Page 1 Pictorial index Search by illustration For safety Make sure to read through them and security Instrument How to read the gauges and meters, the variety of cluster warning lights and indicators, etc. Operation of Opening and closing the doors and windows, each component adjustment before driving, etc.
Page 2: Table Of Contents
TABLE OF CONTENTS For your information....... 8 Instrument cluster Reading this manual ....12 How to search......13 Pictorial index ......14 Instrument cluster Warning lights For safety and security and indicators ....78 Gauges and meters ..... 84 Multi-information display..88 1-1.
Page 3 Opening the fuel tank cap........232 4-5. Using the driving support 4-1. Before driving systems Driving the vehicle..... 166 Toyota Safety Sense P..235 Cargo and luggage.... 176 Vehicle load limits ..... 180 (Pre-Collision System)..242 Trailer towing..... 181 LDA (Lane Departure Dinghy towing....
Page 4 TABLE OF CONTENTS ® 5-9. Bluetooth Phone Audio system Making a phone call... 383 When receiving a phone call ......385 5-1. Basic Operations Speaking on the phone..386 Audio system types ... 328 ® 5-10. Bluetooth Using the steering wheel ®...
Page 5: Automatic
5-17. Using an external device 5-21. Phonebook iPod player operation ..420 Contact/Call History Settings ......462 USB memory device ® player operation ....425 5-22. Bluetooth Using the AUX port ... 430 What to do if... ® (Troubleshooting) .... 472 5-18.
Page 6 TABLE OF CONTENTS 6-4. Using the other interior 7-3. Do-it-yourself maintenance features Do-it-yourself service precautions...... 553 Other interior features ..523 • Sun visors ....523 Hood ........555 • Vanity mirrors ....523 Positioning a floor jack..557 • Power outlets ....524 Engine compartment ..
Page 7 For vehicles with Entune Premium Audio with Navigation or Entune Audio Plus, refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL” for information regarding the equipment listed below. • Navigation system • Toyota parking assist monitor • Audio system • Panoramic view monitor • Rear view monitor system RAV4_OM_OM0R012U_(U)
Page 8: For Your Information
Accessories, spare parts and modification of your Toyota A wide variety of non-genuine spare parts and accessories for Toyota vehi- cles are currently available on the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
Page 9 SRS airbag system ● Seat belt pretensioner system Be sure to check with your Toyota dealer for precautionary measures or spe- cial instructions regarding installation of a mobile two-way radio system. Vehicle data recordings Your Toyota is equipped with several sophisticated computers that will record certain data, such as: •...
Page 10 EDR. ● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehi- cle) is obtained •...
Page 11 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
Page 12: Reading This Manual
Reading this manual WARNING: Explains something that, if not obeyed, could cause death or serious injury to people. NOTICE: Explains something that, if not obeyed, could cause damage to or a malfunction in the vehicle or its equipment. 1 2 3 Indicates operating or working procedures.
Page 13: How To Search
How to search ■ Searching by name • Alphabetical index ..P. 728 ■ Searching installation position • Pictorial index....P. 14 ■ Searching by symptom or sound • What to do if... (Troubleshooting) ..P. 724 ■ Searching by title • Table of contents .....P. 2 RAV4_OM_OM0R012U_(U)
Page 14: Pictorial Index
Pictorial index Pictorial index ■ Exterior Side doors ........P. 107 Locking/unlocking .
Page 15 Pictorial index Windshield wipers ....... . . P. 225 Precautions against winter season ..... P. 317 To prevent freezing (windshield wiper de-icer) .
Page 16 Pictorial index ■ Instrument panel Engine switch....... . . P. 198, 200 Starting the engine/changing the modes .
Page 17 Pictorial index Turn signal lever ........P. 213 Headlight switch .
Page 18 Pictorial index ■ Switches Outside rear view mirror switches ....P. 153 Instrument panel light control dial ..... P. 86 LDA (Lane Departure Alert with steering control) switch .
Page 19 Pictorial index Audio remote control switches ....P. 331, 396 Telephone switches ......P. 368, 459 Paddle shift switches .
Page 20 Pictorial index Emergency flasher switch ......P. 608 1, 2 Panoramic view monitor switch VSC OFF switch ........P. 312 Driving mode select switches .
Page 21 Pictorial index ■ Interior SRS airbags ........P. 36 Floor mats .
Page 22 Pictorial index Auxiliary box ........P. 511 Interior lights /Personal lights .
Page 23 For safety and security 1-1. For safe use Before driving...... 24 For safe driving ....26 Seat belts ......28 SRS airbags......36 Front passenger occupant classification system ..49 Safety information for children ......56 Child restraint systems..57 Installing child restraints..
Page 24: 1-1. For Safe Use
1-1. For safe use Before driving Floor mat Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks (clips) into the floor mat eyelets. Turn the upper knob of each retaining hook (clip) to secure the floor mats in place.
Page 25 When installing the driver’s floor mat ● Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver’s seat. ●...
Page 26: For Safe Driving
1-1. For safe use For safe driving For safe driving, adjust the seat and mirror to an appropriate position before driving. Correct driving posture Adjust the angle of the seat- back so that you are sitting straight up and so that you do not have to lean forward to steer.
Page 27 1-1. For safe use Adjusting the mirrors Make sure that you can see backward clearly by adjusting the inside and outside rear view mirrors properly. (→P. 151, 153) WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ●...
Page 28: Seat Belts
1-1. For safe use Seat belts Make sure that all occupants are wearing their seat belts before driving the vehicle. Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.
Page 29 1-1. For safe use Fastening the seat belt (for the rear center seat) Press plate “B” to release. Then Plate “B” pull the seat belt down toward the rear seat bottom cushion. Push plate “A” into buckle “A” Plate “A” until a clicking sound is heard.
Page 30 1-1. For safe use Releasing and stowing the seat belt (for the rear center seat) To release the hooked buckle “B”, push the release button. Release button To release the hooked plate “A”, insert the plate “B”, the wireless key or the mechanical key (→P.
Page 31 1-1. For safe use Adjusting the seat belt shoulder anchor height (front seats) Push the seat belt shoulder anchor down while pressing the release button. Push the seat belt shoulder anchor up. Move the height adjuster up and down as needed until you hear a click.
Page 32 ■ Seat belt extender If your seat belts cannot be fastened securely because they are not long enough, a personalized seat belt extender is available from your Toyota dealer free of charge. RAV4_OM_OM0R012U_(U)
Page 33 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at one time, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ●...
Page 34 ● Ensure that the belt and plate are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. ● Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there is no obvious damage.
Page 35 1-1. For safe use WARNING ■ When using the rear center seat belt Do not use the rear center seat belt with either buckle released. Fastening only one of the buckles may result in death or serious injury in case of sudden braking, sudden swerving or an accident.
Page 36: Srs Airbags
1-1. For safe use SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. RAV4_OM_OM0R012U_(U)
Page 37 1-1. For safe use ◆ SRS front airbags SRS driver airbag/front passenger airbag Can help protect the head and chest of the driver and front pas- senger from impact with interior components SRS driver knee airbag Can help provide driver protection SRS seat cushion airbag Can help restrain the front passenger ◆...
Page 38 1-1. For safe use SRS airbag system components Side impact sensors (front Side impact sensors (rear) doors) Seat belt pretensioners and Front passenger airbag force limiters Curtain shield airbags Driver’s seat position sensor Front passenger’s seat cush- Driver’s seat belt buckle ion airbag switch...
Page 39 1-1. For safe use Your vehicle is equipped with ADVANCED AIRBAGS designed based on the US motor vehicle safety standards (FMVSS208). The airbag sensor assembly (ECU) controls airbag deployment based on infor- mation obtained from the sensors etc. shown in the system compo- nents diagram above.
Page 40 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front passenger seat.
Page 41 1-1. For safe use WARNING ■ SRS airbag precautions ● Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger. ● Do not allow the front seat occupants to hold items on their knees.
Page 42 If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillar garnishes, are damaged or cracked, have them replaced by your Toyota dealer. ● Do not place anything, such as a cushion, on the front passenger’s seat.
Page 43 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
Page 44 1-1. For safe use ■ SRS airbag deployment conditions (SRS front airbags) ● The SRS front airbags will deploy in the event of an impact that exceeds the set threshold level (the level of force corresponding to an approximately 12 - 18 mph [20 - 30 km/h] frontal collision with a fixed wall that does not move or deform).
Page 45 1-1. For safe use ■ Conditions under which the SRS airbags may deploy (inflate), other than a collision The SRS front airbags, SRS side and curtain shield airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration.
Page 46 1-1. For safe use ■ Types of collisions that may not deploy the SRS airbags (SRS side and curtain shield airbags) The SRS side and curtain shield airbags may not activate if the vehicle is subjected to a collision from the side at certain angles, or a collision to the side of the vehicle body other than the passenger compartment.
Page 47 1-1. For safe use ■ When to contact your Toyota dealer In the following cases, the vehicle will require inspection and/or repair. Con- tact your Toyota dealer as soon as possible. ● Any of the SRS airbags have been inflated. ●...
Page 48 1-1. For safe use ● The portion of the front pillars, rear pil- lars or roof side rail garnishes (padding) containing the curtain shield airbags inside is scratched, cracked or otherwise damaged. RAV4_OM_OM0R012U_(U)
Page 49: Front Passenger Occupant Classification System
1-1. For safe use Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classi- fication system. This system detects the conditions of the front passenger seat and activates or deactivates the devices for the front passenger. Seat belt reminder light SRS warning light “AIR BAG OFF”...
Page 50 1-1. For safe use Condition and operation in the front passenger occupant classi- fication system ■ Adult “AIR BAG ON” and “AIR BAG OFF” “AIR BAG ON” indicator lights Indicator/ SRS warning light warning light Seat belt reminder light flashing Front passenger airbag Side airbag Activated...
Page 51 1-1. For safe use ■ Child “AIR BAG OFF” “AIR BAG ON” and “AIR BAG OFF” indicator lights “AIR BAG ON” Indicator/ warning light SRS warning light Seat belt reminder light flashing Deactivated or Front passenger airbag activated Side airbag on the front passenger seat Activated Curtain shield airbag...
Page 52 1-1. For safe use ■ Unoccupied “AIR BAG ON” and “AIR BAG OFF” “AIR BAG OFF” indicator lights Indicator/ SRS warning light warning light Seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seat Activated Curtain shield airbag Devices in the front passenger side...
Page 53 1-1. For safe use ■ There is a malfunction in the system “AIR BAG ON” and “AIR BAG OFF” “AIR BAG OFF” indicator lights Indicator/ SRS warning light warning light Seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seat Activated Curtain shield airbag...
Page 54 1-1. For safe use WARNING ■ Front passenger occupant classification system precautions Observe the following precautions regarding the front passenger occupant classification system. Failure to do so may cause death or serious injury. ● Wear the seat belt properly. ● Make sure the front passenger’s seat belt plate has not been left inserted into the buckle before someone sits in the front passenger seat.
Page 55 SRS warning light may come on to indicate a malfunction of the front passenger occupant classification system. In this case, contact your Toyota dealer immediately. ● Child restraint systems installed on the rear seat should not contact the front seatbacks.
Page 56: Safety Information For Children
1-1. For safe use Safety information for children Observe the following precautions when children are in the vehi- cle. Use a child restraint system appropriate for the child, until the child becomes large enough to properly wear the vehicle’s seat belt.
Page 57: Child Restraint Systems
1-1. For safe use Child restraint systems A child restraint system for a small child or baby must itself be properly restrained on the seat with the LATCH anchors or the lap portion of the lap/shoulder belt. The laws of all 50 states of the U.S.A. and Canada now require the use of child restraint systems.
Page 58 1-1. For safe use Types of child restraints Child restraint systems are classified into the following 3 types according to the age and size of the child: Rear facing ⎯ Infant seat/con- Forward facing ⎯ Convertible   vertible seat seat ...
Page 59 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 60 1-1. For safe use WARNING ■ Child restraint precautions ● Do not allow the child to lean his/her head or any part of his/her body against the door or the area of the seat, front and rear pillars or roof side rails from which the SRS side airbags or SRS curtain shield airbags deploy even if the child is seated in the child restraint system.
Page 61: Installing Child Restraints
1-1. For safe use Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the seats using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH (Lower Anchors and Tethers for Children) system.
Page 62 1-1. For safe use Installation with LATCH system If the child restraint has a top tether strap, adjust the head restraint to the upmost position. (→P. 146) Adjust the seatback to the 6th lock position from the most upright position. (→P. 141) Most upright position 6th lock position Widen the gap between the seat cushion and seatback slightly.
Page 63 1-1. For safe use  Type B Latch the buckles onto the LATCH anchors. If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether strap anchor. When installing child restraint system with the head restraint being raised, be sure to have the top tether strap pass...
Page 64 1-1. For safe use Installing child restraints using a seat belt (child restraint lock function belt) Rear-facing ⎯ Infant seat/convertible seat ■ Adjust the seatback to the 6th lock position from the most upright position. (→P. 141) Most upright position 6th lock position If your child restraint system interferes with a head restraint and cannot be installed properly, install the child restraint system after...
Page 65 1-1. For safe use Fully extend the shoulder belt and allow it to retract to put it in lock mode. In lock mode, the belt cannot be extended. While pushing child restraint system down into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place.
Page 66 1-1. For safe use Forward-facing ⎯ Convertible seat ■ Adjust the seatback to the 6th lock position from the most upright position. (→P. 141) Most upright position 6th lock position If your child restraint system interferes with a head restraint and cannot be installed properly, install the child restraint system after removing the head restraint.
Page 67 1-1. For safe use Fully extend the shoulder belt and allow it to retract to put it in lock mode. In lock mode, the belt cannot be extended. While pushing child restraint system into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place.
Page 68 1-1. For safe use Place the child restraint system on the seat facing the front of the vehicle.  Booster type  High back type Sit the child in the child restraint system. Fit the seat belt to the child restraint sys- tem according to the manu- facturer’s instructions...
Page 69 1-1. For safe use Removing a child restraint installed with a seat belt Push the buckle release button and fully retract the seat belt. Child restraint systems with a top tether strap Adjust the seatback to the 6th lock position from the most upright position.
Page 70 1-1. For safe use ■ Laws and regulations pertaining to anchorages The LATCH system conforms to FMVSS225 or CMVSS210.2. Child restraint systems conforming to FMVSS213 or CMVSS213 specifica- tions can be used. This vehicle is designed to conform to the SAE J1819. WARNING ■...
Page 71 1-1. For safe use WARNING ■ When installing a child restraint system ● When installing a child restraint system in the rear center seat, adjust both seatbacks at the same angle. Otherwise, the child restraint system cannot be securely restrained and this may cause death or serious injuries in the event of sudden braking, sudden swerving or an accident.
Page 72: Exhaust Gas Precautions
Keep the back door closed. ● If you smell exhaust gases in the vehicle even when the back door is closed, open the windows and have the vehicle inspected at your Toyota dealer as soon as possible. ■ When parking ●...
Page 73: Theft Deterrent System
1-2. Theft deterrent system Engine immobilizer system The vehicle’s keys have built-in transponder chips that prevent the engine from starting if a key has not been previously regis- tered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehi- cle.
Page 74 1-2. Theft deterrent system ■ Certification  For vehicles sold in the U.S.A. RAV4_OM_OM0R012U_(U)
Page 75 1-2. Theft deterrent system  For vehicles sold in Canada WARNING ■ Certification for the engine immobilizer system Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. RAV4_OM_OM0R012U_(U)
Page 76 1-2. Theft deterrent system NOTICE ■ To ensure the system operates correctly Do not modify or remove the system. If modified or removed, the proper operation of the system cannot be guaranteed. RAV4_OM_OM0R012U_(U)
Page 77: Instrument Cluster
Instrument cluster Instrument cluster Warning lights and indicators ....78 Gauges and meters .... 84 Multi-information display ..88 Fuel consumption information ......94 RAV4_OM_OM0R012U_(U)
Page 78: Instrument Cluster Warning Lights
2. Instrument cluster Warning lights and indicators The warning lights and indicators on the instrument cluster and center panel inform the driver of the status of the vehicle’s vari- ous systems. For the purpose of explanation, the following illustrations dis- play all warning lights and indicators illuminated.
Page 79 2. Instrument cluster Warning lights Warning lights inform the driver of malfunctions in the indicated vehi- cle’s systems. Brake system warning Slip indicator (→P. 620) light (→P. 619) (U.S.A.) Brake system warning Seat belt reminder light light (→P. 619) (→P. 620) (Canada) Malfunction indicator Low fuel level warning...
Page 80 They will turn off after the engine is started, or after a few seconds. There may be a malfunction in a system if the lights do not come on, or turn off. Have the vehicle inspected by your Toyota dealer. : This light illuminates on the center panel.
Page 81 2. Instrument cluster Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Turn signal indicator VSC OFF indicator (→P. 213) (→P. 312) Headlight indicator Security indicator (→P. 215) (→P. 73) (U.S.A.) Tail light indicator “SPORT”...
Page 82 They will turn off after the engine is started, or after a few seconds. There may be a malfunction in a system if the lights do not come on, or turn off. Have the vehicle inspected by your Toyota dealer. : The light flashes to indicate that the system is operating.
Page 83 Have the vehicle inspected by your Toyota dealer immedi- ately if this occurs.
Page 84: Gauges And Meters
2. Instrument cluster Gauges and meters The units used on the meter and display may differ depending on the tar- get region. RAV4_OM_OM0R012U_(U)
Page 85 2. Instrument cluster Tachometer Displays the engine speed in revolutions per minute Speedometer Displays the vehicle speed Fuel gauge Displays the quantity of fuel remaining in the tank Shift position and shift range Displays the selected shift position or selected shift range (→P. 205) Multi-information display Presents the driver with a variety of driving-related data (→P.
Page 86 2. Instrument cluster Changing the odometer and trip meter display Switches the items of the odome- ter and trip meter display by pressing the “TRIP” switch. When the trip meter is displayed, pressing and holding the “TRIP” switch will reset the trip meter. Instrument panel light control The brightness of the instrument panel lights can be adjusted by turn- ing the dial.
Page 87 • When the outside temperature has changed suddenly (at the entrance/ exit of a garage, tunnel, etc.) ● When “--” is displayed, the system may be malfunctioning. Take your vehicle to your Toyota dealer. ● The temperature range that can be displayed is from -40°F (-40°C) to 122°F (50°C).
Page 88: Multi-Information Display
2. Instrument cluster Multi-information display Display contents The multi-information display presents the driver with a variety of vehi- cle data. ● Menu icons Displays the following informa- tion when an icon is selected. (→P. 89) Some of the information may be displayed automatically depending on the situation.
Page 89 2. Instrument cluster Warning message display Select to display warning messages and measures to be taken if a malfunction is detected. (→P. 629) Settings display Select to change the system settings and meter display settings. (→P. 91) : If equipped Operating the meter control switches The multi-information display is operated using the meter control...
Page 90 2. Instrument cluster ■ Average speed (after start/after reset /after refuel) Displays the average vehicle speed since the engine was started, the function was reset and the vehicle was refueled, respectively ■ Range (after refuel) Displays the estimated maximum distance that can be driven with the quantity of fuel remaining •...
Page 91 2. Instrument cluster Settings display The settings of the following items can be changed, refer to P. 697 For functions that can be enabled or disabled, the function switches between on and off each time is pressed. ● (Lane Departure Alert with steering control) (→P.
Page 92 2. Instrument cluster ■ System check display After turning the engine switch to IGNITION ON mode, opening image is dis- played while system operation is checked. When the system check is com- plete, the normal screen will return. ■ Dynamic Torque Control AWD system display Displays the Dynamic Torque Control AWD system operation state and the G- force state.
Page 93 2. Instrument cluster WARNING ■ Caution for use while driving For safety, avoid operating the meter control switches while driving as much as possible, and do not look continuously at the multi-information display while driving. Stop the vehicle and operate the meter control switches. Fail- ure to do so may cause a steering wheel operation error, resulting in an unexpected accident.
Page 94: Fuel Consumption Information
2. Instrument cluster Fuel consumption information The fuel consumption information can be displayed on Entune Premium Audio with Navigation and Entune Audio screen. Display the trip information or past record screen  Vehicles with Entune Audio Press the “CAR” button. ...
Page 95 2. Instrument cluster Past record If the “Past Record” screen does not appear, select “Past Record”. Reset the past record data Best recorded fuel consumption Average fuel consumption (if equipped) Previous fuel consumption record Current fuel consumption Update the past record data “Trip Information”...
Page 96 2. Instrument cluster RAV4_OM_OM0R012U_(U)
Page 97: Operation Of Each Component
Operation of each component 3-1. Key information Keys ........98 3-2. Opening, closing and locking the doors Side doors......107 Back door......113 Smart key system ..... 130 3-3. Adjusting the seats Front seats ......139 Rear seats......141 Driving position memory ... 144 Head restraints....
Page 98: 3-1. Key Information
3-1. Key information Keys The keys The following keys are provided with the vehicle.  Vehicles without smart key system Master keys Operating the wireless remote con- trol function Key number plate Vehicles with smart key system  Electronic keys •...
Page 99 3-1. Key information Wireless remote control  Vehicles without smart key sys-  Vehicles with smart key sys- Locks all the doors (→P. 107) Check that the door is securely locked. Unlocks all the doors (→P. 107) Pressing the button unlocks the driver’s door. Pressing the button again within 3 seconds unlocks the other doors.
Page 100 ■ If you lose your keys New genuine keys can be made by your Toyota dealer using a master key (vehicles without smart key system) or the other mechanical key (vehicles with smart key system) and the key number stamped on your key number plate.
Page 101 ■ Confirmation of the registered key number The number of keys already registered to the vehicle can be confirmed. Ask your Toyota dealer for details. ■ If a wrong key is used (vehicles with smart key system) The key cylinder rotates freely to isolate inside mechanism.
Page 102 3-1. Key information ■ Certification for wireless remote control (vehicles without smart key sys- tem)  For vehicles sold in the U.S.A. RAV4_OM_OM0R012U_(U)
Page 103 3-1. Key information  For vehicles sold in Canada RAV4_OM_OM0R012U_(U)
Page 104 3-1. Key information ■ Certification for wireless remote control (vehicles with smart key sys- tem)  For vehicles sold in the U.S.A. RAV4_OM_OM0R012U_(U)
Page 105 3-1. Key information  For vehicles sold in Canada RAV4_OM_OM0R012U_(U)
Page 106 When an electronic key is lost (vehicles with smart key system) If the electronic key remains lost, the risk of vehicle theft increases signifi- cantly. Visit your Toyota dealer immediately with all remaining electronic keys that was provided with your vehicle.
Page 107: Side Doors
3-2. Opening, closing and locking the doors Side doors Unlocking and locking the doors from the outside ◆ Smart key system (if equipped) Carry the electronic key to enable this function. Grip the driver’s door handle to unlock the door. Grip the front passenger’s/rear pas- senger’s (if equipped) door handle to unlock all the...
Page 108 3-2. Opening, closing and locking the doors ◆  Vehicles without smart key system Locks all the doors Unlocks all the doors Turning the key unlocks the driver’s door. Turning the key again within 3 seconds unlocks the other doors. Vehicles with smart key system ...
Page 109 3-2. Opening, closing and locking the doors Unlocking and locking the doors from the inside ◆ Door lock switch Locks all the doors Unlocks all the doors ◆ Inside lock buttons Locks the door Unlocks the door The front doors can be opened by pulling the inside handle even if the lock buttons are in the lock position.
