Manual E X O S eries G igE
exo174, exo183, exo183T R , exo249, exo250, exo250Z, exo253Z, exo264, exo265,
exo267, exo273, exo304, exo304T R , exo342, exo367, exo367T R , exo387, exo387T R ,
exo428, exo540, exo541, exo542, exo545, exo547, exo990, exo4000

Advertisement

loading
Need help?

Need help?

Do you have a question about the GigE EXO Series and is the answer not in the manual?

Questions and answers

Related Manuals for SVS-Vistek GigE EXO Series

Summary of Contents for SVS-Vistek GigE EXO Series

  • Page 1 Manual E X O S eries G igE exo174, exo183, exo183T R , exo249, exo250, exo250Z, exo253Z, exo264, exo265, exo267, exo273, exo304, exo304T R , exo342, exo367, exo367T R , exo387, exo387T R , exo428, exo540, exo541, exo542, exo545, exo547, exo990, exo4000...
  • Page 2 C ontent Company information Standards Disclaimer Copyright notice Legal information USA and Canada Europe The EXO series 4I/ O adds light and functionality Lens control 3.2.1 The Tracer adds dynamic lens control 3.2.2 Use liquid lens on C-mount 3.2.3 Use of Canon lenses Connectors GigE IP Setup 4.1.1...
  • Page 3 5.5.1 SVCapture 2.x 5.5.2 Software development kit 5.5.3 Firmware update Feature description Basic features 6.1.1 Gain 6.1.2 Resolution 6.1.3 Offset 6.1.4 Color 6.1.5 Flip image 6.1.6 Binning 6.1.7 Decimation 6.1.8 GenICam 6.1.9 Trigger modes 6.1.10 Shutter modes 6.1.11 Exposure 6.1.12 Exposure speed 6.1.13 Auto exposure...
  • Page 4 6.3.2 Assigning I/ O Lines – IOMUX 6.3.3 6.3.4 LED strobe control 6.3.5 Sequencer 6.3.6 Optical input 6.3.7 PLC / Logical operation on inputs 6.3.8 Serial data interfaces 6.3.9 Trigger-edge sensitivity 6.3.10 Debouncing trigger signals 6.3.11 Prescale Dimensions C-mount exo428GE exo183GETR , exo304GETR exo267GE, exo304GE, exo253ZGE exo250GE, exo264GE, exo264ZGE, exo265GE...
  • Page 5 82229 Seefeld Germany Tel.: + 49 (0) 81 52 9985-0 Fax: + 49 (0) 81 52 9985-79 Mail: info@svs-vistek.com Web: https:/ / www.svs-vistek.com S tandards This manual is based on the following standards: DIN EN 62079 DIN EN ISO 12100...
  • Page 6 C opyright notic e Forwarding and duplicating of this document, as well as using or revealing its con- tents are prohibited without written approval. All rights reserved with regard to patent claims or submission of design or utility patent. 1 C ompany information...
  • Page 7 Customers, integrators and end users of SVS-Vistek products might sell these products and agree to do so at their own risk, as SVS-Vistek will not take any liability for any damage from improper use or sale.
  • Page 8 4I/O adds light and func tionality Fig.: 3-1: Illustration of 4I/ O concept of switching LEDs Your SVS-Vistek camera is equipped with the innovative 4I/ O-interface allowing full light control, replacing external strobe controllers. Each of the outputs can be indi- vidually configured and managed using pulse width modulation.
  • Page 9 Up to 4 x open drain high power OUT Up to 4 x high voltage IN – TTL up to 25 Volts Power MOSFET transistors PWM strobe control Sequencer for various configurations PLC fuctionality with AND, OR and timers Safe Trigger (debouncer, prescaler, high low trigger) INFO Find an example how to operate light control in the section on sequencer ("Sequen-...
  • Page 10 Very often varying distances and difficult light conditions make it a hard job to integrate machine vision into an industrial work flow. SVS-Vistek pioneered the use of variable focus lenses into machine vision.
