Related Manuals for Jeep GRAND CHEROKEE L 2023

Summary of Contents for Jeep GRAND CHEROKEE L 2023

  • Page 1 2023 GR A N D CHER OK EE/GR A N D CHER OKE E L OW NER ’S M ANUAL...
  • Page 2 This Owner’s Manual illustrates and describes the operation of features and equipment that are either standard or optional on this vehicle. This manual may also include a description of features and equipment that are no longer available or were not ordered on this vehicle. Please disregard any features and equipment described in this manual that are not on this vehicle.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ..........................10 GETTING TO KNOW YOUR VEHICLE ..................18 GETTING TO KNOW YOUR INSTRUMENT PANEL ............95 STARTING AND OPERATING ....................119 MULTIMEDIA ..........................203 SAFETY ............................248 IN CASE OF EMERGENCY ....................307 SERVICING AND MAINTENANCE ..................330 TECHNICAL SPECIFICATIONS ....................396 CUSTOMER ASSISTANCE ....................
  • Page 4 INTRODUCTION UCONNECT VOICE RECOGNITION QUICK VEHICLE SECURITY SYSTEM — IF EQUIPPED ..26 To Arm The System ..........26 TIPS — IF EQUIPPED ..........33 SYMBOLS KEY............11 To Disarm The System ........27 Introducing Voice Recognition ......33 ROLLOVER WARNING .......... 11 Rearming Of The System .........27 Basic Voice Commands ........33 VEHICLE MODIFICATIONS/ALTERATIONS..
  • Page 5 WINDSHIELD WIPERS AND WASHERS ..... 64 MIRRORS ............... 49 EXTERIOR LIGHTS ..........57 Inside Rearview Mirror........49 Headlight Switch ..........57 Windshield Wiper Operation......64 Illuminated Vanity Mirrors .......50 Multifunction Lever ..........58 Rain Sensing Wipers — If Equipped ....65 Outside Mirrors ..........51 Daytime Running Lights (DRLs) — Rear Wiper And Washer ........66 Windshield Wiper De-Icer —If Equipped ..66 Outside Automatic Dimming Mirror —...
  • Page 6 STARTING AND OPERATING POWER SUNROOF — IF EQUIPPED ....83 INSTRUMENT CLUSTER DISPLAY......98 Single Pane Power Sunroof — If Equipped ..83 Location And Controls........98 STARTING THE ENGINE ........119 Dual Pane Power Sunroof —If Equipped ..85 Engine Oil Life Reset ........100 Automatic Transmission .......
  • Page 7 PARKSENSE FRONT/REAR PARK ASSIST FOUR-WHEEL DRIVE OPERATION......131 STOP/START SYSTEM — IF EQUIPPED..... 140 Quadra-Trac I Operating Instructions/ Autostop Mode ..........140 SYSTEM — IF EQUIPPED ........159 Precautions — If Equipped ......131 Possible Reasons The Engine Does Not ParkSense Sensors........160 Quadra-Trac II Operating Instructions/ Autostop............
  • Page 8 MULTIMEDIA PARKVIEW REAR BACK UP CAMERA ....174 TRAILER TOWING..........185 Zoom View ............. 175 Common Towing Definitions......185 UCONNECT SYSTEMS .........203 Viewing At Speed........... 176 Trailer Hitch Classification......188 CYBERSECURITY ..........203 TRAILCAM SYSTEM — IF EQUIPPED....176 Trailer Towing Weights (Maximum Trailer UCONNECT SETTINGS .........204 Weight Ratings) ..........
  • Page 9 SAFETY REAR SEAT ENTERTAINMENT (RSE) WITH Replacing the Voice Remote with Alexa Batteries ..........239 AMAZON FIRE TV BUILT-IN — IF EQUIPPED ..234 SAFETY FEATURES ..........248 Rear Seat Entertainment with Fire TV Built-In Overview............234 Anti-Lock Brake System (ABS) ..... 248 streaming (Using the Front Radio and Rear Getting Started ..........
  • Page 10 IN CASE OF EMERGENCY ENHANCED ACCIDENT RESPONSE SYSTEM Windshield Wiper Blades......343 Exhaust System ..........345 (EARS) ..............329 HAZARD WARNING FLASHERS ......307 Cooling System..........346 EVENT DATA RECORDER (EDR) ......329 ASSIST AND SOS SYSTEM — IF EQUIPPED ..307 Brake System ..........
  • Page 11 STORING THE VEHICLE ........392 Materials Added To Fuel ......398 IF YOU NEED ASSISTANCE ........403 Gasoline/Oxygenate Blends......398 BODYWORK............392 Roadside Assistance........404 Do Not Use E-85 In Non-Flex Fuel Vehicles ..398 FCA US LLC Customer Center....... 405 Protection From Atmospheric Agents ..392 CNG And LP Fuel System Modifications ..

  • Page 12: Introduction

    Congratulations on the purchase of your new Jeep® vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality. The all-new Jeep® Grand Cherokee/Grand Cherokee L continues to build on its proud legacy as the most celebrated SUV ever, while raising the bar in luxury and performance.

  • Page 13: Symbols Key

    SYMBOLS KEY ROLLOVER WARNING Utility vehicles have a significantly higher rollover rate than other types of These statements apply to operating procedures vehicles. This vehicle has a higher ground clearance and a higher center of WARNING! that could result in a collision, bodily injury and/or death.

  • Page 14: Vehicle Modifications/Alterations

    VEHICLE MODIFICATIONS/ALTERATIONS Red Warning Lights WARNING! Battery Charge Warning Light Ú page 109 Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to a collision resulting in serious injury or death. Door Open Warning Light Ú...
  • Page 15 Yellow Warning Lights Red Warning Lights Active Driving Assist - Driver Inattentiveness Warning Light Night Vision Pedestrian Warning Light Ú page 111 Ú page 110 Active Driving Assist Fault Warning Light Oil Pressure Warning Light Ú page 111 Ú page 110 Active Lane Management Warning Light Oil Temperature Warning Light Ú...
  • Page 16 Yellow Warning Lights Yellow Warning Lights Electronic Stability Control (ESC) OFF Warning Light Service 4WD Warning Light Ú page 112 Ú page 113 Engine Check/Malfunction Indicator Warning Light (MIL) Service Active Lane Management Warning Light Ú page 112 Ú page 112 Fuel Level Sensor Failure Warning Light Service Adaptive Cruise Control (ACC) Warning Light Ú...
  • Page 17 Yellow Indicator Lights Yellow Indicator Lights Forward Collision Warning (FCW) Or Pedestrian Emergency 4WD Low Indicator Light Braking (PEB) OFF Indicator Light Ú page 114 Ú page 115 Air Suspension Active Indicator Light Max Payload Exceeded Indicator Light Ú page 114 Ú...
  • Page 18 Green Indicator Lights Green Indicator Lights Adaptive Cruise Control (ACC) Set With Target Indicator Light Parking/Headlights On Indicator Light Ú page 115 Ú page 116 Adaptive Cruise Control (ACC) Set With No Target Detected Rear Seat Belt Fastened Indicator Light Indicator Light Ú...
  • Page 19 White Indicator Lights Blue Indicator Lights Active Driving Assist On Indicator Light High Beam Indicator Light Ú page 116 Ú page 117 Adaptive Cruise Control (ACC) Ready Indicator Light Gray Indicator Lights Ú page 116 Night Vision Suppressed Indicator Light Cruise Control Ready Indicator Light Ú...

  • Page 20: Getting To Know Your Vehicle

    GETTING TO KNOW YOUR VEHICLE KEYS With the ignition in the ON position and the In case the ignition switch does not change  vehicle moving at 2 mph (4 km/h), all RKE positions with the push of a button, the key fob commands are disabled.
  • Page 21 GETTING TO KNOW YOUR VEHICLE NOTE: NOTE: Using The Key Fob To Open Vehicle Windows — If Equipped If the vehicle is equipped with the Auto Relock The interior lights will turn off if you place the   feature, and is unlocked with the key fob, and ignition in the ON/RUN position while the Panic From outside of the vehicle, push and release the no door is opened within 60 seconds, the...
  • Page 22 GETTING TO KNOW YOUR VEHICLE Do not replace the coin battery if the LED on the 3. Next, locate the gap on the right side of the key  key fob above the top row buttons blinks when fob, which is positioned farther to the edge a button is pressed.
  • Page 23 GETTING TO KNOW YOUR VEHICLE WARNING! The integrated key fob contains a coin cell  battery. Do not ingest the battery; there is a chemical burn hazard. If the coin cell battery is swallowed, it can cause severe internal burns in just two hours and can lead to death.

  • Page 24: Sentry Key

    GETTING TO KNOW YOUR VEHICLE The system uses a key fob, keyless push button WARNING! CAUTION! ignition and a Radio Frequency (RF) receiver to prevent unauthorized vehicle operation. Therefore, Always remove the key fobs from the vehicle The Sentry Key Immobilizer system is not ...
  • Page 25 GETTING TO KNOW YOUR VEHICLE START WARNING! The engine will start (when foot is on the brake  When exiting the vehicle, always place the  pedal) ignition in the OFF position, remove the key NOTE: fob from the vehicle, and lock your vehicle. If the ignition position does not change with a ...

  • Page 26: Remote Start - If Equipped

    GETTING TO KNOW YOUR VEHICLE NOTE: NOTE: NOTE: Obstructions between the vehicle and key fob may The key fob may not be detected by the vehicle If the Remote Start button on the key fob is   reduce this range Ú page 408. Keyless Enter ‘n Go™...

  • Page 27: To Exit Remote Start Mode

    GETTING TO KNOW YOUR VEHICLE All of the following conditions must be met before For vehicles equipped with the Keyless  WARNING! the engine will remote start: Enter ‘n Go™ — Passive Entry feature, the message “Remote Start Active — Push Start Button” will Keep key fobs away from children.

  • Page 28: Remote Start Windshield Wiper De-Icer

    GETTING TO KNOW YOUR VEHICLE Automatic Temperature Control (ATC) Vehicle Security system will provide the following EMOTE TART BORT ESSAGE audible and visible signals: The climate controls will automatically adjust to One of the following messages will display in the the optimal temperature and mode settings The horn will pulse ...

  • Page 29: To Disarm The System

    GETTING TO KNOW YOUR VEHICLE When the Vehicle Security system is armed, the the vehicle through the opened liftgate, then EARMING YSTEM Vehicle Security Light (located in the lower right opens any door from the inside, the alarm will If something triggers the alarm and no action is portion of the instrument cluster display) will begin sound.

  • Page 30: Power Door Locks

    GETTING TO KNOW YOUR VEHICLE NOTE: When the doors are locked, an indicator light in the WARNING! lock button will illuminate. When using the emergency key to unlock the outside door handle, make sure the handle of the For personal security and safety in the event ...

  • Page 31: Keyless Enter 'N Go™ - Passive Entry

    GETTING TO KNOW YOUR VEHICLE Rear Passenger Power Door Locks equipped]) for a preset duration of 0, 30, 60 or 90 seconds. Passive Entry unlock also initiates Power door lock buttons are located on each rear two flashes of the turn signal lights. door trim panel.
  • Page 32 GETTING TO KNOW YOUR VEHICLE There are five situations that trigger a FOBIK-Safe There is a valid Passive Entry key fob outside the  search in any Passive Entry vehicle: vehicle within 5 ft (1.5 m) of a Passive Entry door handle.

  • Page 33: Automatic Unlock Doors On Exit

    GETTING TO KNOW YOUR VEHICLE To Unlock/Enter The Liftgate NOTE: HILD ROTECTION The liftgate Passive Entry lock button will lock all The liftgate Passive Entry unlock feature is built — R YSTEM OORS doors and the liftgate Ú page 408. into the electronic liftgate release button.

  • Page 34: Steering Wheel

    GETTING TO KNOW YOUR VEHICLE STEERING WHEEL NOTE: WARNING! When the Child-Protection Door Lock system is  Do not adjust the steering column while driving. engaged, the door can be opened only by using ANUAL ELESCOPING TEERING Adjusting the steering column while driving or the outside door handle even though the inside —...

  • Page 35: If Equipped

    WARNING! the vehicle’s Wake Up word, “Hey Uconnect” or serious injury or death. “Hey Jeep®”. The factory default Wake Up word is Persons who are unable to feel pain to the  set to “Hey Uconnect” and can be reprogrammed skin because of advanced age, chronic illness, —...

  • Page 36: Get Started

    GETTING TO KNOW YOUR VEHICLE TARTED DDITIONAL NFORMATION © 2022 FCA US LLC. All rights reserved. Mopar and The VR button is used to activate/deactivate Uconnect are registered trademarks and Mopar your Voice Recognition system. You can also use Owner Connect is a trademark of FCA US LLC. the system’s “Wake Up”...

  • Page 37: Programming The Memory Feature

    GETTING TO KNOW YOUR VEHICLE Passenger’s Side (If Equipped) ROGRAMMING EMORY EATURE INKING NLINKING Seat Position  EMORY To create a new memory profile, perform the The memory settings switches are located on the following: Your key fobs can be programmed to recall one of front door panels, next to the door handle, and NOTE: two saved driver’s side memory profiles.

  • Page 38: Memory Position Recall

    GETTING TO KNOW YOUR VEHICLE Manual Front Passenger Seat Forward/ EMORY OSITION ECALL WARNING! Rearward Adjustment NOTE: Do not allow people to ride in any area of your  Some models may be equipped with a manual Memory Recall is available when not in PARK, if the vehicle that is not equipped with seats and front passenger seat.

  • Page 39: Manual Adjustment (Rear Seats)

    GETTING TO KNOW YOUR VEHICLE ANUAL DJUSTMENT EATS WARNING! Vehicles equipped with third row seating may have Adjusting a seat while driving may be  a second row bench seat, or second row captain’s dangerous. Moving a seat while driving could chairs.
  • Page 40 GETTING TO KNOW YOUR VEHICLE Second Row Bench Seat — If Equipped To lower the seatback, pull upward on the recline lever located on the outboard side of the seat, and SECOND ROW BENCH SEAT FORWARD/REAR- let the seatback fold forward automatically. WARD ADJUSTMENT Lift up on the adjusting bar located at the front of the seat near the floor and release it when the seat...
  • Page 41 GETTING TO KNOW YOUR VEHICLE SECOND ROW BENCH SEAT EASY ACCESS FOR SECOND ROW CAPTAIN’S CHAIRS FORWARD/ THIRD ROW — IF EQUIPPED REARWARD ADJUSTMENT If the vehicle is equipped with third row seating, the Lift up on the adjusting bar located at the front of second row seats can tip forward to allow the seat near the floor and release it when the seat passengers to easily access the third row seats.
  • Page 42 GETTING TO KNOW YOUR VEHICLE SECOND ROW CAPTAIN’S CHAIRS RECLINE SECOND ROW CAPTAIN’S CHAIRS FOLD FLAT WARNING! ADJUSTMENT SEATS Be certain that the seatback is securely locked To recline, lean forward slightly and lift the lever The second row seatbacks can be folded flat to into position.

  • Page 43: Power Adjustment (Front Seats) - If Equipped

    GETTING TO KNOW YOUR VEHICLE WARNING! Be certain that the seatback is securely locked into position. If the seatback is not securely locked into position the seat will not provide the proper stability for child seats and/or passengers. An improperly latched seat could cause serious injury. ) —...
  • Page 44 GETTING TO KNOW YOUR VEHICLE Adjusting The Seat Forward Or Rearward Seatback Bolster Adjustment WARNING! The seat can be adjusted both forward and The front driver and passenger seatback bolsters Adjusting a seat while driving may be  rearward. Push the seat switch forward or can be extended outward, or retracted inward by dangerous.

  • Page 45: Power Adjustment (Rear Seats) - If Equipped

    GETTING TO KNOW YOUR VEHICLE ) — Cushion Extender Easy Entry/Exit Seat — If Equipped OWER DJUSTMENT EATS The cushion can be extended forward a few inches This feature provides automatic driver seat QUIPPED (centimeters) to increase thigh support. Push the positioning to enhance driver mobility when cushion extender switch forward or rearward to entering and exiting the vehicle.

  • Page 46: Power Seatback Massage - If Equipped

    GETTING TO KNOW YOUR VEHICLE The head restraints will lower automatically as There are also power folding switches for the third  CAUTION! necessary when the power seat begins to move row seats located on the C-pillar (just behind the when the vehicle is in PARK, and a rear door or rear doors on the trim panels).

  • Page 47: Heated Seats - If Equipped

    GETTING TO KNOW YOUR VEHICLE Extend  WARNING! Low Extend  Do not place anything on the seat or seatback  Rock Climb  that insulates against heat, such as a blanket The selected settings will save in the system’s or cushion.

  • Page 48: Ventilated Seats - If Equipped

    GETTING TO KNOW YOUR VEHICLE NOTE: NOTE: The level of heat selected will stay on until the operator changes it. The engine must be running for the ventilated Once a heat setting is selected, heat will be felt  seats to operate. within two to five minutes.

  • Page 49: Head Restraints

    GETTING TO KNOW YOUR VEHICLE NOTE: ESTRAINTS The head restraints should only be removed by Head restraints are designed to reduce the risk of qualified technicians, for service purposes only. If injury by restricting head movement in the event of either of the head restraints require removal, see a rear impact.
  • Page 50 GETTING TO KNOW YOUR VEHICLE The center head restraint has one adjustment WARNING! WARNING! position, and can be adjusted up or down when the seat is occupied. Pull up on the head restraint to All occupants, including the driver, should not All occupants, including the driver, should not ...

