  • Page 1 Manual HR series hr11002*GE, hr16000*GE, hr16050*GE, hr16071*GE, hr29050*GE 2.24.2017...
  • Page 2 The camera in your possession has been produced with great care and has been thoroughly tested. Nonetheless, should you have reasons for complaint, then please contact your local SVS-VISTEK distributor. You will find a list of distributors in your area under: http://www.svs-...

  • Page 3: Table Of Contents

    Contents Contents Safety Messages ............5 Legal Information ............. 6 The HR-Series – GigE Vision ........7 Details matter ............7 GigE-Vision features ..........8 4IO adds Light and Functionality ........ 9 Getting Started ............10 Contents of Camera Set ..........
  • Page 4 Contents 7.1.9 Color ................. 38 7.1.10 Resolution – active & effective ........39 7.1.11 Offset ................ 40 7.1.12 Gain ................41 7.1.13 Image Flip ..............42 7.1.14 Binning ..............43 7.1.15 Burst Mode ..............44 Camera Features ........... 45 7.2.1 Standard Tap Geometries ..........

  • Page 5: Safety Messages

    A white graphical symbol inside a blue circle defines a safety sign that indicates that an action shall be taken to avoid a hazard. Cross-reference NOTICE Provides references and tips 1: T IGURE ABLE OF SAFETY MESSAGES SVS-VISTEK– Details matter...

  • Page 6: Legal Information

    Customers, integrators and end users of SVS-Vistek products might sell these products and agree to do so at their own risk, as SVS-Vistek will not take any liability for any damage from improper use or sale.

  • Page 7: The Hr-Series - Gige Vision

    Here, we can support you with our expertise. The HR series is a sound investment to reach your cost and quality targets in sensitive tasks in the inspection of high quality products. SVS-VISTEK–The HR-Series – GigE Vision Details matter...

  • Page 8: Gige-Vision Features

    SVS-VISTEK 3.2 GigE-Vision features GigE Vision is an industrial interface standard for video transmission and device control over Ethernet networks. It provides numerous software and hardware advantages for machine vision. Being an industry standard, it facilitates easy and quick interchangeability between units, shortening design cycles and reducing development costs.

  • Page 9: 4Io Adds Light And Functionality

    SVS-VISTEK 3.3 4IO adds Light and Functionality Your SVS-Vistek camera is equipped with the innovative 4IO-interface Figure 2: Illustration of 4IO concept of switching LEDs (depending on camera model up to 4 inputs/outputs, see specs) allowing full light control, replacing external strobe controllers. Each of the outputs can be individually configured and managed using pulse- width modulation.

  • Page 10: Getting Started

    Red slow ( 1 Hz ) Problem with initialization Red quickly ( 8 Hz) Camera overheating Blue permanent Waiting for trigger Cyan permanent Exposure active Violet permanent Readout/FVAL Table 1 table of flashing LED codes SVS-VISTEK–Getting Started Contents of Camera Set...

  • Page 11: Software

    (GenICam drivers and transport layer DDLs) SVCapture 2.x is a XML based software tool provided for free. It is created to show the capabilities of your SVS-Vistek camera and to show/modify values to your cam. Get control of exposure timing, trigger delay, image correction etc. or control up to 4 LED lights connected to the SVCam directly via the PC.
  • Page 12 SVS-VISTEK Installation Installation prosecco may differ from PC to PC. It is recommended to install the whole software package. Copy/expand the installation executable file to your hard drive. Run installation Read and accept the terms of license agreement Choose destination folder...
  • Page 13 SVS-VISTEK Install the USB 3.0 Driver Generic driver included in the windows system will not match all SVS-VISTEK USB3 Vision features. Start installation System, warning The installer will modify your system (USB 3.0 driver); there for windows systems will warn you with an interrupt.
  • Page 14 SVS-VISTEK Installation will proceed Installation completed Getting Started...
  • Page 15 SVS-VISTEK Initialization I R S T L A U N C H The software is XML based. So in case there is no Camera connected to the USB slot, no XML camera properties can be loaded, no values to control are available.
  • Page 16 SVS-VISTEK Conform to GenICam all control features will be listed in a flat tree diagram. Getting Started...
  • Page 17 SVS-VISTEK USB 3.0 driver The USB 3.0 driver You can find the USB 3.0 driver within your hardware manager: Firmware update From time to time make sure your camera is running up to date firmware. A firmware update tool is integrated in the software.

