SANbox 9000 Series Stackable Chassis Switch
Global services
1
• Standard one year hardware/firmware warranty
• SAN Pro Service and Support Programs
– SAN Pro Preferred standard on BASE Model
SB9200 & ENTRY Model SB9100: Next
Business Day (NBD) Advanced Delivery spares,
24x7 technical phone support
– Optional: upgrades to SAN Pro Choice (NBD
Onsite Replacement) and SAN Pro Prime
(4-hour Onsite Replacement) available for a fee
Physical Characteristics
Enclosure chassis module/blade packaging
• Standard Rack Mountable Chassis Module
– Includes adjustable forward/reverse Mounting
Rail/Racking kit and dual power cords
• I/O Blades
– Standard and optional I/O Blades do NOT
Include SFPs, X2 transceivers, or copper/
optical cables (orderable separately)
• Hardware and Software License Field
Upgradeability:
– SB9100 ENTRY Model to SB9200 BASE Model
– SB9200 Model to SB9200 Fault Tolerant Model
– One SB9200 BASE Model to Dual HyperStack
Model
– Two SB9200 BASE Models to Dual HyperStack
Model
Dimensions (chassis module)
• Width: 431 mm (17.0") 19" rack mountable
• Height: 179 mm (7.0") (4U)
• Depth: 673 mm (26.5")
Weight (SB9200 chassis module maximum)
• 40.82 kg (90 lbs)
Power supply/cooling (both SB9100 and SB9200)
• Hot-Pluggable/Dual-Redundant power supply
blades with integrated cooling fans
– Dual 7'6" long 3-wire 16AWG power cables
with IEC320 input connector
– Popular international country dual power
cable/connector kit options available
• Hot-Pluggable/Dual-Redundant fan blades
• Back-to-Front and Front-to-Back Airflow
Direction Models available
• 150-cfm airflow
• 1,000 watts or 3,414 BTU/hour rating per power
supply
Heat output (SB9200 full data traffic maximum)
• 2,046 BTU/hour at 128-ports 4Gb Fibre Channel
1 For additional information on SANbox 9000
service options, visit http://www.qlogic.com/Sup-
port/ServicePrograms.aspx?id=m11.
Designed to the Core™ for Open Systems
(incl. SFPs and "local switching")
• 4,228 BTU/hour at 256-ports 4Gb Fibre Channel
HyperStack (incl. SFPs and "local switching")
Electrical Requirements
Operating voltage/frequency
• 100 to 240 VAC auto-sensing, single phase
• 47 to 63Hz
Power source loading (SB9200 chassis module
maximum power supply rating)
• 10 Amps at 100 VAC
• 4.2 Amps at 240 VAC
Operating load (SB9200 with no data traffic)
• 550 Watts at 128-ports 4Gb Fibre Channel
(including SFPs)
• 1,120 watts at 256-ports 4-Gb Fibre Channel
HyperStack (including SFPs)
Operating load (SB9200 with full data traffic)
• 600 Watts at 128-ports 4Gb Fibre Channel
(includ ing SFPs and "local switching")
• 1,240 watts at 256-ports 4-Gb Fibre Channel
HyperStack (including SFPs and "local
switching")
Circuit protection
• Internally fused

Environmental Factors

Operating
• Temperature: 0°C to 40°C (32° to 104°F)
• Humidity: 15% to 80% non-condensing
• Altitude: 0 to 3048m (0 to 10,000 feet)
• Vibration: IEC 68-2, 5-500 Hz, random, 0.21g
RMS, 10 minutes
• Shock: IEC 68-2: 4g, 11ms, 20 repetitions
Non-operating
• Temperature: -40°C to 70°C (-40° to 158 °F)
• Humidity: 5% to 90% non-condensing
• Altitude: 0 to 15,240m (0 to 50,000 feet)
• Vibration: IEC 68-2: 5-500 Hz, random, 2.1g
RMS,10 minutes
• Shock: IEC 68-2: 30g, 13 msec, trapezoidal pulse
SN0058047-00 F
D A T A S H E E T

Regulatory Certifications

Safety standards
• UL 60950-1 – UL Listed (United States)
• CAN/CSA C22.2 No. 60950-1 – cUL Listed
(Canada)
• EN60950-1 (EC)
• CB Scheme-IEC 60950-1 (International)
• GOST R (Russia)
Emissions standards
• FCC Part 15B Class A (USA)
• VCCI Class A ITE (Japan)
• ICES-003 Class A ITE (Canada)
• EN 55022 Level A (EC)
• CISPR 22, Class A (International)
• AS/NZS CISPR 22:2002 Class A (AUS/NZ)
• GOST R (Russia)
• KN22 – Class A (Korea)
Environmental standards
• RoHS-5/WEEE (EU & Japan)
Voltage fluctuations
• EN 61000-3-3
Harmonics
• EN 61000-3-2
Immunity
• EN 55024
Marking
• FCC Part 15, UL (United States)
• cUL, CUE, TUV (Canada)
• TUV , CUE, CE (EC)
• VCCI-A (Japan)
• C-Tick (AUS/NZ)
• GOST R (Russia)
• MIC (Korea)
• Exempt (Taiwan)
• UL AR/S-Mark (Argentina)
• CCC – Field Replaceable Unit (FRU) power supply
modules (China)
11
