Summary of Contents for Volvo XC40 2019

  • Page 1 XC40 O W NE R 'S M ANU AL...
  • Page 3 VÄLKOMMEN! We hope you will enjoy many years of driving pleasure in your Volvo. manual. The owner's manual is also available as a mobile app (Volvo The car has been designed for the safety and comfort of you and Manual) and on the Volvo Cars support site (support.volvocars.com).
  • Page 4: Table Of Contents

    YOUR VOLVO SAFETY Owner information Volvo ID Safety Owner's manual in centre display Creating and registering a Volvo ID Safety during pregnancy Navigate in the owner's manual in Drive-E - cleaner driving pleasure Whiplash Protection System the centre display IntelliSafe – driver support and safety...
  • Page 5 DISPLAYS AND VOICE CONTROL Child seat mounting Handling a message saved from the driver display Displays and controls by the driver Overview table for location of in a left-hand drive car child seats Overview of centre display Displays and controls by the driver Table for location of child seats Managing the centre display in a right-hand drive car...
  • Page 6 LIGHTING WINDOWS, GLASS AND MIRRORS Open contextual setup in the cen- Lighting control tre display Windows, glass and mirrors Adjusting light functions via the Resetting user data for change of centre display Pinch protection for windows and ownership sun blinds Position lamps Resetting settings in the centre Reset sequence for pinch protection...
  • Page 7 SEATS AND STEERING WHEEL CLIMATE Manual front seat Climate Activating and deactivating auto- matic start of heated steering wheel* Power* front seat Climate zones Activating auto climate control Climate control - sensors Adjusting the power* front seat Activating and deactivating air Using a stored position for seat Perceived temperature recirculation...
  • Page 8 KEY, LOCKS AND ALARM Adding and editing time setting Lock confirmation Unlocking the tailgate from the for preconditioning* inside of the car Lock indication setting Activating and deactivating time Activating and deactivating child Remote control key setting for preconditioning* safety locks Locking and unlocking with the Removing time setting for precon- Automatic locking when driving...
  • Page 9 DRIVER SUPPORT Driving support systems Activating or deactivating road Adaptive cruise control* sign information* Speed-dependent steering force Controls for adaptive cruise control* Display mode for road sign infor- General speed warning Display mode for adaptive cruise mation* control* Electronic stability control Road Sign Information and Selecting and activating adaptive Sensus Navigation*...
  • Page 10 Use Overtaking Assistance Steering assistance upon risk of Activating or deactivating the rear-end collision* parking assistance system* Warning from driver support in the event of a collision risk Limitations for steering assistance Limitations of Parking assistance at risk of collision Change of target with driver support Symbols and messages for Park Symbols and messages for steer-...
  • Page 11 STARTING AND DRIVING Recommended maintenance for Starting the car Auto braking after a collision camera and radar unit Switching off the car Regenerative braking* Symbols and messages for cam- Ignition positions Gearbox era and radar unit Selecting ignition mode Manual gearbox Alcohol lock* Automatic gearbox Bypass of the alcohol lock*...
  • Page 12 SOUND, MEDIA AND INTERNET Activating and deactivating low- Using jump starting with another Sound, media and Internet speed driving* using a function button battery Audio settings Hill descent control* Towbar* Sound experience* Activating and deactivating hill Specifications for towbar* Apps descent control* with the function Extendable and retractable towbar* button...
  • Page 13: Connecting A Phone To The Car Via