  • Page 18: Firmware

    (download it from website, login area) matching your camera model. 4.5.1 Firmware Update GigE A separate tool called “Firmware Update Tool.exe” is provided in the login area of the SVS-Vistek website. Execute firmware update > Download the firmware tool and the firmware file from the SVS-Vistek website.
  • Page 19 SVS-VISTEK Start SVCapture on your computer. As soon as the camera has booted, all SVS-Vistek GigE cameras are showing up in the main window. The cameras will show their IP addresses. In any case, the last number (1-254) has to be unique in your subnet.

  • Page 20: Driver Circuit Schematics

    SVS-VISTEK 4.7 Driver Circuit Schematics Figure 6: basic Illustration of driver circuit Getting Started...

  • Page 21: Connectors

    Use the upper right network port for single line operation. NOTICE Dual GigE connection is required only if single network connection does not provide sufficient bandwidth. For dual GigE operation, 2 NICs need to be teamed. NIC teaming is a feature of the operating system SVS-VISTEK–Connectors Dual GigE Vision...
  • Page 22 SVS-VISTEK Connectors...

  • Page 23: Teaming Dual Gige

    SVS-VISTEK 5.1.3 Teaming Dual GigE NOTICE Windows 10 does not support static link aggregation. You need to run win7, win8, macOS or linux if you want to use dual GigE For higher transfer rates on GigE, you might want to team 2 GigE ports together.
  • Page 24 SVS-VISTEK Figure 9: team wizard Choose Static Link Aggregation, next and finish. Figure 10: setting Static Link Aggregation (SLA) Jumbo Frames The transport efficiency in the streaming channel can be improved by using “jumbo frames”. This will reduce overhead caused by maintaining header data upon each data packet sent.

  • Page 25: Xml Files

    SVS-VISTEK NOTICE Resends result in higher consumption of bandwidths and will lead to drop frames. High quality cables prevent resends. 5.1.4 XML Files According to the GigE Vision standard a GigE camera provides an XML file that defines the camera’s capabilities and current settings.

  • Page 26: Input / Output Connectors

    SVS-VISTEK 5.2 Input / output connectors For further information using the breakout box and simplifying I/O connection refer to SVCam Sensor Actor manual (with Murr and Phoenix breakout boxes). To be found separate within the USP manuals. Hirose™ 12Pin For detailed information about switching lights from inside the camera, refer to strobe control.

  • Page 27: Dimensions

    All length units in mm. CAD step files available on DVD or SVS- VISTEK.com 6.1 HR GigE with M58 mount Including: hr11002CTLGEC, hr11002MTLGEC, hr16000CTLGEC, hr16000MTLGEC, hr16050CFLGEA, hr16050CFLGEC, hr16050MFLGEA, hr16050MFLGEC, hr16070CFLGEA, hr16070CFLGEC, hr16070MFLGEA, hr16070MFLGEC, hr29050CFLGEA, hr29050CFLGEC, hr29050MFLGEA, hr29050MFLGEA4IO, hr29050MFLGEC SVS-VISTEK–Dimensions HR GigE with M58 mount...
  • Page 28 SVS-VISTEK Dimensions...
  • Page 29 SVS-VISTEK Dimensions...

  • Page 30: M58 Mount

    SVS-VISTEK M58 Mount Diameter: 58 mm Thred pitch 0.75 mm Back-focus distance from sensor to flange of the camera: 11.48 mm Distance from sensor surface to lens differs depending on lens specifications and how far the lens is screwed in.

  • Page 31: Feature-Set

    Charge is an integration of time and light intensity on the element. Like this the image gets brighter the longer the CCD cell is exposed to light. The sensor converts light into charge and transports it to an amplifier and subsequently to the analog to digital converter (ADC). SVS-VISTEK–Feature-Set Basic Understanding...

  • Page 32: Interline Transfer

    SVS-VISTEK 7.1.2 Interline Transfer Interline Transfer is only used in CCD sensors. With a single pixel clock the charge from each pixel is transferred to the vertical shift register. At this time, the light sensitive elements are again collecting light. The charge in the vertical registers is transferred line by line into the horizontal shift register.

