Page 1 XC40 T W I N E N G I N E O W NE R 'S M ANU AL...
Page 3 VÄLKOMMEN! We hope you will enjoy many years of driving pleasure in your Volvo. manual. The owner's manual is also available as a mobile app (Volvo The car has been designed for the safety and comfort of you and Manual) and on the Volvo Cars support site (support.volvocars.com).
Page 4: Table Of Contents
YOUR VOLVO SAFETY Owner information Volvo ID Safety Owner's manual in centre display Creating and registering a Volvo ID Safety during pregnancy Navigate in the owner's manual in Drive-E - cleaner driving pleasure Whiplash Protection System the centre display IntelliSafe – driver support and safety...
Page 5 DISPLAYS AND VOICE CONTROL Child seat mounting Managing messages in the driver display Displays and controls by the driver Overview table for location of in a left-hand drive car child seats Handling a message saved from the driver display Displays and controls by the driver Table for location of child seats in a right-hand drive car using the car's seatbelts...
Page 6 LIGHTING WINDOWS, GLASS AND MIRRORS Other settings in the centre dis- Lighting control play's top view Windows, glass and mirrors Adjusting light functions via the Open contextual setup in the cen- centre display Pinch protection for windows and tre display sun blinds Position lamps Resetting user data for change of...
Page 7 SEATS AND STEERING WHEEL CLIMATE Manual front seat Climate Activating and deactivating auto- matic start of heated steering wheel* Power* front seat Climate zones Activating auto climate control Climate control - sensors Adjusting the power* front seat Activating and deactivating air Using a stored position for seat Perceived temperature recirculation...
Page 8 KEY, LOCKS AND ALARM Adding and editing time setting Lock confirmation Unlocking the tailgate from the for preconditioning inside of the car Lock indication setting Activating and deactivating time Activating and deactivating child Remote control key setting for preconditioning safety locks Locking and unlocking with the Removing time setting for precon- Automatic locking when driving...
Page 9 DRIVER SUPPORT Driving support systems Activating or deactivating road Adaptive cruise control* sign information* Speed-dependent steering force Controls for adaptive cruise control* Display mode for road sign infor- General speed warning Display mode for adaptive cruise mation* control* Electronic stability control Road Sign Information and Selecting and activating adaptive Sensus Navigation*...
Page 10 Use Overtaking Assistance Steering assistance upon risk of Activating or deactivating the rear-end collision* parking assistance system* Warning from driver support in the event of a collision risk Limitations for steering assistance Limitations of Parking assistance at risk of collision Change of target with driver support Symbols and messages for Park Symbols and messages for steer-...
Page 11 ELECTRIC OPERATION AND STARTING AND DRIVING CHARGING Recommended maintenance for Starting the car camera and radar unit General information about Twin Switching off the car Engine Symbols and messages for cam- Ignition positions era and radar unit Charging the hybrid battery Selecting ignition mode Charging current Alcohol lock*...
Page 12 ® Auto braking after a collision Driving in water Type approval for HomeLink Regenerative braking* Opening and closing the fuel filler flap Compass* Gearbox Filling fuel Activating and deactivating the compass* Automatic gearbox Handling of fuel Calibrating the compass* Changing gear with automatic Petrol gearbox Petrol particle filter...
Page 13 SOUND, MEDIA AND INTERNET ® Sound, media and Internet Switch between Bluetooth-con- Playing back DivX nected phones Audio settings Settings for video Removing devices connected to Sound experience* ® Media via Bluetooth Bluetooth Apps ® Connecting a device via Bluetooth Managing phone calls Downloading apps Media via USB port...
Page 14 WHEELS AND TYRES User terms and conditions and Tyres Using a puncture repair kit data sharing Dimension designation for tyre Inflating tyres with the compressor Activating and deactivating data from the puncture repair kit Dimension designation for wheel rim sharing Tyres' rotation direction Data sharing for services Tread wear indicators on the tyres...
Page 15 LOADING, STORAGE AND MAINTENANCE AND SERVICE PASSENGER COMPARTMENT Volvo service programme Exterior lamp positions Passenger compartment interior Data transfer between car and Replacing the rear direction indica- workshop via Wi-Fi tor bulb Tunnel console Download Center Changing brake light bulb...
Page 16 SPECIFICATIONS ALPHABETICAL INDEX Car paintwork Type designations Alphabetical Index Touching up minor paintwork damage Dimensions Colour codes Weights Replacing the wiper blade, rear Towing capacity and towball load window Engine specifications Replacing windscreen wiper blades Engine oil – specifications Set the wiper blades in service Adverse driving conditions for position engine oil...
Page 17 OWNER INFORMATION...
Page 18 Volvo Cars support site. There is a and in PDF format. On the interior images of the car. The Quick Guide and a supplement to the...
Page 19 Owner's manual in centre display A printed owner's manual and associated sup- Volvo Cars support site (p. 21) • plement can be ordered. Contact a Volvo Reading the owner's manual (p. 22) A digital version of the owner's manual is •...
Page 20 OWNER INFORMATION Related information Owner's manual Contextual owner's manual Navigate in the owner's manual in the • centre display (p. 19) Navigating in the centre display's views • (p. 106) Downloading apps (p. 484) • Top view with button for owner's manual. Top view with button for contextual owner's manual.
Page 21 OWNER INFORMATION Navigate in the owner's manual in Opening the menu in the top menu Featured articles the centre display Press the symbol to access a Press in the upper list in the owner's – page with links to a selection The digital owner's manual can be accessed manual.
Page 22 OWNER INFORMATION Using the search function in the top Hotspots for exterior and interior Favourites Exterior and interior overview Press the symbol to access menu images of the car. Different the articles saved as favour- Tap on in the top menu of the owner's parts are designated with ites.
Page 23 The owner's manual is available as a mobile More information on your car is available on the Volvo Cars website and support site. from both the App Store and Google Play. The app is adapted for smartphones and Support on the Internet tablets.
Page 24 Reading the owner's manual Log in to Volvo Cars website Options/accessories Create a personal Volvo ID and log in to In addition to standard equipment, the To help you get to know your new car, read www.volvocars.com. When you have logged...
Page 25 Owner's manual in centre display (p. 17) • Owner's Manual in mobile devices (p. 21) • Volvo Cars support site (p. 21) • Black ISO symbols on yellow warning field, white text/image on black message field. Used to indicate the presence of danger which, if the warning is ignored, may result in serious personal injury or fatality.
Page 26 OWNER INFORMATION The owner's manual and the environment The Owner's Manual is printed on paper orig- inating from controlled forests. ® The Forest Stewardship Council (FSC) sym- bol shows that the paper pulp in a printed ® owner's manual comes from FSC -certified forests or other controlled sources.
Page 27: Your Volvo
YOUR VOLVO...
Page 28: Volvo Id
YOUR VOLVO Volvo ID Creating and registering a Volvo ID When a Volvo ID is registered in the car, sev- eral services will be made available. Several Volvo ID is a personal ID that gives access to It is possible to create a Volvo ID in different...
Page 29 Registering your Volvo ID to the car Create a Volvo ID with the Volvo On Call If you created your Volvo ID via the web or the Volvo On Call app, register it to your car as fol- Download the latest version of the Volvo...
Page 30: Drive-E - Cleaner Driving Pleasure
Fuel consumption Environmental care is one of Volvo Cars’ core air inside a Volvo is, for example, cleaner than values and influences all operations. The envi- the air outside thanks to the climate control...
Page 31 Interior Contributing to a better environment ommended. An energy-efficient and economical car can The material used in the interior of a Volvo is contribute to reduced environmental impact carefully selected and has been tested in order Efficient emission control and also involve reduced costs for the owner to be pleasant and comfortable.
Page 32 YOUR VOLVO Related information Fuel consumption and CO emissions • (p. 650) Economical driving (p. 451) • Start and switch off preconditioning • (p. 207) The owner's manual and the environment • (p. 24) Air quality (p. 186) •...
Page 33: Intellisafe - Driver Support And Safety
Whiplash Protection System • • safety Road Sign Information* Seatbelts with seatbelt tensioners • • IntelliSafe is the Volvo Cars concept for car Electronic stability control Airbags • • safety. IntelliSafe comprises a number of sys- Roll Stability Control •...
Page 34: Sensus - Online Connectivity And 21 Entertainment
YOUR VOLVO Sensus - online connectivity and Sensus offers an intelligent interface and Information when it is needed, where entertainment online connectivity with the digital world. An it is needed intuitive navigation structure makes it possible The different displays in the car provide infor-...
Page 35 YOUR VOLVO Different types of information are shown in different displays depending on how the information should be prioritised. The driver display shows information on speed Driver display Centre display and e.g. incoming calls or song tracks being played. The display is operated via the two steering wheel keypads.
Page 36 YOUR VOLVO Many of the main functions of the car are con- trolled from the centre display, a touch screen which reacts to touch. The number of physical buttons and controls in the car is therefore minimal. The screen can even be operated while wearing gloves.
Page 37: Software Updates
The EDR is designed to record data related to vehicle dynamics and safety systems for a So that you as a Volvo customer get the best As part of Volvo's safety and quality assur- short time, usually 30 seconds or less.
Page 38: Terms & Conditions For Services
YOUR VOLVO Terms & Conditions for Services In addition to the EDR, the car is equipped into agreements with Volvo have access to is with a number of computers designed to con- required to be able to read and interpret the...
Page 39: Customer Privacy Policy
Volvo serv- If the on-board information differs from the The types of personal data we gather.
Page 40: Installation Of Accessories
Incorrect connection and installation of soft- accessories. ries, and that installation of accessories is ware or diagnostic tools may have a negative only carried out by trained and qualified Volvo effect on the car's electronic system. Related information service technicians. Certain accessories only...
Page 41: Showing The Car's Identification Number
YOUR VOLVO Showing the car's identification NOTE number Volvo Cars accepts no liability for the con- When contacting a Volvo dealer concerning sequences if unauthorised equipment is your Volvo On Call subscription, for example, connected to the On-board Diagnostic you will need the car's identification number socket (OBDII).
Page 42: Driver Distraction
Your new Volvo is, or can be, equipped with content-rich entertainment and communica- Never program the audio system while •...
Page 43: Safety
SAFETY...
Page 44: Seatbelts
Defective work in one of the systems can cause malfunction such as Whiplash Protection System. The car and result in serious personal injury. Volvo is also constructed so that a large part of the recommends that an authorised Volvo force of a collision is distributed to beams, pil- workshop should be contacted.
Page 45: Whiplash Protection System
Volvo recommends that an and steering wheel). The aim should be to tem consists of energy absorbing backrests authorised Volvo workshop should be con- position the seat with as large a distance as and seat cushion, as well as a specially tacted.
Page 46 SAFETY Seatbelts WHIPS and child seats WARNING The protection provided by the car to children Heavy braking can have serious consequen- Do not squeeze rigid objects between the seated in a child seat or on a booster cushion ces if the seatbelts are not used. rear seat cushion and the front seat's back- is not diminished by WHIPS.
Page 47: Putting On And Taking Off Seatbelts
Make sure that all passengers have fastened Never modify or repair the seatbelts your- > A loud "click" indicates that the belt has their seatbelts before starting to drive. self. Volvo recommends that an authorised locked. Volvo workshop should be contacted. Putting on seatbelts...
Page 48 SAFETY 3. In the front seats the seatbelt can be WARNING adjusted for height. Each seatbelt is designed for only one per- son. WARNING Remember not to clip or hook the seatbelt to hooks or other interior fittings, as this prevents the belt from tightening properly.
Page 49: Seatbelt Tensioner
Never modify or repair the seatbelts your- pant. self. Volvo recommends that an authorised Volvo workshop should be contacted. Electric seatbelt tensioner* If the seatbelt has been subjected to a...
Page 50: Resetting The Electric Seatbelt
WARNING Visual reminder in the roof console. Never modify or repair the seatbelts your- self. Volvo recommends that an authorised A visual reminder is given in the roof console Volvo workshop should be contacted. and by means of the warning symbol in the driver display.
Page 51 10 km/h (6 mph) then since the airbags may deploy. Recovering the driver display's information sym- the car. Volvo recommends that it is trans- bol illuminates. ported to an authorised Volvo workshop. If the car is driven at a speed higher than approx.
Page 52 SAFETY Driver airbags Volvo workshop. Do not drive with and deflation of the airbag, occurs within deployed airbags. tenths of a second. As a supplement to the seatbelts, the car is equipped with steering wheel airbag and Volvo recommends engaging an author- •...
Page 53 Passenger airbag (p. 51) • backs against the backrest. WARNING Volvo recommends that an authorised Volvo workshop should be contacted for repair. Defective work in the airbag system could cause malfunction and result in seri- ous personal injury. Passenger side front airbag.
Page 54: Activating And Deactivating Pas
SAFETY Activating and deactivating Label for passenger airbag WARNING passenger airbag* Never allow anybody to stand or sit in front The passenger airbag can be deactivated if of the front passenger seat. the car is equipped with a switch, Passenger Never use a rear-facing child seat on the Airbag Cut Off Switch (PACOS).
Page 55 SAFETY Activating passenger airbag 2. Confirm the message by pressing the WARNING right-hand steering wheel keypad's O but- If the car is not equipped with a switch to ton. activate/deactivate the passenger airbag, the airbag will always be activated. Pull the switch outward and turn from OFF to ON.
Page 56 SAFETY Deactivating passenger airbag 2. Confirm the message by pressing the IMPORTANT right-hand steering wheel keypad's O but- If the passenger airbag is deactivated, the ton. electric seatbelt tensioner on the passen- ger side will also be deactivated. Related information Seatbelt tensioner (p.
Page 57 Volvo recommends the use only of car seat covers approved by Volvo. Other seat cov- ers may impede the operation of the side airbags.
Page 58 Volvo recommends only using been shown. Volvo genuine parts that are approved for symbol as long as the display is not damaged fitting within these areas. and the car's electrical system is still in work- ing order.
Page 59: Starting And Moving The Car After
If the car is in safety mode it must not be tems check and then try to resume nor- towed. It must be transported from its mal status. The driver display shows location. Volvo recommends that it is the message Car start System check, transported to an authorised Volvo work- wait during this time.
Page 60 Make sure that the child seat is positioned, In the event of questions when fitting child fitting in this particular car. Using Volvo's child mounted and used correctly. safety equipment, contact the manufac-...
Page 61: Upper Mounting Points For Child Seats
SAFETY Upper mounting points for child Related information WARNING seats Child safety (p. 58) • The child seat's upper straps must be The car is equipped with upper mounting Upper mounting points for child seats • routed through the hole in the head points for child seats on the rear seat's outer (p.
Page 62: Lower Mounting Points For Child Seats
SAFETY Lower mounting points for child i-Size/ISOFIX mounting points for switch to activate/deactivate the passenger seats child seats airbag*. The car is equipped with lower mounting The car is equipped with i-Size/ISOFIX points for child seats in the front seat* and mounting points for child seats in the rear seat.
Page 63: Child Seat Positioning
SAFETY Child seat positioning Related information NOTE Child seats (p. 58) • It is important to position the child seat in the Regulations regarding the placement of right place in the car. The choice of location Upper mounting points for child seats •...
Page 64 Volvo recommends using the kick Do not secure the straps for the child seat guard accessory to protect the car's fit- into the seat's horizontal adjustment bar or tings.
Page 65 With the installation of an infant seat in the rear seat, child seat's upper straps should be pulled Volvo recommends a distance of at least 50 mm through the hole in the head restraint (2 tum) from the front part of the infant seat to the before being tensioned at the mounting rearmost part of the seat in front.
Page 66 SAFETY Overview table for location of child seats The table gives an overview of the types of child seats suitable for the car's seats. Seat positions in right-hand drive cars. Seat positions in left-hand drive cars. i-Size child seats Universally approved child seats secured using the car's seatbelt Other child seat categories 3, 5 India:...
Page 67 SAFETY Related information Child seat positioning (p. 61) • Child seat mounting (p. 62) • Table for location of child seats using the • car's seatbelts (p. 66) Table for location of i-Size child seats • (p. 68) Table for location of ISOFIX child seats •...
Page 68 SAFETY Table for location of child seats NOTE using the car's seatbelts Always read the owner's manual section The table gives a recommendation for which on installing a child seat before installing child seats suit which locations, and for what one in the car.
Page 69 Volvo recommends: Volvo rear-facing seat (type approval E5 04212). Volvo recommends rear-facing child seat for children in this mass group. Volvo recommends: Booster cushion with and without back (type approval E5 04216); Volvo booster seat (type approval E1 04301312). Related information Table for location of i-Size child seats •...
Page 70 X: Not suitable for universally approved child seats. Volvo recommends that children travel in a rear-facing child seat until as late an age as possible, at least until 3-4 years of age. Volvo recommends: BeSafe iZi Kid X2 i-Size (type approval E4-129R-000002).
Page 71 SAFETY Table for location of ISOFIX child The child seat must be approved in accord- NOTE seats ance with UN Reg R44 and the car model Always read the owner's manual section must be included in the manufacturer's vehicle The table gives a recommendation for which on installing a child seat before installing list.
Page 72 The seat cushion extension must always be retracted for the installation of child seats. Volvo recommends: Volvo infant seat secured using the ISOFIX fixture system (type approval E1 04301146). Applicable if the car is not fitted with an ISOFIX bracket.
Page 73 SAFETY Related information Child seat positioning (p. 61) • Child seat mounting (p. 62) • Overview table for location of child seats • (p. 64) Table for location of child seats using the • car's seatbelts (p. 66) Table for location of i-Size child seats •...
Page 75: Displays And Voice Control
DISPLAYS AND VOICE CONTROL...
Page 76: Displays And Controls By The Driver In A Left-Hand Drive Car
DISPLAYS AND VOICE CONTROL Displays and controls by the driver Left-hand steering wheel keypad Centre and tunnel console in a left-hand drive car Display lighting, unlocking/opening*/clos- The overviews show where the displays and ing* of tailgate controls near the driver are located. Roof console Steering wheel and instrument panel Centre display...
Page 77: Displays And Controls By The Driver In A Right-Hand Drive Car
DISPLAYS AND VOICE CONTROL Displays and controls by the driver Driver's door Horn in a right-hand drive car Steering wheel adjustment The overviews show where the displays and controls near the driver are located. Left-hand steering wheel keypad Steering wheel and instrument panel Roof console Memory for settings for power front seat*, door mirrors...
Page 78 DISPLAYS AND VOICE CONTROL Centre and tunnel console Driver's door Centre display Memory for settings for power front seat*, door mirrors Start button Central locking, power windows, door mir- rors, electric child safety locks* Hazard warning flashers, defrosting, media, drive mode button* Bonnet opening Electrical socket, USB port, wireless Adjusting front seat...
Page 79: Driver Display
You should visit a workshop immediately. equipment, settings and which functions are Volvo recommends an authorised Volvo active at that time. workshop. The driver display is activated as soon as a door is opened, i.e.
Page 80 DISPLAYS AND VOICE CONTROL On the left In the middle On the right – Navigation map* Instantaneous fuel consumption – Phone App menu (activated via steering wheel keypad) – Voice recognition – Depends on drive mode selected. Accumulated mileage. Dynamic symbol Indicator symbols in the driver display •...
Page 81: Driver Display Settings
DISPLAYS AND VOICE CONTROL Driver display settings Settings via the centre display 2. Tap on System System Languages Settings for the driver display's display and Units System Language to select Selecting information type options can be made via the driver display's language.
Page 82: Fuel Gauge
DISPLAYS AND VOICE CONTROL Fuel gauge Hybrid gauge Indicates the power level when the combustion engine starts. If the The fuel gauge in the driver display shows the In drive modes Hybrid and Pure, the driver symbol is filled in, it means that the fuel level in the tank.
Page 83: Hybrid Battery Gauge
DISPLAYS AND VOICE CONTROL Hybrid battery gauge Example: The hybrid battery gauge shows how much energy there is in the hybrid battery. The car generates current to the battery, the battery is charged, e.g. when the brake pedal is pressed The car is started but stationary, no power is reques- lightly or during engine braking down a hill.
Page 84: Trip Computer
DISPLAYS AND VOICE CONTROL Trip computer Symbols in the hybrid battery gauge Distance to empty battery • The car's trip computer records vales such as Tourist - alternative speedometer • e.g. distance, fuel consumption and average Units for distance, speed, etc. can be changed speed whilst driving.
Page 85 Volvo has decided to use a the car's instruments. start value when the car is fully charged. The...
Page 86: Show Trip Data In The Driver Display
DISPLAYS AND VOICE CONTROL Show trip data in the driver display Open the app menu in the driver display 3. Scroll down to the option buttons to by pressing (1). select which information to show in the The trip computer's recorded and calculated driver display: values can be shown in the driver display.
Page 87: Resetting The Trip Meter
DISPLAYS AND VOICE CONTROL Resetting the trip meter Show trip statistics in the centre display Reset the trip meter using the left-hand stalk switch. Trip statistics from the trip computer are dis- played graphically in the centre display and provide an overview that facilitates more fuel- efficient driving.
Page 88: Settings For Trip Statistics
DISPLAYS AND VOICE CONTROL Settings for trip statistics Date and time zone is then adjusted automatically based on the location of the car. For certain types of Reset or adjust settings for trip statistics. The clock is shown in both the driver display navigation systems, the current location Open the Driver performance...
Page 89: Outside Temperature Gauge
The that warns of potentially slippery emissions system. Drive to a car's regular brake system con- conditions. workshop for checking. Volvo tinues to work, but without the Change the unit for the temperature gauge, recommends that an authorised ABS function.
Page 90 DISPLAYS AND VOICE CONTROL Symbol Specification Symbol Specification Symbol Specification Left and right-hand direction Main beam On Rain sensor on indicator The symbol illuminates when This symbol illuminates when the The symbol flashes when the main beam is on and with main rain sensor is on.
Page 91: Warning Symbols In The Driver Display
DISPLAYS AND VOICE CONTROL Warning symbols in the driver Symbol Specification Symbol Specification display Stability system, sport mode Lane assistance and rain sen- The warning symbols alert the driver that an important function is activated or that a seri- The symbol illuminates when the ous fault or condition exists.
