- Page 1 MANUAL ENGLISH Small Mushroom LED Q6 Ordercode: 43159 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
Small Mushroom LED Q6 Table of contents Warning ....................................2 Unpacking Instructions ..............................2 LED Expected Lifespan ..............................2 Safety Instructions ................................. 2 Operating Determinations ............................4 Rigging .................................... 4 Connection with the mains............................5 Return Procedure ................................5 Claims ....................................5 Description of the device .............................. -
Page 3: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: ● Showtec Small Mushroom LED Q6 ● IEC Power cable (1,0 m) ●... - Page 4 Leave the device switched off until it has reached room temperature. ● If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service.
-
Page 5: Operating Determinations
Small Mushroom LED Q6 Operating Determinations ● This device is not designed for permanent operation. Consistent operation breaks will ensure that the device will serve you for a long time without defects. ● The minimum distance between light output and the illuminated surface must be bigger than 1 meter. -
Page 6: Connection With The Mains
Small Mushroom LED Q6 Connection with the mains Connect the device to the mains with the power plug. Always check if the right color cable is connected to the right place. International EU Cable UK Cable US Cable BROWN YELLOW/COPPER PHASE BLUE BLACK... -
Page 7: Description Of The Device
Small Mushroom LED Q6 Description of the device Features The Showtec Small Mushroom LED Q6 is a light effect with high output and great effects. Legendary Light FX Plug & Play Sound-controlled through a built-in microphone ... -
Page 8: Backside
Small Mushroom LED Q6 Backside Fig. 02 03) Built-in microphone 04) Sound sensitivity control 05) Ground/Earth connection 06) IEC Power connector OUT 07) IEC Power connector IN + Fuse 1A/250V Installation Remove all packing materials from the Small Mushroom LED Q6. Check if all foam and plastic padding is removed. -
Page 9: Maintenance
03) Mechanically moving parts like axles, eyes and others may not show any traces of wearing. 04) The electric power supply cables must not show any damages or material fatigue. The Showtec Small Mushroom LED Q6 requires almost no maintenance. However, you should keep the unit clean. Otherwise, the fixture’s light-output will be significantly reduced. -
Page 10: Product Specifications
The power supply settings do not • Disconnect fixture. Check settings match local AC voltage and and correct if necessary frequency Product Specifications Model: Showtec Small Mushroom LED Q6 Input Voltage: 100-240V AC, 50/60Hz Power consumption: Protection rate: IP-20 Fuse: 1A/250V Dimensions: 345 mm x 175 mm x 285 mm (LxWxH) (incl. -
Page 11: Dimensions
Small Mushroom LED Q6 Dimensions Ordercode: 43159... - Page 12 ©2017 Showtec...