Page 110 3-2. Opening, closing and locking the doors Rear door child-protector lock The door cannot be opened from inside the vehicle when the lock is set. Unlock Lock These locks can be set to prevent children from opening the rear doors. Push down on each rear door switch to lock both rear doors.
Page 111 3-2. Opening, closing and locking the doors ■ Switching the door unlock function (vehicles with smart key system) It is possible to set which doors the entry function unlocks using the wireless remote control. Turn the engine switch off. When the indicator light on the key surface is not on, press and hold for approximately 5 seconds while pressing and holding The setting changes each time an operation is performed, as shown below.
Page 112 3-2. Opening, closing and locking the doors WARNING ■ To prevent an accident Observe the following precautions while driving the vehicle. Failure to do so may result in a door opening and an occupant throwing out of the vehicle, resulting in death or serious injury. ●...
Page 113: Back Door
3-2. Opening, closing and locking the doors Back door The back door can be locked/unlocked and opened/closed by the following procedures. Locking and unlocking the back door ◆ Smart key system (if equipped) Carry the electronic key to enable this function. Press the button to unlock all the doors.
Page 114 3-2. Opening, closing and locking the doors Opening the back door from outside the vehicle ◆ Back door opener  Vehicles without power back door Raise the back door while pressing up the back door opener switch.  Vehicles with power back door When back...
Page 115 3-2. Opening, closing and locking the doors ◆ Touchless sensor (vehicles with touchless power back door) The touchless power back door enables automatic opening and closing of the power back door by putting your foot near the lower center part of the rear bumper and moving it away from the rear bumper.
Page 116 3-2. Opening, closing and locking the doors Power back door switch (vehicles with power back door) Pressing the switch closes the back door automatically. buzzer sounds.) Pressing the switch while the back door is opening/closing stops the operation. Pressing the switch again will reverse the operation.
Page 117 3-2. Opening, closing and locking the doors Canceling the power back door system (vehicles with power back door) The power back door system can be disabled by operating the multi- information display. Press of the meter control switches and select the multi-information display.
Page 118 3-2. Opening, closing and locking the doors Adjusting the open position of the back door (vehicles with power back door) The open position of the power back door can be adjusted. ■ Using the multi-information display Press of the meter control switches and select on the multi-information display.
Page 119 3-2. Opening, closing and locking the doors ■ Luggage compartment light The luggage compartment light turns on when the back door is opened with the luggage compartment light switch on. ■ If the back door opener is inoperative The back door can be unlocked from the inside. Remove the cover on the back door trim.
Page 120 3-2. Opening, closing and locking the doors  Vehicles with power back door After loosening the screw, move the cover. Push the lever for the back door motor. ■ Back door operation ● A buzzer (if equipped) sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked.
Page 121 3-2. Opening, closing and locking the doors ■ Jam protection function (vehicles with power back door) If anything obstructs the power back door while it is closing/opening, the back door will automatically operate in the opposite direction or stop. ■ When reconnecting the battery (vehicles with power back door) To enable the power back door to operate properly, close the back door man- ually.
Page 122 3-2. Opening, closing and locking the doors ■ Situations in which the touchless sensor does not operate properly (vehicles with touchless power back door) If the touchless sensor does not operate in the following situations, use the back door opener switch or power back door switch or wireless remote con- trol to open the power back door.
Page 123 3-2. Opening, closing and locking the doors WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ Before driving ● Make sure that the back door is fully closed. If the back door is not fully closed, it may open unexpectedly while driving and hit near-by objects or luggage in the luggage compartment may be thrown out, causing an acci- dent.
Page 124 When installing an accessory part to the back door, using a genu- ine Toyota part is recommended. RAV4_OM_OM0R012U_(U)
Page 125 3-2. Opening, closing and locking the doors WARNING ■ Back door closer (vehicles with power back door) ● In the event that the back door is left slightly open, the back door closer will automatically close it to the fully closed position.
Page 126 When installing an accessory part to the back door, ask your Toyota dealer for details. ■...
Page 127 Do not touch the damper stay rod with gloves or other fabric items. ● Do not attach any accessories other than genuine Toyota parts to the back Damper stays door. ● Do not place your hand on the damper stay or apply lateral forces to it.
Page 128 3-2. Opening, closing and locking the doors NOTICE ■ To prevent damage to the power back door (if equipped) ● Make sure that there is no ice between the back door and frame that would prevent movement of the back door. Operating the power back door when excessive load is present on the back door may cause a malfunc- tion.
Page 129 If it does not operate, have the vehicle inspected by your Toyota dealer. ● Do not apply coatings that have a rain clearing (hydrophilic) effect, or other coatings, to the lower center part of the rear bumper.
Page 130: Smart Key System
3-2. Opening, closing and locking the doors ∗ Smart key system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. The driver should always carry the electronic key. ● Locks and unlocks the side doors (→P. 107) ●...
Page 131 3-2. Opening, closing and locking the doors ■ Alarms and warning indicators A combination of exterior and interior alarms as well as warning messages shown on the multi-information display are used to prevent theft of the vehicle and accidents resulting from erroneous operation. Take appropriate mea- sures in response to any warning message on the multi-information dis- play.(→P.
Page 132 3-2. Opening, closing and locking the doors ■ Conditions affecting operation The smart key system uses weak radio waves. In the following situations, the communication between the electronic key and the vehicle may be affected, preventing the smart key system, wireless remote control and engine immobi- lizer system from operating properly.
Page 133 3-2. Opening, closing and locking the doors ■ Note for the entry function ● Even when the electronic key is within the effective range (detection areas), the system may not operate properly in the following cases: • The electronic key is too close to the window or outside door handle, near the ground, or in a high place when the doors are locked or unlocked.
Page 134 To prevent theft of the vehicle, do not leave the electronic key within 6 ft. (2 m) of the vehicle. ● The smart key system can be deactivated in advance. Ask your Toyota dealer for details. ■ To operate the system properly Make sure to carry the electronic key when operating the system.
Page 135 3-2. Opening, closing and locking the doors ■ Electronic key battery depletion ● The standard battery life is 1 to 2 years. ● If the battery becomes low, an alarm will sound in the cabin when the engine stops. (→P. 643) ●...
Page 136 3-2. Opening, closing and locking the doors ■ Certification for the smart key system  For vehicles sold in the U.S.A. RAV4_OM_OM0R012U_(U)
Page 137 3-2. Opening, closing and locking the doors  For vehicles sold in Canada RAV4_OM_OM0R012U_(U)
Page 138 (→P. 130) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of the emitted radio waves.
Page 139: Adjusting The Seats
3-3. Adjusting the seats Front seats Adjustment procedure  Manual seat Seat position adjustment lever Seatback angle adjustment lever Vertical height adjustment lever (driver’s side only) Power seat (driver’s side only)  Seat position adjustment switch Seatback angle adjustment switch Seat cushion (front) angle adjustment switch Vertical height adjustment switch Lumbar support adjustment switch...
Page 140 3-3. Adjusting the seats WARNING ■ When adjusting the seat position ● Take care when adjusting the seat position to ensure that other passen- gers are not injured by the moving seat. ● Do not put your hands under the seat or near the moving parts to avoid injury.
Page 141: Rear Seats
3-3. Adjusting the seats Rear seats Adjustment procedure Pull up the lever. Then lean back to the desired angle and release the lever. When a person sits in the rear center position, align all seatbacks at the same angle. RAV4_OM_OM0R012U_(U)
Page 142 3-3. Adjusting the seats Folding down the rear seatbacks ■ Before folding down the rear seatbacks Stow the rear center seat belt. (→P. 30) Stow the rear seat belt buck- les. Lower the head restraint to the lowest position. (→P. 146) ■...
Page 143 3-3. Adjusting the seats WARNING ■ When folding the rear seatbacks down Observe the following precautions. Failure to do so may result in death or serious injury. ● Do not fold the seatbacks down while driving. ● Stop the vehicle on level ground, set the parking brake and shift the shift lever to P.
Page 144: Driving Position Memory
3-3. Adjusting the seats ∗ Driving position memory This feature automatically adjusts the driver’s seat to suit your preferences. Driving position memory Your preferred driving position (the position of the driver’s seat) can be recorded and recalled by pressing a button. Two different driving positions can be recorded into memory.
Page 145 3-3. Adjusting the seats ■ Recall procedure Check that the shift lever is in P. Turn the engine switch to the “ON” position (vehicles without smart key system) or IGNITION ON mode (vehicles with smart key system). Press one of the buttons for the driving position you want to recall until the buzzer sounds.
Page 146: Head Restraints
3-3. Adjusting the seats Head restraints Head restraints are provided for all seats. Front seats Pull the head restraint up. Down Push the head restraint down while pressing the lock release button. Lock release button Rear seats Pull the head restraints up. Down Push the head restraint down while pressing the lock release button.
Page 147 3-3. Adjusting the seats ■ Removing the head restraints  Front seats Pull the head restraint up while pressing the lock release button. Lock release button  Rear seats Pull the head restraint up while pressing the lock release button. Lock release button ■...
Page 148 3-3. Adjusting the seats ■ Adjusting the height of the head restraints Make sure that the head restraints are adjusted so that the center of the head restraint is closest to the top of your ears. ■ Adjusting the rear center seat head restraint Always raise the head restraint one level from the stowed position when using.
Page 149: Steering Wheel
3-4. Adjusting the steering wheel and mirrors Steering wheel Adjustment procedure Hold the steering wheel and press the lever down. Adjust to the ideal position by moving the steering wheel hori- zontally and vertically. After adjustment, pull the lever up to secure the steering wheel.
Page 150 3-4. Adjusting the steering wheel and mirrors WARNING ■ Caution while driving Do not adjust the steering wheel while driving. Doing so may cause the driver to mishandle the vehicle and an accident, resulting in death or serious injury. ■ After adjusting the steering wheel Make sure that the steering wheel is securely locked.
Page 151: Inside Rear View Mirror
3-4. Adjusting the steering wheel and mirrors Inside rear view mirror The rear view mirror’s position can be adjusted to enable suffi- cient confirmation of the rear view. Adjusting the height of rear view mirror The height of the rear view mirror can be adjusted to suit your driving posture.
Page 152 3-4. Adjusting the steering wheel and mirrors  Auto anti-glare inside rear view mirror Responding to the level of brightness of the headlights of vehicles behind, the reflected light is automatically reduced. Changing automatic anti-glare function mode On/off When the automatic anti-glare function is in ON mode, the indica- tor illuminates.
Page 153: Outside Rear View Mirrors
3-4. Adjusting the steering wheel and mirrors Outside rear view mirrors Adjustment procedure To select a mirror to adjust, press the switch. Left Right To adjust the mirror, press the switch. Right Down Left Folding the mirrors Push the mirror back in the direc- tion of the vehicle’s rear.
Page 154 3-4. Adjusting the steering wheel and mirrors Blind Spot Mirrors (if equipped) The Blind Spot Mirrors increase the view of surrounding area to assist the driver when checking surrounding area before chang- ing lanes. Blind Spot Mirror field of view (range of the solid line) Main mirror field of view (range of the dotted line)
Page 155 3-4. Adjusting the steering wheel and mirrors WARNING ■ Important points while driving Observe the following precautions while driving. Failure to do so may result in loss of control of the vehicle and cause an accident, resulting in death or serious injury. ●...
Page 156: Power Windows
3-5. Opening, closing the windows and moon roof Power windows Opening and closing procedures The power windows can be opened and closed using the switches. Operating the switch moves the windows as follows: Closing One-touch closing (if equipped for driver’s window) Opening One-touch opening...
Page 157 3-5. Opening, closing the windows and moon roof ■ The power windows can be operated when  Vehicles without smart key system The engine switch is in the “ON” position.  Vehicles with smart key system The engine switch is in IGNITION ON mode. ■...
Page 158 1 second or more. If you release the switch while the window is moving, start again from the beginning. If the window reverses and can not be closed or completely open, have the vehicle inspected by your Toyota dealer. RAV4_OM_OM0R012U_(U)
Page 159 3-5. Opening, closing the windows and moon roof WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ Closing the windows ● The driver is responsible for all the power window operations, including the operation for the passengers.
Page 160: Moon Roof
3-5. Opening, closing the windows and moon roof ∗ Moon roof Use the overhead switches to open and close the moon roof and tilt it up and down. Opening and closing Opens the moon roof The moon roof stops slightly before the fully open position to reduce wind noise.
Page 161 3-5. Opening, closing the windows and moon roof ■ The moon roof can be operated when  Vehicles without smart key system The engine switch is in the “ON” position.  Vehicles with smart key system The engine switch is in IGNITION ON mode. ■...
Page 162 3-5. Opening, closing the windows and moon roof ■ Moon roof open reminder function  Vehicles without smart key system The buzzer sounds when the engine switch is turned to the “LOCK” position and the driver’s door is opened with the moon roof open. ...
Page 163 3-5. Opening, closing the windows and moon roof WARNING Observe the following precautions. Failure to do so may cause death or serious injury. ■ Opening the moon roof ● Do not allow any passengers to put their hands or heads outside the vehi- cle while it is moving.
Page 164 3-5. Opening, closing the windows and moon roof RAV4_OM_OM0R012U_(U)
Page 165: Driving
Cargo and luggage ... 176 4-5. Using the driving support Vehicle load limits ..... 180 systems Trailer towing..... 181 Toyota Safety Sense P ..235 Dinghy towing ....197 4-2. Driving procedures (Pre-Collision System) ..242 Engine (ignition) switch LDA (Lane Departure...
Page 166: 4-1. Before Driving
4-1. Before driving Driving the vehicle The following procedures should be observed to ensure safe driving: Starting the engine →P. 198, 200 Driving With the brake pedal depressed, shift the shift lever to D. (→P. 205) Release the parking brake. (→P. 214) Gradually release the brake pedal and gently depress the accelera- tor pedal to accelerate the vehicle.
Page 167 When the accelerator pedal is released ● When the brake pedal is depressed while sport mode is selected ■ Breaking in your new Toyota To extend the life of the vehicle, observing the following precautions is recom- mended: ● For the first 200 miles (300 km): Avoid sudden stops.
Page 168 Your vehicle has a drum-in-disc type parking brake system. This type of brake system needs bedding-down of the brake shoes periodically or whenever the parking brake shoes and/or drum are replaced. Have your Toyota dealer per- form the bedding down operation.
Page 169 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When driving the vehicle ● During normal driving, do not turn off the engine. Turning the engine off while driving will not cause loss of steering or braking control, but the power assist to these systems will be lost.
Page 170 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When driving on slippery road surfaces ● Sudden braking, acceleration and steering may cause tire slippage and reduce your ability to control the vehicle. ●...
Page 171 If you hear a squealing or scraping noise (brake pad wear limit indica- tors) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. The rotor damage may result if the pads are not replaced when needed.
Page 172 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When the vehicle is parked ● Do not leave glasses, cigarette lighters, spray cans, or soft drink cans in the vehicle when it is in the sun. Doing so may result in the following: •...
Page 173 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When taking a nap in the vehicle Always turn the engine off. Otherwise, if you accidentally move the shift lever or depress the accelerator pedal, this could cause an accident or fire due to engine overheating.
Page 174 4-1. Before driving NOTICE ■ When driving the vehicle ● Do not depress the accelerator and brake pedals at the same time during driving, as this may restrain driving torque. ● Do not use the accelerator pedal or depress the accelerator and brake pedals at the same time to hold the vehicle on a hill.
Page 175 Short in electrical components ● Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following: ● Brake function ●...
Page 176: Cargo And Luggage
Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. (→P. 180) For vehicles with SE grade: Toyota does not recommend towing a trailer with your vehicle. Your vehicle is not designed for trailer towing. RAV4_OM_OM0R012U_(U)
Page 177 4-1. Before driving Calculation formula for your vehicle Cargo capacity Total load capacity (vehicle capacity weight) (→P. 672) When 2 people with the combined weight of A lb. (kg) are riding in your vehicle, which has a total load capacity (vehicle capacity weight) of B lb.
Page 178 4-1. Before driving WARNING ■ Things that must not be carried in the luggage compartment The following things may cause a fire if loaded in the luggage compart- ment: ● Receptacles containing gasoline ● Aerosol cans ■ Storage precautions Observe the following precautions. Failure to do so may prevent the pedals from being depressed properly, may block the driver’s vision, or may result in items hitting the driver or passengers, possibly causing an accident.
Page 179 4-1. Before driving WARNING ■ Capacity and distribution ● Do not exceed the maximum axle weight rating or the total vehicle weight rating. ● Even if the total load of occupant’s weight and the cargo load is less than the total load capacity, do not apply the load unevenly. Improper loading may cause deterioration of steering or braking control which may cause death or serious injury.
Page 180: Vehicle Load Limits
4-1. Before driving Vehicle load limits Vehicle load limits include total load capacity, seating capacity, TWR (Trailer Weight Rating) and cargo capacity. ◆ Total load capacity (vehicle capacity weight): →P. 672 Total load capacity means the combined weight of occupants, cargo and luggage.
Page 181: Trailer Towing
For vehicles with SE grade Toyota does not recommend towing a trailer with your vehicle. Toyota also does not recommend the installation of a tow hitch or the use of a tow hitch carrier for a wheelchair, scooter, bicy- cle, etc. Your vehicle is not designed for trailer towing or for the use of tow hitch mounted carriers.
Page 182 To tow a trailer safely, use extreme care and drive the vehicle in accordance with your trailer’s characteristics and operating conditions. Toyota warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. Contact your Toyota dealer for further information about additional requirements such as a towing kit, etc.
Page 183 4-1. Before driving Towing related terms ■ GCWR (Gross Combination Weight Rating) The maximum allowable gross combination weight. The gross combination weight is the sum of the total vehicle weight (including the occupants, cargo and any optional equipment installed on the vehicle) and the weight of the trailer being towed (including the cargo in the trailer).
Page 184 4-1. Before driving ■ GAWR (Gross Axle Weight Rating) The maximum allowable gross Front GAWR axle weight. The gross axle weight is the load placed on each axle (front and rear). Rear GAWR ■ TWR (Trailer Weight Rating) The maximum allowable gross (With brakes) trailer weight.
Page 185 4-1. Before driving ■ Unbraked TWR (Unbraked Trailer Weight Rating) The trailer weight rating for tow- (Without brakes) ing a trailer without a trailer ser- vice brake system. ■ Tongue Weight The load placed on the trailer hitch ball. (→P. 188) RAV4_OM_OM0R012U_(U)
Page 186 4-1. Before driving Weight limits ● The gross trailer weight must never exceed the TWR described below.  Without towing package 1500 lb. (680 kg) With towing package  2WD models: 2900 lb. (1315 kg) AWD models: 3500 lb. (1590 kg) ●...
Page 187 4-1. Before driving GCWR, TWR and Unbraked TWR Confirm that the gross trailer weight, gross combination weight, gross vehicle weight, gross axle weight and tongue weight are all within the limits. ■ GCWR  Without towing package 2WD models: 6025 lb. (2735 kg) AWD models: 6140 lb.
Page 188 4-1. Before driving Trailer Tongue Weight ● A recommended tongue weight varies in accordance with the types of trailers or towing as described below. ● To ensure the recommended values shown below, the trailer must be loaded by referring to the following instructions. •...
Page 189 Toyota hitch/bracket for your vehicle. For details, contact your Toyota dealer. ● If you wish to install a trailer hitch, contact your Toyota dealer. ● Use only a hitch that conforms to the gross trailer weight require- ment of your vehicle.
Page 190 ● Speed limits for towing a trailer vary by state or province. Do not exceed the posted towing speed limit. ● Toyota recommends that the vehicle-trailer speed limit is 65 mph (104 km/h) on a flat, straight, dry road. Do not exceed this limit, the posted towing speed limit or the speed limit for your trailer as set forth in your trailer owner’s manual, whichever is lowest.
Page 191 4-1. Before driving ● As stopping distance is increased when towing a trailer, vehicle-to vehicle distance should be increased. For each 10 mph (16 km/h) of speed, allow at least one vehicle and trailer length. ● Avoid sudden braking as you may skid, resulting in the trailer jack- knifing and a loss of vehicle control.
Page 192 4-1. Before driving ● Due to the added load of the trailer, your vehicle’s engine may over- heat on hot days (at temperatures over 85°F [30°C]) when driving up a long or steep grade. If the engine coolant temperature gauge indicates overheating, immediately turn off the air conditioning (if in use), pull your vehicle off the road and stop in a safe spot.
Page 193 4-1. Before driving ■ Matching trailer ball height to trailer coupler height No matter which class of tow hitch applies, for a more safe trailer hookup, the trailer ball setup must be the proper height for the coupler on the trailer. Coupler Trailer ball ■...
Page 194 Break-in schedule If your vehicle is new or equipped with any new power train components (such as an engine, transmission, differential or wheel bearing), Toyota rec- ommends that you do not tow a trailer until the vehicle has been driven for over 500 miles (800 km).
Page 195 4-1. Before driving WARNING ■ Trailer towing precautions To tow a trailer safely, use extreme care and drive the vehicle in accordance with the trailer’s characteristics and operating conditions. Failure to do so could cause an accident resulting in death or serious injury. Vehicle stability and braking performance are affected by trailer stability, brake setting and performance, and the hitch.
Page 196 NOTICE ■ When installing a trailer hitch Use only the position recommended by your Toyota dealer. Do not install the trailer hitch on the bumper; this may cause body damage. ■ Do not directly splice trailer lights Do not directly splice trailer lights.
Page 197: Dinghy Towing
4-1. Before driving Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE ■ To avoid serious damage to your vehicle Do not tow your vehicle with 4 wheels on the ground.
Page 198: Engine (Ignition) Switch (Vehicles Without
4-2. Driving procedures Engine (ignition) switch (vehicles without smart key system) Starting the engine Check that the parking brake is set. Check that the shift lever is set in P. Firmly depress the brake pedal. Turn the engine switch to the “START” position to start the engine. Changing the engine switch positions “LOCK”...
Page 199 Do not crank the engine for more than 30 seconds at a time. This may overheat the starter and wiring system. ● Do not race a cold engine. ● If the engine becomes difficult to start or stalls frequently, have your vehi- cle checked by your Toyota dealer immediately. RAV4_OM_OM0R012U_(U)
Page 200: Engine (Ignition) Switch (Vehicles With Smart Key System)
4-2. Driving procedures Engine (ignition) switch (vehicles with smart key system) Performing the following operations when carrying the elec- tronic key on your person starts the engine or changes engine switch modes. Starting the engine Check that the parking brake is set. Check that the shift lever is set in P.
Page 201 4-2. Driving procedures Stopping the engine Stop the vehicle completely. Set the parking brake (→P. 214), and shift the shift lever to P. Press the engine switch. Release the brake pedal and check that the display on the instru- ment cluster is off. Changing engine switch modes Modes can be changed by pressing the engine switch with the brake pedal released.
Page 202 If the engine does not start ● The engine immobilizer system may not have been deactivated. (→P. 73) Contact your Toyota dealer. ● Check that the shift lever is securely set in P. The engine may not start if the shift lever is displaced out of P.
Page 203 4-2. Driving procedures ■ Steering lock After turning the engine switch off and opening and closing the doors, the steering wheel will be locked due to the steering lock function. Operating the engine switch again automatically cancels the steering lock. ■...
Page 204 Do not race a cold engine. ● If the engine becomes difficult to start or stalls frequently, have your vehi- cle checked by your Toyota dealer immediately. ■ Symptoms indicating a malfunction with the engine switch If the engine switch seems to be operating somewhat differently than usual, such as the switch sticking slightly, there may be a malfunction.