Page 92 If the symbol illuminates High engine temperature authorised Volvo workshop is and the oil level is normal, con- contacted. tact a workshop. Volvo recom- The symbol switches on while mends that an authorised Volvo driving when the temperature of Fault in brake system workshop is contacted.
Page 93: License Agreement For The Driver Display
The wrote this software. If you use it, or only parts documentation, unless otherwise stated in the following text is Volvo's agreement with the of it, in a program, you must acknowledge file in its original, unmodified form as manufacturer or developer.
Page 94 DISPLAYS AND VOICE CONTROL object code forms) and derivative works `FreeType library', or `FreeType Distribution'. Copyright © 2009 Martin Hosken and SIL • thereof for any purpose; and to authorize As you have not signed this license, you are International others to exercise some or all of the rights not required to accept it.
Page 95 DISPLAYS AND VOICE CONTROL MERCHANTABILITY AND FITNESS FOR A The origin of this software must not be ACCEPT, AND AGREE TO BE BOUND BY, PARTICULAR PURPOSE. THE SOFTWARE misrepresented; you must not claim that ALL OF THE TERMS AND CONDITIONS OF PROVIDED HEREUNDER IS ON AN "AS IS"...
Page 96 DISPLAYS AND VOICE CONTROL EXPRESS OR IMPLIED, INCLUDING BUT commercial applications, and to alter it and GLEW Licence (Modified BSD Licence) NOT LIMITED TO THE WARRANTIES OF redistribute it freely, subject to the following The OpenGL Extension Wrangler Library MERCHANTABILITY, FITNESS FOR A restrictions: Copyright (C) 2002-2008, Milan Ikits •...
Page 97: App Menu In The Driver Display
DISPLAYS AND VOICE CONTROL App menu in the driver display OWNER OR CONTRIBUTORS BE LIABLE Functions FOR ANY DIRECT, INDIRECT, INCIDENTAL, The app menu in the driver display provides Trip com- Selection of trip meter, selec- SPECIAL, EXEMPLARY, OR quick access to commonly used functions for puter tion of what to show in the CONSEQUENTIAL DAMAGES (INCLUDING,...
Page 98: Managing The App Menu In The Driver Display
DISPLAYS AND VOICE CONTROL Managing the app menu in the Opening/closing the app menu If the app menu is opened again, the functions driver display of the most recently selected app are shown Press on open/close (1). – first. The app menu in the driver display is oper- >...
Page 99: Messages In The Driver Display
- parts may vary depending on car Part of message, shown together with information on model. shop where the problem has arisen. An authorised Volvo workshop is recommended. The driver display shows messages that are of Service urgent Contact a workshop high priority for the driver.
Page 100: Display
DISPLAYS AND VOICE CONTROL Managing messages in the driver Handling a message saved from 2. Confirm the selection by pressing on con- display the driver display firm (2). > The message disappears from the Messages in the driver display are handled Whether saved from the driver display or the driver display.
Page 101 Messages in the driver display (p. 97) • the owner's manual. Managing messages in the driver display • (p. 98) Message in centre display (p. 131) • Market dependent. Volvo ID and selected workshop also need to be registered.
Page 102: Overview Of Centre Display
DISPLAYS AND VOICE CONTROL Overview of centre display Many of the car's functions are controlled from the centre display. Presented here is the centre display and its options.
Page 103 DISPLAYS AND VOICE CONTROL Three of the centre display's basic views. Swipe right or left to access the function or app view respectively Function view - car functions that are acti- functions are also so-called trigger func- vated or deactivated with a press. Certain tions, which means they open a window The views are reversed for right-hand drive cars.
Page 104 DISPLAYS AND VOICE CONTROL with setting options. Examples of these Phone - the phone function can be Climate controls (p. 195) • include Camera. reached from here. Tap on the subview to Switching off and changing the volume of • expand it.
Page 105: Managing The Centre Display
DISPLAYS AND VOICE CONTROL Managing the centre display can be performed by touching the screen in IMPORTANT different ways. Many of the car's functions are controlled and Do not use sharp objects on the screen as regulated from the centre display. The centre An infrared light curtain just above the surface they may scratch it.
Page 106 DISPLAYS AND VOICE CONTROL Procedure Execution Result Drag. Changes between different views, scrolls a list, text or view. Hold depressed and drag in order to move apps or map points on the map. Drag horizontally or vertically across the screen. Swipe/drag quickly.
Page 107 DISPLAYS AND VOICE CONTROL Returning to home view from another The control is used for many of the car's func- tions. Regulate e.g. temperature by means of view one of the following: Briefly press the home button below the centre display. drag the control to the desired tempera- •...
Page 108: Activating And Deactivating Centre
DISPLAYS AND VOICE CONTROL Activating and deactivating centre Navigating in the centre display's Give a long press on the physical home display views button below the screen. > The screen goes dark except for the cli- The centre display can be dimmed and reacti- There are five different basic views in the cen- mate row, which continues to be vated using the home button beneath the...
Page 109 DISPLAYS AND VOICE CONTROL pressing on the tab or by dragging/swiping Climate view NOTE from the top downwards across the screen. The climate row is always visible at the bot- In home view standard mode - briefly press tom of the screen. The most common climate In the top view, access is always available to: the home button.
Page 110 DISPLAYS AND VOICE CONTROL App view view, such as the number of unread text mes- Function view sages for Messages Tap on an app to open it. The app then opens Media in the tile to which it belongs, e.g. You can scroll down in the app view, depend- ing on the number of apps.
Page 111 DISPLAYS AND VOICE CONTROL Depending on the amount of functions, it is also possible here to scroll downward in the view. Do this by swiping/dragging from the bottom and up. Unlike in app view, where an app is opened with a press, a function is activated or deacti- vated by pressing the relevant function button.
Page 112: Managing Subviews In Centre Display
DISPLAYS AND VOICE CONTROL Managing subviews in centre display Home view consists of four subviews: Navigation Media Phone and an extra sub- view. These views can be expanded.
Page 113 DISPLAYS AND VOICE CONTROL Expanding a subview from default mode Standard mode and expanded mode of a subview in the centre display.
Page 114 DISPLAYS AND VOICE CONTROL Expanding a subview: When a new subview is opened in full-screen There is always the option to go back to home mode, no information from the other subviews view by pressing the home button. To go back For tiles Navigation Media...
Page 115: Function View In Centre Display
DISPLAYS AND VOICE CONTROL Function view in centre display from home view by swiping from left to right Different types of buttons across the screen There are three different types of buttons for All the buttons for car functions are located in car functions;...
Page 116 DISPLAYS AND VOICE CONTROL The buttons' different modes The function is deactivated when the LED indicator is extinguished. When the LED indicator illuminates in green on a function or parking button, the function is activated. When a function is activated, extra text with an explanation for certain functions is shown.
Page 117: Moving Apps And Buttons In Cen
DISPLAYS AND VOICE CONTROL Moving apps and buttons in centre Symbols in the centre display's NOTE display status bar Hide the apps that you rarely or never use The apps and buttons for car functions in the Overview of the symbols that can be shown by moving them to the bottom, off the visi- app view and function view respectively can in the centre display's status bar.
Page 118 DISPLAYS AND VOICE CONTROL Internet-connected car* (p. 519) • Symbol Specification Connecting a device via USB port (p. 499) • Car modem activated. Wireless phone charger* (p. 516) • Phone (p. 508) • USB sharing active. Date and time (p. 86) •...
Page 119: Keyboard In Centre Display
DISPLAYS AND VOICE CONTROL Keyboard in centre display The centre display keyboard makes it possi- ble make entries using keys. It is also possi- ble to "draw in" letters and characters on the screen by hand. The keyboard can be used to enter characters, letters and numbers, e.g.
Page 120 DISPLAYS AND VOICE CONTROL The image shows an overview of some of the buttons which may be shown in the keyboard. The appearance varies depending on language settings and the context in which the keyboard is being used.
Page 121 DISPLAYS AND VOICE CONTROL addresses, each word automatically starts Variants of a letter or character Row of suggested words or characters with a capital letter. In text fields for pass- The suggested words are adjusted as new word, web address or email address entry, letters are being entered.
Page 122: Changing Keyboard Language In
DISPLAYS AND VOICE CONTROL Changing keyboard language in Enter the characters, letters and Switching between different centre display words manually in the centre languages in the keyboard display When a number of languages To make it possible to switch between differ- have been selected in ent languages for the keyboard, the lan- The centre display keyboard allows you to...
Page 123 DISPLAYS AND VOICE CONTROL Suggestions for characters/letters/word/ Writing characters/letters/words by hand Deleting/changing characters/letters part of word. It is possible to scroll Write a character, a letter, a word or parts written by hand through the list. of a word in the area for hand-written let- ters (1).
Page 124: Changing The Appearance In The
DISPLAYS AND VOICE CONTROL Changing the appearance in the Switching off and changing the Changing row in the free text field with centre display volume of the system sound in the handwriting centre display The appearance of the screen in the centre display can be changed by selecting a theme.
Page 125: Changing System Units
DISPLAYS AND VOICE CONTROL Changing system units Changing system language Other settings in the centre display's top view Units settings are defined in the centre dis- Language settings are defined in the centre play's Settings menu. display menu Settings You can change settings and information for Press Settings in the top view in the cen-...
Page 126 (here, a multi-selector button and system from the beginning, but are the type radio buttons). that can be downloaded e.g. Volvo ID . Here Related information the settings are always made inside the app and not from the top view.
Page 127 Factory reset - clears all data and files • Other settings in the centre display's top • to change the owner of the Volvo On Call* and resets all settings to their default val- view (p. 123) service. ues. Table showing centre display settings •...
Page 128 Driver Profiles . Other settings are global, which means they are not Car Wi-Fi Hotspot linked to a driver profile. Car Modem Internet Route and Guidance My Car Volvo On Call Traffic Subcategories Volvo Service Networks Media Displays Subcategories Climate...
Page 129 DISPLAYS AND VOICE CONTROL Driver profiles System files. They remain the same regardless of which driver profile is active. Many of the settings made in the car can be Subcategories adapted according to the driver's personal Keyboard layout settings are an example of Driver Profile preferences and can be saved in one or more global settings.
Page 130 DISPLAYS AND VOICE CONTROL Selecting driver profile Renaming a driver profile 3. Select the driver profile required. When the centre display has been started, It is possible to change the name of the dif- 4. Press Confirm the selected driver profile is shown at the top ferent driver profiles used in the car.
Page 131 DISPLAYS AND VOICE CONTROL Protect driver profile Linking remote control key to 5. Save your profile protection option by driver profile pressing Back Close In some cases it is preferable not to save vari- ous settings defined in the car to the active >...
Page 132 DISPLAYS AND VOICE CONTROL The active profile can then be linked to the 5. Select Connect key to link the profile with Related information key. the key. It is not possible to link a driver Driver profiles (p. 127) • profile to a different key than the one cur- Renaming a driver profile (p.
Page 133 DISPLAYS AND VOICE CONTROL Resetting settings in the driver Message in centre display Pop-up messages profiles In some cases, a message is shown in the The centre display can show messages to form of a pop-up window. Pop-up messages inform or assist the driver in the event of dif- Settings that have been saved to one or more have higher priority than messages shown in ferent events.
Page 134 DISPLAYS AND VOICE CONTROL Managing messages in the centre Handling a message saved from For messages without buttons: display the centre display Close the message by tapping on it, or – Messages in the centre display are handled in Whether saved from the driver display or the allow the message to close automatically centre display views.
Page 135 DISPLAYS AND VOICE CONTROL Voice recognition Reading a saved message WARNING Open the top view in the centre display. Voice control allows you to control func- The driver always holds overall responsibil- > A list of saved messages is shown. tions in the car, e.g.
Page 136 DISPLAYS AND VOICE CONTROL Using voice recognition Avoid background noise in the passenger • NOTE compartment by having the doors, win- Not all system languages support voice Start voice control dows and panoramic roof* closed. recognition. The ones that do are high- To give commands via the lighted with the symbol in the list of...
Page 137 DISPLAYS AND VOICE CONTROL Cancel voice control 2. Say " Call [Forename] [Surname] e.g. "zero, three, one, two, two, four, four, [number category] Call Robin three" (03122443). Voice control can be cancelled in different ", e.g. " ways: Smith Mobile ".
Page 138 DISPLAYS AND VOICE CONTROL Controlling a telephone with voice Related information message. For this function to work, the car must be connected to the Internet. Voice recognition (p. 133) recognition • Controlling a telephone with voice recog- Call a contact, have messages read aloud or •...
Page 139 DISPLAYS AND VOICE CONTROL Voice control of radio and media " iPod " - starts playback from iPod. Settings for voice recognition • " Bluetooth " - starts playback from a Commands for radio and media player device • Settings for the voice control system are control are shown below.
Page 140 DISPLAYS AND VOICE CONTROL Related information Voice recognition (p. 133) • Using voice recognition (p. 134) • Controlling a telephone with voice recog- • nition (p. 136) Controlling climate control with voice rec- • ognition (p. 185) Voice control of radio and media (p. 137) •...
Page 141 LIGHTING...
Page 142 Rotating ring in the left-hand stalk switch. on only the position lamps instead of other lighting. When the car's electrical system is in ignition Volvo recommends that mode is used position II, the following functions are availa- when the vehicle is driven.
Page 143 LIGHTING Adjusting light functions via the Using direction indicators (p. 145) • WARNING centre display Using main beam (p. 144) • The car's lighting system is not able to Several light functions can be adjusted and determine when daylight is too weak or Dipped beam (p.
Page 144 LIGHTING Position lamps Daytime running lights position from another position to switch on only the position lamps instead of other light- Position lamps can be used so that other road The car has sensors that detect the light con- ing. users can see the car if it stops or is parked.
Page 145 LIGHTING Dipped beam Tunnel detection WARNING The car detects when it is driven into a tunnel When driving with the stalk switch's rotating This system help to save energy - it cannot and switches from daytime running lights to ring in the position, dipped beam is determine in all situations when daylight is dipped beam.
Page 146 LIGHTING Using main beam Active main beam main beam by moving the stalk switch for- wards. Main beam is operated with the left-hand Active main beam is a function which uses a stalk switch. Main beam is the car's stron- camera sensor at the top edge of the wind- Deactivate by moving the stalk switch gest lighting and should be used when driv-...
Page 147 LIGHTING Using direction indicators Activate active main beam Active main beam may be temporarily unavail- able e.g. in situations with dense fog or heavy Active main beam is activated and deactivated The car's direction indicators are operated rain. When active main beam becomes availa- by turning the left-hand stalk switch to posi- with the left-hand stalk switch.
Page 148 LIGHTING Active bending lights* The function is only active in weak daylight or NOTE darkness and only when the car is moving and Active bending lights are designed to provide This automatic flashing sequence can • dipped beam is switched on. additional illumination in bends and junctions.
Page 149 LIGHTING Front fog lamps/cornering lights* The front fog lamps switch off automatically Related information when the car is switched off or when the Lighting control (p. 140) • The fog lights are activated manually when rotating ring on the stalk switch is set to the driving in fog and automatically when revers- Ignition positions (p.
Page 150 LIGHTING Rear fog lamp Brake lights rotating ring on the stalk switch is set to the position. The rear fog lamp is considerably stronger The brake light automatically comes on dur- than the normal rear lights and should only be ing braking.
Page 151 LIGHTING Emergency brake lights Hazard warning flashers NOTE Emergency brake lights are activated to alert Hazard warning flashers warn other road Regulations for the use of hazard warning vehicles behind about heavy braking. users by means of all of the car's direction flashers may vary between countries.
Page 152 LIGHTING Using home safe lighting Approach light duration Interior lighting Some of the exterior lighting can be kept Approach lighting is switched on when the The passenger compartment is equipped switched on to work as home safe lighting car is unlocked and is used to switch on the with several types of lighting, e.g.
Page 153 LIGHTING Auto function for passenger compartment The passenger compartment lighting goes off lighting when: Reading lamp, right-hand side The car is locked • The car is started • Reading lighting The reading lamps on the right and left-hand A side door is closed •...
Page 154 LIGHTING Adjusting interior lighting Lighting in the cargo area brightness can be precisely adjusted using the thumbwheel in the instrument panel. The lighting in the cargo area is switched on or The lamps inside the car come on differently off when the tailgate is opened or closed. depending on the ignition position used.
Page 155 LIGHTING Ignition positions (p. 426) Changing the brightness of the lights • Settings Press in the top view in the cen- tre display. 2. Press My Car Lights and Lighting Interior Lighting Interior Mood Lighting. 3. Under Interior Mood Light Intensity High select from Changing the colour of the light...
Page 157 WINDOWS, GLASS AND MIRRORS...
Page 158 WINDOWS, GLASS AND MIRRORS Windows, glass and mirrors Pinch protection for windows and Activating and deactivating the heated • sun blinds rear window and door mirrors (p. 203) The car contains several different windows, glass panes and mirrors. Some of the win- All power windows and sun blinds* have dows in the car are laminated.
Page 159 Controls for rear windows. Pinch protection for windows and sun • Reset sequence for pinch protection • Controls for front windows. blinds (p. 156) (p. 157) Operating power windows (p. 158) • An authorised Volvo workshop is recommended. * Option/accessory.
Page 160 WINDOWS, GLASS AND MIRRORS Operating power windows WARNING Using the driver's door control panel, all Check that children or other passengers power windows can be operated - using the are not at risk of crushing when all the win- control panels in the other doors operates the dows are closed with a remote control key power window in the individual door.
Page 161 WINDOWS, GLASS AND MIRRORS Rearview and door mirrors Keyless locking and unlocking* (p. 251) Angling adjustment of the door mirrors • • (p. 161) The rearview mirrors and door mirrors can be Locking and unlocking with the remote • used to give the driver better visibility to the control key (p.
Page 162 WINDOWS, GLASS AND MIRRORS Adjusting rearview mirror dimming Automatic dimming* For the door mirrors to be equipped with auto- matic dimming, the interior rearview mirror Bright light from behind is automatically Bright light from behind could be reflected in must also be equipped with automatic dim- dimmed by the interior rearview and door mir- the rearview mirrors and dazzle the driver.
Page 163 WINDOWS, GLASS AND MIRRORS Angling adjustment of the door 2. Adjust the position with the joystick in the 3. Repeat the above procedure as necessary. mirrors centre. The mirrors are returned to the original posi- To ensure better visibility to the rear, the door 3.
Page 164 WINDOWS, GLASS AND MIRRORS Panorama roof* 3. Under Exterior Mirror Tilt at Reverse WARNING Driver Passenger Both select The panorama roof is divided into two glass Children, other passengers or objects may activate/deactivate and to select which sections. The front section can be opened be trapped by the moving parts.
Page 165 WINDOWS, GLASS AND MIRRORS Operating the panorama roof* Keyless locking and unlocking* (p. 251) • IMPORTANT The panoramic roof and sun blind are oper- Locking and unlocking with the remote • Remove ice and snow before opening • ated with a control in the roof panel and both control key (p.
Page 166 WINDOWS, GLASS AND MIRRORS The movement of both panoramic roof and Open and close ventilation position IMPORTANT sun blind are also stopped if the roof control is Remove ice and snow before opening • operated again in the opposite direction to the the panoramic roof.
Page 167 WINDOWS, GLASS AND MIRRORS Fully open and close the panoramic downward to the manual closing position Related information instead. roof using the roof control Panorama roof* (p. 162) • Automatic operation Automatic closing of the panoramic roof's* • Open the sun blind to maximum position - sun blind (p.
Page 168 WINDOWS, GLASS AND MIRRORS Automatic closing of the Wiper blades and washer fluid Locking and unlocking with the remote • panoramic roof's* sun blind control key (p. 226) Together with the washer fluid, the wipers aim to improve visibility as well as headlamp With this function, the sun blind is closed pattern.
Page 169 WINDOWS, GLASS AND MIRRORS Using windscreen wipers Intermittent wiping Wiper blades and washer fluid (p. 166) • Move the lever up to switch the wipers The windscreen wipers are designed to clean Using the rain sensor's memory function • to intermittent wiping. Set the number the windscreen.
Page 170 WINDOWS, GLASS AND MIRRORS Using the rain sensor Activate the rain sensor by pressing the rain Related information Using windscreen and headlamp washers sensor button • The rain sensor automatically starts the wind- (p. 169) screen wipers based on how much water it Move the lever down to make the wipers detects on the windscreen.
Page 171 WINDOWS, GLASS AND MIRRORS Using the rain sensor's memory Using windscreen and headlamp Set the wiper blades in service position • function washers (p. 632) The rain sensor automatically starts the wind- Replacing windscreen wiper blades Windscreen and headlamp washers are •...
Page 172 WINDOWS, GLASS AND MIRRORS Using the rear window wiper and Filling washer fluid (p. 633) • IMPORTANT washer Set the wiper blades in service position • Avoid activating the washer system when (p. 632) The rear windscreen washer and wiper are it is frozen or the washer reservoir is designed to clean the rear window.
Page 173 WINDOWS, GLASS AND MIRRORS Using automatic rear windscreen Set the wiper blades in service position • wiping when reversing (p. 632) Replacing windscreen wiper blades Engaging reverse gear while the windscreen • wipers are switched on initiates rear window (p. 631) wiping.
Page 174 WINDOWS, GLASS AND MIRRORS Replacing the wiper blade, rear window • (p. 630) Using windscreen wipers (p. 167) •...
Page 175 SEATS AND STEERING WHEEL...
Page 176 SEATS AND STEERING WHEEL Manual front seat Raise/lower the seat by means of pump- Using a stored position for seat and door • ing the lever up/down. mirrors (p. 176) The car's front seats have a range of setting options in order to enhance comfort. Change the backrest inclination by turning Adjusting* the length of the seat cushion •...
Page 177 SEATS AND STEERING WHEEL Power* front seat Adjusting the power* front seat Adjusting the lumbar support* in the front • seat (p. 178) The car's front seats have a range of setting Set to desired sitting position using the con- options in order to enhance comfort.
Page 178 SEATS AND STEERING WHEEL Using a stored position for seat The backrests of the front seats cannot be Closed front door and door mirrors lowered fully forward. Hold one of the memory buttons 1 ( ) or – If the positions for the power* seat and the ) depressed until seat and door mir- door mirrors have been stored, they can be rors stop in the positions that are stored in...
