Summary of Contents for Jeep 2006 Liberty

Page 1 SECTION ............. 3 INTRODUCTION THINGS TO KNOW BEFORE STARTING YOUR VEHICLE UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 3 CONTENTS Introduction ......4 Roll Over Warning ..... 4 How To Use This Manual .
Page 4 4 INTRODUCTION INTRODUCTION Thank you for selecting a Jeep Liberty and welcome to our worldwide family. This is a specialized utility vehicle designed for both on-road and off-road use. It can go places and perform tasks for which conventional two-wheel drive vehicles were not intended.
Page 5 Do not attempt sharp turns or abrupt maneuvers or other unsafe driving actions that can cause loss of vehicle control. Failure to operate this vehicle safely may result in an accident, roll over of the vehicle, and severe or fatal injury.
Page 6 6 INTRODUCTION NOTE: After you read the manual, it should be stored in the vehicle for convenient reference and remain with the vehicle when sold so that the new owner will be aware of all safety warnings. When it comes to service, remember that the manufac- turer knows your vehicle best, has the factory-trained technicians and genuine Mopar parts, and is interested in your satisfaction.
Page 7 INTRODUCTION 7 VEHICLE IDENTIFICATION NUMBER The vehicle identification number (VIN) is located on a stamped plate on the bottom of the left front A-Pillar, visible from outside of the vehicle through the wind- shield. This number also appears on the Automobile Information Disclosure Label affixed to a window on your vehicle.
Page 8 8 INTRODUCTION VEHICLE MODIFICATIONS / ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to an accident resulting in serious injury or death.
Page 9: Things To Know Before Starting Your Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....12 Ignition Key ......12 Key-In-Ignition Reminder .
Page 10 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Unlock The Doors ....23 To Lock The Doors .....23 To Unlatch The Swing Gate Flip-Up Window .
Page 11 Seat Belt Extender ..... .46 Driver And Front Passenger Supplemental Restraint Systems (SRS) — Airbags ..47 Child Restraint .
Page 12 12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS The keys for your new vehicle are enclosed in a plastic bag with the key code number on it. If you received your keys without the bag, ask your dealer to give you the number.
Page 13 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 WARNING! Leaving children in a vehicle unattended is danger- ous for a number of reasons. A child or others could be injured. Children should be warned not to touch the parking brake, brake pedal, or the gear selector lever.
Page 14 14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Key-In-Ignition Reminder If you open the driver’s door and the key is fully inserted in the ignition switch, a chime will sound to remind you to remove the key. SENTRY KEY IMMOBILIZER SYSTEM The Sentry Key Immobilizer System (SKIM) prevents unauthorized operation of the vehicle by disabling the engine.
Page 15 NOTE: • The Sentry Key Immobilizer System is not compatible with remote starting systems. Use of these systems may result in vehicle starting problems and loss of security protection. • Mobil Speedpass™, additional Sentry Keys, or any other transponder equipped components on the same keychain will not cause a key-related (Transponder) fault unless the additional part is physically held against the ignition key being used when starting the...
Page 16 16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE consists of programming a blank key to the vehicle electronics. A blank key is one which has never been programmed. NOTE: When having the Sentry Key System serviced, bring all vehicle keys to the dealer. Customer Key Programming You can program new keys to the system if you have two valid keys by doing the following:...
Page 17 2. This device must accept any interference that may be received, including interference that may cause undes- ired operation. STEERING WHEEL LOCK — IF EQUIPPED Your vehicle may be equipped with a passive steering wheel lock (manual transmission only). This lock pre- vents steering the vehicle without the ignition key.
Page 18 18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE DOORS AND DOOR LOCKS The vacuum fluorescent (VF) display located in the odometer area displays the word “door” as an indication of a door ajar or door not completely closed. When the vehicle is not moving and the door is ajar or not completely closed, the VF display will show the word “door”...
Page 19 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19 chime for each complete display cycle (three cycles total). After this, the display will continue to cycle only (no chimes). If the trip/reset button is pressed while the VF warnings are being displayed, the VF display will revert back to only displaying the odometer/trip odometer mileage.
Page 20 20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • For personal security, and safety in the event of an accident, lock the vehicle doors as you drive as well as when you park and leave the vehicle. • When leaving the vehicle always remove the key from the ignition lock, and lock your vehicle.
Page 21 If you press the door lock switch while the keys are in the ignition switch, and the driver’s door is open, the doors will not lock. The rear doors cannot be opened from inside the vehicle until you pull up the lock plungers. Automatic Door Locks —...
Page 22 22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE REMOTE KEYLESS ENTRY This system allows you to lock or unlock the doors, open the swing gate flip-up window, or activate the panic alarm from distances of 23–50 feet (7–15 meters) using a transmitter.
Page 23 To Unlock the Doors Press and release the “Unlock” button once to unlock the driver’s door. Press the button again within 5 seconds to unlock all the doors. If your vehicle is equipped with Illuminated Entry, the interior lights also come on and remain on for about 30 seconds, when you unlock the doors.
Page 24 24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: The horn chirp can be enabled or disabled (within 23–50 feet (7–15 meters) of the vehicle) by the following procedure: 1. Press and hold the Lock button on the transmitter. 2. Continue to hold the Lock button, wait at least 4 but no longer than 10 seconds, then press the Panic button.
Page 25 Panic Alarm The panic mode flashes the park lights, and sounds the horn for about 3 minutes or until the alarm is turned off. To Use the Panic Alarm Press and hold the PANIC button for at least 1 second to activate the panic alarm.
Page 26 26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Enter Program Mode: Turn the ignition to the ON position, and using a currently programmed transmitter; press and hold the Unlock button on the transmitter. Continue to hold the “Unlock” button, wait at least 4 but no longer than 10 seconds, then press and hold the PANIC button for at least 1 second.
Page 27 Transmitter Battery Service The recommended replacement battery is the Panasonic CR2032 or equivalent. 1. Pry the transmitter halves apart with a dime or similar object. Make sure not to damage the rubber gasket material during removal. Separating Transmitter THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27 2.
Page 28 28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: The “Panic” and “Security” alarms are quite different. Please take a moment to activate the “Panic” and the “Security” modes to hear the differences in the horn. In case one should go off in the future, you will need to know which mode has been activated in order to deactivate it.
Page 29 press the “Unlock” button on the remote keyless entry transmitter to disarm the system. You may also acciden- tally disarm the system by unlocking the driver’s door with the key and then locking it. The door will be locked but the Security Alarm will not arm. REAR SWING GATE The swing gate can be unlocked using the remote keyless entry, or by activating the power door lock switches...
Page 30 30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! To avoid injury stand back when opening. Glass will automatically rise. The vacuum fluorescent (VF) display located in the odometer area displays the words “GATE” and/or “GLASS” as an indication of when the swing gate and/or flip-up window, is not completely closed.
Page 31 Glass Open Display If any other active warnings including “door” or “LO- WASH” are present, they will be shown in the VF display and will also continue to cycle. If the vehicle is moving, two single chimes will occur if the rear glass is open or three single chimes will occur if the rear swing gate is THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31 open (one chime for each complete display cycle).
Page 32 32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Driving with the flip-up window open can allow poisonous exhaust gases into your vehicle. You and your passengers could be injured by these fumes. Keep the flip-up window closed when you are operating the vehicle.
Page 33 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33 The window lock switch located next to the window switches allows you to disable the rear passenger win- dow switches that are located on the back of the center floor console. Auto Down Feature — If Equipped The driver’s and passenger’s front window switches have an auto down feature.
Page 34 34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Rear Passenger Window Switches The rear passenger window switches are located on the back of the center floor console. Rear Power Window Switches Wind Buffeting Wind buffeting can be described as the perception of pressure on the ears or a helicopter type sound in the ears.
Page 35 NOTE: The front airbags have a multi stage inflator design. This allows the airbag to have different rates of inflation that are based on collision severity. Please pay close attention to the information in this section. It tells you how to use your restraint system properly to keep you and your passengers as safe as possible.
Page 36 36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Lap/Shoulder Belts All the seats in your vehicle are equipped with lap/ shoulder belts. The belt webbing retractor is designed to lock during very sudden stops or collisions. This feature allows the shoulder part of the belt to move freely with you under normal conditions.
Page 37 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37 Lap/Shoulder Belt Operating Instructions 1. Enter the vehicle and close the door. Sit back and adjust the seat. 2. The seat belt latch plate is above the back of your seat. Grasp the latch plate and pull out the belt. Slide the latch plate up the webbing as far as necessary to make the belt go around your lap.
Page 38 38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. When the belt is long enough to fit, insert the latch plate into the buckle until you hear a “click.” Latch Plate To Buckle WARNING! A belt that is buckled into the wrong buckle will not protect you properly.
Page 39 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39 4. Position the lap belt across your thighs, below your abdomen. To remove slack in the lap portion, pull up a bit on the shoulder belt. To loosen the lap belt if it is too tight, tilt the latch plate and pull on the lap belt.
Page 40 40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! A lap belt worn too high can increase the risk of injury in a collision. The belt forces won’t be at the strong hip and pelvic bones, but across your abdo- men.
Page 41 Rear Center Lap/Shoulder Belt Retractor Lock-Out This feature is designed to lock the retractor whenever the 65% rear seat back is not fully latched. This prevents someone from wearing the rear center lap/shoulder belt when the rear seat back is not fully latched. NOTE: •...
Page 42 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE the height of the shoulder belt, slide the height adjuster up. Pull down on the height adjuster to make sure it is locked in place. Adjusting Upper Shoulder Belt WARNING! Position the shoulder belt height adjusters so that the belt rests across the middle of your shoulder.
Page 43 When To Use The Automatic Locking Mode Anytime a child safety seat is installed in a passenger front or outboard rear seating position (if equipped). Children 12 years old and under should be properly restrained in the rear seat whenever possible. How To Use The Automatic Locking Mode 1.
Page 44 44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • After a vehicle collision, the driver and front passenger outboard seat belt system must be checked by a qualified technician to verify that the “automatic locking retractor” feature for child seats is still functioning properly.
Page 45 Enhanced Seat Belt Use Reminder System (BeltAlert) If the driver’s or front passenger seat belt has not been buckled within 60 seconds of starting the vehicle and if the vehicle speed is greater than 5 mph (8 km/h), the Enhanced Warning System (BeltAlert) will alert the driver or front passenger to buckle their seat belt.
Page 46 46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. Turn the ignition key to the OFF position. A single chime will sound to signify that you have successfully completed the programming. The Enhanced Warning System (BeltAlert) can be reacti- vated by repeating this procedure. NOTE: Although the Enhanced Warning System (BeltAlert) has been deactivated, the Seat Belt Warning...
Page 47 WARNING! Using a seat belt extender when not needed can increase the risk of injury in a collision. Only use when the lap belt is not long enough when it is worn low and snug, and in the recommended seating positions.
Page 48 48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE the instrument panel, above the glove compartment. The words SRS/AIRBAG are embossed on the airbag covers. NOTE: The front airbags are certified to the Federal regulations that allow less forceful deployment. The front airbags have a multi stage inflator design. This may allow the airbag to have different rates of inflation that are based on collision severity and occupant size.
Page 49 WARNING! • Do not put anything on or around the front airbag covers or attempt to manually open them. You may damage the airbags and you could be injured be- cause the airbags are no longer functional. These protective covers for the airbag cushions are de- signed to open only when the airbags are inflating.
Page 50 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE airbags work, you need the seat belts to keep you in the right position for the airbags to protect you properly. Here are some simple steps you can take to minimize the risk of harm from a deploying airbag.
Page 51 WARNING! • Relying on the airbags alone could lead to more severe injuries in a collision. The airbags work with your seat belt to restrain you properly. In some collisions the airbags won’t deploy at all. Always wear your seat belts even though you have airbags.
Page 52 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Driver and Front Passenger Seat Belt Pretensioners • Front Passenger Seat Occupant Classification System (OCS) − Occupant Classification Module − Passenger Airbag Disabled (PAD) Indicator Light − Interconnecting Wiring − Pressure Sensor, Bladder Assembly, and Belt Tension Sensor How The Airbag System Works •...
Page 53 in any part of the system, it turns on the AIRBAG warning light either momentarily or continuously. A single chime will sound if the light comes on again after initial start up. WARNING! Ignoring the AIRBAG warning light in your instru- ment panel could mean you won’t have the airbags to protect you in a collision.
Page 54 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE the crash side of the vehicle. A quantity of nontoxic gas is generated to inflate the window bag. The inflating window bag pushes the outside edge of the headliner out of the way and covers the window. The airbag inflates in about 30 milliseconds (about one quarter of the time it takes to blink your eyes) with enough force to injure you if you are not belted and seated properly,...
Page 55 grab handle) and AIRBAG warning light (located in the instrument cluster) are illuminated the airbag will be disabled. The ORC will not allow front airbag deployment in the event of a collision for occupants classified into the empty or child size categories. The PAD indicator light will illuminate indicating that the Passenger Airbag is OFF when the OCS has determined that the occupant size category is a child.
Page 56 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE should always use the PAD indicator light as an indica- tion if the front passenger is properly positioned or not. If the PAD indicator light comes on when an adult is in the passenger seat, have the passenger re-position them- selves in the seat until the light goes out.
Page 57 pressure increase due to applied lap belt tension does not cause a small occupant to be classified as a larger occupant. • The Bladder Mat and Pressure Sensor are located beneath the seat cushion foam. The pressure sensor sends a signal to the OCM. The front passenger seat assembly contains critical com- ponents that affect the front passenger airbag deploy- ment.