Page 205: Automatic Transmission
4-2. Driving procedures Automatic transmission Shifting the shift lever  Vehicles without smart key system While the engine switch is in the “ON” position, move the shift lever with the brake pedal depressed. When shifting the shift lever between P and D, make sure that the vehicle is completely stopped.
Page 206 4-2. Driving procedures Shift position purpose Shift position Objective or function Parking the vehicle/starting the engine Reversing Neutral Normal driving S mode driving (→P. 209) : Shifting the shift lever to D allows the system to select a gear suitable for the driving conditions.
Page 207 4-2. Driving procedures Selecting the driving mode The following modes can be selected to suit driving conditions. ■ Eco drive mode Use Eco drive mode to help achieve low fuel consumption during trips that involve frequent accelerating. Press the “ECO MODE” button to select Eco drive mode.
Page 208 4-2. Driving procedures Selecting shift ranges in the D position (vehicles with paddle shift switches) To drive using temporary shift range selection, operate the “-” or “+” paddle shift switch. When the “-” paddle shift switch is operated, the shift range will be downshifted to a range that enables engine braking force that is suit- able to driving conditions.
Page 209 4-2. Driving procedures Selecting shift ranges in the S position To enter S mode, shift the shift lever to S. Shift ranges can be selected by operating the shift lever, allowing you to drive in the shift ranges of your choosing. The shift range can be selected by the shift lever. Vehicles with paddle shift switches: Shift ranges can be selected by the shift lever or operating the “-”...
Page 210 4-2. Driving procedures ■ S mode ● When the shift range is 4 or lower, holding the shift lever toward “+” sets the shift range to 6. ● To prevent the engine from over-revving, upshifting may automatically occur. ● To protect the automatic transmission, a higher shift range may automati- cally selected when the fluid temperature is high.
Page 211 S This may indicate a malfunction in the automatic transmission system. Have the vehicle inspected by your Toyota dealer immediately. (In this situation, the transmission will operate in the same manner as when the shift lever is in D.)
Page 212 D position driving. (Vehicles with paddle shift switches only) When the warning message goes out, the vehicle can be driven again. If the warning message does not go out after waiting a while, have your vehi- cle inspected by your Toyota dealer. ■ AI-SHIFT The AI-SHIFT automatically selects the suitable gear according to driver per- formance and driving conditions.
Page 213: Turn Signal Lever
4-2. Driving procedures Turn signal lever Operating instructions Right turn Lane change to the right (move the lever partway and release The right hand signals will flash 3 times. Lane change to the left (move the lever partway and release The left hand signals will flash 3 times.
Page 214: Parking Brake
4-2. Driving procedures Parking brake Sets the parking brake Fully pull the parking brake while depressing the brake pedal. U.S.A. Canada Releases the parking brake Slightly raise the lever and lower it completely while pressing the but- ton. ■ Parking the vehicle →P.
Page 215: Headlight Switch
4-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. Operating instructions Turning the end of the lever turns on the lights as follows:  Type A The side marker, parking, tail, license plate, instru- ment panel lights, and daytime running...
Page 216 4-3. Operating the lights and wipers  Type B The side marker, parking, tail, license plate, instru- ment panel lights, and daytime running lights (→P. 217) turn on. The headlights and all lights listed above (except daytime running lights) turn on. The daytime running lights turn on.
Page 217 4-3. Operating the lights and wipers Turning on the high beam headlights With the headlights on, push the lever away from you to turn on the high beams. Pull the lever toward you to the center position to turn the high beams off.
Page 218 4-3. Operating the lights and wipers  Vehicles with LED headlights ● The daytime running lights illuminate using the same lights as the parking lights and illuminate brighter than the parking lights. ● To make your vehicle more visible to other drivers during daytime driving, the daytime running lights turn on automatically when all of the following conditions are met.
Page 219 4-3. Operating the lights and wipers ■ Automatic light off system When the headlights are on: The lights turn off 30 seconds after the engine switch is turned to the “LOCK” position (vehicles without smart key system) or off (vehicles with smart key system) and a door is opened and all of the doors are closed.
Page 220: Automatic High Beam
4-3. Operating the lights and wipers ∗ Automatic High Beam The Automatic High Beam uses an in-vehicle camera sensor to assess the brightness of streetlights, the lights of vehicles ahead etc., and automatically turns the high beam on or off as necessary.
Page 221 4-3. Operating the lights and wipers Turning the high beam on/off manually ■ Switching to low beam Pull the lever to the original position. ■ Switching to high beam Turn the light switch to position. The Automatic High Beam indi- cator will turn off and the high beam indicator will turn on.
Page 222 4-3. Operating the lights and wipers ■ Camera sensor detection information ● The high beam may not be automatically turned off in the following situa- tions: • When oncoming vehicles suddenly appear from a curve • When the vehicle is cut in front of by another vehicle •...
Page 223 Automatic High Beam (headlights) may turn on even the vehicle is stopped. ■ If a warning message of the Automatic High Beam is displayed It may indicate a malfunction in the system. Contact your Toyota dealer. ■ Customization The Automatic High Beam can be turned off.
Page 224: Fog Light Switch
4-3. Operating the lights and wipers ∗ Fog light switch The fog lights secure excellent visibility in difficult driving con- ditions, such as in rain and fog. (U.S.A.) (Canada) Turns the fog lights off Turns the fog lights on ■ Fog lights can be used when The headlights are on in low beam.
Page 225: Windshield Wipers And Washer
4-3. Operating the lights and wipers Windshield wipers and washer Operating the wiper lever The wiper operation is selected by moving the lever as follows.  For the U.S.A. Intermittent operation Low speed operation High speed operation Temporary operation RAV4_OM_OM0R012U_(U)
Page 226 4-3. Operating the lights and wipers If equipped, wiper intervals can be adjusted when intermittent opera- tion is selected. Increases the intermittent wind- shield wiper frequency Decreases intermittent windshield wiper frequency Washer/wiper dual operation The wipers will automatically oper- ate a couple of times after the washer squirts.
Page 227 4-3. Operating the lights and wipers If equipped, wiper intervals can be adjusted when intermittent opera- tion is selected. Increases the intermittent wind- shield wiper frequency Decreases intermittent windshield wiper frequency Washer/wiper dual operation The wipers will automatically oper- ate a couple of times after the washer squirts.
Page 228 Do not operate the switch continually as the washer fluid pump may over- heat. ■ When a nozzle becomes blocked In this case, contact your Toyota dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged. ■ To prevent battery discharge Do not leave the wipers on longer than necessary when the engine is off.
Page 229: Rear Window Wiper And Washer
4-3. Operating the lights and wipers Rear window wiper and washer Turning the end of the lever turns on the rear window wiper, and push- ing the lever away from you turns on the rear window wiper and washer.  For the U.S.A.
Page 230 4-3. Operating the lights and wipers  For Canada Intermittent operation Normal operation Washer/wiper dual operation RAV4_OM_OM0R012U_(U)
Page 231 4-3. Operating the lights and wipers ■ The rear window wiper and washer can be operated when  Vehicles without smart key system The engine switch is in the “ON” position.  Vehicles with smart key system The engine switch is in IGNITION ON mode. ■...
Page 232: Refueling Opening The Fuel Tank Cap
4-4. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap: Before refueling the vehicle ● Close all the doors and windows, and turn the engine switch to the “LOCK” position (vehicles without smart key system) or off (vehicles with smart key system).
Page 233 4-4. Refueling WARNING ■ When refueling the vehicle Observe the following precautions while refueling the vehicle. Failure to do so may result in death or serious injury. ● After exiting the vehicle and before opening the fuel door, touch an unpainted metal surface to discharge any static electricity.
Page 234 WARNING ■ When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 235: Using The Driving Support
■ Toyota Safety Sense P The Toyota Safety Sense P is designed to operate under the assumption that the driver will drive safely, and is designed to help reduce the impact to the occupants and the vehicle in the case of a collision or assist the driver in normal driving conditions.
Page 236 Toyota will not disclose the recorded data to a third party except: • With the consent of the vehicle owner or with the consent of the lessee if the vehicle is leased •...
Page 237 4-5. Using the driving support systems Sensors Two types of sensors, located behind the front grille and windshield, detect information necessary to operate the drive assist systems. Radar sensor Camera sensor RAV4_OM_OM0R012U_(U)
Page 238 Do not subject the radar sensor or surrounding area to a strong impact. If the radar sensor, front grille, or front bumper has been subjected to a strong impact, have the vehicle inspected by your Toyota dealer. ● Do not disassemble the radar sensor.
Page 239 ● Do not attach window tinting to the windshield. ● Replace the windshield if it is damaged or cracked. If the windshield needs to be replaced, contact your Toyota dealer. ● Do not get the camera sensor wet. ● Do not allow bright lights to shine into the camera sensor.
Page 240 ● Do not attach any accessories that may obstruct the camera sensor to the hood, front grille or front bumper. Contact your Toyota dealer for details. ● If a surfboard or other long object is to be mounted on the roof, make sure that it will not obstruct the camera sensor.
Page 241 4-5. Using the driving support systems RAV4_OM_OM0R012U_(U)
Page 242: (Pre-Collision System)
The countries and areas for each region listed in the table are cur- rent as of August 2017. However, depending on when the vehicle was sold, the countries and areas of each region may be different. Contact your Toyota dealer for details. ∗ : If equipped...
Page 243 4-5. Using the driving support systems ◆ Pre-collision warning When the system determines that the possibility of a frontal collision is high, a buzzer will sound and a warning message will be displayed on the multi- information display to urge the driver to take evasive action.
Page 244 4-5. Using the driving support systems WARNING ■ Limitations of the pre-collision system ● The driver is solely responsible for safe driving. Always drive safely, taking care to observe your surroundings. Do not use the pre-collision system instead of normal braking operations under any circumstances.
Page 245 4-5. Using the driving support systems WARNING ■ When to disable the pre-collision system In the following situations, disable the system, as it may not operate prop- erly, possibly leading to an accident resulting in death or serious injury: ● When the vehicle is being towed ●...
Page 246 4-5. Using the driving support systems Changing settings of the pre-collision system ■ Enabling/disabling the pre-collision system Press of the meter control switches and select on the multi-information display. Press of the meter control switches and select and then press Select and then press Each time...
Page 247 4-5. Using the driving support systems ■ Changing the pre-collision warning timing Press of the meter control switches and select on the multi-information display. Press of the meter control switches and select and then press Select “Sensitivity” and then press Each time is pressed, the operation timing of the warning will be changed.
Page 248 4-5. Using the driving support systems ■ Operational conditions Availability of the pedestrian detection function and pre-collision braking func- tion depend on the region in which the vehicle was sold. (For specific coun- tries/areas: →P. 242) Read the following for details: ...
Page 249 4-5. Using the driving support systems  Region B (The pedestrian detection function is not available) The pre-collision system is enabled and the system determines that the pos- sibility of a frontal collision with a vehicle is high. Each function is operational at the following speeds: ●...
Page 250 4-5. Using the driving support systems ■ Cancelation of the pre-collision braking If either of the following occur while the pre-collision braking function is oper- ating, it will be canceled: ● The accelerator pedal is depressed strongly. ● The steering wheel is turned sharply or abruptly. ■...
Page 251 4-5. Using the driving support systems • When there is a vehicle, pedes- trian , or object by the roadside at the entrance of a curve • When driving on a narrow path surrounded by a structure, such as in a tunnel or on an iron bridge •...
Page 252 4-5. Using the driving support systems • When driving through under objects that may contact the vehicle, such as thick grass, tree branches, or a banner • When the vehicle is hit by water, snow, dust, etc. from a vehicle ahead •...
Page 253 4-5. Using the driving support systems • If the sun or other light is shining directly on a vehicle ahead • If a vehicle cuts in front of your vehicle or emerges from beside a vehicle • If a vehicle ahead makes an abrupt maneuver (such as sudden swerving, acceleration or deceleration) •...
Page 254 4-5. Using the driving support systems ● In some situations such as the following, sufficient braking force may not be obtained, preventing the system from performing properly: • If the braking functions cannot operate to their full extent, such as when the brake parts are extremely cold, extremely hot, or wet •...
Page 255 If the PCS warning light continues to flash or remains illuminated or the warning message does not disappear even though the vehicle has returned to normal, the system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. ■ If VSC is disabled ●...
Page 256: Lda (Lane Departure Alert With Steering Control)
4-5. Using the driving support systems LDA (Lane Departure Alert with steering ∗ control) Summary of functions When driving on highways and freeways with white (yellow) lines, this function alerts the driver when the vehicle might depart from its lane and provides assistance by operating the steering wheel to keep the vehicle in its lane.
Page 257 4-5. Using the driving support systems ◆ Steering control function When the system determines that the vehicle might depart from its lane, the system pro- vides assistance as necessary by operating the steering wheel in small amounts for a short period of time to keep the vehi- cle in its lane.
Page 258 4-5. Using the driving support systems WARNING ■ Before using LDA system Do not rely solely upon the LDA system. The LDA system does not auto- matically drive the vehicle or reduce the amount of attention that must be paid to the area in front of the vehicle. The driver must always assume full responsibility for driving safely by paying careful attention to the surround- ing conditions and operating the steering wheel to correct the path of the vehicle.
Page 259 Do not install or place anything on the hood or grille. Also, do not install a grille guard (bull bars, kangaroo bar, etc.). ● If your windshield needs repairs, contact your Toyota dealer. Turning LDA system on Press the LDA switch to turn the LDA system on.
Page 260 4-5. Using the driving support systems Indications on multi-information display LDA indicator The illumination condition of the indicator informs the driver of the system operation status. Illuminated in white: LDA system is operating. Illuminated in green: Steering wheel assistance of the steering control function is operat- ing.
Page 261 4-5. Using the driving support systems ■ Operation conditions of each function ● Lane departure alert function This function operates when all of the following conditions are met. • LDA is turned on. • Vehicle speed is approximately 32 mph (50 km/h) or more. •...
Page 262 4-5. Using the driving support systems ■ Hands off steering wheel alert When the system determines that the driver has removed the hands from the steering wheel while the steering control function is operating, a warning message is displayed on the multi-information display. If the driver continues to keep the hands off of the steering wheel, a buzzer sounds and a warning message is displayed.
Page 263 4-5. Using the driving support systems ● The vehicle is moving up and down a large amount due to road conditions during driving (poor roads or road seams). ● The headlight lenses are dirty and emit a faint amount of light at night, or the beam axis has deviated.
Page 264: Dynamic Radar Cruise Control
4-5. Using the driving support systems ∗ Dynamic radar cruise control Summary of functions In vehicle-to-vehicle distance control mode, the vehicle automatically accelerates and decelerates to match the speed changes of the pre- ceding vehicle even if the accelerator pedal is not depressed. In con- stant speed control mode, the vehicle runs at a fixed speed.
Page 265 4-5. Using the driving support systems WARNING ■ Before using dynamic radar cruise control Driving safely is the sole responsibility of the driver. Do not rely solely on the system, and drive safely by always paying careful attention to your sur- roundings.
Page 266 4-5. Using the driving support systems WARNING ■ Situations unsuitable for dynamic radar cruise control Do not use dynamic radar cruise control in any of the following situations. Doing so may result in inappropriate speed control and could cause an acci- dent resulting in death or serious injury.
Page 267 4-5. Using the driving support systems Driving in vehicle-to-vehicle distance control mode This mode employs a radar sensor to detect the presence of vehicles up to approximately 328 ft. (100 m) ahead, determines the current vehicle-to-vehicle following distance, and operates to maintain a suit- able following distance from the vehicle ahead.
Page 268 4-5. Using the driving support systems Setting the vehicle speed (vehicle-to-vehicle distance control mode) Press the “ON-OFF” button to activate the cruise control. Radar cruise control indicator will come on and a message will be displayed on the multi-information display. Press the button again to deacti- vate the cruise control.
Page 269 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is displayed. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direction.
Page 270 4-5. Using the driving support systems Changing the vehicle-to-vehicle distance (vehicle-to-vehicle dis- tance control mode) Pressing the switch changes the Preceding vehicle-to-vehicle distance as fol- vehicle mark lows: Long Medium Short The vehicle-to-vehicle distance is set automatically to long mode when the engine switch is turned to IGNITION ON mode.
Page 271 4-5. Using the driving support systems Canceling and resuming the speed control Pulling the lever toward you cancels the speed control. The speed control is also canceled when brake pedal depressed. Pushing the lever up resumes the cruise control and returns vehicle speed to the set speed.
Page 272 4-5. Using the driving support systems Selecting constant speed control mode When constant speed control mode is selected, your vehicle will main- tain a set speed without controlling the vehicle-to-vehicle distance. Select this mode only when vehicle-to-vehicle distance control mode does not function correctly due to a dirty radar sensor, etc.
Page 273 The sensor cannot detect correctly because it is covered in some way. ● Pre-collision braking is activated. If vehicle-to-vehicle distance control mode is automatically canceled for any other reason, there may be a malfunction in the system. Contact your Toyota dealer. ■ Automatic cancelation of constant speed control mode...
Page 274 4-5. Using the driving support systems ■ When the sensor may not be correctly detecting the vehicle ahead In the case of the following and depending on the conditions, operate the brake pedal when deceleration of the system is insufficient or operate the accelerator pedal when acceleration is required.
Page 275 4-5. Using the driving support systems ■ Conditions under which the vehicle-to-vehicle distance control mode may not function correctly In the case of the following conditions, operate the brake pedal (or accelera- tor pedal, depending on the situation) as necessary. As the sensor may not be able to correctly detect vehicles ahead, the system may not operate properly.
Page 276: Cruise Control
4-5. Using the driving support systems ∗ Cruise control Summary of functions Use the cruise control to maintain a set speed without depressing the accelerator pedal. Indicators Indicators and set speed Cruise control switch Setting the vehicle speed Press the “ON-OFF” button to activate the cruise control.
Page 277 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is obtained. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direc- tion.
Page 278 If the cruise control speed cannot be set or if the cruise control cancels imme- diately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer. RAV4_OM_OM0R012U_(U)
Page 279 4-5. Using the driving support systems WARNING ■ To avoid operating the cruise control by mistake Switch the cruise control off using the “ON-OFF” button when not in use. ■ Situations unsuitable for cruise control Do not use cruise control in any of the following situations. Doing so may result in loss of control and could cause an accident resulting in death or serious injury.
Page 280: Intuitive Parking Assist
4-5. Using the driving support systems ∗ Intuitive parking assist The distance from your vehicle to nearby obstacles when paral- lel parking or maneuvering into a garage is measured by the sensors and communicated via the multi-information display, navigation system or multimedia system screen and a buzzer. Always check the surrounding area when using this system.
Page 281 4-5. Using the driving support systems Display When the sensors detect an obstacle, the following displays inform the driver of the position and distance to the obstacle. ■ Multi-information display Front corner sensor opera- tion Front center sensor opera- tion Rear corner sensor operation Rear center sensor operation RAV4_OM_OM0R012U_(U)
Page 282 4-5. Using the driving support systems ■ Navigation system or multimedia system screen (if equipped) Intuitive parking assist dis- play When the rear view monitor system or Toyota parking assist monitor or panoramic view monitor is not dis- played: A graphic is automatically dis- played when an obstacle is detected.
Page 283 4-5. Using the driving support systems Sensor detection display, obstacle distance ■ Distance display Sensors that detect an obstacle will illuminate continuously or blink. Approximate distance to obstacle Display Insert display Front corner sensor/ Rear corner sensor/ front center sensor rear center sensor Front center Rear center...
Page 284 4-5. Using the driving support systems ■ Buzzer operation and distance to an obstacle A buzzer sounds when the sensors are operating. ● The buzzer sounds faster as the vehicle approaches an obstacle. When the vehicle comes within the following distance of the obstacle, the buzzer sounds continuously.
Page 285  Vehicles with Entune Audio Press the “SETUP” button. Select “Vehicle” on the screen. Select “TOYOTA Park Assist Settings” on the screen. Select the desired item.  Vehicles with Entune Audio Plus or Entune Premium Audio with Navigation Press the “APPS” button.
Page 286 ■ Intuitive parking assist display When an obstacle is detected while the Toyota parking assist monitor is in use, the warning indicator will appear in the top right or left of the screen even if the display setting has been set to off.
Page 287 4-5. Using the driving support systems ● The following situations may occur during use: • Depending on the shape of the obstacle and other factors, the detection distance may shorten, or detection may be impossible. • Obstacles may not be detected if they are too close to the sensor. •...
Page 288 When using intuitive parking assist In the following situations, the system may not function correctly due to a sensor malfunction etc. Have the vehicle checked by your Toyota dealer. ● If the area around a sensor collides with something, or is subjected to strong impact.
Page 289: Rear View Monitor System
4-5. Using the driving support systems ∗ Rear view monitor system The rear view monitor system assists the driver by displaying an image of the view behind the vehicle and fixation guide lines while backing up, for example while parking. The screen illustrations used in this text are intended as examples, and may differ from the image that is actually displayed on the screen.
Page 290 4-5. Using the driving support systems Using the rear view monitor system ■ Screen description  Vehicles without smart key system The rear view monitor system screen will be displayed if the shift lever is shifted to R while the engine switch is in the “ON” position. ...
Page 291 4-5. Using the driving support systems Rear view monitor system precautions ■ Area displayed on screen The rear view monitor system displays an image of the view from the bumper of the rear area of the vehicle. The image on the rear view monitor system adjusted: refer to P.
Page 292 4-5. Using the driving support systems ■ Rear view monitor system camera The camera for the rear view monitor system located above the license plate. ● Using the camera If dirt or foreign matter (such as water droplets, snow, mud etc.) is adhering to the camera, it cannot transmit a clear image.
Page 293 4-5. Using the driving support systems ● When the ground behind the vehicle slopes up sharply The distance guide lines will appear to be closer to the vehicle than the actual dis- tance. Because this, objects will appear to be far- ther away than they actually are.
Page 294 4-5. Using the driving support systems ● When any part of the vehicle sags When any part of the vehicle sags due to the number of passengers or the distribu- tion of the load, there is a margin of error between the fixation guide lines on the screen and the actual dis- A margin of error...
Page 295 4-5. Using the driving support systems ● Distance guide lines Visually check the surround- ings and the area behind the vehicle. On the screen, it appears that a truck is park- ing at point . However, in reality if you back up to point , you will hit the truck.
Page 296 If you notice any of the following symptoms, refer to the likely cause and the solution, and re-check. If the symptom is not resolved by the solution, have the vehicle inspected by your Toyota dealer. Likely cause Solution  The image is difficult to see •...
Page 297 4-5. Using the driving support systems WARNING ■ When using the rear view monitor system The rear view monitor system is a supplemental device intended to assist the driver when backing up. When backing up, be sure to check visually behind and all around the vehicle before proceeding.
Page 298 Doing so may result in the camera malfunc- tioning. ● Do not expose the camera to strong impact as this could cause a malfunc- tion. If this happens, have the vehicle inspected by your Toyota dealer as soon as possible. RAV4_OM_OM0R012U_(U)
Page 299: All-Wheel Drive Lock Switch (Awd Models)
4-5. Using the driving support systems All-wheel drive lock switch (AWD models) All-wheel drive lock mode can be used when a large amount of drive power needs to be applied to all the wheels, such as when the vehicle gets stuck in mud and you need to free it. Press the switch.
