Toyota RAV4 2011 Manual

Introduction

This Quick Reference Guide is a summary of basic vehicle operations. It contains brief descriptions of fundamental operations so you can locate and use the vehicle's main equipment quickly and easily.
The Quick Reference Guide is not intended as a substitute for the Owner's Manual located in the vehicle's glove box. We strongly encourage you to review the Owner's Manual and supplementary manuals so you will have a better understanding of the vehicle's capabilities and limitations.
Your dealership and the entire staff of Toyota Motor Sales, U.S.A., Inc. wish you many years of satisfied driving in your new RAV4.

! A word about safe vehicle operations
This Quick Reference Guide is not a full description of RAV4 operations. Every RAV4 owner should review the Owner's Manual that accompanies this vehicle.
Pay special attention to the boxed information highlighted in color throughout the Owner's Manual. Each box contains safe operating instructions to help you avoid injury or equipment malfunction.
All information in this Quick Reference Guide is current at the time of printing. Toyota reserves the right to make changes at any time without notice.

OVERVIEW

Instrument panel
OVERVIEW - Part 1
OVERVIEW - Part 2

Steering wheel controls
Without telephone controls
OVERVIEW - Part 3

With telephone controls
OVERVIEW - Part 4

  1. Steering wheel audio controls1
  2. Telephone controls1
  3. Trip information display switch
  4. Speech command button1
  5. Cruise control
  6. Headlight, turn signal and fog light1 control
  7. Wiper and washer controls
  8. Four-wheel drive lock switch (4WD models)
  9. Audio system/Navigation system1,2
  10. Emergency flasher switch
  11. Air Conditioning controls
  12. "ENGINE START STOP" button (Smart Key)1
  13. Engine immobilizer indicator
  14. Front passenger seat belt reminder light
  15. Clock and Air Conditioning display
  16. Front passenger occupant classification indicator
  17. Rear window and outside rearview mirror defogger switch1
  18. 12V DC Power outlet
  19. Seat heater switch1
  20. VSC OFF switch
  21. Ignition switch (standard key)1
  22. Tilt and telescopic steering release
  23. Downhill Assist Control (DAC) switch1
  24. Instrument panel light control

1 If equipped
2 Vehicles with navigation system: for details, refer to the "Navigation System Owner's Manual."

Instrument cluster
Instrument cluster

  1. Tachometer
  2. Service indicator and reminder
  3. Speedometer
  4. Engine coolant temperature
  5. Fuel gauge
  6. Odometer, two trip meters and trip information display
  7. Automatic Transmission shift position indicator
  8. Odometer/trip meter switch and trip meter reset button

Indicator symbols
Indicator symbols - Part 1
Indicator symbols - Part 2

1 If indicator does not turn off within a few seconds of starting engine, there may be a malfunction. Have vehicle inspected by your Toyota dealer.
2 For details, refer to "Four-wheel drive lock switch," Section 2-4, 2011 Owner's Manual.
3 If this light flashes, refer to "Cruise control," Section 2-4, 2011 Owner's Manual.

Keyless entry
Beep sound can be switched ON or OFF. Refer to the Owner's Manual for more details.

Locking operation
Locking operation

Unlocking operation
Unlocking operation
NOTE: If a door is not opened within 60 seconds of unlocking, all doors will relock for safety.

Panic button
Panic button

Smart Key system (if equipped)
Start function

Start function
NOTE: Gear shift lever must be in Park and brake pedal depressed.

Power (without starting engine)
Without depressing the brake pedal, pressing the "ENGINE START STOP" switch will change the operation mode in succession from:

Locking operation
Locking operation

Unlocking operation
Unlocking operation

Back door lock/unlock
Back door lock/unlock
* Driver door unlocking function can be programmed to unlock driver door only, or all doors. Grasping passenger door handle will unlock all doors.
NOTE: Doors may also be locked/unlocked using remote.

Fuel tank door release and cap
Fuel tank door release and cap
NOTE: Tighten until one click is heard. If the cap is not tightened enough, Check Engine " " indicator may illuminate.

Hood release
Hood release

Engine maintenance
4 cylinder (2AR-FE) engine

Engine maintenance - Part 1

V6 (2GR-FE) engine
Engine maintenance - Part 2

  1. Engine coolant reservoir
  2. Engine oil filler cap
  3. Engine oil level dipstick
  4. Windshield and back window washer fluid tank

NOTE: Regularly scheduled maintenance, including oil changes, will help extend the life of your vehicle and maintain performance. Please refer to the "Warranty Maintenance Guide."

