SANbox 9000 Series Stackable Chassis Switch
• 4Gb I/O blade (SB9004-4G) – Hot-pluggable,
industry standard 3.3 volt SFPs for 4/2/1 Gbps
speeds
• 10Gb I/O blade (SB9010-10G) – Hot-pluggable,
indusatry-standard X2 optical transceivers or X2
copper ISL cables for 10 Gbps speed
Supported SFP transceiver types
• Short Wave (optical)
• Long Wave (optical)
• Active/Passive Copper (8/4/2Gb)
• Supported X2 transceiver types
• Short Wave (optical)
• Long Wave (optical)
Media transmission ranges (@ 10Gbps speeds)
• Optical Media
– Short Wave: 300 m (984 ft.)
– Long Wave: 8.34 km (5.18 miles)
Optical cable types (4Gb, 8Gb, and 10Gb)
• 50/62.5 micron multimode fiber optic
• 9 micron single-mode fiber optic
Interoperability/Certifications
• Fully interoperable with all QLogic SANbox switch
products
• Compatible with FC-SW-2 compliant switches,
including Brocade, Cisco and McDATA
• Management interoperability with leading SAN
management applications
• FCIA SANmark and SNIA SMI-S certified
– SCD-3001v2a1 (E_Port)
– SCD-3002v2 (FL_Port)
– SCD-3010v1 (RSCN)
– SCD-3020v1 (Zoning)
• Certified with leading SAN hardware and
software vendors. Visit www.qlogic.com/
interoperability/interoperability.aspx
comprehensive listing

Fabric Services

Software releases
• QuickTools version 7.08.XX or later
• Enterprise Fabric Suite 2007 version 7.08.XX or
later
• Switch Firmware version 7.8.XX or later
Ethernet connections
• CPU Blade: RJ-45 Ethernet connector on each
CPU Blade on back of chassis module
• Maintenance Panel: Two alternate RJ-45 Ethernet
connectors on Maintenance Panel on front of
chassis module
• IPv6 support
Designed to the Core™ for Open Systems
Management methods
• Enterprise Fabric Suite 2007 GUI
• QuickTools web applet
• Application Programming Interface (API)
• CLI
• GS-4 Management Server (including FDMI)
• Simple Network Management Protocol (SNMP)
• RADIUS
• File Transfer Protocol (FTP)
• Trivial File Transfer Protocol (TFTP)
• Storage Management Initiative Specification
(SMI-S)
Fabric security
• Fabric binding via list of allowed domain IDs and
switch WWNs
• Inter-switch management communication data
path encryption
– SSH for CLI
– SSL for QuickTools, EFS 2007, and SMI-S
• Device, Host, and Switch Authentication
– Local security database configuration, or
– Remote authentication via a RADIUS Server
– Additional MS request authentication via FC-
GS4 CT authentication
– Enable/Disable in-band management of switch
Registered State Change Notification (RSCN)
• RSCNs are generated per standard (FC-GS, FC-
FS, FC-SW, etc.)
• Delayed to allow consolidation into single RSCN
• QLogic I/O StreamGuard™ suppresses RSCNs
between initiators
Fabric diagnostics
• Optional SANdoctor™ software package
Call Home
• Switch initiated problem message notification to
for a
multiple end-user e-mail boxes
• Message content criteria selectable by log event
level (fault, alarm, critical, warning)
• Up to 25 profiles; up to 10 e-mail recipients per
profile
• Message queue, status, and history statistics can
be queried
• Ability to test a new/changed Call Home profile
and view log failures
• Operates an SMTP client to transfer e-mail
messages to designated SMTP servers via TCP/
IP interconnect
• ·Call Home directly to QLogic worldwide
Technical Support Center coming in mid-CY2008
SN0058047-00 F
D A T A S H E E T
Maintainability
Maintenance strategy
• Hot-pluggable CRUs per chassis module
– SFP & X2 transceivers
– I/O Blades (eight maximum, three types w/
Intermix)
– CPU Blades (two w/Model SB9200, one w/
Model SB9100)
– Power supply blades (two)
– Fan blades (two)
• Enhanced data integrity on all data paths
• Fabric Shortest Path First (FSPF) rerouting around
failed links
• Integration with SNMP managers
• Non-disruptive "hot" firmware code load and
activation (NDCLA)
• Easy configuration, save, and restore
• E-mail Call Home system initiated alarm/fault
notification
Maintenance access methods
• Single point in-band management with auto-
discovery across multiple switches via software
GUI
• One out-of-band Ethernet 10/100Mb BaseT
RJ-45 management port per CPU Blade, each
replicated on Maintenance Panel
• One RJ-45 serial port per CPU Blade (RJ-45 to
DB-9 conversion dongle included)
• FC-GS4 Management Server
Diagnostics
• Power-On Self-Test (POST) tests all functional
components except SFP and X2 transceivers
• Optional SANdoctor fabric diagnostics software
– FC Ping: verifies functional path existence
between two ports
– FC Trace Route: displays path information
between a source and destination
– Digital Diagnostics Monitoring: displays real-
time SFP, X2, and XPAK transceiver data
Visual user interface
• LED indicators on the Maintenance Panel, I/O
Blades, CPU blade(s), power supply blades, and
fan blades
Maintenance Panel (MP)
• Dual redundant Maintenance Panel EPROMs
maintain chassis-specific information (such
as WWN, SNMP system object ID, serial
number, part number, etc.), alternate Ethernet
management interface ports, and LED summary
status information for the switch