  • Page 51: Mirrors

    GETTING TO KNOW YOUR VEHICLE MIRRORS NOTE: WARNING! The head restraints must be raised manually  All occupants, including the driver, should not NSIDE EARVIEW IRROR  when occupying the third row. operate a vehicle or sit in a vehicle’s seat until Do not fold if there are passengers seated in the ...

  • Page 52: Illuminated Vanity Mirrors

    GETTING TO KNOW YOUR VEHICLE Automatic Dimming Mirror — If Equipped To activate the Digital Rearview Mirror, pull the on/ When not in use, push the on/off forward toward off control lever on the bottom of the mirror the windshield to return the mirror to the regular The mirror head can be adjusted up, down, left, rearward toward the driver.

  • Page 53: Outside Mirrors

    GETTING TO KNOW YOUR VEHICLE Outside Mirrors With Turn Signal And UTSIDE IRRORS Approach Lighting — If Equipped To receive maximum benefit, adjust the outside Driver and passenger outside mirrors with turn mirror(s) to center on the adjacent lane of traffic signal and approach lighting contain four LEDs, with a slight overlap of the view obtained on the which are located in the upper outer corner of each...

  • Page 54: Outside Automatic Dimming Mirror

    GETTING TO KNOW YOUR VEHICLE Power Folding UTSIDE UTOMATIC IMMING — I To fold the door mirrors in using the Power Folding IRROR QUIPPED Mirror function, rotate the control switch to the The outside driver side mirror will automatically power folding position. Rotating the control to the adjust for glare from vehicles behind you.

  • Page 55: If Equipped

    GETTING TO KNOW YOUR VEHICLE UNIVERSAL GARAGE DOOR OPENER — NOTE: UTOMATIC OWER OLDING IRRORS If the mirrors were folded manually, by using the QUIPPED (HOMELINK®) — IF EQUIPPED power folding mirror switch on the driver’s door panel, they will not automatically unfold. When enabled within Uconnect Settings Ú...

  • Page 56: Before You Begin Programming Homelink

    GETTING TO KNOW YOUR VEHICLE ® To operate HomeLink®, push and release any not be immediately visible when looking at the  RASING of the programmed HomeLink® buttons. These device. The name and color of the button may vary HANNELS buttons will activate the devices they are slightly by manufacturer.

  • Page 57: Programming Homelink® To A Miscellaneous Device

    GETTING TO KNOW YOUR VEHICLE 3. Push and hold the HomeLink® button you 3. Push the programmed HomeLink® button to WARNING! confirm that the garage door opener motor want to program while you push and hold the garage door opener transmitter button you are operates.

  • Page 58: Reprogramming A Single Homelink® Button

    GETTING TO KNOW YOUR VEHICLE 5. Push and hold the programmed HomeLink® during programming. Similar to this Canadian law, EPROGRAMMING INGLE some U.S. gate operators are designed to time-out button and observe the indicator light. ® B UTTON in the same manner. NOTE: To reprogram a single HomeLink®...

  • Page 59: Security

    GETTING TO KNOW YOUR VEHICLE EXTERIOR LIGHTS ECURITY WARNING! It is advised to erase all channels before you sell or Vehicle exhaust contains carbon monoxide, a EADLIGHT WITCH  turn in your vehicle. dangerous gas. Do not run your vehicle in the The headlight switch is located on the left side of To do this, push and hold the two outside buttons garage while programming the transceiver.

  • Page 60: Multifunction Lever

    GETTING TO KNOW YOUR VEHICLE instrument panel lights are also turned on. To turn ULTIFUNCTION EVER off the headlights, rotate the headlight switch back The multifunction lever is located on the left side of to the O (off) position. the steering column. For vehicles sold in Canada, rotate the headlight switch clockwise from the parking lights and instrument panel lights position to the AUTO...

  • Page 61: High/Low Beam Switch

    GETTING TO KNOW YOUR VEHICLE On some vehicles, the Daytime Running Lights The headlight switch must also be turned to the up to 90 seconds after you place the ignition into   may deactivate, or reduce intensity, on one side AUTO position after Automatic High Beams is the OFF position.

  • Page 62: Headlights On Automatically With Wipers

    GETTING TO KNOW YOUR VEHICLE Proximity Wake-Up — If Equipped Headlight Animation — If Equipped EADLIGHTS UTOMATICALLY This feature is enabled/disabled within the When “Headlight Illumination On Approach” is IPERS Uconnect system, and is activated when the turned on, and set to a time value above zero, the If your vehicle is equipped with Automatic operator approaches the driver’s door, exterior lights illuminate in a theatrical manner...

  • Page 63: Lights-On Reminder

    GETTING TO KNOW YOUR VEHICLE IGHTS EMINDER IGNALS If the headlights or parking lights are left on after Move the multifunction lever up or down and the the ignition is placed in the OFF position, a chime arrows on each side of the instrument cluster will will sound when the driver’s door is opened.

  • Page 64: Battery Saver

    GETTING TO KNOW YOUR VEHICLE Rear Courtesy/Reading Lights Dome Defeat button on the overhead console will ATTERY AVER cause all of the interior lights to turn off. Located above the rear passenger seating in both To protect the life of your vehicle’s battery, load Front Map/Reading Lights —...
  • Page 65 GETTING TO KNOW YOUR VEHICLE NOTE: Five colors can be selected for the following two zones inside of the vehicle: Multicolor ambient lighting for first and second  rows, and overhead white ambient lighting in Zone 1:  the second and third row (if equipped) seating Instrument panel decorative ambient lights ...

  • Page 66: Windshield Wipers And Washers

    GETTING TO KNOW YOUR VEHICLE WINDSHIELD WIPERS AND WASHERS cycle every second to a maximum of approximately INDSHIELD IPER PERATION 36 seconds between cycles. The delay intervals The wipers and washers are operated by a switch The windshield wiper/washer lever is located on will double in duration when the vehicle speed is within the wiper lever.

  • Page 67: Rain Sensing Wipers - If Equipped

    GETTING TO KNOW YOUR VEHICLE — I The Rain Sensing system has protective features ENSING IPERS QUIPPED WARNING! for the wiper blades and arms. It will not operate This feature senses rain or snowfall on the under the following conditions: Sudden loss of visibility through the windshield windshield and automatically activates the wipers.

  • Page 68: Rear Wiper And Washer

    GETTING TO KNOW YOUR VEHICLE — IPER ASHER INDSHIELD IPER UTOMATIC LIMATE ONTROL QUIPPED ESCRIPTIONS UNCTIONS The rear wiper/washer is operated by rotating a switch, located at the middle of the lever. Your vehicle may be equipped with a Windshield Rotate the center portion of the lever Wiper De-Icer feature that may be activated under upward to the first detent for intermittent...
  • Page 69 GETTING TO KNOW YOUR VEHICLE Max A/C Button Recirculation may be unavailable if conditions this feature is on. Performing this function will exist that could create fogging on the inside of the cause the automatic climate controls to change to Press and release to change the current windshield.
  • Page 70 GETTING TO KNOW YOUR VEHICLE Lift the driver’s or passenger’s side change to match the driver’s settings when the CAUTION! toggle switch on the faceplate upward, or vehicle is first started, without changing the press and slide the temperature bar SYNC status.
  • Page 71 GETTING TO KNOW YOUR VEHICLE Panel Mode Mix Mode Controlling The Rear Climate Controls From The Front ATC Panel Air comes from the outlets in the Air is directed through the floor, defrost, instrument panel. Each of these outlets and side window demister outlets. This can be individually adjusted to direct the setting works best in cold or snowy flow of air.
  • Page 72 GETTING TO KNOW YOUR VEHICLE REAR LOCK BUTTON The Three-Zone and Four-Zone ATC system allows (temperature, blower speed, and mode) will for adjustment of the rear climate controls from change to match the driver’s settings when the Press and release this button to lock out the front ATC panel.
  • Page 73 GETTING TO KNOW YOUR VEHICLE Rear Automatic Temperature Control AUTO BUTTON REAR MODE CONTROL The AUTO button automatically controls Push the rear mode button to adjust the interior cabin temperature by airflow distribution. The rear mode adjusting distribution and amount of settings are shown in the rear display.

  • Page 74: Automatic Temperature Control (Atc)

    GETTING TO KNOW YOUR VEHICLE REAR TEMPERATURE LOCK NOTE: Once the desired temperature is shown on the rear display, the ATC System will automatically achieve It is not necessary to move the temperature The Rear Temperature Lock symbol on and maintain that comfort level. When the system settings.

  • Page 75: Operating Tips

    GETTING TO KNOW YOUR VEHICLE Push the VR button. After the beep, say one of the Summer Operation Outside Air Intake following commands: The engine cooling system must be protected with Make sure the air intake, located directly in front of “Set the driver temperature to 70 degrees”...

  • Page 76: Interior Storage And Equipment

    GETTING TO KNOW YOUR VEHICLE INTERIOR STORAGE AND EQUIPMENT Activation By Rear Defrost  WEATHER CONTROL SETTINGS The Windshield Wiper De-Icer activates auto- Turn (A/C) on and TORAGE matically when the Rear Defrost is operating Warm Weather set the mode control to and the ambient temperature is below 33°F Glove Compartment (0.6°C).
  • Page 77 GETTING TO KNOW YOUR VEHICLE Front Center Console Sunglasses Bin Door Rear Full Center Console — If Equipped The front center console contains both an upper At the front of the console a compartment is The rear full center console contains both an upper and a lower storage area.

  • Page 78: Lighted Cupholders - If Equipped

    GETTING TO KNOW YOUR VEHICLE — I The storage compartment may also be lifted IGHTED UPHOLDERS QUIPPED forward. Pull the paddle release lever located on On some vehicles, the front cupholders are the back of the console lid. equipped with a light ring that illuminates the cupholders for the front passengers.

  • Page 79: Usb/Aux Control

    GETTING TO KNOW YOUR VEHICLE For example, if a device is plugged into the Type A USB port and another device is plugged into the Type C USB port, a message will appear and allow you to select which device to use. The following messages will appear when a non-phone device is plugged into the smaller and larger USB ports, and when a phone device is...

  • Page 80: Electrical Power Outlets

    GETTING TO KNOW YOUR VEHICLE Using This Feature Second And Third Row USB Ports By using a USB cable to connect an external The second row USB ports can be used to charge device: an external device. The device can be played on the vehicle’s sound ...
  • Page 81 GETTING TO KNOW YOUR VEHICLE ignition switch is in the ON/RUN position, while the NOTE: outlets labeled with a battery symbol are The rear cargo power outlet can be changed from connected directly to the battery and powered at battery powered to powered by ignition in the ON/ all times.

  • Page 82: Power Inverter - If Equipped

    GETTING TO KNOW YOUR VEHICLE — IRELESS HARGING CAUTION! QUIPPED Accessories that draw higher power (i.e.,  coolers, vacuum cleaners, lights, etc.) will degrade the battery even more quickly. Only use these intermittently and with greater caution. After the use of high power draw accessories, ...

  • Page 83: Windows

    GETTING TO KNOW YOUR VEHICLE WINDOWS The wireless charging pad is equipped with an charging coils of the system. Movement of the anti-slip mat to hold your mobile phone in place, phone during charging may prevent or slow the and an LED indicator light. rate of charge.
  • Page 84 GETTING TO KNOW YOUR VEHICLE The window controls will operate only when the To stop the window from going all the way down  WARNING! vehicle’s ignition is placed in the ON/RUN posi- during the Auto-Down operation, pull up or push tion.

  • Page 85: Wind Buffeting

    GETTING TO KNOW YOUR VEHICLE Window Lockout Switch windows open, open the front and rear windows WARNING! together to minimize the buffeting. If the buffeting The window lockout switch on the driver's door trim occurs with the sunroof open, adjust the sunroof Never leave children unattended in a vehicle, ...
  • Page 86 GETTING TO KNOW YOUR VEHICLE Opening And Closing The Sunroof Express Venting The Sunroof Sunshade Operation To vent the sunroof, push TILT on the vent switch Express Open/Close The sunshade can be opened manually. However, and release within one half second. The sunroof the sunshade will open automatically as the To open the sunroof, push OPEN on the sunroof will open to the vent position regardless of its initial...

  • Page 87: Dual Pane Power Sunroof -If Equipped

    GETTING TO KNOW YOUR VEHICLE — Express Open/Close OWER UNROOF WARNING! To open the sunroof, push OPEN on the sunroof QUIPPED Never leave children unattended in a vehicle,  switch and release it within one-half second. The The power sunroof switches are located on the or with access to an unlocked vehicle.
  • Page 88 GETTING TO KNOW YOUR VEHICLE Pinch Protect Feature Express Venting The Sunroof Express Open/Close To vent the sunroof, push TILT on the vent switch To open the sunshade, push OPEN on the This feature will detect an obstruction in the and release within one half second.

  • Page 89: Hood

    GETTING TO KNOW YOUR VEHICLE HOOD 2. Reach under the hood from outside the LOSING vehicle, move the safety latch to the left and In one continuous motion, pull down on the front lift the hood. PENING edge of the hood with moderate force until the angle is below the crossover point (where the gas To open the hood, two latches must be released.

  • Page 90: Liftgate

    GETTING TO KNOW YOUR VEHICLE LIFTGATE NOTE: Key fob  When you push the electronic liftgate release button, Hands-free (if equipped)  either only the liftgate will unlock, or all the doors and NLOCK IFTGATE Liftgate close button in the cargo area ...

  • Page 91: Adjustable Power Liftgate Height

    GETTING TO KNOW YOUR VEHICLE — I Power Liftgate Malfunction Procedure: DJUSTABLE OWER IFTGATE EIGHT ANDS IFTGATE QUIPPED 1. In the event of a power malfunction to the The maximum height that the liftgate will open can liftgate, the liftgate can be released by be adjusted and saved so that the liftgate will only accessing the service release feature in the open to the desired height.

  • Page 92: Cargo Area Features

    GETTING TO KNOW YOUR VEHICLE NOTE: If the power liftgate encounters multiple Gas props support the liftgate in the open position.  obstructions within the same cycle, the system However, because the gas pressure drops with Opening or closing the Hands-Free Liftgate ...
  • Page 93 GETTING TO KNOW YOUR VEHICLE Additional storage can be found under the storage WARNING! lid. To access the lower storage, lift the handle and raise the storage lid. Cargo tie-downs are not safe anchors for a  child seat tether strap. In a sudden stop or accident, a tie-down could pull loose and allow the child seat to come loose.
  • Page 94 GETTING TO KNOW YOUR VEHICLE Foldable Cargo Area Cover — If Equipped WARNING! The purpose of this cover is for privacy, not to Place as much cargo as possible in front of the  secure loads. It will not prevent cargo from shifting rear axle.

  • Page 95: Roof Luggage Rack - If Equipped

    GETTING TO KNOW YOUR VEHICLE NOTE: WARNING! The liftgate may be opened with the cargo cover in place. In a collision, a loose cargo cover in the vehicle could cause injury. It could fly around in a To store the foldable cargo area cover, reverse the sudden stop and strike someone in the vehicle.
  • Page 96 GETTING TO KNOW YOUR VEHICLE To move the crossbars, loosen the attachments, WARNING! CAUTION! located at the upper edge of each crossbar, approximately eight turns using the anti-theft Cargo must be securely tied down before driving Long loads which extend over the windshield, ...

  • Page 97: Digital Instrument Cluster

    GETTING TO KNOW YOUR INSTRUMENT PANEL DIGITAL INSTRUMENT CLUSTER Holding the OK button on the Instrument Cluster Display controls located on the steering wheel will allow you to change your display from Digital to Analog.

  • Page 98: Digital Instrument Cluster Descriptions

    GETTING TO KNOW YOUR INSTRUMENT PANEL Use this QR code to access your 3. Tachometer WARNING! digital experience. Indicates the engine speed in revolutions  A hot engine cooling system is dangerous. You or per minute (RPM x 1000). IGITAL NSTRUMENT others could be badly burned by steam or boiling 4.

  • Page 99: Getting To Know Your Instrument Panel

    GETTING TO KNOW YOUR INSTRUMENT PANEL ANALOG INSTRUMENT CLUSTER Holding the OK button on the Instrument Cluster Display controls located on the steering wheel will allow you to change your display from Analog to Digital.

  • Page 100: Analog Instrument Cluster Descriptions

    GETTING TO KNOW YOUR INSTRUMENT PANEL opening/closing of a door will activate the display NALOG NSTRUMENT LUSTER CAUTION! for viewing, and display the total miles, or ESCRIPTIONS kilometers, in the odometer. Your instrument Driving with a hot engine cooling system could cluster display is designed to display important damage your vehicle.
  • Page 101 GETTING TO KNOW YOUR INSTRUMENT PANEL The system allows the driver to select information 1. Up Arrow Button 5. Down Arrow Button by pushing the following buttons mounted on the Push and release the up arrow button to Push and release the down arrow button to steering wheel: scroll upward through the main menu.

  • Page 102: Engine Oil Life Reset

    GETTING TO KNOW YOUR INSTRUMENT PANEL Custom Tile Configuration You can customize your Instrument Cluster Display Off Road  with up to five tiles that may consist of the Selec-Terrain Status/ Air Suspension Status To customize the instrument cluster further, you ...