FEATURES/OPERATIONS

Automatic Transmission
4-speed models

Automatic Transmission - 4-speed models

5-speed models
Automatic Transmission - 5-speed models
* The ignition/"ENGINE START STOP" switch must be "ON" and the brake pedal depressed to shift from Park.
Downshifting increases power going uphill, or provides engine braking downhill. For best fuel economy during normal driving conditions, always drive with the shift lever in the "D" position.

Parking brake
Parking brake

Active torque control 4WD Auto lock functions (4WD models)
Four-wheel drive lock switch

Four-wheel drive lock switch
Push the switch to ensure that the engine torque is applied to the four wheels.
NOTE: Should ONLY be used when wheel spinning occurs on loose or unpaved surfaces.
Refer to the Owner's Manual for more details.

Seat adjustments-Front
Seat adjustments-Front

Seat adjustments-Front
Manual seat

Seat adjustments-Front - Manual seat

Power seat (driver side only)
Seat adjustments-Front - Power seat (driver side only)

  1. Seat position (forward/backward)
  2. Height crank (driver side only)
  3. Seatback angle
  4. Seat position, cushion angle and height
  5. Seatback angle
  6. Lumbar support

Seats-Folding down second row seats
Seats-Folding down second row seats

  1. Seat position (forward/backward)
  2. Seatback angle
  3. Seatback lock release

Seats-Folding down second row seats
From inside

Seats-Folding down second row seats - From inside

From outside (vehicles without third row seats)
Seats-Folding down second row seats - From outside

Seats-Stowing third row seats (if equipped)
Seats-Stowing third row seats (if equipped)

Lights & turn signals
Headlights

Lights & turn signals - Headlights

  • Daytime Running Light system (DRL) (if equipped)
    Automatically turns on the headlights at a reduced intensity.
  • Automatic light cut off system
    Will automatically turn lights off after a delay of 30 seconds.

Turn signals
Turn signals

Fog lights (if equipped)
Fog lights (if equipped)
Front fog lights come on only when the headlights are on low beam.

Windshield wipers & washers
Front

Windshield wipers & washers - Front
* Intermittent windshield wiper frequency adjustment
Rotate to increase/decrease wipe frequency.

Rear
Windshield wipers & washers - Rear

Windows-Power
Windows-Power
Automatic operation (driver side only) Push the switch completely down or pull it completely up and release to fully open or close. To stop window midway, lightly push the switch in the opposite direction.
Window lock switch Deactivates all passenger windows. Driver's window remains operable.
NOTE: If the battery is disconnected, the window needs to be reinitialized. Refer to the Owner's Manual for more details.

Moonroof (if equipped)
Sliding operation

Push once to open partway; again to open completely.
Moonroof - Sliding operation

Tilting operation
Moonroof - Tilting operation
NOTE: If battery is disconnected, the moonroof needs to be reinitialized. Refer to the Owner's Manual for more details.

Door locks
Door locks

VSC OFF button
VSC OFF button
The VSC OFF button is used to switch between modes related to the TRAC, VSC and Auto LSD functions (2WD models.)

Telephone controls (Bluetooth (if equipped)
Telephone controls (Bluetooth (if equipped)
Bluetooth ® technology allows dialing or receipt of calls without taking hands from the steering wheel or using a cable to connect the compatible telephone and the system. Refer to "Using the hands-free phone system (for cellular phone)," Section 3-3 in the Owner's Manual, or go to Toyota. LetsTalk.com for more information about phone connections and compatibility.

Tilt and telescopic steering wheel
Tilt and telescopic steering wheel
Hold wheel, push lever down, set angle and length, and return lever.
NOTE: Do not attempt to adjust while the vehicle is in motion.

Seat heaters (if equipped)
Seat heaters (if equipped)

Air Conditioning/Heating
Automatic Air Conditioning

Automatic Air Conditioning

  1. Temperature selector (driver side)
  2. Recirculate cabin air (fresh air when OFF)
  3. Airflow vent
  4. In " " mode, use fresh air (" " indicator OFF) to reduce window fogging. " " mode uses fresh air only.
  5. Air Conditioning ON/OFF "DUAL" button
    Indicator ON: Separate temperature settings for driver and passenger.
    Indicator OFF: Synchronize temperature settings for driver and passenger.
  6. Temperature selector (front passenger side)
  7. Micro dust and pollen filter ON/OFF
  8. Rear defogger
  9. Fan speed
  10. Windshield deffogger
  11. Climate control OFF
  12. Automatic climate control ON
    Adjust the temperature setting, and airflow vents and fan will adjust automatically.