Page 58 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Do not use prior or future model year seat covers not designated for the specific model being repaired. Al- ways use the correct seat cover specified for the vehicle. • Do not replace the seat cover with an aftermarket seat cover.
Page 59 However, if you haven’t healed significantly within a few days, or if you have any blistering, see your doctor immediately. As the airbags deflate you may see some smoke-like particles. The particles are a normal by- product of the process that generates the nontoxic gas used for airbag inflation.
Page 60 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Enhanced Accident Response System (E.A.R.S.) If the airbags deploy after an impact and the electrical system remains functional, the interior lights will turn on and the power door locks (if equipped) will unlock 5 seconds after airbag deployment.
Page 61 WARNING! • You need proper knee impact protection in a collision. Do not mount or locate any aftermarket equipment on or behind the knee bolsters. • It is dangerous to try to repair any part of the airbag system yourself. Be sure to tell anyone who works on your vehicle that it has an airbag system.
Page 62 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! In a collision, an unrestrained child, even a tiny baby, can become a missile inside the vehicle. The force required to hold even an infant on your lap can become so great that you could not hold the child, no matter how strong you are.
Page 63 infant carriers do, so they can be used rearward-facing by children who weigh more than 20 lbs (9 kg) but are less than one year old. • Rearward-facing child seats must NEVER be used in the front seat of a vehicle with a front passenger airbag.
Page 64 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • Improper installation can lead to failure of an infant or child restraint. It could come loose in a collision. The child could be badly injured or killed. Follow the manufacturer’s directions ex- actly when installing an infant or child restraint.
Page 65 belt system will loosen with time, so check the belt occasionally and pull it tight if necessary. If the seat belt has a automatic locking retractor, it will have a distinctive label. Pull the belt from the retractor until there is enough to allow you to pass through the child restraint and slide the latch plate into the buckle.
Page 66 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE kits or retro-fit kits. You are urged to take advantage of all the available attachments provided with your child re- straint in any vehicle. NOTE: When using the LATCH attaching system to install a child restraint, please ensure that all seat belts not being used for occupant restraints are stowed and out of reach of children.
Page 67 The rear seat lower anchorages are round bars, located at the rear of the seat cushion where it meets the seat back, and are just visible when you lean into the rear seat to install the child restraint. You will easily feel them if you run your finger along the intersection of the seatback and seat cushion surfaces.
Page 68 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Many, but not all restraint systems will be equipped with separate straps on each side, with each having a hook or connector for attachment to the lower anchorage and a means of adjusting the tension in the strap. Forward- facing toddler restraints and some rear-facing infant restraints will also be equipped with a tether strap, a hook for attachment to the tether strap anchorage and a...
Page 69 Installing Child Restraints Using the Vehicle Seat Belt The passenger seat belts are equipped with either cinch- ing latch plates or automatic locking retractors, which are designed to keep the lap portion tight around the child restraint so that it is not necessary to use a locking clip. If the seat belt has a cinching latch plate, pulling up on the shoulder portion of the lap/shoulder belt will tighten the belt.
Page 70 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To attach a child restraint tether strap: Route the tether strap over the seat back and attach the hook to the tether anchor located on the back of the seat. For the outboard seating positions, route the tether under the head restraint between the head restraint posts.
Page 71 • Check belt fit periodically. A child’s squirming or slouching can move the belt out of position. • If the shoulder belt contacts the face or neck, move the child closer to the center of the vehicle. Never allow a child to put the shoulder belt under an arm.
Page 72 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A new engine may consume some oil during its first few thousand miles (kilometers) of operation. This should be considered as a normal part of the break-in and not interpreted as an indication of difficulty. SAFETY TIPS Exhaust Gas WARNING!
Page 73 Safety Checks You Should Make Inside The Vehicle Seat Belts Inspect the belt system periodically, checking for cuts, frays and loose parts. Damaged parts must be replaced immediately. Do not disassemble or modify the system. Seat belt assemblies must be replaced after an accident if they have been damaged (bent retractor, torn webbing, pretensioners, etc.).
Page 74 74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Fluid Leaks Check area under vehicle after overnight parking for fuel, coolant, oil or other fluid leaks. Also, if gasoline fumes are detected, the cause should be located and corrected immediately.
Page 75: Understanding The Features Of Your Vehicle
UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Mirrors .......79 Inside Day/Night Mirror ....79 Inside Automatic Dimming Mirror —...
Page 76 76 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Front Seat Adjustment — Recline ..107 Head Restraints ..... . 108 Power Seat Adjuster —...
Page 77 Electronic Brake Control System ... . 125 ABS (Anti-Lock Brake System) ... . 125 TCS (Traction Control System) ... . 126 BAS (Brake Assist System) .
Page 78 78 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Sunroof Maintenance ....153 Power Outlet ......153 Cup Holders .
Page 79 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 79 MIRRORS Inside Day/Night Mirror The mirror should be adjusted to center on the view through the rear window. A two-point pivot system allows for horizontal and vertical adjustment of the mirror. The mirror should be adjusted while set in the day position (toward windshield).
Page 80 80 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Inside Automatic Dimming Mirror — If Equipped This mirror automatically adjusts for annoying headlight glare from vehicles behind you. You can turn the feature on or off by pressing the button at the base of the mirror. A light in the button will indicate when the dimming feature is activated.
Page 81 WARNING! Vehicles and other objects seen in the right side convex mirror will look smaller and farther away than they really are. Relying too much on your right side mirror could cause you to collide with another vehicle or other objects. Use your inside mirror when judging the size or distance of a vehicle seen in the right side mirror.
Page 82 82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Heated Remote Control Mirrors — If Equipped These mirrors are heated to melt frost or ice. This feature is activated whenever you turn on the rear window defrost. Illuminated Vanity Mirrors — If Equipped An illuminated vanity mirror is on the sun visor.
Page 83 HANDS–FREE COMMUNICATION (UConnect™) — IF EQUIPPED UConnect™ is a voice-activated, hands-free, in- vehicle communications system. UConnect™ allows you to dial a phone number with your cellular phone using simple voice commands (e.g., Call” “Mike” ”Work or Dial” “248-555-1212 ). Your cellular phone’s audio is trans- mitted through your vehicle’s audio system;...
Page 84 84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The rearview mirror contains the microphone for the system and the control buttons that will enable you to access the system. UConnect™ Switches The UConnect™ system can be used with any Hands- Free Profile certified Bluetooth™ cellular phone. See www.chrysler.com/uconnect for supported phones.
Page 85 UConnect™ system prompts. You will be prompted for a specific command and then guided through the available options. • Prior to giving a voice command, one must wait for the voice on beep, which follows the Ready prompt or another prompt. •...
Page 86 NOTE: • www.chrysler.com/uconnect • www.dodge.com/uconnect • www.jeep.com/uconnect The following are general phone to UConnect™ System pairing instructions: • Press the ’Phone’ button to begin. • After the Ready prompt and the following beep, say Setup Phone Pairing.
Page 87 • The UConnect™ system will then prompt you to begin the cellular phone pairing process on your cellular phone. Before attempting to pair phone, please see your cellular phone’s user manual (Bluetooth section) for instructions on how to complete this step. •...
Page 88 88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 234-567-890 is nine digits long, which is not a valid phone number - the closest valid phone number has ten digits. • The UConnect™ system will confirm the phone num- ber and then dial. The number will appear in the display of certain radios.
Page 89 • When prompted, say the name of the new entry. Use of long names helps the voice recognition and is recom- mended. For example, say Robert Smith or Robert instead of Bob. • When prompted, enter the number designation (e.g.: Home, Work, Mobile, or Pager ).
Page 90 90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE After you are finished editing an entry in the phonebook, you will be given the opportunities to edit another entry in the phonebook, call the number you just edited, or return to the main menu. Phonebook Edit can be used to add another phone number to a name entry that already exists in the phonebook.
Page 91 Delete All Entries in the UConnect™ Phonebook • Press the ’Phone’ button to begin. • After the Ready prompt and the following beep, say Phonebook Erase All. • The UConnect™ system will ask you to verify that you wish to delete all the entries from the phonebook. •...
Page 92 92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Answer or Reject an Incoming Call - No Call Currently in Progress When you receive a call on your cellular phone, the UConnect™ system will interrupt the vehicle audio system, if on, and will ask if you would like to answer the call.
Page 93 Conference Call When two calls are in progress (one active and one on hold), press and hold the ’Phone’ button until you hear a double beep indicating that the two calls have been joined into one conference call. Three-Way Calling To initiate three-way calling, press the ’Voice Recogni- tion’...
Page 94 94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE until the vehicle battery condition dictates cessation of the call on the UConnect™ system and transfer of the call to the mobile phone. • After ignition key is switched to off, a call can continue on the UConnect™...
Page 95 If the phone is not reachable and the UConnect™ system is operational, you may reach the emergency number as follows: • Press the ’Phone’ button to begin. • After the Ready prompt and the following beep, say Emergency and the UConnect™ system will instruct the paired cellular phone to call the emergency num- ber.
Page 96 96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Paging To learn how to page, refer to Working with Automated Systems. Paging works properly except for pagers of certain companies which time-out a little too soon to work properly with the UConnect™ system. Voice Mail Calling To learn how to access your voice mail, refer to Working with Automated Systems.
Page 97 Turning Confirmation Prompts On/Off Turning confirmation prompts off will stop the system from confirming your choices (e.g. the UConnect™ sys- tem will not repeat a phone number before you dial it). • Press the ’Phone’ button to begin. • After the Ready prompt and the following beep, say Setup Confirmations.
Page 98 98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Mute/Un-mute (Mute off) When you mute the UConnect™ system, you will still be able to hear the conversation coming from the other party, but the other party will not be able to hear you. In order to mute the UConnect™...
Page 99 If you would like to connect or disconnect the Blue- tooth™ connection between a UConnect™ paired cellular phone and the UConnect™ system, follow the instruction described in your cellular phone user’s manual. List Paired Cellular Phone Names • Press the ’Phone’ button to begin. •...
Page 100 100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • The selected phone will be used for the next phone call. If the selected phone is not available, the UCon- nect™ system will return to using the highest priority phone present in or near (approximately with in 30 feet) the vehicle.
Page 101 • low road noise, • smooth road surface, • fully closed windows, • dry weather condition. • Even though the system is designed for users speaking in North American English, French, and Spanish ac- cents, the system may not always work for some. •...
Page 102 102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • dry weather condition. • Operation from driver seat. • Performance, such as, audio clarity, echo. and loud- ness to a large degree, rely on the phone and network, and not the UConnect™ system. •...
Page 103 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103...
Page 104 104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 105 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105...
Page 106 106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE North American English Primary Alternate(s) Zero Add location Add new All of them Confirmation prompts Confirmations prompts Delete a name Delete Language Select language List names List all List paired phones List phones Pager Beeper Phone pairing...
Page 107 Using body pressure, move forward and rearward on the seat to be sure the seat adjusters have latched. WARNING! • Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be properly adjusted and you could be injured.
Page 108 108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Head Restraints Head restraints can reduce the risk of whiplash injury in the event of impact from the rear. Adjustable head restraints should be adjusted so that the upper edge is as high as practical. The head restraints have a locking button that must be pushed inward to lower the head restraint.
Page 109 Power Seat Adjuster — If Equipped WARNING! Do not ride with the seatback reclined so that the seat belt is no longer resting against your chest. In a collision you could slide under the seat belt and be seriously or even fatally injured. Use the recliner only when the vehicle is parked.
Page 110 110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE This seat also has a manual recline lever located just to the rear of the power seat switch. Pull up on the lever to recline the seat. Recline Control Lever Heated Seats — If Equipped The heated seat switch is located on the outboard side of the front seats.
Page 111 Once the heated seat switch is activated, depressing it a second time will de-activate it. WARNING! Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaus- tion or other physical condition must exercise care when using the seat heater.
Page 112 112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! • It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed. •...
Page 113 Folding Rear Seat NOTE: When lifting up on the release handle, the seatback will release easier if you do not pull forward on the seatback; only lift up on the release handle until the seatback disengages, then fold the seat forward. When the seatback is folded completely forward, the head restraints should be flush against the seat cushion.
Page 114 114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE TO OPEN AND CLOSE THE HOOD To open the hood, two latches must be released. First pull the hood release lever inside your vehicle located under the left side of the instrument panel. Hood Release Lever Then, reach under the hood and slide the safety latch to the right and lift the hood.
Page 115 secure both latches. Never drive your vehicle unless the hood is fully closed, with both latches engaged. WARNING! If the hood is not fully latched, it could fly up when the vehicle is moving and block your forward vision. Be sure all hood latches are latched fully before driving.
Page 116 116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Daytime Brightness Feature Certain components (odometer, radio, etc.) can be illumi- nated at full brightness during the daytime. This can be helpful when driving with your headlights on during the daytime such as in a parade or a funeral procession. To activate this feature, rotate the multi-function control lever one detent lower than the dome light.
Page 117 To change the brightness of the instrument panel lights, rotate the center portion of the multi-function control lever up or down. High Beam/Low Beam Select Switch Pull the multi-function control lever towards you to switch the headlights to HIGH beam. Pull the multi- function control lever a second time to switch the head- lights to LOW beam.
Page 118 118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Lights-On Reminder A chime will sound if the driver’s door is left open, and the headlights or parking lights are left on. Battery Saver Feature — Exterior Lights If the park lights, headlights, fog lights, or high beams are left on when the ignition switch is in the OFF position, the battery saver feature will automatically turn off the exterior lights after eight minutes.