    ® Switch between Bluetooth-con- User terms and conditions and Playing back DivX nected phones data sharing Settings for video Removing devices connected to Activating and deactivating data ® Media via Bluetooth Bluetooth sharing ® Connecting a device via Bluetooth Managing phone calls Data sharing for services Media via USB port Managing text messages...
  • Page 14 WHEELS AND TYRES LOADING, STORAGE AND PASSENGER COMPARTMENT Tyres Using a puncture repair kit Passenger compartment interior Dimension designation for tyre Inflating tyres with the compressor from the puncture repair kit Tunnel console Dimension designation for wheel rim Using the cigarette lighter* Tyres' rotation direction Emptying the ashtray* Tread wear indicators on the tyres...
  • Page 15 MAINTENANCE AND SERVICE Volvo service programme Exterior lamp positions Car paintwork Data transfer between car and Replacing the rear direction indica- Touching up minor paintwork damage workshop via Wi-Fi tor bulb Colour codes Download Center Changing brake light bulb Replacing the wiper blade, rear...
  • Page 16 SPECIFICATIONS ALPHABETICAL INDEX Type designations Alphabetical Index Dimensions Weights Towing capacity and towball load Engine specifications Engine oil – specifications Adverse driving conditions for engine oil Coolant – specifications Transmission fluid – specifications Brake fluid – specifications Fuel tank - volume ®...
  • Page 17 OWNER INFORMATION...
  • Page 18 Volvo Cars support site. There is a and in PDF format. On the interior images of the car. The Quick Guide and a supplement to the...
  • Page 19 Owner's manual in centre display A printed owner's manual and associated sup- Volvo Cars support site (p. 21) • plement can be ordered. Contact a Volvo Reading the owner's manual (p. 22) A digital version of the owner's manual is •...
  • Page 20 OWNER INFORMATION Related information Owner's manual Contextual owner's manual Navigate in the owner's manual in the • centre display (p. 19) Navigating in the centre display's views • (p. 105) Downloading apps (p. 470) • Top view with button for owner's manual. Top view with button for contextual owner's manual.
  • Page 21 OWNER INFORMATION Navigate in the owner's manual in Opening the menu in the top menu Featured articles the centre display Press the symbol to access a Press in the upper list in the owner's – page with links to a selection The digital owner's manual can be accessed manual.
  • Page 22 OWNER INFORMATION Using the search function in the top Hotspots for exterior and interior Favourites Exterior and interior overview Press the symbol to access menu images of the car. Different the articles saved as favour- Tap on in the top menu of the owner's parts are designated with ites.
  • Page 23 The owner's manual is available as a mobile More information on your car is available on the Volvo Cars website and support site. from both the App Store and Google Play. The app is adapted for smartphones and Support on the Internet tablets.
  • Page 24 Reading the owner's manual Log in to Volvo Cars website Options/accessories Create a personal Volvo ID and log in to In addition to standard equipment, the To help you get to know your new car, read www.volvocars.com. When you have logged...
  • Page 25 Owner's manual in centre display (p. 17) • Owner's Manual in mobile devices (p. 21) • Volvo Cars support site (p. 21) • Black ISO symbols on yellow warning field, white text/image on black message field. Used to indicate the presence of danger which, if the warning is ignored, may result in serious personal injury or fatality.
  • Page 26 OWNER INFORMATION The owner's manual and the environment The Owner's Manual is printed on paper orig- inating from controlled forests. ® The Forest Stewardship Council (FSC) sym- bol shows that the paper pulp in a printed ® owner's manual comes from FSC -certified forests or other controlled sources.
  • Page 27: Your Volvo

    YOUR VOLVO...
  • Page 28: Volvo Id

    YOUR VOLVO Volvo ID Creating and registering a Volvo ID When a Volvo ID is registered in the car, sev- eral services will be made available. Several Volvo ID is a personal ID that gives access to It is possible to create a Volvo ID in different...
  • Page 29 Registering your Volvo ID to the car Create a Volvo ID with the Volvo On Call If you created your Volvo ID via the web or the Volvo On Call app, register it to your car as fol- Download the latest version of the Volvo...
  • Page 30: Drive-E - Cleaner Driving Pleasure

    Fuel consumption Environmental care is one of Volvo Cars’ core air inside a Volvo is, for example, cleaner than values and influences all operations. The envi- the air outside thanks to the climate control...
  • Page 31 Interior carded - an authorised Volvo workshop is rec- and also involve reduced costs for the owner The material used in the interior of a Volvo is ommended. of the car. As the driver, it is easy to reduce carefully selected and has been tested in order...
  • Page 32 YOUR VOLVO of the car is therefore requested to contact a retailer for referral to a certified/approved recycling facility. Related information Fuel consumption and CO emissions • (p. 643) Economical driving (p. 430) • Start and switch off preconditioning* •...
  • Page 33: Intellisafe - Driver Support And Safety

    Whiplash Protection System • • safety Road Sign Information* Seatbelts with seatbelt tensioners • • IntelliSafe is the Volvo Cars concept for car Electronic stability control Airbags • • safety. IntelliSafe comprises a number of sys- Roll Stability Control •...
  • Page 34: Sensus - Online Connectivity And 21 Entertainment

    YOUR VOLVO Sensus - online connectivity and Sensus offers an intelligent interface and Information when it is needed, where entertainment online connectivity with the digital world. An it is needed intuitive navigation structure makes it possible The different displays in the car provide infor-...
  • Page 35 YOUR VOLVO Different types of information are shown in different displays depending on how the information should be prioritised. The driver display shows information on speed Driver display Centre display and e.g. incoming calls or song tracks being played. The display is operated via the two steering wheel keypads.
  • Page 36 YOUR VOLVO Many of the main functions of the car are con- trolled from the centre display, a touch screen which reacts to touch. The number of physical buttons and controls in the car is therefore minimal. The screen can even be operated while wearing gloves.
  • Page 37: Software Updates