Page 179 SEATS AND STEERING WHEEL Adjusting* the length of the seat Adjusting the lumbar support* in the front Adjusting the lumbar support* in the front • • cushion in the front seat seat (p. 178) seat (p. 178) Angling adjustment of the door mirrors For increased comfort, you can adjust the •...
Page 180 SEATS AND STEERING WHEEL Adjusting the lumbar support* in Lowering the backrests in the rear Adjusting the lumbar support the front seat seat The lumbar support is adjusted using a con- The rear seat's backrest is divided into two trol on the side of the seat cushion. parts.
Page 181 SEATS AND STEERING WHEEL Ensure that there are no occupants or objects 4. If necessary, raise the centre seat's head IMPORTANT in the rear seat. restraint. The armrest* for the centre seat must be Lower the centre seat's head restraint raised before lowering the seat.
Page 182 SEATS AND STEERING WHEEL Adjusting the head restraints in the rear seat Adjust the centre seat head restraint accord- ing to the height of the passenger. Fold down the outer seat head restraints* to improve rearward visibility. Adjust the head restraint for the centre seat To lower the head restraint, the button (see Press the...
Page 183 SEATS AND STEERING WHEEL Steering wheel controls and horn Related information Horn Lowering the backrests in the rear seat • The steering wheel houses the horn and con- (p. 178) trols for e.g. the driver support systems and voice recognition. The horn is located in the centre of the steering wheel.
Page 184 SEATS AND STEERING WHEEL Steering lock Adjusting the steering wheel The steering wheel lock makes it difficult to The steering wheel can be adjusted in differ- steer the car if it is stolen, for example. A ent positions. mechanical noise can be perceived when the steering lock is locked or unlocked.
Page 185 CLIMATE...
Page 186 CLIMATE Climate Climate zones Climate control - sensors The car is equipped with electronic climate The number of climate zones that the car is The climate control system has a number of control. The climate control system cools or divided into governs the options for setting sensors to help control the climate in the car.
Page 187 CLIMATE Perceived temperature Controlling climate control with With the Interior Air Quality System* there is also an air quality sensor that is fitted into the voice recognition The climate control system regulates the cli- climate control system air intake. mate in the passenger compartment based Voice recognition commands for the climate on the perceived temperature, not on actual control system to e.g.
Page 188 Turn steering wheel heat on "/" Turn Use cleaning agents and car care products • steering wheel heat off " - activates/ recommended by Volvo to clean the interior. deactivates the heated steering wheel*. Air cleaning system " Raise steering wheel heat "/" Lower •...
Page 189 CLIMATE Clean Zone* Clean Zone Interior Package* (p. 188) That the air quality system Interior Air • • Quality System* is activated. The Clean Zone function checks and indi- Interior Air Quality System* (p. 188) • cates whether or not all conditions have been That the ventilation fan is activated.
Page 190 CLIMATE Clean Zone Interior Package* Interior Air Quality System* Clean Zone Interior Package* (p. 188) • Clean Zone Interior Package (CZIP) compri- Interior Air Quality System (IAQS) is a fully Passenger compartment filter (p. 189) • ses a series of modifications that keep the automatic air quality system that separates passenger compartment even clearer from gases and particles to reduce the levels of...
Page 191 Settings Press in the top view in the cen- necessary, the air distribution can be con- Follow the Volvo Service Programme for the tre display. trolled manually. recommended replacement intervals. If the car is used in a severely contaminated environ- 2.
Page 192 CLIMATE Changing air distribution NOTE The air distribution can be changed manually At low ambient temperatures, no air is dis- if required. tributed from the adjustable air vents on the rear of the tunnel console. Related information Open climate view in the centre display by Climate (p.
Page 193 CLIMATE Opening, closing and aiming the air vents Some air vents in the passenger compart- ment can be opened, closed and aimed indi- vidually. If the car's outer vents are aimed at the side windows then misting can be eliminated. If the car's outer vents are aimed inwards then, in a hot climate, a comfortable environ- ment is obtained in the passenger compart-...
Page 194 CLIMATE Table of air distribution options The air distribution can be changed manually if required. The following options are available for setting. Air distribution Purpose If all air distribution buttons are deselected in manual mode, the climate control system returns to automatically regulated climate control.
Page 195 CLIMATE Air distribution Purpose Main air from the defroster vents and air vents in the instrument panel. Provides good comfort in hot and dry climates. Some air flows from other air vents. Main air flow from the defroster vents and air vents at the floor. Some Provides good comfort and good demisting in a cold or air flows from other air vents.
Page 196 CLIMATE Related information Air distribution (p. 189) • Opening, closing and aiming the air vents • (p. 191) Changing air distribution (p. 190) •...
Page 197 CLIMATE Climate controls Main climate In addition to the climate row's functions, The climate control system's functions are other main climate functions can also be con- controlled from physical buttons in the centre Main climate trolled in the tab. console, the centre display and the climate controls at the rear of the tunnel console*.
Page 198 CLIMATE Activating and deactivating heated Fan control. Regulating fan level for front seat (p. 204) • front seat* Synchronising temperature (p. 205) • AUTO - Auto regulating the climate. The seats can be heated in order to increase Activating and deactivating air condition- •...
Page 199 CLIMATE Activating and deactivating Activating and deactivating heated WARNING automatic start of heated front rear seat* Heated seats must not be used by people seat* The seats can be heated in order to increase who find it difficult to perceive an increase The seats can be heated in order to increase comfort for driver and passengers when it is in temperature due to a lack of sensation or...
Page 200 CLIMATE Activating and deactivating the Activating and deactivating WARNING heated steering wheel* automatic start of heated steering Heated seats must not be used by people wheel* The steering wheel can be heated in order to who find it difficult to perceive an increase increase comfort for the driver when it is The steering wheel can be heated in order to in temperature due to a lack of sensation or...
Page 201 CLIMATE Activating auto climate control Activating and deactivating air NOTE recirculation With auto climate control activated, multiple Temperature and fan speed can be climate functions are controlled automati- Air recirculation shuts out bad air, exhaust changed without deactivating the automat- cally.
Page 202 CLIMATE Activating and deactivating time Activating and deactivating max Related information setting for air recirculation defroster Climate controls (p. 195) • Air recirculation shuts out bad air, exhaust Max defroster is used to quickly remove mist Activating and deactivating time setting •...
Page 203 CLIMATE Activating and deactivating the NOTE heated windscreen* Max defroster starts with a certain delay in A heated windscreen is used to quickly order to avoid a short increase in fan level if remove mist and ice from the window. the heated windscreen is deactivated by two quick presses of the button.
Page 204 CLIMATE Activating and deactivating Activating and deactivating heated Related information automatic start of heated windscreen from centre display Climate controls (p. 195) • windscreen* Activating and deactivating automatic • A heated windscreen is used to quickly start of heated windscreen* (p. 202) remove mist and ice from the window.
Page 205 CLIMATE Activating and deactivating the Activating and deactivating Activating and deactivating heated heated rear window and door automatic starting of the heated rear window and door mirrors from mirrors rear window and door mirrors centre display The heated rear window and door mirrors are The heated rear window and door mirrors are used to quickly remove mist and ice from the used to quickly remove mist and ice from the...
Page 206 CLIMATE Regulating temperature for front Regulating fan level for front seat IMPORTANT seat The fan can be set to several different auto- If the fan is fully switched off then the air matically controlled fan speeds for the front The temperature can be set to the desired conditioning is not engaged, which results seat.
Page 207 CLIMATE Synchronising temperature Related information Climate controls (p. 195) • The temperature in the car's different climate zones can be synchronised with the tempera- ture set on the driver's side. Temperature control. 2. Regulate the temperature by either of the following: drag the control to the desired tem- •...
Page 208 CLIMATE Activating and deactivating air Parking climate NOTE conditioning Parking climate control is a generic term for It is not possible to activate the air condi- various functions that improve the passenger The air conditioning cools and dehumidifies tioning when the fan control is in posi- compartment climate when the car is parked, incoming air as required.
Page 209 CLIMATE Preconditioning Start and switch off NOTE preconditioning Preconditioning is a climate function which, if Preconditioning is available only when the possible, attempts to reach comfort tempera- Preconditioning heats or cools the passenger car is connected to an electrical socket ture in the passenger compartment before compartment, if possible, prior to driving.
Page 210 Starting from the app* Start of preconditioning and information about the selected settings can be managed from a device that has the Volvo On Call* app. Pre- conditioning heats or cools the passenger compartment (using the car's air conditioning) to comfort temperature.
Page 211 CLIMATE Preconditioning time setting Adding and editing time setting for Removing time setting for preconditioning • preconditioning (p. 211) The timer can be set so that the precondition- ing is finished at a predetermined time. The timer for preconditioning can manage up to 8 time settings.
Page 212 CLIMATE 3. Press Add timer 7. Tap on Confirm in order to add the time 3. Press the time setting that is to be setting. changed. > A pop-up window is shown. > A pop-up window is shown. > The time setting is added to the list and is activated.
Page 213 CLIMATE Activating and deactivating time Removing time setting for WARNING setting for preconditioning preconditioning Do not use preconditioning A time setting in the timer for preconditioning A time setting for preconditioning that is no In unventilated spaces indoors. can be activated or deactivated based on •...
Page 214 CLIMATE Climate comfort when parking Related information Related information Preconditioning (p. 207) Parking climate (p. 206) • • The climate in the car's passenger compart- ment can be maintained while the car is Preconditioning time setting (p. 209) Starting and switching off climate comfort •...
Page 215 CLIMATE Starting and switching off climate NOTE comfort when parking Climate comfort retention is switched off Climate comfort retention maintains the cli- when the car is locked from the outside to mate in the passenger compartment after avoid using residual heat unnecessarily. driving.
Page 216 This symbol illuminates in the driver climate control can also be displayed in a device which has display when the parking heater is the Volvo On Call* app. active. A number of symbols and messages regar- ding parking climate control can be shown in the driver display.
Page 217 The running time for parking climate control is limited when the state of charge in the hybrid battery is low. Start the car. Limited Charge level too low An authorised Volvo workshop is recommended. Applies to fuel-driven heater. Applies to electric heater.
Page 218 Warning label on fuel filler flap. is perfectly normal. The heater uses fuel from the car's normal fuel tank. An authorised Volvo dealer has information regarding which markets use which type of heater. Applicable to fuel-driven auxiliary heater. Applies to fuel-driven heater.
Page 219 , switch parking climate's preconditioning is activated off the heater and, if possible, pull out its and the passenger compartment needs to be fuse. Volvo recommends that an authorised heated up. Volvo workshop should be contacted for repair. Applies to fuel-driven heater.
Page 220 CLIMATE Additional heater Related information Related information Heater (p. 216) Heater (p. 216) • • The auxiliary heater helps to heat the passen- ger compartment and engine while driving. Additional heater (p. 218) Parking heater (p. 217) • • The additional heater is one of two subfunc- Activating and deactivating automatic •...
Page 221 Additional Heater to activate/ deactivate automatic start of the addi- tional heater. NOTE Volvo recommends that the automatic start for the additional heater should be switched off for short driving distances NOTE If the auxiliary heater's automatic starting is deactivated, this may impede comfort in...
Page 223 KEY, LOCKS AND ALARM...
Page 224 KEY, LOCKS AND ALARM Lock confirmation Lock and alarm indicator on the Indication in lock buttons instrument panel The car indicates with hazard warning flash- Front door ers when the car is locked or unlocked. Exterior indication Locking The car's hazard warning flashers indicate •...
Page 225 KEY, LOCKS AND ALARM Lock indication setting Remote control key Rear door* It is possible to select various options for how The remote control key locks and unlocks the the car confirms locking and unlocking in the doors and tailgate. The remote control key settings menu in the centre display.
Page 226 KEY, LOCKS AND ALARM Remote control key buttons automatically when the button is held WARNING depressed. The tailgate is also closed with The remote control key contains a button a long press – acoustic warning signals cell battery. Keep new and used batteries sound.
Page 227 KEY, LOCKS AND ALARM Detachable key blade (p. 233) • NOTE NOTE Immobiliser (p. 236) • Avoid storing the remote control key close Be aware of the risk of locking the remote Linking remote control key to driver profile • to metal objects or electronic apparatus, control key in the car.
Page 228 KEY, LOCKS AND ALARM Locking and unlocking with the activated when all the doors and the tailgate Automatic relocking remote control key are closed and locked. If none of the doors or the tailgate is opened within 2 minutes of unlocking, they are locked The buttons on the remote control key can be NOTE automatically.
Page 229 KEY, LOCKS AND ALARM Settings for remotely controlled Unlocking the tailgate with the 2. With the power operated tailgate option* - and inside unlocking remote control key Long press (approx. 1.5 seconds) on the It is possible to select different sequences for It is possible to unlock just the tailgate by remote control key's button...
Page 230 KEY, LOCKS AND ALARM Remote control key range Replacing the battery in the NOTE remote control key In order for the remote control key to work The remote control key functions may be properly it needs to be within a certain dis- The battery in the remote control key needs disrupted by surrounding radio waves, tance from the car.
Page 231 Hold the remote control key with the front visible and the Volvo logo facing the The shell will then come free and can right way - slide the button at bottom be lifted off the key.
Page 232 KEY, LOCKS AND ALARM Use a screwdriver or similar to turn the The battery (+) side is facing upwards. Install a new battery with the (+) side up. battery cover anticlockwise until the mark- Then carefully prize loose the battery as Avoid touching the remote control key's ings meet at the OPEN text.
Page 233 KEY, LOCKS AND ALARM NOTE Volvo recommends that the batteries to be used in the remote control key fulfil UN Manual of Test and Criteria, Part III, sub- section 38.3. Batteries fitted in the factory or replaced by an authorised Volvo work- shop fulfil the above criteria.
Page 234 If you lose a remote control key then a new since they can be swallowed by chil- one can be ordered at a workshop - an author- dren or pets. ised Volvo workshop is recommended. The Batteries must not: be dismantled, • remaining remote control keys must be taken short-circuited or thrown into open to the workshop.
Page 235 Detach the key blade by angling it up. Using the remote control key's detachable key blade Hold the remote control key with the front visible and the Volvo logo facing the the left-hand front door can be opened • right way - slide the button at bottom manually if central locking cannot be acti- edge by the key ring to the right.
Page 236 KEY, LOCKS AND ALARM Locking and unlocking with the Related information 5. Pull out the handle. detachable key blade Locking and unlocking with the detacha- • > The door opens. ble key blade (p. 234) Amongst other things, the detachable key Locking will be performed in the same way, blade can be used to unlock the car from the Remote control key (p.
Page 237 Volvo On 2. Press the start button. Call*. Manual locking of the door. Not to be mixed up with >...
Page 238 KEY, LOCKS AND ALARM Immobiliser Related information Starting the car (p. 424) • The electronic immobiliser is a theft protec- tion system that prevents an unauthorised Detachable key blade (p. 233) • person from starting the car. Activating and deactivating alarms* •...
Page 239 KEY, LOCKS AND ALARM Type approval for the remote Lock system keyless start (Passive control key system Start) and keyless locking/unlocking (Passive Entry*) Type approval for the car's remote key sys- tem can be seen in the following tables. For detailed information on type approval, go to www.volvocars.com/intl/support.
Page 240 KEY, LOCKS AND ALARM Country/Area Type approval Brazil MT-3245/2015 Indonesia Nomor: 38301/SDPPI/2015 Malaysia RAAT/37A/1215/S(15-5198) Mexico IFETEL: RLVDEVO15-0396 Russia The United Arab Emi- ER37847/15 rates DA0062437/11...
Page 241 KEY, LOCKS AND ALARM Country/Area Type approval Namibia TA-2016-02 South Africa TA-2014-1868...
Page 242 KEY, LOCKS AND ALARM Remote control key Country/ Type approval Area Europe Huf Hülsbeck & Fürst GmbH & Co. KG hereby declares that this type of radio equipment HUF8423 conforms to directive 2014/53/EU. The full text of the EU declaration of conformity can be found at www.volvocars.com/intl/support Wavelength: 433.92 MHz Maximum radiated transmission power: 10 mW...
Page 243 KEY, LOCKS AND ALARM Country/ Type approval Area (Customs Union) Belarus, Kazakhstan, Russia Indonesia [41005/SDPPI/2015] [5149] Jordan TRC/LPD/2015/104 Morocco AGREE PAR L'ANRT MAROC Numéro d’agrément: MR 10668 ANRT 2015 Date d’agrément: 24/07/2015 Moldova...
Page 244 KEY, LOCKS AND ALARM Country/ Type approval Area Mexico IFETEL Marca: HUF Modelo (s): HUF8423 NOM-121-SCT1-2009 La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es posible que este equipo o dispositivo no cause interferencia perjudicial y (2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su operación no deseada.
Page 245 KEY, LOCKS AND ALARM Country/ Type approval Area Philippines Serbia Singapore Complies with IMDA Standards DA103787 South Africa TA-2015-432...
Page 246 KEY, LOCKS AND ALARM Country/ Type approval Area 本產品符合低率電波輻射性電機管理辦法第十二條第十四條等條文規定 1. 經 Taiwan 型式認證合格之低率射頻電機，非經許可，公司商號或使用者均不得擅自變更頻率大率或變更原設計之特性及能 2. 低率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並改善至無干擾時方得繼續使用前項合法通信，指依電信法規定作業之無線電通信低率射頻電機須忍受合法通信或工業科學及醫療用電波輻射性電機設備之干擾 The United Arab Emi- rates...
Page 247 KEY, LOCKS AND ALARM Key Tag Country/ Type approval Area Europe Huf Hülsbeck & Fürst GmbH & Co. KG hereby declares that this type of radio equipment HUF8432 conforms to directive 2014/53/EU. The full text of the EU declaration of conformity can be found at www.volvocars.com/intl/support.
Page 248 KEY, LOCKS AND ALARM Country/ Type approval Area (Customs Union) Belarus, Kazakhstan, Russia Indonesia [41006/SDPPI/2015] [5149] Jordan TRC/LPD/2015/107 Morocco AGREE PAR L'ANRT MAROC Numéro d’agrément: MR 10667 ANRT 2015 Date d’agrément: 24/07/2015 Mexico IFETEL Marca: HUF Modelo (s): HUF8432 NOM-121-SCT1-2009 IFT: RLVHUHU15-0972 La operación de este equipo está...
Page 249 KEY, LOCKS AND ALARM Country/ Type approval Area Moldova Nigeria Connection and use of this communications equipment is permitted by the Nigerian Communications Commission Oman Philippines ESD-1511501C...
Page 250 KEY, LOCKS AND ALARM Country/ Type approval Area Serbia Singapore Complies with IMDA Standards DA103787 South Africa TA-2015-414...
Page 251 KEY, LOCKS AND ALARM Country/ Type approval Area 本產品符合低率電波輻射性電機管理辦法第十二條第十四條等條文規定 1. 經 Taiwan 型式認證合格之低率射頻電機，非經許可，公司商號或使用者均不得擅自變更頻率大率或變更原設計之特性及能 2. 低率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並改善至無干擾時方得繼續使用前項合法通信，指依電信法規定作業之無線電通信低率射頻電機須忍受合法通信或工業科學及醫療用電波輻射性電機設備之干擾 The United Arab Emi- rates Related information Remote control key (p.
Page 252 KEY, LOCKS AND ALARM Keyless and touch-sensitive Related information NOTE surfaces* Keyless locking and unlocking* (p. 251) • It is important that only one touch-sensi- With the keyless locking and unlocking func- Keyless unlocking of the tailgate* (p. 252) • tive surface is activated at a time.
Page 253 KEY, LOCKS AND ALARM Keyless locking and unlocking* Keyless locking Keyless unlocking All side doors must be closed to be able to Grasp a door handle or gently press the With keyless locking and unlocking, it is suffi- – lock the car. The tailgate, on the other hand, rubberised pressure plate beneath the tail- cient to touch the door handle's touch-sensi- can be open when locking the car with a side...
Page 254 KEY, LOCKS AND ALARM Settings for Keyless entry* Keyless unlocking of the tailgate* Related information Settings for Keyless entry* (p. 252) • It is possible to select different sequences for With keyless locking and unlocking, it is suffi- Keyless entry. cient to touch the touch-sensitive surface on Keyless unlocking of the tailgate* (p.
Page 255 KEY, LOCKS AND ALARM Antenna locations for the start and 2. Lift by the outside handle in order to open WARNING lock systems the tailgate. People with pacemaker operations should An antenna for the keyless starting system not come closer than 22 cm (9 inches) to IMPORTANT and antennas for the keyless locking system* the keyless system's antennas with their...
Page 256 KEY, LOCKS AND ALARM Locking and unlocking from inside Locking using a button in the front Alternative unlocking method the car door The doors and tailgate can be locked and Press the button - both front doors – unlocked from inside using the central lock- must be closed.
Page 257 KEY, LOCKS AND ALARM Unlocking the tailgate from the Related information Related information inside of the car Settings for remotely controlled and inside Locking and unlocking from inside the car • • unlocking (p. 227) (p. 254) The tailgate can be unlocked from inside by pressing the button on the instrument panel.
Page 258 KEY, LOCKS AND ALARM Activating and deactivating child 2. Press the button in the driver's door con- NOTE safety locks trol panel. A door's knob control only blocks that • > The driver display shows the message The child safety locks prevent the rear doors particular door - not both rear doors Rear child lock Activated and the but-...
Page 259 KEY, LOCKS AND ALARM Automatic locking when driving Opening and closing the power*- Symbol Message Specification operated tailgate The doors and tailgate are locked automati- Rear child Child safety cally when the car starts to move. Function where the tailgate can be opened locks are acti- lock Acti- To change this setting:...
Page 260 KEY, LOCKS AND ALARM Foot movement* under the rear bumper. Long press on the instrument panel's – Press the button on the underside of – – button. Keep it depressed until the tailgate the tailgate to close. Closing starts to open. >...
Page 261 KEY, LOCKS AND ALARM Closing and locking detected sufficiently close to the tail- Long press on the button on the – gate. remote control key. > The tailgate closes automatically and acoustic signals sound – the tailgate remains unlocked. IMPORTANT Long press on the button on the During manual tailgate operation, open or...
Page 262 KEY, LOCKS AND ALARM Programming maximum opening Pinch protection Pre-tensioned springs for power operated tailgate* If something with sufficient resistance pre- vents the tailgate from opening or closing then Adapt the tailgate's opening position to low the pinch protection is activated. roof height.