Page 119 Light Bar — If Equipped 1. Remove lamp covers by pressing the thumb tab up- wards, and pulling the cover off. Light Bar UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119 CAUTION! The auxiliary lights mounted on the off road light bar should be illuminated during OFF-ROAD USE ONLY.
Page 120 120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. With the ignition in the ON position, press the button to turn on the light bar (located on the instrument panel to the left of the steering column). Press the button again to turn off the light bar.
Page 121 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121 WINDSHIELD WIPERS AND WASHERS The wipers and washers are operated by a switch on the control lever. This control lever is located on the right side of the steering column. For front wiper operation, turn the control lever end cap upward to select the desired wiper speed.
Page 122 122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Windshield Washers To use the washer, pull the lever toward you and hold while spray is desired. If the lever is pulled while in the delay range, the wiper will operate for two wipe cycles after the lever is released, and then resume the intermit- tent interval previously selected.
Page 123 Mist Feature Push down on the wiper lever to activate a single wipe to clear off road mist or spray from a passing vehicle. As long as the lever is held down, the wipers will continue to operate. CAUTION! In cold weather, always turn off the wiper switch and allow the wipers to return to the park position before turning off the engine.
Page 124 124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE TILT STEERING COLUMN To tilt the column, push down on the lever below the turn signal control and move the wheel up or down, as desired. Pull the lever back towards you and firmly push the lever until it is above the lower surface of the shroud to lock the column in place.
Page 125 WARNING! Tilting the steering column while the vehicle is moving is dangerous. Without a stable steering col- umn, you could lose control of the vehicle and have an accident. Adjust the column only while the ve- hicle is stopped. Be sure it is locked before driving. ELECTRONIC BRAKE CONTROL SYSTEM Your vehicle is equipped with an advanced electronic brake control system that includes ABS (Anti-Lock Brake...
Page 126 126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! ABS (Anti-Lock Brake System) cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase the traction afforded by prevail- ing road conditions. ABS cannot prevent accidents, including those resulting from excessive speed in turns, driving on very slippery surfaces, or hydro- planing.
Page 127 BAS (Brake Assist System) The BAS is designed to optimize the vehicle’s braking capability during emergency braking maneuvers. The system detects an emergency braking situation by sens- ing the rate and amount of brake application and then applies optimum pressure to the brakes. This can help reduce braking distances.
Page 128 128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ERM (Electronic Rollover Mitigation) This system anticipates the potential for wheel lift by monitoring the driver’s steering wheel input and the speed of the vehicle. When ERM determines that the rate of change of the steering wheel angle and vehicles speed are sufficient to potentially cause wheel lift, it applies the appropriate brake and may reduce engine power to lessen the chance that wheel lift will occur.
Page 129 ESP (Electronic Stability Program) This system enhances directional control and stability of the vehicle under various driving conditions. ESP cor- rects for over/under steering of the vehicle by applying the brake of the appropriate wheel to assist in counter- acting the over/under steer condition. Engine power may also be reduced to help the vehicle maintain the desired path.
Page 130 130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! ESP (Electronic Stability Program) cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase the traction afforded by prevailing road conditions. ESP cannot prevent acci- dents, including those resulting from excessive speed in turns, driving on very slippery surfaces, or hydroplaning.
Page 131 Partial Off This mode is entered by momentarily depressing the “ESP Control Switch” (located on top of the steering column). When in “Partial Off” mode, the TCS portion of ESP, except for the “limited slip” feature described in the TCS section, has been disabled and the “ESP/TCS Indi- cator Light”...
Page 132 132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE overcome, turn ESP back on by momentarily depressing the “ESP Control Switch”. This may be done while the vehicle is in motion. 4WD Low Range Partial Off This is the normal operating mode for ESP in 4WD low range.
Page 133 NOTE: • The ESP/TCS Indicator Light and the ESP/BAS Warning Lamp come on momentarily each time the ignition switch is turned ON. • Each time the ignition is turned ON, the ESP System will be ON even if it was turned off previously. •...
Page 134 134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Set At A Desired Speed When the vehicle has reached the desired speed, press and release the SET button. Release the accelerator and the vehicle will operate at the selected speed. To Deactivate A soft tap on the brake pedal, normal braking, or pressing the CANCEL button will deactivate the Speed Control without erasing the memory.
Page 135 To Accelerate for Passing Depress the accelerator as you would normally. When the pedal is released, the vehicle will return to the set speed. NOTE: When driving uphill, at elevations above 2,000 ft. (610 meters), or when the vehicle is heavily loaded (especially when towing) the vehicle may slow below the SET speed.
Page 136 136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Pressing the MENU button will change the displayed programming features. Pressing the STEP button will select the available choices. Pressing the C/T (Compass/ Temperature) button will return the display to the normal compass/temperature display. NOTE: Temperature accuracy can be effected from heat soak.
Page 137 NOTE: The dome/reading lights will remain on until the switch is pressed a second time, so be sure they have been turned off before leaving the vehicle. Electronic Vehicle Information Center The electronic vehicle information center (EVIC), when the appropriate conditions exist, displays the following messages and symbols.
Page 138 138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Customer Programmable Features Press the MENU button until one of the display choices following appears: Language? When in this display you may select one of five lan- guages for all display nomenclature, including the trip computer functions.
Page 139 ALL DOORS. This can also be programmed using the key fob, refer to “Remote Keyless Entry” earlier in this section. Train Remote? Pressing the STEP button when in this display will select “Yes” or “No.” NOTE: Any time you perform this procedure, it is necessary to retrain all currently trained key fobs.
Page 140 140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Flash Lights With Locks? When this feature is selected, the front and rear turn signals will flash when the doors are locked or unlocked using the remote keyless entry transmitter. This feature may be selected with or without the sound horn on lock feature selected.
Page 141 Low Fuel Chime? When this feature is selected a chime will sound when the “Low Fuel Indicator Light” is displayed in the instrument panel cluster. Pressing the STEP button when in this display will select “Yes” or “No.” Mini-Trip Computer This feature, located in the overhead console, displays information on outside temperature, compass direction, and trip information.
Page 142 142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Even if the display still reads a few degrees above 32°F (0°C), the road surface may be icy, particularly in woods or on bridges. Drive carefully under such conditions to prevent an accident and possible per- sonal injury or property damage.
Page 143 Tire PSI Shows the pressure and location of each tire, except for the spare tire. The tire location will blink when under pressure. Blank Screen Shows a blank screen. Pressing the C/T button returns to the Compass and Temperature display. Pressing the STEP button returns you to the Average Miles per Gallon display.
Page 144 144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Compass Variance is the difference between magnetic north and geographic north. In some areas of the country, the difference between magnetic and geographic north is great enough to cause the compass to give false readings. If this occurs, the compass variance must be set according to the Compass Variance Map.
Page 145 To set the variance: Turn the ignition ON and set the display to “Compass/Temperature.” Press and hold the RESET button five seconds (no more than 10 seconds). The last variance zone number will be displayed. Press the STEP button to select the new variance zone and press the RESET button to resume normal operation.
Page 146 146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Before programming HomeLink to a garage door opener or gate operator, make sure that people and objects are out of the way of the device to prevent potential harm or damage. When programming a garage door opener, it is advised to park outside of the garage.
Page 147 WARNING! Vehicle exhaust contains carbon monoxide, a danger- ous gas. Do not run the vehicle’s engine while programming HomeLink. Exhaust gas can cause se- rious injury or death. WARNING! Your motorized door or gate will open and close while you are programming HomeLink. Do not program HomeLink if people or pets are in the path of the door or gate.
Page 148 148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. Simultaneously press and hold both the desired HomeLink button and the hand-held transmitter button. After a short time, the message TRAINING will show on HomeLink display. Do not release the buttons until the next step has been completed.
Page 149 steps five through seven below to complete the program- ming of a rolling code equipped device (most commonly a garage door opener). 5. At the garage door opener receiver (motor-head unit) in the garage, locate the learn or smart button. This can usually be found where the hanging antenna wire is attached to the motor-head unit.
Page 150 150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE garage door opener’s Owner’s Manual. Finally, repro- gram the hand-held transmitter(s) to HomeLink using the steps under Programming HomeLink . Gate Operator/Canadian Programming Canadian radio-frequency laws require transmitter sig- nals to time-out (or quit) after several seconds of transmission - which may not be long enough for HomeLink to pick up the signal during programming.
Page 151 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 151 POWER SUNROOF — IF EQUIPPED The sunroof control is located on the headliner between the sun visors. Press and hold the switch rearward to fully open the sunroof. The sunroof can be stopped at any position between closed and full open.
Page 152 152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Sunroof Switch (w/Console) Press and hold the “V” button in the center of the sunroof switch to open the vent. The sunroof can be stopped at any position between closed and full vent. To close the sunroof from the vent position, press and hold the switch forward.
Page 153 WARNING! • In an accident, there is a greater risk of being thrown from a vehicle with an open sunroof. You could also be seriously injured or killed. Always fasten your seat belt properly and make sure all passengers are properly secured too. •...
Page 154 154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE There is a rear power outlet located in the right rear cargo area above the storage cargo net/CD changer (if equipped). Rear Power Outlet The rear power outlet is a direct feed from the battery so it receives power whether the ignition is in the ON or OFF position.
Page 155 CAUTION! Electrical Outlet Use With Engine Off • Many accessories that can be plugged in draw power from the vehicle’s battery, even when not in use (i.e., cellular phones, etc.). Eventually, if plugged in long enough, the vehicle’s battery will discharge sufficiently to degrade battery life and/or prevent engine starting.
Page 156 156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Smoker’s Package — If Equipped With the optional Smoker’s package, a removable ash tray is inserted into the front cup holder location. The rear passengers have access to a cup holder on each rear door trim panel.
Page 157 CARGO AREA FEATURES Cargo Light The cargo area light is activated by opening the swing gate, opening any door, or by rotating the dimmer control on the multi-function control lever to the extreme top position. If all doors are closed and only the swing gate is open, pushing on the cargo light lens surface will turn off all interior lights.
Page 158 158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! In an accident a cargo cover loose in the vehicle could cause injury. It could fly around in a sudden stop and strike someone in the vehicle. Do not store the cargo cover on the cargo floor or in the passenger compartment.
Page 159 WARNING! • Cargo tie-down hooks are not safe anchors for a child seat tether strap. In a sudden stop or colli- sion a hook could pull loose and allow the child seat to come loose. A child could be badly injured. Use only the anchors provided for child seat tethers.
Page 160 160 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Cargo Organizer — If Equipped This vehicle may be equipped with a cargo organizer that mounts on the floor behind the rear seat. Items may be placed on the flat surface or stored in the three storage compartments.
Page 161 2. Place the rear corners of the cargo organizer into the supports located on the rear trim panel. Press down on the back of the cargo organizer to lock it into place. Cargo Organizer Mounting UNDERSTANDING THE FEATURES OF YOUR VEHICLE 161 WARNING! Do not load objects over 30 lbs (13.5 kg) in the upper position.
Page 162 162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Open Storage Compartments 1. Pull up on the center opening of the cargo organizer. Using Cargo Organizer 2. Lift up on the storage compartment dividers and lock into place. Cargo Organizer Removal Loosen screw, then lift lever from each mount located on the floor of the rear cargo area, and remove the cargo organizer from the vehicle.
Page 163 If the swing gate flip-up window is open or the swing gate is open, connection to the rear window wiper is interrupted preventing activation of the rear wiper blade. When the swing gate flip-up window or the swing gate is closed, the rear wiper switch or the ignition switch needs to be turned OFF, and then to ON to restart the rear wiper.
Page 164 164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The defroster will automatically turn off after about ten minutes. For about five more minutes of operation, push the button again. To prevent excessive battery drain, use the defroster only when the engine is operating. The push button also activates the heated exterior mirrors, if so equipped.
Page 165 CAUTION! • To avoid damage to the roof rack and vehicle, do not exceed the maximum roof rack load capacity of 150 lbs (68 kg) or 65 lbs (29.5 kg) on Renegade models. Always distribute heavy loads as evenly as possible and secure the load appropriately. •...
Page 167: Understanding Your Instrument Panel
UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instrument Panel And Interior Controls ..170 Instrument Cluster ..... . 171 3.7L Engines .
Page 168 168 UNDERSTANDING YOUR INSTRUMENT PANEL CD Changer Control Capability — If Equipped ......189 Sales Code RBQ—AM/FM Stereo Radio With 6 - Disc CD Changer .
Page 169 Tape Player ......206 CD Player — Single Disc In Radio ..206 CD Player —...
Page 170 170 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT PANEL AND INTERIOR CONTROLS...
Page 171 UNDERSTANDING YOUR INSTRUMENT PANEL 171 INSTRUMENT CLUSTER 3.7L ENGINES...
Page 172 172 UNDERSTANDING YOUR INSTRUMENT PANEL 2.8L DIESEL ENGINES...
Page 173 INSTRUMENT CLUSTER DESCRIPTION 1. Tachometer Indicates the permissible engine revolutions-per-minute for each gear range. Before reaching the red area, ease up on the accelerator to prevent engine damage. 2. Turn Signal Indicator Light The arrows will flash in unison with the exterior turn signals, when using the multi-function control lever.
Page 174 174 UNDERSTANDING YOUR INSTRUMENT PANEL inflate them to the proper pressure. Driving on a signifi- cantly under-inflated tire causes the tire to overheat and can lead to tire failure. Under-inflation also reduces fuel efficiency and tire tread life, and may affect the vehicle’s handling and stopping ability.