  • Page 11 All of theses functions can be accessed in the application by the camera pro- gramming interface or via GenICam properties. This makes integration of dynamic lens control into third party software possible with no effort. Power supply and data control for the lens are done through the MFT bayonet, so no external cables are vis- ible.
  • Page 12 This camera series does have the firmware support already included in the GenICam tree and provides you with Canon lens control in all GenICam based software pack- ages. 3 T he E X Oseries...
  • Page 13 For finding and accessing your camera, start SVCapture on your computer. As soon as the camera has booted, all SVS-Vistek GigE cameras are showing up in the main window. Select the camera you want to connect to and press ok.
  • Page 14 Manual IP configuration will permit you to Assign a new IP address (make sure the new address is unique and valid in the current subnet) Save a specific address as a permanent address to the camera (Persistent) Save automatic address mode or the manually configured address to the cam- For saving an persistent IP configuration (configuration will survive power off) you need to check the „Persistent IP address“.
  • Page 15 G igE Vis ion 4.2.1 Network (T C P /IP ) A ddres s A s s ignm ent By default, the camera does not have a persistent IP address. When forcing an IP address by using the PC internal network dialog, changes are only valid until the next restart of the Camera.
  • Page 16 Fig.: 4-3: Connecting multiple cameras on multi NICs Multiple c am eras c onnec ted by a s witc h To connect multiple cameras by a switch, the switch must be managed. It might also be necessary to operate the cameras in an “inter packet delay” applying a smother image data stream.
  • Page 17 distributes it to multiple destinations in this mode. Since a GigE camera always needs a single controlling application, there will be only one master application. The controlling master application has to open a camera in multicast mode (IP 232.x.x.x for local multicast groups) in order to allow other applic- ations to connect to the same image data stream.
  • Page 18 Hiros e I/O c onnec tor The Hirose™ connector provides power, input and output signal access. Max power out is 2 Amperes peak. Fig.: 4-6: I/ O Hirose connector layout Inputs and outputs connect via 4I/ O-matrix in the GenICam software tree to the appropriate actions.
  • Page 19 You can put your support request to us via our support form: https:/ / www.svs-vistek.com/ en/ support/ svs-support-request.php Please fill the form with special attention to camera model, frame grabber model and operating system. Our support team will come back to you.
  • Page 20 the Hirose connector to reduce load on the data port. The external power on the Hirose connector is the preferred power source. The power up is defined as follows: Power over USB3, CoaXPress port or GigE port (with PoE) or on the Hirose con- nector will power on the camera.
  • Page 21 C/ C# programming libs and interface SVCapture 2.x is a GenICam/ XML based software tool provided for free. It is created to show the capabilities of your SVS-Vistek camera and to show/ modify values to your cam. Get control of exposure timing, trigger delay, image correction etc. or control up to 4 LED lights connected to the SVCam directly via "GenICam"...
  • Page 22 2. Start installation. Read and accept the terms of license agreement. 3. Choose destination folder and select necessary modules / drivers. The TLxxx modules are the GenTL drivers, necessary as well if you want to use SVS-Vistek driver with third party software.
  • Page 23 Initialization First launch 1. Connect the camera to your computer. In case of a new USB3 camera driver hardware installation notice will pop up. 2. Start SVCapture. SVCapture will try to discover your camera. 3. Click on the camera being found and you’re connected. Depending on your interface type, with TL Settings you are able to adjust which inter- face types should be included in the camera discover process.
  • Page 24 INFO If you have installed third-party GenTL drivers (e.g. Euresys CoaXPress or Camera Link drivers), they should be selectable as well. This works only if third-party software has been installed before SVCapture. 4. Find and adjust your camera features in the GenICam tree. Click and adjust items by number (1.) or slider (2.) and start grabbing images from the camera.
  • Page 25 C:\ Program Files\ SVS-VISTEK GmbH\ SVCam Kit\ SDK INFO Refer to the “ Getting started with SDK” manual for first steps in programming your SVS-Vistek camera. This document should be included in the docs section of your installation. The following platforms are supported:...