  • Page 103: Display And Messages

    GETTING TO KNOW YOUR INSTRUMENT PANEL Vehicles Equipped With Keyless Enter ‘n Go™ Secondary Method Of Resetting Engine Oil Life Gear Selector Status (PRND)  Ignition 1. Without pressing the brake pedal, push the Driver Interactive Display (Compass, Temp,  Use the steering wheel instrument cluster display ENGINE START/STOP button and place the Range to Empty, Trip A, Trip B, Average Fuel...
  • Page 104 GETTING TO KNOW YOUR INSTRUMENT PANEL Unstored Messages Until RUN Door Ajar” and “Press Brake Pedal and Push display area for five seconds and then returns to  Button to Start”. the previous screen. An example of this These messages deal primarily with the Remote message type is “Automatic High Beams On”.

  • Page 105: Instrument Cluster Display Menu Items

    GETTING TO KNOW YOUR INSTRUMENT PANEL Night Vision — If Equipped Fuel Economy NSTRUMENT LUSTER ISPLAY While viewing the Speedometer menu Average Fuel Economy TEMS  title, push and release the left Current Fuel Economy  The instrument cluster display can be used to view right arrow button until the Night Range To Empty...
  • Page 106 GETTING TO KNOW YOUR INSTRUMENT PANEL Tire Pressure Monitor System Average Fuel Economy – Shows the average Pitch And Roll   fuel economy (MPG or L/100 km or km/L) of If tire pressure is OK for all tires a vehicle icon is Vehicle Pitch ...

  • Page 107: Head Up Display (Hud) - If Equipped

    GETTING TO KNOW YOUR INSTRUMENT PANEL Screen Setup your vehicle is equipped Traffic Sign Assist or Favorite Menus Driver Assist systems. Push and release the up or down arrow Trip (Show/ Off Road Driver Info Push and release the up or down arrow button until the Settings Menu title is highlighted in...

  • Page 108: Battery Saver On/Battery Saver Mode Message - Electrical Load Reduction Actions - If Equipped

    GETTING TO KNOW YOUR INSTRUMENT PANEL NOTE: Content and Layout  Simple: Speed, Speed Limit The HUD basic settings (Brightness, Display   Height and Non Custom layouts), are controlled Standard: Speed, Speed Limit, Navigation  through the Settings Screen in the Instrument Cluster Ú...
  • Page 109 GETTING TO KNOW YOUR INSTRUMENT PANEL When load reduction is activated, the message Loss of the battery charge may indicate one or What to do when an electrical load reduction “Battery Saver On” or “Battery Saver Mode” will more of the following conditions: action message is present (“Battery Saver On”...

  • Page 110: Warning Lights And Messages

    GETTING TO KNOW YOUR INSTRUMENT PANEL WARNING LIGHTS AND MESSAGES in the master cylinder has dropped below a single chime when a fault with the air bag has been detected, it will stay on until the fault is cleared. If specified level.
  • Page 111 GETTING TO KNOW YOUR INSTRUMENT PANEL applied or a brake fault is detected. If the light does Electric Power Steering (EPS) Fault NOTE: not illuminate, have the light inspected by an This light may turn on if the accelerator and brake Warning Light authorized dealer.
  • Page 112 GETTING TO KNOW YOUR INSTRUMENT PANEL Hood Open Warning Light If enabled, a chime will sound and a video pop-up of the instrument cluster display, momentarily may display when a detection occurs. replacing the configurable corner information. If a This warning light will illuminate when the second row seat belt that was buckled at the start Oil Pressure Warning Light hood is left open and not fully closed.

  • Page 113: Yellow Warning Lights

    GETTING TO KNOW YOUR INSTRUMENT PANEL Active Driving Assist Fault Warning Light Electronic Stability Control (ESC) Active WARNING! Warning Light — If Equipped This light will turn on when the Active If you continue operating the vehicle when the Driving Assist system has detected a This warning light will indicate when the Transmission Temperature Warning Light is fault.
  • Page 114 GETTING TO KNOW YOUR INSTRUMENT PANEL Electronic Stability Control (ESC) OFF Low Fuel Warning Light When the engine is running, the MIL may flash to alert serious conditions that could lead to Warning Light — If Equipped When the fuel level reaches immediate loss of power or severe catalytic approximately 2 gal (7.5 L), this light will This warning light indicates the ESC is off.
  • Page 115 GETTING TO KNOW YOUR INSTRUMENT PANEL Night Vision Animal Warning Light Service Forward Collision Warning (FCW) Should one or more tires be in the condition previously mentioned, the display will show the Or Pedestrian Emergency Braking (PEB) The Night Vision Animal Warning Light indications corresponding to each tire.

  • Page 116: Yellow Indicator Lights

    GETTING TO KNOW YOUR INSTRUMENT PANEL Air Suspension Active Indicator Light — also reduces fuel efficiency and tire tread life, and CAUTION! may affect the vehicle’s handling and stopping If Equipped ability. The TPMS has been optimized for the original This light will illuminate when the air equipment tires and wheels.

  • Page 117: Green Indicator Lights

    GETTING TO KNOW YOUR INSTRUMENT PANEL Auto HOLD! Fault Indicator Light — Sway Bar Indicator Light — If Equipped Auto HOLD Indicator Light — If Equipped If Equipped This indicator light will illuminate when Auto HOLD keeps your vehicle at a the front sway bar is disconnected complete stop without you having to keep The Auto HOLD! Fault Indicator light will...

  • Page 118: White Indicator Lights

    GETTING TO KNOW YOUR INSTRUMENT PANEL Night Vision Active Indicator Light — Turn Signal/Hazard Indicator Lights Cruise Control Ready Indicator Light If Equipped When the left or right turn signal is This indicator light will illuminate when activated, the turn signal indicator will the cruise control is ready, but not set This light alerts the driver that the Night flash independently and the...

  • Page 119: Blue Indicator Lights

    GETTING TO KNOW YOUR INSTRUMENT PANEL Selec-Speed Control Indicator Light — NDICATOR IGHTS CAUTION! If Equipped Night Vision Suppressed Indicator Light — Prolonged driving with the MIL on could cause  This light will turn on when Selec-Speed If Equipped further damage to the emission control Control is activated.

  • Page 120: Programs

    GETTING TO KNOW YOUR INSTRUMENT PANEL For states that require an Inspection and The MIL will flash for about 10 seconds and  WARNING! Maintenance (I/M), this check verifies then return to being fully illuminated until the Malfunction Indicator Light (MIL) is you turn OFF the ignition or start the engine.

  • Page 121: Starting And Operating

    STARTING AND OPERATING STARTING THE ENGINE WARNING! CAUTION! Before starting your vehicle, adjust your seat, Do not leave the key fob in or near the vehicle, Shift into PARK only after the vehicle has   adjust the inside and outside mirrors, fasten your or in a location accessible to children, and do come to a complete stop.

  • Page 122: Autopark

    STARTING AND OPERATING NOTE: 3. The system takes over and attempts to start the vehicle. If the vehicle fails to start, the If the gear selector is not in PARK, and the ENGINE AutoPark is a supplemental feature to assist with starter will disengage automatically after 10 START/STOP button is pushed once with the placing the vehicle in PARK (P) should the...

  • Page 123: Extended Park Starting

    STARTING AND OPERATING If the vehicle is not in PARK and the driver turns off The message “AutoPark Engaged Shift To P Then Additional customer warnings will be given when both of these conditions are met: the engine, the vehicle may AutoPark. Shift To Gear”...

  • Page 124: If Engine Fails To Start

    STARTING AND OPERATING 4. If the engine fails to start after eight attempts, EATHER PERATION WARNING! allow the starter to cool for at least –22°F O −30°C) ELOW 10 minutes, then repeat the Extended Park Never pour fuel or other flammable liquid into ...

  • Page 125: Parking Brake

    STARTING AND OPERATING The parking brake switch is located on the NOTE: CAUTION! instrument panel to the left of the steering wheel The EPB Warning Light will illuminate if the EPB (below the headlamp switch). Never use non-detergent oil or straight mineral switch is held for longer than 20 seconds in either the released or applied position.
  • Page 126 STARTING AND OPERATING NOTE: If exceptional circumstances should make it WARNING! necessary to engage the parking brake while the When parking on a hill, it is important to turn the vehicle is in motion, maintain upward pressure on front wheels toward the curb on a downhill grade Do not leave the key fob in or near the vehicle, ...

  • Page 127: Auto Park Brake

    STARTING AND OPERATING SafeHold can be temporarily bypassed by pushing The following conditions must be met for Hold ‘N RAKE the EPB switch while the driver door is open. Once Go to activate: The EPB can be programmed to be applied manually bypassed, SafeHold will be enabled Driver’s door is closed ...

  • Page 128: Automatic Transmission

    STARTING AND OPERATING AUTOMATIC TRANSMISSION Maintenance Mode has requirements that must be WARNING! met in order to be activated: You must press and hold the brake pedal while It is dangerous to shift out of PARK or The vehicle must be at a standstill. ...

  • Page 129: Ignition Park Interlock

    STARTING AND OPERATING GNITION NTERLOCK PEED UTOMATIC RANSMISSION WARNING! This vehicle is equipped with an Ignition Park The transmission is controlled using a rotary Never leave children alone in a vehicle, or with  Interlock which requires the transmission to be in electronic gear selector located on the center access to an unlocked vehicle.
  • Page 130 STARTING AND OPERATING NOTE: Only shift from DRIVE to PARK or REVERSE when CAUTION! the accelerator pedal is released and the vehicle is After selecting any gear range, wait a moment to stopped. Be sure to keep your foot on the brake allow the selected gear to engage before acceler- Before moving the transmission gear selector ...
  • Page 131 STARTING AND OPERATING NEUTRAL (N) When frequent transmission shifting occurs (such Light (MIL) may be illuminated. A message in the as when operating the vehicle under heavy loading instrument cluster will inform the driver of the Use this range when the vehicle is standing for conditions, in hilly terrain, traveling into strong more serious conditions, and indicate what actions prolonged periods with the engine running.
  • Page 132 STARTING AND OPERATING NOTE: Operation SECOND gear can be helpful in snowy or icy conditions. Even if the transmission can be reset, we To activate AutoStick mode, tap one of the paddle recommend that you visit an authorized dealer at shifters on the steering wheel.

  • Page 133: Sport Mode - If Equipped

    STARTING AND OPERATING SPORT MODE — IF EQUIPPED FOUR-WHEEL DRIVE OPERATION NOTE: The Quadra-Trac I system is not appropriate for The driveline is equipped with a Front Axle conditions where 4WD LOW range is recom- Disconnect (FAD) for the one-speed and two-speed mended Ú...

  • Page 134: Shift Positions

    STARTING AND OPERATING N (NEUTRAL) Proper operation of four-wheel drive vehicles HIFTING ROCEDURES depends on tires of equal size, type, and This range disengages the driveline from the 4WD HI To 4WD LOW circumference on each wheel. Any difference will powertrain.

  • Page 135: Quadra-Trac Ii System -If Equipped

    STARTING AND OPERATING — 4WD LOW To 4WD HI shift completion to occur. The preferred LECTRONIC ISCONNECT method is with the vehicle rolling 0 to 3 mph With the vehicle at speeds of 0 to 3 mph (0 to QUIPPED (0 to 5 km/h).

  • Page 136: Selec-Terrain - If Equipped

    STARTING AND OPERATING Push the SWAY BAR switch to activate the system. bar to disconnect/reconnect, the right and left WARNING! Push the switch again to deactivate the system. halves of the bar must be aligned. This alignment The Sway Bar Indicator Light (located in the may require that the vehicle be driven onto level Ensure the stabilizer/sway bar is reconnected instrument cluster) will illuminate when the bar is...

  • Page 137: Instrument Cluster Display Messages

    STARTING AND OPERATING SAND/MUD – Off-road calibration for use on low NOTE:  traction surfaces such as mud or sand. Driveline If equipped with air suspension, the level will only is maximized for traction. Some binding may be raise to Normal Ride Height (NRH) in the AUTO felt on less forgiving surfaces.

  • Page 138: Quadra-Lift - If Equipped

    STARTING AND OPERATING QUADRA-LIFT — IF EQUIPPED Off-Road 2 (OR2) (Non-TrailHawk raises the  vehicle approximately 2.4 inches [60 mm]) (TrailHawk raises the vehicle approximately ESCRIPTION 3.0 inches [75 mm]) – This position is intended The Quadra-Lift Air Suspension system provides for off-road use only where maximum ground full time load leveling capability along with the clearance is required.
  • Page 139 STARTING AND OPERATING Normal Ride Height (NRH) 0.0 inches (0 mm) – NOTE: vehicle will move up first and then the front. When  lowering the vehicle, the front will move down first This is the standard position of the suspension Automatic lowering of the vehicle into Entry/Exit and is meant for normal driving.

  • Page 140: Air Suspension Modes

    STARTING AND OPERATING Transport Mode NSTRUMENT LUSTER ISPLAY WARNING! To assist with flat bed towing, the air suspension ESSAGES The air suspension system uses a high pressure system has a feature which will put the vehicle into volume of air to operate the system. To avoid When the appropriate conditions exist, a message Entry/Exit height and disable the automatic load personal injury or damage to the system, see an...

  • Page 141: Fuel Saver Technology 5.7L Only

    STARTING AND OPERATING pushed multiple times. Each toggle down will lower Wheel Alignment Mode – Indicator lamps 3  WARNING! the requested level by one position down to a through 5 will be illuminated. Driving above minimum of Entry/Exit Height or the lowest 5 mph (8 km/h) or deselecting setting in the Continued operation with reduced assist could position allowed based on current conditions (i.e.

  • Page 142: Stop/Start System - If Equipped

    STARTING AND OPERATING If the Steering icon is displayed and the “Power To Activate The Autostop Mode, The Following Battery temperature is too warm or cold.  Steering System Over Temp” message is displayed Must Occur: Battery charge is low. ...

  • Page 143: To Start The Engine While In Autostop Mode

    STARTING AND OPERATING TART NGINE HILE ANUALLY ANUALLY UTOSTOP TART YSTEM TART YSTEM While in a forward gear, the engine will start when Push the Stop/Start OFF switch (located on the the brake pedal is released or the throttle pedal is switch bank).

  • Page 144: Cruise Control Systems

    STARTING AND OPERATING CRUISE CONTROL SYSTEMS ACC will allow you to keep Cruise Control engaged WARNING! in light to moderate traffic conditions without the Your vehicle is equipped with the Adaptive Cruise constant need to reset your Cruise Control. ACC Adaptive Cruise Control (ACC) is a conve- ...
  • Page 145 STARTING AND OPERATING Adaptive Cruise Control (ACC) Operation Driving Assist Menu WARNING! The buttons on the right side of the steering wheel The instrument cluster display will show the Will bring the vehicle to a complete stop  operate the ACC system. current system settings for Adaptive Cruise Control and hold the vehicle in the stop position (ACC), Active Lane Management (ALM), and the...
  • Page 146 STARTING AND OPERATING NOTE: Adaptive Cruise Control Off When there is a stationary vehicle in front of  your vehicle in close proximity Fixed Speed Cruise Control (if equipped) is used When ACC is deactivated, the display will read without ACC enabled. To change between Adaptive “Adaptive Cruise Control Off”.
  • Page 147 STARTING AND OPERATING NOTE: The following conditions will only cancel the ACC Resume can be used at any speed above 20 mph system: (32 km/h) when only Fixed Speed Cruise Control is Keeping your foot on the accelerator pedal can ...
  • Page 148 STARTING AND OPERATING To Vary The Speed Setting NOTE: Setting The Following Distance In ACC When you override and push the SET (+) button or To Increase Or Decrease The Set Speed The specified following distance for ACC can be set SET (-) button, the new set speed will be the current by varying the distance setting between four bars After setting a speed, you can increase the set...
  • Page 149 STARTING AND OPERATING To decrease the distance setting, push the A Proximity Warning will alert the driver if ACC If the vehicle in front does not start moving within Distance Decrease button and release. Each time predicts that its maximum braking level is not two seconds of your vehicle coming to a standstill, the button is pushed, the distance setting sufficient to maintain the set distance.
  • Page 150 STARTING AND OPERATING Display Warnings And Maintenance To keep the ACC System operating properly, it is Installing a snowplow, front-end protector, an  important to note the following maintenance aftermarket grille or modifying the grille is not “WIPE FRONT RADAR SENSOR IN FRONT OF items: recommended.
  • Page 151 STARTING AND OPERATING When the condition that created limited Precautions While Driving With ACC functionality is no longer present, the system will In certain driving situations, ACC may have return to full functionality. detection issues. In these cases, ACC may brake NOTE: late or unexpectedly.
  • Page 152 STARTING AND OPERATING USING ACC ON HILLS STATIONARY OBJECTS AND VEHICLES ACC performance may be limited when driving on ACC does not react to stationary objects or hills. ACC may not detect a vehicle in your lane vehicles. For example, ACC will not react in depending on the speed, vehicle load, traffic situations where the vehicle you are following exits conditions, and the steepness of the hill.

  • Page 153: Traffic Sign Assist System - If Equipped

    STARTING AND OPERATING TRAFFIC SIGN ASSIST SYSTEM — Visual + Chime CTIVATION EACTIVATION When Visual + Chime is selected, the system will IF EQUIPPED The TSA System can be enabled/disabled within alert the driver when the current speed of the the Uconnect system through the Safety/Driver vehicle exceeds the detected speed limit by The Traffic Sign Assist (TSA) system uses a camera...