Page 175 When the engine is running, the “Malfunction Indicator Light” may flash to alert of serious conditions that could lead to immediate loss of power or severe catalytic converter damage. The vehicle should be serviced as soon as possible if this occurs. (See page 316 for more information.) 9.
Page 176 176 UNDERSTANDING YOUR INSTRUMENT PANEL or the battery is low. Also, a chime will sound if the light comes back on. See your authorized dealer immediately. 11. Temperature Gage Indicates engine coolant temperature. Any read- ing within the normal range indicates that the cooling system is operating satisfactorily.
Page 177 the instrument cluster). For additional information, refer to “Overhead Console — If Equipped” in Section 3. (See page 135 for more information.) NOTE: The warnings “LOCOOL” and “GASCAP” will always be displayed in the odometer display. U.S. federal regulations require that upon transfer of vehicle ownership, the seller certify to the purchaser the correct mileage that the vehicle has been driven.
Page 178 178 UNDERSTANDING YOUR INSTRUMENT PANEL 17. Part Time Indicator Light — If Equipped This light alerts the driver that the vehicle is in the PART TIME four–wheel drive high range mode, and the front and rear driveshafts are mechanically locked together forcing the front and rear wheels to rotate at the same speed.
Page 179 Also, the light will come on when the parking brake is applied with the ignition switch in the ON position. NOTE: This light shows only that the parking brake is applied. It does not show the degree of brake application. If the parking brake is off and the light remains on, have the brake system inspected as soon as possible.
Page 180 180 UNDERSTANDING YOUR INSTRUMENT PANEL light doesn’t come on, stays on, or comes on while driving, have the airbag system checked by an autho- rized dealer. 24. O/D (Overdrive) Off Indicator Light This light will illuminate when the O/D OFF button has been selected.
Page 181 the vehicle is safely and completely stopped and the gear selector is placed in the P (Park) position. The light should turn off. If the light remains on with the engine running, your vehicle will usually be drivable, however, see your dealer for service as soon as possible. If the light continues to flash when the engine is running, immediate service is required and you may experience reduced performance, an elevated / rough idle, or engine...
Page 182 182 UNDERSTANDING YOUR INSTRUMENT PANEL 30. Electronic Stability Program (ESP) Warning Light/Brake Assist System (BAS) Warning Light — If Equipped The ESP/BAS warning light in the instrument cluster comes on when the ignition switch is turned to the “ON” position. The light should go out with the engine running.
Page 183 ELECTRONIC DIGITAL CLOCK The clock and radio each use the display panel built into the radio. A digital readout shows the time in hours and minutes whenever the ignition switch is in the ON or ACC position and the time button is pressed. When the ignition switch is in the OFF position, or when the radio frequency is being displayed, time keeping is accurately maintained.
Page 184 184 UNDERSTANDING YOUR INSTRUMENT PANEL Electrical Disturbances Radio waves may pick up electrical disturbances during transmission. They mainly affect the wave amplitude, and thus remain a part of the AM reception. They interfere very little with the frequency variations that carry the FM signal.
Page 185 SALES CODE RBK—AM/ FM STEREO RADIO WITH CD PLAYER AND CD CHANGER CONTROLS NOTE: The radio sales code is located on the lower left side of your radio faceplate. RBK Radio UNDERSTANDING YOUR INSTRUMENT PANEL 185 Radio Operation Power/Volume Control Press the ON/VOL control to turn the radio on.
Page 186 186 UNDERSTANDING YOUR INSTRUMENT PANEL the radio will continue to tune until you release the button. The frequency will be displayed and continu- ously updated while the button is pressed. To Set The Radio Push-Button Memory When you are receiving a station that you wish to commit to push-button memory, press the SET button.
Page 187 Press the AUDIO button a fourth time and FADE will be displayed. Press the SEEK + or SEEK – to adjust the sound level between the front and rear speakers. Press the AUDIO button again or wait 5 seconds to exit setting tone, balance, and fade.
Page 188 188 UNDERSTANDING YOUR INSTRUMENT PANEL Inserting The Compact Disc CAUTION! This CD player will accept 4 only. The use of other sized discs may damage the CD player mechanism. You may either insert or eject a disc with the radio OFF. If you insert a disc with the ignition ON and the radio OFF, the display will show the time of day.
Page 189 FF/TUNE/RW Press FF (Fast Forward) and the CD player will begin to fast forward until FF is released. The RW ( Reverse) button works in a similar manner. Random Play — RND/Program Button 4 Press the RND (button 4) button while the CD is playing to activate Random Play.
Page 190 190 UNDERSTANDING YOUR INSTRUMENT PANEL Disc Up/Program Button 1 Press the DISC up (button 1) button to play the next available disc. Disc Down/Program Button 5 Press the DISC down (button 5) button to play the previous disc. Seek Button Press the SEEK up or down to select another track on the same disc.
Page 191 CD HOT will pause the operation. Play can be resumed when the operating temperature is corrected or another MODE is selected. An ERR symbol will appear on the display if the laser is unable to read the Disc data for the following reasons: •...
Page 192 192 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: Power to operate the radio is controlled by the ignition switch. It must be in the ON or ACC position to operate the radio. Mode Press the MODE button repeatedly to select between AM, FM, the CD changer and Sirius Satellite Radio™...
Page 193 and release that button. If a button is not selected within 5 seconds after pressing the SET RND button, the station will continue to play but will not be locked into push- button memory. You may add a second station to each push-button by repeating the above procedure with this exception: Press the SET button twice and SET 2 will show in the display window.
Page 194 194 UNDERSTANDING YOUR INSTRUMENT PANEL General Information This radio complies with Part 15 of FCC rules and with RSS-210 of Industry Canada. Operation is subject to the following conditions: 1. This device may not cause harmful interference, 2. This device must accept any interference received, including interference that may cause undesired opera- tion.
Page 195 show the disc number, the track number, and index time in minutes and seconds. Play will begin at the start of track 1. LOAD/ EJT — Load Press the LOAD/ EJT button and the button with the corresponding number where the CD is being loaded. After the radio displays “load”...
Page 196 196 UNDERSTANDING YOUR INSTRUMENT PANEL FF/TUNE/RW Press FF (Fast Forward) and the CD player will begin to fast forward until FF is released. The RW ( Reverse) button works in a similar manner. Random Play — SET / RND Press the RND button while the CD is playing to activate Random Play.
Page 197 Program Type Radio Display Nostalgia Nostalga Oldies Oldies Personality Persnlty Public Public Rhythm and Blues R & B Religious Music Rel Musc Religious Talk Rel Talk Rock Rock Soft Soft Soft Rock Soft Rck Soft Rhythm and Blues Soft R&B Sports Sports Talk...
Page 198 198 UNDERSTANDING YOUR INSTRUMENT PANEL Time Press the TIME button to change the display from elapsed CD playing time to time of day. Operating Instructions - Satellite Radio Mode (If Equipped) Refer to the Satellite Radio section of the Owner’s Manual.
Page 199 SALES CODE RB1—AM/FM STEREO RADIO WITH DVD/GPS NAVIGATION SYSTEM RB1 Radio The navigation system provides maps, turn identifica- tion, selection menus and instructions for selecting a UNDERSTANDING YOUR INSTRUMENT PANEL 199 variety of destinations and routes. Refer to your “Navi- gation User’s Manual”...
Page 200 200 UNDERSTANDING YOUR INSTRUMENT PANEL 1. Slide the CD changer door all the way to the right. 2. Press the green EJECT button. 3. Gently remove the magazine by pulling it out of the CD changer. 4. Close the CD changer door by sliding it to the left. Loading Discs into the Magazine Gently pull out a tray from the magazine, and place the disc with the label as indicated on the top of the...
Page 201 Installing the CD Changer Magazine 1. Slide the CD changer door all the way to the right to access the magazine slot. 2. Insert the magazine into the changer slot in the direction of the arrow on the magazine. 3. Slide the changer door to the left to close the changer door.
Page 202 202 UNDERSTANDING YOUR INSTRUMENT PANEL ESN/SID Access With RBB, RAH and RBK Radios With the ignition switch in the ACCESSORY position and the radio OFF, press the Tape Eject or CD Eject (depend- ing on the radio type) and Time buttons simultaneously for 3 seconds.
Page 203 • The current channel number will then be displayed until an action occurs. A CD or tape may remain in the radio while in the Satellite radio mode. Selecting a Channel Press and release the SEEK or TUNE buttons to search for the next channel.
Page 204 204 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: Pressing the SEEK or SCAN button while performing a music type scan will change the channel by one and stop the search. Pressing a pre-set memory button during a music type scan, will call up the memory channel and stop the search.
Page 205 REMOTE SOUND SYSTEM CONTROLS — IF EQUIPPED The remote sound system controls are located on the rear surface of the steering wheel. Reach behind the wheel to access the switches. UNDERSTANDING YOUR INSTRUMENT PANEL 205 The right hand control is a rocker type switch with a push-button in the center and controls the volume and mode of the sound system.
Page 206 206 UNDERSTANDING YOUR INSTRUMENT PANEL Radio Operation Pressing the top of the switch will “Seek” up for the next listenable station and pressing the bottom of the switch will “Seek” down for the next listenable station. The button located in the center of the left hand control will tune to the next preset station that you have pro- grammed in the radio preset push-button.
Page 207 If you press the switch up or down twice it plays the second track, three times, it will play the third, etc. The button in the center of the left hand switch will cause the CD changer to play the next available disc in the 6–disc magazine.
Page 208 208 UNDERSTANDING YOUR INSTRUMENT PANEL CLIMATE CONTROLS The controls for the heating, air conditioning, and venti- lation system in this vehicle consist of a series of rotary knobs, and a push-button. These comfort controls can be set to obtain desired interior conditions. Manual Climate Control Blower Control The rotary knob on the left controls the blower and can be...
Page 209 This position turns off the blower motor and outside air will not pass through any outlets. Recirculate (Max A/C) Air flows through the outlets located in the instrument panel. Allows for circulation of interior air only which will cool the cabin faster.
Page 210 210 UNDERSTANDING YOUR INSTRUMENT PANEL Air flows through the floor outlets, the outlets at the base of the windshield, and the side window demisters outlets. Defrost Air flows through the outlets at the base of the windshield and through the side window demister outlets.
Page 211 Summer Operation Air conditioned equipped vehicle’s cooling systems must be protected with a high quality engine coolant during summer to provide proper corrosion protection and to raise the boiling point of the coolant for protection against overheating. A 50% concentration is recom- mended.
Page 213: Starting And Operating
STARTING AND OPERATING CONTENTS Starting Procedures ..... 217 Manual Transmission ....217 Automatic Transmission .
Page 214 214 STARTING AND OPERATING Shift Positions ......240 Shifting Procedure ....241 Trac-Lok™...
Page 215 Replacement Tires ..... 266 Alignment And Balance ....267 Tire Pressure Monitor System (TPMS) —...
Page 216 216 STARTING AND OPERATING Towing Tips ......292 Towing — 4WD Models ....294 Recreational Towing (Behind Motorhome, Etc.) .
Page 217 STARTING PROCEDURES Before starting your vehicle, adjust your seat, adjust both inside and outside mirrors, and fasten your seat belts. WARNING! Do not leave children or animals inside parked vehicles in hot weather. Interior heat build up may cause serious injury or death. Manual Transmission Apply the parking brake, place the gearshift control lever in N (Neutral) and depress the clutch pedal before...
Page 218 218 STARTING AND OPERATING Normal Starting — Gasoline Engines Normal starting of either a cold or a warm engine is obtained without pumping or depressing the accelerator pedal. Turn the key to the START position and release when the engine starts. If the engine fails to start within 10 seconds, turn the key to the OFF position, wait 5 seconds, then repeat the normal starting procedure.
Page 219 CAUTION! To prevent damage to the starter, do not crank the engine for more than 15 seconds at a time. Wait 10 to 15 seconds before trying again. If the engine has been flooded, it may start to run, but not have enough power to continue running when the key is released.
Page 220 220 STARTING AND OPERATING operation may result in starter or battery damage. If the engine does not start at once, repeat Steps 1 through 4. • Cold engine speeds higher than necessary for driving or higher than specified for idling may damage engine components.
Page 221 Driving Conditions Stop & Go Stop & Go Highway Speeds City Traffic Highway Speeds Uphill Grade Diesel Fuel-Water Separator A diesel fuel-water separator separates the water nor- mally found in diesel fuel. A manual hand prime pump is located on the filter head for re-priming the fuel system. The fuel-water separator is located on the driver side cowl in the engine compartment.
Page 222 222 STARTING AND OPERATING Should your vehicle run out of fuel, the fuel system must be re-primed in order to start the engine. Factors such as temperature, which affects the viscosity of the fuel, how long the vehicle has been sitting and other factors will influence how quickly the engine starts.
Page 223 5. Depress the fuel-water separator knob 20 consecutive times. 6. Turn the ignition to START and crank the engine a maximum of 10 seconds. The engine should start and remain running. NOTE: If the engine does not start, repeat the cycle as many times as necessary.
Page 224 224 STARTING AND OPERATING TRANSMISSION SHIFTING 6-Speed Manual Transmission Follow the shift pattern on the gearshift knob. NOTE: The backup lights will come on when your vehicle is in R (Reverse) gear and the ignition is in the ON position. Manual Shift Controls...
Page 225 WARNING! When parking your vehicle, always leave a manual transmission in first gear and apply the parking brake fully to guard against vehicle movement and possible injury or damage. Never use any gear as a substitute for the parking brake. CAUTION! To drive as safely as possible and to prolong the life of your manual transmission, follow these tips:...