    The EDR is designed to record data related to vehicle dynamics and safety systems for a So that you as a Volvo customer get the best As part of Volvo's safety and quality assur- short time, usually 30 seconds or less.
  • Page 38: Terms & Conditions For Services

    YOUR VOLVO Terms & Conditions for Services In addition to the EDR, the car is equipped into agreements with Volvo have access to is with a number of computers designed to con- required to be able to read and interpret the...
  • Page 39: Customer Privacy Policy

    Volvo serv- If the on-board information differs from the The types of personal data we gather.
  • Page 40: Installation Of Accessories

    Incorrect connection and installation of soft- accessories. ries, and that installation of accessories is ware or diagnostic tools may have a negative only carried out by trained and qualified Volvo effect on the car's electronic system. Related information service technicians. Certain accessories only...
  • Page 41: Showing The Car's Identification Number

    YOUR VOLVO Showing the car's identification NOTE number Volvo Cars accepts no liability for the con- When contacting a Volvo dealer concerning sequences if unauthorised equipment is your Volvo On Call subscription, for example, connected to the On-board Diagnostic you will need the car's identification number socket (OBDII).
  • Page 42: Driver Distraction

    Your new Volvo is, or can be, equipped with content-rich entertainment and communica- Never program the audio system while •...
  • Page 43: Safety

    SAFETY...
  • Page 44: Seatbelts

    Defective work in one of the systems can cause malfunction such as Whiplash Protection System. The car and result in serious personal injury. Volvo is also constructed so that a large part of the recommends that an authorised Volvo force of a collision is distributed to beams, pil- workshop should be contacted.
  • Page 45: Whiplash Protection System

    Volvo recommends that an and steering wheel). The aim should be to tem consists of energy absorbing backrests authorised Volvo workshop should be con- position the seat with as large a distance as and seat cushion, as well as a specially tacted.
  • Page 46 SAFETY Seatbelts WHIPS and child seats WARNING The protection provided by the car to children Heavy braking can have serious consequen- Do not squeeze rigid objects between the seated in a child seat or on a booster cushion ces if the seatbelts are not used. rear seat cushion and the front seat's back- is not diminished by WHIPS.
  • Page 47: Putting On And Taking Off Seatbelts

    Make sure that all passengers have fastened Never modify or repair the seatbelts your- > A loud "click" indicates that the belt has their seatbelts before starting to drive. self. Volvo recommends that an authorised locked. Volvo workshop should be contacted. Putting on seatbelts...
  • Page 48 SAFETY 3. In the front seats the seatbelt can be WARNING adjusted for height. Each seatbelt is designed for only one per- son. WARNING Remember not to clip or hook the seatbelt to hooks or other interior fittings, as this prevents the belt from tightening properly.
  • Page 49: Seatbelt Tensioner

    Never modify or repair the seatbelts your- pant. self. Volvo recommends that an authorised Volvo workshop should be contacted. Electric seatbelt tensioner* If the seatbelt has been subjected to a...
  • Page 50: Resetting The Electric Seatbelt

    WARNING Visual reminder in the roof console. Never modify or repair the seatbelts your- self. Volvo recommends that an authorised A visual reminder is given in the roof console Volvo workshop should be contacted. and by means of the warning symbol in the driver display.
  • Page 51 10 km/h (6 mph) then since the airbags may deploy. Recovering the driver display's information sym- the car. Volvo recommends that it is trans- bol illuminates. ported to an authorised Volvo workshop. If the car is driven at a speed higher than approx.
  • Page 52 SAFETY Driver airbags Volvo workshop. Do not drive with and deflation of the airbag, occurs within deployed airbags. tenths of a second. As a supplement to the seatbelts, the car is equipped with steering wheel airbag and Volvo recommends engaging an author- •...
  • Page 53 Passenger airbag (p. 51) • backs against the backrest. WARNING Volvo recommends that an authorised Volvo workshop should be contacted for repair. Defective work in the airbag system could cause malfunction and result in seri- ous personal injury. Passenger side front airbag.
  • Page 54: Activating And Deactivating Pas

