DPM5500
Quick Start Guide

TABLE OF CONTENTS

Choosing a Location ..........................1
Rack Space Requirements...............1
Taking ESD Precautions ..................2
Unpacking the DPM5500 ...................2
Cabling the DPM5500 ........................5
Protection Manager 2006 ................10
This quick start guides provides basic installation and configuration instructions for
the DPM5500 system. For more information on Microsoft DPM, see
www.microsoft.com/windowsserversystem/dpm/default.mspx.

Choosing a Location

When choosing an installation site for the DPM5500 system, consider the
following requirements:
•

Rack Space Requirements

•

Environmental Conditions

Rack Space Requirements
Table 1
contains the rack requirements for the DPM5500.
Table 1 Rack Requirements
Depth
Width
Height
Weight
Air Clearance
Environmental Conditions
The installation site must have the following environmental conditions:
•
Humidity: 20%-80% non-condensing
•
Temperature: 10°C-35°C (50°F-95°F)
•
Altitude: 0 to 10,000 feet (0 to 3048 meters)
These environmental conditions apply when the DPM5500 system is in operation.
0
DPM5500
25.4 in (64.5 cm)
19 in (48.3 cm)
8.75 in (22.2 cm), 5U
122 lbs (55.33 kg)
Open 4.0 in (10.2 cm) behind unit for proper air
flow
0
http://
0