Page 300: (Blind Spot Monitor)
4-5. Using the driving support systems ∗ BSM (Blind Spot Monitor) Summary of the Blind Spot Monitor The Blind Spot Monitor is a system that has 2 functions; ● The Blind Spot Monitor function Assists the driver in making the decision when changing lanes ●...
Page 301 4-5. Using the driving support systems Outside rear view mirror indicators Blind Spot Monitor function: When a vehicle is detected in the blind spot, the outside rear view mirror indicator comes on while the turn signal lever is not operated. If the turn signal lever is operated toward the detected side, the outside rear view mirror indicator flashes.
Page 302 4-5. Using the driving support systems ■ Certification  For vehicles sold in the U.S.A.  For vehicles sold in Canada RAV4_OM_OM0R012U_(U)
Page 303 Do not attach accessories or stickers to the sensor or surrounding area on the bumper. ● Do not modify the sensor or surrounding area on the bumper. ● Do not paint the rear bumper any color other than an official Toyota color. RAV4_OM_OM0R012U_(U)
Page 304: The Blind Spot Monitor Function
4-5. Using the driving support systems The Blind Spot Monitor function The Blind Spot Monitor function uses radar sensors to detect vehicles that are traveling in an adjacent lane in the area that is not reflected in the outside rear view mirror (the blind spot), and advises the driver of the vehicles existence via the outside rear view mirror indicator.
Page 305 4-5. Using the driving support systems ■ The Blind Spot Monitor function is operational when ● The Blind Spot Monitor system is set to on ● Vehicle speed is greater than approximately 10 mph (16 km/h). ■ The Blind Spot Monitor function will detect a vehicle when ●...
Page 306 4-5. Using the driving support systems ■ Conditions under which the Blind Spot Monitor function may not func- tion correctly ● The Blind Spot Monitor function may not detect vehicles correctly in the fol- lowing conditions: • During bad weather such as heavy rain, fog, snow, etc. •...
Page 307: The Rear Cross Traffic Alert Function
4-5. Using the driving support systems The Rear Cross Traffic Alert function The Rear Cross Traffic Alert functions when your vehicle is in reverse. It can detect other vehicles approaching from the right or left rear of the vehicle. It uses radar sensors to alert the driver of the other vehi- cle’s existence through flashing the outside rear view mirror indicators and sounding a buzzer.
Page 308 4-5. Using the driving support systems The Rear Cross Traffic Alert function detection areas The areas that vehicles can be detected in are outlined below. To give the driver a more consistent time to react, the buzzer can alert for faster vehicles from farther away. Example: Approximate Approaching vehicle...
Page 309 4-5. Using the driving support systems ■ Conditions under which the Rear Cross Traffic Alert function will not detect a vehicle The Rear Cross Traffic Alert function is not designed to detect the following types of vehicles and/or objects. ● Small motorcycles, bicycles, pedestrians, etc.
Page 310: Driving Assist Systems
4-5. Using the driving support systems Driving assist systems To help enhance driving safety and performance, the following systems operate automatically in response to various driving situations. Be aware, however, that these systems are supple- mentary and should not be relied upon too heavily when operat- ing the vehicle.
Page 311 4-5. Using the driving support systems ◆ Dynamic Torque Control AWD system (AWD models) Automatically switches from front-wheel drive to all-wheel drive (AWD) according to the driving conditions, helping to ensure reliable handling and stability. Examples of conditions where the system will switch to AWD are when cornering, going uphill, starting off or accelerating, and when the road surface is slippery due to snow, rain, etc.
Page 312 4-5. Using the driving support systems Disabling the TRAC system If the vehicle gets stuck in mud, dirt or snow, the TRAC system may reduce power from the engine to the wheels. Pressing to turn the system off may make it easier for you to rock the vehicle in order to free it.
Page 313 When the message is displayed on the multi-information display show- ing that TRAC has been disabled even if the VSC OFF switch has not been pressed (AWD models) TRAC and hill-start assist control cannot be operated. Contact your Toyota dealer. ■...
Page 314 4-5. Using the driving support systems ■ Reduced effectiveness of the EPS system The effectiveness of the EPS system is reduced to prevent the system from overheating when there is frequent steering input over an extended period of time. The steering wheel may feel heavy as a result. Should this occur, refrain from excessive steering input or stop the vehicle and turn the engine off.
Page 315 4-5. Using the driving support systems WARNING ■ The ABS does not operate effectively when ● The limits of tire gripping performance have been exceeded (such as excessively worn tires on a snow covered road). ● The vehicle hydroplanes while driving at high speed on wet or slick roads. ■...
Page 316 The ABS, TRAC and VSC/Trailer Sway Control systems will not function correctly if different tires are installed on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■ Handling of tires and the suspension Using tires with any kind of problem or modifying the suspension will affect the driving assist systems, and may cause a system to malfunction.
Page 317: Driving Tips
4-6. Driving tips Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a man- ner appropriate to the prevailing weather conditions. Preparation for winter ● Use fluids that are appropriate to the prevailing outside tempera- tures.
Page 318 If the shift lever can be shifted from P, there may be a problem with the shift lock system. Have the vehicle inspected by your Toyota dealer immediately. Selecting tire chains Use the correct tire chain size when mounting the tire chains.
Page 319 4-6. Driving tips ■ Tire chain installation Observe the following precautions when installing and removing chains: ● Install and remove tire chains in a safe location. ● Install tire chains on the front tires only. Do not install tire chains on the rear tires.
Page 320 Repairing or replacing snow tires (vehicles with the tire pressure warn- ing system) Request repairs or replacement of snow tires from Toyota dealers or legiti- mate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
Page 321: Utility Vehicle Precautions
4-6. Driving tips Utility vehicle precautions This vehicle belongs to the utility vehicle class, which has higher ground clearance and narrower tread in relation to the height of its center of gravity to make it capable of performing in a wide variety of off-road applications. Utility vehicle feature ●...
Page 322 4-6. Driving tips Off-road driving When driving your vehicle off-road, please observe the following pre- cautions to ensure your driving enjoyment and to help prevent the clo- sure of areas to off-road vehicles: ● Drive your vehicle only in areas where off-road vehicles are permit- ted to travel.
Page 323 4-6. Driving tips WARNING ■ Off-road driving precautions Always observe the following precautions to minimize the risk of death, seri- ous injury or damage to your vehicle: ● Drive carefully when off the road. Do not take unnecessary risks by driving in dangerous places.
Page 324 4-6. Driving tips NOTICE ■ To prevent the water damage Take all necessary safety measures to ensure that water damage to the engine or other components does not occur. ● Water entering the engine air intake will cause severe engine damage. ●...
Page 325 4-6. Driving tips RAV4_OM_OM0R012U_(U)
Page 326: Audio System
Audio system ® 5-1. Basic Operations 5-8. Bluetooth Audio ® Audio system types ... 328 Operating a Bluetooth enabled portable Using the steering wheel player ......380 audio switches ....331 ® 5-9. Bluetooth Phone AUX port/USB port .... 334 Making a phone call ..
Page 327 Audio system ® 5-15. Using the radio 5-19. Bluetooth Audio ® Radio operation....411 Listening to Bluetooth Audio....... 443 5-16. Playing an audio CD and ® MP3/WMA/AAC discs 5-20. Bluetooth Phone ® CD player operation ..413 Using a Bluetooth Phone ......
Page 328: 5-1. Basic Operations
5-1. Basic Operations Audio system types  Vehicles with Entune Premium Audio with Navigation Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”. Vehicles with Entune Audio Plus  Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”. Vehicles with Entune Audio ...
Page 329 5-1. Basic Operations  Vehicles without Entune Premium Audio with Navigation or Entune Audio Plus or Entune Audio CD player with AM/FM radio Changing language setting Press the “SETUP” button. Turn the “TUNE•SCROLL” knob to select “Language”. Press the knob. Turn the knob as corresponds to the desired language.
Page 330 5-1. Basic Operations WARNING ■ Certification for the disc player ● Part 15 of the FCC Rules FCC Warning: Changes or modifications not expressly approved by the party responsi- ble for compliance could void the user’s authority to operate the equip- ment.
Page 331: Using The Steering Wheel Audio Switches
5-1. Basic Operations Using the steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel. Operation may differ depending on the type of audio system or navigation system. For details, refer to the manual provided with the audio system or navigation system.
Page 332 5-1. Basic Operations Turning on the power Press the “MODE” switch when the audio system is turned off. Changing the audio source Press the “MODE” switch when the audio system is turned on. The audio source changes as follows each time the button is pressed. If a mode cannot be used, it will be skipped.
Page 333 5-1. Basic Operations Selecting a track/file or song ® Press the “MODE” switch to select the CD, Bluetooth audio, iPod or USB memory mode. Press the “∧” or “∨” switch to select the desired track/file or song. Selecting an album ®...
Page 334: Aux Port/Usb Port
5-1. Basic Operations AUX port/USB port Connect an iPod, USB memory device or portable audio player to the AUX port/USB port as indicated below. Press the “MEDIA” button to select “iPod”, “USB” or “AUX”. Connecting using the AUX port/USB port ■...
Page 335 5-1. Basic Operations WARNING ■ While driving Do not connect a device or operate the device controls. RAV4_OM_OM0R012U_(U)
Page 336: Audio System
5-2. Using the audio system ∗ Optimal use of the audio system The sound quality, volume balance and ASL settings can be adjusted. Displays the “SETUP” menu Changes the following settings • Sound quality and volume balance The sound quality and balance setting can be changed to pro- duce the best sound.
Page 337: Using The Audio System
5-2. Using the audio system ■ Adjusting sound quality Turning the “TUNE•SCROLL” knob adjusts the level. Sound Mode Turn to the Turn to the Level quality mode displayed left right Bass “BASS” -5 to 5 High Treble “TREBLE” -5 to 5 Front/rear volume “FADER”...
Page 338: 5-3. Using The Radio
5-3. Using the radio ∗ Radio operation Power AM/FM mode button Volume Station selectors Adjusting the frequency Seeking the frequency Scanning for receivable sta- Displaying text message tions Setting station presets Search for the desired stations by turning the “TUNE•SCROLL” knob or pressing “∧”...
Page 339 5-3. Using the radio Scanning radio stations ■ Scanning the preset radio stations Press and hold the “SCAN” button until you hear a beep. Preset stations will be played for 5 seconds each. To cancel, press the button again. When the desired station is reached, press the button again. ■...
Page 340: Cd Player Operation
5-4. Playing an audio CD and MP3/WMA discs ∗ CD player operation Power Selecting a folder Volume Fast-forwarding or rewinding CD eject Changing the audio source/ playback Selecting a track or displaying track list Playback/pause Searching playback Selecting a track Random play or back button Displaying text message Repeat play...
Page 341 5-4. Playing an audio CD and MP3/WMA discs ■ Selecting a track from a track list Press the “TUNE•SCROLL” knob. The track list will be displayed. Turn and press the knob to select a track. To return to the previous display, press (BACK).
Page 342 5-4. Playing an audio CD and MP3/WMA discs Playing back MP3 and WMA discs ■ Selecting folders one at a time Press (<FOLDER) or (FOLDER>) to select the desired folder. Press (MORE>) to display the commands. ■ Selecting a folder and file from folder list Press the “TUNE•SCROLL”...
Page 343 5-4. Playing an audio CD and MP3/WMA discs ■ Fast-forwarding and rewinding files Press ) or Press (<BACK) to display the commands. ■ Random play Pressing (RDM) changes modes in the following order: Folder random→Disc random→Off Press (MORE>) to display the command. ■...
Page 344 Operation has stopped due to a high tempera- ture inside the player. Wait for a while and “WAIT” then press the “MODE” button. If the CD still cannot be played back, contact your Toyota dealer. This indicates that the MP3/WMA file is not “NO SUPPORT”...
Page 345 5-4. Playing an audio CD and MP3/WMA discs ■ MP3 and WMA files MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 for- mat.
Page 346 5-4. Playing an audio CD and MP3/WMA discs ● Compatible media Media that can be used for MP3 and WMA playback are CD-Rs and CD- RWs. Playback in some instances may not be possible, depending on the status of the CD-R or CD-RW. Playback may not be possible or the audio may jump if the disc is scratched or marked with fingerprints.
Page 347 5-4. Playing an audio CD and MP3/WMA discs ● MP3 and WMA playback When a disc containing MP3 or WMA files is inserted, all files on the disc are first checked. Once the file check is finished, the first MP3 or WMA file is played.
Page 348 5-4. Playing an audio CD and MP3/WMA discs NOTICE ■ CDs and adapters that cannot be used Do not use the following types of CDs. Also, do not use 3 in. (8 cm) CD adapters, DualDiscs or printable discs. Doing so may damage the player and/or the CD insert/eject function. ●...
Page 349 5-4. Playing an audio CD and MP3/WMA discs NOTICE ● CDs with a transparent or translucent recording area ● CDs that have tape, stickers or CD-R labels attached to them, or that have had the label peeled off ■ CD Player precautions Failure to follow the precautions below may result in serious damage to the CDs or the player itself.
Page 350: 5-5. Using An External Device
5-5. Using an external device ∗ Listening to an iPod Connecting an iPod enables you to enjoy music from the vehicle speakers. Connecting an iPod →P. 334 Control panel Power Changing the audio source/ playback Volume Playback/pause Selecting an iPod menu/song or displaying song list iPod menu mode, playback Random play or back button...
Page 351 5-5. Using an external device Selecting a play mode Press (BROWSE) to select iPod menu mode. Turning the “TUNE•SCROLL” knob clockwise changes the play mode in the following order: “Playlists” → “Artists” → “Albums” → “Songs” → “Podcasts” → “Genres” → “Composers” → “Audiobooks” Press the knob to select the desired play mode.
Page 352 5-5. Using an external device Listening to songs ■ Selecting songs ∧ Turn the “TUNE•SCROLL” knob or press “ ” or “∨” on the “SEEK/ TRACK” button to select the desired song. ■ Selecting a song from the song list Press the “TUNE•SCROLL”...
Page 353 5-5. Using an external device ■ About iPod ● “Made for iPod” and “Made for iPhone” mean that an electronic accessory has been designed to connect specifically to iPod, or iPhone, respectively, and has been certified by the developer to meet Apple performance stan- dards.
Page 354 Error messages If an error message is displayed, refer to the following table and take the appropriate measures. If the problem is not rectified, take the vehicle to your Toyota dealer. Message Cause/Correction procedures This indicates a problem in the iPod or its con- “ERROR”...
Page 355 5-5. Using an external device WARNING ■ While driving Do not connect iPod or operate the controls. Doing so may cause an acci- dent, resulting in death or serious injury. NOTICE ■ To prevent damage to iPod ● Do not leave iPod in the vehicle. The temperature inside the vehicle may become high, resulting in damage to the iPod.
Page 356: Listening To Usb Memory Device
5-5. Using an external device ∗ Listening to USB memory device Connecting a USB memory enables you to enjoy music from the vehicle speakers. Connecting a USB memory →P. 334 Control panel Power Fast-forwarding, rewinding or selecting a folder Volume Changing the audio source/ Selecting a file or displaying playback...
Page 357 5-5. Using an external device Using a USB memory ■ Selecting folders one at a time Press (<FOLDER) or (FOLDER>) to select the desired folder. Press (MORE>) to display the commands. ■ Selecting a folder and file from folder list Press the “TUNE•SCROLL”...
Page 358 Error messages If an error message is displayed, refer to the following table and take the appropriate measures. If the problem is not rectified, take the vehicle to your Toyota dealer. Message Cause/Correction procedures This indicates a problem in the USB memory “ERROR”...
Page 359 5-5. Using an external device ■ USB memory ● Compatible devices USB memory that can be used for MP3 and WMA playback ● Compatible device formats The following device formats can be used: • USB communication formats: USB2.0 FS (12mbps) •...
Page 360 5-5. Using an external device ● WMA file compatibility • Compatible standards WMA Ver. 7, 8, 9 • Compatible sampling frequencies 32, 44.1, 48 (kHz) • Compatible bit rates (only compatible with 2-channel playback) Ver. 7, 8: CBR 48 - 192 (kbps) Ver.
Page 361 5-5. Using an external device WARNING ■ While driving Do not connect USB memory or operate the controls. Doing so may cause an accident, resulting in death or serious injury. NOTICE ■ To prevent damage to USB memory ● Do not leave USB memory in the vehicle. The temperature inside the vehi- cle may become high, resulting in damage to the USB memory.
Page 362: Using The Aux Port
5-5. Using an external device Using the AUX port This port can be used to connect a portable audio device and lis- ten to it using the vehicle’s speakers. Connecting a portable player →P. 334 ■ Operating portable audio devices connected to the audio system The volume can be adjusted using the vehicle’...
Page 363: Phone
® 5-6. Using Bluetooth devices ® ∗ Bluetooth audio/phone ® The following can be performed using Bluetooth wireless com- munication: ® ■ Bluetooth audio ® The Bluetooth audio system enables you to enjoy music played on a portable digital audio player (portable player) from the vehicle speakers via wireless communication.
Page 364 ® 5-6. Using Bluetooth devices Device registration/connection flow ® 1. Register the Bluetooth device to be used with audio system (→P. 369) ® 2. Connect the registered Bluetooth device to be used (→P. 370) 3. Set automatic connection of the device (→P.
Page 365: Using Bluetooth ® Devices
® 5-6. Using Bluetooth devices Audio unit ® Bluetooth connection condi- tion If “BT” is not displayed, the ® Bluetooth audio/phone cannot be used. Displays set up menu Selects items such as menu and number Turn: Selects an item Press: Inputs the selected item Off-hook switch Turns the hands-free system on/starts a call On-hook switch...
Page 366 ® 5-6. Using Bluetooth devices ® Menu list of the Bluetooth audio/phone First menu Second menu Third menu Operation details Registering “BT pairing” ® Bluetooth device Listing the registered “List phone” cellular phones Listing the registered “List audio” portable players Changing the pass- “Passkey”...
Page 367: Bluetooth ® Audio
® 5-6. Using Bluetooth devices First menu Second menu Third menu Operation details Adding a new num- “Add contacts” Registering a speed “Add SD” dial Deleting a number “Delete call stored in the call his- “Phonebook” history” tory Deleting a number “Delete contacts”...
Page 368: Using The Steering Wheel Switches
® 5-6. Using Bluetooth devices Using the steering wheel switches The steering wheel switches can be used to operate a connected cellular phone, or portable digital audio player (portable player). ® Operating Bluetooth phone using the steering wheel switches Volume The voice guidance volume cannot be adjusted using this button.
Page 369: Register A Bluetooth ® Device
® 5-6. Using Bluetooth devices ® Register a Bluetooth device ® Before using the Bluetooth audio/phone, it is necessary to reg- ® ister a Bluetooth device in the system. Follow the procedure below to register (pair) a device: ® How to register a Bluetooth device Press the “SETUP”...
Page 370: 5-7. "Setup" Menu
5-7. “SETUP” menu Using the “SETUP” menu (“Bluetooth*” ∗ menu) ® Registering a Bluetooth device in the system allows the system to function. The following functions can be used for registered devices: ■ Functions and operation procedures Press the “SETUP” button and select “Bluetooth ”...
Page 371 5-7. “SETUP” menu ® Registering a Bluetooth device Select “BT pairing” using the “TUNE•SCROLL” knob. ® ● If a Bluetooth device is not connected currently ® Perform the procedure for registering a Bluetooth device from step . (→P. 369) ® ●...
Page 372 5-7. “SETUP” menu Listing the registered portable players Select “List audio” using the “TUNE•SCROLL” knob. The list of regis- tered portable players will be displayed. ● Connecting the registered portable player to the audio system Select the name of the portable player to be connected using the “TUNE•SCROLL”...
Page 373 5-7. “SETUP” menu Changing the passkey Select “Passkey” using the “TUNE•SCROLL” knob. Select a 4 to 8-digit passkey using the knob. Input the number 1 digit at a time. When the entire number to be registered as a passkey has been input, press (ENTER).
Page 374 5-7. “SETUP” menu Setting the automatic connection confirmation display to on or off If the “Display setting” is set to on, the portable player connection sta- tus will be displayed when the engine switch is turned to the “ACC” or “ON”...
Page 375: Using The "Setup" Menu ("Phone" Menu)
5-7. “SETUP” menu ∗ Using the “SETUP” menu (“PHONE” menu) ■ Functions and operation procedures To enter the menu for each function, press the “SETUP” button and follow the steps below using the “TUNE•SCROLL” knob: ● Adding a new phone number 1.
Page 376 5-7. “SETUP” menu Adding a new phone number Select “Add contacts” using the “TUNE•SCROLL” knob. ● Transferring all contacts from the cellular phone Select “Overwrite all” using the “TUNE•SCROLL” knob and press (YES). ● Transferring one contact from the cellular phone Select “Add one contact”...
Page 377 5-7. “SETUP” menu Deleting call histories Select “Delete call history” using the “TUNE•SCROLL” knob. ● Deleting outgoing call history Select “Outgoing calls” using the “TUNE•SCROLL” knob. Select the desired phone number using the knob and press (YES). To delete all outgoing call history data, press (ALL) and then press (YES).
Page 378 5-7. “SETUP” menu Deleting a registered phone number Select “Delete contacts” using the “TUNE•SCROLL” knob. Select the desired phone number using the knob and press (YES). To delete all the registered phone numbers, press (ALL) and then press (YES). Press (A-Z) to display the registered names in alphabetical order of the initial.
Page 379 5-7. “SETUP” menu Setting ring tone Select “Ringtone” using the “TUNE•SCROLL” knob. Using the knob, select a ring tone (1 - 3). To set the selected ring tone, press (SAVE). Transferring call histories Select “Transfer histories” using the “TUNE•SCROLL” knob and press (YES).
Page 380: Bluetooth Audio
® 5-8. Bluetooth Audio ® Operating a Bluetooth enabled portable ∗ player Power Changing the audio source/ playback Volume Playback/pause Search playback Previous commands Next commands, random play or back button Selecting a track Repeat play Displaying text message Fast-forwarding, rewinding or selecting an album ∗...
Page 381 ® 5-8. Bluetooth Audio Selecting an album Press (<FOLDER) or (FOLDER>) to select desired album. Press (MORE>) to display the commands. Scanning an album Press and hold the “SCAN” button until you hear a beep. The first 10 seconds of the first track in each album will be played. To cancel, press the button again.
Page 382 ® 5-8. Bluetooth Audio Playing and pausing tracks Press Press (<BACK) to display the command. Switching the display Press the “TEXT” button to display or hide the album title. If there are continuing texts, is displayed. Press and hold the button to display the remaining texts. ®...
Page 383: Bluetooth ® Phone
® 5-9. Bluetooth Phone ∗ Making a phone call To enter the “PHONE” mode, press the off-hook switch. Dialing by selecting a name Select “Phonebook” using the “TUNE•SCROLL” knob. Select the desired name using the knob and press the off-hook switch.
Page 384 ® 5-9. Bluetooth Phone Dialing by entering the number Select “Dial by number” using the “TUNE•SCROLL” knob. Enter the phone number and press the off-hook switch. Dialing from call histories Select “All calls”, “Missed calls”, “Incoming calls” or “Outgoing calls” using the “TUNE•SCROLL”...
Page 385: When Receiving A Phone Call
® 5-9. Bluetooth Phone When receiving a phone call Answering the phone Press the off-hook switch. Refusing the call Press the on-hook switch. Receiving a call when on another call Press the off-hook switch. Pressing the off-hook switch again returns you to the previous call. Adjusting the ring tone volume when receiving a call To decrease the volume: Turn the “PWR•VOL”...