Page 226 226 STARTING AND OPERATING • When “rocking” a stuck vehicle by shifting between a forward gear and reverse, do not spin wheels faster than 15 mph (24 km/h), or drivetrain damage may result. Recommended Manual Transmission Shifting Speeds The manufacturer recommends that you use the shift speeds listed in the chart below.
Page 227 Automatic Transmission Shifting from D (Drive) to P (Park) or R (Reverse) (or from P or R to D) should be done only after the accelerator pedal is released and the vehicle is stopped. Be sure to keep your foot on the brake when moving the shift lever between these gears.
Page 228 228 STARTING AND OPERATING Gear Ranges P (Park) Supplements the parking brake by locking the transmis- sion. The engine can be started in this range. Never use P (Park) while the vehicle is in motion. Apply the parking brake when leaving the vehicle in this range. Always place the gear selector in the P (Park) position first, and then apply the parking brake.
Page 229 The following indicators should be used to ensure that you have engaged the transmission shift lever into the P (Park) position: • When shifting into P (Park), depress the button on the shift lever and firmly move the lever all the way forward until it stops.
Page 230 230 STARTING AND OPERATING WARNING! Do not coast in N (Neutral) and never turn off the ignition to coast down a hill. These are unsafe prac- tices that limit your response to changing traffic or road conditions. You might lose control of the vehicle. Overdrive (O/D) For most city and highway driving.
Page 231 Overdrive can be locked out by pressing the O/D OFF button located on side of the gearshift lever. The O/D OFF indicator light will illuminate to show that the switch has been activated. When the indicator light is on, Overdrive is locked out. Pressing the switch a second time restores the Overdrive function.
Page 232 232 STARTING AND OPERATING CAUTION! • Never press on the accelerator pedal with the engine running, vehicle in gear, and the brakes applied. Always apply the brakes when stopped on a incline. Failure to follow these instructions can cause overheating and damage to the trans- mission.
Page 233 (48 km/h). To understand the difference in operation, drive the vehicle so that TCC engagement conditions are correct, and then press and release the “O/D OFF” button once to disengage the TCC. Wait a few seconds, and then press and release the “O/D OFF” button again to engage the TCC.
Page 234 234 STARTING AND OPERATING CAUTION! When “rocking” a stuck vehicle by moving between “First” and R (Reverse), do not spin the wheels faster than 15 mph (24 km/h), or drivetrain damage may result. FOUR-WHEEL DRIVE OPERATION Command-Trac Operating Information/Precautions The Command-Trac transfer case provides 4 mode positions - 2 (rear) wheel drive high range, 4-wheel drive high range, neutral, and 4-wheel drive low range.
Page 235 CAUTION! • Do not attempt to make a shift while only the front or rear wheels are spinning. The Command- Trac transfer case is not equipped with a synchro- nizer and therefore the front and rear driveshaft speeds must be equal for the shift to take place. Shifting while only the front or rear wheels are spinning can cause damage to the transfer case.
Page 236 236 STARTING AND OPERATING WARNING! • Because 4-wheel drive provides improved trac- tion, there is a tendency to exceed safe turning and stopping speeds. Do not go faster than road con- ditions permit. • You or others could be injured if you leave the vehicle unattended with the transfer case in the Neutral (N) position without first fully engaging the parking brake.
Page 237 4-Wheel-Drive Low Range - Low speed 4 wheel drive. Locks the front and rear driveshafts together. Forces the front and rear wheels to rotate at the same speed. Additional traction and maximum pulling power for loose, slippery road surfaces only. Do not exceed 25 mph (40 km/h).
Page 238 238 STARTING AND OPERATING NOTE: Shifting into or out of 4L is possible with the vehicle completely stopped, however difficulty may oc- cur due to the mating clutch teeth not being properly aligned. Several attempts may be required for clutch teeth alignment and shift completion to occur.
Page 239 The PART TIME indicator light, located on the instru- ment cluster, illuminates when the transfer case is shifted to the 4 PART TIME position. The FULL TIME indicator light, located on the instru- ment cluster, illuminates when the transfer case is shifted to the 4 FULL TIME position.
Page 240 240 STARTING AND OPERATING Proper operation of 4-wheel drive vehicles depends on tires of equal size, type, and circumference on each wheel. Any difference will adversely affect shifting and can cause damage to the transfer case. WARNING! • Because 4-wheel drive provides improved trac- tion, there is a tendency to exceed safe turning and stopping speeds.
Page 241 Neutral - Disengages both the front and rear driveshafts from the powertrain. To be used for flat towing behind another vehicle. Refer to “Recreational Towing” in Sec- tion 5 for more information. Part Time 4–Wheel Drive Low Range - Low speed 4–wheel drive.
Page 242 242 STARTING AND OPERATING shifting. This will allow full engagement of the newly selected position. Apply a constant force when shifting the transfer case lever. 4 FULL TIME to 4 LO or 4 LO to 4 FULL TIME With the vehicle rolling at 2 to 3 mph (3 to 5 km/h), shift an automatic transmission to N (Neutral).
Page 243 TRAC-LOK™ REAR AXLE — IF EQUIPPED The optional Trac-Lok™ rear axle provides a constant driving force to both rear wheels and reduces wheel spin caused by the loss of traction at one driving wheel. If traction differs between the two rear wheels, the differ- ential automatically proportions the usable torque by providing more torque to the wheel that has traction.
Page 244 244 STARTING AND OPERATING To release the parking brake, pull up slightly, press the center button, then lower the lever completely. Before leaving the vehicle parked on a hill, you must make sure the parking brake is fully applied and place the gear selector in the P (Park) position.
Page 245 Be sure the parking brake is fully disengaged before driving. Failure to do so can lead to brake failure. NOTE: Parking brake adjustment and maintenance should be performed by your authorized dealer. ANTI-LOCK BRAKE SYSTEM — IF EQUIPPED The Anti-Lock Brake System is designed to aid the driver in maintaining vehicle control under adverse braking conditions.
Page 246 246 STARTING AND OPERATING During off-road use, loss of traction can temporarily defeat the system and cause the warning light to illumi- nate. Turn the ignition OFF and ON again to restore Anti-Lock Brake System function. WARNING! Pumping of the Anti-Lock Brakes will diminish their effectiveness and may lead to an accident.
Page 247 CAUTION! The Anti-Lock Brake System is subject to possible detrimental effects of electronic interference caused by improperly installed aftermarket radios or tele- phones. NOTE: During severe braking conditions, a pulsing sensation may occur and a clicking noise will be heard. This is normal, indicating that the Anti-Lock Brake System is functioning.
Page 248 248 STARTING AND OPERATING WARNING! Continued operation with reduced power steering assist could pose a safety risk to yourself and others. Service should be obtained as soon as possible. CAUTION! Prolong operation of the steering system at the end of the steering wheel travel will increase the steering fluid temperature and should be avoided when possible.
Page 249 OFF-ROAD DRIVING TIPS When To Use 4L or 4LO (Low) Range When off-road driving, shift to 4L or 4LO for additional traction and control on slippery or difficult terrain, ascending or descending steep hills, and to increase low-speed pulling power. This range should be limited to extreme situations such as deep snow, mud, or sand where additional low speed pulling power is needed.
Page 250 250 STARTING AND OPERATING and/or the flow rate is reduced. If you must cross flowing water avoid depths in excess of 9 inches. The flowing water can erode the streambed causing your vehicle to sink into deeper water. Determine exit point(s) that are downstream of your entry point to allow for drifting.
Page 251 If you stall or begin to lose headway while climbing a steep hill, allow your vehicle to come to a stop and immediately apply the brakes. Restart the engine and shift to R (Reverse). Back slowly down the hill allowing the compression braking of the engine to help regulate your speed.
Page 252 252 STARTING AND OPERATING After Driving Off-Road Off-road operation puts more stress on your vehicle than does most on-road driving. After going off-road it is always a good idea to check for damage. That way you can get any problems taken care of right away and have your vehicle ready when you need it.
Page 253 TIRE SAFETY INFORMATION Tire Markings NOTE: • P(Passenger)-Metric tire sizing is based on U.S. design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designation. Ex- ample: P215/65R15 95H. STARTING AND OPERATING 253 • European Metric tire sizing is based on European design standards.
Page 254 254 STARTING AND OPERATING Tire Sizing Chart Size Designation: P = Passenger car tire size based on U.S. design standards ...blank... = Passenger car tire based on European design standards LT = Light Truck tire based on U.S. design standards T = Temporary Spare tire 31 = Overall Diameter in Inches (in) 215 = Section Width in Milimeters (mm)
Page 255 Service Description: 95 = Load Index —A numerical code associated with the maximum load a tire can carry. H = Speed Symbol —A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions. —The maximum speed corresponding to the Speed Symbol should only be achieved un- der specified operating conditions.
Page 256 256 STARTING AND OPERATING Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire however the date code may only be on one side. Tires with white sidewalls will have the full TIN including date code DOT = Department of Transportation —This symbol certifies that the tire is in compliance with the U.S.
Page 257 STARTING AND OPERATING 257 Tire Loading and Tire Pressure Tire Placard Location NOTE: The proper cold tire inflation pressure for pas- senger cars is listed on either the face of the driver’s door or the driver’s side “B” pillar. For vehicles other than passenger cars, the cold tire inflation pressures are listed on either the shutface of the driver’s door, the “B”...
Page 258 258 STARTING AND OPERATING Tire and Loading Information Placard Tire and Loading Information This placard tells you important information about the: 1) number of people that can be carried in the vehicle 2) the total weight your vehicle can carry 3) the tire size designed for your vehicle 4) the cold tire inflation pressures for the front, rear and spare tires.
Page 259 combined weight of occupants, cargo/luggage and trailer tongue weight (if applicable) should never exceed the weight referenced here. Steps for Determining Correct Load Limit 1. Locate the statement “The combined weight of occu- pants and cargo should never exceed XXX pounds” on your vehicle’s placard.
Page 260 260 STARTING AND OPERATING...
Page 261 WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them. TIRES — GENERAL INFORMATION Tire Pressure Proper tire inflation pressure is essential to the safe and satisfactory operation of your vehicle.
Page 262 262 STARTING AND OPERATING 2. Economy— Improper inflation pressures can cause uneven wear patterns to develop across the tire tread. These abnormal wear patterns will reduce tread life resulting in a need for earlier tire replacement. Under inflation also increases tire rolling resistance and results in higher fuel consump- tion.
Page 263 check tire pressure. Do not make a visual judgement when determining proper inflation. Radial tires may look properly inflated even when they are under inflated. CAUTION! After inspecting or adjusting the tire pressure al- ways reinstall the valve stem cap–if equipped. This will prevent moisture and dirt from entering the valve stem, which could damage the valve stem.
Page 264 264 STARTING AND OPERATING Tire Pressures for High Speed Operation The manufacturer advocates driving at safe speeds within posted speed limits. Where speed limits or condi- tions are such that the vehicle can be driven at high speeds, maintaining correct tire inflation pressure is very important.
Page 265 WARNING! Fast spinning tires can be dangerous. Forces gener- ated by excessive wheel speeds may cause tire dam- age or failure. A tire could explode and injure someone. Do not spin your vehicle’s wheels faster than 35 mph (55 km/h) when you are stuck, and do not let anyone near a spinning wheel no matter what the speed.
Page 266 266 STARTING AND OPERATING Life of Tire The service life of a tire is dependent upon varying factors including but not limited to: • Driving style • Tire pressure • Distance driven WARNING! Tires and spare tire should be replaced after six years, regardless of the remaining tread.
Page 267 WARNING! • Do not use a tire, wheel size or rating other than that specified for your vehicle. Some combinations of unapproved tires and wheels may change sus- pension dimensions and performance characteris- tics, resulting in changes to steering, handling, and braking of your vehicle.
Page 268 268 STARTING AND OPERATING Improper alignment will not cause vehicle vibration. Vibration may be a result of tire and wheel out-of- balance. Proper balancing will reduce vibration and avoid tire cupping and spotty wear. TIRE PRESSURE MONITOR SYSTEM (TPMS) — IF EQUIPPED Base System The Tire Pressure Monitor System (TPMS) uses wireless...
Page 269 The system will consist of tire pressure monitoring sensors attached to each wheel through the valve stem mounting hole, a central receiver module and a “Tire Pressure Monitoring Telltale Light.” A sensor is located in the spare wheel if the vehicle is equipped with a match- ing full size spare wheel and tire assembly.
Page 270 270 STARTING AND OPERATING CAUTION! After inspecting or adjusting the tire pressure al- ways reinstall the valve stem cap. This will prevent moisture and dirt from entering the valve stem, which could damage the wheel rim sensor. NOTE: • The TPMS can inform the driver of a low tire pressure condition.
Page 271 when a system fault is detected. The flash cycle will repeat every ten minutes or until the fault condition is removed and reset. The Tire Pressure Monitor System (TPMS) consists of the following components: • Receiver Module • 4/5 Wheel Sensors •...
Page 272 272 STARTING AND OPERATING Telltale Light” will illuminate continuously (solid) and shall remain illuminated until the warning condition is removed/reset. NOTE: The “Tire Pressure Monitoring Telltale Light” will only illuminate for the four active road tires. A low spare tire pressure will not cause the “Tire Pressure Monitoring Telltale Light”...
Page 273 CAUTION! The TPMS has been optimized for the original equipment tires and wheels. TPMS pressures have been established for the tire size equipped on your vehicle. Undesirable system operation or sensor damage may result when using replacement equip- ment that is not of the same size, type, and/or style. After-market wheels can cause sensor damage.