  • Page 33: Global Shutter / Progressive Scan

    SVS-VISTEK 7.1.3 Global Shutter / Progressive Scan Unlike rolling shutter or interlaced scan modes all pixels are exposed at the same time. Fast moving objects will be captured without showing movement distortion. Figure 17: motion blur Figure 18 rolling shutter with...

  • Page 34: Frames Per Second

    SVS-VISTEK 7.1.4 Frames per Second Frames per second, or frame rate describes the number of frames output per second. The inverse (1/ frame rate) defines the frame time. frame per second frame time (Exposure) applicable standard 0,25 500ms 41,6 � ms...

  • Page 35: Exposure

    SVS-VISTEK 7.1.6 Exposure See various exposure and timing modes in chapter: Basic capture modes. Combine various exposure timings with PWM LED illumination, refer to sequencer. Setting Exposure time Exposure time can be set by width of the external or internal triggers or programmed by a given value.

  • Page 36: Bit-Depth

    SVS-VISTEK 7.1.8 Bit-Depth Values of brighness are internally represented by numbers. Numbers are represented by bytes, consisting out of single bits. The number of bits for brightness representation is limiting the number of brightness values or colour values that can be represented. Bit depth defines how many unique colors or grey levels are available in an image after digitization.
  • Page 37 SVS-VISTEK Figure 24: Figure of original picture - black & white Figure 25: Figure of quantification with 6 shades of gray (reduced colour depth) Feature-Set...

  • Page 38: Color

    SVS-VISTEK 7.1.9 Color Color cameras are identical to the monochrome versions. The color pixels are transferred in sequence from the camera, in the same manner as the monochrome, but considered as “raw”-format. The camera sensor has a color mosaic filter called “Bayer” filter pattern named after the person who invented it.

  • Page 39: Resolution - Active & Effective

    SVS-VISTEK 7.1.10 Resolution – active & effective As mentions in the specifications, there is a difference between the active and the effective resolution of almost every sensor. Some pixels towards the borders of the sensor will be used only to calibrate the sensor values.

  • Page 40: Offset

    SVS-VISTEK 7.1.11 Offset For physical reasons the output of a sensor will never be zero, even the camera is placed in total darkness or simply closed. Always there will be noise or randomly appearing electrons that will be detected as a signal.

  • Page 41: Gain

    SVS-VISTEK 7.1.12 Gain Setting gain above 0 dB (default) is another way to boost the signal coming from the sensor. Especially useful for low light conditions. Setting Gain amplifies the signal of individual or binned pixels before the ADC. Referring to Photography adding gain corresponds to increasing ISO.

  • Page 42: Image Flip

    SVS-VISTEK 7.1.13 Image Flip Images can be mirrored horizontally or vertically. Image flip is done inside the memory of the camera, therefore not increasing the CPU load of the Figure 32: Figure of original image Figure 33: Figure of image horizontally flipped...

  • Page 43: Binning

    SVS-VISTEK 7.1.14 Binning Binning provides a way to enhance dynamic range, but at the cost of lower resolution. Instead of reading out each individual pixel, binning combines charge from neighboring pixels directly on the chip, before readout. Binning is only used with monochrome CCD Sensors. For reducing resolution on color sensors refer to decimation.

  • Page 44: Burst Mode

    (as soon as there is enough time later on to deliver the images) (not applicable to USB cameras) Please note, as soon as the internal memory buffer is filled up, frames will be dropped. Due to this reason, SVS-Vistek camers provide up to 512MB image buffer memory. Feature-Set...

  • Page 45: Camera Features

    SVS-VISTEK 7.2 Camera Features 7.2.1 Standard Tap Geometries Similar to other sensor readout technologies Camera Link is sending many pixel values in parallel at the same time. The image can be split in “taps” or “channels” which can be sent in parallel. The tap geometry is describing how many taps are read and how they are transmitted through the Camera Link interface.
  • Page 46 SVS-VISTEK In a single-tap CCD sensor the readout of pixel charge is done sequentially. Pixel by pixel, line by line. The maximum frame rate is determined by the pixel clock frequency and the total number of pixels to be read out.

  • Page 47: Tap Balancing

    SVS-VISTEK 1.1.1.1 Tap Reconstruction on GigE Vision Tap reconstruction takes place within the Camera in order to display the image correctly. Further balancing still can be done after reconstruction. 7.2.3 Tap Balancing In sensors with multiple the tap structure, parts of the picture may appear differently.

