710-0129 IG-870-SH / S870-H 3 Person IR Sauna
Ver. 3
3 Person Infrared Sauna
Touch Pad and Bluetooth
IG-870-SH/S870 User Manual
Canadian Patents No. 2,729,500
Precautions Before Use
Preassembly Information
Electrical Requirements
Sauna Assembly
Electrical Connection-Under Bench
Electrical Connection-Inside Ceiling
Control Panel Instructions
Lighting Operation
Audio System
How to Use Sauna
Tips & Troubleshooting
Wiring Diagram
Warranty
S3-Series
This Product is covered by:
US Patents No. 8,692,168
2,794,059 & 2,813,340
and other Patents Pending.
Page 1
2
2
3
4
7
12
14
14
15
16
17
18
19
04/09/19
Rev. 4
Advertisement
Related Manuals for Saunatec S3-870
Summary of Contents for Saunatec S3-870
- Page 1 S3-Series 3 Person Infrared Sauna Touch Pad and Bluetooth IG-870-SH/S870 User Manual This Product is covered by: US Patents No. 8,692,168 Canadian Patents No. 2,729,500 2,794,059 & 2,813,340 and other Patents Pending. Note: Room must be installed on flat, level surface. Precautions Before Use Preassembly Information Electrical Requirements...
-
Page 2: Precautions Before Use
Precautions before Use: Warning (Room Configuration & Use): Proper Electrical Grounding is Required Electrical Receptacles not Allowed in the Room Do not Apply Water to any Heating Element Do not Add a Locking or Latching System to the Door ... - Page 3 Electrical Requirements: The IR Sauna Room is designed for a 120 Volt AC / 15 or 20 Amp Circuit Breaker! A 120 Volt AC (dedicated) circuit is recommended to avoid unnecessary tripping of the breaker. The Sauna should be plugged into a NEMA (5-15R or 5-20R) Amp electrical outlet.
- Page 4 Sauna Assembly Instructions _________________________________________________________________________ Floor Panel (Box #1): Locate the Floor Panel on a level surface (3-6) inches from wall and no more than (5 ft) from 120 Volt AC / 15 or 20 amp dedicated receptacle. Position the Floor panel so that the Ceramic tiles / IR Floor Heaters are to the front of the room Note: place the Ceiling, Bench Skirt and Bench to the side until the appropriate steps.
- Page 5 Right Back Wall (Box #3): Place Back Right Wall panel into the back slot of the Floor Panel. Back Right Wall panel must be held in place until the Back Left Wall panel is added. Left Back Wall (Box #3): ...
- Page 6 Left & Right Front Wood Walls (Box #2): Place Left Front Wall section into the left slot of the Floor Panel. Attach the Left Back Wall to the Left Front Wall by lifting up the Wall slid into the Left Front corner interlock brackets.
- Page 7 Bench Top (Box #1): Slide the Long Bench seat down against the back wall with Power Junction Box facing you. Tilt the Bench against the Back Wall so it will remain standing. Electrical Connections (under bench - left side): ...
- Page 8 Bench Top (Left Side): Install the left Bench Top by tucking the back of the bench under the heater guard. Push Bench Top all the way to the Left Back Wall. The Bench Top should fit down flush from front to back. It may be necessary to use the openings in the skirt to apply pressure forward or rearward on the skirt to allow the bench to drop into place.
- Page 9 Connect wire S3 from the distribution plate to S3 from the Bench Skirt. Connect wire S1 from the distribution plate to S1 from the Bench Top. Connect wire #6 from the distribution plate to #6 on Bench Top. ...
- Page 10 The Bench Top should fit down flush from front to back. It may be necessary to use the openings in the skirt to apply pressure forward or rearward on the skirt to allow the bench to drop into place. Left &...
- Page 11 Ceiling (Box #1): Install Styrofoam packing squares on top of the Right & Left Wall panels. One block should be placed in the front portion and one toward the rear portion of each wall. These will be used to set the ceiling on.
- Page 12 Front Wall Glass (Box #2): Place the Right Side Front / Door panel into the Floor panel slot. Note: Do not let go of glass panel, it needs to be held in place. While carefully still supporting the Front Wall Glass, one person on each side. ...
- Page 13 Electrical Connections (inside the Ceiling panel-rear left side): Near the Touch Screen harness in Ceiling connect Left Wall wire #3 to Ceiling wire #3. Connect Left Wall wire #7 to the Ceiling wire #7. Connect Left Wall wire F to Ceiling wire F. ...
- Page 14 Control Panel Instructions: Color Therapy Bench Heat Lights Interior Lights Valance Power ON or Light Main Power: Press POWER to switch room ON or OFF Timer Functions: Press and hold “+” or “–“ to set room operating time. Increases time (5 minute increments) / Decreases time (5 minute increments) Temperature Functions: Press to alternate between either C or F (C or F will light to indicate the units desired) Press and hold + or –...
-
Page 15: Audio Operation
Audio System: Audio Power ON or OFF Auxiliary Input AUDIO OPERATION Audio Power On Press Bluetooth icon to turn on or off audio system Blue LED indicates the audio system is operating. Bluetooth Bluetooth is always enabled when blue LED is glowing and Aux Input is not connected Auxiliary Input ... - Page 16 How to Use Infrared Sauna: Avoid eating large meals and excessive alcohol intake before using Sauna. Never smoke or drink alcohol or exercise inside of Sauna. If you are taking any medications or under the care of a Physician, consult with them prior to Sauna usage. Refer to Sauna Usage Warning signs located inside of Sauna Room Prior to Sauna session, if possible before using Sauna, take a warm shower without drying.
-
Page 17: Troubleshooting Tips
Ensure the floor is flat by using a level on the ceiling of the room. It may be necessary to use a small door or window shim to adjust the level under the floor. ------------------------------------------------------------------------------------------- For additional assistance or service questions? Please do not hesitate contacting Saunatec/TyloHelo Mon – Fri. 8AM – 5PM CST 1-888-780-4427 techsupport@tyloheloinc.com... - Page 18 710-0129 IG-870-SH / S870-H 3 Person IR Sauna Page 18 04/09/19 Ver. 3 Rev. 4...
- Page 19 710-0129 IG-870-SH / S870-H 3 Person IR Sauna Page 19 04/09/19 Ver. 3 Rev. 4...