  • Page 26 “Firmware Update Tool.exe” and the firmware file (download it from website, login area) matching your camera model. E xec ute firm ware update Download the GigE firmware tool and the firmware file from the SVS-Vistek web- site. Unpack everything into any folder, e.g. “C:\ temp”.
  • Page 27 Fig.: 5-3: Firmware update 5 G etting started...
  • Page 28 For information about the features of your spe- cific model, please refer to the specifications area of our website with your exact model. https:/ / www.svs-vistek.com/ en/ industrial-cameras/ svs-svcam-searchresult.php B as ic features This section covers basic functionality of area sensor cameras.
  • Page 29 6.1.1 G ain Setting gain above 0 dB (default) is a way to boost the signal coming from the sensor. Especially useful for low light conditions. Setting gain amplifies the signal of indi- vidual or binned pixels before the ADC. Referring to photography adding gain cor- responds to increasing ISO.
  • Page 30 will be used only internally to calibrate sensor values (“Dark pixels”). The amount of dark current in these areas is used to adjust the offset (see "Offset" below). For calculating image sizes, the maximum camera resolution is determining max- imum image resolution, refer to the specifications of the camera model). 6.1.3 O ffset For physical reasons the output of a sensor will never be zero, even the camera is...
  • Page 31 6.1.4 C olor Color cameras are identical to the monochrome versions. The color pixels are trans- ferred in sequence from the camera, in the same manner as the monochrome, but considered as “raw”-format. Fig.: 6-3: CCD with Bayer pattern The camera sensor has a color mosaic filter called “Bayer” filter pattern named after the person who invented it.
  • Page 32 Fig.: 6-4: Original image Fig.: 6-5: Horizontal flip 6 F eature description...
  • Page 33 Fig.: 6-6: Vertical flip 6.1.6 Binning Binning provides a way to enhance dynamic range, but at the cost of lower res- olution. Binning combines electron charges from neighboring pixels directly on the chip, before readout. Binning is only used with monochrome CCD Sensors. For reducing resolution on color sensors refer to "Decimation"...
  • Page 34 Horizontal binning Accumulates horizontal pixels. Fig.: 6-8: Horizontal binning 2× 2 B inning A combination of horizontal and vertical binning. When DVAL signal is enabled only every third pixel in horizontal direction is grabbed. Fig.: 6-9: 2x2 binning 6.1.7 Decimation For reducing width or height of an image, decimation can be used.
  • Page 35 Fig.: 6-10: Horizontal decimation Fig.: 6-11: Vertical decimation Dec im ation on c olor s ens ors The Bayer pattern color information is preserved with 1/ 3 horizontal and vertical res- olution. The frame readout speed increases approx. by factor 2.5. Fig.: 6-12: Decimation on color sensors 6 F eature description...
  • Page 36 With your SVCam, the GenICam tree does have some hardware related extensions, especially in the I/ O sector. See the Quick guide install for a short introduction into the SVS-Vistek GenICam tree. The GenICam properties are organized in views. The recommended way to view and adjust is by using SVCapture.
  • Page 37 Default input is Input1 for trigger. At the rising edge of the trigger the camera will initiate the exposure. The software provided by SVS-Vistek allows the user to set exposure time e.g. from 60 μs to 60 sec (camera type dependent).
  • Page 38 Details of external trigger m ode Diagrams below are equivalent for CCD and CMOS technique. 6 F eature description...
  • Page 39 6 F eature description...
  • Page 40 6.1.10 S hutter modes CCD and CMOS area cameras consist of pixels, ordered in lines and columns. All pixel are exposed to light and then read out to camera electronics. There is a dif- ference of reading out the sensor between global and rolling shutter. Especially flash- ing and moving objects might need more attention with rolling shutter.
  • Page 41 the maximum achievable frame rate with applied ROI will be the maximum frame rate of the sensor reading the full sensor area (internal full sensor speed), please refer to relating sensor specs. Artifacts All pixel show same artifacts Deformed image of moving objects Exposure with flash Fig.: 6-13: flash control with rolling shutter Flash strobe on whole exposure time...