    SAFETY Activating and deactivating Label for passenger airbag WARNING passenger airbag* Never allow anybody to stand or sit in front The passenger airbag can be deactivated if of the front passenger seat. the car is equipped with a switch, Passenger Never use a rear-facing child seat on the Airbag Cut Off Switch (PACOS).
  • Page 55 SAFETY Activating passenger airbag 2. Confirm the message by pressing the WARNING right-hand steering wheel keypad's O but- If the car is not equipped with a switch to ton. activate/deactivate the passenger airbag, the airbag will always be activated. Pull the switch outward and turn from OFF to ON.
  • Page 56 SAFETY Deactivating passenger airbag 2. Confirm the message by pressing the IMPORTANT right-hand steering wheel keypad's O but- If the passenger airbag is deactivated, the ton. electric seatbelt tensioner on the passen- ger side will also be deactivated. Related information Seatbelt tensioner (p.
  • Page 57 Volvo recommends the use only of car seat covers approved by Volvo. Other seat cov- ers may impede the operation of the side airbags.
  • Page 58 Volvo recommends only using been shown. Volvo genuine parts that are approved for symbol as long as the display is not damaged fitting within these areas. and the car's electrical system is still in work- ing order.
  • Page 59: Starting And Moving The Car After

    2. Do not move the car further than neces- 2. Switch off the car. sary. WARNING If the car is in safety mode it must not be towed. It must be transported from its location. Volvo recommends that it is transported to an authorised Volvo work- shop.
  • Page 60 Make sure that the child seat is positioned, In the event of questions when fitting child fitting in this particular car. Using Volvo's child mounted and used correctly. safety equipment, contact the manufac-...
  • Page 61: Upper Mounting Points For Child Seats

    SAFETY Upper mounting points for child Related information WARNING seats Child safety (p. 58) • The child seat's upper straps must be The car is equipped with upper mounting Upper mounting points for child seats • routed through the hole in the head points for child seats on the rear seat's outer (p.
  • Page 62: Lower Mounting Points For Child Seats

    SAFETY Lower mounting points for child i-Size/ISOFIX mounting points for switch to activate/deactivate the passenger seats child seats airbag*. The car is equipped with lower mounting The car is equipped with i-Size/ISOFIX points for child seats in the front seat* and mounting points for child seats in the rear seat.
  • Page 63: Child Seat Positioning

    SAFETY Child seat positioning Related information NOTE Child seats (p. 58) • It is important to position the child seat in the Regulations regarding the placement of right place in the car. The choice of location Upper mounting points for child seats •...
  • Page 64 Volvo recommends using the kick Do not secure the straps for the child seat guard accessory to protect the car's fit- into the seat's horizontal adjustment bar or tings.
  • Page 65 With the installation of an infant seat in the rear seat, child seat's upper straps should be pulled Volvo recommends a distance of at least 50 mm through the hole in the head restraint (2 tum) from the front part of the infant seat to the before being tensioned at the mounting rearmost part of the seat in front.
  • Page 66 SAFETY Overview table for location of child seats The table gives an overview of the types of child seats suitable for the car's seats. Seat positions in right-hand drive cars. Seat positions in left-hand drive cars. i-Size child seats Universally approved child seats secured using the car's seatbelt Other child seat categories 3, 5 India:...
  • Page 67 SAFETY Related information Child seat positioning (p. 61) • Child seat mounting (p. 62) • Table for location of child seats using the • car's seatbelts (p. 66) Table for location of i-Size child seats • (p. 68) Table for location of ISOFIX child seats •...
  • Page 68 SAFETY Table for location of child seats NOTE using the car's seatbelts Always read the owner's manual section The table gives a recommendation for which on installing a child seat before installing child seats suit which locations, and for what one in the car.
  • Page 69 Volvo recommends: Volvo rear-facing seat (type approval E5 04212). Volvo recommends rear-facing child seat for children in this mass group. Volvo recommends: Booster cushion with and without back (type approval E5 04216); Volvo booster seat (type approval E1 04301312). Related information Table for location of i-Size child seats •...
  • Page 70 X: Not suitable for universally approved child seats. Volvo recommends that children travel in a rear-facing child seat until as late an age as possible, at least until 3-4 years of age. Volvo recommends: BeSafe iZi Kid X2 i-Size (type approval E4-129R-000002).
  • Page 71 SAFETY Table for location of ISOFIX child The child seat must be approved in accord- NOTE seats ance with UN Reg R44 and the car model Always read the owner's manual section must be included in the manufacturer's vehicle The table gives a recommendation for which on installing a child seat before installing list.
  • Page 72 The seat cushion extension must always be retracted for the installation of child seats. Volvo recommends: Volvo infant seat secured using the ISOFIX fixture system (type approval E1 04301146). Applicable if the car is not fitted with an ISOFIX bracket.
  • Page 73 SAFETY Related information Child seat positioning (p. 61) • Child seat mounting (p. 62) • Overview table for location of child seats • (p. 64) Table for location of child seats using the • car's seatbelts (p. 66) Table for location of i-Size child seats •...
  • Page 75: Displays And Voice Control