  • Page 48: System Clock Frequency

    SVS-VISTEK 7.2.4 System Clock Frequency Default system clock frequency in almost every SVCam is set to 66.6 MHz. To validate your system frequency: refer to: specifications. Using the system clock as reference of time, time settings can only be made in multiples of 15 ns.

  • Page 49: Basic Capture Modes

    SVS-VISTEK 7.2.7 Basic Capture Modes Free Running Free running (fixed frequency) with programmable exposure time. Frames are readout continously and valid data is indicated by LVAL for each line and FVAL for the entire frame. There is no need to trigger the camera in order to get data. Exposure time is programmable via serial interface and calculated by the internal logic of the camera.
  • Page 50 At the rising edge of the trigger the camera will initiate the exposure. The software provided by SVS-Vistek allows the user to set exposure time e.g. from 60 μs 60 Sec (camera type dependent).
  • Page 51 SVS-VISTEK Software Trigger Trigger can also be initiated by software (serial interface). NOTICE Software trigger can be influenced by jitter. Avoid Software trigger at time sensitive applications Feature-Set...

  • Page 52: Lookup Table

    SVS-VISTEK 7.2.8 LookUp Table The LookUp Table Feature (LUT) lets the user define certain values to every bit value that comes from the ADC. To visualize a LUT a curve diagram can be used, similar to the diagrams used in photo editing software.
  • Page 53 SVS-VISTEK Gamma Correction Using the LookUp Table makes is also possible to implement a logarithmic correction. Commonly called Gamma Correction. Historically Gamma Correction was used to correct the illumination behavior of CRT displays, by compensating brightness-to-voltage with a Gamma value between 1,8 up to 2,55.

  • Page 54: Roi / Aoi

    SVS-VISTEK 7.2.9 In Partial Scan or Area-Of-Interest or Region-Of-Interest (ROI) -mode only a certain region will be read. Figure 50: Illustration of AOI limitation on a CCD sensor Selecting an AOI will reduce the number of horizontal lines being read.

  • Page 55: Defect Pixel Correction

    All image sensor have defect pixels in a lesser or greater extent. The number of defects determines the quality grade and the value of all sensors integrated by SVS-VISTEK. Defect Pixels either be dark pixels, i.e. that don’t collect any light, or bright pixels (hot pixel) that always are outputting a bright signal.

  • Page 56: Shading Correction

    SVS-VISTEK 7.2.11 Shading Correction The interactions between objects, illumination, and the camera lens might lead to a non-uniform flatfield in brightness. Shading describes the non- uniformity of brightness from one edge to the other or center towards edge(s). This shading can be caused by non-...

  • Page 57: I/O Features

    SVS-VISTEK 7.3 I/O Features 7.3.1 Assigning I/O Lines – IOMUX The IOMUX is best described as a switch matrix. It connects inputs, and outputs with the various functions of SVCam I/O. It also allows combining inputs with Boolean arguments. Figure 52: "IN0" connected to "debouncer"...
  • Page 58 EPROM. Default setting can be restored from within the Camera. Note: If you connect the camera with a non-SVS-Vistek GigEVision client, you might not see the clearnames of the lines, but only line numbers. In this case, use this list of line names...
  • Page 59 SVS-VISTEK Refer to pinout in input / output connectors when physically wiring. Also the IOMUX can be illustrated as a three dimensional dice. Long address spaces indicate which signals are routed to witch module within the camera. Figure 53: illustration of the backside view of the camera mudules.
  • Page 60 SVS-VISTEK Figure 54: illustration of frontside view to the camera modules. Lines with open end indicate physical in- and outputs Feature-Set...
  • Page 61 SVS-VISTEK input vector to switch matrix name description io_in(0) trigger input 0 – 24 Volt / RS-232 / opto * io_in(1) trigger input 0 – 24 Volt / RS-232 / opto * io_in(2) trigger input 0 – 24 Volt / RS-232 / opto * io_in(3) trigger input 0 –...
  • Page 62 SVS-VISTEK output vector from switch matrix name / register describtion io_out(0) output open drain io_out(1) output open drain io_out(2) output open drain * io_out(3) output open drain * io_txd output, when debug='0' rxd_to_uart1 output (uart_in) trigger output sequenzer_hw_trigger input to module iomux_sequenzer_0...
  • Page 63 SVS-VISTEK Example of an IOMUX configuration > The trigger signal comes in on line 0 > Debounce it. connect line 0 to 8: 1000000000000000000000000 signal appears again on line 15 – debouncer out > Use the prescaler to act only on every second pulse.

