Summary of Contents for Hans Grohe Focus 04506 1 Series
- Page 1 Installation / User Instructions / Warranty Instructions de montage / Mode d'emploi / Garantie Instrucciones de montaje / Manejo / Garantía Focus Talis S 04505xx0 14872xx1 04506xx1 Talis S Talis S 14877xx1 04247xx0 04310xx1 04286xx0...
-
Page 2: Technical Information
English Français Technical Information Données techniques Water pressure Pression d’eau Recommended 15 - 75 PSI (0.1 - 0.5 MPa) recommandée 15 - 75 PSI (0.1 - 0.5 MPa) Maximum 145 PSI (1 MPa) maximum 145 PSI (1 MPa) Hot water temp. Température d'eau chaude Recommended 120°-140°... -
Page 3: Consideraciones Para La Instalación
Español Datos tecnicos Tools Required / Outiles Utiles / Herramientas Útiles Presión en servicio recomendada 15 - 75 PSI (0.1 - 0.5 MPa) max. 145 PSI (1 MPa) Temperatura del agua caliente recomendada 120°-140° F (48° - 60° C)* max. 158°F (70°... - Page 4 Talis S 14877xx1 04310xx1 1⅛" 3⅛" 2⅛" 8¾" 5¼" 3¾" 2" 1⅜" ⅜" Talis S Talis S 04286xx0 14872xx1 1⅛" 1⅛" 5¼" 8¼" 3¾" 5¼" 7⅜" 3¾" 2" 2" 1⅜" 1⅜" ⅜" ⅜"...
- Page 5 Focus Focus 04505xx0 04506xx1 9¼" 7⅜" 1⅛" 1⅛" 3¾" 3¾" 2½" 2½" 2" 2" 8⅝" 1⅜" 1⅜" ⅜ ⅜ Talis S 04247xx0 4⅛" 3⅝" 1¼" 2" 1⅜" 9" 10" ⅜...
-
Page 6: Installation / Installation / Instalación
Installation / Installation / Instalación English Français Español Place the faucet and sealing ring Placez l'anneau d'étanchéite Coloque el oro de sellado y on the mounting surface. et le robinet sur la surface de el grifo sobre la superficie de montage. - Page 7 English Français Español Connect the hot and cold sup- Connectez les tuyaux d'arrivée Conecte las mangueras de sumi- ply hoses to the stops. Use two d'eau chaude et d'eau froide nistro de agua caliente y fría a wrenches. aux tuyau d'alimentation. las alimentaciones de la red.
- Page 8 04286xx0 04247xx0 04505xx0 04310xx0 04506xx1 14872xx1 14877xx1 English Français Español Install the hose weight on the Installez le contrepoids sur le Instale el contrapeso. handshower side of the hose, tuyau. near the loop. Test the handspray hose. If it Tirez sur la douchette. Elle Tire del rociador de mano.
- Page 9 > 2 min English Français Español Remove the sprayhead. Retirez la douchette. Retire la ducha. Remove the hose filter. Retirez le filtre. Retire el filtro. Flush the faucet for at least two Rincez le robinet pour un mini- Enjuague el grifo durante un minutes.
- Page 10 English Français Español Flush the hose filter. Rincez le filtre. Enjuague el filtro. Reinstall the hose filter and Installez le filtre et la douchette. Instale el filtro y la ducha. sprayhead.
- Page 11 Set the High Temperature Limit Stop (optional) / Réglage de la butée limite d’eau chaude (en option) / Ajuste el tope de límite de alta temperatura (opcional) 140 °F 50 °F 44 PSI...
- Page 12 Replacement Parts / Pièces détachées / Repuestos Talis S 95562xx0 (14877/14872 / 04310) 04286xx0 04310xx1 14872xx1 95560xx0 14877xx1 96338000 97735000 95498xx0 37x2 95140000 96316001 97209000 95008000 92730000 95376000 (04310xx1) 93218000 (14877xx1, 14872xx1, 04310xx0, 04286xx0) 88659xx0 97350000 95561000 88624000 xx = Colors / Couleurs / Acabados 98551000 00 = Chrome 04310xx1...
- Page 13 Replacement Parts / Pièces détachées / Repuestos Talis S 04247xx0 95560xx0 96338000 93218000 95140000 95008000 96316001 96468xx0 97209000 97999xx1 92730000 95561000 88624000 98551000 xx = Colors / Couleurs / Acabados 00 = Chrome 80 = Steel Optik...
- Page 14 Replacement Parts / Pièces détachées / Repuestos Focus 04505xx0 04506xx1 95562xx0 98193000 (04505xx0) (32x2) 98460xx0 98127000 (11x2) 96338000 95498xx0 97209000 92730000 97735000 93218000 97350000 98231000 (18x1,5) 95140000 95008000 96316001 98140000 (20x1) 95910000 95561000 95049000 88624000 xx = Colors / Couleurs / Acabados 00 = Chrome 80 = Steel Optik...
- Page 15 User Instructions / Instructions de service / Manejo ouvert fermé abierto cerrar cold froid chaud frío caliente 14877xx1, 04310xx1, 04286xx0...
- Page 16 User Instructions / Instructions de service / Manejo 04505xx0 / 04247xx0 04506xx1 14877xx1 only / seulement / solamente " / . 2 ¾ m i n...
- Page 17 Cleaning / Nettoyage / Limpieza Maintenance / Entretien / Mantenimiento...
- Page 18 Cleaning Recommendation for Hansgrohe Products Modern bathroom faucets, kitchen faucets and shower products are made from different materials to comply with the needs of the market with regard to design and functionality. To avoid damage to the product, it is necessary to take proper care of it.
- Page 19 Important • Les residus de produits pour le corps comme les savons liquides, shampooings, gels de douche, teintures pour cheveux, parfums, apres-rasage et vernis a ongles peuvent causer des deteriorations. Rincez le produit avec de l’eau propre après chaque utilisation. •...
-
Page 20: Limited Consumer Warranty
Limited Consumer Warranty This warranty is limited to products manufactured by Hansgrohe, conditions in the home such as excessive water pressure Inc. (“Hansgrohe”) that are purchased by a consumer in the United or corrosion. States or Canada after March 1, 1996, and installed in either the Labor and other expenses for disconnection, deinstallation, United States or in Canada.