    DISPLAYS AND VOICE CONTROL...
  • Page 76: Displays And Controls By The Driver In A Left-Hand Drive Car

    DISPLAYS AND VOICE CONTROL Displays and controls by the driver Left-hand steering wheel keypad Centre and tunnel console in a left-hand drive car Display lighting, unlocking/opening*/clos- The overviews show where the displays and ing* of tailgate controls near the driver are located. Roof console Steering wheel and instrument panel Centre display...
  • Page 77: Displays And Controls By The Driver In A Right-Hand Drive Car

    DISPLAYS AND VOICE CONTROL Displays and controls by the driver Driver's door Horn in a right-hand drive car Steering wheel adjustment The overviews show where the displays and controls near the driver are located. Left-hand steering wheel keypad Steering wheel and instrument panel Roof console Memory for settings for power front seat*, door mirrors...
  • Page 78 DISPLAYS AND VOICE CONTROL Centre and tunnel console Driver's door Centre display Memory for settings for power front seat*, door mirrors Start button Central locking, power windows, door mir- rors, electric child safety locks* Hazard warning flashers, defrosting, media, drive mode button* Bonnet opening Electrical socket, USB port, wireless Adjusting front seat...
  • Page 79: Driver Display

    You should visit a workshop immediately. equipment, settings and which functions are Volvo recommends an authorised Volvo active at that time. workshop. The driver display is activated as soon as a door is opened, i.e.
  • Page 80 DISPLAYS AND VOICE CONTROL On the left In the middle On the right – Phone App menu (activated via steering wheel keypad) – Voice recognition – – – Compass Depends on drive mode selected. Accumulated mileage. Dynamic symbol Indicator symbols in the driver display •...
  • Page 81: Driver Display Settings

    DISPLAYS AND VOICE CONTROL Driver display settings Settings via the centre display 2. Tap on System System Languages Settings for the driver display's display and Units System Language to select Selecting information type options can be made via the driver display's language.
  • Page 82: Fuel Gauge

    DISPLAYS AND VOICE CONTROL Fuel gauge Trip computer Units for distance, speed, etc. can be changed via system settings in the centre display. The fuel gauge in the driver display shows the The car's trip computer records vales such as fuel level in the tank.
  • Page 83: Show Trip Data In The Driver Display

    DISPLAYS AND VOICE CONTROL Show trip data in the driver display The calculation is based on the average fuel Show trip statistics in the centre display • consumption over the last 30 km (20 miles) (p. 83) The trip computer's recorded and calculated and the remaining drivable fuel quantity.
  • Page 84: Resetting The Trip Meter

    DISPLAYS AND VOICE CONTROL Resetting the trip meter Open the app menu in the driver display 3. Scroll down to the option buttons to by pressing (1). select which information to show in the Reset the trip meter using the left-hand stalk driver display: switch.
  • Page 85: Show Trip Statistics In The Centre Display

    DISPLAYS AND VOICE CONTROL Show trip statistics in the centre Settings for trip statistics display Reset or adjust settings for trip statistics. Open the Driver performance app in app Trip statistics from the trip computer are dis- view in order to show the trip statistics. played graphically in the centre display and provide an overview that facilitates more fuel- efficient driving.
  • Page 86: Date And Time

    DISPLAYS AND VOICE CONTROL Date and time Outside temperature gauge zone is then adjusted automatically based on the location of the car. For certain types of The clock is shown in both the driver display The outside temperature is shown in the navigation systems, the current location and the centre display.
  • Page 87: Indicator Symbols In The Driver Display

    The emissions system. Drive to a car's regular brake system con- Active main beam off workshop for checking. Volvo tinues to work, but without the The symbol lights up white when recommends that an authorised ABS function.
  • Page 88 DISPLAYS AND VOICE CONTROL Symbol Specification Symbol Specification Symbol Specification Main beam On Rain sensor on Stability system, sport mode The symbol illuminates when This symbol illuminates when the The symbol illuminates when the main beam is on and with main rain sensor is on.
  • Page 89: Warning Symbols In The Driver Display

    Read Warning the message in the driver display. Grey symbol: Lane assistance is Volvo recommends that an The red warning symbol illumi- on but road lines are not authorised Volvo workshop is nates when a fault has been indi- detected.
  • Page 90: License Agreement For The Driver