Page 274 274 STARTING AND OPERATING General Information This device complies with part 15 of the FCC rules and RSS 210 of Industry Canada. Operation is subject to the following conditions: • This device may not cause harmful interference. • This device must accept any interference received, including interference that may cause undesired op- eration.
Page 275 Tire chains that are recommended for this vehicle are listed below: • Mopar P/N 82206828 with P235/70R16 and P235/ 65R17 tires. • Mopar P/N 82207074 with P215/75R16 tires. NOTE: In order to avoid damage to tires, chains, and your vehicle do not drive for a prolonged period of time on dry pavement.
Page 276 276 STARTING AND OPERATING 2.8L Turbo Diesel Engines Rotate the tires every 6,000 miles (10 000 km). NOTE: The Premium Tire Pressure Monitor System will automatically locate the pressure values displayed in the correct vehicle position following a tire rotation. The suggested rotation method is the “forward-cross”...
Page 277 • Low humidity Light spark knock at low engine speeds is not harmful to your engine. However, continued heavy spark knock at high speeds can cause damage and immediate service is required. Poor quality gasoline can cause problems such as hard starting, stalling and hesitations.
Page 278 278 STARTING AND OPERATING CAUTION! DO NOT use gasoline containing METHANOL. Gasoline containing methanol may damage critical fuel system components. MMT In Gasoline MMT is a manganese containing metallic additive that is blended into some gasoline to increase octane. Gasoline blended with MMT provides no performance advantage beyond gasoline of the same octane number without MMT.
Page 279 • The use of leaded gas is prohibited by Federal law. Using leaded gasoline can impair engine performance, damage the emission control system. • An out-of-tune engine, or certain fuel or ignition malfunctions, can cause the catalytic converter to overheat. If you notice a pungent burning odor or some light smoke, your engine may be out of tune or malfunctioning and may require immediate service.
Page 280 280 STARTING AND OPERATING the vehicle is raised. Have any abnormal conditions repaired promptly. Until repaired, drive with all side windows fully open. • Keep the swing gate closed when driving your vehicle to prevent carbon monoxide and other poisonous exhaust gases from entering the vehicle.
Page 281 FUEL TANK FILLER CAP (GAS CAP) CAUTION! • To avoid fuel spillage and overfilling, do not “top off” the fuel tank after filling. • DO NOT put gasoline in your diesel vehicle (if equipped). If you accidentally put gasoline in your vehicle, DO NOT start the engine.
Page 282 282 STARTING AND OPERATING Loose Fuel Filler Cap Message If the vehicle diagnostic system determines that the fuel filler cap is loose, improperly installed, or damaged, a “GAS CAP” message will be displayed in the odometer (located on the instrument cluster). Replace, or tighten the fuel filler cap properly to turn the message off (light will time out).
Page 283 Common Towing Definitions The following trailer towing related definitions will assist you in understanding the following information: Gross Vehicle Weight Rating (GVWR) The GVWR is the total allowable weight of your vehicle. This includes driver, passengers, cargo and tongue weight. The total load must be limited so that you do not exceed the GVWR.
Page 284 284 STARTING AND OPERATING WARNING! It is important that you do not exceed the maximum front or rear GAWR. A dangerous driving condition can result if either rating is exceeded. You could lose control of the vehicle and have an accident. Tongue Weight (TW) The downward force exerted on the hitch ball by the trailer.
Page 285 Trailer Hitch Classification The rear bumper is intended to tow trailers up to 2,000 lbs (907 kg) without added equipment or alterations to the standard equipment. Your vehicle may be factory equipped for safe towing of trailers weighing over 2,000 lbs (907 kg) with the optional Trailer Tow Prep Package.
Page 286 286 STARTING AND OPERATING Engine/ GVWR Model (Gross Vehicle Wt. Transmission Rating) 3.7L/6-Speed 5,350 lbs (2 427 kg) Manual 3.7L/6-Speed 5,600 lbs (2 540 kg) Manual 3.7L/ 5,350 lbs (2 427 kg) Automatic 3.7L/ 5,600 lbs (2 540 kg) 7,400 lbs ( 3 356 kg) 32 Sq. Ft. (2.97 Automatic 3.7L/ 5,350 lbs (2 427 kg)
Page 287 Note 1 – The trailer tongue weight must be considered as part of the combined weight of occupants and cargo, and should never exceed the weight referenced on the Tire and Loading Information placard. Refer to the Tire– Safety Information Section in this manual. Trailer and Tongue Weight Always load a trailer with 60% to 65% of the weight in the front of the trailer.
Page 288 288 STARTING AND OPERATING NOTE: Remember that everything put into or on the trailer adds to the load on your vehicle. Also, additional factory-installed options, or dealer-installed options, must be considered as part of the total load on your vehicle. Refer to the Tire and Loading Information plac- ard in the Tire Safety Information Section of this manual for the maximum combined weight of occupants and cargo for your vehicle.
Page 289 WARNING! Improper towing can lead to an injury accident. Follow these guidelines to make your trailer towing as safe as possible: Make certain that the load is secured in the trailer and will not shift during travel. When trailering cargo that is not fully secured, dynamic load shifts can occur that may be difficult for the driver to control.
Page 290 290 STARTING AND OPERATING 2. GTW 3. GAWR 4. Tongue weight rating for the trailer hitch utilized (This requirement may limit the ability to always achieve the 10% to 15% range of tongue weight as a percentage of total trailer weight). Towing Requirements —...
Page 291 actuated brakes. When towing a trailer equipped with a hydraulic surge actuated brake system, an electronic brake controller is not required. − Trailer brakes are recommended for trailers over 1,000 lbs (454 kg) and required for trailers in excess of 2,000 lbs (907 kg).
Page 292 292 STARTING AND OPERATING NOTE: Do not cut or splice wiring into the vehicles wiring harness. The electrical connections are all complete to the vehicle but you must mate the harness to a trailer connector. Refer to the following illustrations. 4 - Pin Connector 7- Pin Connector Towing Tips...
Page 293 If using a manual transmission vehicle for trailer towing, all starts must be in FIRST gear to avoid excessive clutch slippage. Towing Tips — Automatic Transmission The “D” range can be selected when towing. However, if frequent shifting occurs while in this range, the “3” range should be selected.
Page 294 294 STARTING AND OPERATING Towing Tips — Cooling System To reduce potential for engine and transmission over- heating, take the following actions: − City Driving When stopped for short periods of time, put transmission in neutral and increase engine idle speed. −...
Page 295 NOTE: The transfer case must be shifted into N (Neu- tral), and the transmission must be shifted into P (Park) (for automatic transmission) or into any forward gear (for manual transmission) for recreational towing. Shifting Into Neutral (N) Use the following procedure to prepare your vehicle for recreational towing.
Page 296 296 STARTING AND OPERATING CAUTION! Transmission damage may occur if the automatic transmission is shifted into P (Park) with the transfer case in N (Neutral) and the engine running. With the transfer case in N (Neutral) ensure that the engine is OFF prior to shifting the transmission into P (Park) (refer to steps 7 –...
Page 297 CAUTION! Do not use a bumper mounted clamp-on tow bar on your vehicle. The bumper face bar will be damaged. SNOW PLOW Snow plows, winches, and other aftermarket equipment should not be added to the front end of your vehicle. The airbag crash sensors may be affected by the change in the front end structure.
Page 299: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flashers ....300 If Your Engine Overheats ....301 Jacking And Tire Changing .
Page 300 300 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHERS Your vehicle’s hazard warning flasher is an emergency warning system. When you activate it, all front and rear directional signals will flash intermittently. Use it when your vehicle is disabled on or near the road. It warns other drivers to steer clear of you and your vehicle.
Page 301 IF YOUR ENGINE OVERHEATS In any of the following situations, you can reduce the potential for overheating by taking the appropriate ac- tion. • On the highways — Slow down. • In city traffic — While stopped, put transmission in N (Neutral), but do not increase engine idle speed.
Page 302 302 WHAT TO DO IN EMERGENCIES If the coolant temperature of a vehicle equipped with a diesel engine approaches the “H” (hot mark) a warning chime will sound to alert the driver. The air conditioning system will turn off automatically and power loss will occur until the engine temperature returns to the normal range.
Page 303 Jack Location The scissor-type jack, and tire changing tools are stored beneath the right rear seat. To remove the jack from its stowage position, turn the thumb screw counterclock- wise to loosen jack assembly and then remove it. Jack Storage Location WHAT TO DO IN EMERGENCIES 303 Spare Tire Stowage To remove the spare tire from the carrier, remove the tire...
Page 304 304 WHAT TO DO IN EMERGENCIES NOTE: If you have added aftermarket accessories to the spare tire mounted carrier, it cannot exceed a gross weight of 50 lbs (23 kg) including the weight of the spare tire. Preparations For Jacking Park the vehicle on a firm level surface, avoid ice or slippery areas, set the parking brake and place auto- matic transmission in P (Park), or manual transmission in...
Page 305 4. Locate the jack as shown. For the front tires, place it in the notch on the body weld seam behind wheel to be changed. For the rear tires, place it under the axle by the wheel to be changed. Position the jack handle on the jack. Do not raise the vehicle until you are sure the jack is fully engaged.
Page 306 306 WHAT TO DO IN EMERGENCIES WARNING! Raising the vehicle higher than necessary can make the vehicle less stable and cause an accident. It could slip off the jack and hurt someone near it. Raise the vehicle only enough to remove the tire. 6.
Page 307 JUMP STARTING — GASOLINE ENGINES NOTE: Check the charge indicator on the battery. If the indicator is light or yellow, replace the battery. 1. Wear eye protection and remove any metal jewelry such as watch bands or bracelets that might make an unintended electrical contact.
Page 308 308 WHAT TO DO IN EMERGENCIES NOTE: To start the vehicle following connection of a booster battery, the Security Alarm System must first be disabled by cycling a front door key cylinder or by using the keyless entry transmitter. WARNING! Jump starting can be dangerous.
Page 309 WARNING! Do not attempt to push or tow your vehicle to get it started. Unburned fuel could enter the catalytic converter and, once the engine has started, ignite and damage the converter and vehicle. EMERGENCY TOW HOOKS — IF EQUIPPED If your vehicle is equipped with tow hooks, they are mounted in the front and the rear.
Page 310 310 WHAT TO DO IN EMERGENCIES TOWING A DISABLED VEHICLE 2WD Models Only Provided the transmission is operable, tow only in N (Neutral) at speeds not exceeding 30 mph (48 km/h), for distances of not more than 15 miles (24 km). Towing at more than 30 mph (48 km/h) or for more than 15 miles (24 km) can cause severe transmission damage.
Page 311: Maintaining Your Vehicle
MAINTAINING YOUR VEHICLE CONTENTS 3.7L Engine ......314 2.8L Turbo Diesel Engine ....315 Onboard Diagnostic System —...
Page 312 312 MAINTAINING YOUR VEHICLE Driveline And Steering Component Lubrication ......329 Body Lubrication ..... 329 Windshield Wiper Blades .
Page 313 Rear Tail, Stop, Turn Signal, And Back-Up Lights ......360 Center High Mounted Stop Light (CHMSL) . . . 361 Fluid Capacities .
Page 314 314 MAINTAINING YOUR VEHICLE 3.7L ENGINE...
Page 315 MAINTAINING YOUR VEHICLE 315 2.8L TURBO DIESEL ENGINE...
Page 316 316 MAINTAINING YOUR VEHICLE ONBOARD DIAGNOSTIC SYSTEM — OBD II Your vehicle is equipped with a sophisticated onboard diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic transmission control systems. When these systems are operating properly, your vehicle will provide excellent performance and fuel economy, as well as engine emis- sions well within current government regulations.
Page 317 the fuel filler cap properly to turn the message off (light will time out). If the problem continues, the message will appear the next time the vehicle is started. EMISSIONS INSPECTION AND MAINTENANCE PROGRAMS In some localities, it may be a legal requirement to pass an inspection of your vehicle’s emissions control system.
Page 318 318 MAINTAINING YOUR VEHICLE a. The MIL will flash for about 10 seconds and then return to being fully illuminated until you turn off the ignition key or start the engine. This means that your vehicle’s OBD system is not ready and you should not proceed to the I/M station.
Page 319 NOTE: Intentional tampering with emissions control systems can result in civil penalties being assessed against you. WARNING! You can be badly injured working on or around a motor vehicle. Do only that service work for which you have the knowledge and the proper equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent mechanic.
Page 320 320 MAINTAINING YOUR VEHICLE The best time to check the engine oil level is about 5 minutes after a fully warmed engine has been shut off, or before starting the engine after it has sat overnight. Checking the oil while the vehicle is on level ground will improve the accuracy of the oil level readings.
Page 321 If ANY of these apply to you, then change your engine oil at every interval shown in schedule “B” of the “Mainte- nance Schedules” section of this manual. If none of these apply to you, then change your engine oil at every interval shown on schedule “A”...
Page 322 322 MAINTAINING YOUR VEHICLE Lubricants which do not have both, the engine oil certi- fication mark and the correct SAE viscosity grade num- ber should not be used. Engine Oil Selection (Diesel Engines) For best performance and maximum protection for all engines under all types of operating conditions, the manufacturer recommends using synthetic engine oils that meet API categories SM and CF (SM/CF), and meet...
Page 323 Disposing of Used Engine Oil Care should be taken in disposing of used engine oil from your vehicle. Used oil and oil filters, indiscriminately discarded, can present a problem to the environment. Contact your authorized dealer, service station, or gov- ernmental agency for advice on how and where used oil can be safely discarded in your area.