  • Page 154: Active Driving Assist System - If Equipped

    STARTING AND OPERATING When a newly detected speed limit is lower than School  CAUTION! the current speed limit, the display will update Construction  along with a down arrow. The area surrounding the sensor must not be  Rain ...
  • Page 155 STARTING AND OPERATING The driver can override ADA at any time by Hands-Free Active Driving Assist System —  If Equipped braking, accelerating, or steering the vehicle. The Hands-Free ADA system uses sensors within Just like ACC, ADA will maintain a set speed as long as the set distance between your vehicle and the the steering wheel and a driver monitoring camera vehicle in front is maintained.
  • Page 156 Emergency Braking systems Ú page 261.  to other vehicles, and brake operation to ensure covered, or slippery. If the vehicle is equipped with the Jeep®  safe operation of the vehicle under all road Connect (Uconnect Connected Services) When driving during difficult or uncertain ...

  • Page 157: Turning Active Driving Assist On Or Off

    STARTING AND OPERATING 3. If ACC was not active before pushing the ADA If equipped with Hands-Free ADA, the light strips URNING CTIVE RIVING SSIST  on/off button, push the SET (+) button or the in the driver’s and front passenger’s door SET (-) button and release when the desired panels will also change to green indicating ADA driving speed is shown in the instrument...

  • Page 158: Indications On The Display

    STARTING AND OPERATING NOTE: If the brake pedal is pressed or ACC system is When the system is deactivated, the system   deactivated status indicator lights will turn off, Active Lane For the system to detect the driver’s hands on the Management will return to its previous state, steering wheel, the wheel must be gripped on the If a turn signal is used when equipped with Base...

  • Page 159: System Status

    STARTING AND OPERATING As the system detects driver inattentiveness as Active Driving Assist Indicators Are White previously described Ú page 152, the system ADA is turned on/enabled by the driver, but the  status indicator lights will change from green, to system is not actively steering and providing yellow, to red.

  • Page 160: System Operation/Limitations

    STARTING AND OPERATING Hands-Free Active Driving Assist System The Base Active Driving Assist and Hands-Free WARNING! Active Driving Assist systems DO NOT: Two haptic brake jerk warnings will be issued  Always keep your hands on the steering wheel (red warning light is being issued). ...

  • Page 161: Parksense Front/Rear Park Assist

    STARTING AND OPERATING If the suspension alignment is not correct, if the NOTE: The automatic braking function may not be   vehicle is modified (e.g. lifting or lowering the applied fast enough for obstacles that move The driver can disable the automatic braking ...

  • Page 162: Parksense Sensors

    STARTING AND OPERATING For limitations of this system and ENSE ENSORS ENSE ISPLAY recommendations, see Ú page 166. The four ParkSense sensors located in the rear The warning display will turn on indicating the ParkSense will retain the last system state fascia/bumper, and the six ParkSense sensors system status when the vehicle is in REVERSE or (enabled or disabled) from the last ignition cycle...
  • Page 163 STARTING AND OPERATING Front/Rear/Side ParkSense Arcs 1 — No Tone/Solid Arc 7 — Fast Tone/Flashing Arc 2 — No Tone/Flashing Arc 8 — Slow Tone/Solid Arc 3 — Fast Tone/Flashing Arc 9 — Slow Tone/Solid Arc 4 — Continuous Tone/Flashing Arc 10 —...
  • Page 164 STARTING AND OPERATING The vehicle is close to the obstacle when the instrument cluster display shows one flashing arc and sounds a continuous tone. The following chart shows the warning alert operation when the system is detecting an obstacle: WARNING ALERTS FOR REAR Greater than Less than Rear Distance...

  • Page 165: Parksense Warning Display

    STARTING AND OPERATING Front Park Assist Audible Alerts When the ParkSense switch is pushed to disable "PARKSENSE UNAVAILABLE SERVICE REQUIRED.” the system, the instrument cluster will display the The pop-up message will display for five seconds. ParkSense will turn off the Front Park Assist “PARKSENSE OFF”...

  • Page 166: Cleaning The Parksense System

    STARTING AND OPERATING If the "PARKSENSE UNAVAILABLE SERVICE ParkSense, when on, will reduce the volume of  WARNING! REQUIRED" message appears in the instrument the radio when it is sounding a tone. cluster display, see an authorized dealer. Drivers must be careful when backing up even ...

  • Page 167: Side Distance Warning System

    STARTING AND OPERATING When the vehicle is in DRIVE, the Side Distance Activation/Deactivation CAUTION! Warning volume/chime will match the Front The system can operate only after driving a short ParkSense volume and chime type. ParkSense is only a parking aid and it is ...

  • Page 168: Parksense Active Park Assist System - If Equipped

    STARTING AND OPERATING ParkSense Usage Precautions system, it is recommended to remove the CAUTION! removable tow hook ball assembly and any Some conditions may influence the performance attachments from the vehicle when it is not ParkSense is only a parking aid and it is unable ...

  • Page 169: Enabling And Disabling The Parksense Active Park Assist System

    STARTING AND OPERATING NOTE: Driver's door is opened NABLING ISABLING  The driver is always responsible for controlling Rear liftgate is opened  ENSE CTIVE SSIST  the vehicle, responsible for any surrounding Electronic Stability Control/Anti-Lock Braking  YSTEM objects, and must intervene as required. System intervention The ParkSense Active Park Assist system The system is designed to assist the driver and...

  • Page 170: Parallel/Perpendicular Parking Space Assistance Operation

    STARTING AND OPERATING NOTE: The driver is responsible to ensure that the  selected parking space is suitable for the If the vehicle is driven above approximately maneuver and free/clear of anything that may 15 mph (25 km/h), the instrument cluster display be overhanging or protruding into the parking will instruct the driver to slow down.
  • Page 171 STARTING AND OPERATING Once active steering begins, a camera image will The system may then instruct the driver to wait for display in the Uconnect display with prompts that steering to complete before then instructing to will display for the duration of the maneuver. check the vehicle’s surroundings, and move backward.

  • Page 172: Exiting The Parking Space

    STARTING AND OPERATING When the system instructs the driver to remove  WARNING! CAUTION! their hands from the steering wheel, the driver should check their surroundings and begin to Drivers must be careful when performing The ParkSense Active Park Assist system is ...

  • Page 173: Active Lane Management System

    STARTING AND OPERATING Selection Of The Maneuver Side The system is operational at speeds above 37 mph (60 km/h) and below 112 mph (180 km/h). Use the direction indicators to choose the direction that you want to perform the maneuver. Use the When both lane markings are detected, and the right arrow indicator to perform the maneuver to vehicle approaches (or crosses) the lane marking...

  • Page 174: Turning Active Lane Management On Or Off

    STARTING AND OPERATING If the Blind Spot Monitoring (BSM) system  URNING CTIVE ANAGEMENT detects a vehicle in the adjacent lane, and the turn signal is applied in that direction, the BSM LED on the mirror will flash. If the driver The Active Lane Management button is continues to attempt the lane change, steering located on the switch panel above the...
  • Page 175 STARTING AND OPERATING Lane Crossed (Flashing Yellow Line) Lanes Sensed (Green Lines) Lane Drift (Solid Yellow Line) NOTE: When the system senses a lane drift situation, When the system senses the lane line is being   the left lane line turns solid yellow. At this time, crossed, the left lane line changes from solid The Active Lane Management system operates steering assist warning is applied to the steering...

  • Page 176: Changing Active Lane Management Status

    STARTING AND OPERATING NOTE: NOTE: Manual Activation Of The Back Up Camera The Active Lane Management system operates The system will not apply vibration and/or 1. Press the Vehicle button located on the   with similar behavior for a right lane departure. steering assist to the steering wheel whenever a bottom of the Uconnect display and then safety system engages (Anti-Lock Brakes, Trac-...

  • Page 177: Zoom View

    STARTING AND OPERATING The following table shows the approximate CAUTION! distances for each zone: When the Rear View Camera image is To avoid vehicle damage, ParkView should  Distance To The Rear Of being displayed, and the vehicle speed is Zone only be used as a parking aid.

  • Page 178: Viewing At Speed

    STARTING AND OPERATING NOTE: The Back Up Camera view can also be activated by pressing the icon on the TrailCam view. If the vehicle is in DRIVE, NEUTRAL, or REVERSE,  and speed is greater than or equal to 8 mph When the vehicle is shifted out of REVERSE with (13 km/h), Zoom View is unavailable and the camera delay turned off and TrailCam view is...

  • Page 179: Famcam System - If Equipped

    STARTING AND OPERATING Cleaning The TrailCam The display will show the entire view inside the NOTE: vehicle on the left side of the screen, and will show When FamCam is turned off, the selected seat in Press and hold the Clean Camera button located a zoomed in view of the selected seat on the right the zoomed in view on the right side of the display on the TrailCam view to wash the TrailCam.
  • Page 180 STARTING AND OPERATING NOTE: The pedestrian/animal is directly in the vehicle  path, close to the headlight area Night Vision only shows objects of interest that Pedestrian Warning Telltale  are warmer or colder than the surroundings. A video pop-up will display when there is a target ...

  • Page 181: Detection Range

    STARTING AND OPERATING The Night Vision alert status telltale will ETECTION ANGE WARNING! be gray when the warnings are The system can detect people 4 ft (1.25 m) tall or suppressed. The telltale will also turn The Night Vision system only provides alerts to ...

  • Page 182: Service The Night Vision System

    STARTING AND OPERATING ERVICE IGHT ISION YSTEM IGHT ISION YSTEM IMITATIONS WARNING! When service conditions are present, the following The Night Vision display is deactivated under the Night Vision can only detect pedestrians and  fault messages may appear in the instrument following conditions: animals located within the range of the cluster display when the vehicle is placed in the ON...

  • Page 183: Surround View Camera System

    STARTING AND OPERATING SURROUND VIEW CAMERA SYSTEM — When the vehicle is shifted out of REVERSE with Modes Of Operation camera delay turned on, the camera image will Manual activation of the Surround View Camera is IF EQUIPPED continue to be displayed for up to 10 seconds selected by pressing the Surround View Camera unless the vehicle speed exceeds 8 mph button located in the Controls menu within the...
  • Page 184 STARTING AND OPERATING NOTE: Front Cross Path View Front And Rear Camera Washers Front tires will be in image when the tires are Pressing the Front Cross Path button will When the front windshield washer is activated by  turned. give the driver a wider angle view of the pulling the windshield wiper/washer lever front camera system.

  • Page 185: Zoom View

    STARTING AND OPERATING REFUELING THE VEHICLE When Zoom View is selected while the vehicle is in CAUTION! REVERSE, then shifted to DRIVE, the camera delay 1. Open the fuel filler door by pushing near the view will display the standard Back Up Camera To avoid vehicle damage, Surround View ...

  • Page 186: Vehicle Loading

    STARTING AND OPERATING 2. Insert the fuel nozzle fully into the filler pipe – axle systems (GAWR). Total load must be limited so WARNING! the nozzle opens and holds the flapper doors GVWR and front and rear GAWR are not exceeded. while refueling.

  • Page 187: Inflation Pressure

    STARTING AND OPERATING heavier items down low and be sure that the NFLATION RESSURE OMMON OWING EFINITIONS weight is distributed equally. Stow all loose items This is the cold tire inflation pressure for your The following trailer towing related definitions will securely before driving.
  • Page 188 STARTING AND OPERATING Gross Combination Weight Rating (GCWR) Trailer Frontal Area Weight-Distributing Hitch The GCWR is the total allowable weight of your The frontal area is the maximum height multiplied A weight-distributing system works by applying vehicle and trailer when weighed in combination. by the maximum width of the front of a trailer.
  • Page 189 STARTING AND OPERATING 3. For vehicles equipped with Quadra-Lift air 7. Install and adjust the tension in the weight WARNING! distributing bars per the manufacturer’s suspension, use the touchscreen radio settings to enable Tire/Jack mode. Tire/Jack recommendations so that the height of the An improperly adjusted weight-distributing ...

  • Page 190: Trailer Hitch Classification

    STARTING AND OPERATING RAILER ITCH LASSIFICATION The following chart provides the industry standard for the maximum trailer weight a given trailer hitch class can tow and should be used to assist you in selecting the correct trailer hitch for your intended towing condition. Trailer Hitch Classification Definitions Class Max.

  • Page 191: Trailer Towing Weights (Maximum Trailer Weight Ratings)

    STARTING AND OPERATING RAILER OWING EIGHTS AXIMUM RAILER EIGHT ATINGS Grand Cherokee — 2nd Row Seats Maximum Trailer TW Engine Model GCWR Frontal Area Maximum GTW (See Note) AWD Without Trailer Tow 2.0L 9,625 lb (4,366 kg) 30 sq ft (2.79 sq m) 3,500 lb (1,588 kg) 350 lb (159 kg) Prep Group...
  • Page 192 STARTING AND OPERATING Grand Cherokee L — 3rd Row Seats Maximum Trailer TW Engine Model GCWR Frontal Area Maximum GTW (See Note) RWD Without Trailer Tow 9,000 lb (4,082 kg) 30 sq ft (2.79 sq m) 3,500 lb (1,588 kg) 350 lb (159 kg) 3.6L Prep Group...

  • Page 193: Trailer Hitch Receiver Cover Removal - If Equipped

    STARTING AND OPERATING To reinstall the cover after towing repeat the RAILER ITCH ECEIVER OVER WARNING! procedure in reverse order. — I EMOVAL QUIPPED Always load a trailer with 60% of the weight in NOTE: Your vehicle may be equipped with a trailer hitch the front of the trailer.

  • Page 194: Towing Requirements

    STARTING AND OPERATING OWING EQUIREMENTS WARNING! WARNING! To promote proper break-in of the new vehicle When hauling cargo or towing a trailer, do not GAWR   drivetrain components, the following guidelines overload your vehicle or trailer. Overloading can Tongue weight rating for the trailer hitch ...
  • Page 195 STARTING AND OPERATING Towing Requirements — Trailer Brakes NOTE: CAUTION! Disconnect the trailer wiring connector from the Do not interconnect the hydraulic brake system   If the trailer weighs more than 1,000 lb (453 kg) vehicle (or any other device plugged into or vacuum system of your vehicle with that of loaded, it should have its own brakes and they vehicle’s electrical connectors) before...

  • Page 196: Towing Tips

    STARTING AND OPERATING Cruise Control — If Equipped OWING Do not use on hilly terrain or with heavy loads.  Before towing, practice turning, stopping, and When using the Cruise Control, if you experience backing up the trailer in an area located away from ...

  • Page 197: Recreational Towing (Behind Motorhome)

    STARTING AND OPERATING RECREATIONAL TOWING (BEHIND MOTORHOME) OWING EHICLE EHIND NOTHER EHICLE Four-Wheel Drive Models Four-Wheel Drive Models Towing Condition Wheels OFF The Ground Two-Wheel Drive Models Without 4WD LOW With 4WD LOW See Instructions Transmission in PARK  Ensure vehicle is set to ...

  • Page 198: Recreational Towing - Two-Wheel Drive Models

    STARTING AND OPERATING — T — ECREATIONAL OWING HEEL ECREATIONAL OWING CAUTION! –T 4WD LOW RIVE ODELS UADRA WITH Towing with the rear wheels on the ground will ANGE cause severe transmission damage. Damage DO NOT flat tow this vehicle. Damage to the drivetrain will result.
  • Page 199 STARTING AND OPERATING Shifting Into Transfer Case N (NEUTRAL) 4. If vehicle is equipped with Quadra-Lift air CAUTION! suspension, ensure the vehicle is set to WARNING! Normal Ride Height with the Auto Entry/Exit DO NOT dolly tow any 4WD vehicle. Towing ...
  • Page 200 STARTING AND OPERATING 11. With the transmission and transfer case in N If the vehicle is equipped with Quadra-Lift in progress. The light will stop blinking (stay on  air suspension, the engine should be solid) when the shift to N (NEUTRAL) is (NEUTRAL), push and hold the ENGINE START/ started and left running for a minimum of complete.

  • Page 201: Driving Tips

    STARTING AND OPERATING NOTE: 12. Press and hold the brake pedal. Steps 1 through 5 are requirements that 13. Release the Electric Park Brake.  must be met before pushing the N 14. Shift the transmission into REVERSE or DRIVE, (NEUTRAL) button, and must continue to be release the brake pedal, and check that the met until the shift has been completed.

  • Page 202: Off-Road Driving Tips

    STARTING AND OPERATING RIVING WARNING! CAUTION! Quadra-Lift — If Equipped Do not drive in 4WD LOW range on dry When driving through water, do not exceed pavement; driveline damage may result. 4WD 5 mph (8 km/h). Always check water depth When off-roading, it is recommended that the LOW range locks front and rear drivelines before entering as a precaution, and check all...
  • Page 203 STARTING AND OPERATING Standing Water Hill Climbing Remember, never drive diagonally across a hill. Always drive straight up or down. Avoid driving in standing water deeper than NOTE: If the wheels start to slip as you approach the crest 24 inches (61 cm) with air suspension or Before attempting to climb a hill, determine the 21 inches (53 cm) without air suspension, and of a hill, ease off the accelerator and maintain...
  • Page 204 STARTING AND OPERATING After Driving Off-Road After extended operation in mud, sand, water, or  similar dirty conditions, have the radiator, fan, Off-road operation puts more stress on your brake rotors, wheels, brake linings, and axle vehicle than does most on-road driving. After going yokes inspected and cleaned as soon as off-road, it is always a good idea to check for possible.

  • Page 205: Multimedia

    MULTIMEDIA UCONNECT SYSTEMS Your vehicle may be equipped with certain security WARNING! features to reduce the risk of unauthorized and For detailed information about your Uconnect 5/ unlawful access to vehicle systems and wireless ONLY insert trusted devices/components into  5 NAV With 8.4-inch Display or Uconnect 5/5 NAV communications.