Page 386: Speaking On The Phone
® 5-9. Bluetooth Phone Speaking on the phone Transferring a call A call can be transferred between the cellular phone and system while dialing, receiving a call, or during a call. Use one of the following methods: a. Operate the cellular phone. Refer to the manual that comes with the cellular phone for the operation of the phone.
Page 387 ® 5-9. Bluetooth Phone ■ When talking on the phone ● Do not talk simultaneously with the other party. ● Keep the volume of the received voice down. Otherwise, voice echo will increase. ■ Automatic volume adjustment When vehicle speed is 50 mph (80 km/h) or more, the volume automatically increases.
Page 388: Bluetooth
® 5-10. Bluetooth ® Bluetooth ■ Conditions affecting operation ® The Bluetooth audio/phone may not operate normally in the fol- lowing situations: ® ● The portable player does not support Bluetooth ● The cellular phone is located outside the service area ●...
Page 389 ® 5-10. Bluetooth ■ Compatible models ● Bluetooth ® specifications: Ver. 1.1, or higher (Recommended: Ver. 2.1 + EDR or higher) ● Following Profiles: • A2DP (Advanced Audio Distribution Profile) Ver. 1.0 or higher (recommended: Ver. 1.2 or higher) • AVRCP (Audio/Video Remote Control Profile) Ver. 1.0 or higher (recommended: Ver.
Page 390 ® 5-10. Bluetooth ■ Certification RAV4_OM_OM0R012U_(U)
Page 391 ® 5-10. Bluetooth WARNING ■ While driving Do not operate the portable audio player, cellular phone or connect a device ® to the Bluetooth system. ■ Caution regarding interference with electronic devices ® ● Your audio unit is fitted with Bluetooth antennas.
Page 392: Using The Audio System
5-11. Using the audio system (Entune Audio) Audio system (Entune Audio) Audio system (Entune Audio) functions Setup (→P. 400, 401, 404) ® Audio system and Bluetooth settings can be adjusted. Audio system (→P. 407, 411, 413, 420, 425, 430, 443) ®...
Page 393 5-11. Using the audio system (Entune Audio) WARNING ■ Laser product This product is a class 1 laser product. Do not open the cover of the player or attempt to repair the unit yourself. Refer servicing to qualified personnel. ● Laser products •...
Page 394: 5-12. Basic Operations
5-12. Basic Operations ∗ Audio system operations (Entune Audio) Operations such as listening to audio, using the hands-free phone, confirming vehicle information and changing audio sys- tem settings are started by using the following buttons. Audio system operation buttons “AUDIO” button Display the “Select Audio Source”...
Page 395 5-12. Basic Operations Touch screen gestures Operations are performed by touching the screen directly with your finger. Operation method Outline Main use Touch Changing and selecting Quickly touch various settings. release once. Drag Touch screen Scrolling the lists, using with your finger, and scroll bar in lists, etc.
Page 396: Steering Wheel Audio Switches
5-12. Basic Operations Steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel. Operation may differ depending on the type of audio system or navigation system. For details, refer to the manual provided with the audio system or navigation system.
Page 397: Aux Port/Usb Port
5-12. Basic Operations AUX port/USB port Connect an iPod, USB memory device or portable audio player to the AUX port/USB port as indicated below. Select “iPod”, “USB” or “AUX” on the audio source selection screen and the device can be operated via audio system. Connecting using the AUX port/USB port ■...
Page 398: Basic Audio Operations
5-12. Basic Operations Basic audio operations Basic audio operations and functions common to each mode are explained in this section. Operating the audio system Press this knob to turn the audio system on and off, and turn it to adjust the volume. Press this button to eject a disc Insert a disc into the disc slot Press to pause or resume playing music.
Page 399 5-12. Basic Operations Random playback Select to change on/off. Repeat play Select to change on/off. ■ Using cellular phones Interference may be heard through the audio system’s speakers if a cellular phone is being used inside or close to the vehicle while the audio system is operating.
Page 400: 5-13. Setup
5-13. Setup Setup menu You can adjust the audio system to your desired settings. Display “Setup” screen Press the “SETUP” button to display the “Setup” screen. Select to adjust the settings for operation sounds, screen ani- mation, etc. (→P. 401) Select to display the voice set- tings screen.
Page 401: General Settings
The animation effect for the screen can be set to on/off. Select to delete personal data (→P. 402) Select to update program versions. For details, contact your Toyota dealer. Select to display the software information. Notices related to third party software used in this product are enlisted. (This includes instructions for obtaining such software, where applicable.)
Page 402 5-13. Setup Clock The clock on the Entune Audio can be adjusted by the following pro- cedure. For vehicles with a navigation system or Entune Audio Plus, refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MAN- UAL”. Press the “SETUP” button and select “General” and then select “Clock”.
Page 403: Audio Settings
5-13. Setup Audio settings Settings are available for adjusting the radio operation, cover art, etc. Screen for audio settings Press the “SETUP” button. Select “Audio” on the “Setup” screen. Number of Radio Presets Select the number of radio preset stations. Display Cover Art on/off Automatic Sound Levelizer Automatic sound leveliser (ASL)
Page 404: Display Settings
5-13. Setup Display settings Settings are available for adjusting the contrast and brightness of the screen. Screen for display settings Press the “SETUP” button. Select “Display” on the “Setup” screen. Adjust the screen display Adjust the camera display Changes to day mode. : If equipped Day mode When the headlights are turned on, the screen dims.
Page 405 5-13. Setup Adjusting the screen brightness/contrast Select “General” or “Camera” on the “Display Settings” screen. Select the desired item. “-” “+” “Brightness” Darker Brighter “Contrast” Weaker Stronger RAV4_OM_OM0R012U_(U)
Page 406: Voice Settings
5-13. Setup Voice settings This screen is used for setting the voice command guidance system. Adjust the voice guidance vol- ume setting. voice recognition prompts “High”, “Low” or “Off”. Set the train voice recognition. Set the voice prompt interrupt on/off. Set the voice recognition tuto- rial.
Page 407: Using The Audio System
5-14. Using the audio system Selecting the audio source Switching between audio sources such as radio and CD are explained in this section. Changing audio source Press the “AUDIO” button to display the audio source selection screen. If the audio source selection screen is not displayed, press the “AUDIO” button again.
Page 408: List Screen Operation
5-14. Using the audio system List screen operation When a list screen is displayed, use the appropriate buttons to scroll through the list. How to scroll : Select to scroll to the next or previous page. : If appears to the right of titles, the complete titles are too long for the display.
Page 409 5-14. Using the audio system Selecting, fast-forwarding and reversing tracks/files/songs ■ Selecting a track/file/song Press the “SEEK >” button or “< TRACK” button, or turn the “TUNE•SCROLL” knob to select the desired track/file/song number. To fast-forward or reverse, press and hold the “SEEK >” button or “<...
Page 410: Optimal Use Of The Audio System
5-14. Using the audio system Optimal use of the audio system On the “Sound Settings” screen, sound quality (Treble/Mid/ Bass), volume balance can be adjusted. How to adjust the sound settings and sound quality 1 2 3 Select “-” or “+” to adjust the treble, mid or bass to a level between -5 and 5.
Page 411: Using The Radio
5-15. Using the radio Radio operation Select “AM” or “FM” on the audio source selection screen to begin listening to the radio. Audio control screen Pressing the “AUDIO” button displays the audio control screen from any screens of the selected source. Audio source selection screen appears Preset stations...
Page 412 5-15. Using the radio Setting station presets Search for desired stations by turning the “TUNE•SCROLL” knob or pressing the “SEEK >” button or “< TRACK” button. Select “(add new)”. To change the preset station to a different one, select and hold the preset station.
Page 413: Cd Player Operation
5-16. Playing an audio CD and MP3/WMA/AAC discs CD player operation Insert disc or select “CD” on the audio source selection screen with a disc inserted to begin listening to a CD. Audio control screen Pressing the “AUDIO” button displays the audio control screen from any screens of the selected source.
Page 414: Cd Player And Disc Information
Error messages If the following error messages appear on the screen, refer to the table and take the appropriate measures. If the problem is not recti- fied, take the vehicle to your Toyota dealer. Message Cause/Correction procedures • The disc is dirty or damaged. Clean the disc.
Page 415 5-16. Playing an audio CD and MP3/WMA/AAC discs ■ MP3, WMA and AAC files MP3 (MPEG Audio LAYER3) is a standard audio compression for- mat. Files can be compressed to approximately 1/10 of their original size by using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression for- mat.
Page 416 5-16. Playing an audio CD and MP3/WMA/AAC discs ● AAC file compatibility • Compatible standards MPEG4/AAC-LC • Compatible sampling frequencies 11.025/12/16/22.05/24/32/44.1/48 (kHz) • Compatible bit rates 16-320 (kbps) ● Compatible media Media that can be used for MP3, WMA and AAC playback are CD-Rs and CD-RWs.
Page 417 5-16. Playing an audio CD and MP3/WMA/AAC discs ● ID3, WMA and AAC tags ID3 tags can be added to MP3 files, making it possible to record the track title, artist name, etc. The system is compatible with ID3 Ver. 1.0, 1.1, and Ver. 2.2, 2.3 ID3 tags.
Page 418 5-16. Playing an audio CD and MP3/WMA/AAC discs ● Playback • To play MP3 files with steady sound quality, we recommend a fixed bit rate of at least 128 kbps and a sampling frequency of 44.1 kHz. • CD-R or CD-RW playback may not be possible in some instances, depending on the characteristics of the disc.
Page 419 5-16. Playing an audio CD and MP3/WMA/AAC discs NOTICE ■ Discs and adapters that cannot be used Do not use the following types of CDs. Also, do not use 3 in. (8 cm) CD adapters, DualDiscs or printable discs. Doing so may damage the CD player and/or the CD insert/eject function. ●...
Page 420: 5-17. Using An External Device
5-17. Using an external device iPod player operation Connecting an iPod enables you to enjoy music from the vehicle speakers. Select “iPod” on the audio source selection screen. When the iPod connected to the system includes iPod video, the system can only output the sound by selecting the browse screen.
Page 421 5-17. Using an external device Selecting a play mode Select “Browse” on the screen. Select the desired play mode by selecting the “Playlists”, “Artists”, “Albums”, “Songs”, “Podcasts”, “Audio books”, “Genres”, “Compos- ers” or “Videos” tab. Then select a song to begin using the selected play mode.
Page 422 5-17. Using an external device ■ About iPod ● “Made for iPod” and “Made for iPhone” mean that an electronic accessory has been designed to connect specifically to iPod or iPhone, respectively, and has been certified by the developer to meet Apple performance stan- dards.
Page 423 ■ Error messages If the following error messages appear on the screen, refer to the table and take the appropriate measures. If the problem is not rectified, take the vehicle to your Toyota dealer. Message Cause/Correction procedures “Connection error. Please consult your Owner’s Man-...
Page 424 5-17. Using an external device ■ Compatible models ® ® ® ® ® The following iPod , iPod nano , iPod classic , iPod touch and iPhone devices can be used with this system. ● Made for • iPod touch (5th generation) •...
Page 425: Usb Memory Device Player Operation
5-17. Using an external device USB memory device player operation Connecting a USB memory device enables you to enjoy music from the vehicle speakers. Touch “USB” on the audio source selection screen. Connecting a USB memory device →P. 397 Audio control screen Pressing the “AUDIO”...
Page 426 Error messages for USB memory If the following error messages appear on the screen, refer to the table and take the appropriate measures. If the problem is not rectified, take the vehicle to your Toyota dealer. Message Cause/Correction procedures “Connection error. Please consult your Owner’s Man-...
Page 427 5-17. Using an external device ■ USB memory ● Compatible devices USB memory device that can be used for MP3, WMA and AAC playback. ● Compatible device formats The following device format can be used: • USB communication format: USB2.0 HS (480Mbps) and FS (12 Mbps) •...
Page 428 5-17. Using an external device ● MP3 file compatibility • Compatible standards MP3 (MPEG1 AUDIO LAYERII, III, MPEG2 AUDIO LAYERII, III, MPEG2.5) • Compatible sampling frequencies MPEG1 AUDIO LAYERII, III: 32, 44.1, 48 (kHz) MPEG2 AUDIO LAYERII, III: 16, 22.05, 24 (kHz) •...
Page 429 5-17. Using an external device ● MP3, WMA and AAC playback • When a device containing MP3, WMA and AAC files is connected, all files in the USB memory device are checked. Once the file check is fin- ished, the first MP3, WMA and AAC file is played. To make the file check finish more quickly, we recommend that you do not include any files other than MP3, WMA and AAC files or create any unnecessary folders.
Page 430: Using The Aux Port
5-17. Using an external device Using the AUX port This port can be used to connect a portable audio device and lis- ten to it through the vehicle’s speakers. Connecting a portable audio player →P. 397 Audio control screen Press the “AUDIO” button to display the audio control screen, then select “AUX”.
Page 431: Connecting Bluetooth
® 5-18. Connecting Bluetooth Preparations to use wireless communica- tion ® The following can be performed using Bluetooth wireless com- munication: ■ A portable audio player can be operated and listened to via audio system ■ Hands-free phone calls can be made via a cellular phone In order to use wireless communication, register and connect a ®...
Page 432 ® 5-18. Connecting Bluetooth Device registration/connection flow ® 1. Register the Bluetooth device to be used with audio sys- tem (→P. 434, 435, 436) ® 2. Connect the Bluetooth device to be used (→P. 438) To be used for audio To be used for hands-free phone ®...
Page 433 ® 5-18. Connecting Bluetooth Registering and connecting from the “Bluetooth* Setup” screen To display the screen shown below, press the “SETUP” button and select “Bluetooth ” on the “Setup” screen. Select to connect the device to be used with audio system. (→P.
Page 434: Registering A Bluetooth ® Audio Player For The First Time
® 5-18. Connecting Bluetooth ® Registering a Bluetooth audio player for the first time ® To use the Bluetooth Audio, it is necessary to register an audio player with the system. Once the player has been registered, it is possible to use the ®...
Page 435: Registering A Bluetooth ® Phone For The First Time
® 5-18. Connecting Bluetooth ® Registering a Bluetooth phone for the first time To use the hands-free system, it is necessary to register a ® Bluetooth phone with the system. Once the phone has been registered, it is possible to use the hands-free system.
Page 436: Registering A Bluetooth ® Device
® 5-18. Connecting Bluetooth ® Registering a Bluetooth device ® Bluetooth compatible phones (HFP) and portable audio players (AVP) can be registered simultaneously. You can register up to 5 ® Bluetooth devices. ® How to register a Bluetooth device Display the “Bluetooth* Setup” screen. (→P. 433) : Bluetooth is a registered trademark of Bluetooth SIG, Inc.
Page 437 ® 5-18. Connecting Bluetooth Check that this screen is dis- played when registration is complete. Select “OK” when the connection status changes from “Connect- ing...” to “Connected”. If an error message is displayed, follow the guidance on the screen to try again.
Page 438: Connecting A Bluetooth ® Device
® 5-18. Connecting Bluetooth ® Connecting a Bluetooth device ® Up to 5 Bluetooth devices (Phones (HFP) and audio players (AVP)) can be registered. ® If more than 1 Bluetooth device has been registered, select which device to connect to. ®...
Page 439 ® 5-18. Connecting Bluetooth Auto connection To turn auto connection mode on, set “Bluetooth* Power” to on. (→P. 441) When you register a phone, auto connection will be activated. Always ® set it to this mode and leave the Bluetooth phone in a place where a connection can be established.
Page 440: Displaying A Bluetooth ® Device Details
® 5-18. Connecting Bluetooth ® Displaying a Bluetooth device details You can confirm and change the registered device details. ® Bluetooth device registration status Display the “Bluetooth* Setup” screen. (→P. 433) : Bluetooth is a registered trademark of Bluetooth SIG, Inc. Select the device.
Page 441: Detailed Bluetooth ® Settings
® 5-18. Connecting Bluetooth ® Detailed Bluetooth settings ® You can confirm and change the detailed Bluetooth settings. ® How to check and change detailed Bluetooth settings Display the “Bluetooth* Setup” screen. (→P. 433) Select “System Settings”. The following screen is displayed: Bluetooth * Power on/off You can change Bluetooth on/off...
Page 442 ® 5-18. Connecting Bluetooth Editing the Bluetooth* PIN ® You can change the PIN-code that is used to register your Bluetooth devices in the system. Select “Bluetooth* PIN”. Input a PIN-code, and select “OK”. : Bluetooth is a registered trademark of Bluetooth SIG, Inc. RAV4_OM_OM0R012U_(U)
Page 443: Bluetooth ® Audio
® 5-19. Bluetooth Audio ® Listening to Bluetooth Audio ® The Bluetooth audio system enables the user to enjoy music played on a portable player from the vehicle speakers via wire- less communication. ® When a Bluetooth device cannot be connected, check the connec- tion status on the “Bluetooth* Audio”...
Page 444 ® 5-19. Bluetooth Audio ® Playing Bluetooth audio Select to Play/Pause. For details on “Bluetooth Audio” screen operation methods, refer to Basic Audio Operations. (→P. 398) For details on how to select a track or album, refer to selecting, fast- forwarding and reversing tracks/files/songs.
Page 445: Bluetooth ® Phone
® 5-20. Bluetooth Phone ® Using a Bluetooth Phone The hands-free system is a function that allows you to use your cellular phone without touching it. ® ® This system supports Bluetooth . Bluetooth is a wireless data system that allows the cellular phone to wirelessly connect to the hands-free system and make/receive calls.
Page 446 ® 5-20. Bluetooth Phone ■ Telephone switch (→P. 459) ■ Microphone The vehicle’s built in micro- phone is used when talking on the phone. The person you are speaking to can be heard from the front speakers. To use the hands-free system, must register your...
Page 447: Making A Call
® 5-20. Bluetooth Phone Making a call ® Once a Bluetooth phone is registered, you can make a call using the following procedure: Dialing Display the phone screen. (→P. 445) Select the “Dial Pad” tab and enter a phone number. To delete the input phone number, select For the first digit, you can enter “+”...
Page 448 ® 5-20. Bluetooth Phone ® ■ For PBAP compatible Bluetooth phones When “Automatic Contact/History Transfer” is set to off  Select the desired item. Select to transfer new con- tacts from a cellular phone, select “Always” and then enable “Automatic Con- tact/History Transfer”.
Page 449 ® 5-20. Bluetooth Phone Calling using favorites list You can make a call using numbers registered in the contact. Display the phone screen. (→P. 445) Select “Favorites” tab. Select the desired number to make a call. Dialing from call history You can make a call using the call history, which has the 3 functions below.
Page 450: Receiving A Call
® 5-20. Bluetooth Phone Receiving a call When a call is received, the following screen is displayed together with a sound. To answer the phone Press the switch on the steer- ing wheel or select To refuse a call Press the switch on the steering wheel or select To adjust the incoming call volume Turn the “PWR VOL”...
Page 451: Speaking On The Phone
® 5-20. Bluetooth Phone Speaking on the phone The following screen is displayed when speaking on the phone. To adjust the call volume Select “-” or “+”. You can also adjust the volume using the steering switches or the volume knob. To prevent the other party from hearing your voice Select “Mute”.
Page 452 ® 5-20. Bluetooth Phone ■ Release Tones ● A continuous tone signal is a character string that consists of numbers and the characters p or w. (e.g.056133w0123p#1∗) ● When the “p” pause tone is used, the tone data up until the next pause tone will be automatically sent after 2 seconds have elapsed.
Page 453 ® 5-20. Bluetooth Phone Call waiting When a call is interrupted by a third party while talking, an incoming call message will be displayed. To talk with the other party: • Press the switch on the steering wheel. • Select To refuse the call: •...
Page 454: Bluetooth ® Phone Message Function
® 5-20. Bluetooth Phone ® Bluetooth phone message function Received messages can be forwarded from the connected ® Bluetooth phone, enabling checking and replying using the audio system. ® Depending on the type of Bluetooth phone connected, received messages may not be transferred to the message inbox. If the phone does not support the message function, this func- tion cannot be used.
Page 455 ® 5-20. Bluetooth Phone ■ Receiving a message ● Depending on the cellular phone used for receiving messages, or its regis- tration status with the navigation system, some information may not be dis- played. ● The pop up screen is separately available for incoming e-mail and SMS/ MMS messages under the following conditions: E-mail: •...
Page 456 ® 5-20. Bluetooth Phone Checking the messages Display the “Message Inbox” screen. (→P. 454) Select the desired message from the list. Check that the message is displayed. E-mails: Select “Mark Unread” or “Mark Read” to mark mail unread or read on the message inbox screen.
Page 457 ® 5-20. Bluetooth Phone ■ Check the messages ® ● Depending on the type of Bluetooth phone being connected, it may be nec- essary to perform additional steps on the phone. ● ® Messages are displayed in the appropriate connected Bluetooth phone’s registered mail address folder.
Page 458 ® 5-20. Bluetooth Phone Calling the message sender Calls can be made to an e-mail/SMS/MMS message sender’s phone number. Display the “Message Inbox” screen. (→P. 454) Select the desired message. Select Check that the “Call” screen is displayed. ■ Calling from a number within a message Calls can be made to a number identified in a message’s text area.
Page 459: Using The Steering Wheel Switches
® 5-20. Bluetooth Phone Using the steering wheel switches The steering wheel switches can be used to operate a connected cellular phone. Operating a telephone using the steering wheel switches Volume switch • Increase/Decrease the vol- • Press and hold: Continuously increase/ decrease the volume...
Page 460: Bluetooth ® Phone Settings
® 5-20. Bluetooth Phone ® Bluetooth phone settings You can adjust the hands-free system to your desired settings. “Phone/Message Settings” screen To display the screen shown below, press the “SETUP” button, and select “Phone” on the “Setup” screen. Set the phone connection (→P.
Page 461 ® 5-20. Bluetooth Phone Sound setting Display the “Phone/Message Settings” screen. (→P. 460) Select “Sound Settings” on the “Phone/Message Settings” screen. Set the desired ringtone. Adjust the ringtone volume. Adjust the message readout volume. Set the desired incoming SMS/MMS tone. Adjust the incoming SMS/ MMS tone volume.
Page 462: 5-21. Phonebook
5-21. Phonebook Contact/Call History Settings ® The contact can be transferred from a Bluetooth phone to the system. The contact also can be added, edited and deleted. The call history can be deleted and contact and favorites can be changed. “Contact/Call History Settings”...
Page 463 5-21. Phonebook Update contacts from phone Operation methods differ between PBAP compatible and PBAP ® incompatible but OPP compatible Bluetooth phones. If your cellular phone is neither PBAP nor OPP compatible, the con- tacts cannot be transferred. ® ■ For PBAP compatible Bluetooth Phones Select “Update Contacts from Phone”.
Page 464 5-21. Phonebook ® ■ For PBAP incompatible but OPP compatible Bluetooth Phones Select “Update Contacts from Phone”. ® Transfer the contact data to the system using a Bluetooth phone. This operation may be unnecessary depending on the type of cellular phone.
Page 465 5-21. Phonebook Registering a new contact to the contact list New contact data can be registered. Up to 4 numbers per person can ® be registered. For PBAP compatible Bluetooth phones, this function is available when “Automatic Contact/History Transfer” is set to off. (→P.
Page 466 5-21. Phonebook Editing the contact data ® For PBAP compatible Bluetooth phones, this function is available when “Automatic Contact/History Transfer” is set to off. (→P. 462) Select “Edit Contact”. Select the desired contact. Select corresponding to the desired name or number. ...