  • Page 64: Strobe Control

    SVS-VISTEK 7.3.2 Strobe Control Drive LED lights form within your camera. Control them via ethernet. Figure 55: use the breakout box to simplify your wiring > SVCam cameras have built-in MOSFETs that can drive up to 3 Amperes. > This allows using the cameras as a strobe controller – saving costs.
  • Page 65 SVS-VISTEK 2 IO’s high voltage drain Figure 56: Illustration of two LEDs switched internal by the camera For detailed connector pin out refer to Connectors. For further information using the breakout box and simplifying OIs refer SVCam Connectivity manual. To be found separate within the USP manuals.
  • Page 66 SVS-VISTEK Figure 58: Illustration of schematic wiring with 4IO model using the break out box (matrix) The pulseloop module A fully programmable timer/counter function with four individual pulse generators (pulseloop0 - 3) that can be combined with all SVCam I/O functions, as well as physical inputs and outputs.
  • Page 67 SVS-VISTEK Camera cascade Three cameras are triggered in cascade where the first camera is the master receiving the external trigger, and the master subsequently triggers the two slave cameras. Figure 60: pulseloop – activating three cameras O D U L E P U L S E L O O P...
  • Page 68 SVS-VISTEK LEDs in Continuous Mode Example Calculation “No Flash” (CW Mode) Voltage drop al 5 LEDs, 2,2 V per LED (see spec. of LED) 11 V Max. continuous current (see spec. of LED) 250 mA Voltage Supply 24 V Voltage drop at Resistor (24 V – 11 V) 13 V ����...
  • Page 69 SVS-VISTEK Strobe Timing 7 .3 .2 .1 .1 Exp osu re D e l a y A value, representing the time between the (logical) positive edge of trigger pulse and start of integration time. Unit is 1μs. Default is 0μs.
  • Page 70 SVS-VISTEK Strobe Control Example Setup Figure 61: Illustration of an application using the 4IO Feature-Set...

  • Page 71: Sequencer

    SVS-VISTEK 7.3.3 Sequencer The sequencer is used when different exposure settings and illuminations are needed in a row. E.g. the scenario to be captured may occur in three different versions and should therefore be recorded with three different light source settings.
  • Page 72 SVS-VISTEK Example: Values to set Interval 0 Interval 1 Interval 2 Sequencer 1.000.000 µs 1.000.000 µs 1.000.000 µs Interval (1s) (1s) (1s) Exposure Start 220.000 µs 875.000 µs 190.000 µs Exposure Stop 700.000 µs 125.000 µs 720.000 µs Strobe Start 110.000 µs...

  • Page 73: Pwm

    SVS-VISTEK 7.3.4 PWM Pulse width modulation Description of the function used within the sequencer or implemented by the pulseloop module During Pulse Width Modulation, a duty cycle is modulated by a fixed frequency square wave. This describes the ratio of ON to OFF as duty factor or duty ratio.
  • Page 74 SVS-VISTEK P W M : H E I N T E N S I T Y O F A That duty ratio is calculated as: Δ% = t / T. It is written about the value of "t" as PWMChange0-3[SeqSelector] per sequence into the Registry.

  • Page 75: Plc/Logical Operation On Inputs

    SVS-VISTEK 7.3.5 PLC/Logical Operation on Inputs The logic input combines trigger signals with Boolean algorithms. The camera provides AND, NAND, OR, NOR as below. You might connect 2 signals on the logic input. The result can be connected to a camera trigger signal or it may be source for the next logical operation with another input.

  • Page 76: Serial Data Interfaces

    SVS-VISTEK If neither input is high, a low pulse_out (0) results. Combine trigger input one and two. Y = A v B No trigger input – one nor two – results in a high or a low level pulse_out. Invert both trigger inputs. By inverting the resulting pulse_out you will get the NOR I pulse Y = A ⊽...
  • Page 77 SVS-VISTEK In the SVCam’s these signals are used to send low-power data signals to control light or lenses (MFT). Serial interface Parameter RS-232 RS-422 Maximum open-circuit voltage ±25 V ±6 V Max Differential Voltage 25 V 10 V Min. Signal Range ±3 V...
  • Page 78 SVS-VISTEK UART Packaging Data into containers (adding start and stop bits) is implemented by the UART (Universal Asynchronous Receiver Transmitter) Figure 66: UART encoding of a data stream RS-422 RS-422 is a differential low voltage communication standard. Figure 67: LVDS signal – no return to zero volt...