  • Page 42 Light control with rolling shutter As being said, not all sensor lines are sensitive to light at the same time. Make sure your light is ON as long any pixel are going to e exposed. An exo183xGE i.e. needs about 62ms of minimal scanning time. An exo183xCL i.e. needs about 120ms of minimal scanning time.
  • Page 43 pen. In the final scanning time, less and less pixels are sensitive to light until the sensor light sensitivity will finish. Rolling shutter limitations Due to the principles of rolling shutter, some standard features of SVS- Vistek cameras are not applicable. External exposure control (expose while trigger signal active) does not make sense with rolling shutter ROI with rolling shutter: With rolling shutter the whole sensor has to be read out...
  • Page 44 G lobal R es et R eleas e Mode Global reset release mode is a special mode to operate rolling shutter sensors. All rolling shutter cameras from SVS-VISTEK GmbH can be operated in Global Reset Release mode. Global reset release shows advantages when operating light sources in non-constant light situations.
  • Page 45 Fig.: 6-16: strobe control in global reset mode In Global Reset Mode flash is starting together with exposure, all CMOS lines are sensitive to light. Flash time has to be shorter than exposure time. Exposure time is determined by flash time. INFO Strobe control jitter might be visible in the image as structures or as brightness instabilities.
  • Page 46 Maximum frame rate might depend on: Pixel clock Image size Tap structure Data transport limitation Processing time L im itations exo183 on expos ure tim e In general, the SVS-specific camera design permits frame rates close to this formula: Fps_max = 1 / exposure time The exo183 has some specific sensor properties.
  • Page 47 6.1.14 A cquisition and processing time The camera has to read the sensor, process the data to a valid image and transfer this to the host computer. Some of these tasks are done in parallel. This implies the data transfer does not end immediately after end of exposure, as the image has to be processed and transferred after exposure.
  • Page 48 6.1.15 Bit depth Values of brightness are internally represented by numbers. The num- ber of bits for brightness representation is limiting the number of color values that can be represented. Bit depth defines the maximum unique colors or gray levels in an image. bit depth No of gray values = 2 All SVCam models support 8-bit format.
  • Page 49 NOTICE Unpacking has to be done manually, this is not a GenTL function. Thus, image acquisition in packed formats won’t be supported by most 3 party software products. 6 F eature description...
  • Page 50 6.1.16 R O I / A O I In partial scan mode or Area-Of-Interest (AOI) mode (or Region-Of-Interest (ROI) mode) only a certain region of the sensor will be read. Fig.: 6-18: AOI on area sensor Selecting an AOI will reduce the number of horizontal lines being read. This will reduce the amount of data to be transferred, thus increasing the maximum speed in terms of frames per second.
  • Page 51 birefringence, the reduction of reflections and glare or simply the enhancement of contrast between materials that are difficult to tell apart with conventional imaging modalities. W hat is light polarization Polarization is a property that characterizes the geometrical orientation of the oscil- lation of the electric field of light.
  • Page 52 (A) Linear polarization at 125° and 2D representation of the electric field vector for a complete cycle. (B) Circular polarization and 2D representation of the trace of the electric field vector over a complete cycle describes a circle. (C) Light from multiple sources, as obtained from the sun or incandescent light bulbs, consists of multiple wave trains.
  • Page 53 (A) A grid polarizer blocks the polarization component that is parallel to the grid array. Only light perpendicular to the grid can pass through. (B) Grid polarizers with different grid orientations result in linear polarized light with orientations perpendicular to the grid orientation, respectively. Here grid ori- entations of 0°, 45°, 135°...
  • Page 54 White balance gets much more difficult. Contrast is lower. INFO SVS-VISTEK recommends IR cut filter for high demands on sharpness with mono- chrome or color sensors. S pec tral im pac t of IR c ut filters IR cut filter do influence the spectral sensitivity of the sensor.