Page 467 5-21. Phonebook Deleting the contact data ® For PBAP compatible Bluetooth phones, this function is available when “Automatic Contact/History Transfer” is set to off. (→P. 462) Select “Delete Contacts”. Select the desired contact and select “Delete”. Select “Yes” when the confirmation screen appears. ■...
Page 468 5-21. Phonebook  When 15 contacts have already been registered to the favorites list When 15 contacts have already been registered to the favorites list, a registered contact needs to be replaced. Select “Yes” when the confirmation screen appears to replace a contact.
Page 469 5-21. Phonebook ■ Deleting the contacts in the favorites list Select “Remove Favorite”. Select the desired contacts and select “Remove”. Select “Yes” when the confirmation screen appears. Check that a confirmation screen is displayed when the opera- tion is complete. ...
Page 470 5-21. Phonebook Message Settings Display the “Phone/Message Settings” screen. (→P. 460) Select “Messaging Settings”. Select the desired item to be set. automatic message transfer on/off. automatic message readout on/off. Set the SMS/MMS notifica- tion popup on/off. Set the e-mail notification popup on/off.
Page 471 5-21. Phonebook ■ Displaying the “Messaging Settings” screen in a different way Display the phone screen. (→P. 445) Select Select “Settings”. Select “Message Settings”. Phone Display Settings Display the “Phone/Message Settings” screen. (→P. 460) Select “Phone Display Settings”. Select the desired item to be set. Change the incoming call display.
Page 472: 5-22. Bluetooth
→ For a list of specific devices which operation has been confirmed on this system, check with your Toyota dealer or the following web- site: http://www.toyota.com/entune/ The Bluetooth version of the connected cellular phone may be older than the specified version.
Page 473 ® 5-22. Bluetooth  When registering/connecting a cellular phone A cellular phone cannot be registered. An incorrect passcode was entered on the cellular phone. → Enter the correct passcode on the cellular phone. The registration operation has not been completed on the cellular phone side.
Page 474 → For a list of specific devices which operation has been confirmed on this system, check with your Toyota dealer or the following web- site: http://www.toyota.com/entune/ Automatic contact transfer function on this system is set to off.
Page 475 ® 5-22. Bluetooth  In other situations ® The Bluetooth connection status is displayed at the top of the screen each time the engine switch is turned to the “ACC” or “ON” position (vehicles without smart key system) or ACCESSORY or IGNITION ON mode (vehi- cles with smart key system).
Page 476: Bluetooth
® 5-22. Bluetooth ® Bluetooth ® ■ When using the Bluetooth audio system ● In the following conditions, the system may not function. • If the portable audio player is turned off • If the portable audio player is not connected •...
Page 477 ® 5-22. Bluetooth ■ ® Bluetooth antenna The antenna is built into the display. If the portable audio player is behind the seat or in the glove box or console box, or is touching or covered by metal objects, the connection status may deteriorate.
Page 478 ® 5-22. Bluetooth ■ Compatible models ® The Bluetooth audio system supports portable audio players with the follow- ing specifications ● ® Bluetooth specifications: Ver. 2.0, or higher (Recommended: Ver. 3.0+EDR or higher) ● Profiles: • A2DP (Advanced Audio Distribution Profile) Ver. 1.0, or higher (Recommended: Ver.
Page 479 ® 5-22. Bluetooth ■ Reconnecting the portable audio player If the portable audio player is disconnected due to poor reception when the engine switch is in the “ACC” or “ON” position (vehicles without smart key system) or ACCESSORY or IGNITION ON mode (vehicles with smart key system), the system automatically reconnects the portable audio player.
Page 480 ® 5-22. Bluetooth RAV4_OM_OM0R012U_(U)
Page 481 ® 5-22. Bluetooth WARNING ■ While driving Do not operate the portable audio player, cellular phone or connect a device ® to the Bluetooth system. ■ Caution regarding interference with electronic devices ® ● Your audio unit is fitted with Bluetooth antennas.
Page 482: System
5-23. Other function Voice command system The voice command system enables the hands-free system to be operated using voice commands. Using the voice command system Press the talk switch. Select to train voice recogni- tion. Select to start the voice rec- ognition tutorial.
Page 483 5-23. Other function ■ Microphone →P. 446 ■ When using the microphone ● It is unnecessary to speak directly into the microphone when giving a com- mand. ● When “Voice Prompt Interrupt” is set on, it is not necessary to wait for the confirmation beep before speaking a command.
Page 484 5-23. Other function Command list Some recognizable voice commands and their actions are shown below as examples.  Basic Command Action Prompts voice guidance to offer examples of com- “Help” mands or operation methods “Go Back” Returns to the previous screen ...
Page 485 5-23. Other function Mobile Assistant ® The Mobile Assistant feature will activate Apple’s Siri Eyes Free mode via the steering wheel switches. To operate the Mobile Assis- tant, a compatible cellular phone must be registered and connected to ® this system via Bluetooth .
Page 486 5-23. Other function ■ Notes about Mobile Assistant ● The available features and functions may vary based on the iOS version installed on the connected device. ● ® Some Siri features are limited in Eyes Free mode. If you attempt to use an ®...
Page 487: Interior Features
Interior features 6-1. Using the air conditioning system and defogger Manual air conditioning system ......488 Automatic air conditioning system ... 494 Heated steering wheel/ seat heaters ....503 6-2. Using the interior lights Interior lights list ....505 • Interior lights ....506 •...
Page 488: 6-1. Using The Air Conditioning System And Defogger
6-1. Using the air conditioning system and defogger ∗ Manual air conditioning system Control panel ■ Adjusting the temperature setting Turn the temperature control dial clockwise (warm) or counterclock- wise (cool). If the “A/C” button is not pressed, the system will blow ambient tempera- ture air or heated air.
Page 489 6-1. Using the air conditioning system and defogger ■ Changing the air flow mode Turn the air outlet selector dial to change the airflow mode. The positions between the air outlet selections can also be selected more delicate adjustment. Air flows to the upper body. Air flows to the upper body and feet.
Page 490 6-1. Using the air conditioning system and defogger ■ Defogging the rear window and outside rear view mirrors (if equipped) Defoggers are used to defog the rear window, and to remove rain- drops, dew and frost from the outside rear view mirrors. Press The defoggers will automatically turn off after a period of time.
Page 491 6-1. Using the air conditioning system and defogger ■ Adjusting the position of and opening and closing the air out- lets  Front center outlets Direct air flow to the left or right, up or down. Turn the knobs to open or close the vents.
Page 492 6-1. Using the air conditioning system and defogger ■ Operation of the air conditioning system in Eco drive mode In Eco drive mode, the air conditioning system is controlled to prioritize fuel efficiency by regulating the engine speed and compressor operation to restrict the heating/cooling capacity.
Page 493 6-1. Using the air conditioning system and defogger WARNING ■ To prevent the windshield from fogging up ● Do not set the air outlet selection dial to during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield can cause the outer surface of the windshield to fog up, blocking your vision.
Page 494: Air Conditioning System
6-1. Using the air conditioning system and defogger ∗ Automatic air conditioning system Air outlets and fan speed are automatically adjusted according to the temperature setting. Control panel ■ Adjusting the temperature setting Turn clockwise to increase the temperature and turn the knob counterclockwise to decrease the temperature.
Page 495 6-1. Using the air conditioning system and defogger ■ Adjusting the fan speed setting Press “∧”on to increase the fan speed and “∨” to decrease the fan speed. Press to turn the fan off. ■ Change the airflow mode To change the air outlets, press “∧”or “∨”on The air outlets used are switched each time either side of the button is pressed.
Page 496 6-1. Using the air conditioning system and defogger ■ Automatic mode indicator If the fan speed setting or air flow modes are operated, the auto- matic mode indicator goes off. However, automatic mode for func- tions other than that operated is maintained. Other functions ■...
Page 497 6-1. Using the air conditioning system and defogger ■ Defogging the windshield Defoggers are used to defog the windshield and front side win- dows. Press The dehumidification function operates and fan speed increases. Set the outside/recirculated air mode button to outside air mode if the recirculated air mode is used.
Page 498 6-1. Using the air conditioning system and defogger Air outlets ■ Location of air outlets The air outlets and air volume changes according selected air flow mode. ■ Adjusting the position of and opening and closing the air out- lets ...
Page 499 6-1. Using the air conditioning system and defogger  Front side outlets Direct air flow to the left or right, up or down. Open the vent. Close the vent. ■ Operation of the air conditioning system in Eco drive mode In Eco drive mode, the air conditioning system is controlled as follows to pri- oritize fuel efficiency: ●...
Page 500 6-1. Using the air conditioning system and defogger ■ Fogging up of the windows ● The windows will easily fog up when the humidity in the vehicle is high. Turning on will dehumidify the air from the outlets and defog the wind- shield effectively.
Page 501 6-1. Using the air conditioning system and defogger ■ Ventilation and air conditioning odors ● To let fresh air in, set the air conditioning system to the outside air mode. ● During use, various odors from inside and outside the vehicle may enter into and accumulate in the air conditioning system.
Page 502 6-1. Using the air conditioning system and defogger NOTICE ■ To prevent battery discharge Do not leave the air conditioning system on longer than necessary when the engine is off. RAV4_OM_OM0R012U_(U)
Page 503: Heated Steering Wheel/ Seat Heaters
6-1. Using the air conditioning system and defogger ∗ ∗ Heated steering wheel /seat heaters Heated steering wheel and seat heaters heat the side grips of the steering wheel and seats, respectively. WARNING ● Care should be taken to prevent injury if anyone in the following categories comes in contact with the steering wheel and seats when the heater is on: •...
Page 504 6-1. Using the air conditioning system and defogger Heated steering wheel Turns the heated steering wheel on/off The indicator light comes on when the heated steering wheel is oper- ating. The heated steering wheel can be used when the engine switch is in the “ON” position (vehicles without smart key system) or IGNITION ON mode (vehicles with smart key system).
Page 505: Using The Interior Lights
6-2. Using the interior lights Interior lights list Interior lights (→P. 506) Interior/personal lights (→P. 506) Engine switch light (if equipped) Instrument panel center illumination (if equipped) Footwell lights (if equipped) RAV4_OM_OM0R012U_(U)
Page 506: Interior Lights
6-2. Using the interior lights Interior lights ■ Front Door position The interior lights come on when a door is opened. They turn off when the doors are closed. ■ Rear Door position The interior light comes on when a door is opened. It turns off when the doors are closed.
Page 507 6-2. Using the interior lights ● Illuminated entry system: The lights automatically turn on/off according to the engine switch position (vehicles without smart key system), engine switch mode or presence of the electronic key (vehicles with smart key sys- tem), whether the doors are locked/unlocked, and whether the doors are opened/closed.
Page 508: 6-3. Using The Storage Features
6-3. Using the storage features List of storage features Glove box (→P. 509) Cup holders (→P. 510) Bottle holders (→P. 511) Storage boxes (→P. 513) Console box (→P. 509) Auxiliary box (→P. 511) WARNING ● Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the following when cabin temperature becomes high: •...
Page 509: Glove Box
6-3. Using the storage features Glove box Pull up the lever to open the glove box. Console box Lift the lid while pulling up the knob to release the lock. Lower box Upper box Vehicles with slide function: When using the console box lid as an armrest, slide the console box lid forward as needed.
Page 510: Cup Holders
6-3. Using the storage features WARNING ● Do not adjust the position of the console box while the vehicle is moving. This may cause the driver to mishandle the vehicle and may lead to an accident that results in death or serious injury. ●...
Page 511: Bottle Holders
6-3. Using the storage features Bottle holders  Front  Rear WARNING Do not place anything other than a bottle in the bottle holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
Page 512: Luggage Compartment Features
6-3. Using the storage features Luggage compartment features Cargo hooks Raise the hooks to use. The cargo hooks are provided for securing loose items. WARNING To avoid injury, always return the cargo hooks to their stowed positions when not in use. Grocery bag hooks NOTICE Do not hang any object heavier than 8.8 lb.
Page 513 6-3. Using the storage features Storage boxes ■ Front Open the deck board by pulling up the strap. Warning reflector etc. can be stowed. ■ Rear Vehicles with full-size spare tire: Turn the knob of each clip on the rear deck board to unlock.
Page 514 6-3. Using the storage features WARNING Do not drive with any of the deck boards opened. Items may fall out and cause injury. Luggage cover (if equipped) ■ Installing the luggage cover With the “TOP” marks up, insert the right end of the lug- gage cover into the recess, then compress the left of the luggage cover and insert it...
Page 515 6-3. Using the storage features ■ Removing the luggage cover Release the cover from the left and right anchors and allow it to retract. Compress the end of the lug- gage cover and lift the lug- gage cover up. ■ Stowing the luggage cover (except for vehicles with full-size spare tire) Open the rear deck board...
Page 516 6-3. Using the storage features WARNING ● When installing/stowing the luggage cover, make sure that the luggage cover is securely installed/stowed. Failure to do so may result in serious injury in the event of sudden braking or a collision. ● Do not place anything on the luggage cover to avoid death or serious injury.
Page 517 6-3. Using the storage features Rear cargo net (If equipped) The fixed position of the poles can be changed to accommodate the size and type of luggage being stored. Also, the cargo net can be used to prevent luggage from spilling out by installing one of the poles at a lower level.
Page 518 6-3. Using the storage features ■ Installing to the upper level and changing the fixed position ● Installing the rear cargo net Except for vehicles with full-size spare tire: Take out the rear cargo net. Push the right or left end of the pole into the slide rail.
Page 519 6-3. Using the storage features ● Changing the fixed position of the pole Lift the pole to move up to the slide rail. Slide the pole to the desired fixed position, and push down. Move the pole so that its left and right ends line up and the pole is straight.
Page 520 6-3. Using the storage features ■ Installing to the lower level and changing the fixed position ● Installing the rear cargo net Except for vehicles with full-size spare tire: Take out the rear cargo net. Push one end of the pole into a fixed position to shorten the pole.
Page 521 6-3. Using the storage features ● Changing the fixed position of the pole Push one end of the pole into its fixed position to shorten the pole, and then remove the rear cargo net. Perform the steps in “Installing the rear cargo net”. (→P.
Page 522 6-3. Using the storage features WARNING Make sure to observe the following precautions. Failure to observe these precautions may result in death or serious injury. ● Do not allow children to climb or ride on the rear cargo net. ● Do not load any luggage into the rear cargo net that extends beyond the height of the pole.
Page 523: Using The Other Interior
6-4. Using the other interior features Other interior features Sun visors Forward position: Flip down. Side position: Flip down, unhook, and swing to the side. Side extender (if equipped): Place in side position then slide backwards. Vanity mirrors Slide the cover to open. The light turns on when the cover is opened.
Page 524: Power Outlets
6-4. Using the other interior features Power outlets ■ 12 VDC type Please use a power supply for electronic goods that use less than 12 VDC/10 A (power consumption of 120 W). When using electronic goods, make sure that the power consump- tion of all the connected power outlets is less than 120 W.
Page 525 6-4. Using the other interior features NOTICE ● To avoid damaging the power outlets, close the power outlet lids when the power outlets are not in use. Foreign objects or liquids that enter the power outlets may cause a short circuit.
Page 526: Armrest
6-4. Using the other interior features Armrest Fold down the armrest for use. NOTICE To prevent damage to the armrest, do not apply too much load on the arm- rest. Coat hooks The coat hooks are provided with the rear assist grips. WARNING Do not hang coat hangers or other hard or sharp objects on the hook.
Page 527: Assist Grips
6-4. Using the other interior features Assist grips An assist grip installed on the ceil- ing can be used to support your body while sitting on the seat. WARNING Do not use the assist grip when getting in or out of the vehicle or rising from your seat.
Page 528: Garage Door Opener
6-4. Using the other interior features ∗ Garage door opener The garage door opener can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, security systems, and other devices. ® Programming the HomeLink ® The HomeLink wireless control system in your vehicle has 3 buttons which can be programmed to operate 3 different devices.
Page 529 6-4. Using the other interior features ® ■ Programming HomeLink Steps through must be performed within 60 seconds, other- wise the indicator light will stop flashing and programming will not be able to be completed. ® Press and release the HomeLink button you want to program ®...
Page 530 6-4. Using the other interior features ® Test the HomeLink operation by pressing the newly pro- grammed button and observing the indicator light: ● Indicator light illuminates: Programming of a fixed code device has completed. The garage door or other device should oper- ®...
Page 531 6-4. Using the other interior features Press and hold the desired ® HomeLink button (inside the vehicle) for 2 seconds and release Repeat this sequence (press/hold/ release) up to 3 times to complete programming. If the garage door opener motor operates when the ®...
Page 532 6-4. Using the other interior features ® ■ Reprogramming a single HomeLink button When the following procedure is performed, buttons which already have devices registered to them can be overwritten: ® With one hand, press and hold the desired HomeLink button.
Page 533 6-4. Using the other interior features ® Erasing the entire HomeLink memory (all three codes) Press and hold the 2 outside but- tons for 10 seconds until the ® HomeLink indicator light changes from continuously lit (orange) rapidly flashing (green). If you sell your vehicle, be sure to erase the programs stored in the ®...
Page 534 6-4. Using the other interior features ■ When support is necessary Visit on the web at www.homelink.com/toyota or call 1-800-355-3515. WARNING ■ When programming a garage door or other remote control device The garage door or other device may operate, so ensure people and objects are out of danger to prevent potential harm.
Page 535: Compass
6-4. Using the other interior features ∗ Compass The compass on the inside rear view mirror indicates the direc- tion in which the vehicle is heading. Operation To turn the compass on or off, press and hold the switch for 3 seconds.
Page 536 6-4. Using the other interior features Calibrating the compass The direction display deviates from the true direction determined by the earth’s magnetic field. The amount of deviation varies according to the geographic position of the vehicle. If you cross over a map boundary shown in illustration, the compass will deviate.
Page 537 6-4. Using the other interior features ■ Circling calibration Stop the vehicle in a place where it is safe to drive in a circle. Press and hold the switch for 9 seconds. “C” appears on the compass display. Drive the vehicle at 5 mph (8 km/h) or less in a circle until a direction is displayed.
Page 538 6-4. Using the other interior features WARNING ■ While driving the vehicle Do not adjust the display. Adjust the display only when the vehicle is stopped. ■ When doing the circling calibration Secure a wide space, and watch out for people and vehicles in the neigh- borhood.
Page 539: Maintenance And Care
Maintenance and care 7-1. Maintenance and care Cleaning and protecting the vehicle exterior..540 Cleaning and protecting the vehicle interior... 543 7-2. Maintenance Maintenance requirements ....546 General maintenance..549 Emission inspection and maintenance (I/M) programs......552 7-3. Do-it-yourself maintenance Do-it-yourself service precautions .....
Page 540: Maintenance And Care Cleaning And Protecting
7-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition: ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 541 ■ Precautions regarding the Blind Spot Monitor (if equipped) If the paint of the rear bumper is chipped or scratched, the system may mal- function. If this occurs, consult your Toyota dealer. RAV4_OM_OM0R012U_(U)
Page 542 7-1. Maintenance and care NOTICE ■ To prevent paint deterioration and corrosion on the body and compo- nents (aluminum wheels etc.) ● Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
Page 543: Cleaning And Protecting The Vehicle Interior
7-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior ● Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces with a cloth dampened with lukewarm water.
Page 544 7-1. Maintenance and care ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 545 Water may also cause the body to rust. ■ When cleaning the inside of the windshield (vehicles with Toyota Safety Sense P) Do not allow glass cleaner to contact the lens. Also, do not touch the lens.
Page 546: 7-2. Maintenance
Toyota recommends the following main- tenance: General maintenance General maintenance should be performed on a daily basis. This can be done by yourself or by a Toyota dealer. Scheduled maintenance Scheduled maintenance should be performed at specified intervals according to the maintenance schedule.
Page 547: Maintenance
■ Repair and replacement It is recommended that genuine Toyota parts be used for repairs to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than a Toyota dealer performs repairs, confirm the war- ranty coverage.
Page 548 7-2. Maintenance WARNING ■ If your vehicle is not properly maintained Improper maintenance could result in serious damage to the vehicle and possible death or serious injury. ■ Handling of the battery ● Engine exhaust, some of its constituents, and a wide variety of automobile components contain or emit chemicals known to the State of California to cause cancer and birth defects and other reproductive harm.
Page 549: General Maintenance
“Owner’s Warranty Information Booklet” or “Owner’s Manual Supplement/Sched- uled Maintenance Guide”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment...
Page 550 7-2. Maintenance Vehicle interior Items Check points • The accelerator pedal should move smoothly Accelerator pedal (without uneven pedal effort or catching). Automatic transmission • When parked on a slope and the shift lever is “Park” mechanism in P, is the vehicle securely stopped? •...
Page 551 7-2. Maintenance Vehicle exterior Items Check points Doors • Do the doors operate smoothly? • Does the engine hood lock system work prop- Engine hood erly? • There should not be any signs of fluid leakage Fluid leaks after the vehicle has been parked. •...
Page 552: Emission Inspection And Maintenance (I/M) Programs
The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. Your vehicle may not pass the I/M test in the following situations: ●...
Page 553: Do-It-Yourself Maintenance
• Rag or paper towel (→P. 564) • Funnel (used only for adding brake fluid) • “Toyota Super Long Life Coolant” or a similar high quality ethylene glycol-based non-silicate, non- amine, non-nitrite and non-borate coolant with long- life hybrid organic acid technology For the U.S.A.:...
Page 554 7-3. Do-it-yourself maintenance WARNING The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury, observe the following precautions. ■ When working on the engine compartment ● Keep hands, clothing and tools away from the moving fan and engine drive belt.
Page 555: Hood
7-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release lever. The hood will pop up slightly. Push the auxiliary catch lever to the left and lift the hood. Hold the hood open by inserting the supporting rod into the slot.
Page 556 7-3. Do-it-yourself maintenance WARNING ■ Pre-driving check Check that the hood is fully closed and locked. If the hood is not locked properly, it may open while the vehicle is in motion and cause an accident, which may result in death or serious injury. ■...
Page 557: Positioning A Floor Jack
7-3. Do-it-yourself maintenance Positioning a floor jack When using a floor jack, follow the instructions in the manual provided with the jack and perform the operation safely. When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement may damage your vehicle or cause injury.
Page 558: Engine Compartment
7-3. Do-it-yourself maintenance Engine compartment Fuse box (→P. 592) Radiator (→P. 564) Engine coolant reservoir Condenser (→P. 564) (→P. 562) Electric cooling fans Engine oil filler cap (→P. 560) Engine oil level dipstick Battery (→P. 565) (→P. 559) Brake fluid reservoir Washer fluid tank (→P.
Page 559 7-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. ■ Checking the engine oil Park the vehicle on level ground. After warming up the engine and turning it off, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
Page 560 7-3. Do-it-yourself maintenance Holding a rag under the end, pull the dipstick out and check the oil level. Normal Excessive  Flat dipstick  Non-flat dipstick Measuring side The shape of the dipstick may differ depending on the type of vehicle or engine.
Page 561 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal. ●...
Page 562 If the coolant level drops within a short time of replenishing Visually check the radiator, hoses, engine coolant reservoir cap, drain cock and water pump. If you cannot find a leak, have your Toyota dealer test the cap and check for leaks in the cooling system. RAV4_OM_OM0R012U_(U)
Page 563 7-3. Do-it-yourself maintenance WARNING ■ When the engine is hot Do not remove the engine coolant reservoir cap. The cooling system may be under pressure and may spray hot coolant if the cap is removed, causing serious injuries, such as burns. NOTICE ■...