    The pressure is too low. Stop the trians, cyclists or large animals. following text is Volvo's agreement with the engine immediately and check High engine temperature manufacturer or developer.
  • Page 91 DISPLAYS AND VOICE CONTROL to use in compliance with this license. We 1. No Warranty – THE FREETYPE PROJECT Introduction thus encourage you to use the following text: IS PROVIDED `AS IS' WITHOUT WARRANTY The FreeType Project is distributed in several OF ANY KIND, EITHER EXPRESS OR archive packages;...
  • Page 92 DISPLAYS AND VOICE CONTROL also encourage you to put an URL to the are looking for support, start in this list if you documentation for any purpose, provided that FreeType web page in your documentation, haven't found anything to help you in the the above copyright notice and the following though this isn't mandatory.
  • Page 93 DISPLAYS AND VOICE CONTROL documentation would be appreciated but SOFTWARE. COPYRIGHT AND Libunibreak License is not required. PERMISSION NOTICE Copyright © This library is released under an open-source 1991-2010 Unicode, Inc. All rights reserved. licence, the zlib/libpng licence. Please check 2.
  • Page 94 DISPLAYS AND VOICE CONTROL RIGHTS. IN NO EVENT SHALL THE you wrote the original software. If you use Copyright (C) 2002, Lev Povalahev • COPYRIGHT HOLDER OR HOLDERS this software in a product, an All rights reserved. INCLUDED IN THIS NOTICE BE LIABLE FOR acknowledgment in the product Redistribution and use in source and binary ANY CLAIM, OR ANY SPECIAL INDIRECT OR...
  • Page 95: App Menu In The Driver Display

    DISPLAYS AND VOICE CONTROL App menu in the driver display INTERRUPTION) HOWEVER CAUSED AND Functions ON ANY THEORY OF LIABILITY, WHETHER The app menu in the driver display provides Trip com- Selection of trip meter, selec- IN CONTRACT, STRICT LIABILITY, OR TORT quick access to commonly used functions for puter tion of what to show in the...
  • Page 96: Managing The App Menu In The Driver Display

    DISPLAYS AND VOICE CONTROL Managing the app menu in the Opening/closing the app menu If the app menu is opened again, the functions driver display of the most recently selected app are shown Press on open/close (1). – first. The app menu in the driver display is oper- >...
  • Page 97: Messages In The Driver Display

    DISPLAYS AND VOICE CONTROL Messages in the driver display Service messages Shown below is a selection of important serv- The driver display can show messages to ice messages and their meanings. inform or assist the driver in the event of dif- ferent events.
  • Page 98: Managing Messages In The Driver Display

    Part of message, shown together with information on steering wheel's right-hand keypad. The figure is where the problem has arisen. schematic - parts may vary depending on car model. An authorised Volvo workshop is recommended. Left/right Related information Managing messages in the driver display...
  • Page 99: The Driver Display

    DISPLAYS AND VOICE CONTROL Handling a message saved from Managing a new message Reading a saved message the driver display For messages with buttons: To read a saved message immediately: Whether saved from the driver display or the Navigate between the buttons by pressing Press the button to the right of the –...
  • Page 100 > The owner's manual opens in the cen- tre display and shows information linked to the message. Saved messages in the app are deleted auto- matically each time the engine is started. Market dependent. Volvo ID and selected workshop also need to be registered.
  • Page 101: Overview Of Centre Display

    DISPLAYS AND VOICE CONTROL Overview of centre display Many of the car's functions are controlled from the centre display. Presented here is the centre display and its options.
  • Page 102 DISPLAYS AND VOICE CONTROL Three of the centre display's basic views. Swipe right or left to access the function or app view respectively Function view - car functions that are acti- functions are also so-called trigger func- vated or deactivated with a press. Certain tions, which means they open a window The views are reversed for right-hand drive cars.
  • Page 103 DISPLAYS AND VOICE CONTROL with setting options. Examples of these Phone - the phone function can be Climate controls (p. 195) • include Camera. reached from here. Tap on the subview to Switching off and changing the volume of • expand it.
  • Page 104: Managing The Centre Display

    DISPLAYS AND VOICE CONTROL Managing the centre display can be performed by touching the screen in IMPORTANT different ways. Many of the car's functions are controlled and Do not use sharp objects on the screen as regulated from the centre display. The centre An infrared light curtain just above the surface they may scratch it.
  • Page 105 DISPLAYS AND VOICE CONTROL Procedure Execution Result Drag. Changes between different views, scrolls a list, text or view. Hold depressed and drag in order to move apps or map points on the map. Drag horizontally or vertically across the screen. Swipe/drag quickly.
  • Page 106 DISPLAYS AND VOICE CONTROL Returning to home view from another The control is used for many of the car's func- tions. Regulate e.g. temperature by means of view one of the following: Briefly press the home button below the centre display. drag the control to the desired tempera- •...
  • Page 107: Activating And Deactivating Centre

