QTek S200 User Manual page 11

No. Item
1 MMC/SD or SDIO
Card Slot
2 CAMERA Button
3 Volume Controller
4 COMM MANAGER/
RECORD Button
5 Strap Holder
6 Notification LEDs
7 Touch Screen
8 Left SOFT KEY
9 Right SOFT KEY
10 TALK Button
11 START Button
12 Navigation Control Press this multi-directional control up, down, left, or right to move through
13 OK Button
14 END Button
15 Stylus
16 POWER Button
17 Infrared Port
18 Car Antenna
Connector
19 Self-Portrait Mirror Turn the back side of your device to face yourself so that your image reflects
Function
In this card slot, insert an MMC or SD card for storing data, or insert an SD
input/output card such as a network card.
Press to launch the camera; press again to take a photo or video clip,
depending on the specified capture mode.
Slide up or down to adjust the volume.
Press to open Comm Manager; press and hold to record a voice note.
Lets you attach a strap for carrying your device.
Green and Amber LED for GSM standby, SMS message, GSM network
status, notification, and battery charging status.
Blinking Blue LED for Bluetooth system notification of powered-up and ready
to transmit radio frequency signal, and blinking Green for Wi-Fi status.
Tap the stylus on-screen to write, draw, or make a selection.
Performs the command shown in the label above the button.
Performs the command shown in the label above the button.
Press to answer an incoming call or dial a number.
Press to open the Start menu.
menus, program instructions; carry out the selection by pressing the center
button.
Press to confirm your data entries, or to exit the program in use.
Press to end a call.
Use the stylus to write, draw, or select items on the touch screen.
Press to turn off your device temporarily. This switches your device to sleep
mode. To turn it off completely, press and hold (for about 5 seconds).
When your device is in sleep mode, you can still use the phone function
to receive calls. When you turn off the device completely, all functions
including the phone will be unavailable for use.
Lets you exchange file(s) or data with other devices wirelessly.
You can connect your phone to a car antenna to have better reception
quality.
on the mirror when taking self-portrait shots.
Getting Started 11