Page 263 KEY, LOCKS AND ALARM Operating the tailgate with foot NOTE movement* If the system has been operating con- • A function which allows the tailgate to open tinuously for a long time, it is switched and close by moving a foot under the rear off to avoid overload.
Page 264 KEY, LOCKS AND ALARM Private locking Opening and closing with foot Cancelling opening or closing with foot movement movement The tailgate can be locked with the private Make one forward kicking motion while locking function which prevents it from being –...
Page 265 KEY, LOCKS AND ALARM Activating and deactivating private To create a security code: 2. Enter the code to be used in order to locking unlock the tailgate after locking and tap on Press the button for private locking in the Confirm Private locking is activated with a function function view.
Page 266 KEY, LOCKS AND ALARM Alarm* If the car is unlocked via Volvo On Call* or the Alarm indicator Volvo On Call app, private locking will be The alarm provides audible and visual warn- deactivated automatically. ings if anyone enters the car without a valid...
Page 267 Lock and arm the car alarm as follows case, contact a workshop - an authorised The movement sensor triggers an alarm in the Volvo workshop is recommended. event of movement in the passenger compart- press the remote control key's lock button •...
Page 268 KEY, LOCKS AND ALARM Open the driver's door with the detacha- Automatic arming and rearming of the ble key blade. alarm > The alarm is triggered. Automatic rearming of the alarm prevents the car being left with the alarm disarmed unin- tentionally.
Page 269 The car can only be unlocked with a remote ing the car. control key, keyless unlocking* or the Volvo On Call* app when double lock is activated. At the same time, the double lock function is The front left door can also be unlocked with deactivated, i.e.
Page 270 KEY, LOCKS AND ALARM Temporarily* deactivating double If the car is unlocked and then locked again, locks the double lock function must be deactivated again. If someone is going to stay in the car but the doors must be locked from the outside, then The system is reset the next time the engine is the double lock function should be deacti- started.
Page 271 DRIVER SUPPORT...
Page 272 DRIVER SUPPORT Driving support systems Speed-dependent steering force Pilot Assist* (p. 314) • The car is equipped with different driver sup- Speed related power steering causes the Overtaking Assistance* (p. 325) • port systems which can assist the driver in steering wheel force to increase with the Lane assistance (p.
Page 273 DRIVER SUPPORT Electronic stability control General speed warning WARNING Electronic Stability Control (ESC ) helps the At speeds between 80-120 km/h If the temperature increases too much, the driver to avoid skidding and improves the (50-75 mph) the driver is warned by an acous- servo may be forced to switch off com- tic signal every other minute.
Page 274 Trailer Stability Assist is deactivated if • bilise the car. Sport Mode is activated. Also known as Active Yaw Control. Engine Drag Control Trailer stability assist is included when the Volvo genuine towbar is installed. Trailer Stability Assist * Option/accessory.
Page 275 DRIVER SUPPORT Electronic Stability Control in sport Activating or deactivating sport Related information mode mode for electronic stability Electronic stability control (p. 271) • control The stability system (ESC ) is always acti- Activating or deactivating sport mode for • vated –...
Page 276 DRIVER SUPPORT ESC Sport Mode function cannot be selected when one of the following functions is activated: Speed limiter • Cruise control • Adaptive cruise control* • Pilot Assist* • Related information Electronic Stability Control in sport mode • (p. 273) Electronic stability control (p.
Page 277 The system is disengaged. Stop the car in a safe place, switch off the engine and start it again. Service required A text message can be cleared by briefly If a message remains: Contact a workshop – Related information an authorised Volvo workshop is recom- Electronic stability control (p. 271) pressing the button, located in the centre •...
Page 278 DRIVER SUPPORT City Safety™ and the car normally stops just behind the WARNING vehicle in front. City Safety can use lights, sound and a The function is supplementary driver • brake pulse warning to alert the driver to The function helps the driver by automatically support intended to facilitate driving pedestrians, cyclists, larger animals and vehi- braking the car in the event of an imminent...
Page 279 DRIVER SUPPORT Subfunctions for City Safety The steps of City Safety Detection of obstacles with City Safety • (p. 280) City Safety carries out three steps in the fol- City Safety can help to prevent a collision or lowing order: City Safety brakes for oncoming vehicles reduce the collision speed.
Page 280 DRIVER SUPPORT City Safety brakes for oncoming vehicles 2 - Brake support • NOTE (p. 284) If the risk of collision has increased further On cars with manual gearbox, the engine after the collision warning then the brake sup- Limitations of City Safety (p. 285) •...
Page 281 DRIVER SUPPORT Setting the warning distance for When warnings are perceived as being too WARNING City Safety frequent or disturbing, the warning distance No automatic system can guarantee • can be reduced, which reduces the total num- City Safety is always activated but the 100% correct function in all situations.
Page 282 DRIVER SUPPORT Detection of obstacles with City Cyclists NOTE Safety The warning with direction indicators for City Safety can help the driver to detect Rear Collision Warning* is deactivated if vehicles, cyclists, large animals and pedes- the warning distance for collision warning trians.
Page 283 DRIVER SUPPORT Good performance requires that the system WARNING WARNING function that detects a pedestrian must City Safety is supplementary driver sup- City Safety is supplementary driver sup- receive the clearest possible information about port, but it cannot detect all cyclists in all port, but it cannot detect all pedestrians in the body outline, requiring the ability to iden- situations and, for example, cannot see:...
Page 284 DRIVER SUPPORT City Safety in cross traffic Large animals WARNING City Safety can help the driver when turning City Safety is supplementary driver sup- and crossing the path of another oncoming port, but it cannot detect all large animals vehicle at an intersection. in all situations and, for example, cannot see: partially obscured large animals.
Page 285 DRIVER SUPPORT Limitations for City Safety in cross The following further criteria must also be ful- NOTE traffic filled: This function uses the car's camera and In some cases City Safety may have difficulty your car must be travelling at no less than •...
Page 286 DRIVER SUPPORT Automatic braking in the event of City Safety brakes for oncoming City Safety does not intervene with the auto- an impeded evasive manoeuvre vehicles brake function as long as the driver him/ with City Safety herself has the opportunity to avoid a collision City Safety can assist the driver to use emer- via a steering manoeuvre.
Page 287 Maintenance of driver support components straight ahead. must only be performed at a workshop – Heat an authorised Volvo workshop is recom- Related information In the event of high passenger compartment mended. City Safety™ (p. 276) •...
Page 288 DRIVER SUPPORT Driver intervention Important warnings WARNING Reversing Warnings and brake interventions • WARNING When your own car is reversing, City Safety is could be implemented late or not at all temporarily deactivated. Driver supports only warn of obstacles if a traffic situation or external influ- which their radar unit has detected –...
Page 289 DRIVER SUPPORT may be disengaged due to darkness or Search path in the top view of the centre dis- WARNING poor visibility. play: The City Safety auto-brake function • Warnings and brake interventions for • • Settings My Car IntelliSafe can prevent a collision or reduce colli- pedestrians and cyclists are deacti- sion speed, but to ensure full brake...
Page 290 City Safety The system does not function as it should. A workshop should be contacted Reduced functionality Service required An authorised Volvo workshop is recommended. A text message can be cleared by briefly pressing the button, located in the centre of the steering wheel's right-hand keypad.
Page 291 DRIVER SUPPORT Road Sign Information* Related information NOTE Driving support systems (p. 270) • The Road Sign Information function (RSI In certain markets, the Road Sign Informa- can help the driver to observe speed-related Activating or deactivating road sign infor- •...
Page 292 DRIVER SUPPORT Activating or deactivating road Display mode for road sign NOTE sign information* information* If the automatic speed limiter function • The Road Sign Information function (RSI ) is The Road Sign Information function (RSI is activated, road sign information is optional –...
Page 293 DRIVER SUPPORT An additional sign, such as if map data has no information on the speed The driver display symbol extinguishes after "no overtaking", may be limit for the road section in question. about 5 minutes until the next speed-related shown together with the sign is passed.
Page 294 DRIVER SUPPORT Road Sign Information and Sensus An additional sign relating to rain is displayed Sign for "School" and "Children at Navigation* only if the windscreen wipers are in use. play" If a warning sign for "School" If the car is equipped with Sensus Navigation*, If a trailer is connected to the car's electrical or "Children at play"...
Page 295 DRIVER SUPPORT Warning for speed limitation and A speed warning is always given if the speed Warning for speed camera speed camera from road sign limit is exceeded in connection with speed A car equipped with road information* camera information. sign information and Sensus Navigation can provide infor- Road sign information (RSI...
Page 296 DRIVER SUPPORT Activating or deactivating Note that the function does 2. Select/deselect Speed Camera Audio warnings from road sign not give any consideration to Warning to activate/switch off the audi- information* selected limit adjustment ble speed camera warning. when the driver display The subfunction Speed Limit Warning Related information...
Page 297 DRIVER SUPPORT Limitations of Road Sign Speed limiter NOTE Information* A speed limiter (SL ) can be likened to a The RSI function may interpret some types reverse cruise control - the driver regulates The Road Sign Information (RSI ) function of bicycle rack, connected to the electrical the speed using the accelerator pedal but is may have limitations in certain situations.
Page 298 DRIVER SUPPORT Set the stored speed for driver support • : From active mode – deactivates/ WARNING (p. 327) changes the speed limiter to standby The function is supplementary driver • mode Automatic speed limiter (p. 299) • support intended to facilitate driving : Reduces stored maximum speed and make it safer –...
Page 299 DRIVER SUPPORT Selecting and activating speed Deactivating the speed limiter 2. When speed limiter is selected – press the limiter steering wheel button (2) to activate. The speed limiter (SL ) can be deactivated and switched off. The speed limiter function (SL ) must first >...
Page 300 DRIVER SUPPORT Temporary deactivation of speed Limitations for speed limiter Related information limiter Speed limiter (p. 295) • Speed limiter (SL ) has certain general limi- tations. Selecting and activating speed limiter The speed limiter (SL ) can be temporarily •...
Page 301 DRIVER SUPPORT Automatic speed limiter Symbol for automatic speed limiter WARNING The sign symbol (displayed along- The Automatic Speed Limiter (ASL ) func- The function is supplementary driver • side the stored speed, "70", in the tion helps the driver to adapt the car's maxi- support intended to facilitate driving centre of the speedometer) can be mum speed to the speed shown on the road...
Page 302 DRIVER SUPPORT Activating or deactivating the Symbol NOTE automatic speed limiter If the automatic speed limiter function • The automatic speed limiter function (ASL is activated, road sign information can be activated and deactivated as a supple- (RSI ) is shown in the driver display ✓...
Page 303 DRIVER SUPPORT Changing the tolerance for the Deactivating the automatic speed Press the steering wheel button – automatic speed limiter limiter until 70 km/h (43 mph) in the centre of To deactivate the automatic speed limiter: the speedometer (2) changes to 75 km/h The Automatic Speed Limiter function (47 mph).
Page 304 DRIVER SUPPORT Limitations for automatic speed Cruise control Marker for stored speed limiter The cruise control (CC ) helps the driver The car's current speed maintain an even speed, which can result in Automatic speed limitation (ASL ) takes more relaxed driving on motorways and long, place using speed information from the Road Stored speed straight roads in regular traffic flows.
Page 305 DRIVER SUPPORT Selecting and activating cruise To do so, proceed as follows: WARNING control Depress the accelerator pedal about half- – The function is supplementary driver • The cruise control function (CC ) must first way down and release. support intended to facilitate driving be selected and activated in order to be able >...
Page 306 DRIVER SUPPORT Deactivating cruise control 2. When cruise control is selected – press Related information Cruise control (p. 302) the steering wheel button (2) to acti- • Cruise control (CC ) can be deactivated and vate. switched off. Change between cruise control and adap- •...
Page 307 DRIVER SUPPORT Standby mode for cruise control Automatic standby mode Adaptive cruise control* Activation of automatic standby mode can be Cruise control (CC ) can be deactivated and The adaptive cruise control (ACC ) can help due to one of the following: set in standby mode.
Page 308 (p. 330) ulations. Change of target with driver support • (p. 327) IMPORTANT Overtaking Assistance* (p. 325) • Maintenance of driver support components must only be performed at a workshop – an authorised Volvo workshop is recom- mended. * Option/accessory.
Page 309 DRIVER SUPPORT Controls for adaptive cruise Display mode for adaptive cruise Increases the time interval to vehicles ahead control* control* Reduces the time interval to vehicles A summary of how adaptive cruise control The following image example shows how ahead (ACC ) is controlled using the left-hand key- Adaptive cruise control (ACC...
Page 310 DRIVER SUPPORT Selecting and activating adaptive Time interval The time interval is only cruise control* adjusted to the vehicle ahead Adaptive cruise control (ACC ) must first be by the Adaptive cruise control selected and then activated to enable it to when the distance symbol control speed and distance.
Page 311 DRIVER SUPPORT Deactivating adaptive cruise the car, or the current speed must be at WARNING least 15 km/h (9 mph). control* A significant increase in speed may follow For cars with manual gearbox. Speed • The adaptive cruise control (ACC ) can be when the speed is resumed with the must be at the lowest 30 km/h (20 mph).
Page 312 DRIVER SUPPORT 2. Press the steering wheel button ◀ (1) or ▶ Standby mode for adaptive cruise WARNING (3) to change to another function. control* With the adaptive cruise control is in • > The driver display's symbol and indica- Adaptive cruise control (ACC ) can be deac- standby mode, the driver must inter-...
Page 313 DRIVER SUPPORT Limitations for adaptive cruise Automatic standby mode may be engaged in Related information the event of one of the following: control* Adaptive cruise control* (p. 305) • Selecting and activating adaptive cruise One of the systems that Adaptive cruise •...
Page 314 DRIVER SUPPORT Change between cruise control Related information WARNING and adaptive cruise control* Adaptive cruise control* (p. 305) • This is not a collision avoidance sys- • the centre display Cruise control (p. 302) • tem. The driver is always responsible When the normal cruise control (CC ) is and must intervene if the system does...
Page 315 Clean the windscreen in front of the camera and radar unit's detectors. Sensor blocked, see Owner's manual A text message can be cleared by briefly If a message remains: Contact a workshop – an authorised Volvo workshop is recom- pressing the button, located in the centre mended.
Page 316 DRIVER SUPPORT Pilot Assist* about all of the function's applications and lim- braking may come unexpectedly or not at itations in order to safely use all of the advan- all. Pilot Assist can help the driver to drive the tages. follow the vehicle ahead in the same lane car between the lane's side markings as well •...
Page 317 DRIVER SUPPORT Steering assistance If Pilot Assist detects that the WARNING driver does not keep his/her The current status of steering Pilot Assist steering assistance is automati- hands on the steering wheel, assistance is indicated by the cally deactivated and is resumed without the system gives a warning colour of the steering wheel's prior warning.
Page 318 Maintenance of driver support components : Activates Pilot Assist from standby must only be performed at a workshop – mode and resumes the stored speed and an authorised Volvo workshop is recom- time interval mended. : Increases the stored speed This function can be either standard or optional, depending on market.
Page 319 DRIVER SUPPORT Display mode for Pilot Assist* Time interval : Reduces stored speed Pilot Assist only regulates the The following image example shows how Increases the time interval to vehicles time interval to the vehicle Pilot Assist can be shown in the display in dif- ahead ahead when the distance ferent contexts.
Page 320 DRIVER SUPPORT The previous illustration shows that Pilot The previous illustration shows that Pilot Assist is set to maintain 110 km/h (68 mph) Assist is set to maintain 110 km/h (68 mph) and that there is no vehicle ahead to follow. and that there is no vehicle ahead to follow.
Page 321 DRIVER SUPPORT Selecting and activating Pilot The speed must not exceed 140 km/h (87 Reactivating Pilot Assist to last stored • mph). Assist* speed When Pilot Assist is selected – press the The driver must keep his/her hands on the Pilot Assist must first be selected and then •...
Page 322 DRIVER SUPPORT Deactivate Pilot Assist* Standby mode for Pilot Assist* WARNING Pilot Assist can be deactivated and switched Pilot Assist can be deactivated and set in With Pilot Assist in standby mode, the • off. standby mode. This can take place due to driver must intervene and steer, regu- driver intervention or automatically.
Page 323 DRIVER SUPPORT Temporary disabling of steering Automatic standby mode The speed is below 5 km/h (3 mph) and • Pilot Assist is uncertain whether the vehi- assistance with Pilot Assist* cle ahead is a stationary vehicle or an WARNING Pilot Assist steering assistance can be tem- object, such as a speed bump.
Page 324 DRIVER SUPPORT Limitations of Pilot Assist* with poor light conditions, back-light- WARNING ing, wet road surface etc. The Pilot Assist function may have limitations In certain situations, Pilot Assist steering The driver should also note that Pilot Assist in certain situations. assistance may have difficulty helping the has the following limitations: The Pilot Assist function is an aid which can...
Page 325 DRIVER SUPPORT data, which may result in varied per- Do not use Pilot Assist if the car has a heavy WARNING formance. load or a trailer is connected to the car. This is not a collision avoidance sys- • Pilot Assist is switched off if the power •...
Page 326 Sensor blocked, see Owner's man- Related information A text message can be cleared by briefly If a message remains: Contact a workshop – an authorised Volvo workshop is recom- Pilot Assist* (p. 314) pressing the button, located in the centre •...
Page 327 DRIVER SUPPORT Overtaking Assistance* Use Overtaking Assistance WARNING Overtaking Assistance can help the driver Overtaking assistance can be used with The function is supplementary driver • when overtaking other vehicles. The function adaptive cruise control* or Pilot Assist*. There support intended to facilitate driving can be used with adaptive cruise control* or are a number of criteria if Overtaking Assis- and make it safer –...
Page 328 DRIVER SUPPORT Warning from driver support in the acoustic warning are activated to alert the WARNING event of a collision risk driver that immediate intervention is required. When using the Overtaking Assistance The driver support systems of adaptive cruise System, the driver should be aware that WARNING control* and Pilot Assist* can warn the driver there may be undesired acceleration if the...
Page 329 DRIVER SUPPORT Change of target with driver Set the stored speed for driver WARNING support support When the driver supports are following The driver supports of adaptive cruise con- It is possible to set stored speed for the another vehicle at speeds in excess of trol* and Pilot Assist*, in combination with speed limiter, cruise control, adaptive cruise approx.
Page 330 DRIVER SUPPORT Set time interval to vehicle ahead Change a set speed with short presses on Pilot Assist can give steering assistance from – almost stationary up to 140 km/h (87 mph). the steering wheel buttons (1) or It is possible to set the time interval to the (2) or by pressing and holding them.
Page 331 DRIVER SUPPORT The adaptive cruise control allows the time Related information NOTE interval to vary significantly in certain situa- Drive modes when using time interval to • When the symbol in the driver display tions in order to allow the car to follow the vehicles (p.
Page 332 DRIVER SUPPORT Drive modes when using time Automatic braking with driver WARNING interval to vehicles support Driver supports only warn of obstacles The driver can select different driving styles The driver supports of adaptive cruise con- which their radar unit has detected – for how driver support should maintain the trol* and Pilot Assist* have a special brake hence a warning may not be given, or it...
Page 333 DRIVER SUPPORT Lane assistance Related information Cessation of automatic braking In some situations, automatic braking ceases Driving support systems (p. 270) • The function of the Lane Keeping Aid (LKA on coming to a standstill and the function is is to help the driver to reduce the risk of the Adaptive cruise control* (p.
Page 334 DRIVER SUPPORT applying a slight torque to the steering WARNING wheel. The function is supplementary driver • Warning activated: If the car is about to • support intended to facilitate driving cross a lane line, the driver is warned by and make it safer –...
Page 335 DRIVER SUPPORT Activating or deactivating lane Lane assistance does not intervene Lane Keeping Aid Apply steering • assistance If the driver follows the prompt to start steer- ing, the function is set in standby mode and The Lane Keeping Aid (LKA) function (LKA this message is shown: is optional –...
Page 336 DRIVER SUPPORT Selecting assistance option for Limitations of Lane assistance NOTE lane assistance In certain demanding conditions lane assis- This function uses the car's camera and The driver can select how the Lane Keeping tance (LKA ) may have difficulty helping the radar units, which have certain general lim- driver correctly.
Page 337 DRIVER SUPPORT Symbols and messages for lane on the driver display. Here are some exam- assistance ples. A number of symbols and messages regar- ding lane assistance (LKA ) can be shown Symbol Message Specification Driver support system The system does not function as it should. A workshop should be contacted Reduced functionality Service required Windscreen sensor The ability of the camera to scan the roadway in front of the car is reduced.
Page 338 Lane Keeping Aid LKA is set in standby mode until the driver starts to steer the car again. Standby until steering applied An authorised Volvo workshop is recommended. A text message can be cleared by briefly pressing the button, located in the centre of the steering wheel's right-hand keypad.
Page 339 DRIVER SUPPORT Display mode for lane assistance Related information Unavailable Lane assistance (p. 331) • Lane assistance (LKA ) is visualised by sym- bols in the driver display depending on the Limitations of Lane assistance (p. 334) • situation. Here are some examples of symbols and the situations in which they are shown: Unavailable —...
Page 340 DRIVER SUPPORT Steering assistance at risk of Related information WARNING collision Driving support systems (p. 270) • The function is supplementary driver • The function Collision avoidance assistance Activating or deactivating steering assis- • support intended to facilitate driving can help the driver reduce the risk of the car tance in the event of a collision risk and make it safer –...
Page 341 DRIVER SUPPORT Activating or deactivating steering Steering assistance upon risk of NOTE assistance in the event of a run-off Collision avoidance When the collision risk Steering assistance has a number of subfunc- assistance function is deactivated, all sub- The steering assistance function is optional – tions.
Page 342 DRIVER SUPPORT Steering assistance upon risk of driving the car, activation of the function will Steering assistance with brake intervention head-on collision be delayed. Steering assistance has a number of subfunc- Related information tions. Steering assistance upon risk of head- Steering assistance at risk of collision •...
Page 343 DRIVER SUPPORT Steering assistance upon risk of The function is active within the speed range the driver to steer the car back into its own rear-end collision* 60-140 km/h (37-87 mph) on roads with lane. clearly visible lane markings/lines. Steering assistance has a number of subfunc- The function can even assist if the driver inten- tions.