Manual Air Conditioning
Manual Air Conditioning

  1. Airflow vent
    " " or " " mode uses fresh air only (" " indicator "OFF") to reduce window fogging.
  2. Fan speed
  3. Temperature selector
  4. Air Conditioning ON/OFF
  5. Select for maximum cooling. Air intake will automatically be set to recirculate.
  6. Rear defogger
  7. Fresh or recirculated cabin air

Clock
Clock

Light control-Instrument panel
Light control-Instrument panel
With the dial turned fully up, instrument panel lights will not dim when the headlights are turned ON.

Audio
Audio

CD player
To scan tracks on a disc Push "SCAN." Push again to hold selection.
CD Changer (Type 2)

  • To load one disc Push "LOAD" and insert one disc.
  • To load multiple discs Push and hold "LOAD" until you hear a beep. Insert one disc. Wait until the green indicator illuminates and shutter opens to insert next disc.

To select a file (MP3/WMA only) Turn "TUNE.FILE."
To select a folder (MP3/WMA only) Push either side of "TYPE/FOLDER."

Radio
To preset stations Tune in the desired station and hold down a preset button (1-6) until you hear a beep. Push desired preset button (1-6) to select.
To scan stations Push "SCAN." Push and hold to scan preset stations. Push again to hold selection.

Steering wheel controls (if equipped)
Steering wheel controls (if equipped)

  1. "MODE"
    Push to turn audio ON and select an audio mode. Push and hold to turn the audio OFF.
  2. " "
    Use to search within the selected audio medium (radio, CD, iPod®, etc.).

Auxiliary (AUX) port
Auxiliary (AUX) port
By inserting a mini plug into the AUX port, you can listen to music from a portable audio device through the vehicle's speaker system while in AUX mode.

Power outlets-12V DC
Power outlets-12V DC
NOTE: Designed for car accessories. Ignition switch/"ENGINE START STOP" switch must be in the "ACC" or "ON" position to be used.

Power outlets-120V AC (if equipped)
Power outlets-120V AC (if equipped)
NOTE: Ignition switch/"ENGINE START STOP" switch must be in the "ON" position to be used.

Downhill Assist Control (DAC) (if equipped)
Downhill Assist Control (DAC)
DAC helps the vehicle to descend steep hills while maintaining a low speed without brake pedal operation. Press the "DAC" button (indicator will blink). Shift into L or R to activate (indicator will be solid). Pressing the button again will turn system off.
Refer to the Owner's Manual for more details.

Hill-start Assist Control (HAC) (if equipped)
Hill-start Assist Control (HAC)
HAC helps prevent rolling backwards on an incline. To engage, push further down on brake pedal while at a complete stop until a beep sounds and slip indicator illuminates. HAC holds for approximately 2 seconds after releasing brake pedal. Refer to the Owner's Manual for more details.

Cruise control
Turning system ON/OFF

Cruise control - Turning system ON/OFF

Functions
Cruise control - Functions

  1. The set speed may also be cancelled by depressing the brake pedal.
  2. The set speed may be resumed once vehicle speed exceeds 25 mph.

Refer to the Owner's Manual for more details.

SAFETY AND EMERGENCY FEATURES

Doors-Child safety locks
Rear door

Doors-Child safety locks - Rear door
Moving the lever to "LOCK" will allow the door to be opened only from the outside.

Seat belts
Seat belts
If belt is fully extended, then retracted even slightly, it cannot be re-extended beyond that point, unless fully retracted again. This feature is used to help hold child restraint systems securely.
To find more information about seat belts, and how to install a child restraint system, refer to the Owner's Manual.

Seat belts-Shoulder belt anchor
Seat belts-Shoulder belt anchor

Tire Pressure Monitoring (warning)
If tire pressure becomes critically low on any of the tires (including the indicator will come on. Correctly adjusting tire inflation will turn off the light after a few minutes. If the light does not turn off, have the system checked by your Toyota dealer.
Refer to the Owner's Manual for more details.

Spare tire (if equipped) & tools
Tool location

Tool location

Removing the spare tire

  1. To remove the spare tire cover,* open the back door. Unhook the latch on the bottom of the cover. Close the back door. Remove the spare tire cover by holding the bottom and lifting it up and away from the vehicle.
    Removing the spare tire - Step 1
  2. To remove the spare tire, turn the wheel nuts counterclockwise with the wheel nut wrench and remove.
    Removing the spare tire - Step 2

Refer to the Owner's Manual for tire changing and jack positioning procedures.
* If equipped