  • Page 79: Trigger-Edge Sensitivity

    SVS-VISTEK 7.3.7 Trigger-Edge Sensitivity Trigger-Edge Sensitivity is implemented by a “schmitt trigger”. Instead of triggering to a certain value Schmitt trigger provides a threshold. Figure 68:illlustration of schmitt trigger noise suspension - high to low I low to high 7.3.8 Debouncing Trigger Signals Bounces or glitches caused by a switch can be avoided by software within the SVCam.
  • Page 80 SVS-VISTEK Therefor the signal will not be accepted till it lasts at least a certain time. Use the IO Assignment tool to place and enable the debouncer module in between the “trigger” (schmitt trigger) and the input source (e.g.: line DebouncDuration register can be set in multiples of 15ns (implement of system clock).

  • Page 81: Prescale

    SVS-VISTEK 7.3.9 Prescale The Prescaler function can be used for masking off input pulses by applying a divisor with a 4-bit word, resulting in 16 unique settings. > Reducing count of interpreted trigger signal > Use the prescaler to ignore a certain count of trigger signals.

  • Page 82: Specifications

    Specifications All specifications can be viewed as well on our website, www.svs- vistek.com We are proud to have ongoing development on our cameras, so specs might change and new features being added. SVS-VISTEK–Specifications I/O Features...

  • Page 83: Hr11002*Tlgec

    SVS-VISTEK 8.1 hr11002*TLGEC Model hr11002MTLGEC hr11002CTLGEC familiy active pixel w x h 4032 x 2672 4032 x 2672 max. frame rate 6,5 fps 6,5 fps chroma mono color interface Dual GigE Vision Dual GigE Vision sensor name KAI-11002-A KAI-11002-C sensor manufacturer...
  • Page 84 70x71x55,4 mm weight 320 g 320 g protection class IP30 IP30 power consumption 8,0 W 8,0 W ambient temperature -10...45°C -10...45°C housing temperature status production production (1) please refer to model drawings © SVS-VISTEK February 24, 2017 February 24, 2017 Specifications...
  • Page 85 SVS-VISTEK Spectral Sensitivity Characteristics Figure 74: Spectral Sensitivity Characteristics KAI-11002-C Figure 75: Spectral Sensitivity Characteristics KAI-11002-A Specifications...

  • Page 86: Hr16000*Tlgec

    SVS-VISTEK 8.2 hr16000*TLGEC Model hr16000MTLGEC hr16000CTLGEC familiy active pixel w x h 4896 x 3248 4896 x 3248 max. frame rate 4 fps 4 fps chroma mono color interface Dual GigE Vision Dual GigE Vision sensor name KAI-16000-A KAI-16000-C sensor manufacturer...
  • Page 87 70x71x55,4 mm weight 320 g 320 g protection class IP30 IP30 power consumption 7,0 W 7,0 W ambient temperature -10...45°C -10...45°C housing temperature status production production (1) please refer to model drawings © SVS-VISTEK February 24, 2017 February 24, 2017 Specifications...
  • Page 88 SVS-VISTEK Spectral Sensitivity Characteristics Figure 76: Spectral Sensitivity Characteristics KAI-16000-C Figure 77: Spectral Sensitivity Characteristics KAI-16000-A Specifications...

  • Page 89: Hr16050*Flgea

    SVS-VISTEK 8.3 hr16050*FLGEA Model hr16050MFLGEA hr16050CFLGEA familiy active pixel w x h 4864 x 3264 4864 x 3264 max. frame rate 10,8 fps 10,8 fps chroma mono color interface Dual GigE Vision Dual GigE Vision sensor name KAI-16050-A KAI-16050-C sensor manufacturer...
  • Page 90 70x71x55,4 mm weight 320 g 320 g protection class IP30 IP30 power consumption 10,0 W 10,0 W ambient temperature -10...45°C -10...45°C housing temperature status production production (1) please refer to model drawings © SVS-VISTEK February 24, 2017 February 24, 2017 Specifications...