Page 344 DRIVER SUPPORT Limitations for steering assistance NOTE at risk of collision This function uses the car's camera and In certain situations the function may have radar units, which have certain general lim- limited functionality and fail to intervene in itations. the following cases, for example: for small vehicles, such as motorcycles •...
Page 345 A text message can be cleared by briefly pressing the button, located in the centre of the steering wheel's right-hand keypad. If a message remains: Contact a workshop – an authorised Volvo workshop is recom- mended. Related information Steering assistance at risk of collision •...
Page 346 DRIVER SUPPORT Limitations of Rear Collision Rear Collision Warning* WARNING Warning* The Rear Collision Warning (RCW) function The function is supplementary driver • In certain cases the Rear Collision Warning can help the driver to avoid being hit by a support intended to facilitate driving (RCW) may have difficulty helping the driver vehicle approaching from behind.
Page 347 DRIVER SUPPORT BLIS* NOTE The BLIS function is intended to help the The warning with direction indicators for driver detect vehicles diagonally behind and Rear Collision Warning* is deactivated if to the side of the car so as to provide assis- the warning distance for collision warning tance in heavy traffic on roads with several in the City Safety function is set at the low-...
Page 348 DRIVER SUPPORT Activating or deactivating BLIS BLIS is active when the driver's vehicle is trav- WARNING elling at a speed above 10 km/h (6 mph). The BLIS function can be activated or deac- The function is supplementary driver • tivated. If passing vehicles drive more than 15 km/h support intended to facilitate driving Activate or deactivate the...
Page 349 DRIVER SUPPORT Limitations of BLIS WARNING The BLIS function may have limitations in BLIS does not work on sharp bends. • certain situations. BLIS does not work when the car is • reversing. NOTE This function uses the car's radar units, which have certain general limitations.
Page 350 Blind spot system off BLIS and CTA have been deactivated as a trailer has been connected to the car's electrical system. Trailer attached An authorised Volvo workshop is recommended. Cross Traffic Alert* A text message can be cleared by briefly pressing the button, located in the centre of the steering wheel's right-hand keypad.
Page 351 DRIVER SUPPORT Driver Alert Control WARNING The Driver Alert Control (DAC) function is Driver Alert Control should not be used to intended to help make the driver aware that extend a period of driving. The driver he or she is starting to drive less consistently, should instead plan for breaks at regular e.g.
Page 352 DRIVER SUPPORT Activating or deactivating Driver Select rest stop guidance in the WARNING Alert Control event of a warning from Driver The function is supplementary driver • Alert Control The Driver Alert Control (DAC) function can support intended to facilitate driving be activated or deactivated.
Page 353 DRIVER SUPPORT Limitations of Driver Alert Control Cross Traffic Alert* If CTA senses that something is approaching from the side, this is also indicated with: The Driver Alert Control (DAC) function may Cross Traffic Alert (CTA) is a driver support have limitations in certain situations.
Page 354 DRIVER SUPPORT Activating or deactivating Cross explanatory text message on why the car was Limitations of Cross Traffic Alert* (p. 353) • braked. Traffic Alert* Messages for Cross Traffic Alert* (p. 354) • The driver can choose to switch off the Cross BLIS* (p.
Page 355 DRIVER SUPPORT Limitations of Cross Traffic However, as your car slowly reverses, the angle it makes with the obstructing vehicle/ Alert* object changes and the blind sector rapidly The Cross Traffic Alert (CTA) function with decreases. auto-brake may have limited functionality in certain situations.
Page 356 Blind spot system off BLIS and CTA have been deactivated as a trailer has been connected to the car's electrical system. Trailer attached An authorised Volvo workshop is recommended. Blind Spot Information System A text message can be cleared by briefly pressing the button, located in the centre of the steering wheel's right-hand keypad.
Page 357 DRIVER SUPPORT Park Assist* The side sectors change colour as the distance NOTE between the car and an object is reduced. The Parking Assistance System (PAS ) uses Except in the sector nearest to the car sensors to assist the driver when manoeu- The shorter the distance to the obstacle, the symbol, audible warnings are only given for vring in tight spaces by indicating the dis-...
Page 358 DRIVER SUPPORT Park Assist Pilot front, rear and Related information NOTE along the sides* Driving support systems (p. 270) • Parking assistance is deactivated when the Park Assist Pilot front, rear and along the Parking Assistance System (PAS ) has dif- •...
Page 359 When reversing with e.g. a trailer or bike view. The warning signal pulses intensively at less than carrier on the towbar - without Volvo genu- approx. 25 cm (0.8 ft) from an obstacle. ine trailer wiring - parking assistance may...
Page 360 DRIVER SUPPORT Limitations of Parking assistance WARNING IMPORTANT The Parking Assistance System (PAS ) can- Pay additional attention Objects e.g. chains, thin glossy poles or not detect everything in all situations and while reversing when this low barriers may be in the "signal shadow" may therefore have limited functionality in symbol is shown if a and are then temporarily not detected by...
Page 361 DRIVER SUPPORT IMPORTANT In certain conditions the parking assistance system may produce incorrect warning signals that are caused by external sound sources with the same ultrasonic frequen- cies that the system works with. Examples of such sources include horns, wet tyres on asphalt, pneumatic brakes, exhaust noises from motorcycles, etc.
Page 362 Park Assist System The system does not function as it should. A workshop should be contacted Unavailable Service required An authorised Volvo workshop is recommended. A text message can be cleared by briefly pressing the button, located in the centre of the steering wheel's right-hand keypad.
Page 363 DRIVER SUPPORT Park assist camera* Lines - activates/deactivates park assist lines Park assist camera (PAC ) can assist the driver when manoeuvring in tight spaces by Towbar* - activates/deactivates the tow- indicating obstacles with a camera image and bar park assist line* graphics in the centre display.
Page 364 DRIVER SUPPORT Park assist camera locations and Activate park assist camera (p. 368) • WARNING surveillance areas* Symbols and messages for Park assist • The function is supplementary driver • camera (p. 369) The Park assist cameras (PAC ) can display support intended to facilitate driving a composite 360°...
Page 365 DRIVER SUPPORT A camera symbol on the cen- Objects shown in the centre display may 360° view* tre display's car symbol indi- appear slightly tilted — this is normal. cates which of the cameras is Forwards active. If the car is also equipped with Park Assist System then distance to detected obstacles is illus-...
Page 366 DRIVER SUPPORT Park assist lines for park assist lel parking, reversing into tight spaces and The sides camera* when connecting a trailer. The Park assist cameras (PAC ) indicate the The lines on the screen are projected as if they position of the car in relation to its surround- were at ground level behind the car and ings by displaying lines on the screen.
Page 367 DRIVER SUPPORT Park assist lines in 360° view* Towbar assist line* IMPORTANT Remember, that with the rear camera • view selected, the monitor only dis- plays the area behind the car. Be aware of the sides and front of the car when manoeuvring in reverse.
Page 368 DRIVER SUPPORT Sensor fields for parking Press Towbar (1). Sensor fields backwards and forwards assistance system > The park assist lines for the towbar's intended "path" appear - the car's park If the car is equipped with the Parking Assis- assist lines disappear simultaneously.
Page 369 DRIVER SUPPORT obstacle decreases – from AMBER through The colour of the side fields changes with ORANGE to RED. reduced distance to the obstacle – from AMBER to RED. Field colour Distance in metres reverse (feet) Colour of side Distance in metres fields (feet) Yellow...
Page 370 DRIVER SUPPORT Activate park assist camera Automatic deactivation of camera The front view extinguishes at 25 km/h The park assist camera (PAC ) is activated (16 mph) to avoid distracting the driver – it automatically when reverse gear is engaged reactivates automatically if the speed drops to or manually with one of the centre display's 22 km/h (14 mph) within 1 minute, on the con-...
Page 371 One or more of the function's sensors are blocked - check and correct as soon as possible. Sensors blocked, cleaning nee- Park Assist System The system does not function as it should. A workshop should be contacted Unavailable Service required An authorised Volvo workshop is recommended. Park Assist Camera...
Page 372 DRIVER SUPPORT A text message can be cleared by briefly pressing the button, located in the centre of the steering wheel's right-hand keypad. If a message persists, contact a workshop Related information Park assist camera* (p. 361) • Limitations for camera and radar unit •...
Page 373 DRIVER SUPPORT Park Assist Pilot* Leaving parallel parking with Park Assist • WARNING Pilot* (p. 376) Park Assist Pilot (PAP ) can assist the driver The function is supplementary driver • to manoeuvre the car while parking. The Limitations of Park Assist Pilot* (p. 376) •...
Page 374 DRIVER SUPPORT Parking variants with Park Assist Related information Perpendicular parking Pilot* Park Assist Pilot* (p. 371) • Park Assist Pilot (PAP ) can be used for Leaving parallel parking with Park Assist • both parallel and perpendicular parking. Pilot* (p. 376) Parallel parking Principle for perpendicular parking.
Page 375 DRIVER SUPPORT Using Park Assist Pilot* NOTE Park Assist Pilot (PAP ) helps the driver The distance between the car and parking park via three steps. The function can also spaces should be 0.5–1.5 metres help the driver to leave a parking space. (1.6–5.0 ft) while the function is searching This function measures space and steers the for a parking space.
Page 376 DRIVER SUPPORT Tap on the Park In button in the function 2. Reverse slowly and carefully without Reversing in to the parking space view or in the camera view. touching the steering wheel - and no faster than 7 km/h (4 mph). >...
Page 377 DRIVER SUPPORT Move the gear selector to the gear posi- or behind the car during a parking manoeuvre, Positioning the car in the parking space tion as instructed by the system, wait until the car is auto-braked to stationary. the steering wheel has been turned and The driver display then shows a pop-up mes- drive forward slowly.
Page 378 DRIVER SUPPORT Leaving parallel parking with Park Limitations of Park Assist Pilot* 3. Be prepared to stop the car when instruc- Assist Pilot* ted by the graphic and message on the The Park Assist Pilot (PAP ) function cannot centre display - follow the instructions in Park Out function can help the driver to detect everything in all situations and may...
Page 379 DRIVER SUPPORT Parking is discontinued There are also a few details to bear in mind IMPORTANT while parking, e.g.: A parking sequence will be discontinued: Under certain circumstances, the function The driver is always responsible for deter- if the driver moves the steering wheel •...
Page 380 DRIVER SUPPORT parked car is protruding more than other parked cars. The function is designed for parking on • straight streets – not sharp curves or bends. For this reason, make sure the car is parallel to the potential parking spaces when the function measures the space.
Page 381 Park Assist System The system does not function as it should. A workshop should be contacted Unavailable Service required An authorised Volvo workshop is recommended. A text message can be cleared by briefly pressing the button, located in the centre of the steering wheel's right-hand keypad.
Page 382 DRIVER SUPPORT Radar unit Related information Driving support systems (p. 270) • The radar unit is used by several driver sup- port systems and has the task of sensing Limitations for camera and radar unit • other vehicles. (p. 389) Recommended maintenance for camera •...
Page 383 DRIVER SUPPORT Type approval for radar device Here you can find type approval for the car's radar units for adaptive cruise control* (ACC ), Pilot Assist* and BLIS* Market BLIS Symbol Type approval & PA ✓ Botswana Este equipamento opera em caráter secundário, isto é, não tem direito à proteção contra interferência prejudicial, mesmo de estações do mesmo tipo, e não pode causar interferência a sistemas operando em caráter primário.
Page 384 DRIVER SUPPORT Market BLIS Symbol Type approval & PA Hereby, Delphi Electronics and Safety declares that L2C0054TR / L2C0055TR are in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU (RED). The original declaration of conformity can be accessed at the following link www.delphi.com/automotive-homologation.
Page 385 DRIVER SUPPORT Market BLIS Symbol Type approval & PA 37295/POSTEL/2014 ✓ 4927 Certificate number: 50459/SDPPI/2017 Indonesia Country of origin Germany ✓ Certificate number: 53578/SDPPI/2017 Country of origin China PLG ID: 6051 ✓ Jamaica This product contains a Type Approved Module by Jamaica: SMA – “RS4”. Type Approval No.: TRC/LPD/2014/255 ✓...
Page 386 DRIVER SUPPORT Market BLIS Symbol Type approval & PA ✓ IFETEL: RLVDEL215-0299 Radar de corto alcance Hella KGaA Hueck & Co Mexico ✓ IFETEL: RLVHERS17-0286 La operación de este equipo esta sujeta a las siguientes dos condiciones: (1) es posible que este equipo o dispositivo no cause interferencia perjudicial y (2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su operación no deseada.
Page 387 DRIVER SUPPORT Market BLIS Symbol Type approval & PA ✓ Russia ✓ И011 14 Serbia ✓ И011 17 ✓ DA 105753 Singapore ✓ DA 103238 ✓ TA-2014/1824 South Africa ✓ TA-2016/3407...
Page 388 DRIVER SUPPORT Market BLIS Symbol Type approval & PA Certification No. ✓ MSIP-CMI- DPH-L2C0054TR South Korea R-CMM-HLA-RS4 ✓ 이 기기는 무용(A급) 전자파 적합기기로서 판 매자 또는 사용 자는 이 점을 주의하시기 바 라 며, 가정외의 지역에서 사용 하는 것을 적으 로 합니다 ✓...
Page 389 DRIVER SUPPORT Market BLIS Symbol Type approval & PA є, є Delphi RACAM/SRR2 ь КМ № 679 2009 .) ✓ ь Delphi : Delphi. : 24,05 – 24,25 ь : 20 .) EIRP Ukraine є, HELLA GmbH & Co. KGaA є...
Page 390 DRIVER SUPPORT Type approval for radio equipment Market Symbol Type approval Hereby, Volvo cars, declares that all radio equipment's are in compliance with the essential requirements and other Europe relevant provisions of Directive 2014/53/EU. R 204-750001 Japan This device is granted pursuant to the Japanese Radio Law and the Japanese Telecommunications Business Law. This device should not be modified (otherwise the granted designation number will become invalid).
Page 391 DRIVER SUPPORT Camera unit Limitations for camera and radar Related information unit Driving support systems (p. 270) • The camera unit is used by several driver sup- port systems and has the task of for example The camera and radar unit has certain limita- Limitations for camera and radar unit •...
Page 392 – the High temperature entire windscreen should be replaced At very high temperatures the camera and instead. radar unit can temporarily be switched off for An authorised Volvo workshop is recommended.
Page 393 DRIVER SUPPORT vehicle that drives in between your car and dust storms and snow flurries. Under such Limited field of vision the vehicle ahead. conditions, the functions of camera-depend- The radar unit has a limited field of vision. In ent systems could be significantly reduced or some situations another vehicle is not Small vehicles, such as motorcycles, or temporarily disengaged.
Page 394 Park assist camera* (p. 361) • There are "blind" sectors between the cameras' fields of vision. Volvo Cars support site (p. 21) • In the park assist camera's 360° view* obsta- cles/objects may "vanish" in the gaps between the individual cameras.
Page 395 Clean camera lenses regularly with luke- • warm water and car shampoo - be careful not to scratch the lenses. IMPORTANT Maintenance of driver support components must only be performed at a workshop – an authorised Volvo workshop is recom- mended. * Option/accessory.
Page 396 Dirt has appeared between the inside of the windscreen and the Visit a workshop to have the windscreen inside the unit's cover cleaned - an camera and radar unit. authorised Volvo workshop is recommended. Strong oncoming light No action. The camera unit is reset automatically in more favourable light con-...
Page 397 Limitations for camera and radar unit • (p. 389) The car's left-hand camera is out of order. Volvo Cars support site (p. 21) • A black camera sector is also shown in the fol- lowing instances, but then without the sym-...
Page 399 ELECTRIC OPERATION AND CHARGING...
Page 400 ELECTRIC OPERATION AND CHARGING General information about Twin The hybrid battery which drives the electric High-voltage current Engine motor is charged via a charging cable but can also be charged by gentle braking and engine Twin Engine runs like a regular car, but cer- braking in gear position B.
Page 401 If drive mode PURE is then selected, the com- NOTE bustion engine starts. Volvo recommends a charging cable in Charging with fixed control unit in accordance with IEC 62196 and IEC accordance with mode 3...
Page 402 ELECTRIC OPERATION AND CHARGING Charging current Charging with the petrol engine Related information Charging cable (p. 402) • Charging current is used for charging the hybrid battery as well as preconditioning of Charging current (p. 400) • the car. Charging takes place with a charging Opening and closing the hatch for the •...
Page 403 ELECTRIC OPERATION AND CHARGING Charging status in the car's charging input • Example 2 NOTE socket (p. 410) If the car is connected to a 230 V/10 A socket If the weather is very hot or very cold, • and the control unit is set at 10 A, then the car Start and switch off preconditioning •...
Page 404 - an author- The charging cable is located in the storage compart- (alternating current) and the charging cable ised Volvo workshop is recommended. ment under the cargo area's floor hatch. may only be used if the adapter is Always position the charging cable so •...
Page 405 ELECTRIC OPERATION AND CHARGING Ground fault breaker in the Related information IMPORTANT charging cable The charging cable's control unit (p. 405) • Clean the charging cable with a clean The control unit for the charging cable charg- Ground fault breaker in the charging cable •...
Page 406 Maintenance or replacement of the • hybrid battery must only be performed Control unit LED lamps. IMPORTANT by a trained and qualified Volvo service technician. LED lamp 1 Check the capacity of the socket. • Do not use a charging cable that has •...
Page 407 Charging cable (p. 402) • NOTE The charging cable's control unit (p. 405) • Volvo recommends a charging cable in accordance with IEC 62196 and IEC 61851 which supports temperature moni- toring. Monitoring in the control unit Charging is switched off if the temperature of the control unit is too high.
Page 408 ELECTRIC OPERATION AND CHARGING Opening and closing the hatch for LED lamp 1 shows different colours Control unit with only indicators the charging input socket depending on charging status. LED lamp 2 shows different colours The flap for the hybrid battery's charging depending on charging status.
Page 409 • be repaired by a workshop - an author- protects the car, but there may still be Volvo recommends a charging cable in ised Volvo workshop is recommended. a risk of overloading the 230 V mains accordance with IEC 62196 and IEC Always position the charging cable so •...
Page 410 ELECTRIC OPERATION AND CHARGING Never connect the charging cable to an Take the charging cable out from the storage • extension cord or a multiple plug compartment under the cargo area floor. socket. Do not use one or more adapters •...
Page 411 ELECTRIC OPERATION AND CHARGING 3. The charging cable's charging handle is Related information fastened/locked in, and charging starts Charging the hybrid battery (p. 399) • within 5 seconds. When charging has The charging cable's control unit (p. 405) • started, the LED lamp in the charging Opening and closing the hatch for the •...
Page 412 ELECTRIC OPERATION AND CHARGING Charging status in the car's LED lamp's Specification charging input socket glow The charging input socket shows the charg- White LED light. ing status using an LED lamp. Yellow Waiting mode - waiting for charging to start. Flashing green Charging in progress Green...
Page 413 ELECTRIC OPERATION AND CHARGING Charging status in the charging LED lamp 1 Control unit with only indicators cable's control unit LED lamp 2 Different indicators on the charging cable's control unit show the status of ongoing charging as well as status after completed charging.
Page 414 ELECTRIC OPERATION AND CHARGING LED 1 LED 2 Status Specification Recommended action Flashes blue, Flashes blue, Initiation Self-test. Wait until the self-test is completed. amber and amber and red Illuminates in Extinguished Standby The charging cable is not connected to Connect the charging cable to the car's charging blue the car.
Page 415 ELECTRIC OPERATION AND CHARGING LED 1 LED 2 Status Specification Recommended action Flashes red Illuminates in Charging is not Charging cable connected to ungroun- Plug the charging cable into a grounded 230 V possible. ded 230 V socket. socket. If the problem persists - consult a qualified professional.
Page 416 ELECTRIC OPERATION AND CHARGING Control unit with both indicators and controls Control unit indicators and controls.
Page 417 ELECTRIC OPERATION AND CHARGING Control unit indicators Status Specification Recommended action The indicator for charging current (1) is Standby The charging cable is connected to the Wait until the battery is fully charged. • extinguished. The car symbol (4) illumi- car.
Page 418 ELECTRIC OPERATION AND CHARGING Charging status in the car's driver is shown for as long as the driver display is display operating. The driver display shows the status for charg- ing with both image and text. The information Image Message Specification Fully charged at: [Time] is shown together with an animation with...
Page 419 ELECTRIC OPERATION AND CHARGING NOTE If the driver display is not used for a while then it is dimmed. Reactivate the display by means of one of the following: depress the brake pedal. • open one of the doors. • set the car in ignition position I by •...
Page 420 ELECTRIC OPERATION AND CHARGING Stop charging of hybrid battery Finish charging by unlocking the car, unplug- ging the charging cable from the car's charg- ing input socket and then from the 230 V socket (alternating current). IMPORTANT Before the charging cable is disconnected from the car's charging input socket, the car must be unlocked using the unlock but- Unlock the car with the remote control key...
Page 421 ELECTRIC OPERATION AND CHARGING Charging the hybrid battery (p. 399) • Start charging the hybrid battery (p. 407) •...
Page 422 ELECTRIC OPERATION AND CHARGING Symbols and messages relating to display. They may also be shown in combina- Twin Engine in the driver display tion with general indicator and warning sym- bols and are then extinguished when the A number of symbols and messages regar- problems have been rectified.
Page 423 Shown when the driver tries to start the car and the charging cable is connected to the car. Disconnect the charging cable and close the charging hatch. Remove before start An authorised Volvo workshop is recommended. Related information Start charging the hybrid battery (p. 407) •...
Page 424 ELECTRIC OPERATION AND CHARGING Long-term storage of vehicles with 2. If storage has lasted longer than 6 months hybrid batteries or the hybrid battery charge level is signifi- cantly lower than 25% – charge the bat- To minimise hybrid battery degradation dur- tery to approx.
Page 425 STARTING AND DRIVING...
Page 426 STARTING AND DRIVING Starting the car To start the car: electric motor has "started" and the car is ready to move. A started car is indicated by The car is started using the start button the driver display's indicator lamps extinguish- IMPORTANT beside the steering wheel when the remote ing and its preset theme illuminating.