  • Page 206: Uconnect Settings

    MULTIMEDIA UCONNECT SETTINGS Press the Vehicle button, then press the Settings USTOMER ROGRAMMABLE EATURES tab on the top of the touchscreen. In this menu, the The Uconnect system uses a combination of Uconnect system allows you to access all of the buttons on the touchscreen and buttons on the available programmable features.
  • Page 207 MULTIMEDIA Display When the Display button is pressed on the touchscreen, the system will display the options related to the theme (if equipped), brightness, and color of the touchscreen. The available settings are: NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description This setting will change the language of the Uconnect system.
  • Page 208 MULTIMEDIA Setting Name Description This setting will allow you to adjust the brightness of your theme. Setting Theme Mode options are “Light”, “Dark” and “Auto”. Select to show themes in Light or Dark mode. “Auto” changes the theme with the headlights. Touchscreen Beep This setting will allow you to turn the touchscreen beep on or off.
  • Page 209 MULTIMEDIA My Profile When the My Profile button is pressed on the touchscreen, the system displays options related to the vehicle’s profiles. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description This setting will change the language of the Uconnect system. The available Language languages are English, French, Spanish, and Italian.
  • Page 210 This setting will allow you to set the system “Wake Up” word. The available Wake Up Word options are “Off”, “Hey, Uconnect”, and “Hey, Jeep®”. This setting will allow Voice Barge-in, which is a feature that will allow you to Voice Barge-in interrupt the help message or system prompts by speaking, to be turned on or off.
  • Page 211 MULTIMEDIA Setting Name Description This setting will activate the vehicle’s comfort system and heated seats or heated steering wheel when the vehicle is remote started or ignition is started. The “Off” setting will not activate the comfort systems. The “Remote Auto-On Driver Heated/Ventilated Seat &...
  • Page 212 MULTIMEDIA Setting Name Description This setting will return all the previously changed settings to their factory Restore Settings to Default defaults. More Profile Options This setting will give access to more profile options. Safety & Driving Assistance When the Safety & Driving Assistance button is pressed on the touchscreen, the system displays the options related to the vehicle’s safety settings. These options will differ depending on the features equipped on the vehicle.
  • Page 213 MULTIMEDIA Setting Name Description Pedestrian Emergency Braking — Located In Automatic Emergency Braking This setting will turn the Pedestrian Emergency Braking system on or off. If Submenu “Off” is selected, an Off icon will display on your Instrument Cluster Display. Active Driving Assist Steering Wheel Vibration This setting will turn the Active Driving Assist Steering Wheel Vibration on or off.
  • Page 214 MULTIMEDIA Setting Name Description This setting will turn the Night Vision Video Warning and green/gray cluster Night Vision Video Warning indicator light on or off. This setting will change the type of ParkSense alert when a close object is ParkSense detected and can provide both an audible chime and a visual display.
  • Page 215 MULTIMEDIA Setting Name Description When this setting is turned on and the rear doors are opened while the engine is Rear Seat Alert running, or if the engine is turned on within 10 minutes of the door opening, a message will appear to check the rear seat when the vehicle is powered OFF. Clock &...
  • Page 216 MULTIMEDIA Phone/Bluetooth® When the Phone/Bluetooth® button is pressed on the touchscreen, the system displays the options related to Bluetooth® connectivity from an external audio device or smartphone. The list of paired audio devices or smartphones can be accessed from this menu. NOTE: Depending on the vehicle’s options, feature settings may vary.
  • Page 217 This setting will allow you to set the system’s “Wake Up” word. The available Wake Up Word options are “Off”, “Hey, Uconnect”, and “Hey, Jeep®”. This setting allows you to respond to a Voice Response before the statement Voice Barge-In is completed by the system.
  • Page 218 MULTIMEDIA Setting Name Description This setting will add a timed delay to the ParkView Backup Camera when ParkView Backup Camera Delay shifting out of REVERSE. ParkView Backup Camera Active Guidelines This setting will turn the ParkView Backup Camera Active Guidelines on or off. Forward Facing Camera Guidelines This setting will turn the Forward Facing Camera Guidelines on or off.
  • Page 219 MULTIMEDIA Lights When the Lights button is pressed on the touchscreen, the system displays the options related to the vehicle’s exterior and interior lights. NOTE: When the “Daytime Running Lights” feature is selected, the daytime running lights can be turned on or off. This feature is only allowed by law in the country ...
  • Page 220 MULTIMEDIA Setting Name Description When the “Greeting Lights” feature is selected, it enables “Headlight Illumination On Approach”. When “Headlight Illumination On Approach” is selected, it allows the adjustment of the amount of time the headlights Greeting Lights remain on after the doors are unlocked with the key fob. “Greeting Lights” must be selected and “Headlight Illumination On Approach”...
  • Page 221 MULTIMEDIA Doors & Locks When the Doors & Locks button is pressed on the touchscreen, the system displays the options related to locking and unlocking the vehicle’s doors. NOTE: The Auto Door Locks feature default condition is enabled. When enabled, the door locks will lock automatically when the vehicle’s speed exceeds 15 mph ...
  • Page 222 MULTIMEDIA Setting Name Description This setting will allow you to turn the Passive Entry feature Passive Entry (Keyless Enter ‘n Go™) on or off. This setting will recall preset radio stations and driver seat position that have Personal Settings Linked To Key Fob been linked to the key fob.
  • Page 223 MULTIMEDIA Setting Name Description This setting will activate the vehicle’s comfort systems and heated seats or heated steering wheel when the vehicle is remote started or ignition is Auto-On Driver Heated/Ventilated Seat & Heated Steering Wheel With Vehicle started. The “Off” setting will not activate the comfort systems. The “Remote Start Start”...
  • Page 224 MULTIMEDIA Setting Name Description This setting will keep the radio on for the selected amount of time after vehicle Radio Off Delay shut off. The available options are “0 sec”, “45 sec”, “5 min”, and “10 min”. This setting will keep the radio on when a door is opened or until the Radio Off Radio Off With Door Delay time is reached.
  • Page 225 MULTIMEDIA Audio When the Audio button is pressed on the touchscreen, the system displays options related to the vehicle’s sound system. These settings can change the audio location within the vehicle, adjust the bass or treble levels, and auto-play settings from an audio device or smartphone. NOTE: Depending on the vehicle’s options, feature settings may vary.
  • Page 226 MULTIMEDIA Notifications When the Notifications button is pressed on the touchscreen, the system displays the options related to Notifications for the system. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description Notification Sounds Turn this setting “On” or “Off” to hear notification sounds throughout your system. App Drawer Favoriting Pop-Ups This setting turns the App Favorited pop-up on or off.
  • Page 227 MULTIMEDIA SiriusXM® Setup When the SiriusXM® Setup button is pressed on the touchscreen, the system displays the options related to SiriusXM® satellite radio. These settings can be used to skip specific radio channels and restart favorite songs from the beginning. NOTE: A subscription to SiriusXM®...
  • Page 228 MULTIMEDIA Software Updates When the Software Updates button is pressed on the touchscreen, the system will display the setting related to updating the Uconnect software. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description This setting will allow software updates to happen over Wi-Fi. Selectable Software Downloads over Wi-Fi options for the setting are “On”...
  • Page 229 MULTIMEDIA Reset When the Reset button is pressed on the touchscreen, the system displays the options related to resetting the Uconnect system back to its default settings. These settings can clear personal data and reset selected settings from other menus. NOTE: Depending on the vehicle’s options, feature settings may vary.

  • Page 230: Steering Wheel Audio Controls

    MULTIMEDIA STEERING WHEEL AUDIO CONTROLS PASSENGER SCREEN — IF EQUIPPED The left-hand control is a rocker-type switch with a push button in the center. The function of the The remote sound system controls are located on Your vehicle may be equipped with a Passenger left-hand control is different depending on which the rear surface of the steering wheel at the three Screen located above the glove compartment on...

  • Page 231: Passenger Screen Permissions

    MULTIMEDIA Navigation When the Passenger Screen is started up and no ASSENGER CREEN ERMISSIONS  other media was running during the last ignition Device Manager  Through the Uconnect system, features within the cycle, the Home screen will display. Here, you can Rear Seat Entertainment —...

  • Page 232: Audio And Video

    MULTIMEDIA Controls Screen The Power Off button will fully shut down the UDIO IDEO Passenger Screen. No audio or video will play From the Controls Screen, you can adjust the from it. daytime/nighttime brightness of the screen, change headphone volume, and power off the Passenger Screen.
  • Page 233 MULTIMEDIA To change the media source, press the Source On the Preset menu, you will be able to listen to button and then press on the desired source. The saved radio presets. Press the desired preset to available sources are: begin listening.

  • Page 234: Rear Seat Entertainment With Amazon Fire Tv Built-In - If Equipped

    MULTIMEDIA Device Manager provides an easy place to view all NTERTAINMENT EVICE ANAGER the devices connected to the Uconnect system and TV B — I MAZON UILT lets you pair the Driver’s smartphone to the QUIPPED Uconnect system. You will also pair Bluetooth® headphones to the Passenger Screen from this Rear Seat Entertainment with Fire TV built-in will let screen.

  • Page 235: Navigation

    MULTIMEDIA Removing Bluetooth® Headphones To launch the app, begin playing audio and follow AMERA these steps: 1. From the Controls screen, press the Manage Camera will display the equipped vehicle camera 1. Press the Apps button. Headphones button. feed. When selected, press the desired Camera 2.

  • Page 236: Rear Seat Entertainment (Rse) With

    MULTIMEDIA Day/Night Mode Press to skip Press to change Skip Backward backward. Press and channel up. Press and Press the Menu button in the upper left-hand hold to fast rewind. hold to seek channel corner to access McIntosh settings. Tap on a Mode up.

  • Page 237: Getting Started

    MULTIMEDIA music, get information, and watch downloaded Fire TV in the vehicle. Streaming service subscrip- There are four different ways to operate the programs all while on the road. Two Voice Remotes tions are not included. Services and features are features of Rear Seat Entertainment with Fire TV with Alexa are included with the system.

  • Page 238: Accessing Rear Seat Entertainment With Fire Tv Built-In From The Rear Screens

    MULTIMEDIA Voice Remote with Alexa Pairing CCESSING CCESSING After the boot-up sequence is complete, the NTERTAINMENT WITH BUILT NTERTAINMENT WITH BUILT system will then give the option to pair a Voice — FROM THE CREENS FROM THE ASSENGER CREEN Remote with Alexa (two are included with the QUIPPED system).

  • Page 239: Alexa Voice Control

    MULTIMEDIA Some options for a network connection are: Parental Controls UICK Wi-Fi Hotspot using a capable smartphone (if Another feature that will appear during this first  Accessing the quick menu will give you more activated, it will show as a possible network for time set up is parental controls.

  • Page 240: Parental Controls (Using The Rear Screens)

    MULTIMEDIA ARENTAL ONTROLS SING THE OICE EMOTE WITH LEXA AIRING EDIA OURCES NPUT SING THE CREENS SING THE CREENS RONT ADIO AND CREENS If parental controls were not set during the first If the Voice Remote with Alexa needs to be paired Front Radio Screen time start up of the system, they can be set by again or a new remote is being paired, follow these...

  • Page 241: Voice Remote With Alexa

    MULTIMEDIA selections and pushing the center button to 15. Channel +/- — Push the up or down arrow OICE EMOTE WITH LEXA button on the Channel button to browse confirm selections. channels available in Fire TV. 3. Back — Push to exit out of menus or return to the previous screen.

  • Page 242: Rear Seat Entertainment With Fire Tv Built-In Streaming (Using The Front Radio And Rear Screens)

    MULTIMEDIA USB Music — Under “USB Music”, music will To access Fire TV on the front screen, select NTERTAINMENT WITH  appear that are options with a USB device “Launch Source” on the front radio rear seat TV B UILT N STREAMING SING THE connected to Rear Seat Entertainment with Fire...

  • Page 243: Fire Tv Apps/Games (Using The Rear Screens)

    MULTIMEDIA TV A Fire TV Home — This will take you back to the Some screen information includes: AMES SING THE  Fire TV home page. Decrease Timing Between Notifications Button CREENS  Menu — This will open the Fire TV menu. ...

  • Page 244: Using The Video Usb Port

    MULTIMEDIA USB P SING IDEO IDEO AMES EADPHONES PERATION Plug in a USB drive or mass storage device and Connect the video game console to either of the Rear Seat Entertainment with Fire TV built-in does play your favorite music or movies. HDMI ports located behind either of the first row not come equipped with headphones.

  • Page 245: Rear Climate Controls

    MULTIMEDIA LIMATE ONTROLS The Rear Climate Controls can also be controlled using Rear Seat Entertainment with Fire TV built-in Ú page 66. Rear Climate Controls can be accessed by using the Vehicle menu. Tap on either rear screen and select the Vehicle icon or press the Vehicle button on the Voice Remote with Alexa.
  • Page 246 MULTIMEDIA Icon Description Headliner Mode Headliner Mode Air comes from the outlets in the headliner. Each of these outlets can be individually adjusted to direct the flow of air. Moving the air vanes of the outlets to one side will shut off the airflow. Bi-Level Mode Bi-Level Mode...

  • Page 247: Legal & Compliance

    MULTIMEDIA & C Off-Road Pages has the following selectable pages: EGAL OMPLIANCE Vehicle Dynamics  To access Legal and Compliance information Accessory Gauges about Rear Seat Entertainment with Fire TV built-in  from the rear screens, follow these steps: Pitch & Roll ...

  • Page 248: Vehicle Dynamics

    MULTIMEDIA & R EHICLE YNAMICS CCESSORY AUGES ITCH The Vehicle Dynamics page displays information The Accessory Gauges page displays the current The Pitch & Roll page displays the vehicle’s current concerning the vehicle’s drivetrain. status of the vehicle’s Coolant Temperature, Oil pitch (angle up and down) and roll (angle side to Temperature, Oil Pressure, Transmission side) in degrees.

  • Page 249: Suspension - If Equipped

    MULTIMEDIA The selectable modes are as follows: will switch to the appropriate height and the Wheel the mobile phone, it is recommended that the Articulation will show the movement and change in volume be turned down or off during mobile phone Rock —...

  • Page 250: Safety

    SAFETY SAFETY FEATURES The ABS is designed to function with the Original WARNING! Equipment Manufacturer (OEM) tires. Modification (ABS) may result in degraded ABS performance. The ABS cannot prevent collisions, including RAKE YSTEM  those resulting from excessive speed in turns, WARNING! The ABS provides increased vehicle stability and following another vehicle too closely, or hydro-...

  • Page 251: Drowsy Driver Detection (Ddd) - If Equipped

    SAFETY If the ABS Warning Light is on, the brake system System Operation NOTE: should be serviced as soon as possible to restore In the event of a DDD system failure, a dedicated Using feedback obtained from the driver’s steering the benefits of Anti-Lock Brakes.

  • Page 252: Electronic Brake Control (Ebc) System

    SAFETY Electronic Roll Mitigation (ERM), Electronic WARNING! WARNING! Stability Control (ESC), Hill Start Assist (HSA), and Traction Control System (TCS). These systems work Before exiting a vehicle, always come to a The Brake Assist System (BAS) cannot prevent  together to enhance both vehicle stability and complete stop, then shift the automatic trans- the natural laws of physics from acting on the control in various driving conditions.
  • Page 253 SAFETY Electronic Brake Force Distribution (EBD) Oversteer — when the vehicle is turning more  WARNING! than appropriate for the steering wheel position. EBD manages the distribution of the braking Many factors, such as vehicle loading, road Understeer — when the vehicle is turning less torque between the front and rear axles by limiting ...
  • Page 254 SAFETY ESC Operating Modes WARNING! WARNING! Depending upon model and mode of operation, the Electronic Stability Control (ESC) cannot prevent When in “Partial Off” mode, the TCS function-   ESC system may have multiple operating modes. the natural laws of physics from acting on the ality of ESC (except for the limited slip feature ESC On vehicle, nor can it increase the traction afforded by...
  • Page 255 SAFETY The ESC Activation/Malfunction Indicator Light Hill Descent Control (HDC) — If Equipped Activating HDC starts to flash as soon as the tires lose traction and Once HDC is enabled it will activate automatically HDC is intended for low speed off-road the ESC system becomes active.
  • Page 256 SAFETY Hill Start Assist (HSA) Driver Override Feedback To The Driver The driver may override HDC activation with The instrument cluster has an HDC icon and the HSA is designed to mitigate roll back from a throttle or brake application at any time. HDC switch has an LED icon, which offers feedback complete stop while on an incline.
  • Page 257 SAFETY Ready Alert Braking (RAB) WARNING! WARNING! RAB may reduce the time required to reach full There may be situations where the Hill Start If you use a trailer brake controller with your  braking during emergency braking situations. It Assist (HSA) will not activate and slight rolling trailer, the trailer brakes may be activated and anticipates when an emergency braking situation...
  • Page 258 SAFETY Enabling SSC SSC Target Set Speeds Driver Override: SSC is enabled by pushing the SSC switch, but the 1st = .6 mph (1 km/h) The driver may override SSC activation with throttle  following conditions must also be met to enable or brake application at any time.
  • Page 259 SAFETY Feedback To The Driver: Traction Control System (TCS) NOTE: TSC cannot stop all trailers from swaying. Always The instrument cluster has an SSC icon and the The TCS monitors the amount of wheel spin of use caution when towing a trailer and follow the SSC switch has an LED which offer feedback to the each of the driven wheels.