  • Page 91: Hr16050*Flgec

    SVS-VISTEK 8.4 hr16050*FLGEC Model hr16050MFLGEC hr16050CFLGEC familiy active pixel w x h 4864 x 3264 4864 x 3264 max. frame rate 8 fps 8 fps chroma mono color interface Dual GigE Vision Dual GigE Vision sensor name KAI-16050-A KAI-16050-C sensor manufacturer...
  • Page 92 70x71x55,4 mm weight 320 g 320 g protection class IP30 IP30 power consumption 10,0 W 10,0 W ambient temperature -10...45°C -10...45°C housing temperature status production production (1) please refer to model drawings © SVS-VISTEK February 24, 2017 February 24, 2017 Specifications...
  • Page 93 SVS-VISTEK Spectral Sensitivity Characteristics Figure 78 Spectral Sensitivity Characteristics KAI-16050-A Figure 79: Spectral Sensitivity Characteristics KAI-16050-C Specifications...

  • Page 94: Hr16070*Flgea

    SVS-VISTEK 8.5 hr16070*FLGEA Model hr16070MFLGEA hr16070CFLGEA familiy active pixel w x h 4864 x 3232 4864 x 3232 max. frame rate 11 fps 11 fps chroma mono color interface Dual GigE Vision Dual GigE Vision sensor name KAI-16070-A KAI-16070-C sensor manufacturer...
  • Page 95 70x71x55,4 mm weight 320 g 320 g protection class IP30 IP30 power consumption 10,0 W 10,0 W ambient temperature -10...45°C -10...45°C housing temperature status production production (1) please refer to model drawings © SVS-VISTEK February 24, 2017 February 24, 2017 Specifications...

  • Page 96: Hr16070*Flgec

    SVS-VISTEK 8.6 hr16070*FLGEC Model hr16070MFLGEC hr16070CFLGEC familiy active pixel w x h 4864 x 3232 4864 x 3232 max. frame rate 8,8 fps 8,8 fps chroma mono color interface Dual GigE Vision Dual GigE Vision sensor name KAI-16070-A KAI-16070-C sensor manufacturer...
  • Page 97 70x71x55,4 mm weight 320 g 320 g protection class IP30 IP30 power consumption 10,0 W 10,0 W ambient temperature -10...45°C -10...45°C housing temperature status production production (1) please refer to model drawings © SVS-VISTEK February 24, 2017 February 24, 2017 Specifications...
  • Page 98 SVS-VISTEK Spectral Sensitivity Characteristics Figure 80: Spectral Sensitivity Characteristics KAI-16070-C Figure 81: Spectral Sensitivity Characteristics KAI-16070-C Specifications...

  • Page 99: Hr29050*Flgea

    SVS-VISTEK 8.7 hr29050*FLGEA Model hr29050MFLGEA hr29050CFLGEA familiy active pixel w x h 6576 x 4384 6576 x 4384 max. frame rate 6,2 fps 6,2 fps chroma mono color interface Dual GigE Vision Dual GigE Vision sensor name KAI-29050-A KAI-29050-C sensor manufacturer...
  • Page 100 70x71x55,4 mm weight 320 g 320 g protection class IP30 IP30 power consumption 10,0 W 10,0 W ambient temperature -10...45°C -10...45°C housing temperature status production production (1) please refer to model drawings © SVS-VISTEK February 24, 2017 February 24, 2017 Specifications...

  • Page 101: Hr29050*Flgec

    SVS-VISTEK 8.8 hr29050*FLGEC Model hr29050MFLGEC hr29050CFLGEC familiy active pixel w x h 6576 x 4384 6576 x 4384 max. frame rate 4,9 fps 4,9 fps chroma mono color interface Dual GigE Vision Dual GigE Vision sensor name KAI-29050-A KAI-29050-C sensor manufacturer...
  • Page 102 70x71x55,4 mm weight 320 g 320 g protection class IP30 IP30 power consumption 10,0 W 10,0 W ambient temperature -10...45°C -10...45°C housing temperature status production production (1) please refer to model drawings © SVS-VISTEK February 24, 2017 February 24, 2017 Specifications...
  • Page 103 SVS-VISTEK Spectral Sensitivity Characteristics Figure 82: Spectral Sensitivity Characteristics KAI-29050-C Figure 83: Spectral Sensitivity Characteristics KAI-29050-A Specifications...