    DISPLAYS AND VOICE CONTROL Activating and deactivating centre Navigating in the centre display's Give a long press on the physical home display views button below the screen. > The screen goes dark except for the cli- The centre display can be dimmed and reacti- There are five different basic views in the cen- mate row, which continues to be vated using the home button beneath the...
  • Page 108 DISPLAYS AND VOICE CONTROL pressing on the tab or by dragging/swiping Climate view NOTE from the top downwards across the screen. The climate row is always visible at the bot- In home view standard mode - briefly press tom of the screen. The most common climate In the top view, access is always available to: the home button.
  • Page 109 DISPLAYS AND VOICE CONTROL App view view, such as the number of unread text mes- Function view sages for Messages Tap on an app to open it. The app then opens Media in the tile to which it belongs, e.g. You can scroll down in the app view, depend- ing on the number of apps.
  • Page 110 DISPLAYS AND VOICE CONTROL Depending on the amount of functions, it is also possible here to scroll downward in the view. Do this by swiping/dragging from the bottom and up. Unlike in app view, where an app is opened with a press, a function is activated or deacti- vated by pressing the relevant function button.
  • Page 111: Managing Subviews In Centre Display

    DISPLAYS AND VOICE CONTROL Managing subviews in centre display Home view consists of four subviews: Navigation Media Phone and an extra sub- view. These views can be expanded.
  • Page 112 DISPLAYS AND VOICE CONTROL Expanding a subview from default mode Standard mode and expanded mode of a subview in the centre display.
  • Page 113 DISPLAYS AND VOICE CONTROL Expanding a subview: When a new subview is opened in full-screen There is always the option to go back to home mode, no information from the other subviews view by pressing the home button. To go back For tiles Navigation Media...
  • Page 114: Function View In Centre Display

    DISPLAYS AND VOICE CONTROL Function view in centre display from home view by swiping from left to right Different types of buttons across the screen There are three different types of buttons for All the buttons for car functions are located in car functions;...
  • Page 115 DISPLAYS AND VOICE CONTROL The buttons' different modes The function is deactivated when the LED indicator is extinguished. When the LED indicator illuminates in green on a function or parking button, the function is activated. When a function is activated, extra text with an explanation for certain functions is shown.
  • Page 116: Moving Apps And Buttons In Cen

    DISPLAYS AND VOICE CONTROL Moving apps and buttons in centre Symbols in the centre display's NOTE display status bar Hide the apps that you rarely or never use The apps and buttons for car functions in the Overview of the symbols that can be shown by moving them to the bottom, off the visi- app view and function view respectively can in the centre display's status bar.
  • Page 117 DISPLAYS AND VOICE CONTROL Internet-connected car* (p. 505) • Symbol Specification Connecting a device via USB port (p. 485) • Car modem activated. Wireless phone charger* (p. 502) • Phone (p. 494) • USB sharing active. Date and time (p. 84) •...
  • Page 118: Keyboard In Centre Display

    DISPLAYS AND VOICE CONTROL Keyboard in centre display The centre display keyboard makes it possi- ble make entries using keys. It is also possi- ble to "draw in" letters and characters on the screen by hand. The keyboard can be used to enter characters, letters and numbers, e.g.
  • Page 119 DISPLAYS AND VOICE CONTROL The image shows an overview of some of the buttons which may be shown in the keyboard. The appearance varies depending on language settings and the context in which the keyboard is being used.
  • Page 120 DISPLAYS AND VOICE CONTROL addresses, each word automatically starts Variants of a letter or character Row of suggested words or characters with a capital letter. In text fields for pass- The suggested words are adjusted as new word, web address or email address entry, letters are being entered.
  • Page 121: Changing Keyboard Language In

    DISPLAYS AND VOICE CONTROL Changing keyboard language in Enter the characters, letters and Switching between different centre display words manually in the centre languages in the keyboard display When a number of languages To make it possible to switch between differ- have been selected in ent languages for the keyboard, the lan- The centre display keyboard allows you to...
  • Page 122 DISPLAYS AND VOICE CONTROL Suggestions for characters/letters/word/ Writing characters/letters/words by hand Deleting/changing characters/letters part of word. It is possible to scroll Write a character, a letter, a word or parts written by hand through the list. of a word in the area for hand-written let- ters (1).
  • Page 123: Changing The Appearance In The