  • Page 55 Fig.: 6-22: IR cut filter light transmission F oc al im pac t of filters As an IR cut filter mainly consist of a small layer of glass (1 mm thick) there is an impact on the flange focal distance. Refraction within the layer cause shortening this distance.
  • Page 56 This shading can be caused by non-uniform illumination, non-uniform camera sens- itivity, vignetting of the lens, or even dirt and dust on glass surfaces (lens). Shading correction is a procedure to create a flatfield image out of a non-uniform image regardless of the reasons of the non-uniformity. Before doing shading cor- rection, make sure your lens is clean and in perfect condition.
  • Page 57 First, shading reference images have to be taken with shading correction disabled (use 16 images minimum). Save it on disk. Use std .bmp files here, if possible with more than 8 bit. 1. Run shading assistant-> Generate Map Fig.: 6-23: Shading control disabled 2.
  • Page 58 5. Save map to disk. This file can be used in programmed environments via SDK as well. 6. Upload it to the camera and see the result. If lighting did not change from start of procedure, you should see a uniform image with enabled shading control. 7.
  • Page 59 The amount of hot pixels is proportional to exposure time and temperature of the sensor. By default, all known defect pixels or clusters are corrected by SVS-VISTEK as a fact- ory default. Under challenging conditions or high temperature environments defect pixel beha- viour might change.
  • Page 60 For easy image processing, it is recommended to have pixel correction activated Pixel correction maps can be saved and loaded The std factory map can be selected any time Generate your own custom map Select your own defect pixel map The procedure to create a std map is pretty straight forward.
  • Page 61 1. Load black images (16 images minimum) into generator 2. Generate map 3. Save map to file for later usage 4. Upload the map to the camera. Make sure pixel correction is activated. 6 F eature description...
  • Page 62 6.2.4 Look-up table The look-up table feature (LUT) lets the user define certain values to every bit value that comes from the ADC. To visualize a LUT a curve diagram can be used, similar to the diagrams used in photo editing software.
  • Page 63 Historically gamma correction was used to correct the illumination behavior of CRT displays, by compensating brightness-to-voltage with a gamma value between 1,8 up to 2,55. The gamma algorithms for correction can simplify resolution shifting as shown seen below. Input & output signal range from 0 to 1 Gamma Output-signal = Input-signal Fig.: 6-26: Several gamma curves comparable to a LUT...
  • Page 64 6.2.5 R O I / A O I In partial scan mode or Area-Of-Interest (AOI) mode (or Region-Of-Interest (ROI) mode) only a certain region of the sensor will be read. Fig.: 6-27: AOI on area sensor Selecting an AOI will reduce the number of horizontal lines being read. This will reduce the amount of data to be transferred, thus increasing the maximum speed in terms of frames per second.
  • Page 65 6.2.6 Basic capture modes The camera has 2 basic operation modes. Free run (timed) run: The camera will expose and deliver images on a fixed schedule. Triggered: The camera will wait for an external sig- nal and start exposure after receiving the external trigger signal.
  • Page 66 Tracer series models support special mount type. For matching lenses visit http:/ / www.four-thirds.org/ en/ microft/ lens_chart.html or call your local SVS-VISTEK distributor. INFO For SVS-Vistek MFT cameras, you’ll find the controls in the GenICam tree as soon as the lens is mounted on the camera. 6 F eature description...
  • Page 67 Fig.: 6-31: Micro Four Thirds in close view Mounting lens es INFO There is a difference in the back focus distance between „ Four Thirds“ -lenses and „ Micro Four Thirds“ lenses. Your camera is equipped with a “ Micro Four Thirds” con- nector.
  • Page 68 Fig.: 6-32: Illustration of physical data stream in time 6.2.9 T emperature sensor A temperature sensor is installed on the main board of the camera. To avoid over- heating, the temperature is constantly monitored and read. Besides software mon- itoring, the camera indicates high temperature by a red flashing LED (see flashing LED codes).
  • Page 69 S ave us er s ets Select the user set to be saved in the UserSetSelector and save it with the UserSetSave command. S et a us er s et as default Use User Set Default to select the user set that is to be loaded when the camera is star- ted.