Page 427 STARTING AND DRIVING Switching off the car NOTE WARNING The car is switched off using the start button Always take the remote control key out When the remote control key is positioned beside the steering wheel. from the car when leaving the car and by the backup reader, make sure that there make sure the car's electrical system is in are no car keys, metal objects or electronic...
Page 428 STARTING AND DRIVING Ignition positions Using jump starting with another battery • Level Functions (p. 462) The car's electrical system can be set in dif- Odometer, clock and tempera- • ferent levels/positions and in this way make Selecting ignition mode (p. 427) •...
Page 429 STARTING AND DRIVING Selecting ignition mode Ignition position I – Depress the start • Level Functions button and release. The car's electrical system can be set in dif- The headlamps come on. • ferent levels/positions and in this way make Ignition position II –...
Page 430 The car has an interface for the electrical con- nection of the different makes and models of Before starting the engine with the alcohol • alcohol lock recommended by Volvo. The lock* (p. 429) interface facilitates alcohol lock connection, Starting the car (p. 424) •...
Page 431 STARTING AND DRIVING Before starting the engine with the Brake functions Foot brake alcohol lock* The car's brakes are used to reduce the The foot brake is part of the brake system. speed or prevent the car from rolling. The car is equipped with two brake circuits. If The alcohol lock is activated automatically In addition to the foot brake and parking a brake circuit is damaged, the brake pedal...
Page 432 - an authorised Battery charging with electric motor braking is Volvo workshop is recommended. indicated in the driver display. If the brake fluid is below the MIN level •...
Page 433 STARTING AND DRIVING Brake assistance Braking on wet roads Braking on gritted roads When driving for a prolonged period of time When driving on salted roads, a layer of salt The brake assist system (BAS ) helps to in heavy rain without braking, the braking may form on the brake discs and brake lin- increase brake force during braking, and can effect may be delayed slightly when next...
Page 434 To keep the car as safe and reliable as possi- mechanically locking/blocking two wheels. Parking on a hill (p. 434) • ble, follow the Volvo service intervals as speci- In the event of a fault in the parking brake • fied in the Service and Warranty Booklet. After (p.
Page 435 STARTING AND DRIVING Activating and deactivating the Symbol in the driver display NOTE parking brake Symbol Specification An acoustic signal sounds while emer- Use the parking brake to prevent the car from gency braking is active at high speeds. The symbol is illuminated when rolling from stationary.
Page 436 STARTING AND DRIVING Automatic parking brake activation Parking on a hill Deactivate automatically setting Start the car. Always use the parking brake when parking on a hill. Choose whether the parking brake is to be 2. Depress the brake pedal firmly. Select activated automatically when the car is gear position D or R and depress the WARNING...
Page 437 Automatic brake when stationary (Auto hold) Symbol Specification means that the driver can release the brake Contact an authorised Volvo workshop if it is If the symbol flashes, it indicates pedal while maintaining braking effect when not possible to deactivate or activate the a fault has occurred.
Page 438 STARTING AND DRIVING Activating and deactivating the Symbols in the driver display The function remains deactivated until it is • automatic brake at a standstill reactivated. Symbol Specification The automatic brake function at a standstill is When the function is deactivated, hill start •...
Page 439: Auto Braking After A Collision
STARTING AND DRIVING Help when starting on a hill Auto braking after a collision Regenerative braking* In the event of a collision in which the activa- The car recovers kinetic energy during brak- Hill start assist (HSA ) prevents the car from tion level is reached for the pyrotechnic seat- ing in order to reduce fuel consumption and rolling backwards when starting on an uphill...
Page 440: Gearbox
STARTING AND DRIVING Gearbox Automatic gearbox Symbols and messages for automatic • gearbox (p. 442) The gearbox is part of the car's powertrain Gears are selected automatically so that you (power transmission) between engine and can drive as energy-efficiently as possible. drive wheels.
Page 441: Changing Gear With Automatic Gearbox
STARTING AND DRIVING Changing gear with automatic Gear positions WARNING gearbox Parking – P Always use the parking brake when park- Change gear position by pressing the spring- ing on an inclined surface. Engaging a gear loaded gear selector forwards or backwards, or the automatic transmission's P position or sideways for manual shifting.
Page 442: Changing Gear With Steering Wheel Paddles
STARTING AND DRIVING Changing gear with steering wheel motor when the accelerator pedal is released, Neutral – N paddles* while also charging the hybrid battery. Select N position when the car shall be started. Apply the parking brake if the car is The steering wheel paddles are a comple- Position B is selected by moving the gear stationary with the gear selector in the N posi-...
Page 443 STARTING AND DRIVING Related information In B position the steering wheel paddles are automatically activated. Automatic gearbox (p. 438) • Changing gear with automatic gearbox • (p. 439) Gear shift indicator (p. 443) • Driver display when changing gear with steering wheel paddles.
Page 444: Gear Selector Inhibitor
STARTING AND DRIVING Gear selector inhibitor Kick-down function Symbols and messages for automatic gearbox The gear selector inhibitor prevents acciden- Kick-down can be used when maximum tal changing between different gear positions acceleration is needed such as for overtaking. If a fault should occur in the gearbox, a sym- in an automatic gearbox.
Page 445: Gear Shift Indicator
STARTING AND DRIVING Gear shift indicator Related information NOTE Automatic gearbox (p. 438) • The gear shift indicator in the driver display On automatic cars, the gear shift indicator shows the current gear during manual gear- is only available on certain markets. shifting and when it is appropriate to engage the next gear for optimum fuel economy.
Page 446: Drive Systems
STARTING AND DRIVING Drive systems Related information General information about Twin Engine • Volvo Twin Engine combines an internal com- (p. 398) bustion engine with an electric motor. Starting and stopping the combustion • Two drive systems engine in Twin Engine (p. 445) Depending on the driver-selected drive mode Drive modes (p.
Page 447: Starting And Stopping The Combustion Engine In Twin Engine
STARTING AND DRIVING Starting and stopping the Drive modes Emission control combustion engine in Twin Engine To ensure that emission control operates as Selection of drive mode affects the car's driv- energy-efficiently as possible, the internal ing characteristics in order to enhance the An advanced control system determines the combustion engine must be run for several driving experience and facilitate driving in...
Page 448 STARTING AND DRIVING At low energy level (hybrid battery almost WARNING empty) the battery's energy level must be Do not leave the car in an unventilated area maintained, leading to the internal combustion with activated drive mode and the fuel- engine starting more often.
Page 449 STARTING AND DRIVING partment in order to reduce energy consump- as possible. Power drive mode is always avail- Pure tion. able regardless of the battery's state of Drive the car with electric motor, with • charge. energy consumption as low as possible and with lowest possible carbon dioxide NOTE Power...
Page 450 STARTING AND DRIVING 3. In Presets , select a drive mode to start Individual Pure Hybrid Power Polestar Adapting a drive mode according to indi- from: • vidual preferences. Engineered Select a drive mode to start from, and then Possible adjustments apply to settings for: adjust the settings according to the desired Driver Display •...
Page 451: Changing Drive Mode
STARTING AND DRIVING Changing drive mode the internal combustion engine to a greater 2. Select the drive mode in one of two ways: extent. Select the drive mode adapted for the current Tap the desired drive mode directly on • driving conditions.
Page 452 STARTING AND DRIVING Energy distribution in hybrid drive The greatest fuel saving is achieved when Add similar commuting routes, i.e. the route using map data* between two charging points, as Favourites the distance to be travelled begins with • in the navigation system to facilitate arrival. Hybrid drive mode is the car's normal driving on a motorway...
Page 453: Economical Driving
STARTING AND DRIVING Economical driving parking. Park the car in an acclimated pedal and can be reinforced with electric garage, for example. motor braking in gear position B. Drive economically and in a more eco-friendly way by driving gently and anticipating situa- During a short drive after preconditioning High speed results in increased energy •...
Page 454: Energy Distribution In Hybrid Drive Using Map Data
STARTING AND DRIVING Factors that affect range when Avoid driving with open windows. in a car with deactivated passenger compart- • running on electricity ment climate control, as well as in a car with Do not hold the car stationary on a hill •...
Page 455: Hold And Charge Function
STARTING AND DRIVING Hold and Charge function Factors the driver can influence NOTE The driver should be aware that the following In some situations, it can be useful to be able The values shown in the tables relate • factors affect the range so he/she can operate to control the hybrid battery's state of charge to a new car.
Page 456: Preparations For A Long Trip
STARTING AND DRIVING Preparations for a long trip Charge Engine charges hybrid Before a driving holiday or some other type of battery long journey, it is important to check the car's functions and equipment particularly care- The function charges the fully.
Page 457: Winter Driving
Winter driving Recommendations for loading (p. 572) Slippery driving conditions • To achieve optimum roadholding Volvo recom- For winter driving it is important to perform Driving with a trailer (p. 468) • mends using winter tyres on all wheels if there certain checks of the car in order to ensure Pilot Assist* (p.
Page 458: Driving In Water
Instead, tow the car out of the should be exercised when passing water and transported on a low loader to a through flowing water. workshop. An authorised Volvo workshop Do not drive faster than walking pace. • is recommended.
Page 459: Filling Fuel
STARTING AND DRIVING Filling fuel NOTE The fuel tank is fitted with a coverless fuel After the fuel filler flap has been opened, filler system. refuelling must take place within about 15 minutes. After this, the valve that was Refuelling the car at a petrol station opened by pressing the button to open the fuel filler cap is closed, and it is no longer possible to refuel because the pump nozzle...
Page 460 STARTING AND DRIVING Fuelling instruction: 4. Do not overfill the tank but fill until the pump nozzle cuts out the first time. Switch off the car and open the fuel filler > The tank is full. flap. NOTE NOTE Overfilled fuel in the tank can overflow in After the fuel filler flap has been opened, hot weather.
Page 461: Handling Of Fuel
Do not use fuel with a lower quality than that It is important to use the correct fuel during Mixtures of various fuel types or use of recommended by Volvo, as this will nega- refuelling. Petrol is available with different fuels which are not recommended will...
Page 462: Petrol Particle Filter
Do not use any additives which have • ling. being oxidised and burned away. The filter is not been recommended by Volvo. Related information emptied in this way. Petrol (p. 459) •...
Page 463: Overheating In The Engine And
STARTING AND DRIVING Overheating in the engine and Stop safely, wait for cooling . Follow the Related information drive system recommendation given, reduce speed or Topping up coolant (p. 594) • stop the car in a safe way and allow the Under certain conditions, e.g.
Page 464: Overloading The Starter Battery
STARTING AND DRIVING Overloading the starter battery Using jump starting with another mends that an authorised Volvo workshop is battery contacted. The electrical functions in the car load the starter battery to varying degrees. Avoid If the starter battery is discharged then the...
Page 465 STARTING AND DRIVING Set the car's electrical system in ignition 9. Check that the jump lead clamps are 12. Wait at least 2 minutes in order to charge position 0. affixed securely so that there are no sparks the starter battery and then make a start during the starting attempt.
Page 466: Towbar
There may be different towbar variants availa- Towbar-mounted bicycle rack* (p. 472) • NOTE ble for the car. Contact a Volvo dealer for more Specifications for towbar* (p. 465) • information. The car cannot be started if the hybrid bat- tery is discharged.
Page 467: Specifications For Towbar
STARTING AND DRIVING Specifications for towbar* Extendable and retractable Dimensions, mounting points in mm towbar* Dimensions and mounting points for towbar. (inches) The retractable tow hook is easy to retract or 939 (37) extend as required. In the retracted position, the towbar is completely concealed.
Page 468 STARTING AND DRIVING 2. Press and release the button – extension might not start if the button is pressed for too long. Open the tailgate. A button for extending/ Move the towbar to its end position, retracting the towbar is located on the where it is secured and locked in place - >...
Page 469: Removable Towbar
STARTING AND DRIVING Removable towbar* NOTE Volvo recommends use of Volvo's towbars, Power save mode activates after a while which are specifically designed for the car. and the indicator lamp goes out. The sys- NOTE tem is reactivated by closing and opening the tailgate.
Page 470: Driving With A Trailer
STARTING AND DRIVING Driving with a trailer Install the ball holder Store the ball holder If necessary, remove the split pin from the When driving with a trailer, there are a num- locking bolt and slide the lock bolt out of WARNING ber of points that are important to think about the towbar unit.
Page 471 2. Select gear position D. 13 pin connector and the trailer has a 7 pin load (up to the maximum permissible weight). connector. Use an adapter approved by Volvo. 3. Releasing the parking brake. When the car is stationary the rear of the car Make sure the cable does not drag on the lowers slightly, which is normal.
Page 472: Trailer Stability Assist
STARTING AND DRIVING Trailer stability assist* Related information eral movements. If snaking is detected, the front wheels are individually braked. This Trailer stability assist* (p. 470) • The function of trailer stability assist (TSA ) is serves to stabilise the car/trailer combination. to stabilise cars towing trailers in situations Checking trailer lamps (p.
Page 473: Checking Trailer Lamps
STARTING AND DRIVING Checking trailer lamps When Trailer Stability Assist therefore that the trailer is equipped with a (TSA) is operating, the ESC rear fog lamp to travel safely. When connecting a trailer - check that all the symbol flashes in the driver trailer lamps work before departure.
Page 474: Towbar-Mounted Bicycle Rack
• 2. Press My Car Lights and Lighting. safety during a journey. Volvo's bicycle racks reduced ground clearance • are available for purchase at authorised Volvo 3. Deselect Automatic Trailer Lamp dealers.
Page 475: Towing
STARTING AND DRIVING Towing sumption. It may also lead to an increased Selecting ignition mode (p. 427) • load on the towbar. During towing, the car is towed by another Gearbox (p. 438) • vehicle by means of a towline. Related information Towing a Twin Engine is not permitted as this Towbar* (p.
Page 476: Fitting And Removing The Towing Eye
STARTING AND DRIVING Fitting and removing the towing 3. Screw in the towing eye until it reaches its end stop. Use the towing eye if the car shall tow another vehicle. The towing eye is screwed into a threaded socket behind a cover on the right-hand side of the rear bumper.
Page 477: Recovery
STARTING AND DRIVING ® Recovery Related information HomeLink Towing (p. 473) • For recovery, the car is taken away with the ®12 HomeLink is a programmable remote con- help of another vehicle. Recovery (p. 475) trol, integrated in the car's electrical system, •...
Page 478: Programming Homelink
STARTING AND DRIVING ® sists of three programmable buttons and one Programming HomeLink Aim the remote control towards the ® indicator lamp in the mirror glass. HomeLink button to be programmed and Follow these instructions to program hold it approx. 2-8 cm (approx. 1-3 inches) ®...
Page 479 STARTING AND DRIVING 3. Do not release the buttons until the indica- call 00 8000 466 354 65 (or the toll number tor lamp has switched from flashing +49 6838 907 277) slowly (approx. once per second) to either Reprogramming individual buttons flashing quickly (approx.
Page 480: Using Homelink
STARTING AND DRIVING ® Related information Using HomeLink WARNING ® • Using HomeLink * (p. 478) ® When HomeLink is fully programmed it can ® • If HomeLink is used to control a ® be used in place of the separate original •...
Page 481: Type Approval For Homelink
STARTING AND DRIVING ® Compass* Activating and deactivating the Type approval for HomeLink compass* The upper right-hand corner of the rearview Type approval for EU mirror has an integrated display that shows The upper right-hand corner of the rearview Gentex Corporation hereby declares that the compass direction in which the front of mirror has an integrated display that shows...
Page 482: Calibrating The Compass
STARTING AND DRIVING Calibrating the compass* 7. Cars with heated windscreen*: If the character is shown in the display when The earth is divided into 15 magnetic zones. the heated windscreen is activated, per- The compass should be calibrated if the car form the calibration in accordance with is moved between several magnetic zones.
Page 483 SOUND, MEDIA AND INTERNET...
Page 484 SOUND, MEDIA AND INTERNET Sound, media and Internet Audio settings Related information Media player (p. 492) • The audio and media system consists of The sound reproduction quality is preset, but media player and radio. You can also connect it can be adjusted as well. Radio (p.
Page 485 SOUND, MEDIA AND INTERNET Sound experience* Apps Control Park Assist Phone Ringtone Sound experience is an app that provides The app view contains apps that give access access to further audio settings. to some of the car's services. High Performance* Sound Experience is opened from the app Swipe from right to left...
Page 486 SOUND, MEDIA AND INTERNET Downloading apps Some basic apps are always available. More 3. Tap on the row for an app in order to apps such as web radio and music services expand in the list and get more informa- New apps can be downloaded when the car can be downloaded when the car is connected tion about the app.
Page 487 SOUND, MEDIA AND INTERNET Updating apps Deleting apps Update some Download Centre Open the app in the The apps can be updated when the car is Apps can be uninstalled when the car is con- app view. connected to the Internet. nected to the Internet.
Page 488 SOUND, MEDIA AND INTERNET Radio Start radio RDS radio (p. 491) • It is possible to listen to the FM bands and to The radio is started from the centre display Internet-connected car* (p. 519) • digital radio (DAB)*. When the car is online, it app view.
Page 489 SOUND, MEDIA AND INTERNET Changing radio band and radio Changing radio band and radio station 2. Select playback from Stations • station (p. 487) Favourites Genres Ensembles Save radio channels in the Radio Favour- There are instructions here for changing the •...
Page 490 SOUND, MEDIA AND INTERNET Searching for radio stations Manual tuning Changing radio band and radio station • (p. 487) The radio automatically compiles a station list of the radio stations within the area that are Voice control of radio and media (p. 137) •...
Page 491 SOUND, MEDIA AND INTERNET Save radio channels in the Radio Settings for radio from a manual station search, the radio does Favourites app not automatically change to a stronger fre- There are various radio functions to activate quency. and deactivate. It is possible to add a radio channel to the Radio favourites app and the favourites list...
Page 492 SOUND, MEDIA AND INTERNET Traffic Announcements : interrupts the the message. Playback of previous media FM Radio current media playback and broadcasts source is resumed when the message is Show Broadcast Information : shows • information about traffic disruptions. Play- finished.
Page 493 SOUND, MEDIA AND INTERNET RDS radio Digital radio* Related information Radio (p. 486) • RDS (Radio Data System) means that the Digital radio (DAB ) is a digital broadcasting radio automatically changes to the strongest system for radio. The radio supports DAB, Settings for radio (p.
Page 494 SOUND, MEDIA AND INTERNET Link between FM and digital radio* Media player DAB subchannel Secondary components are usually named The function enables the digital radio (DAB) The media player can play back audio from subchannels. These are temporary and can to switch from a channel with poor or no external audio sources connected via the contain e.g.
Page 495 SOUND, MEDIA AND INTERNET Media playback Related information USB memory Media playback (p. 493) Insert the USB memory. • The media player is controlled from the cen- tre display. Several functions can also be Controlling and changing media (p. 494) •...
Page 496 SOUND, MEDIA AND INTERNET Controlling and changing media Related information Bluetooth connected device Activate Bluetooth in the media source. Managing the app menu in the driver dis- • The playback of media can be controlled with play (p. 96) voice control, steering wheel keypad or the 2.
Page 497 SOUND, MEDIA AND INTERNET Searching media Change track/song - tap on the desired track Similar - tap on the button in order to use Gracenote to in the centre display, press on It is possible to search by artist, composer, search for similar music on under the centre display or on the steering song titles, album, video, audio book, playlist...
Page 498 SOUND, MEDIA AND INTERNET ® Media playback (p. 493) Gracenote Updating Gracenote • The content of the Gracenote database is Enter the characters, letters and words Gracenote identifies artist, album, song titles • updated continuously. Download the latest manually in the centre display (p. 120) and associated images, which are shown dur- update to take advantage of improvements.
Page 499 SOUND, MEDIA AND INTERNET ® Video Playing a video Playing back DivX Videos on USB-connected devices can be Videos are played using the app in the ® This DivX Certified device must be regis- played back using the media player. app view.
Page 500 SOUND, MEDIA AND INTERNET ® ® Settings for video Media via Bluetooth Connecting a device via Bluetooth Certain language settings can be changed for ® The car's media player is equipped with Connect a Bluetooth device to the car for video playback.
Page 501 SOUND, MEDIA AND INTERNET Media via USB port Connecting a device via USB port ® An external audio source, e.g. an iPod® or An external audio source, e.g. an iPod MP3 player, can be connected to the audio MP3 player, can be connected to the audio system via the car's USB port.
Page 502 SOUND, MEDIA AND INTERNET Technical specifications for USB Compatible media formats Voltage supply 5 V • devices The following file formats must be used for Current supply max. 3.0 A • media playback. The following specifications must be met to Related information allow the contents of the USB devices to be Audio files...
Page 503 ® • Playing back DivX (p. 497) broken. Please note that Volvo is not responsi- When you see the DivX logo, you have the ble for the content in CarPlay. freedom to play DivX films. When using map navigation via CarPlay no...
Page 504 Bluetooth will there- (including its position) is transferred to fore not be available when CarPlay is your iPhone. In relation to Volvo Cars, you active. An alternative Internet source must are fully responsible for your and any be used to connect to the Internet for the others person’s use of Apple CarPlay.
Page 505 SOUND, MEDIA AND INTERNET Switch the connection between Connect the car to the Internet via a Starting CarPlay • phone (Wi-Fi) (p. 520) To start CarPlay from an iOS device that has CarPlay and iPod been connected previously: Connect the car to the Internet via car •...
Page 506 SOUND, MEDIA AND INTERNET ® ® ® ® Settings for Apple CarPlay Tips for using Apple CarPlay 2. Tap on Sound System Volumes make the settings for the following: ® Settings for iOS device connected with Here are some useful tips for using CarPlay Update your iOS device with the latest CarPlay •...
Page 507 When you use auto/. For third-party apps, see Google Play. NOTE Android Auto, your car transfers certain Please note that Volvo is not responsible for information (including its location) to your Availability and functionality may vary the content in Android Auto.
Page 508 SOUND, MEDIA AND INTERNET Using Android Auto* Settings for Android Auto* Previously connected Android Connect your device to the USB input To use the Android Auto app, the app must Settings for an Android device that has been with a white frame. be installed on your Android device and the connected the first time with Android Auto.