  • Page 260: Auxiliary Driving Systems

    SAFETY AUXILIARY DRIVING SYSTEMS The BSM detection zone covers approximately one The BSM system can become blocked if snow, ice, lane in width on both sides of the vehicle 12 ft mud, or other road contaminations accumulate on (3.8 m). The zone length starts at the side of the the rear fascia/bumper where the radar sensors (BSM) LIND...
  • Page 261 SAFETY The BSM system notifies the driver of objects in the Overtaking Traffic detection zones by illuminating the BSM Warning If you pass another vehicle slowly with a relative Light located in the outside mirrors. In addition, speed of less than 15 mph (24 km/h) the warning when the turn signal is activated during the alert on light will be illuminated.
  • Page 262 SAFETY Rear Cross Path (RCP) NOTE: The BSM system is designed not to issue an alert on stationary objects such as guardrails, posts, walls, In a parking lot situation, oncoming vehicles can be RCP is intended to aid the driver when backing out foliage, berms, etc.

  • Page 263: Forward Collision Warning (Fcw)

    SAFETY Blind Spot Alert Lights Only When the system is in RCP, the system shall NOTE: respond with both visual and audible alerts when a If either FCW or Pedestrian Emergency Braking When operating in Blind Spot Alert mode, the BSM detected object is present.
  • Page 264 SAFETY FCW Braking Status And Sensitivity If a Forward Collision Warning with Mitigation event The FCW alerts may be triggered on objects  begins at a speed below 39 mph (62 km/h), the other than vehicles, such as guardrails or sign The FCW Sensitivity and Active Braking status are system may provide maximum braking to mitigate posts based on the course prediction.
  • Page 265 SAFETY The “Near” setting may result in a lesser FCW Limited Warning number of FCW possible collision warnings If the instrument cluster displays “Automatic experienced. Emergency Braking (AEB) Limited Service NOTE: Required” or “Limited Functionality Clean Front Windshield” momentarily, there may be a Changing the FCW status to “Only Warning”...

  • Page 266: Tire Pressure Monitoring System (Tpms)

    SAFETY NOTE: The tire pressure will vary with temperature by about WARNING! 1 psi (7 kPa) for every 12°F (6.5°C). This means that The PEB system will retain the last setting selected when the outside temperature decreases, the tire by the driver after ignition shut down. The system Pedestrian Emergency Braking (PEB) is not pressure will decrease.
  • Page 267 SAFETY NOTE: NOTE: CAUTION! When filling warm tires, the tire pressure may need The TPMS is not intended to replace normal tire  to be increased up to an additional 4 psi (28 kPa) The TPMS has been optimized for the original ...
  • Page 268 SAFETY The Tire Pressure Monitoring System (TPMS) uses Various Tire Pressure Monitoring System Should a low tire condition occur on any of the four  wireless technology with wheel rim-mounted messages, which display in the instrument active road tire(s), you should stop as soon as electronic sensors to monitor tire pressure levels.
  • Page 269 SAFETY Service TPMS Warning NOTE: In addition, the Tire Pressure Monitoring System Warning Light will turn off and the graphic in the A TPMS sensor is not offered on any size spare tire. The Tire Pressure Monitoring System Warning Light instrument cluster display will display a new In either option of having a full size spare equipped will flash on and off for 75 seconds, and remain on...
  • Page 270 SAFETY Beginning with the next ignition cycle, the TPMS flashing or 26-30 seconds after the desired Operation: will no longer chime or display the “SERVICE TPM pressure is achieved in one wheel before The horn will chirp once to let the user know ...

  • Page 271: Occupant Restraint Systems

    SAFETY In the Selectable Tire Fill Alert application, which is transmission. The hazard lamps will come on to CCUPANT ESTRAINT YSTEMS located in the apps menu of the Uconnect system, confirm the vehicle is in Tire Fill Alert mode. EATURES you will be able to select a pressure setting for both When Tire Fill Alert mode is entered, the tire the front and rear axle tire pressures by scrolling...

  • Page 272: Seat Belt Systems

    SAFETY Enhanced Seat Belt Use Reminder System 3. If a child from 2 to 12 years old (not in a WARNING! rear-facing child restraint) must ride in the (BeltAlert) front passenger seat, move the seat as far Never place a rear-facing child restraint in ...
  • Page 273 SAFETY outboard front passenger seat is unoccupied). The NOTE: WARNING! BeltAlert warning sequence starts by blinking the If BeltAlert has been deactivated and the driver or Seat Belt Reminder Light and sounding an outboard front seat passenger (if equipped with In a collision, you and your passengers can ...
  • Page 274 SAFETY WARNING! WARNING! WARNING! Wearing your seat belt incorrectly could make A twisted seat belt may not protect you prop- A shoulder belt placed behind you will not    your injuries in a collision much worse. You erly. In a collision, it could even cut into you. protect you from injury during a collision.
  • Page 275 SAFETY Lap/Shoulder Belt Operating Instructions 5. Position the shoulder belt across the shoulder and chest with minimal, if any slack so that it 1. Enter the vehicle and close the door. Sit back is comfortable and not resting on your neck. and adjust the seat.
  • Page 276 SAFETY Adjustable Upper Shoulder Belt Anchorage NOTE: Seat Belt Extender The adjustable upper shoulder belt anchorage is In the driver and outboard front passenger seats, If a seat belt is not long enough to fit properly, even equipped with an Easy Up feature. This feature the top of the shoulder belt can be adjusted when the webbing is fully extended and the allows the shoulder belt anchorage to be adjusted...
  • Page 277 SAFETY Seat Belts And Pregnant Women from the seat belt early in a collision. Pretensioners work for all size occupants, including those in child restraints. NOTE: These devices are not a substitute for proper seat belt placement by the occupant. The seat belt still must be worn snugly and positioned properly.
  • Page 278 SAFETY How To Disengage The Automatic Locking Mode restraint is installed in a seating position that has a seat belt with this feature. Children 12 years old Unbuckle the combination lap/shoulder belt and and under should always be properly restrained in allow it to retract completely to disengage the the rear seat of a vehicle with a rear seat.

  • Page 279: Supplemental Restraint Systems (Srs)

    SAFETY Third Row Stow Clip — If Equipped Air Bag System Components WARNING! Six And Seven Passenger Only Occupant Restraint Controller (ORC)  Do not place the seat belt webbing behind the Your vehicle may be equipped with a stow clip on Air Bag Warning Light third row stow clip when using the seat belt to ...
  • Page 280 SAFETY NOTE: The ORC contains a backup power supply system have an authorized dealer service the vehicle that may deploy the air bag system even if the immediately Ú page 108. If the speedometer, tachometer, or any engine battery loses power or it becomes disconnected related gauges are not working, the Occupant Front Air Bags prior to deployment.
  • Page 281 SAFETY The first stage inflator is triggered immediately WARNING! WARNING! during an impact that requires air bag deployment. A low energy output is used in less severe Being too close to the steering wheel or instru- Do not put anything on or around the air bag ...
  • Page 282 SAFETY On the other hand, depending on the type and The Occupant Classification System (OCS) consists The front passenger seat is occupied by a small  location of impact, front air bags may deploy in of the following: passenger, including a child; or crashes with little vehicle front-end damage but Occupant Restraint Controller (ORC) The front passenger seat is occupied by a...
  • Page 283 SAFETY In order for the OCS to operate as designed, it is Lighter Weight Passengers (Including Small Adults) WARNING! important for the front passenger to be seated When a lighter weight passenger, including a small properly and properly wearing the seat belt. Never place a rear-facing child restraint in ...
  • Page 284 SAFETY Examples of improper front passenger seating include: The front passenger’s weight is transferred to  another part of the vehicle (like the door, arm rest or instrument panel). The front passenger leans forward, sideways, or  turns to face the rear of the vehicle. The front passenger’s seatback is not in the full ...
  • Page 285 SAFETY Always use the correct seat cover and cushion The Air Bag Warning Light in the instrument WARNING! specified for the vehicle. panel will turn on whenever the OCS is unable to If a child restraint system, child, small teen- classify the front passenger seat status.
  • Page 286 SAFETY Knee Impact Bolsters Supplemental Seat-Mounted Side Air Bags (SABs) WARNING! are located in the outboard side of the front seats. The Knee Impact Bolsters help protect the knees The SABs are marked with “SRS AIRBAG” or Do not use accessory seat covers or place of the driver and front passenger, and position the “AIRBAG”...
  • Page 287 SAFETY SABICs may help reduce the risk of head and other The Side Air Bags will not deploy in all side WARNING! collisions, including some collisions at certain injuries to front and rear seat outboard occupants in certain side impacts, in addition to the injury angles, or some side collisions that do not impact In order for the SABICs to work as intended, do ...
  • Page 288 SAFETY The Side Air Bags and seat belt pretensioners will Supplemental Knee Air Bags  WARNING! not deploy in all rollover events. The rollover Front and Side Impact Sensors  sensing system determines if a rollover event may Side Air Bags need room to inflate. Do not lean ...
  • Page 289 SAFETY As the air bags deflate, you may see some Enhanced Accident Response System Electric park brake   smoke-like particles. The particles are a normal Automatic transmission gear selector In the event of an impact, if the communication  by-product of the process that generates the network remains intact, and the power remains Horn...
  • Page 290 SAFETY Event Data Recorder (EDR) After an accident, if the vehicle will not start after WARNING! performing the reset procedure, the vehicle must This vehicle is equipped with an event data be towed to an authorized dealer to be inspected Do not attempt to modify any part of your air ...

  • Page 291: Child Restraints

    SAFETY NOTE: Children 12 years or younger should ride properly Before buying any restraint system, make sure that it has a label certifying that it meets all applicable EDR data are recorded by your vehicle only if a buckled up in a rear seat, if available. According to crash statistics, children are safer when properly Safety Standards.
  • Page 292 SAFETY Summary Of Recommendations For Restraining Children In Vehicles Child Size, Height, Weight Or Age Recommended Type Of Child Restraint Children who are two years old or younger and who Either an Infant Carrier or a Convertible Child Infants and Toddlers have not reached the height or weight limits of their Restraint, facing rearward in a rear seat of the child restraint...
  • Page 293 SAFETY Older Children And Child Restraints 2. Do the child’s knees bend comfortably over WARNING! the front of the vehicle seat while the child is Children who are two years old or who have still sitting all the way back? After a child restraint is installed in the ...
  • Page 294 SAFETY Recommendations For Attaching Child Restraints Use Any Attachment Method Shown With An “X” Below Combined Weight of LATCH – Lower Restraint Type the Child + Child LATCH – Lower Seat Belt + Top Tether Seat Belt Only Anchors + Top Tether Restraint Anchors Only Anchor...
  • Page 295 SAFETY LATCH Positions For Installing Child Restraints In This Vehicle Captain’s Chairs Second Row LATCH Positions 60/40 Second Row LATCH Positions (7 Passenger) (6 Passenger) Lower Anchorage Symbol (2 Anchorages Per Lower Anchorage Symbol (2 Anchorages Per Seating Position) Second Row LATCH Positions (5 Passenger) Seating Position) Top Tether Anchorage Symbol Lower Anchorage Symbol (2 Anchorages Per...
  • Page 296 SAFETY Frequently Asked Questions About Installing Child Restraints With LATCH Use the LATCH anchorage system until the combined weight of What is the weight limit (child’s weight + weight of the child the child and the child restraint is 65 lb (29.5 kg). Use the seat restraint) for using the LATCH anchorage system to attach the child 65 lb (29.5 kg) belt and tether anchor instead of the LATCH system once the...
  • Page 297 SAFETY Locating The LATCH Anchorages Locating The Upper Tether Anchorages The lower anchorages are round bars Five, Six, And Seven Passenger Vehicles: that are found at the rear of the seat Second Row Upper Tether Anchorage cushion where it meets the seatback. Locations The anchorages are under a flap with the There are tether strap anchorages behind each rear...
  • Page 298 SAFETY LATCH-compatible child restraint systems will be equipped with a rigid bar or a flexible strap on each side. Each will have a hook or connector to attach to the lower anchorage and a way to tighten the connection to the anchorage. Forward-facing child restraints and some rear-facing child restraints will also be equipped with a tether strap.
  • Page 299 SAFETY Six Passenger Second Row Seating: To Install A LATCH-Compatible Child 5. Tighten all of the straps as you push the child restraint rearward and downward into the Restraint WARNING! seat. Remove slack in the straps according to If the selected seating position has a Switchable the child restraint manufacturer’s instructions.
  • Page 300 SAFETY Installing Child Restraints Using The The seat belts in the passenger seating positions WARNING! are equipped with a Switchable Automatic Locking Vehicle Seat Belt Retractor (ALR) that is designed to keep the lap Improper installation of a child restraint to the ...
  • Page 301 SAFETY Lap/Shoulder Belt Systems For Installing Child Restraints In This Vehicle Captain’s Chairs Second Row (6 Passenger) Automatic 60/40 Second Row (7 Passenger) Automatic Locking Locking Retractor (ALR) Locations Retractor (ALR) Locations ALR — Switchable Automatic Locking Retractor ALR — Switchable Automatic Locking Retractor 5 Passenger Automatic Locking Retractor (ALR) Locations Top Tether Anchorage Symbol Top Tether Anchorage Symbol...
  • Page 302 SAFETY Installing A Child Restraint With A 2. Pull enough of the seat belt webbing from the 9. Test that the child restraint is installed tightly retractor to pass it through the belt path of the by pulling back and forth on the child seat at Switchable Automatic Locking Retractor child restraint.
  • Page 303 SAFETY Five Passenger Six And Seven Passenger 1. Look behind the seating position where you 1. Look behind the seating position where you plan to install the child restraint to find the plan to install the child restraint to find the tether anchorage.
  • Page 304 SAFETY Third Row Top Tether Strap Anchorage Second Row Bench Seat Top Tether Strap Mounting Third Row Seating Top Tether Strap Mounting (Located On Seatback) (5 And 7 Passenger Seating) 6. Remove slack in the tether strap according to the child restraint manufacturer’s instructions. 3.

  • Page 305: Safety Tips

    SAFETY RANSPORTING AFETY HECKS HOULD WARNING! NSIDE EHICLE Air Bags deploying in the front seat could harm If your vehicle is equipped with a split rear  your pet. An unrestrained pet will be thrown about seat, make sure the tether strap does not slip Seat Belts and possibly injured, or injure a passenger during into the opening between the seatbacks as...
  • Page 306 SAFETY Defroster WARNING! WARNING! Check operation by selecting the defrost mode and ALWAYS securely attach your floor ONLY use the driver’s side floor mat on the   place the blower control on high speed. You should mat using the floor mat fasteners. DO driver’s side floor area.

  • Page 307: Periodic Safety Checks You Should Make Outside The Vehicle

    SAFETY Fluid Leaks ERIODIC AFETY HECKS HOULD WARNING! Check area under the vehicle after overnight UTSIDE EHICLE NEVER place any objects under the floor mat  parking for fuel, coolant, oil, or other fluid leaks. (e.g., towels, keys, etc.). These objects could Tires Also, if gasoline fumes are detected or if fuel or change the position of the floor mat and may...

  • Page 308: Carbon Monoxide Warnings

    SAFETY The best protection against carbon monoxide entry ARBON ONOXIDE ARNINGS WARNING! into the vehicle body is a properly maintained engine exhaust system. Guard against carbon monoxide with proper  WARNING! maintenance. Have the exhaust system Whenever a change is noticed in the sound of the Carbon monoxide (CO) in exhaust gases is inspected every time the vehicle is raised.

  • Page 309: In Case Of Emergency

    4G (data) network, which comes as a oncoming traffic of an emergency. Push the switch built-in function. Other Jeep® Connect services a second time to turn off the Hazard Warning ASSIST And SOS Buttons will only be operable if you are connected to an Flashers.
  • Page 310 The last known GPS coordinates of the  5. The SOS operator may attempt to contact Jeep® Connect Customer Care – Total support vehicle  for Radio, Phone and NAV issues. appropriate emergency responders and 4.
  • Page 311  (INCLUDING DURING OR AFTER AN ACCI- mean you will not have SOS Call services. If DENT), THE JEEP® CONNECT FEATURES, Equipment malfunction at the SOS operator facility  the overhead console light is illuminated, have APPS AND SERVICES, AMONG OTHERS, WILL Operator error by the SOS operator ...

  • Page 312: Jacking And Tire Changing

    IN CASE OF EMERGENCY WARNING! CAUTION! WARNING! ALWAYS obey traffic laws and pay attention to To avoid damage to the mirror during cleaning, Do not attempt to change a tire on the side of  the road. ALWAYS drive safely with your hands on never spray any cleaning solution directly onto the vehicle close to moving traffic.

  • Page 313: Preparations For Jacking

    IN CASE OF EMERGENCY NOTE: 1. Locate and lift up on the load floor handle. Before changing a tire or using the jack please disable the hands free lift gate, This feature can be disabled through the Uconnect system Ú page 219. REPARATIONS ACKING 1.
  • Page 314 IN CASE OF EMERGENCY 3. Remove the jack storage cover. To remove, firmly press the two side tabs inward while lifting up or out. Jack Storage Location Jack Removal (Third Row Seating Without Air Suspension) (Third Row Seating Without Air Suspension) Jack Storage Cover Tabs 4.

  • Page 315: Spare Tire Stowage

    IN CASE OF EMERGENCY 5. Jack And Tools Description Second Row Seating — If Equipped For vehicles equipped with second row seating, the spare tire is located in the rear cargo area under the load floor. Spare Tire Location (Third Row Seating) Jack And Tools CAUTION! 1 —...
  • Page 316 IN CASE OF EMERGENCY Second Row Seating — If Equipped 3. After removing the fastener, pull the spare tire up away from the fastener pin and out of the 1. Lift up on the rear load floor to access the spare vehicle.