Page 564 Radiator and condenser Check the radiator and condenser and clear away any foreign objects. If either of the above parts is extremely dirty or you are not sure of their condition, have your vehicle inspected by your Toyota dealer. WARNING ■...
Page 565 7-3. Do-it-yourself maintenance ■ Brake fluid can absorb moisture from the air Excess moisture in the brake fluid can cause a dangerous loss of braking effi- ciency. Use only newly opened brake fluid. WARNING ■ When filling the reservoir Take care as brake fluid can harm your hands and eyes and damage painted surfaces.
Page 566 Make sure to turn off the engine before disconnect the battery. Take extra care when connecting the battery if the engine switch mode prior to discharge is unknown. If the engine will not start even after multiple attempts, contact your Toyota dealer. RAV4_OM_OM0R012U_(U)
Page 567 7-3. Do-it-yourself maintenance WARNING ■ Chemicals in the battery A battery contains poisonous and corrosive sulfuric acid and may produce hydrogen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near the battery: ●...
Page 568 7-3. Do-it-yourself maintenance NOTICE ■ When recharging the battery Never recharge the battery while the engine is running. Also, be sure all accessories are turned off. Washer fluid If any washer does not work or the warning message appears on the multi-information display, washer tank may be empty.
Page 569: Tires
7-3. Do-it-yourself maintenance Tires Replace or rotate tires in accordance with maintenance sched- ules and treadwear. Checking tires Check if the treadwear indicators are showing on the tires. Also check the tires for uneven wear, such as excessive wear on one side of the tread.
Page 570 Front Front Do not fail to initialize the tire pressure warning system after tire rota- tion. To equalize tire wear and extend tire life, Toyota recommends that tire rotation is carried out at the same interval as tire inspection. RAV4_OM_OM0R012U_(U)
Page 571 ID codes must be registered in the tire pressure warning computer and the tire pressure warning system must be initialized. Have tire pressure warning valve and transmitter ID codes registered by your Toyota dealer. (→P. 573) ◆ Initializing the tire pressure warning system When the tire size is changed, the tire pressure warning system must be initialized.
Page 572 7-3. Do-it-yourself maintenance ■ How to initialize the tire pressure warning system Park the vehicle in a safe place and turn the engine switch to the “LOCK” position (vehicles without smart key system) or off (vehi- cles with smart key system). Initialization cannot be performed while the vehicle is moving.
Page 573 A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. ■ Replacing tires and wheels (vehicles with the tire pressure warning...
Page 574 7-3. Do-it-yourself maintenance ■ Maximum load of tire Check that the number given by dividing the maximum load by 1.10 of the replacement tire is greater than 1/2 of the Gross Axle Weight Ratings (GAWR) of either the front axle or the rear axle, whichever is greater. For the GAWR, see the Certification Label.
Page 575 ● In the following cases, the tire pressure warning system may not operate properly. • If non-genuine Toyota wheels are used. • A tire has been replaced with a tire that is not an OE (Original Equip- ment) tire. • A tire has been replaced with a tire that is not of the specified size.
Page 576 If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by your Toyota dealer. ● When operating the tire pressure warning reset switch, the tire pressure warning light does not blink 3 times.
Page 577 7-3. Do-it-yourself maintenance ■ Tire pressure warning system certification  For vehicles sold in the U.S.A. <Sensor, Receiver> TRW Automotive Tire Pressure Monitoring Sensor FCC ID: GQ4-51T This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation of this device.
Page 578 7-3. Do-it-yourself maintenance  For vehicles sold in Canada <Sensor, Receiver> TRW Automotive Tire Pressure Monitoring Sensor Model: 228408 IC: 1470A-32T MADE IN U.S.A This device complies with Industry Canada license-exempt RSS stan- dard(s). Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation of this device.
Page 579 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 580 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when repairing or replacing the tire.
Page 581: Tire Inflation Pressure
7-3. Do-it-yourself maintenance Tire inflation pressure Tire inflation pressure The recommended cold tire infla- tion pressure and tire size are dis- played on the tire and loading information label. (→P. 679) RAV4_OM_OM0R012U_(U)
Page 582 Reduced fuel economy ● Reduced driving comfort and poor handling ● Reduced tire life due to wear ● Reduced safety ● Damage to the drive train If a tire needs frequent inflating, have it checked by your Toyota dealer. RAV4_OM_OM0R012U_(U)
Page 583 7-3. Do-it-yourself maintenance ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ● Check only when the tires are cold. If your vehicle has been parked for at least 3 hours or has not been driven for more than 1 mile or 1.5 km, you will get an accurate cold tire inflation pressure reading.
Page 584: Wheels
● Used wheels ● Bent wheels that have been straightened Aluminum wheel precautions ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
Page 585 7-3. Do-it-yourself maintenance ■ When replacing wheels (vehicles with the tire pressure warning sys- tem) The wheels of your vehicle are equipped with tire pressure warning valves and transmitters that allow the tire pressure warning system to provide advance warning in the event of a loss in tire inflation pressure. Whenever wheels are replaced, tire pressure warning valves and trans- mitters must be installed.
Page 586 Because tire repair or replacement may affect the tire pressure warn- ing valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.
Page 587: Air Conditioning Filter
7-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. Removal method Vehicles without smart key system: Turn the engine switch to the “LOCK” position. Vehicles with smart key system: Turn the engine switch off. Open the glove box.
Page 588 7-3. Do-it-yourself maintenance Remove the air conditioning fil- ter and replace it with a new one. The “↑UP” marks shown on the fil- ter should be pointing up. ■ Changing interval Inspect and replace the air conditioning filter according to the maintenance schedule.
Page 589: Wireless Remote Control/Electronic Key Battery
7-3. Do-it-yourself maintenance Wireless remote control/electronic key battery Replace the battery with a new one if it is depleted. You will need the following items: ● Flathead screwdriver ● Small flathead screwdriver ● Lithium battery CR2016 (vehicles without smart key system), or CR2032 (vehicles with smart key system) Replacing the battery ...
Page 590 7-3. Do-it-yourself maintenance  Vehicles with smart key system Take out the mechanical key. Remove the cover. To prevent damage to the key, cover the tip of the screwdriver with a rag. Remove the depleted battery. Insert a new battery with the “+” terminal facing up.
Page 591 Use a CR2016 (vehicles without smart key system), or CR2032 (vehicles with smart key system) lithium battery ● Batteries can be purchased at your Toyota dealer, local electrical appliance shops or camera stores. ● Replace only with the same or equivalent type recommended by the manu- facturer.
Page 592: Checking And Replacing Fuses
7-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as nec- essary. Vehicles without smart key system: Turn the engine switch to the “LOCK” position. Vehicles with smart key system: Turn the engine switch off.
Page 593 Type A and B: Replace the blown fuse with a new fuse of an appropriate amperage rat- ing. The amperage rating can be found on the fuse box lid. Type C and D: Contact your Toyota dealer.  Type A ...
Page 594 If the lights do not turn on even after the fuse has been replaced, a bulb may need replacement. (→P. 595) ● If the replaced fuse blows again, have the vehicle inspected by your Toyota dealer. ■ If there is an overload in a circuit The fuses are designed to blow, protecting the wiring harness from damage.
Page 595: Light Bulbs
Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer. Preparing for light bulb replacement Check the wattage of the light bulb to be replaced. (→P. 680) Bulb locations ■...
Page 596 7-3. Do-it-yourself maintenance ■ Rear Tail light (bulb type) Stop/tail light and rear side marker light (bulb type) Back-up light License plate lights Rear turn signal light Replacing light bulbs ■ Headlights/daytime running lights (halogen headlights) Turn the bulb base counter- clockwise.
Page 597 7-3. Do-it-yourself maintenance Replace the light bulb. Align the 3 tabs on the light bulb with the mounting, and insert. Turn and secure the bulb base. Install the bulb base. Shake the bulb base gently to check that it is not loose, turn the headlights on once and visu- ally confirm that no light is leak- ing through the mounting.
Page 598 7-3. Do-it-yourself maintenance Remove the light bulb. When installing, reverse the steps listed. ■ Front side maker lights Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed. ■ Fog lights (if equipped) To allow enough working space, turn steering...
Page 599 7-3. Do-it-yourself maintenance Remove the screws from the fender liner. Remove the fender liner clip and open the fender liner. Unplug the connector while pressing the lock release. Turn the bulb base counter- clockwise. RAV4_OM_OM0R012U_(U)
Page 600 7-3. Do-it-yourself maintenance Set the new light bulb. Align the 3 tabs on the light bulb with the mounting, and insert. Turn it clockwise to set. Set the connector. After installing the connector, shake the bulb base gently to check that it is not loose, turn the fog lights on once and visu- ally confirm that no light is leak- ing through the mounting.
Page 601 7-3. Do-it-yourself maintenance ■ Stop/tail lights, rear side marker lights (bulb type) and rear turn signal lights Open the back door and remove bolts, remove the lamp assembly by pulling it directly backward from the rear of the vehicle. Turn the bulb base counterclockwise. Stop/tail lights and rear side Rear turn signal lights ...
Page 602 7-3. Do-it-yourself maintenance ■ Tail lights (bulb type) Open the back door and remove the cover. To prevent damage, cover the tip of the screwdriver with rag. Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed. RAV4_OM_OM0R012U_(U)
Page 603 7-3. Do-it-yourself maintenance ■ Back-up lights Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed. After installing the bulb base, make sure that the rubber cover is installed securely. Rubber cover RAV4_OM_OM0R012U_(U)
Page 604 7-3. Do-it-yourself maintenance ■ License plate lights Open the back door and remove the cover. To prevent damage, cover the tip of the screwdriver with rag. Turn the bulb base counterclockwise.  Left side  Right side Remove the light bulb. When installing, reverse the steps listed.
Page 605 Temporary condensation build-up on the inside of the headlight lens does not indicate a malfunction. Contact your Toyota dealer for more information in the following situations: ● Large drops of water have built up on the inside of the lens.
Page 606 7-3. Do-it-yourself maintenance WARNING ■ Replacing light bulbs ● Turn off the lights. Do not attempt to replace the bulb immediately after turning off the lights. The bulbs become very hot and may cause burns. ● Do not touch the glass portion of the light bulb with bare hands. When it is unavoidable to hold the glass portion, use and hold with a clean dry cloth to avoid getting moisture and oils on the bulb.
Page 607: When Trouble Arises
When trouble arises 8-1. Essential information Emergency flashers ..608 If your vehicle has to be stopped in an emergency ...... 609 8-2. Steps to take in an emergency If your vehicle needs to be towed ..... 611 If you think something is wrong ..
Page 608: Emergency Flashers
8-1. Essential information Emergency flashers The emergency flashers are used to warn other drivers when the vehicle has to be stopped in the road to a breakdown, etc. Press the switch. All the turn signals will flash. To turn them off, press the switch once again.
Page 609: If Your Vehicle Has To Be Stopped In An Emergency
8-1. Essential information If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the follow- ing procedure: Steadily step on the brake pedal with both feet and firmly depress it. Do not pump the brake pedal repeatedly as this will increase the effort required to slow the vehicle.
Page 610 8-1. Essential information WARNING ■ If the engine has to be turned off while driving ● Power assist for the brakes and steering wheel will be lost, making the brake pedal harder to depress and the steering wheel heavier to turn. Decelerate as much as possible before turning off the engine.
Page 611: Steps To Take In An
If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or commercial towing service, using a wheel-lift type truck or flatbed truck. Use a safety chain system for all towing, and abide by all state/ provincial and local laws.
Page 612 8-2. Steps to take in an emergency Towing with a wheel-lift type truck  From the front (2WD models)  From the front (AWD models) Release the parking brake. Use a towing dolly under the rear wheels.  From the rear Use a towing dolly under the front wheels.
Page 613 8-2. Steps to take in an emergency Emergency towing (vehicles with a towing eyelet) If a tow truck is not available in an emergency, your vehicle may be temporarily towed using cables or chains secured to the emergency towing eyelets. This should only be attempted on hard surfaced roads for at most 50 miles (80 km) at under 18 mph (30 km/h).
Page 614 8-2. Steps to take in an emergency Tighten down the towing eyelet securely using a wheel nut wrench or hard metal bar. Securely attach cables or chains to the towing eyelet. Take care not to damage the vehicle body. Enter the vehicle being towed and start the engine. If the engine does not start, turn the engine switch to the “ON”...
Page 615 8-2. Steps to take in an emergency WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When towing the vehicle 2WD models: Be sure to transport the vehicle with the front wheels raised or with all four wheels raised off the ground.
Page 616 8-2. Steps to take in an emergency NOTICE ■ To prevent damage to the vehicle when towing using a wheel-lift type truck ● Vehicles without smart key system: Do not tow the vehicle from the rear when the engine switch is in the “LOCK” position or the key is removed. The steering lock mechanism is not strong enough to hold the front wheels straight.
Page 617: If You Think Something Is Wrong
8-2. Steps to take in an emergency If you think something is wrong If you notice any of the following symptoms, your vehicle proba- bly needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms ● Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)
Page 618: Fuel Pump Shut Off System
8-2. Steps to take in an emergency Fuel pump shut off system To minimize the risk of fuel leakage when the engine stalls or when an airbag inflates upon collision, the fuel pump shut off system stops the supply of fuel to the engine. Follow the procedure below to restart the engine after the system is activated.
Page 619: If A Warning Light Turns On Or A Warning Buzzer Sounds
If the light turns off after the parking brake is fully released the system is operating normally. → Immediately stop the vehicle in a safe place and con- (Canada) tact your Toyota dealer. Continuing to drive the vehi- cle may be dangerous. Malfunction indicator lamp Indicates a malfunction in: •...
Page 620 Electric power steering system warning light (warning buzzer) Indicates a malfunction in the EPS (Electric Power Steer- ing) system → Have the vehicle inspected by your Toyota dealer immediately. Slip indicator Indicates a malfunction in: • The VSC/Trailer Sway Control system;...
Page 621 Toyota dealer. When the light comes on after blinking for 1 minute: Malfunction in the tire pressure warning system → Have the system checked by your Toyota dealer. RAV4_OM_OM0R012U_(U)
Page 622 8-2. Steps to take in an emergency : Parking brake engaged warning buzzer: A buzzer will sound if the vehicle is driven at a speed of approximately 3 mph (5 km/h) or more. : Driver’s seat belt warning buzzer: The driver’s seat belt warning buzzer sounds to alert the driver that his or her seat belt is not fastened.
Page 623 Is the fuel tank cap loose? If it is, tighten it securely. The light will go off after several driving trips. If the light does not go off even after several trips, contact your Toyota dealer as soon as possible. RAV4_OM_OM0R012U_(U)
Page 624 8-2. Steps to take in an emergency ■ Electric power steering system warning light (warning buzzer) When the battery charge becomes insufficient or the voltage temporarily drops, the electric power steering system warning light may come on and the warning buzzer may sound. ■...
Page 625 If there is a lot of snow or ice on the vehicle, particularly around the wheels or wheel housings ● If non-genuine Toyota wheels are used (Even if you use Toyota wheels, the tire pressure warning system may not work properly with some types of tires.) ●...
Page 626 ■ If both the ABS and the brake system warning lights remain on Stop your vehicle in a safe place immediately and contact your Toyota dealer. The vehicle will become extremely unstable during braking, and the ABS system may fail, which could cause an accident resulting in death or serious injury.
Page 627 8-2. Steps to take in an emergency WARNING ■ Maintenance of the tires (vehicles with the tire pressure warning system) Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label (tire and load information label).
Page 628 8-2. Steps to take in an emergency NOTICE ■ To ensure the tire pressure warning system operates properly (vehicles with the tire pressure warning system) Do not install tires with different specifications or makers, as the tire pressure warning system may not operate properly. RAV4_OM_OM0R012U_(U)
Page 629: If A Warning Message Is Displayed
Multi-information display If any of the warning messages comes on again after the following actions have been performed, contact your Toyota dealer. RAV4_OM_OM0R012U_(U)
Page 630 (Amber) (Flashes) (If equipped) Indicates a malfunction in the brake system A buzzer also sounds. → Have the vehicle inspected by your Toyota dealer immediately. Continuing to drive the vehicle may be dan- gerous. (U.S.A.) (Canada)
Page 631 Indicates a malfunction in the intuitive parking assist All the sensor lights flash. A buzzer also sounds. → Have the vehicle inspected by your Toyota dealer. (If equipped) Indicates that an intuitive parking assist sensor is dirty or covered with ice All the sensor lights flash.
Page 632 • The front passenger occupant classification system; or, • The seat belt pretensioner system A buzzer also sounds. → Have the vehicle inspected by your Toyota dealer. Indicates a malfunction in: • The ABS; or • The brake assist system A buzzer also sounds.
Page 633 Indicates a malfunction in the vehicle’s charging system. → Immediately stop the vehicle in a safe place and contact your Toyota dealer. Continuing to drive the vehicle may be dangerous. Indicates that the radar sensor is dirty or covered with ice A buzzer also sounds.
Page 634 Warning message Details/Actions Indicates a malfunction in the smart key system A buzzer also sounds. → Have the vehicle inspected by your Toyota dealer. (If equipped) Indicates that a Blind Spot Monitor sensor or the surrounding area on the bumper is dirty or cov- ered with ice A buzzer also sounds.
Page 635 (Amber) vehicle for a short time, and then turn the (If equipped) LDA system back on. Indicates a malfunction in the pre-collision sys- A buzzer also sounds. → Have the vehicle inspected by your Toyota dealer. (Flashes) (If equipped) RAV4_OM_OM0R012U_(U)
Page 636 Warning message Details/Actions Indicates a malfunction in the BSM (Blind Spot Monitor) system A buzzer also sounds. → Have the vehicle inspected by your Toyota dealer. (If equipped) Indicates abnormal engine oil pressure A buzzer also sounds. → Immediately stop the vehicle in a safe place and contact your Toyota dealer.
Page 637 8-2. Steps to take in an emergency Warning message Details/Actions Indicates that the LDA (Lane Departure Alert with steering control) system cannot be used as the vehicle speed is approximately 32 mph (50 km/h) or less → Drive the vehicle at approximately 32 mph (50 km/h) or more.
Page 638 • The LED headlight system (if equipped) A buzzer also sounds. → Have the vehicle inspected by your Toyota dealer. Indicates that the washer fluid level is low → Add washer fluid. Indicates that remaining fuel is approximately 2.4 gal.
Page 639 → Please wait until the system returns. If the message does not disappear, the system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immedi- (Flashes) ately. (If equipped) Indicates that part of the PCS (Pre-Collision Sys- tem) sensor is dirty, covered with ice, etc.
Page 640 8-2. Steps to take in an emergency Interior Exterior Warning message Details/Actions buzzer buzzer electronic detected when an attempt is ⎯ Once made to start the engine. → Start the engine with the electronic key present. (Flashes) The electronic key was carried outside the vehicle and a door other than the driver’s door was opened and closed while the...
Page 641 8-2. Steps to take in an emergency Interior Exterior Warning message Details/Actions buzzer buzzer An attempt was made to drive when the regular key was not inside the vehicle. ⎯ → Confirm times that elec- tronic key is inside the vehicle.
Page 642 8-2. Steps to take in an emergency Interior Exterior Warning message Details/Actions buzzer buzzer An attempt was made to lock Contin- the doors using the smart key uous system while the electronic key Once was still inside the vehicle. → Retrieve the electronic key sec- onds) from the vehicle and lock...
Page 643 8-2. Steps to take in an emergency Interior Exterior Warning message Details/Actions buzzer buzzer An attempt was made to start the engine with the shift lever in ⎯ Once an incorrect position. → Shift the shift lever to P and start the engine. (Flashes) Power was turned off due to the automatic power off function.
Page 644 8-2. Steps to take in an emergency Interior Exterior Warning message Details/Actions buzzer buzzer The steering lock could not be released within 3 seconds of engine switch being pressed. ⎯ → Press the engine switch Once while depressing the brake pedal moving (Flashes)
Page 645: If You Have A Flat Tire
8-2. Steps to take in an emergency If you have a flat tire Your vehicle is equipped with a spare tire. The flat tire can be replaced with the spare tire. For details about tires: →P. 569 WARNING ■ If you have a flat tire Do not continue driving with a flat tire.
Page 646 8-2. Steps to take in an emergency Location of the spare tire, jack and tools Tool bag Spare tire Jack : It may be placed together with the jack. RAV4_OM_OM0R012U_(U)
Page 647 8-2. Steps to take in an emergency WARNING ■ Using the tire jack Observe the following precautions. Improper use of the tire jack may cause the vehicle to suddenly fall off the jack, leading to death or serious injury. ● Do not use the tire jack for any purpose other than replacing tires or installing and removing tire chains.
Page 648 8-2. Steps to take in an emergency Taking out the jack Vehicles with full-size spare tire: Turn the knob of each clip on the rear deck board to unlock. Remove the rear deck board. Take out the jack. Unclasp the hook and remove the jack.
Page 649 8-2. Steps to take in an emergency Taking out the spare tire Loosen the center fastener that secures the spare tire. WARNING ■ When storing the spare tire Be careful not to catch fingers or other body parts between the spare tire and the body of the vehicle.
Page 650 8-2. Steps to take in an emergency For vehicles with steel wheels, remove the wheel ornament using the wrench. To protect the wheel ornament, place a rag between the wrench and the wheel ornament. Slightly loosen the wheel nuts (one turn). Turn the tire jack portion hand until the notch of the jack is in contact with the jack point.
Page 651 8-2. Steps to take in an emergency Assemble the jack handle and the wheel nut wrench as shown in the illustration. Raise the vehicle until the tire is slightly raised off the ground. Remove all the wheel nuts and the tire. When resting the tire on the ground, place the tire so that the wheel design faces up to avoid...
Page 652 • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Toyota dealer. • When installing the wheel nuts, be sure to install them with the tapered ends facing inward.
Page 653 8-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign mat- ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, causing the tire to come off.
Page 654 8-2. Steps to take in an emergency Lower the vehicle. Firmly tighten each wheel nut two or three times in the order shown in the illustration. Tightening torque: 76 ft•lbf (103 N•m, 10.5 kgf•m) For vehicles with steel wheels, reinstall the wheel ornament Align the cutout of the wheel orna- ment with the valve stem as shown.
Page 655 8-2. Steps to take in an emergency ■ The compact spare tire (if equipped) ● The compact spare tire is identified by the label “TEMPORARY USE ONLY” on the tire sidewall. Use the compact spare tire temporarily, and only in an emergency. ●...
Page 656 • ABS & Brake assist • Rear view monitor system (if • VSC/Trailer Sway Control equipped) • TRAC • Toyota parking assist monitor (if • Cruise control (if equipped) equipped) • Dynamic radar cruise control (if • Panoramic view monitor (if...
Page 657 When replacing the tires (vehicles with the tire pressure warning system) When removing or fitting the wheels, tires or the tire pressure warning valve and transmitter, contact your Toyota dealer as the tire pressure warning valve and transmitter may be damaged if not handled correctly. RAV4_OM_OM0R012U_(U)
Page 658: If The Engine Will Not Start
8-2. Steps to take in an emergency If the engine will not start If the engine will not start even though correct starting proce- dures are being followed (→P. 198, 200), consider each of the fol- lowing points: The engine will not start even though the starter motor operates normally.