Page 509 SOUND, MEDIA AND INTERNET Tips for using Android Auto* Related information Related information Android Auto* (p. 505) Android Auto* (p. 505) • • Here are some useful tips for using Android Auto. Using Android Auto* (p. 506) Connect the car to the Internet via a •...
Page 510 SOUND, MEDIA AND INTERNET Phone Overview Connecting a phone to the car via Blue- • tooth automatically (p. 510) A phone with Bluetooth can be connected wirelessly to the car's built-in hands-free sys- Connecting a phone to the car via Blue- •...
Page 511 SOUND, MEDIA AND INTERNET Connecting a phone to the car via 2. Open the phone tile in the centre display. Option 2 - search car from phone Bluetooth for the first time Open the phone tile in the centre display. If there is no phone connected to the •...
Page 512 SOUND, MEDIA AND INTERNET Connecting a phone to the car via Removing devices connected to Bluetooth • NOTE Bluetooth automatically (p. 512) The message function must be acti- • Settings for Bluetooth devices (p. 516) It is possible to connect a phone to the car •...
Page 513 SOUND, MEDIA AND INTERNET Connecting a phone to the car via Disconnecting a Bluetooth- Connect the car to the Internet via a Blue- • Bluetooth manually connected phone tooth-enabled phone (p. 520) Ignition positions (p. 426) It is possible to connect a phone to the car It is possible to disconnect a phone con- •...
Page 514 SOUND, MEDIA AND INTERNET Switch between Bluetooth- Removing devices connected to Managing phone calls connected phones Bluetooth Call handling in the car for a Bluetooth-con- nected phone. It is possible to switch between a number of It is possible to remove phones from the list Bluetooth-connected phones.
Page 515 SOUND, MEDIA AND INTERNET Private call Managing text messages Making multi-party calls During a call: Privacy During the current call, press – Message handling in the car for a Bluetooth- select setting: connected phone. Add call Press In some phones, the message function must Switch to mobile phone - the hands- •...
Page 516 – keypad. A dictation dialogue starts. Valid in certain markets only. Contact a Volvo dealer for more information. Only certain phones can send messages via the car. The connected phone must support the Bluetooth Message Access Profile (MAP). * Option/accessory.
Page 517 SOUND, MEDIA AND INTERNET Managing the phone book Settings for phone sorted under . It is possible to sort by first name or surname, and this setting is adjusted When a phone is connected to the car with When the telephone is connected to the car, in the telephone setup.
Page 518 SOUND, MEDIA AND INTERNET Settings for Bluetooth devices Wireless phone charger* Using the wireless telephone charger* Settings for Bluetooth-connected devices. There is a charging plate for wireless phone Press Settings in the top view. charging located under the centre display. The rubber plate under the centre display A condition for being able to charge makes it possible to charge phones without...
Page 519 SOUND, MEDIA AND INTERNET If the phone does not charge: Check that the charging plate is free from • other objects. Check that the phone supports wireless • charging (Qi). Remove the case from the phone if one is • fitted.
Page 520 SOUND, MEDIA AND INTERNET Certificate for wireless charger Country/Area Mexico: RCPVAPVO 18-1919 Paraguay: 2018-11-1-000541 Ukraine: : 107 - 115 М ь ь є ь ) ), 63 К є : N / A М : 13,56 М +/- 0,01% М ь...
Page 521 Remove Wi-Fi network (p. 524) • Wi-Fi technologies and security (p. 524) • NOTE Volvo ID (p. 26) • When using Android Auto, it is possible to User terms and conditions and data shar- • connect the car to the Internet using Wi-Fi, ing (p.
Page 522 SOUND, MEDIA AND INTERNET Connect the car to the Internet via Connect the car to the Internet via 6. If another connection source has been a Bluetooth-enabled phone a phone (Wi-Fi) used, confirm the option to change con- nection. Create an Internet connection via Bluetooth Create an Internet connection via Wi-Fi by >...
Page 523 To show a list of saved used, confirm the option to change con- card (P-SIM)*. networks or manually delete saved networks, nection. Cars equipped with Volvo On Call will use the go to Settings Communication Wi-Fi 6.
Page 524 SOUND, MEDIA AND INTERNET Settings for car modem* Sharing Internet access from the Change PIN - a maximum of 4 digits can car via a Wi-Fi hotspot be entered. The car is equipped with a modem that can be used to connect the car to the Internet. It Disable PIN - select whether the PIN When the car is online, its Internet connec-...
Page 525 SOUND, MEDIA AND INTERNET No or poor Internet connection The network operator (SIM card) must sup- NOTE port tethering (sharing of the Internet connec- Factors that affect the Internet connection. Activation of Wi-Fi-hotspot can result in tion). The amount of data transferred is dependent further charges from your network opera- on the services or apps in use in the car.
Page 526 SOUND, MEDIA AND INTERNET Remove Wi-Fi network Wi-Fi technologies and security Related information Internet-connected car* (p. 519) • Removing a network that is not to be used. Possible network types to connect to. Press Settings in the top view. It is only possible to connect to the following Wi-Fi technologies and security (p.
Page 527: User Terms And Conditions And Data Sharing
With the software update made available NOTE November 2017, privacy and data sharing set- After a visit to a Volvo workshop, you may tings were introduced for online services and need to reactivate data sharing so that the downloaded apps. The settings can be found online services and apps shall work again.
Page 528: Data Sharing For Services
Volvo's terms and con- To approve data sharing for an app that needs first need to approve Volvo's terms and ditions for online services.
Page 529: Storage Space On Hard Disk
SOUND, MEDIA AND INTERNET Storage space on hard disk It is possible to view how much free space there is on the car's hard disk. Storage information for the car's hard disk, including total capacity, available capacity and how much space is used for installed apps can be shown.
Page 530: License Agreement For Audio And Media
A license is an agreement for the right to operate a certain activity or the right to use someone else's entitlement according to the terms and conditions in the agreement. The following texts are Volvo's agreements with manufacturers/developers. ® Dirac Unison Parts of the content are copyright ©...
Page 531 SOUND, MEDIA AND INTERNET Gracenote servers, including all ownership and the company reserves the right to discon- Gracenote End User License Agreement ® rights. Gracenote will under no circumstances tinue its services at any time. This program or device contains software from have any obligation to pay you for any informa- Gracenote, Inc.
Page 532 SOUND, MEDIA AND INTERNET permitted provided that the following OTHERWISE) ARISING IN ANY WAY OUT WITHOUT WARRANTY OF ANY KIND, conditions are met: Redistributions of source OF THE USE OF THIS SOFTWARE, EVEN IF EXPRESS OR IMPLIED, INCLUDING BUT code must retain the above copyright notice, ADVISED OF THE POSSIBILITY OF SUCH NOT LIMITED TO THE WARRANTIES OF this list of conditions and the following...
Page 533 SOUND, MEDIA AND INTERNET You have the right of acquisition, modification, conditions and the following disclaimer as Copyright c 1991-2013 Unicode, Inc. All rights and distribution of the source code of the the first lines of this file unmodified. reserved. Distributed under the Terms of Use GPL/LGPL software.
Page 534 SOUND, MEDIA AND INTERNET COPYRIGHT HOLDER OR HOLDERS use or other dealings in these Data Files or Declaration of Conformity INCLUDED IN THIS NOTICE BE LIABLE FOR Software without prior written authorization of ANY CLAIM, OR ANY SPECIAL INDIRECT OR the copyright holder.
Page 535 SOUND, MEDIA AND INTERNET Country/ Area Brazil: Este equipamento opera em caráter secundário isto e, náo tem direito a protecão contra interferéncia prejudicial, mesmo tipo, e não pode causar interferéncia a sistemas operando em caráter primário. Para consultas, visite: www.anatel.gov.br Manufacturer: Mitsubishi Electric Corporation Sanda Works 2-3-33, Miwa, Sanda-city.
Page 536 SOUND, MEDIA AND INTERNET Country/ Area Kazakh- stan: Model name: NR 0V Manufacturer: Mitsubishi Electric Corporation Exporting country: Japan...
Page 537 SOUND, MEDIA AND INTERNET Country/ Area China: ■ 使用频率 2.4 - 2.4835 GHz ■ 等效全向辐射率(EIRP) 天线增益 10dBi 时 ≤100 mW 或≤20 dBm ① ■ 最大率谱密度天线增益 10dBi 时 ≤20 dBm / MHz(EIRP) ① ■ 载频容限 20 ppm ■ 帯外发射率(在 2.4-2.4835GHz 頻段以外) ≤-80 dBm / Hz (EIRP) ■...
Page 538 SOUND, MEDIA AND INTERNET Country/ Area B 급 기기 (가정용 방송통신기자재) Korea: 이 기기는 가정용(B 급) 전자파적합기기로서 주로 가정에서 사용하는 것을 적으로 하며, 든 지역에서 사용할 수 있습니다. 해당 무선설비는 전파혼신 가능성이 있으므로 인명안전과 관련된 서비스는 할 수 습니다. Malaysia: This device has been certified under the Communications &...
Page 539 SOUND, MEDIA AND INTERNET Country/ Area Mexico: 低率電波輻射性電機管理辦法 Taiwan: 第十二條經型式認證合格之低功率射頻電機，非經許可，公司商號或使用者均不得擅自變更頻率加大功率或變更原設計之特性及功能第十四條低率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立停用，改善至無干擾時方得繼續使用前項合法通信，指依電信法規定作業之無線電通信低率射頻電機須忍受合法通信或工業科學及醫療用電波輻射性電機設備之干擾 Related information Sound, media and Internet (p. 482) • Internet-connected car* (p. 519) • Media player (p. 492) •...
Page 541: Wheels And Tyres
WHEELS AND TYRES...
Page 542: Tyres
Recommended tyres best tread must be fitted on the rear especially important with regard to winter On delivery, the car is equipped with Volvo wheels to reduce the risk of oversteer dur- tyres. The last four digits in the sequence...
Page 543 Volvo accepts no lia- than having the rear end skidding to one side, bility for death, personal injury or any resulting in possible complete loss of control costs caused by such installations.
Page 544: Dimension Designation For Tyre
WHEELS AND TYRES Dimension designation for tyre Speed rating 270 km/h (168 mph) Each tyre can withstand a certain maximum Designations for tyre dimension, load index 300 km/h (186 mph) speed. Tyre speed rating, SS (Speed Symbol), and speed rating. must at least correspond with the car's top The car has an approval for the complete vehi- speed.
Page 545: Dimension Designation For Wheel Rim
WHEELS AND TYRES Dimension designation for wheel Tyres' rotation direction NOTE Tyres with a tread pattern which are designed Make sure that both pairs of wheels have to only turn in one direction have the direc- Wheel and rim dimensions are designated in the same type and dimension, and also the tion of rotation marked with an arrow.
Page 546: Tread Wear Indicators On The Tyres
WHEELS AND TYRES Tread wear indicators on the tyres Checking tyre pressure Cold tyres The tyre pressure must be checked when the Tread wear indicators show the status of the Correct tyre pressure helps to improve driv- tyres are cold. Tyres are considered cold when tyre's tread depth.
Page 547: Adjusting Tyre Pressure
WHEELS AND TYRES Adjusting tyre pressure Related information 3. Refit the dust cap. Adjusting tyre pressure (p. 545) • Tyre pressure decreases over time, this is a NOTE natural phenomenon. The tyre pressure must Recommended tyre pressure (p. 546) • therefore sometimes be adjusted in order to After a tyre has been inflated, always Tyre pressure monitoring system*...
Page 548: Recommended Tyre Pressure
WHEELS AND TYRES Recommended tyre pressure Related information Improved fuel economy with ECO pressure Recommended tyre pressure (p. 546) For a light load (max. 3 people) and a speed of • The tyre pressure label on the driver's side up to 160 km/h (100 mph), the ECO pres- door pillar (between frame and rear door) Checking tyre pressure (p.
Page 549: Tyre Pressure Monitoring System
WHEELS AND TYRES Tyre pressure monitoring system* Each tyre, including the spare tyre*, should be system fault indicator is combined with the checked once a month. When checking, the indicator symbol for low tyre pressure. When The tyre pressure monitoring system gives a tyre should be cold and have the air pressure the system detects a fault, the symbol in the...
Page 550: Saving A New Tyre Pressure In The Monitoring System
The new tyre pressure is losing control of the car. the tyre pressure should be adjusted in stored when the car is driven at a speed accordance with Volvo's recommended tyre The system cannot indicate sudden • above 35 km/h (22 mph).
Page 551: See Tyre Pressure Status In The Centre Display
WHEELS AND TYRES See tyre pressure status in the Related information WARNING centre display* Saving a new tyre pressure in the monitor- • The exhaust gases contain carbon monox- ing system* (p. 548) With the system for tyre pressure monitor- ide, which is invisible and odourless, but , tyre pressure status can be viewed in Action in the event of warning for low tyre...
Page 552: Action In The Event Of Warning For
WHEELS AND TYRES Action in the event of warning for Related information NOTE low tyre pressure Recommended tyre pressure (p. 546) • To avoid incorrect tyre pressure, the pres- When the system for tyre pressure warns Adjusting tyre pressure (p. 545) •...
Page 553: Changing Wheel
Car status (p. 582) • WARNING low Check Car that there is low tyre Volvo Cars support site (p. 21) • Status app in pressure in one or more If a wheel must be changed in a traf- •...
Page 554 WHEELS AND TYRES 2. Screw together the towing eye with the 2. Put on the wheel. Tighten the wheel bolts IMPORTANT wheel wrench to the stop position. thoroughly. When the jack* is not in use it must be • Do not use lubricant on the threads of the stored in its storage space under the wheel bolts.
Page 555: Tool Kit
WHEELS AND TYRES Tool kit Emergency puncture repair kit (p. 558) • WARNING Tools that can be useful during towing, wheel Fitting and removing the towing eye • The wheel bolts may need to be re-tight- changes or similar are found in the car's (p.
Page 556: Jack
Only use rims that are tested and approved by cargo area floor. Volvo and which are Volvo genuine accesso- The jack included with the car is only • ries. designed for occasional, short-term...
Page 557: Spare Wheel
Look out for high wrench, contact your Volvo dealer. If the spare wheel is damaged, a new one can kerbs and do not machine-wash the be purchased from a Volvo dealer. Related information car. Changing wheel (p. 551) •...
Page 558: Handling The Spare Wheel
• mounted on, for example L for left and R for right. Contact a Volvo dealer for advice about which The illustration is generic and appearance may differ. wheel rim and tyre types are most suitable. The spare wheel is stored in a bag and must...
Page 559: Snow Chains
WHEELS AND TYRES Snow chains on tyres than summer conditions. Volvo there- IMPORTANT fore recommends not to drive on winter tyres Use of snow chains and/or winter tyres can Snow chains can be used on the car with that have a tread depth of less than 4 mm...
Page 560: Emergency Puncture Repair Kit
NOT be used. sor and a bottle with sealing fluid. The sealing works as a temporary repair. You can obtain more information on snow chains from a Volvo dealer. NOTE Related information The sealing fluid is effective at sealing tyres Sealing fluid expiry date Winter driving (p.
Page 561: Using A Puncture Repair Kit
WHEELS AND TYRES Using a puncture repair kit Sealing fluid bottle WARNING The emergency puncture repair kit (TMK Bottle opening Please keep the following points in mind can be used to seal a puncture. Read through when using the tyre sealing system: all instructions before use.
Page 562 WHEELS AND TYRES the upper and lower eyelids. Get medi- 2. Detach the decal for maximum permitted 7. Begin puncture repair cal attention if symptoms occur. speed that is affixed on one side of the Connect the electrical cable to the closest compressor.
Page 563 Call roadside 2. Remove the air hose from the bottle. unscrew. assistance for recovery to a tyre centre. Volvo recommends an authorised tyre cen- 3. Remove the bottle from the compres- tre. sor. 13. Clean the air hose before putting it away 4.
Page 564: Inflating Tyres With The Compressor
• the puncture repair kit (p. 562) WARNING Check the tyre pressure regularly. Volvo recommends that the car is driven to the nearest authorised Volvo workshop for the replacement/repair of the damaged tyre. Advise the workshop that the tyre contains...
Page 565 WHEELS AND TYRES 4. Connect the electrical cable to the closest 8. Refit the dust cap on the tyre. 12 V socket and start the car. NOTE WARNING After a tyre has been inflated, always • Inhaling car exhaust fumes could result in refit the dust cap in order to avoid dam- danger to life.
Page 567 LOADING, STORAGE AND PASSENGER COMPARTMENT...
Page 568 LOADING, STORAGE AND PASSENGER COMPARTMENT Passenger compartment interior front seat backrest and also USB ports* in the tunnel console. Overview of the passenger compartment's interior and storage locations. WARNING Front seat Keep loose objects such as mobile phones, cameras, remote controls for accessories, etc.
Page 569 LOADING, STORAGE AND PASSENGER COMPARTMENT Tunnel console Using the cigarette lighter* IMPORTANT The tunnel console is located between the The cigarette lighter can be a complement to Keep in mind that high gloss surfaces, for front seats. the 12 V socket in the front section of the tun- example, are easily scratched by metal nel console.
Page 570 Emptying the ashtray* (p. 568) • console. the cargo area. If a problem occurs with an electrical socket, contact a workshop - an authorised Volvo workshop is recommended. 12 V electrical socket Detach the ashtray by pulling it straight up and empty the contents.
Page 571 LOADING, STORAGE AND PASSENGER COMPARTMENT Using electrical sockets WARNING 12 V sockets can be used for various acces- Do not use accessories with large or • sories designed for this, such as music play- heavy connectors - they can damage ers, cooler boxes and mobile phones.
Page 572 LOADING, STORAGE AND PASSENGER COMPARTMENT Using the glovebox Related information Electrical sockets (p. 568) • The glovebox is located on the passenger side. The printed owner's manual and maps Passenger compartment interior (p. 566) • can be kept in the glovebox, for example. There is also space for a pen and card holder.
Page 573 LOADING, STORAGE AND PASSENGER COMPARTMENT Sun visors There are sun visors in the roof in front of the driver seat and the front seat passenger seat which can be folded down and angled out to the side when necessary. The figure is schematic - the design may vary. The figure is schematic - the design may vary.
Page 574 LOADING, STORAGE AND PASSENGER COMPARTMENT Cargo area Recommendations for loading WARNING The car has a flexible cargo area that makes it There are a number of things that are impor- Leave 10 cm (4 inches) space between the possible to transport and secure large tant to bear in mind when loading the car.
Page 575 • to weights and maximum permitted load. in order to achieve the maximum possible (p. 575) safety during a journey. Volvo's load carriers Roof load and loading on load carriers • Related information are available for purchase at authorised Volvo (p.
Page 576 LOADING, STORAGE AND PASSENGER COMPARTMENT Bag hooks Load retaining eyelets Fitting and removing the safety net* • (p. 575) Bag hooks keep carrier bags in place and pre- Use the load retaining eyelets to attach vent them from overturning and spreading straps in order to anchor items in the cargo their contents across the cargo area.
Page 577 LOADING, STORAGE AND PASSENGER COMPARTMENT Through-load hatch in the rear Folding up the cargo area floor Fitting and removing the safety seat* net* The cargo area floor can be secured in raised position using the support arm. The hatch in the rear seat's backrest can be The safety net prevents loads from being Grip the handle to fold up the cargo area opened to transport long narrow items, e.g.
Page 578 LOADING, STORAGE AND PASSENGER COMPARTMENT 2. Hook one retaining hook of the net into the WARNING front or rear roof mounting with the Loads in the luggage compartment must anchoring strap locks turned towards you. be anchored well, and also using a cor- Remove any clothing hooks from the roof rectly fitted safety net.
Page 579 LOADING, STORAGE AND PASSENGER COMPARTMENT Remove and store the parcel shelf 5. Tension the safety net with the anchoring straps. The parcel shelf can be removed to increase the size of the cargo area. Removing the safety net The safety net can be easily removed and Removing parcel shelf folded up.
Page 580 LOADING, STORAGE AND PASSENGER COMPARTMENT First aid kit* Warning triangle The first aid kit contains first aid equipment. Use the warning triangle to warn other road Store the first aid kit behind the elastic strap, if users if the car is stationary in traffic. the car is equipped with one of these.
Page 581 MAINTENANCE AND SERVICE...
Page 582 IMPORTANT Servicing the climate control system • type of communication, the car only connects For the Volvo warranty to apply, check and (p. 588) to a workshop's network. It is not possible to follow the instructions in the Service and connect the car to another Wi-Fi network, Brake system maintenance (p.
Page 583 MAINTENANCE AND SERVICE Download Center Managing system updates via the WARNING Download Centre Several of the car's systems can be updated The car must not be driven when con- from the centre display with an online car Functions for online car and infotainment can nected to the workshop's networks and Download Centre app is...
Page 584 MAINTENANCE AND SERVICE Car status Note that only the download can be cancelled, NOTE when the installation phase has started, this The general status of the car can be shown in Data download may affect other services cannot be cancelled. the centre display.
Page 585 Before the service can be used would like done during the workshop visit 8. Tap on Cancel request to cancel your Create a Volvo ID and register it to the car. • or any other important information to your request. workshop.
Page 586 (p. 106) Related information display. You can cancel data transmis- sion by tapping the X in the activity Book service and repair (p. 583) • Volvo ID (p. 26) • indicator. Car status (p. 582) • Internet-connected car* (p. 519) •...
Page 587 MAINTENANCE AND SERVICE Raise the car When raising the car, it is important that the jack is fitted in the intended points on the car's underbody. The triangles in the plastic cover indicate the locations of the lifting points (marked in red).
Page 588 NOTE WARNING WARNING If the car is raised using a workshop jack, Volvo recommends only using the jack that Apply the parking brake and set the • this must be placed beneath one of the belongs to the car model in question. If a gear selector in Park position (P).
Page 589 MAINTENANCE AND SERVICE 4. Position the jack or the lift arms at the 7. Turn the jack so that the crank is as far designated spots of the car's undercar- away from the side of the car as possible, riage. The triangle markings in the plastic at which point the jack's arms are perpen- cover indicate the locations of the jacking/ dicular to the direction of the car.
Page 590 Volvo recommends that an authorised Volvo the system. workshop is contacted. Cars with R134a refrigerant Related information Volvo service programme (p.