  • Page 104: Terms Of Warranty

    If warranty label of camera is broken warranty is void. Seller makes no other warranties express or implied, and specifically, seller makes no warranty of merchantability of fitness for particular purpose. Please contact your local distributor first. What to do in case of Malfunction SVS-VISTEK–Terms of warranty hr29050*FLGEC...
  • Page 105 SVS-VISTEK Terms of warranty...

  • Page 106: Troubleshooting

    – especially when using around 730 nm like “Schott KG 3“ to prevent IR radiation reaching the halogen light. CCD. No serial communication is possible Use “load camera DLL” and try again. between the camera and the PC. SVS-VISTEK–Troubleshooting FAQ...

  • Page 107: Support Request Form / Check List

    SVS-VISTEK Please fax this form to your 10.2 Support Request Form / Check List local distributor. The right Fax number you can find on our Dear valued customer, homepage: http://www.svs- In order to help you with your camera and any interfacing problems we vistek.com...
  • Page 108 SVS-VISTEK Space for further descriptions, screenshots and log-files Troubleshooting...

  • Page 109: Ip Protection Classes

    The conditions must, however, be more severe than code 7 Protected against water from high- pressure Water directed at the enclosure from any angle under high and steam jet cleaning pressure must not have any harmful effect SVS-VISTEK–IP protection classes Support Request Form / Check List...
  • Page 110 SVS-VISTEK IP protection classes...

  • Page 111: Glossary Of Terms

    In electronics, gain is a measure of the ability of a two-port circuit (often an Gain amplifier) to increase the power or amplitude of a signal from the input to the output port by adding energy to the signal. SVS-VISTEK–Glossary of Terms Support Request Form / Check List...
  • Page 112 A camera RAW image file contains minimally processed data from the image sensor. It is referred as raw in its meaning. SVS-VISTEK plays out RAW only. Read-Out control defines a delay between exposure and image readout. It...
  • Page 113 SVS-VISTEK A bright light source with a very short light pulse. Ideal for use with Strobe light industrial cameras, e.g. for “freezing” the image capture of fast moving objects. Can often be a substitute for the electronic shutter of the image sensor.

  • Page 114: Index Of Figures

    Figure 30: Table of dB and corresponding ISO ......... 41 Figure 31: noise caused by increasing gain excessively ....... 41 Figure 32: Figure of original image ............. 42 Figure 33: Figure of image horizontally flipped ........42 SVS-VISTEK–Index of figures Support Request Form / Check List...
  • Page 115 SVS-VISTEK Figure 34: Figure of image vertically flipped ........42 Figure 35: Illustration of vertical binning ..........43 Figure 36: Illustration of horizontal binning ........43 Figure 37: Illustration of 2x2 binning ..........44 Figure 1: table of tap geometry/configurations ........45 Figure 39: Illustrations of the nomenclature used in specifications ..
  • Page 116 SVS-VISTEK Figure 70: block diagram – debouncer in between the trigger source and the trigger ..................80 Figure 71: Illustration of the debouncer module ......... 80 Figure 72: illustration of prescale values ..........81 Figure 73: Illustration of the prescale module ........81 Figure 74: Spectral Sensitivity Characteristics KAI-11002-C....

  • Page 117: Index

    Firmware 18 Connectors 21 Firmware update 17 Contents of Camera Set 10 Firmware Update GigE 18 Continuously Tap Balancing 47 fixed frequency 49, 73 ConvCam 107 Flashing LED Codes 10 Correction 55 Flip 42 SVS-VISTEK– Support Request Form / Check List...
  • Page 118 SVS-VISTEK Frames per Second 34 ISO 41 Free Running 49 Jumbo Frames 24 FVAL 49 Kelvin 38 Gain 41 LED 48 Gamma 53 LED Codes 10 LEDs 73 Gamma Correction 53 LEDs in Continuous Mode 68 Getting Started 10 GigE IP Setup 18...
  • Page 119 SVS-VISTEK PWM 73 Strobe Delay 69 Quad-Tap 46 Strobe Duration 69 raw 38 Strobe Polarity 69 readout 49 Strobe Timing 69 Read-Out 48 Support Request Form 107 Support Request Form / Check Read-Out-Control 48 List 107 reference of time 48 SVCapture 2.x 11...
  • Page 120 SVS-VISTEK XML Files 25 Index...
