the upper and lower eyelids. Get medi-
cal attention if symptoms occur.
Inhalation: Move the exposed person
to fresh air. If irritation persists, get
medical attention.
Ingestion: Do NOT induce vomiting
unless directed to do so by medical
personnel. Get medical attention.
Disposal: Dispose of this material and
its container at a hazardous or special
waste collection point.
WARNING
Do not remove the bottle while the tire
sealing system is being used.
Do not remove the hose while the tire
sealing system is being used.
1.
Turn on the vehicle's hazard warning
flashers if the tire sealing system is to be
used in an area with traffic.
If the puncture was caused by a nail or
similar object, do not remove it. It will help
seal the hole.
2. Peel off the speed limit sticker from the
side of the compressor. Affix the decal to a
clearly visible location on the windshield
to remind the driver not to exceed this
speed limit. Do not drive faster than
80 km/h (50 mph) while using a tire that
has been temporarily repaired with the tire
sealing system.
Also peel off the warning decal and affix it
securely to the side of the wheel.
3. Make sure the switch is in the 0 (Off)
position and take out the electric cable
and the hose.
4. Attach the sealing compound bottle to the
compressor, making sure that the red
arrows on the compressor and bottle are
aligned, and then turn clockwise until it
clicks into place.
The bottle is equipped with a check valve
that prevents fluid leakage when the bot-
tle is not connected to the compressor.
5. Attach the hose in the bottle opening and
turn clockwise until it clicks into place.
6. Unscrew the tire's valve cap and screw
the hose's valve connector as far as possi-
ble onto the valve.
WHEELS AND TIRES
7. Connect the electrical cable to the nearest
12 V outlet and start the vehicle.
NOTE
Make sure that none of the vehicle's other
12 V sockets are used while the compres-
sor is running.
WARNING
Never leave children unattended in the
vehicle while the engine is running.
WARNING
Inhaling exhaust fumes could lead to seri-
ous injury. Never leave the engine running
in an enclosed space or a space without
sufficient ventilation.
}}
509