Page 324 324 MAINTAINING YOUR VEHICLE Spark Plugs Spark plugs must fire properly to assure engine perfor- mance and emission control. New plugs should be in- stalled at the mileage specified in the appropriate main- tenance chart. The entire set should be replaced if there is any malfunction due to a faulty spark plug.
Page 325 WARNING! A hot exhaust system can start a fire if you park over materials that can burn. Such materials might be grass or leaves coming into contact with your ex- haust system. Do not park or operate your vehicle in areas where your exhaust system can contact any- thing that can burn.
Page 326 326 MAINTAINING YOUR VEHICLE Crankcase Emission Control System Proper operation of this system depends on freedom from sticking or plugging due to deposits. As vehicle mileage builds up, the PCV valve and passages may accumulate deposits. If a valve is not working properly, replace it with a new valve.
Page 327 WARNING! Battery posts, terminals, and related accessories con- tain lead and lead compounds. Always wash hands after handling the battery. To determine the battery charge, check the battery test indicator (if equipped) on top of the battery. Refer to the illustration.
Page 328 328 MAINTAINING YOUR VEHICLE WARNING! • Use only refrigerants and compressor lubricants approved by the manufacturer for your air condi- tioning system. Some unapproved refrigerants are flammable and can explode, injuring you. Other unapproved refrigerants or lubricants can cause the system to fail, requiring costly repairs. Refer to Section 3 of the Warranty Information Book for additional warranty information.
Page 329 WARNING! Fluid level should be checked on a level surface with the engine off to prevent injury from moving parts, and to insure accurate fluid level reading. Do not overfill. Use only the manufacturer’s recommended fluid. If necessary, add fluid to restore to the proper indicated level.
Page 330 330 MAINTAINING YOUR VEHICLE attention should also be given to hood latching compo- nents to insure proper function. When performing other underhood services, the hood latch, release mechanism and safety catch should be cleaned and lubricated. The external lock cylinders should be lubricated twice a year, preferably in the fall and spring.
Page 331 should be checked for fluid level at regular intervals. Fill the reservoir with windshield washer solvent (not antifreeze/coolant) and operate the system for a few seconds to flush out the residual water. WARNING! Commercial windshield washer solvents are flam- mable. They could ignite and burn you. Care must be exercised when filling or working around the washer solution.
Page 332 332 MAINTAINING YOUR VEHICLE Cooling System WARNING! You or others can be badly burned by hot antifreeze/ coolant or steam from your radiator. If you see or hear steam coming from under the hood, don’t open the hood until the radiator has had time to cool. Never try to open a cooling system pressure cap when the radiator or coolant bottle is hot.
Page 333 Selection Of Engine Coolant Use only the manufacturer’s recommended antifreeze/ coolant, refer to Fluids, Lubricants, and Genuine Parts for correct antifreeze/coolant type. MAINTAINING YOUR VEHICLE 333 CAUTION! • Mixing of antifreeze/coolant other than the speci- fied HOAT antifreeze/coolant may result in de- creased corrosion protection and engine damage.
Page 334 334 MAINTAINING YOUR VEHICLE Adding Engine Coolant Your vehicle has been built with an improved antifreeze/ coolant that allows extended maintenance intervals. This antifreeze/coolant can be used up to 5 Years or 100,000 miles before replacement. To prevent reducing this ex- tended maintenance period, it is important that you use the same antifreeze/coolant throughout the life of your vehicle.
Page 335 The cap should be inspected and cleaned if there is any accumulation of foreign material on the sealing surfaces. WARNING! The warning words DO NOT OPEN HOT on the cooling system pressure cap are a safety precaution. Never add antifreeze/coolant when the engine is overheated.
Page 336 336 MAINTAINING YOUR VEHICLE When additional antifreeze/coolant is needed to main- tain the proper level, it should be added to the coolant recovery bottle. Do not overfill. Points To Remember NOTE: When the vehicle is stopped after a few miles (kilometers) of operation, you may observe vapor coming from the front of the engine compartment.
Page 337 ONLY the correct type thermostat. Other designs may result in unsatisfactory cooling performance, poor gas mileage, and increased emissions. Hoses and Vacuum/Vapor Harnesses Inspect surfaces of hoses and nylon tubing for evidence of heat and mechanical damage. Hard or soft spots, brittle rubber, cracking, tears, cuts, abrasions, and exces- sive swelling indicate deterioration of the rubber.
Page 338 338 MAINTAINING YOUR VEHICLE Brake and Power Steering System Hoses When servicing the vehicle for scheduled maintenance, inspect surface of hoses for evidence of heat and me- chanical damage. Hard and brittle rubber, cracking, tears, cuts, abrasion, and excessive swelling suggest deteriora- tion of the rubber.
Page 339 Be sure to clean the top of the master cylinder area before removing the cap. If necessary, add fluid to bring the fluid level up to the requirements described on the brake fluid reservoir. With disc brakes, fluid level can be expected to fall as the brake pads wear.
Page 340 340 MAINTAINING YOUR VEHICLE Use only brake fluid that has been in a tightly closed container to avoid contamination from foreign matter. Do not allow petroleum base fluid to contaminate the brake fluid as seal damage will result. Automatic Transmission Selection of Lubricant It is important that the proper lubricant is used in the transmission to assure optimum transmission perfor-...
Page 341 To check the automatic transmission fluid level properly, the following procedure must be used: 1. The vehicle must be on level ground. 2. The engine should be running at curb idle speed for a minimum of 60 seconds. 3. Fully apply parking brake. 4.
Page 342 342 MAINTAINING YOUR VEHICLE Hydraulic Clutch Fluid — Manual Transmission The clutch hydraulic system is a sealed maintenance free system. In the event of leakage or other malfunction, the system must be replaced. Manual Transmission Selection of Lubricant Use only manufacturer’s recommended manual trans- mission fluid, refer to Fluids, Lubricants, and Genuine Parts for correct fluid type.
Page 343 Adding Fluid Only at filler hole until fluid runs out of the hole, when the vehicle is in a level position. Drain First remove fill plug (B), then drain plug (C). Recom- mended tightening torque for drain and fill plugs is 15–25 ft.
Page 344 344 MAINTAINING YOUR VEHICLE Adding Fluid Add lubricant only at the fill hole and only to the level specified above. Selection of Lubricant Use only manufacturer’s recommended fluid, refer to Fluids, Lubricants, and Genuine Parts for correct fluid type. Maintenance After Off-Pavement Driving After extended operation in mud, sand or water, or similar dirty conditions, have your brake drums, brake linings, and axle joints inspected and cleaned as soon as...
Page 345 Appearance Care And Protection From Corrosion Protection Of Body And Paint From Corrosion Vehicle body care requirements vary according to geo- graphic locations and usage. Chemicals that make roads passable in snow and ice, and those that are sprayed on trees and road surfaces during other seasons, are highly corrosive to the metal in your vehicle.
Page 346 346 MAINTAINING YOUR VEHICLE • Use Mopar Cleaner Wax to remove road film, stains, and to protect your paint finish. Take care never to scratch the paint. • Avoid using abrasive compounds and power buffing that may diminish the gloss or thin out the paint finish.
Page 347 oven cleaner. Avoid automatic car washes that use acidic solutions or harsh brushes that may damage the wheels’ protective finish. • If you carry special cargo such as chemicals, fertilizers, de-icer salt, etc., assure that such materials are well packaged and sealed. •...
Page 348 348 MAINTAINING YOUR VEHICLE WARNING! Do not use volatile solvents for cleaning purposes. Many are potentially flammable, and if used in closed areas they may cause respiratory harm. Glass Surfaces All glass surfaces should be cleaned on a regular basis with Mopar Glass Cleaner or any commercial household-type glass cleaner.
Page 349 FUSE PANEL Interior Fuses The fuse panel is on the left side of the instrument panel. A label is attached to the fuse panel cover to identify each fuse for ease of replacement. Fuse Panel MAINTAINING YOUR VEHICLE 349 Cavity Fuse Description 15 Amp Blue Horn Relay, Power Sunroof...
Page 350 350 MAINTAINING YOUR VEHICLE Cavity Fuse Description 10 Amp Red Body Control Module/ CMTC/Cluster/Pass. Airbag On,Off Indicator, Auto Day- light Mirror/Light Bar Switch (Renegade Only) 10 Amp Red PDC Fuel Pump/AC Clutch, Starter Relay/Engine Controller/Transmission Controller (Diesel Only) Spare 20 Amp Yellow Power Outlet (Rear) 15 Amp Blue Rear Wiper 20 Amp Yellow Radio Choke &...
Page 351 Cavity Fuse Description 15 Amp Blue Body Control Module/ Cluster/Interior Lights, Hands Free Module/Radio/ CMTC/ITM Module & Siren (Export Only) Spare 10 Amp Red Airbag Control Module/ Occupation Classification Module (Right Front Seat) 10 Amp Red Airbag Control Module 10 Amp Red ABS Controller/Shifter As- sembly 10 Amp Red...
Page 352 352 MAINTAINING YOUR VEHICLE Power Distribution Center Power Distribution Center (Gasoline Engines) Cavity Fuse Description 40 Amp Green Blower Motor 40 Amp Green Radiator Fan 50 Amp Red JB Power 40 Amp Green ABS Pump 20 Amp Yellow NGC Trans 30 Amp Pink 50 Amp Red JB Power...
Page 353 Cavity Fuse Description Open Open Open 30 Amp Pink Rear Window Defogger (HBL) Open 20 Amp Yellow A/C Clutch Open Open 20 Amp Yellow Fuel Pump 20 Amp Yellow ABS Valves 25 Amp Natural Injectors Open 15 Amp Blue Starter Half ISO Relay Fuel Pump Half ISO Relay...
Page 354 354 MAINTAINING YOUR VEHICLE Power Distribution Center (Diesel Engines) Cavity Fuse Description 40 Amp Green Blower Motor 40 Amp Green Radiator Fan 50 Amp Red JB Power 40 Amp Green ABS Pump Open 30 Amp Pink 50 Amp Red JB Power 40 Amp Green Ign/Start 50 Amp Red...
Page 355 Cavity Fuse Description Half ISO Relay Wiper On/Off Half ISO Relay Wiper Hi/Lo Full ISO Relay H. Blower Full ISO Relay Rad. Fan Hi Half ISO Relay A/C Clutch Half ISO Relay Viscous Heat Open Open Full ISO Relay Full ISO Relay Rad.
Page 356 356 MAINTAINING YOUR VEHICLE REPLACEMENT BULBS Interior Lights A/C Heater ....Not Serviceable Ashtray Receiver Light ....161 Climate Control (Manual A/C).
Page 357 3. Firmly grasp the lock ring on the back of the headlamp unit housing. 4. Rotate the lock ring on the back of the headlamp housing counter-clockwise to unlock it. CAUTION! Do not touch the new bulb with your fingers. Oil contamination will severely shorten bulb life.
Page 358 358 MAINTAINING YOUR VEHICLE 3. Rotate the bulb socket counter-clockwise to unlock it. CAUTION! Do not touch the new bulb with your fingers. Oil contamination will severely shorten bulb life. If the bulb comes in contact with any oily surface, clean the bulb with rubbing alcohol.
Page 359 4. Pivot the retainer clip up off of the bulb flange and out of the way. CAUTION! Do not touch the new bulb with your fingers. Oil contamination will severely shorten bulb life. If the bulb comes in contact with any oily surface, clean the bulb with rubbing alcohol.
Page 360 360 MAINTAINING YOUR VEHICLE CAUTION! Do not touch the new bulb with your fingers. Oil contamination will severely shorten bulb life. If the bulb comes in contact with any oily surface, clean the bulb with rubbing alcohol. 5. Replace the bulb. Rear Tail, Stop, Turn Signal, and Back-Up Lights 1.
Page 361 Center High Mounted Stop Light (CHMSL) 1. Remove the two screws securing the CHMSL. 2. Twist the bulb socket to remove from the CHMSL housing. 3. Pull the bulb out of the socket. MAINTAINING YOUR VEHICLE 361 4. Replace the bulb, reinstall the socket and reattach the CHMSL.
Page 362 362 MAINTAINING YOUR VEHICLE FLUID CAPACITIES Fuel (Approximate) Engine Oil with Filter 3.7 Liter Engines (SAE 5W-30, API Certified Engine Oil) 2.8 Liter Diesel Engine (SAE 0W-40 Synthetic Engine Oil) Cooling System * 3.7 Liter Engine (Mopar Antifreeze/Coolant 5 Year/100,000 Mile Formula) 2.8 Liter Diesel Engine (Mopar Antifreeze/Coolant 5 Year/ 100,000 Mile Formula)
Page 363 FLUIDS, LUBRICANTS, AND GENUINE PARTS Engine Component Fluid, Lubricant, or Genuine Part Engine Coolant Mopar Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Organic Ad- ditive Technology) Engine Oil (3.7L Engines) Use API Certified SAE 5W-30 Engine Oil, meeting the requirements of DaimlerChrysler Material Standard MS-6395.
Page 364 364 MAINTAINING YOUR VEHICLE Chassis Component Automatic Transmission Manual Transmission Transfer Case Axle Differential (Front) Axle Differential (Rear) Brake Master Cylinder Power Steering Reservoir Fluid, Lubricant, or Genuine Part Mopar ATF+4 Automatic Transmission Fluid Mopar Manual Transmission Lubricant or equivalent (meeting the re- quirements of DaimlerChrysler Material Standard MS-9224) Mopar ATF+4 Automatic Transmission Fluid Mopar Gear &...