  • Page 70 (not applicable to USB cameras) INFO As soon as the internal memory buffer is filled up, frames will be dropped. Due to this, SVS-Vistek cameras provide up to 512 MB image buffer memory. 6 F eature description...
  • Page 71 Standard 2.0. INFO Cameras from SVS-Vistek require firmware b2987 at least for operating PTP. According to the PTP protocol, several devices agree on a master. The other devices in the network communicate with the master as slaves and synchronize their own time base for the time stamp with the time base of the master.
  • Page 72 Fig.: 6-36: Enable synced multi camera trigger in PTP slave mode INFO Slave operation with Precision Time Protocol is permitted with timed exposure only. INFO It is recommended to connect the cameras with a single switch. Daisy-chain switches are not permitted. 6 F eature description...
  • Page 73 With your SVCam, the GenICam tree does have some hardware related extensions, especially in the I/ O sector. See the Quick guide install for a short introduction into the SVS-Vistek GenICam tree. The GenICam properties are organized in views. The recommended way to view and adjust is by using SVCapture.
  • Page 74 6.3.2 A ssigning I/O Lines – IO MUX The IOMUX is best described as a switch matrix. It connects inputs, and outputs with the various functions of SVCam I/ O. It also allows combining inputs with Boolean arguments. Fig.: 6-37: "IN0" connected to "debouncer" Now the debounced signal can be taken from Debouncer (line 8) in the next module as source.
  • Page 75 LineSelector T rans lation Line20 Pulse2 Line21 Pulse3 Line22 Uart2 In The input and output lines for Strobe and Trigger impulses can be arbitrarily assigned to actual data lines. Individual assignments can be stored persistently to the EPROM. Default setting can be restored from within the Camera. INFO Refer to pin-out in input / output connectors when physically wiring.
  • Page 76 Input vec tor to s witc h m atrix Name Description io_in(0) trigger input 0 – 24 Volt / RS-232 / opto * io_in(1) trigger input 0 – 24 Volt / RS-232 / opto * io_in(2) trigger input 0 – 24 Volt / RS-232 / opto * io_in(3) trigger input 0 –...
  • Page 77 O utput vec tor from s witc h m atrix Nam e / regis ter Des c ription io_out(0) output open drain io_out(1) output open drain io_out(2) output open drain * io_out(3) output open drain * io_txd output, when debug= '0' rxd_to_uart1 output (uart_in) trigger...
  • Page 78 E xam ple of an IO MUX c onfiguration Fig.: 6-38: Example of an IOMUX configuration The trigger signal comes in on line 0 Debounce it. connect line 0 to 8: 1000000000000000000000000 signal appears again on line 15 – debouncer out Use the prescaler to act only on every second pulse.
  • Page 79 Inverter The inverter enabled at a certain line provides the reverse signal to or from a module. Set to “1” With set to “1” enabled in a certain line, this line will provide a high signal no matter what signal was connected to the line before. Set to “1”...
  • Page 80 6.3.3 P W M During Pulse Width Modulation (PWM), a duty cycle is modulated by a fixed fre- quency square wave. This describes the ratio of ON to OFF as duty factor or duty ratio. W hy P W M? Pulse width modulation is an extremely efficient way (in terms of power dissipation) to provide/ regulate electrical power to consumers as long as they do not need unin- terrupted supply (such as diodes or LEDs).
  • Page 81 Fig.: 6-39: PWM intensity Examples of PWMs The integrals over both periods are equal. An equal amount of Photons will be emitted. The intensity of light is the same. The periods are equal in length. 6 F eature description...
  • Page 82 Fig.: 6-40: Example: 25% PWM load Fig.: 6-41: Example: 50% PWM load 6 F eature description...
  • Page 83 Fig.: 6-42: Example: 75% PWM load The PWM module Fig.: 6-43: The PWM module 6 F eature description...
