Note: Room must be installed on flat, level surface.
710-0124 IG-810-SH / S810-H 1 Person IR Sauna
Ver. 3
1 Person Infrared Sauna
Touch Pad and Bluetooth
IG-810-SH/S810
This Product is covered by:
US Patents No. 8,692,168
Canadian Patents No. 2,729,500
2,794,059 & 2,813,340
and other Patents Pending.
Precautions Before Use
Preassembly Information
Electrical Requirements
Sauna Assembly
Electrical Connection-Under Bench
Electrical Connection-Inside Ceiling
Control Panel Instructions
Lighting Operation
Audio System
How to Use Sauna
Tips & Troubleshooting
Wiring Diagram
Warranty
S3-Series
User Manual
Page 1
2
2
3
4
8
13
15
15
16
17
18
19
20
04-09-19
Rev. 4
Advertisement
Related Manuals for Saunatec S810
Summary of Contents for Saunatec S810
- Page 1 Sauna Assembly Electrical Connection-Under Bench Electrical Connection-Inside Ceiling Control Panel Instructions Lighting Operation Audio System How to Use Sauna Tips & Troubleshooting Wiring Diagram Warranty 710-0124 IG-810-SH / S810-H 1 Person IR Sauna Page 1 04-09-19 Ver. 3 Rev. 4...
-
Page 2: Precautions Before Use
Note: Front wall glass assembly is heavy and fragile. Box #1: Floor, Ceiling, Bench Skirt, Bench, Manual & Deluxe Door Handle Set Box #2: Left & Right Walls Box #3: Front & Back Walls 710-0124 IG-810-SH / S810-H 1 Person IR Sauna Page 2 04-09-19 Ver. 3... - Page 3 Record your model number and serial number from box in the event you should need to contact your dealer or technical support. Serial Number ______________________________ Model Number ______________________________ Dealer Name________________________________ 710-0124 IG-810-SH / S810-H 1 Person IR Sauna Page 3 04-09-19 Ver. 3 Rev. 4...
- Page 4 Note: place the power cord on the ground to the side of the floor; be sure that all wires and connectors on the sauna floor are clear of the slots. Note – Do NOT Plug the Sauna Room 120 VAC Power Cord into the Outlet Yet! 710-0124 IG-810-SH / S810-H 1 Person IR Sauna Page 4 04-09-19 Ver.
- Page 5 Place Back Wall panel into the back slot of the Floor Panel. Back Wall panel must be held in place until the Right Wall panel is added. 710-0124 IG-810-SH / S810-H 1 Person IR Sauna Page 5 04-09-19 Ver.
- Page 6 Note: When wall panels are connected in place properly the corners will be flat on top, notice the illustration above right. The right wall is incorrect; the left wall is the correct installation. 710-0124 IG-810-SH / S810-H 1 Person IR Sauna Page 6 04-09-19 Ver.
- Page 7 Slide the Bench seat down against the back wall with Power Junction Box facing you. Tilt the Bench against the Back Wall so it will remain standing. 710-0124 IG-810-SH / S810-H 1 Person IR Sauna Page 7 04-09-19 Ver.
- Page 8 Connect wire #6 from the Back Wall harness to the Bench Top wire #6. Connect wire S1 from the distribution plate to the Bench Top wire S1. 710-0124 IG-810-SH / S810-H 1 Person IR Sauna Page 8 04-09-19 Ver.
- Page 9 Connect wire B1 from the distribution plate to B1 from the Back Wall panel. View of the finished connections. Locate the electrical switch on the black Master Control Box and ensure the switch is on. 710-0124 IG-810-SH / S810-H 1 Person IR Sauna Page 9 04-09-19 Ver. 3 Rev. 4...
- Page 10 The Bench Top should fit down flush from front to back. It may be necessary to use the openings on the bench skirt to apply pressure either forward or rearward on the skirt to allow bench to drop into place. 710-0124 IG-810-SH / S810-H 1 Person IR Sauna Page 10 04-09-19 Ver.
- Page 11 The Front Wall panel should now be held tightly in place by the corner interlock brackets. The corners at top of all of the walls should be level and flush. 710-0124 IG-810-SH / S810-H 1 Person IR Sauna Page 11 04-09-19 Ver.
- Page 12 Ceiling panel. Note: Position the cam locks on the top of the Left & Right Wall panels as shown above. 710-0124 IG-810-SH / S810-H 1 Person IR Sauna Page 12 04-09-19 Ver.
- Page 13 Connect wire #4 from the Back Wall harness to the Ceiling wire #4. Connect wire #5 from the Back Wall harness to the Ceiling wire #5. Connect wire #6 from the Back Wall harness to the Ceiling wire #6. 710-0124 IG-810-SH / S810-H 1 Person IR Sauna Page 13 04-09-19 Ver.
- Page 14 Logo Handle goes on the outside of room Place other handle with slot side up inside of room. Slot is designed to hold electronic devices. Secure handles together with provided screws. 710-0124 IG-810-SH / S810-H 1 Person IR Sauna Page 14 04-09-19 Ver.
- Page 15 7th press – BLUE-RED-GREEN 8th press – Activates full rotation of all 7 color therapy in sequence noted above 9th press – Turns Color Therapy Functions OFF 710-0124 IG-810-SH / S810-H 1 Person IR Sauna Page 15 04-09-19 Ver. 3...
-
Page 16: Audio Operation
95⁰F and above. The recommended operating temperature is 32⁰F to 95⁰F to fall into the warranty. Check with any other device manufactures for operation temperatures before using the device in the Sauna/IR Room. 710-0124 IG-810-SH / S810-H 1 Person IR Sauna Page 16 04-09-19 Ver. - Page 17 Open the door and clean the Sauna walls, bench and floor areas with a soft clean damp cloth. Enjoy a final shower or bath to cool down. Relax, in the special “after sauna glow” and you may choose to enjoy a healthy snack and cool drink. 710-0124 IG-810-SH / S810-H 1 Person IR Sauna Page 17 04-09-19 Ver.
-
Page 18: Troubleshooting Tips
------------------------------------------------------------------------------------------- For additional assistance or service questions? Please do not hesitate contacting Saunatec/TyloHelo Mon – Fri. 8AM – 5PM CST 1-888-780-4427 techsupport@tyloheloinc.com 710-0124 IG-810-SH / S810-H 1 Person IR Sauna Page 18 04-09-19 Ver. 3 Rev. 4... - Page 19 710-0124 IG-810-SH / S810-H 1 Person IR Sauna Page 19 04-09-19 Ver. 3 Rev. 4...
- Page 20 710-0124 IG-810-SH / S810-H 1 Person IR Sauna Page 20 04-09-19 Ver. 3 Rev. 4...