  • Page 317: Jacking Instructions

    IN CASE OF EMERGENCY ACKING NSTRUCTIONS WARNING! If working on or near a roadway, be extremely  WARNING! careful of motor traffic. Carefully follow these tire changing warnings to To assure that spare tires, flat or inflated, are  help prevent personal injury or damage to your securely stowed, spares must be stowed with vehicle: the valve stem facing the ground.
  • Page 318 IN CASE OF EMERGENCY NOTE: 1. Loosen (but do not remove) the wheel lug nuts, using the lug wrench by turning them Proper placement for the front and rear jacking counterclockwise, one turn, while the wheel is locations is critical. See the following images for still on the ground.
  • Page 319 IN CASE OF EMERGENCY 4. For a rear tire, place the jack in the slot on the CAUTION! rear tie-down bracket, just forward of the rear tire (as indicated by the triangular lift point Be sure to mount the spare tire with the valve symbol on the sill molding).
  • Page 320 IN CASE OF EMERGENCY Second Row Seating — If Equipped 9. Finish tightening the lug nuts. Push down on 12. After 25 miles (40 km), check the lug nut the wrench while at the end of the handle for torque with a torque wrench to ensure that all 1.

  • Page 321: Jump Starting

    IN CASE OF EMERGENCY JUMP STARTING Third Row Seating — If Equipped 1. Position the wheel behind the rear fascia/ If your vehicle has a discharged battery, it can be bumper facing outward. Push the end of the jump started using a set of jumper cables and a winch’s cable, spring and steel sleeve battery in another vehicle, or by using a portable through the back of the road wheel.

  • Page 322: Preparations For Jump Start

    IN CASE OF EMERGENCY 1. Apply the parking brake, shift the automatic REPARATIONS TART WARNING! transmission into PARK (P) and turn the The battery in your vehicle is located under the ignition OFF. Remove any metal jewelry such as rings, ...

  • Page 323: Refueling In Emergency

    IN CASE OF EMERGENCY Connecting The Jumper Cables CAUTION! CAUTION! 1. Connect the positive (+) end of the jumper Do not run the booster vehicle engine above Accessories plugged into the vehicle power cable to the remote positive (+) post of the 2,000 RPM since it provides no charging benefit, outlets draw power from the vehicle’s battery, discharged vehicle.

  • Page 324: If Your Engine Overheats

    IN CASE OF EMERGENCY IF YOUR ENGINE OVERHEATS NOTE: 3. Ensure funnel is inserted fully to hold flapper doors open. In certain cold conditions, ice may prevent the fuel If the vehicle is overheating, it will need to be door from opening. If this occurs, lightly push 4.

  • Page 325: Manual Park Release

    IN CASE OF EMERGENCY In the event it is observed that the temperature To move the vehicle in cases where the CAUTION! gauge is moving towards or close to the HOT (H) transmission will not shift out of PARK (P) (such as position, you can reduce the potential for a depleted battery), a Manual Park Release is Driving with a hot cooling system could damage...
  • Page 326 IN CASE OF EMERGENCY NOTE: To Reset The Manual Park Release: Insert the flathead screwdriver or similar tool in the 1. Apply firm pressure to the brake pedal while lower notch of the access cover and gently rotate seated in the driver’s seat. clockwise to remove.

  • Page 327: Freeing A Stuck Vehicle

    IN CASE OF EMERGENCY FREEING A STUCK VEHICLE NOTE: CAUTION! Push the ESC OFF button to place the Electronic If your vehicle becomes stuck in mud, sand or Stability Control (ESC) system in “Partial OFF” Racing the engine or spinning the wheels may ...

  • Page 328: Towing A Disabled Vehicle

    IN CASE OF EMERGENCY TOWING A DISABLED VEHICLE This section describes procedures for towing a disabled vehicle using a commercial towing service. If the transmission and drivetrain are operable, disabled 4x4 vehicles may also be towed as described on Ú page 195. Four-Wheel Drive Models Four-Wheel Drive Models Towing Condition...

  • Page 329: Rear-Wheel Drive Models

    IN CASE OF EMERGENCY NOTE: If you must use the accessories (wipers, HEEL RIVE ODELS defrosters, etc.) while being towed, the ignition You must ensure that the Auto Park Brake  FCA US LLC recommends towing your vehicle with must be in the ON/RUN mode. Ú...

  • Page 330: Four-Wheel Drive Models

    IN CASE OF EMERGENCY — If the transmission is not operable, or the vehicle Vehicles equipped with a single-speed transfer MERGENCY OOKS must be towed faster than 30 mph (48 km/h) or case have no NEUTRAL (N) position, and therefore QUIPPED farther than 30 miles (48 km), tow with the rear must be towed will all four wheels OFF the ground.

  • Page 331: Enhanced Accident Response System (Ears)

    IN CASE OF EMERGENCY ENHANCED ACCIDENT RESPONSE SYSTEM NOTE: WARNING! For off road recovery, it is recommended to use (EARS) both of the front tow hooks to minimize the risk of Do not use a chain for freeing a stuck vehicle. ...

  • Page 332: Servicing And Maintenance

    SERVICING AND MAINTENANCE SCHEDULED SERVICING An authorized dealer will reset the oil change Once A Month Or Before A Long Trip: indicator message after completing the scheduled Check engine oil level.  Your vehicle is equipped with an automatic oil oil change.

  • Page 333: Maintenance Plan

    SERVICING AND MAINTENANCE AINTENANCE Refer to the Maintenance Plan for the required maintenance intervals. At Every Oil Change Interval As Indicated By Oil Change Indicator System: Change oil and filter.  Rotate the tires at the first sign of irregular wear, even if it occurs before the oil indicator system turns on. ...
  • Page 334 SERVICING AND MAINTENANCE Mileage Or Time Passed (Whichever Comes First) Or Years: Or Kilometers: Inspect the front and rear axle fluid, change if using your vehicle for police, taxi, fleet, off-road or frequent trailer towing. Inspect the brake linings, parking brake function.
  • Page 335 SERVICING AND MAINTENANCE Mileage Or Time Passed (Whichever Comes First) Or Years: Or Kilometers: Inspect accessory drive belt tensioner and pulley, replace if necessary. Change transfer case fluid - Normal Usage. Change transfer case fluid — Severe Usage (police, taxi, fleet, off-road, or frequent trailer towing.) Replace PCV valve.

  • Page 336: Engine Compartment

    SERVICING AND MAINTENANCE ENGINE COMPARTMENT 2.0L E NGINE 1 — Washer Fluid Reservoir Cap 5 — Brake Fluid Reservoir Access 2 — Power Distribution Center (Fuses) 6 — Engine Coolant Pressure Cap 3 — Engine Oil Dipstick 7 — Intercooler Coolant Reservoir Cap 4 —...

  • Page 337: L Engine

    SERVICING AND MAINTENANCE 3.6L E NGINE 1 — Washer Fluid Reservoir Cap 5 — Engine Oil Filter Access 2 — Power Distribution Center (Fuses) 6 — Engine Oil Fill 3 — Engine Coolant Pressure Cap 7 — Brake Fluid Reservoir Access 4 —...

  • Page 338: L Engine

    SERVICING AND MAINTENANCE 5.7L E NGINE 1 — Washer Fluid Reservoir Cap 5 — Brake Fluid Reservoir Access 2 — Power Distribution Center (Fuses) 6 — Engine Oil Dipstick 3 — Engine Coolant Pressure Cap 7 — Engine Air Cleaner Filter 4 —...

  • Page 339: Checking Oil Level

    SERVICING AND MAINTENANCE NOTE: NOTE: HECKING EVEL Use care when filling under hood fluids such as Use care when filling under hood fluids such as To ensure proper engine lubrication, the engine oil engine oil, washer fluid, antifreeze, etc., to engine oil, washer fluid, antifreeze, etc., to must be maintained at the correct level.

  • Page 340: Maintenance-Free Battery

    SERVICING AND MAINTENANCE VEHICLE MAINTENANCE AINTENANCE ATTERY CAUTION! Your vehicle is equipped with a maintenance-free An authorized dealer has the qualified service It is essential when replacing the cables on  battery. Water will never have to be added, and personnel, special tools, and equipment to the battery that the positive cable is attached periodic maintenance is not required.

  • Page 341: Engine Oil Filter

    SERVICING AND MAINTENANCE NOTE: NGINE ILTER CAUTION! Hemi engines at times can tick right after startup The engine oil filter should be replaced with a new and then quiet down after approximately 30 Do not use chemical flushes in your engine oil as filter at every engine oil change.

  • Page 342: Air Conditioner Maintenance

    SERVICING AND MAINTENANCE Engine Air Cleaner Filter Selection Engine Air Cleaner Filter Installation WARNING! The quality of replacement engine air cleaner NOTE: Use only refrigerants and compressor lubri-  filters varies considerably. Only high quality Inspect and clean the housing assembly if signif- cants approved by the manufacturer for your Mopar®...
  • Page 343 SERVICING AND MAINTENANCE Refrigerant Recovery And Recycling — The cabin air filter is located in the fresh air inlet 3. With the glove compartment door loose, behind the glove compartment. Perform the remove the glove compartment tension tether R–1234yf following procedure to replace the filter: and tether clip by sliding the clip toward the R–1234yf Air Conditioning Refrigerant is a face of the glove compartment door and lifting...

  • Page 344: Accessory Drive Belt Inspection

    SERVICING AND MAINTENANCE 8. Lift the glove compartment door up and When inspecting accessory drive belts, small reattach the tension tether by inserting the cracks that run across ribbed surface of belt from tether clip in the glove compartment and rib to rib, are considered normal.

  • Page 345: Body Lubrication

    SERVICING AND MAINTENANCE Belt broken (identify and correct problem before The external lock cylinders should be lubricated The wiper blades and wiper arms should be  twice a year, preferably in the Autumn and Spring. new belt is installed) inspected periodically, not just when wiper Apply a small amount of a high quality lubricant, performance problems are experienced.
  • Page 346 SERVICING AND MAINTENANCE 1. Lift the wiper arm to raise the wiper blade off of the glass, until the wiper arm is in the full up position. Wiper Blade With Release Tab In Unlocked Position Wiper Blade Removed From Wiper Arm 1 —...

  • Page 347: Exhaust System

    SERVICING AND MAINTENANCE 4. Slide the wiper blade up into the hook on the the wiper blade away from the wiper arm past Installing The Rear Wiper wiper arm and rotate the wiper blade until it is its stop (far enough to unsnap the wiper blade 1.

  • Page 348: Cooling System

    SERVICING AND MAINTENANCE To minimize the possibility of catalytic converter WARNING! CAUTION! damage: Exhaust gases can injure or kill. They contain Damage to the catalytic converter can result if   Do not interrupt the ignition when the transmis-  Carbon Monoxide (CO), which is colorless and your vehicle is not kept in proper operating sion is in gear and the vehicle is in motion.
  • Page 349 SERVICING AND MAINTENANCE Cooling System — Drain, Flush And Refill coolant (conforming to MS.90032), by an autho- WARNING! rized dealer as soon as possible. NOTE: When working near the radiator cooling fan,  Do not use water alone or alcohol-based engine ...
  • Page 350 SERVICING AND MAINTENANCE Please review these recommendations for using excess fluid that is spilled onto the top of the WARNING! Organic Additive Technology (OAT) engine coolant engine should be removed using compressed that meets the requirements of the manufacturer air or an absorbent cloth. Do not open a hot engine cooling system.
  • Page 351 SERVICING AND MAINTENANCE coolant (antifreeze) in the bottle should be With the engine OFF and cold, the level of the Cooling System Notes between the ranges indicated on the bottle. engine coolant should be within the OK range NOTE: between the ADD and FULL range on the dipstick. The radiator normally remains completely full, so When the vehicle is stopped after a few miles/kilo- there is no need to remove the radiator/coolant...

  • Page 352: Brake System

    SERVICING AND MAINTENANCE Fluid Level Check — Brake Master Cylinder Make sure that the coolant expansion bottle  WARNING! overflow hoses are not kinked or obstructed. The fluid level of the master cylinder should be To avoid contamination from foreign matter or Keep the front of the radiator clean.

  • Page 353: Automatic Transmission

    SERVICING AND MAINTENANCE UTOMATIC RANSMISSION CAUTION! CAUTION! Special Additives If a transmission fluid leak occurs, visit an Using a transmission fluid other than the authorized dealer immediately. Severe manufacturer’s recommended fluid may cause The manufacturer strongly recommends against transmission damage may occur. An authorized deterioration in transmission shift quality and/or using any special additives in the transmission.

  • Page 354: Transfer Case

    SERVICING AND MAINTENANCE Rear Axle Fluid Level Check Adding Fluid USES The rear axle oil level needs to be no lower than Add fluid at the filler hole, until it runs out of the General Information 1/8 inch (3 mm) below the bottom of the fill hole. hole, when the vehicle is in a level position.
  • Page 355 SERVICING AND MAINTENANCE The fuses protect electrical systems against CAUTION! CAUTION! excessive current. If it is necessary to wash the engine When installing the power distribution center When a device does not work, you must check the compartment, take care not to directly hit the cover, it is important to ensure the cover is fuse element inside the blade fuse for a break/ fuse box, and the windshield wiper motor with...
  • Page 356 SERVICING AND MAINTENANCE Power Distribution Center NOTE: Fuses for safety systems must be serviced by an authorized dealer.
  • Page 357 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped – – Crank Batt – – Spare 500 Amp Gray – Starter 250 Amp Gray – Alternator – – Spare – – Aux Battery Input 100 Amp Gray –...
  • Page 358 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped 30 Amp Pink – BSM Valves #2* – – Not Populated – – Not Populated – – Not Populated F23A ECM / EPS / PIM / SLM / GPF –...
  • Page 359 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped – – Not Populated – – Not Populated – 5 Amp Tan Battery Sensor #1 – 20 Amp Yellow CADM MAP* – – Not Populated – 10 Amp Red Engine Control Module (ECM) –...
  • Page 360 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped – – Not Populated – – Not Populated – – Not Populated – – Not Populated – – Not Populated – 20 Amp Yellow Camera Washer Front – 15 Amp Blue Smart Bar Control Module ACT Grille Shutter / ACT Rear Axle...
  • Page 361 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped – 20 Amp Yellow TCM SBW – 20 Amp Yellow – 10 Amp Red Fuel Door / ELCM / Fuel Injectors * 20 Amp Blue – 40 Amp Green –...
  • Page 362 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped – – Not Populated – – Not Populated – – Not Populated F100A – – Not Populated F100B – – Not Populated F101 – – Not Populated F102 –...
  • Page 363 SERVICING AND MAINTENANCE Interior Power Distribution Center NOTE: Fuses for safety systems must be serviced by an The Interior Power Distribution Center is located authorized dealer. underneath the steering column on the driver’s side of the vehicle. This center contains cartridge fuses, micro fuses, relays, and circuit breakers.
  • Page 364 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped 40 Amp Green – HVAC Blower Motor – – Spare – 20 Amp Yellow Assy Cigar Lighter Assy Mirror Inside Rearview / Digital TV (DTV) */ Sunroof Single - Dual –...
  • Page 365 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped – – Spare – – Spare – – Spare – – Spare – – Spare – – Spare – – Spare – – Spare MOD ICS Switch Bank / SW Bank –...
  • Page 366 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped MOD Occupant Class / Steering F41A Column Lock – 10 Amp Red F41B Spare Parktronics System MOD (PTS) / MOD F42A Haptic Lane Feedback / Trailer Tow Module –...
  • Page 367 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped Telematics Box Module (TBM) / MOD F50A Front Passenger Display Module – 10 Amp Red (FPDM) / MOD DCSD* F50B Port Diagnostics 1 & 2 F51A – – Spare F51B –...
  • Page 368 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped Media HUB #1 Frt / Port UC1 Dual F63A USB Frt / Wireless Charging Pad MOD – 15 Amp Blue (WCPM) F63B Not Populated F64A MOD ORC – 10 Amp Red Steering Column Control Module F64B...
  • Page 369 SERVICING AND MAINTENANCE Rear Power Distribution Center The Rear Power Distribution Center is located underneath the passenger seat. This center contains cartridge fuses, micro fuses, relays, and circuit breakers. The following chart corresponds to the fuses inside. NOTE: Fuses for safety systems must be serviced by an authorized dealer. Cavity Cartridge Fuse Micro Fuse...
  • Page 370 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped F15A Spare – 10 Amp Red Hands-Free Liftgate / Rear Window F15B Switches / MOD HVAC Cntrl Frt – – Spare 40 Amp Green – Mod BCM Feed #3 30 Amp Pink –...
  • Page 371 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped MOD ICS Switch Bank Rear (Frt F29A Console) – 10 Amp Red F29B Spare MOD Memory / Power Seat (Driver 30 Amp Pink – Frt) – – Spare –...
  • Page 372 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped F42A Spare Rear Entertainment Screens 1 (Res1) / (Res2) / Media Hub #2 RR – 10 Amp Red F42B Wake Up / Media Hub #3 Wake Up / APO Illumination / 2nd - 3rd Row Seat Switches-Illumination –...
  • Page 373 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped Electronic Limited Slip Differential 30 Amp Pink – (ELSD) Rear #1 – – Spare 30 Amp Pink – MOD Inverter Folding Seat Module 3rd Row Feed 30 Amp Pink –...
  • Page 374 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped – 30 Amp Green MOD Audio Amplifier #1B – – Spare L2+ Central ADAS Decision Module – 20 Amp Yellow (CADM) MID* Video Routing Module (VRM) / Port –...
  • Page 375 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped – – Spare – 20 Amp Yellow Module Seat Heater Frt (PASS)* – 10 Amp Red SW Seat Heater (RR RT - RR LT)* – – Spare – –...