  • Page 84 6.3.4 LE D strobe control The SVCam 4I/ O concept contains an integrated strobe controller. Its controls are integrated into the GenICam tree. With LED lights attached to the outputs, this enables the user to control the light without external devices. Being controlled via GenICam, any GenICam-compliant 3 party software is able to control the light as well.
  • Page 85 Table: 6-5: Example Calculation “No Flash” (CW Mode) L E Ds in flas h m ode Most LED lights can cope with currents higher than specs. This gives you higher light output when light is ON. Refer to your LED specs if LED overdrive is permitted. By controlling the duty cycle the intensity of light and current can be controlled.
  • Page 86 6.3.5 S equencer The sequencer is used when different exposure settings and illuminations are needed in a row. Values to set Description Sequencer interval Duration of the interval Exposure start Exposure delay after interval start Exposure stop Exposure stop related to interval Start Strobe start Strobe delay after interval start Strobe stop...
  • Page 87 I/ O matrix 4 images to be taken (RGBW) result in 4 sequences RGB PWM change with different intensities (duty cycle) taking care for dif- ferences in spectral response of the camera sensor PWM change 0-2 is connected to out 0-2 Seq pulse A is driving the exposure (trigger) Seq pulse B is driving the strobe Seq pulse B in WHITE sequence is reduced down to 33% as light intensities of 3...
  • Page 88 Values to set in GenICam prop- Interval 1 erties Interval 0 (RED) (GREEN) Interval 2 (BLUE) Interval 3 (WHITE) Sequencer Interval 66666667 tic 66666667 tic 66666667 tic 66666667 tic (1000 ms) (1000 ms) (1000 ms) (1000 ms) 0 tic 0 tic 6666667 tic 0 tic Seq pulse A start...
  • Page 89 S equenc er s etup with S VC apture Starting with SVCapture 2.5.2, there is a sequencer assistant, providing easy setup of the sequencer settings. The assistant will help you to setup timings for start exposure and lighting and so on. The PWMs are connected to the physical outputs (e.g. for driv- ing LED lights)..
  • Page 90 Feature name Feature value Acquisition Control - Continuous Acquisition Mode Acquisition Control – Trigger Selector - Trig- ger Mode Acquisition Control – Line 1 Trigger Selector - Trig- ger Source Acquisition Control – Trigger Selector – Trigger Width Exposure Mode Enhanced IO –...
  • Page 91 If your camera trigger is in the ms range or slower, we recommend to use the optical input. An optical input needs some current for operation. The SVS-Vistek optical input is spe- cified to 5-24 V, 8 mA. Fig.: 6-46: Optical input The optocoupler galvanically separates electrical circuits by emitting light on one side and interpreting light in the other.
  • Page 92 Do it in the G enIC am tree The logic function always combines the values of Digital IO InputA/ LogicA and InputB/ LogicB. In case of the Trigger enable logic function, LogicB is the trigger enable signal and will be combined with LogicA value. NAND XNOR A B Y...
  • Page 93 6.3.8 S erial data interfaces (ANSI EIA/ ) TIA-232-F RS-232 and RS-422 (from EIA, read as Radio Sector or commonly as Recommended Standard) are technical standards to specify electrical characteristics of digital sig- naling circuits. Serial connection might be used to control SVCams. These signals are used to send low-power data signals to control exposure, light or lenses (MFT).
  • Page 94 6.3.9 T rigger-edge sensitivity Trigger-edge sensitivity is implemented by a “Schmitt trigger”. Instead of triggering to a certain value, the Schmitt trigger provides a threshold. Fig.: 6-48: Schmitt trigger noise suppression 6 F eature description...
  • Page 95 6.3.10 Debouncing trigger signals Bounces or glitches caused by a switch can be avoided by software within the SVCam. Fig.: 6-49: Bounces or glitches caused by a switch Therefore the signal will not be accepted until it lasts at least a certain time. >...
  • Page 96 Input 1 debounce time here is about 1ms. T he debounc er m odule Fig.: 6-51: The debouncer module 6 F eature description...
