for FastStor 2:
- Install manual (6 pages) ,
- User manual (76 pages) ,
- User manual (68 pages)
Advertisement
Table of Contents
Racking or De-racking the Autoloader
You can convert your FastStor 2 autoloader from a desktop to a rackmount configuration or from a
rackmount to a desktop configuration.
Contents
Page
Topic
1
What's in the Box?
1
Tools Required
2
Converting from Desktop to Rackmount
5
Converting from Rackmount to Desktop
6
Contacting ADIC
What's in the Box?
The following items are included in the rackmount kit:
Description
Phillips screws
Clip nuts
L-brackets; right side and left side
Rail assembly; right side and left side
Tools Required
The following tools are required to work with the rackmount kit:
Description
Small flat blade screwdriver
# 2 Phillips head screwdriver
© May 2005, ADIC®
ADIC, Scalar, and SNC are registered trademarks of Advanced Digital
Information Corporation. All other product, company, or service names
mentioned herein are the property of their respective owners.
FastStor
Quantity
10
10
2
2
Quantity
1
1
2
TM
6-00519-01 Rev B