Page 365: Maintenance Schedules
MAINTENANCE SCHEDULES CONTENTS Emission Control System Maintenance ..366 Maintenance Schedules — Gasoline Engines ..366 Schedule “B” — Gasoline Engines ..369 Schedule “A”...
Page 366 366 MAINTENANCE SCHEDULES EMISSION CONTROL SYSTEM MAINTENANCE The “Scheduled” maintenance services, listed in bold type must be done at the times or mileages specified to assure the continued proper functioning of the emission control system. These, and all other maintenance services included in this manual, should be done to provide best vehicle performance and reliability.
Page 367 • Heavy loading. • Taxi, police, or delivery service (commercial service). • Off-road or desert driving. • If equipped for and operated with E-85 (ethanol) fuel. NOTE: If ANY of these apply to you then change your engine oil every 3,000 miles (5 000 km) or 3 months, whichever comes first and follow “Schedule B”...
Page 368 368 MAINTENANCE SCHEDULES • Check the windshield washer solvent, add as required. Once a Month • Check the tire pressure and look for unusual wear or damage. • Inspect the battery, and clean and tighten the terminals as required. • Check the fluid levels of the engine coolant/anti- freeze reservoir, brake master cylinder, and transmis- sion, and add as needed.
Page 369 Schedule “B” — Gasoline Engines Follow schedule “B” if you usually operate your vehicle under one or more of the following conditions. • Day or night temperatures are below 32°F (0°C). • Stop and go driving. • Extensive engine idling. •...
Page 370 370 SCHEDULE “B” — GASOLINE ENGINES Miles (Kilometers) Change the engine oil and engine oil filter, if not replaced at 3 months. Rotate the tires. Inspect the engine air filter element, replace if necessary. Inspect the brake linings. Drain and refill the front and rear axle fluid‡ 3,000 6,000 9,000...
Page 371 Miles (Kilometers) Change the engine oil and engine oil filter, if not replaced at 3 months. Rotate the tires. Inspect the engine air filter element, replace if necessary. Replace the spark plugs. Inspect and replace the PCV valve, if necessary. Inspect the brake linings.
Page 372 372 SCHEDULE “B” — GASOLINE ENGINES Miles (Kilometers) Change the engine oil and engine oil filter, if not replaced at 3 months. Rotate the tires. Inspect the engine air filter element, replace if necessary. Inspect the brake linings. Drain and refill the front and rear axle fluid‡ Inspect the drive belt and replace as needed.
Page 373 Miles (Kilometers) Change the engine oil and engine oil filter, if not replaced at 3 months. Rotate the tires. Inspect the engine air filter element, replace if necessary. Replace the spark plugs. Inspect and replace the PCV valve, if necessary. Inspect the brake linings.
Page 374 374 SCHEDULE “B” — GASOLINE ENGINES Miles (Kilometers) Change the engine oil and engine oil filter, if not replaced at 3 months. Rotate the tires. Inspect the engine air filter element, replace if necessary. Inspect the brake linings. Drain and refill the front and rear axle fluid‡ Inspect the drive belt and replace as needed.
Page 375 Miles (Kilometers) Change the engine oil and engine oil filter, if not replaced at 3 months. Rotate the tires. Inspect the engine air filter element, replace if necessary. Replace the spark plugs. Inspect and replace the PCV valve, if necessary. Inspect the brake linings.
Page 376 376 SCHEDULE “B” — GASOLINE ENGINES Miles (Kilometers) Change the engine oil and engine oil filter, if not replaced at 3 months. Rotate the tires. Inspect the engine air filter element, replace if necessary. Inspect the brake linings. Drain and refill the front and rear axle fluid‡ Inspect the drive belt and replace as needed.
Page 377 Miles (Kilometers) Change the engine oil and engine oil filter, if not replaced at 3 months. Rotate the tires. Inspect the engine air filter element, replace if necessary. Replace the spark plugs. Inspect and replace the PCV valve, if necessary. Inspect the brake linings.
Page 378 378 SCHEDULE “B” — GASOLINE ENGINES Miles (Kilometers) Drain and refill the transfer case fluid. Flush and replace the engine coolant/anti-freeze at 120 months, if not replaced at 102,000 miles (170 000 km). Inspection and service should be performed anytime a malfunction is observed or suspected.
Page 379 Schedule “A” — Gasoline Engines Miles (Kilometers) [Months] Change the engine oil and engine oil filter. Rotate the tires. Inspect the engine air filter element, and replace if necessary. Replace the spark plugs. Inspect the manual transmission fluid, add as nec- essary.
Page 380 380 SCHEDULE “A” — GASOLINE ENGINES Miles (Kilometers) [Months] Change the engine oil and engine oil filter. Rotate the tires. Inspect the brake linings. 36,000 42,000 48,000 (60 000) (70 000) (80 000) [36] [42] [48] 54,000 (90 000) [54]...
Page 381 Miles (Kilometers) [Months] Change the engine oil and engine oil filter. Rotate the tires. Inspect the engine air filter element, and replace if nec- essary. Replace the spark plugs. Inspect and replace the PCV valve, if necessary. Inspect the brake linings. Inspect the drive belt and replace, if needed.
Page 382 382 SCHEDULE “A” — GASOLINE ENGINES Miles (Kilometers) [Months] Change the engine oil and engine oil filter. Rotate the tires. Inspect the engine air filter element, and replace if nec- essary. Replace the spark plugs. Inspect and replace the PCV valve, if necessary. Inspect the brake linings.
Page 383 Miles (Kilometers) [Months] Change the engine oil and engine oil filter. Rotate the tires. Inspect the engine air filter element, and replace if necessary. Replace the spark plugs. Inspect and replace the PCV valve, if necessary. Inspect the brake linings. Inspect the drive belt and replace as needed.
Page 384 384 SCHEDULE “A” — GASOLINE ENGINES MAINTENANCE SCHEDULES — DIESEL ENGINES There are two maintenance schedules that show the required service for your vehicle. First is Schedule B . It is for vehicles that are operated under the conditions that are listed below and at the beginning of the schedule.
Page 385 At Each Stop for Fuel • Check the engine oil level about 5 minutes after a fully warmed engine is shut off. Checking the oil level while the vehicle is on level ground will improve the accu- racy of the oil level reading. Add oil only when the level is at or below the ADD or MIN mark.
Page 386 386 SCHEDULE “B” — DIESEL ENGINES Schedule “B” — Diesel Engines Follow schedule “B” if you usually operate your vehicle under one or more of the following conditions. • Day or night temperatures are below 32°F (0°C). • Stop and go driving. •...
Page 387 Miles (Kilometers) Change the engine oil and engine oil filter. Inspect the engine air filter element. Replace as necessary. Replace the engine air filter element. Inspect the boost pressure solenoid filter. Replace as necessary. Replace the fuel filter/water separator unit. Inspect the brake linings.
Page 388 388 SCHEDULE “B” — DIESEL ENGINES Miles (Kilometers) Change the engine oil and engine oil filter. Inspect the engine air filter element. Replace as necessary. Replace the engine air filter element. Inspect the boost pressure solenoid filter. Replace as necessary. Replace the boost pressure solenoid filter, if not previously replaced.
Page 389 Miles (Kilometers) Change the engine oil and engine oil filter. Inspect the engine air filter element. Re- place as necessary. Replace the engine air filter element. Inspect the boost pressure solenoid filter. Re- place as necessary. Replace the boost pressure solenoid filter, if not previously replaced.
Page 390 390 SCHEDULE “B” — DIESEL ENGINES Miles (Kilometers) Inspect the brake linings. Drain and refill the front and rear axle fluid. Applies only if vehicle is used for frequent trailer towing, or fleet/commercial service. † The replacement of such component is requested if there is superficial wear, bearing clearance, or evident grease leak.
Page 391 Schedule “A” — Diesel Engines Miles (Kilometers) Change the engine oil and engine oil filter. Inspect the engine air filter element. Replace as neces- sary. Replace the engine air filter element. Inspect the boost pressure solenoid filter. Replace as nec- essary.
Page 392 392 SCHEDULE “A” — DIESEL ENGINES Miles (Kilometers) Change the engine oil and engine oil filter. Inspect the engine air filter element. Replace as necessary. Replace the engine air filter element. Inspect the boost pressure solenoid filter. Replace as necessary. Replace the boost pressure solenoid filter, if not previously replaced.
Page 393: If You Need Consumer Assistance
IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Vehicle ......394 Prepare For The Appointment .
Page 394 We want you to be happy with our products and services. Warranty service must be done by an authorized Chrysler, Dodge, or Jeep dealer. We strongly recommend that you take your vehicle to your selling dealer. They know you and your vehicle best, and are most concerned that you get prompt and high quality service.
Page 395 technicians, special tools, and the latest information to assure your vehicle is fixed correctly and in a timely manner. This is why you should always talk to your dealer’s service manager first. Most matters can be resolved with this process. •...
Page 396 396 IF YOU NEED CONSUMER ASSISTANCE Customer Assistance For The Hearing Or Speech Impaired (TDD/TTY) To assist customers who have hearing difficulties, the manufacturer has installed special TDD (Telecommuni- cation Devices for the Deaf) equipment at its Customer Center. Any hearing or speech impaired customer who has access to a TDD or a conventional teletypewriter (TTY) in the United States can communicate with the manufacturer by dialing 1–800–380–CHRY.
Page 397 WARRANTY INFORMATION (U.S. Vehicles Only) See the Warranty Information Booklet for the terms and provisions of DaimlerChrysler’s warranties applicable to this vehicle. MOPAR PARTS Mopar fluids, lubricants, parts, and accessories are available from your dealer. They will help you keep your vehicle operating at its best.
Page 398 398 IF YOU NEED CONSUMER ASSISTANCE PUBLICATION ORDER FORMS To order the following manuals, you may use either the website or the phone numbers listed below. Visa, Mas- tercard, American Express, and Discover orders are ac- cepted. If you prefer mailing your payment, please call for an order form.
Page 399 Call Toll Free at: • 1–800–890–4038 (U.S.) • 1–800–387–1143 (Canada) Visit us on the World Wide Web at: • www.techauthority.daimlerchrysler.com • www.daimlerchrysler.ca/manuals DEPARTMENT OF TRANSPORTATION UNIFORM TIRE QUALITY GRADES The following describes the tire grading categories estab- lished by the National highway Traffic Safety Adminis- tration.
Page 400 400 IF YOU NEED CONSUMER ASSISTANCE on specified government test surfaces of asphalt and concrete. A tire marked C may have poor traction perfor- mance. WARNING! The traction grade assigned to this tire is based on straight-ahead braking traction tests, and does not include acceleration, cornering, hydroplaning, or peak traction characteristics.
Page 401 INDEX...
Page 402 402 INDEX ABS (Anti-Lock Brake System) ... . 175,245 Adding Washer Fluid ..... 163 Air Cleaner, Engine (Engine Air Cleaner Filter) .
Page 403 Bar, Light ......119,359 Battery ....... 326 Emergency Starting .
Page 404 404 INDEX Caution, Exhaust Gas ....72,147 CD (Compact Disc) Changer ... . . 189,199 CD (Compact Disc) Player .
Page 405 Temperature Gauge ..... 176 Crankcase Emission Control System Cruise Control (Speed Control) ....133 Cruise Light .
Page 406 406 INDEX Electronic Stability Program (ESP) ... . 129 Electronic Throttle Control Warning Light ..180 Electronic Vehicle Information Center (EVIC) ..137 Emergency, In Case of Freeing Vehicle When Stuck .
Page 407 Exhaust Gas Caution ....72,279 Exhaust System ......331 Exterior Finish Care .
Page 408 408 INDEX Octane Rating ......276 Requirements ....276,280,362 Tank Capacity .
Page 409 Hitches Trailer Towing ......285 Holder, Cup ......155 HomeLink (Garage Door Opener) Transmitter .
Page 410 410 INDEX Lane Change and Turn Signals ....173 Lap/Shoulder Belts ..... . . 36 LATCH (Lower Anchors and Tether for CHildren) .
Page 411 Malfunction Indicator (Check Engine) ..174 Map Reading ......116 Oil Pressure .
Page 412 412 INDEX Diesel ......384 Light Duty Schedule “A” ....379,391 Light Duty Schedule “B”...
Page 413 Capacity ......362 Change Interval ..... . . 320 Checking .
Page 414 414 INDEX Windows ......32 Pregnant Women and Seat Belts ....46 Preparation for Jacking .
Page 415 Restraints, Occupant ..... . 34 Retractable Cargo Area Cover ....157 Rocking Vehicle When Stuck .
Page 416 416 INDEX Sentry Key (Immobilizer) ....14 Sentry Key Programming ....16 Sentry Key Replacement .
Page 417 Storage, Vehicle ......355 Storing Your Vehicle ..... . 355 Sun Roof .
Page 418 418 INDEX Sizes ....... 254 Spare Tire ......303 Spinning .
Page 419 Turbo Cool Down ..... . . 220 Turn Signals ....117,173,357,360 Underhood Fuses .
Page 420 NOTES...
Page 421 NOTES...
Page 422 NOTES...
Page 423 NOTES...
Page 424 NOTES...

This manual is also suitable for:

Liberty

Jeep 2006 Liberty Owner's Manual

Quick Links

TABLE OF CONTENTS

Need help?

Questions and answers

Related Manuals for Jeep 2006 Liberty

Summary of Contents for Jeep 2006 Liberty

This manual is also suitable for:

Table of Contents