  • Page 376: Bulb Replacement

    SERVICING AND MAINTENANCE Tire Markings NOTE: EPLACEMENT P (Passenger) — Metric tire sizing is based on US  Replacement Bulbs, Names, And Part design standards. P-Metric tires have the letter Numbers “P” molded into the sidewall preceding the size designation. Example: P215/65R15 95H. In the instance a bulb needs to be replaced, this section includes bulb description and replacement European —...
  • Page 377 SERVICING AND MAINTENANCE TIRE SIZING CHART EXAMPLE: Example Size Designation: P215/65R15XL 95H, 215/65R15 96H, LT235/85R16C, T145/80D18 103M, 31x10.5 R15 LT P = Passenger car tire size based on US design standards, or "..blank.." = Passenger car tire based on European design standards, or LT = Light truck tire based on US design standards, or T or S = Temporary spare tire or 31 = Overall diameter in inches (in)
  • Page 378 SERVICING AND MAINTENANCE EXAMPLE: Service Description: 95 = Load Index A numerical code associated with the maximum load a tire can carry  H = Speed Symbol A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions ...
  • Page 379 SERVICING AND MAINTENANCE Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire; however, the date code may only be on one side. Tires with white sidewalls will have the full TIN, including the date code, located on the white sidewall side of the tire.
  • Page 380 SERVICING AND MAINTENANCE Tire Terminology And Definitions Term Definition The vehicle B-pillar is the structural member of the body located behind the B-pillar front door. Cold tire inflation pressure is defined as the tire pressure after the vehicle has not been driven for at least three hours, or driven less than 1 mile (1.6 km) Cold Tire Inflation Pressure after sitting for a minimum of three hours.
  • Page 381 SERVICING AND MAINTENANCE Tire Loading And Tire Pressure This placard tells you important information about the: NOTE: 1. Number of people that can be carried in the The proper cold tire inflation pressure is listed on vehicle. the driver’s side B-pillar or the rear edge of the driver's side door.
  • Page 382 SERVICING AND MAINTENANCE (4) The resulting figure equals the To determine the maximum loading conditions of Metric Example For Load Limit your vehicle, locate the statement “The combined available amount of cargo and luggage For example, if “XXX” amount equals 635 kg and weight of occupants and cargo should never load capacity.
  • Page 383 SERVICING AND MAINTENANCE...

  • Page 384: Tires - General Information

    SERVICING AND MAINTENANCE Fuel Economy WARNING! WARNING! Underinflated tires will increase tire rolling Overloading of your tires is dangerous. Overinflation reduces a tire's ability to cushion  resistance resulting in higher fuel consumption. Overloading can cause tire failure, affect vehicle shock.
  • Page 385 SERVICING AND MAINTENANCE Tire pressure may increase from 2 to 6 psi (13 to Radial Ply Tires CAUTION! 40 kPa) during operation. DO NOT reduce this normal pressure buildup or your tire pressure will WARNING! After inspecting or adjusting the tire pressure, be too low.
  • Page 386 SERVICING AND MAINTENANCE Run Flat Tires — If Equipped These indicators are molded into the bottom of the WARNING! tread grooves. They will appear as bands when the Run Flat tires allow you the capability to drive tread depth becomes 1/16 of an inch (1.6 mm). Fast spinning tires can be dangerous.

  • Page 387: Tire Types

    SERVICING AND MAINTENANCE NOTE: It is recommended you contact an authorized tire CAUTION! dealer or original equipment dealer with any Wheel valve stem must be replaced as well when questions you may have on tire specifications or installing new tires due to wear and tear in existing Replacing original tires with tires of a different capability.

  • Page 388: Spare Tires - If Equipped

    SERVICING AND MAINTENANCE Spare Tire Matching Original Equipped Tire Summer tires do not contain the all season authorized tire dealer for recommended safe designation or mountain/snowflake symbol on the operating speeds, loading and cold tire inflation And Wheel — If Equipped tire sidewall.
  • Page 389 SERVICING AND MAINTENANCE Do not install a wheel cover or attempt to mount a Since this tire has limited tread life, the original Full Size Spare — If Equipped conventional tire on the compact spare wheel, equipment tire should be repaired (or replaced) The full size spare is for temporary emergency use since the wheel is designed specifically for the and reinstalled on your vehicle at the first...

  • Page 390: Wheel And Wheel Trim Care

    SERVICING AND MAINTENANCE Your wheels are susceptible to deterioration WARNING! CAUTION! caused by salt, sodium chloride, magnesium chloride, calcium chloride, etc., and other road Limited use spares are for emergency use only. Do not use scouring pads, steel wool, a bristle chemicals used to melt ice or control dust on dirt Installation of this limited use spare tire affects brush, metal polishes or oven cleaner.

  • Page 391: Snow Traction Devices

    SERVICING AND MAINTENANCE RACTION EVICES Use of traction devices require sufficient tire-to-body clearance. Due to limited clearance, the following snow traction devices are recommended. Follow these recommendations to guard against damage: Snow traction device must be of proper size for the tire, as recommended by the snow traction device manufacturer. ...
  • Page 392 SERVICING AND MAINTENANCE Snow Traction Device (Maximum Axle Tire/Wheel Size Projection Beyond Tire Profile Or Trim Level Equivalent) P245/70R17-Two Row Only LAREDO 265/60R18 265/50R20 S Class TRAILHAWK-Two Row Only 265/60R18 Rear LIMITED 265/60R18 OVERLAND 265/50R20 265/50R20 20” - S Class SUMMIT 275/45R21XL 21”...

  • Page 393: Tire Rotation Recommendations

    SERVICING AND MAINTENANCE All passenger vehicle tires must conform The suggested rotation method is the “rearward OTATION ECOMMENDATIONS cross” shown in the following diagram. to Federal safety requirements in The tires on the front and rear of your vehicle addition to these grades. operate at different loads and perform different steering, handling, and braking functions.

  • Page 394: Traction Grades

    SERVICING AND MAINTENANCE STORING THE VEHICLE Sustained high temperature can cause RACTION RADES the material of the tire to degenerate The Traction grades, from highest to If you are storing your vehicle for more than three and reduce tire life, and excessive lowest, are AA, A, B, and C.

  • Page 395: Body And Underbody Maintenance

    SERVICING AND MAINTENANCE The following maintenance recommendations will To minimize the possibility of scratching the lenses CAUTION! enable you to obtain maximum benefit from the and reducing light output, avoid wiping with a dry corrosion resistance built into your vehicle. cloth.

  • Page 396: Interiors

    SERVICING AND MAINTENANCE Seat Belt Maintenance If you carry special cargo such as chemicals,  LASTIC OATED ARTS fertilizers, de-icer salt, etc., be sure that such Do not bleach, dye or clean the belts with chemical Use Mopar® Total Clean to clean vinyl upholstery. materials are well packaged and sealed.

  • Page 397: Leather Surfaces

    SERVICING AND MAINTENANCE Cleaning Plastic Instrument Cluster NOTE: LASS URFACES If equipped with light colored leather, it tends to Lenses All glass surfaces should be cleaned on a regular show any foreign material, dirt, and fabric dye The lenses in front of the instruments in this basis with Mopar®...

  • Page 398: Technical Specifications

    TECHNICAL SPECIFICATIONS VEHICLE IDENTIFICATION NUMBER (VIN) BRAKE SYSTEM ORQUE PECIFICATIONS The VIN is found on a label located on the left front Your vehicle is equipped with dual hydraulic brake Lug Nut/Bolt **Lug Nut/ Lug Nut/Bolt corner of the instrument panel pad, visible from systems.

  • Page 399: Fuel Requirements

    TECHNICAL SPECIFICATIONS FUEL REQUIREMENTS 3.6L E Tighten the lug nuts/bolts in a star pattern until NGINE each nut/bolt has been tightened twice. Ensure Do not use E-85 flex fuel or ethanol blends greater While operating on gasoline with the required that the socket is fully engaged on the lug nut/bolt than 15% in this engine.

  • Page 400: Reformulated Gasoline

    TECHNICAL SPECIFICATIONS E-85 I Indiscriminate use of fuel system cleaning agents EFORMULATED ASOLINE should be avoided. Many of these materials EHICLES Many areas of the country require the use of intended for gum and varnish removal may contain cleaner burning gasoline referred to as active solvents or similar ingredients.

  • Page 401: Methylcyclopentadienyl Manganese Tricarbonyl (Mmt) In Gasoline

    TECHNICAL SPECIFICATIONS ETHYLCYCLOPENTADIENYL YSTEM AUTIONS CAUTION! (MMT) I ANGANESE RICARBONYL The use of fuel additives, which are now being  CAUTION! ASOLINE sold as octane enhancers, is not recom- Follow these guidelines to maintain your mended. Most of these products contain high MMT is a manganese-containing metallic additive vehicle’s performance: concentrations of methanol.

  • Page 402: Fluid Capacities

    TECHNICAL SPECIFICATIONS FLUID CAPACITIES Metric Fuel (Approximate) All Engines 23 gal 87 L Engine Oil With Filter 2.0L Engine 5 qt 4.7 L 3.6L Engine 5 qt 4.7 L 5.7L Engine 7 qt 6.6 L Cooling System * 2.0L Engine 10.4 qt 9.8 L 2.0L Engine Intercooler...

  • Page 403: Engine Fluids And Lubricants

    TECHNICAL SPECIFICATIONS ENGINE FLUIDS AND LUBRICANTS Component Fluid, Lubricant, or Genuine Part We recommend using Mopar® Antifreeze/Coolant 10 year/150,000 mile Engine Coolant (240,000 km) Formula OAT (Organic Additive Technology) meeting the requirements of the manufacturer Material Standard MS.90032. We recommend using Mopar® Antifreeze/Coolant 10 year/150,000 mile Intercooler (240,000 km) Formula OAT (Organic Additive Technology) or equivalent meeting the requirements of the manufacturer Material Standard MS.90032.

  • Page 404: Chassis Fluids And Lubricants

    TECHNICAL SPECIFICATIONS CHASSIS FLUIDS AND LUBRICANTS Component Fluid, Lubricant, or Genuine Part Use only Mopar® ZF 8 & 9 Speed ATF Automatic Transmission Fluid or Automatic Transmission equivalent. Failure to use the correct fluid may affect the function or performance of your transmission. Transfer Case –...

  • Page 405: Customer Assistance

    CUSTOMER ASSISTANCE SUGGESTIONS FOR OBTAINING SERVICE This is why you should always talk to an authorized EASONABLE EQUESTS dealer’s service manager first. If for some reason FOR YOUR VEHICLE If you list a number of items and you must have you are still not satisfied, talk to the general your vehicle by the end of the day, discuss the manager or owner of the authorized dealer.

  • Page 406: Roadside Assistance

    CUSTOMER ASSISTANCE FCA US LLC reserves the right to modify the terms are calling. Briefly describe the nature of the OADSIDE SSISTANCE problem and answer a few simple questions. You or discontinue the Roadside Assistance Program Available 24 hours, 7 days a week. will be given the name of the service provider and at any time.

  • Page 407: Fca Us Llc Customer Center

    San Juan 00919-1857 transport your vehicle to the closest authorized extended protection plans authorized, endorsed Chrysler, Dodge, Jeep®, or Ram dealer. If you Phone: (877) 426-5337 and backed by FCA US LLC to provide additional choose to go to another dealer, you will be protection beyond your vehicle’s warranty.

  • Page 408: Warranty Information

    CUSTOMER ASSISTANCE WARRANTY INFORMATION REPORTING SAFETY DEFECTS We appreciate that you have made a major investment when you purchased the vehicle. An See the Warranty Information for the terms and authorized dealer has also made a major 50 U NITED TATES provisions of FCA US LLC warranties applicable to investment in facilities, tools, and training to...

  • Page 409: In Canada

    CUSTOMER ASSISTANCE PUBLICATION ORDER FORMS To contact NHTSA, you may call the To order a hard copy of your Service or Diagnostic Procedure manuals, visit: Vehicle Safety Hotline toll free at To order the following manuals, you may use either 1-888-327-4236 (TTY: www.techauthority.com (US and Canada).

  • Page 410: Change Of Ownership Or Address

    CUSTOMER ASSISTANCE CHANGE OF OWNERSHIP OR ADDRESS GENERAL INFORMATION Le présent appareil est conforme aux CNR d`Innovation, Science and Economic Development *If you have purchased this vehicle used or have The following regulatory statement applies to all applicables aux appareils radio exempts de changed your address, please provide the Radio Frequency (RF) devices equipped in this licence.
  • Page 411 INDEX ...... 329 ............339 Event Data Recorder (EDR) Air Filter .........396 ..........280 About Your Brakes Front Air Bag Air Pressure .....342 ....... 286 ............382 Accessory Drive Belt Inspection If Deployment Occurs Tires ......152 ....... 284 Active Driving Assist System Knee Impact Bolsters Alarm ..
  • Page 412 ..... 111 ..78 Anti-Lock Brake System (ABS) Auxiliary Electrical Outlet (Power Outlet) .........111 ........78 ..........176 Anti-Lock Warning Light Auxiliary Power Outlet Camera, Front ..............233 ............402 ........177 Apps Axle Fluid Camera, Night Vision ........174 Arming System Camera, Rear ..........
  • Page 413 Checking Your Vehicle For Safety ....303 Cooling System ..........346 Dipsticks Checks, Safety ..........303 Adding Coolant (Antifreeze) ...... 347 Oil (Engine) ..........337 Child Restraint ..........289 Coolant Level ........348 Disposal Child Restraints Cooling Capacity ........400 Antifreeze (Engine Coolant) ......
  • Page 414 ..........334 ............ 305 Emergency Oil Filler Cap Fluid Leaks ......325 ............ 339 Freeing A Stuck Vehicle Oil Filter Fluid Level Checks ......307 ......338 ............350 Hazard Warning Flashers Oil Selection Brake ..........319 ..........339 ..........337 Jump Starting Oil Synthetic Engine Oil ........323...
  • Page 415 Octane Rating ...........397 Headlights ............57 Requirements ......... 397 Automatic ............59 Ignition .............22 Specifications ..........401 Cleaning ........... 393 Key Fob Battery Low Or Dead ......22 Tank Capacity ..........400 Delay ............60 Key Fob Not Detected ........22 Fuel Saver Technology ........139 High Beam/Low Beam Select Switch ..59 Keyless Ignition ...........22...
  • Page 416 ........... 384 ......59 Life Of Tires High Beam/Low Beam Select ..........311 ...........88 ..116 Jack Location Liftgate Hill Descent Control Indicator ..........315 ........89 ............62 Jack Operation Adjustable Height Interior .......310 ............88 ........61 Jacking And Tire Changing Closing Lights On Reminder ..311 ..........89 ...........
  • Page 417 Loading Vehicle ..........184 Mirrors .............49 Off Road Pages ..........245 Tires ............379 Automatic Dimming Rearview .....50 Accessory Gauges ........246 Locks Digital Rearview ...........50 Pitch And Roll ........... 246 Child Protection ........... 31 Exterior Folding ..........51 Selec Terrain ..........246 Manual ............
  • Page 418 ......117 ............80 Onboard Diagnostic System Inverter ........117 ............52 ..........383 Operating Precautions Mirrors Radial Ply Tires ....78 .... 348 Operator Manual Outlet (Auxiliary Electrical Outlet) Radiator Cap (Coolant Pressure Cap) ........407 ............41 Owner's Manual Seats Radio ........ 51 ............ 139 .........
  • Page 419 Remote Keyless Entry ........18 Seat Belts ..........270 Extend ............43 Arm The Alarm ..........26 Adjustable Shoulder Belt ......274 Heated ............45 Disarm The Alarm ........27 Adjustable Upper Shoulder Anchorage ..274 Massage ............44 Programming Additional Key Fobs ....
  • Page 420 ........165 ..........83 ..........310 Side Distance Warning Sun Roof Changing ........116 ............84 ......... 386 Signals, Turn Opening Compact Spare ......389 ............51 ......382 Snow Chains (Tire Chains) Sun Visor General Information .............386 .........75 ..........383 Snow Tires Sunglasses Storage High Speed .........
  • Page 421 Towing This Vehicle Behind Another Vehicle ..195 Traction Control ..........257 Uconnect (Radio) .......... 203 Warning Lights Traffic Sign Assist System ......151 Uconnect 5/5 NAV ........203 (Instrument Cluster Descriptions) ....108 TrailCam System ..........176 Uconnect Settings ......... 204 Warning Lights And Messages ......
  • Page 423 It is always the driver’s responsibility to comply with all local laws. This Owner’s Manual has been prepared to help you get acquainted with your new Jeep brand vehicle and to provide a convenient reference source for ®...
  • Page 424 ©2022 FCA US LLC. All Rights Reserved. Tous droits réservés. Jeep is a registered trademark of FCA US LLC. Jeep est une Second Edition marque déposée de FCA US LLC. App Store is a registered trademark of Apple Inc. Google Play Store is a registered trademark of Google.

This manual is also suitable for:

Grand cherokee 2023

Table of Contents

Save PDF