Page 659 ● There may be a malfunction in the steering lock system (vehicles with smart key system). Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function (vehicles with smart key system)
Page 660: If The Electronic Key Does Not Operate Properly (Vehicles With Smart Key System)
8-2. Steps to take in an emergency If the electronic key does not operate properly (vehicles with smart key system) If communication between the electronic key and vehicle is interrupted (→P. 132) or the electronic key cannot be used because the battery is depleted, the smart key system and wire- less remote control cannot be used.
Page 661 Firmly depress the brake pedal and check that is displayed on the multi-information display. Press the engine switch. In the event that the engine still cannot be started, contact your Toyota dealer. ■ Stopping the engine Shift the shift lever to P and press the engine switch as you normally do when stopping the engine.
Page 662: If The Vehicle Battery Is Discharged
The following procedures may be used to start the engine if the vehicle’s battery is discharged. You can also call your Toyota dealer or a qualified repair shop. If you have a set of jumper (or booster) cables and a second vehicle with a 12-volt battery, you can jump start your vehicle by following the steps below.
Page 663 ON mode. Once the vehicle’s engine has started, remove the jumper cables in the exact reverse order from which they were connected. Once the engine starts, have the vehicle inspected at your Toyota dealer as soon as possible. ■ Starting the engine when the battery is discharged The engine cannot be started by push-starting.
Page 664 ● The moon roof (if equipped) must be initialized. (→P. 162) ● Toyota parking assist monitor (if equipped) must be initialized. (Refer to “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”) ● Panoramic view monitor (if equipped) must be initialized. (Refer to “NAVI- GATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”)
Page 665 8-2. Steps to take in an emergency WARNING ■ Battery precautions The battery contains poisonous and corrosive acidic electrolyte, while related parts contain lead and lead compounds. Observe the following pre- cautions when handling the battery: ● When working with the battery, always wear safety glasses and take care not to allow any battery fluids (acid) to come into contact with skin, clothing or the vehicle body.
Page 666: If Your Vehicle Overheats
If you do not see steam: Carefully lift the hood. After the engine has cooled down sufficiently, inspect the hoses and radiator core (radiator) for any leaks. Radiator Cooling fans If a large amount of coolant leaks, immediately contact your Toyota dealer. RAV4_OM_OM0R012U_(U)
Page 667 (The fans may not operate in freezing temperatures.) If the fans are not operating: Stop the engine immediately and contact your Toyota dealer. If the fans are operating: Have the vehicle inspected at the nearest Toyota dealer.
Page 668 8-2. Steps to take in an emergency WARNING ■ When inspecting under the hood of your vehicle Observe the following precautions. Failure to do so may result in serious injury such as burns. ● If steam is seen coming from under the hood, do not open the hood until the steam has subsided.
Page 669: If The Vehicle Becomes Stuck
8-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt or snow: Stop the engine. Set the parking brake and shift the shift lever to P. Remove the mud, snow or sand from around the stuck tire.
Page 670 8-2. Steps to take in an emergency WARNING ■ When attempting to free a stuck vehicle If you choose to push the vehicle back and forth to free it, make sure the surrounding area is clear to avoid striking other vehicles, objects or people. The vehicle may also lunge forward or lunge back suddenly as it becomes free.
Page 671: Vehicle Specifications
Vehicle specifications 9-1. Specifications Maintenance data (fuel, oil level, etc.) ..672 Fuel information ....681 Tire information ....684 9-2. Customization Customizable features ..697 9-3. Initialization Items to initialize ....708 RAV4_OM_OM0R012U_(U)
Page 672: Specifications Maintenance Data
9-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weights Without front license 181.1 in. (4600 mm) plate garnish Overall length With front license 181.3 in. (4605 mm) plate garnish Overall width 72.6 in. (1845 mm) Without the roof 65.9 in.
Page 673 The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
Page 674 9-1. Specifications ■ Engine number The engine number is stamped on the engine block as shown. Engine Model 2.5 L 4-cylinder (2AR-FE) Type 4-cylinder in line, 4-cycle, gasoline 3.54 × 3.86 in. (90.0 × 98.0 mm) Bore and stroke Displacement 152.2 cu.in.
Page 675 ■ Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: ILSAC GF-5 multigrade engine oil...
Page 676 7.2 qt. (6.8 L, 6.0 Imp. qt.) Capacity With towing package: 7.0 qt. (6.6 L, 5.8 Imp. qt.) Use either of the following: • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based Coolant type non-silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technology Do not use plain water alone.
Page 677 Toyota Genuine Differential gear oil LT Oil type and viscosity 75W-85 GL-5 or equivalent Your Toyota vehicle is filled with “Toyota Genuine Differential Gear Oil” at the factory. Use Toyota approved “Toyota Genuine Differential Gear Oil” or an equivalent of matching quality to satisfy the above specification. Please contact your Toyota dealer for further details.
Page 678 Toyota Genuine Differential gear oil LT Oil type and viscosity 75W-85 GL-5 or equivalent Your Toyota vehicle is filled with “Toyota Genuine Differential Gear Oil” at the factory. Use Toyota approved “Toyota Genuine Differential Gear Oil” or an equivalent of matching quality to satisfy the above specification. Please contact your Toyota dealer for further details.
Page 679 9-1. Specifications Tires and wheels  Type A Tire size 225/65R17 102H, T165/80R17 104M (spare) Tire inflation pressure Front: 33 psi (230 kPa, 2.3 kgf/cm or bar) (Recommended cold Rear: 33 psi (230 kPa, 2.3 kgf/cm or bar) tire inflation pressure) Spare: 60 psi (420 kPa, 4.2 kgf/cm or bar) 17 ×...
Page 680 9-1. Specifications Light bulbs Light bulbs Bulb No. Type Headlights/daytime running 9012 lights (halogen headlights) ⎯ Fog lights Front turn signal lights/ parking lights (halogen head- 7444NA 28/8 lights) Front turn signal lights (LED 7444NA headlights) Exterior ⎯ Front side marker lights Stop/tail lights and rear side 7443 21/5...
Page 681: Fuel Information
In very few cases, driveability problems may be caused by the brand of gaso- line you are using. If driveability problems persist, try changing the brand of gasoline. If this does not correct the problem, consult your Toyota dealer. ■...
Page 682 Non-recommendation of the use of gasoline containing MMT Some gasoline contains an octane enhancing additive called MMT (Methylcy- clopentadienyl Manganese Tricarbonyl). Toyota does not recommend the use of gasoline that contains MMT. If fuel containing MMT is used, your emission control system may be adversely affected.
Page 683 9-1. Specifications NOTICE ■ Notice on fuel quality ● Do not use improper fuels. If improper fuels are used, the engine will be damaged. ● Do not use leaded gasoline. Leaded gasoline can cause damage to your vehicle’s three-way catalytic converters causing the emission control system to malfunction.
Page 684: Tire Information
9-1. Specifications Tire information Typical tire symbols  Full-size tire Compact spare tire  RAV4_OM_OM0R012U_(U)
Page 685 9-1. Specifications Tire size (→P. 687) DOT and Tire Identification Number (TIN) (→P. 686) Location of treadwear indicators (→P. 569) Tire ply composition and materials Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies in a tire. Radial tires or bias-ply tires A radial tire has “RADIAL”...
Page 686 9-1. Specifications Typical DOT and Tire Identification Number (TIN)  Type A  Type B DOT symbol Tire Identification Number (TIN) Tire manufacturer’s identification mark Tire size code Manufacturer’s optional tire type code (3 or 4 letters) Manufacturing week Manufacturing year Manufacturer’s code : The DOT symbol certifies that the tire conforms to applicable Federal Motor Vehicle Safety Standards.
Page 687 9-1. Specifications Tire size ■ Typical tire size information The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 digits or 3 digits) Speed symbol (alphabet with one letter)
Page 688 9-1. Specifications Tire section names Bead Sidewall Shoulder Tread Belt Inner liner Reinforcing rubber Carcass Rim lines Bead wires Chafer RAV4_OM_OM0R012U_(U)
Page 689 U.S. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. ■ DOT quality grades All passenger vehicle tires must conform to Federal Safety Require- ments in addition to these grades.
Page 690 9-1. Specifications ■ Temperature A, B, C The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissi- pate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 691 9-1. Specifications Glossary of tire terminology Tire related term Meaning Tire pressure when the vehicle has been Cold tire inflation pres- parked for three hours or more, or has not sure been driven more than 1 mile or 1.5 km under that condition The maximum cold inflated pressure to which Maximum...
Page 692 9-1. Specifications Tire related term Meaning The combined weight of installed regular pro- duction options weighing over 5 lb. (2.3 kg) in excess of the standard items which they Production options replace, not previously considered in curb weight weight or accessory weight, including heavy duty brakes, ride levelers, roof rack, heavy duty battery, and special trim A metal support for a tire or a tire and tube...
Page 693 9-1. Specifications Tire related term Meaning A pneumatic tire in which the ply cords that extend to the beads are laid at alternate Bias ply tire angles substantially less than 90 degrees to the centerline of the tread The tire structure, except tread and sidewall Carcass rubber which, when inflated, bears the load The breaking away of pieces of the tread or...
Page 694 9-1. Specifications Tire related term Meaning A tire designated by its manufacturer as pri- Light truck (LT) tire marily intended for use on lightweight trucks or multipurpose passenger vehicles The maximum load that a tire is rated to carry Load rating for a given inflation pressure The load rating for a tire at the maximum per- Maximum load rating...
Page 695 9-1. Specifications Tire related term Meaning The linear distance between the exteriors of the sidewalls of an inflated tire, excluding ele- Section width vations due to labeling, decoration, or protec- tive bands That portion of a tire between the tread and Sidewall bead The parting of the rubber compound from the...
Page 696 9-1. Specifications Designated seating Occupant distribution Vehicle normal load, capacity, Number of in a normally loaded Number of occupants occupants vehicle 2 through 4 2 in front 2 in front, 1 in second 5 through 10 seat 2 in front, 1 in second 11 through 15 seat, 1 in third seat, 1 in fourth seat...
Page 697: Customization
Premium Audio with Navigation or Entune Audio, or at your Toyota dealer. Some function settings are changed simultaneously with other func- tions being customized. Contact your Toyota dealer for further details. Customizing vehicle features When customizing vehicle features, ensure that the vehicle is parked in a safe place with the shift lever in P and the parking brake set.
Page 698 Entune Premium Audio with Navigation or Entune Audio Plus or Entune Audio Settings that can be changed using the multi-information display Settings that can be changed by your Toyota dealer Definition of symbols: O = Available, — = Not available ■...
Page 699 9-2. Customization ■ LDA (Lane Departure Alert with steering control) (→P. 256) Customized Function Default setting setting Steering Assist — O — Alert sensitivity Standard High — O — Vehicle sway warning — O — Vehicle sway warning sensitiv- Standard —...
Page 700 9-2. Customization ■ Door lock (→P. 107, 660) Customized Function Default setting setting Driver’s door unlocked in All doors one step, all Unlocking using a key unlocked in — — O doors one step unlocked in two steps Speed linked door locking function (vehicles with smart O —...
Page 701 9-2. Customization ■ Power back door (→P. 113) Customized Function Default setting setting 1, 2 Touchless Sensor — O O 1 to 4 Opening angle — O — User setting Operation buzzer volume — O — All on When the All off back door When the...
Page 702 9-2. Customization ■ Smart key system (→P. 130) and wireless remote control (→P. 99, 107, 113) Customized Function Default setting setting Operation signal Level 7 O — O (Buzzers) Level 1 to 6 Operation signal O — O (Emergency flashers) Time elapsed before the auto- matic door lock function is 60 seconds...
Page 703 9-2. Customization ■ Smart key system (→P. 107, 113, 130) Customized Function Default setting setting Smart key system — — O Select doors to unlock Driver’s door All the doors O — O Number of consecutive door As many as 2 times —...
Page 704 9-2. Customization → ■ Intuitive parking assist P. 280) Customized Function Default setting setting Detection distance of the front Near O — O center sensor Detection distance of the rear Near O — O center sensor Buzzer volume Level 3 Level 1 to 5 O —...
Page 705 9-2. Customization ■ Turn signal lever (→P. 213) Customized Function Default setting setting Time of flashing of the lane — — O change signal flashers ■ Automatic air conditioning system (→P. 494) Customized Function Default setting setting A/C Auto switch operation O —...
Page 706 9-2. Customization ■ Illumination (→P. 505) Customized Function Default setting setting Interior lights illumination con- — — O trol Time elapsed before the inte- 15 seconds — O seconds rior lights turn off seconds Operation after the engine switch is turned to the “LOCK” position (vehicles without...
Page 707 9-2. Customization WARNING ■ During customization As the engine needs to be running during customization, ensure that the vehicle is parked in a place with adequate ventilation. In a closed area such as a garage, exhaust gases including harmful carbon monoxide (CO) may collect and enter the vehicle.
Page 708: 9-3. Initialization
(U.S.A. only) Tire pressure warning • When changing the P. 572 system (If equipped) tire size Toyota parking assist monitor (if equipped) Refer to “NAVIGATION • After reconnecting or AND MULTIMEDIA changing the battery SYSTEM OWNER’S • After changing a fuse MANUAL”...
Page 709: For Owners
For owners Reporting safety defects for U.S. owners......710 Seat belt instructions for Canadian owners (in French) ....... 711 SRS airbag instructions for Canadian owners (in French) ....... 713 RAV4_OM_OM0R012U_(U)
Page 710: Reporting Safety Defects For U.s. Owners
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800-331-4331). If NHTSA receives similar complaints, it may open an investiga- tion, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 711: Seat Belt Instructions For Canadian Owners (In French)
Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English. Utilisation adéquate des ceintures de sécurité...
Page 712 Entretien et soin ■ Ceintures de sécurité Avec un chiffon ou une éponge, nettoyez à l’aide d’un savon doux et de l’eau tiède. Vérifiez aussi les ceintures régulièrement pour vous assurer qu’elles ne présentent pas d’usure excessive, d’effilo- chage ou de coupures. AVERTISSEMENT ■...
Page 713: Srs Airbag Instructions For Canadian Owners (In French)
SRS airbag instructions for Canadian own- ers (in French) The following is a French explanation of SRS airbag instructions extracted from the SRS airbag section in this manual. See the SRS airbag section for more detailed SRS airbag instruc- tions in English. RAV4_OM_OM0R012U_(U)
Page 714 ◆ Coussins gonflables SRS avant Coussin gonflable SRS du conducteur/coussin gonflable SRS du passager avant Peuvent aider à protéger la tête et la poitrine du conducteur et du passager avant contre les impacts avec des composants inté- rieurs Coussin gonflable SRS de protection des genoux du conducteur Peut aider à...
Page 715 Composants du système de coussins gonflables SRS Capteurs d’impact latéral (por- Capteurs d’impact latéral tières avant) (arrière) Coussin gonflable du passa- Limiteurs de force et disposi- ger avant tifs de tension des ceintures de sécurité Coussins gonflables en rideau Capteur de position du siège Coussin gonflable du coussin du conducteur de siège du passager avant...
Page 716 Votre véhicule est doté de COUSSINS GONFLABLES ÉVOLUÉS dont la conception s’appuie sur les normes de sécurité des véhicules à moteur américains (FMVSS208). Le module de capteur de coussin gonflable (ECU) contrôle le déploiement des coussins gonflables en fonction des informations obtenues des capteurs et d’autres éléments affichés dans le diagramme des composants du système ci-dessus.
Page 717 AVERTISSEMENT ■ Précautions relatives aux coussins gonflables SRS Observez les précautions suivantes en ce qui concerne les coussins gon- flables SRS. Les négliger pourrait occasionner des blessures graves, voire mortelles. ● Le conducteur et tous les passagers du véhicule doivent porter leur cein- ture de sécurité...
Page 718 Un bébé ou un enfant trop petit pour utiliser une ceinture de sécurité doit être correctement retenu à l’aide d’un dispositif de retenue pour enfants. Toyota recommande vivement de placer et d’attacher correcte- ment tous les bébés et tous les enfants sur les sièges arrière du véhicule à...
Page 719 AVERTISSEMENT ■ Précautions relatives aux coussins gonflables SRS ● N’installez jamais un dispositif de retenue pour enfants de type dos à la route sur le siège du passager avant, même si le voyant “AIR BAG OFF” est allumé. En cas d’accident, la force et la vitesse de déploiement du coussin gon- flable du passager avant pourraient infliger à...
Page 720 AVERTISSEMENT ■ Précautions relatives aux coussins gonflables SRS ● Ne laissez personne s’agenouiller face à la portière sur le siège du passager ni sortir la tête ou les mains à l’extérieur du véhicule. ● Ne fixez rien et n’appuyez rien sur des zones telles que la planche de bord, le tampon de volant et la partie inférieure du tableau de bord.
Page 721 Si les emplacements de stockage des coussins gonflables SRS, tels que le tampon de volant et les garnitures des montants avant et arrière, sont endommagés ou fissurés, faites-les remplacer par votre concessionnaire Toyota. ● Ne placez aucun objet, par exemple un coussin, sur le siège du passager avant.
Page 722 SRS Ne mettez pas votre véhicule au rebut et n’effectuez aucune des modifica- tions suivantes sans d’abord consulter votre concessionnaire Toyota. Les coussins gonflables SRS pourraient fonctionner de manière incorrecte ou se déployer (gonfler) accidentellement, ce qui serait susceptible d’occasion- ner des blessures graves, voire mortelles.
Page 723: Index
Entune Audio Plus, refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL” for information regarding the equipment listed below. • Navigation system • Audio system • Rear view monitor system • Toyota parking assist monitor • Panoramic view monitor RAV4_OM_OM0R012U_(U)
Page 724 You lose your keys ● If you lose your keys or mechanical keys, new genuine keys or mechanical keys can be made by your Toyota dealer. (→P. 100) ● Vehicles with smart key system If you lose your electronic keys, the risk of vehicle theft increases signifi- cantly.
Page 725 What to do if... (Troubleshooting) If you think something is wrong The engine does not start (vehicles without smart key system) ● Is the shift lever in P? (→P. 198) ● Is the battery discharged? (→P. 662) The engine does not start (vehicles with smart key system) ●...
Page 726 What to do if... (Troubleshooting) The windows do not open or close by operating the power window switches ● Is the window lock switch pressed? The power window except for the one at the driver’s seat cannot be oper- ated if the window lock switch is pressed. (→P. 156) The engine switch is turned off automatically (vehicles with smart key system) ●...
Page 727 What to do if... (Troubleshooting) When a problem has occurred If you have a flat tire ● Stop the vehicle in a safe place and replace the flat tire with the spare tire. (→P. 645) The vehicle becomes stuck ● Try the procedure for when the vehicle becomes stuck in mud, dirt, or snow.
Page 728: Alphabetical Index
Alphabetical index Alphabetical index Side and curtain shield airbags precautions....41 A/C ........488, 494 SRS airbag instructions for Air conditioning filter ..... 587 Canadian owners ....713 Automatic air conditioning SRS airbags ......36 system ........ 494 All-wheel drive lock switch..299 Manual air conditioning Anchor brackets ......
Page 729 Alphabetical index ® Automatic High Beam ..... 220 Bluetooth phone Automatic light control (audio system)....... 363 system........218 Deleting the call history ..377 Automatic transmission..205 Making a call......383 If the shift lever cannot be Managing speed dials... 376 shifted from P .....
Page 730 Alphabetical index Cargo capacity......672 Child-protectors ...... 110 Cargo hooks......512 Cleaning ......540, 543 Catch protection function..157 Aluminum wheels ....541 CD player......340, 413 Exterior ......... 540 Chains........317 Interior ........543 Child restraint system....57 Radar sensor ....237, 303 Booster seats, definition ..
Page 731 Alphabetical index Display Dynamic radar cruise Dynamic radar cruise control........264 control......... 264 Function........ 264 Fuel consumption Warning message....630 information......94 Intuitive parking assist ..281 LDA (Lane Departure Alert Eco drive mode......207 with steering control) ..260 EDR (Event data recorder)..
Page 732 Alphabetical index Emergency flashers ....608 Entune Audio ......394 Engine AUX Port/USB port ....397 “ACC” position ...... 198 Basic Audio Operations ..398 Accessory mode ....201 CD player......413 Compartment ......558 iPod ........420 ® Engine switch....198, 200 Listening to Bluetooth Hood ........
Page 733 Alphabetical index Front seats ....... 139 Adjustment......139 Hands-free system Cleaning........ 543 (for cellular phone) ..383, 445 Correct driving posture ... 26 ® HD Radio system Driving position memory ..144 Head restraints ......146 Head restraints ..... 146 Headlights ........
Page 734 Alphabetical index I/M test ........552 Keyless entry ..... 99, 130 Identification ......673 Smart key system ....130 Engine........674 Wireless remote control..99 Vehicle ........673 Keys..........98 Ignition switch Battery-saving function ..131 (engine switch) ....198, 200 Electronic key ......
Page 735 Alphabetical index Light Mirrors Automatic High Beam Inside rear view mirror ..151 system ........ 220 Outside rear view mirror Engine switch light defoggers ....490, 497 (ignition switch light) ... 505 Outside rear view mirrors ..153 Fog light switch ..... 224 Vanity mirrors .......
Page 736 Alphabetical index Paddle shift switches ..208, 209 Radar cruise control Panoramic view monitor (dynamic radar cruise Parking assist sensors control)........264 (intuitive parking assist)..280 Radiator........564 Parking brake......214 Radio ........ 338, 411 Operation ......214 Radio Broadcast Data Parking brake engaged System (RBDS) warning buzzer ....
Page 737 Alphabetical index Resetting the maintenance Seats......... 139, 141 required reminder Adjustment....139, 141 message......... 547 Adjustment precautions....140, 143 Child seats/child restraint system installation....61 Seat belts........28 Cleaning ....... 543 Adjusting the seat belt .... 31 Driving position memory ..144 Automatic Locking Folding down the rear Retractor.......
Page 738 Alphabetical index Side mirrors ......153 Switch Adjusting and folding .... 153 All-wheel drive lock switch..299 Blind Spot Monitor ....300 Audio remote control Heaters ......490, 497 switches ..... 331, 396 Side turn signal lights ..... 213 Cruise control switch .... 276 Replacing light bulbs.....
Page 739 Tire information ....... 684 Trailer Sway Control ..... 311 Glossary........ 691 Trailer towing ......181 Size........687 Toyota Safety Sense P.... 235 Tire identification number ..686 TRAC (Traction Control) ..310 Uniform Tire Quality Trailer Sway Control ....311 Grading.......
Page 740 Alphabetical index Turn signal lights..... 213 Warning lights ......619 Replacing light ABS ........619 bulbs....597, 601, 605 Brake system......619 Turn signal lever ....213 Electric power steering ..620 Wattage ........ 680 Low fuel level......620 Malfunction indicator lamp..619 Pre-Collision System ....
Page 741 Alphabetical index Winter driving tips ....317 Wireless remote control key ..........99 Locking/Unlocking....99 Replacing the battery.... 589 WMA disc ......340, 413 ® Satellite Radio : Refer to “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”. RAV4_OM_OM0R012U_(U)
Page 742 Alphabetical index RAV4_OM_OM0R012U_(U)
Page 743 Alphabetical index RAV4_OM_OM0R012U_(U)
Page 744 (L, Imp.qt.) (Drain and refill — With filter 4.6 (4.4, 3.9) reference) Without filter 4.2 (4.0, 3.5) “Toyota Genuine Motor Oil” or equivalent Oil grade: ILSAC GF-5 multigrade engine oil Engine oil type Recommended viscosity: SAE 0W-20 P. 675 RAV4_OM_OM0R012U_(U)