Page 591 Engine compartment overview (p. 590) • If the warning symbol is lit or the warning Door and seatbelt reminder (p. 48) • signal is heard despite the bonnet being closed properly, contact an authorised Volvo workshop. Bonnet not completely closed.
Page 592 MAINTENANCE AND SERVICE Engine compartment overview The overview shows some service-related components. Some of the components included in the car's electric drive system are located under the bonnet. Exercise caution in this area and only touch anything that is related to normal main- tenance.
Page 593 Always have the engine cleaned by a work- in the owner's manual should be exact rep- shop - an authorised Volvo workshop is licas of those in the car. They are included recommended. There is a risk of fire if the to show their approximate appearance and engine is hot.
Page 594 The oil level should be claims any liability for any such damage. checked regularly. Volvo recommends that oil changes are carried out at an authorised Volvo work- Open the Car Status app from the app shop.
Page 595 The oil level may be too high. the car as quickly as possible and have the car recovered to a work- shop – an authorised Volvo workshop is WARNING recommended. Do not spill oil onto the hot exhaust mani- fold due to the risk of fire.
Page 596 Use ready-mixed coolant as recom- • to the coolant can be used to heat the pas- mended by Volvo. If concentrated liq- senger compartment. uid is used, make sure that the ratio is When topping up the coolant, follow the 50 % coolant to 50 % water of an instructions on the packaging.
Page 597 MAINTENANCE AND SERVICE Starter battery battery is discharged a large number of times, WARNING it will negatively affect the service life. The starter battery is used to start up the The battery can generate oxyhydrogen • electrical system and drive electrical equip- In order to maintain the starter battery in good gas, which is highly explosive.
Page 598 Capacity (Ah) According to EN standard. Cold Cranking Amperes. Volvo recommends entrusting battery replace- Using jump starting with another battery • ment to an authorised Volvo workshop. (p. 462) Reset sequence for pinch protection • IMPORTANT (p. 157) If the battery is replaced, make sure you Battery recycle (p.
Page 599 The hybrid battery must only be replaced Store the battery out of The hybrid battery's coolant must only be by a workshop - an authorised Volvo work- the reach of children. topped up by a workshop - an authorised shop is recommended.
Page 600 - an authorised Volvo workshop is rec- WARNING ommended. Never use a foreign object or a fuse with an...
Page 601 Fuses under the left-hand front seat • WARNING (p. 605) Contact an authorised Volvo workshop about the fuses not mentioned in the owner's manual. If replacing the fuse is not performed correctly, it can cause serious damage to the electrical systems.
Page 602 MAINTENANCE AND SERVICE Fuses in engine compartment Fuses in the engine compartment protect engine and brake functions, amongst other things.
Page 603 MAINTENANCE AND SERVICE On the inside of the cover there are tweezers The fuse box also provides space for several Positions that facilitate the procedure for the removal spare fuses. On the inside of the cover is a label that shows and fitting of fuses.
Page 604 MAINTENANCE AND SERVICE Function Ampere Type Airbags Micro Accelerator pedal sensor Micro Supplied when the ignition is switched on: Engine control module; Transmission components; Electric steering servo; Micro Central electronic module; Control module for brake system Electric additional heater*; OBD II firewall Micro Exterior audio module Alcohol lock*...
Page 605 MAINTENANCE AND SERVICE Function Ampere Type High voltage battery; Inverter generator Micro Horn Micro Siren* Micro Windscreen wipers MCase Control module for brake system (valves, parking brake) MCase Brake control with 48V battery MCase Control unit for brake system (ABS pump) MCase Brake booster MCase...
Page 606 Control function for support battery Micro Left-hand headlamp Micro Right-hand headlamp Micro This type of fuse should be replaced by a workshop. An authorised Volvo workshop is recommended. Related information Fuses and central electrical units (p. 598) • Replacing a fuse (p. 599) •...
Page 607 MAINTENANCE AND SERVICE Fuses under the left-hand front seat Fuses under the left-hand front seat protect, amongst other things, electrical sockets, dis- plays and door modules.
Page 608 MAINTENANCE AND SERVICE The fuse box in the engine compartment facilitate the procedure for the removal and fit- Positions provides space for several spare fuses. On the ting of fuses. On the inside of the cover is a label that shows inside of the cover there are tweezers that the location of the fuses.
Page 609 MAINTENANCE AND SERVICE Function Ampere Type Audio control device (amplifier) MCase Central Electric Module A: Sensors, radar units, power seats* MCase Central Electric Module B: Sensors, radar units, power seats* MCase Fan module for climate control system, front MCase Power operated tailgate* MCase Power seat*, right MCase...
Page 610 Steering wheel module Micro Module for start knob; Electronic shifting module; Electronic parking brake Micro Centre display Micro Control module for online car; Control module for Volvo On Call Micro Module for multi-band antenna Micro Relay coils Micro Module for detecting foot movement* (for opening the power operated tailgate)
Page 611 MAINTENANCE AND SERVICE Function Ampere Type Lock motor for head restraint on rear left-hand side Micro Lock motor for head restraint on rear right-hand side Micro Rear window defroster MCase Seatbelt pretensioner module, left-hand side MCase Seatbelt pretensioner module, right-hand side MCase Humidity sensor Micro...
Page 612 MAINTENANCE AND SERVICE Function Ampere Type – – Micro Seatbelt pretensioner module Micro Blind Spot Information (BLIS)*: control module, exterior reversing sound Micro – – Micro – – Micro All Wheel Drive (AWD) control module* Micro – – Micro Parking camera* Micro –...
Page 613 Micro – – Micro Applicable to certain variants. This type of fuse should be replaced by a workshop. An authorised Volvo workshop is recommended. Applies to certain markets. Related information Fuses and central electrical units (p. 598) • Replacing a fuse (p. 599) •...
Page 614 Outside lighting such as headlamps and For information about bulbs not covered in rear lamps may temporarily have conden- this Owner's Manual, contact a Volvo sation on the inside of the lens. This is nor- dealer or an authorised Volvo workshop.
Page 615 MAINTENANCE AND SERVICE Replacing the rear direction Lamps, rear indicator bulb Bulbs for rear direction indicators are located behind the panel in the side of the cargo area. 3. Unscrew and remove the spring bolt anti- clockwise, press the clips into the sides Brake light - central, high-level (LED) and remove the supporting bridge.
Page 616 MAINTENANCE AND SERVICE Changing brake light bulb IMPORTANT Bulbs for brake lights are located behind the Never touch the glass part of the bulbs panel in the side of the cargo area. with your fingers. Grease from your fingers is vaporised by the heat, coating the reflec- tor and then causing damage.
Page 617 MAINTENANCE AND SERVICE Replacing the rear fog lamp bulb Related information Exterior lamp positions (p. 612) • The rear foglight is fitted in the rear bumper on the driver's side. Bulb specifications (p. 616) • 3. Undo the black bulb holder by turning it anticlockwise and pulling it out.
Page 618 Specifications for replaceable bulbs. Use cleaning agents and car care products 8. Insert the hook on the wide part of the recommended by Volvo. Clean regularly, and foglight unit in the rear bumper and rotate Contact a workshop if faults occur in lamps deal with stains straight away.
Page 619 MAINTENANCE AND SERVICE Cleaning the centre display Related information IMPORTANT Cleaning the centre display (p. 617) • Dirt, stains and grease from fingers can affect The microfibre cloth used to clean the cen- the centre display's performance and reada- Cleaning fabric upholstery and headlining •...
Page 620 MAINTENANCE AND SERVICE Cleaning fabric upholstery and Cleaning the leather steering wheel • IMPORTANT headlining (p. 621) Always clean the entire upholstery, even Cleaning interior plastic, metal and wood It is recommended to use a fabric cleaning • there are only individual stains. This is to parts (p.
Page 621 Use water and a synthetic detergent. A special Remove inlaid carpets for separate cleaning of textile cleaning agent is available from Volvo the floor carpet and the inlaid carpets. Each retailers. Ensure that the seatbelt is dry before inlay mat is secured with pins.
Page 622 • required in order that the properties and col- > Protecting the leather upholstery (p. 618) ours of the leather shall be preserved. Volvo makes it more resistant to the stresses Cleaning the seatbelts (p. 619) • offers a comprehensive product, Volvo Leather from the sun's UV radiation.
Page 623 • Use cleaning agents and car care products Use cleaning agents and car care products (p. 619) recommended by Volvo. Clean regularly, and recommended by Volvo. Clean regularly, and Cleaning leather upholstery* (p. 620) • deal with stains straight away. Vacuuming is deal with stains straight away.
Page 624 Use a soft washing sponge. in a car wash with oil separator. Use car the car in direct sunlight, the surface being shampoo that is recommended by Volvo. polished should be a maximum of 45 °C Polishing glossy trim mouldings could (113 °F).
Page 625 After the car has been washed, tar from • and have an abrasive effect. asphalt may remain. Use tar remover that is recommended by Volvo to get rid of the Remove bird droppings from the paint- • last spots. work as soon as possible. They contain substances that damage and discolour paintwork very quickly.
Page 626 NOTE Never use polishing agent with abra- • Volvo recommends that the car is not sive properties on the panoramic roof. washed in an automatic car wash during Never use wax on the rubber mould- •...
Page 627 MAINTENANCE AND SERVICE Keyless and touch-sensitive surfaces* • IMPORTANT IMPORTANT (p. 250) For car washes where the car is pulled for- The system will automatically switch to P ward with rolling wheels, the following mode unless the above step is followed. applies: The wheels are locked in P mode, which they should not be when putting the car...
Page 628 Wash the car in a car wash with oil separator. Use car shampoo that is with oil separator. Use car shampoo that is recommended by Volvo. recommended by Volvo. When using high-pressure washing, use Asphalt, dust and salt residue on wiper blades, sweeping movements and make sure that the as well as insects, ice etc.
Page 629 Use car shampoo that is rec- Never use metal polishing agent on ano- ommended by Volvo. dised aluminium parts, this can result in A special cleaning agent available from Volvo discolouration and destroy the surface dealers is recommended for the cleaning and treatment.
Page 630 Use car shampoo and shielding plastic components, abrasion the edges of wings, doors and bumpers. To that is recommended by Volvo. protection and supplemental rust inhibitor on avoid the onset of rust, damaged paintwork exposed areas. In the chassis, exposed com- should be rectified immediately.
Page 631 Touch-up pens and spray paints for touching clean and dry. The temperature of the sur- up paintwork are available from Volvo dealers. If the damage has not reached down to the face should be at least 15 °C (59 °F).
Page 632 MAINTENANCE AND SERVICE Colour codes Replacing the wiper blade, rear Replacing the wiper blade, rear window window Colour code The wiper blades sweep water away from the The decal for the colour code is positioned on windscreen and rear window. Together with the car's right-hand door pillar between the washer fluid, they aim to clean the windows front and rear door and will be visible when...
Page 633 MAINTENANCE AND SERVICE Replacing windscreen wiper 3. Press the new wiper blade into place. You Fold up the wiper arm when it is in service blades should hear a click. Check that it is firmly position. Service position is activated/ installed.
Page 634 MAINTENANCE AND SERVICE Set the wiper blades in service wipers are not on. Service mode is activated/ NOTE position deactivated via the function view in the centre When replacing the wiper blades, note that display: In some situations, the windscreen's wiper they have different lengths.
Page 635 MAINTENANCE AND SERVICE Filling washer fluid Related information Prescribed grade: Washer fluid recom- mended by Volvo – with frost protection dur- Using the rain sensor (p. 168) • Washer fluid is used for cleaning the head- ing cold weather and for temperatures below...
Page 636 MAINTENANCE AND SERVICE Using the rain sensor's memory function • (p. 169) Using the rear window wiper and washer • (p. 170) Set the wiper blades in service position • (p. 632) Replacing windscreen wiper blades • (p. 631) Replacing the wiper blade, rear window •...
Page 637 SPECIFICATIONS...
Page 638 The illustration is schematic - details may vary depending on market and model. Knowing the car's type designation, vehicle identification and engine numbers can facili- tate all contact with an authorised Volvo dealer regarding the car and when ordering spare parts and accessories.
Page 639 SPECIFICATIONS Decal for type designation, vehicle identifi- Decal A/C system for cars with refrigerant Decal for engine code and the engine's cation number, permissible maximum weights R134a. serial number. and code designation for exterior colour and date of manufacture. The decal is positioned on the door pillar, and will be visible when the right-hand rear door is opened.
Page 640 SPECIFICATIONS NOTE It is not intended that the decals illustrated in the owner's manual should be exact rep- licas of those in the car. They are included to show their approximate appearance and locations in the car. The information that applies to your particular car can be found on the decal on the car.
Page 641 SPECIFICATIONS Dimensions Measurement of car length, height, etc. can be read in the table. Dimensions inches Dimensions inches Dimensions inches Ground clear- Load length, 34.9 Width 1873 73.7 floor ance (1863 (73.3 1658 65.3 Wheelbase 2702 106.4 Height Length 4425 174.2 Load height 28.9...
Page 642 SPECIFICATIONS Dimensions inches Width includ- 2034 80.1 ing door mir- rors Width includ- 1910 75.2 ing folded-in door mirrors At kerb weight + 1 person. (Varies slightly depending on tyre dimension, chassis option, etc.) Including roof antenna, for kerb weight. Body width.
Page 643 SPECIFICATIONS Weights NOTE Max. gross vehicle weight, etc. can be read The documented kerb weight applies to on a label in the car. cars in the standard version - i.e. a car Kerb weight includes the driver, the fuel tank without extra equipment or accessories.
Page 644 SPECIFICATIONS Towing capacity and towball load Max. weight braked trailer Towing capacity and towball load for driving NOTE with a trailer can be read in the tables. Use of vibration dampers on the towbar is recommended for trailers heavier than 1800 kg.
Page 645 SPECIFICATIONS Related information Type designations (p. 636) • Weights (p. 641) • Driving with a trailer (p. 468) • Trailer stability assist* (p. 470) • * Option/accessory.
Page 646 SPECIFICATIONS Engine specifications The Twin Engine variant is driven both by a petrol engine and an electric drive motor NOTE Engine specifications (power, etc.) for each (ERAD – Electric Rear Axle Drive). respective engine alternative can be found in If there is no engine data in the table, this the table below.
Page 647 SPECIFICATIONS Engine oil – specifications Engine oil grade and volume for each respec- tive engine alternative can be read in the table. Volvo recommends: Engine Oil grade Volume, incl. oil filter Engine code (litres, approx.) T4 Twin Engine B3154T10 Castrol Edge Professional V 0W-20 or VCC RBS0-2AE 0W-20...
Page 648 Volvo dis- claims any liability for any such damage. Volvo recommends: Volvo recommends that oil changes are carried out at an authorised Volvo work- shop. Related information Engine oil – specifications (p. 645) •...
Page 649 Prescribed grade: Ready-mixed coolant The transmission fluid needs to be replaced Brake fluid is the medium in a hydraulic brake approved by Volvo. If concentrated coolant is every 60,000 km. system that is used to transfer pressure from used, mix with 50% water (of approved e.g.
Page 650 SPECIFICATIONS Fuel tank - volume Air conditioning – specifications Decal for R1234yf The fuel tank's filling capacity can be read in The car's climate control system uses a freon- the table below. free refrigerant either R1234yf or R134a depending on market. Information about All models which refrigerant the car's climate control Litres (approx)
Page 651 SPECIFICATIONS Symbol explanation R1234yf Cars with R134a refrigerant WARNING Symbol Meaning The air conditioning system contains pres- surised refrigerant R1234yf. In accordance Caution with SAE J2845 (Technician Training for Safe Service and Containment of Refriger- ants Used in Mobile A/C System), service and repair of the refrigerant system must only be performed by trained and certified Mobile air conditioning system...
Page 652 SPECIFICATIONS Fuel consumption and CO Related information emissions Type designations (p. 636) • Weights (p. 641) Fuel consumption and CO emissions can be • negatively impacted by a number of factors. Economical driving (p. 451) • Examples of causes of increased fuel con- Factors that affect range when running on •...
Page 653 SPECIFICATIONS Approved tyre pressures NOTE Approved tyre pressures for each engine All engines, tyres or combinations of these alternative can be found in the table. are not always available in all markets. Engine Tyre size Speed Load, 1-3 persons Max. load ECO pressure Front Rear...
Page 654 SPECIFICATIONS Performance Top speed can be read in the table below. Engine Top speed Engine code (km/h) (mph) T5 Twin Engine B3154T5 The engine code, component number and serial number can be found on the engine. Top speed for electric operation is up to 125 km/h. Top speed for electric operation is up to 78 mph.
Page 655 ALPHABETICAL INDEX ALPHABETICAL INDEX Symbols and messages Alarm WARNING deactivation A/C (Air conditioning) motion and tilt sensors Additional heater (Auxiliary heater) reduced alarm level Adjusting the steering wheel anti-lock brakes Alcohol lock 428, 429 Aerial Accessories and extra equipment Allergy and asthma inducing sub- location installation stances.
Page 656 ALPHABETICAL INDEX Auto hold Hybrid battery Brakes jump starting Anti-lock braking system, ABS Automatic brake maintenance autobrake with adaptive cruise con- activate/deactivate overload trol after collision recycling auto brake with Pilot Assist Driver support symbols on the battery automatic when stationary Automatic car wash brake assist system, BAS Bicycle rack...
Page 657 ALPHABETICAL INDEX maintenance and cleaning central locking Child safety Symbols and messages Centre display Child safety locks Car care 622, 623, 624, 626, 627, 628 change appearance Child seat 58, 61, 62 Leather upholstery cleaning i-Size/ISOFIX mounting points climate control Car functions lower mounting points function view...
Page 658 ALPHABETICAL INDEX rims Collision warning Cooling system Seatbelts from behind overheating upholstery 616, 618, 619, 620, 621 with adaptive cruise control Cornering lights with Pilot Assist Cleaning wheel rims Corner Traction Control Collision warning system Cleaning wiper blades Crash, see Collision cross traffic rear Clean Zone Cross Traffic Alert...
Page 659 ALPHABETICAL INDEX Deadlock Drive-E Driving mode deactivation Environmental philosophy change when using driver support Defrosting Driver Alert Control activate/deactivate Driving with a trailer Diagnosis guide to rest stops towball load via the workshop's Wi-Fi Limitations towing capacity Digital radio (DAB) Driver display Dimensions app menu...
Page 660 ALPHABETICAL INDEX Emergency puncture repair kit External dimensions Front seat, power Pump up tyre adjusting seat using Lumbar support massage Emissions of carbon dioxide multi-function control 177, 178 Energy distribution store position assisted by map data Air distribution FSC, ecolabelling Engine Air vents Fuel...
Page 661 IAQS (Interior Air Quality System) automatic gearbox seats 196, 197 IC (Inflatable Curtain) Gear selector inhibitor steering wheel Windows 201, 203 ID, Volvo Gear shift indicator High engine temperature Identification number General speed warning High-pressure washing Ignition position 426, 427 Glass, laminated/reinforced...
Page 662 ALPHABETICAL INDEX IntelliSafe select assistance option Driver support Symbols and messages Kerb weight Interior Air Quality System Lane Keeping Aid see Lane assistance Interior lighting adapt Keyboard 117, 120 Language change language Interior rearview mirror Large Animal Detection (LAD) Dipping Keyless Leather upholstery, washing instruc- Locking/unlocking...
Page 663 ALPHABETICAL INDEX rear fog lamp Meters settings fuel gauge Main beam Hybrid battery Lighting, bulb replacement brake light Maintained climate comfort Mileage bulbs, specifications start/shut-off Electric operation direction indicator, rear maintenance Misting rear fog lamp Rustproofing condensation in headlamps 622, 624 Limp home Max.
Page 664 ALPHABETICAL INDEX Option/accessory Parallel parking Parking climate Symbols and messages Output Parcel shelf electric motor Parking heater Park Assist outside temperature gauge activate/deactivate Passenger Airbag Cut Off Switch forward, backward and along the Overheating 461, 468 Passenger compartment filter sides Overtaking Assistance Passenger compartment heater (Parking Limitations...
Page 665 ALPHABETICAL INDEX text message Power windows 157, 158 Radio favourites voice control opening and closing Rain sensor 168, 169 pinch protection Phone charger Rain sensor memory function Preconditioning Pilot Assist Raising the car start/shut-off activate Range Timer Auto brake during electric operation change of target Privacy policy (Customer privacy policy) Rear Collision Warning...
Page 666 ALPHABETICAL INDEX Recovery Road run-off protection seatbelt reminder seatbelt tensioner Refrigerant Road sign information climate control system Limitations Seatbelt, see Seatbelts Refuelling Road Sign Information Seatbelt reminder activate/deactivate Regeneration seatbelt tensioner activating / deactivating warnings Resetting Remote control, HomeLink® display mode Seatbelt tensioner programmable Sensus Navigation...
Page 667 ALPHABETICAL INDEX Settings Speed warning, general Storage spaces Categories glovebox Spin control contextual Sun visor Stabiliser Resetting tunnel console trailer Side airbag Stored speed Stability and traction control system Side Impact Protection System Sun blind sport mode panorama roof 162, 166 SIM card Symbols and messages pinch protection...
Page 668 ALPHABETICAL INDEX foldable Trip meter specifications Trip meter, resetting Tailgate Towing 473, 475 Trip statistics Locking/unlocking 227, 252 Towing a trailer settings opening/closing with foot move- Towbar TSA - trailer stability assist ment Towing bracket power Tunnel console unlock from inside Towing capacity and towball load Tunnel detection Target vehicle change...
Page 669 Storage Washers using 134, 136, 137 tread wear indicators Headlamps tyre pressure table VOL marking rear window 170, 171 winter tyres Volvo ID washer fluid, filling create and register windscreen Waxing Weights Units kerb weight Unlocking Wheel bolts Warning lamps...
Page 670 ALPHABETICAL INDEX Wi-Fi connect car to Internet delete network share internet connection, hotspot technology and security Windows and glass Windscreen heating Windscreen washing Windscreen wiper rain sensor 168, 169 Winter driving snow chains winter tyres Wiper blades changing 630, 631 Service position Wiper blades and washer fluid...
Page 672 TP 31783 (English Int.), AT 1946, MY20, Copyright © 2000-2019 Volvo Car Corporation...

Save PDF