  • Page 97 6.3.11 P rescale The Prescale function can be used for masking off input pulses by applying a divisor with a 4-bit word, resulting in 16 unique settings. Reducing count of interpreted trigger signal Use the prescale function to ignore a certain count of trigger signals. Divide the amount of trigger signals by setting a divisor.
  • Page 98 Dim ens ions INFO All length units in mm. Find the technical drawings in the web download area at https:/ / www.svs-vistek.com/ en/ support/ svs-support-download-center.php CAD step files available with valid login at SVS-VISTEK.com C -m ount C-mount back focus distance from sensor to lens is 17.526 mm. The camera is fitted with a standard C-mount threading.
  • Page 99 exo428G E 7 Dimensions...
  • Page 100 7 Dimensions...
  • Page 101 7 Dimensions...
  • Page 102 exo183G E T R , exo304G E T R 7 Dimensions...
  • Page 103 7 Dimensions...
  • Page 104 exo267G E , exo304G E , exo253ZG E 7 Dimensions...
  • Page 105 7 Dimensions...
  • Page 106 Fig.: 7-2: exo267*GE, exo304*GE, exo253Z*GE right view 7 Dimensions...
  • Page 107 7 Dimensions...
  • Page 108 exo250G E , exo264G E , exo264ZG E , exo265G E Fig.: 7-3: exo250*GE, exo264*GE, exo265*GE back view 7 Dimensions...
  • Page 109 7 Dimensions...
  • Page 110 Fig.: 7-4: exo250*GE, exo264*GE, exo265*GE top view 7 Dimensions...
  • Page 111 exo4000G E 7 Dimensions...
  • Page 112 Fig.: 7-5: exo4000*GE left side view 7 Dimensions...
  • Page 113 7 Dimensions...
  • Page 114 exo174G E , exo183G E , exo249G E Fig.: 7-6: exo174*GE, exo183*GE, exo249*GE front view 7 Dimensions...
  • Page 115 7 Dimensions...
  • Page 116 7 Dimensions...
  • Page 117 exo367G E 7 Dimensions...
  • Page 118 7 Dimensions...
  • Page 119 exo387G E 7 Dimensions...
  • Page 120 7 Dimensions...
  • Page 121 7 Dimensions...
  • Page 122 7.10 exo342G E 7 Dimensions...
  • Page 123 7 Dimensions...
  • Page 124 7 Dimensions...
  • Page 125 7.11 exo540G E , exo541G E , exo542G E , exo545G E , exo547G E 7 Dimensions...
  • Page 126 7 Dimensions...
  • Page 127 7.12 exo990G E , exo991G E 7 Dimensions...
  • Page 128 7 Dimensions...
  • Page 129 7 Dimensions...
  • Page 130 A ppendix I/O driver c irc uit s c hem atic s Camera power supply and power supply for PWM out is 25V max. Power for PWM out has to be supplied via Hirose connector. The open drain outputs are ledged to ground, that means you connect your LED on the positive side to your (light-)power source, the negative LED connector goes to the camera out.
  • Page 131 IP protec tion c las s es 8 A ppendix...
  • Page 132 IP Protection Classes is a classification system regarding the kind of environment influences which might do harm to your product. 8 A ppendix...
  • Page 133 First Second Digit Digit Brief description Definition Not protected Protected against A probing object, a ball of 50mm in dia- solid foreign meter, must not enter or penetrate the objects, enclosure 50 mm and larger Protected against A probing object, a ball of 12.5mm in solid foreign diameter, must not enter or penetrate the objects, 12.5 mm...
  • Page 134 First Second Digit Digit Brief description Definition enclosure from any angle must not have any harmful effect Water must not enter the equipment in Protected against amounts that can have a harmful effect if the effect of brief the enclosure is briefly submerged in submersion in water under standardised pressure and water...
  • Page 135 SVS-VISTEK GmbH Mühlbachstr. 20 82229 Seefeld Phone: + 49 (0) 81 52 9985-0 https:/ / www.svs-vistek.com info@svs-vistek.com © April-2021...