    DISPLAYS AND VOICE CONTROL Changing the appearance in the Switching off and changing the Changing row in the free text field with centre display volume of the system sound in the handwriting centre display The appearance of the screen in the centre display can be changed by selecting a theme.
  • Page 124: Changing System Units

    DISPLAYS AND VOICE CONTROL Changing system units Changing system language Other settings in the centre display's top view Units settings are defined in the centre dis- Language settings are defined in the centre play's Settings menu. display menu Settings You can change settings and information for Press Settings in the top view in the cen-...
  • Page 125 (here, a multi-selector button and system from the beginning, but are the type radio buttons). that can be downloaded e.g. Volvo ID . Here Related information the settings are always made inside the app and not from the top view.
  • Page 126 Factory reset - clears all data and files • Other settings in the centre display's top • to change the owner of the Volvo On Call* and resets all settings to their default val- view (p. 122) service. ues. Table showing centre display settings •...
  • Page 127 Driver Profiles . Other settings are global, which means they are not Car Wi-Fi Hotspot linked to a driver profile. Car Modem Internet Route and Guidance My Car Volvo On Call Traffic Subcategories Volvo Service Networks Media Displays Subcategories Climate...
  • Page 128 DISPLAYS AND VOICE CONTROL Driver profiles System files. They remain the same regardless of which driver profile is active. Many of the settings made in the car can be Subcategories adapted according to the driver's personal Keyboard layout settings are an example of Driver Profile preferences and can be saved in one or more global settings.
  • Page 129 DISPLAYS AND VOICE CONTROL Selecting driver profile Renaming a driver profile 3. Select the driver profile required. When the centre display has been started, It is possible to change the name of the dif- 4. Press Confirm the selected driver profile is shown at the top ferent driver profiles used in the car.
  • Page 130 DISPLAYS AND VOICE CONTROL Protect driver profile Linking remote control key to 5. Save your profile protection option by driver profile pressing Back Close In some cases it is preferable not to save vari- ous settings defined in the car to the active >...
  • Page 131 DISPLAYS AND VOICE CONTROL The active profile can then be linked to the 5. Select Connect key to link the profile with Related information key. the key. It is not possible to link a driver Driver profiles (p. 126) • profile to a different key than the one cur- Renaming a driver profile (p.
  • Page 132 DISPLAYS AND VOICE CONTROL Resetting settings in the driver Message in centre display Pop-up messages profiles In some cases, a message is shown in the The centre display can show messages to form of a pop-up window. Pop-up messages inform or assist the driver in the event of dif- Settings that have been saved to one or more have higher priority than messages shown in ferent events.
  • Page 133 DISPLAYS AND VOICE CONTROL Managing messages in the centre Handling a message saved from For messages without buttons: display the centre display Close the message by tapping on it, or – Messages in the centre display are handled in Whether saved from the driver display or the allow the message to close automatically centre display views.
  • Page 134 DISPLAYS AND VOICE CONTROL Voice recognition Reading a saved message WARNING Open the top view in the centre display. Voice control allows you to control func- The driver always holds overall responsibil- > A list of saved messages is shown. tions in the car, e.g.
  • Page 135 DISPLAYS AND VOICE CONTROL Using voice recognition Avoid background noise in the passenger • NOTE compartment by having the doors, win- Not all system languages support voice Start voice control dows and panoramic roof* closed. recognition. The ones that do are high- To give commands via the lighted with the symbol in the list of...
  • Page 136 DISPLAYS AND VOICE CONTROL Cancel voice control 2. Say " Call [Forename] [Surname] e.g. "zero, three, one, two, two, four, four, [number category] Call Robin three" (03122443). Voice control can be cancelled in different ", e.g. " ways: Smith Mobile ".
  • Page 137 DISPLAYS AND VOICE CONTROL Controlling a telephone with voice Related information message. For this function to work, the car must be connected to the Internet. Voice recognition (p. 132) recognition • Controlling a telephone with voice recog- Call a contact, have messages read aloud or •...
  • Page 138 DISPLAYS AND VOICE CONTROL Voice control of radio and media " " - starts DAB radio*. Settings for voice recognition • " " - starts playback from USB. Commands for radio and media player device • Settings for the voice control system are control are shown below.
  • Page 139 DISPLAYS AND VOICE CONTROL Related information Voice recognition (p. 132) • Using voice recognition (p. 133) • Controlling a telephone with voice recog- • nition (p. 135) Controlling climate control with voice rec- • ognition (p. 186) Voice control of radio and media (p. 136) •...
  • Page 141 LIGHTING...
  • Page 142 Rotating ring in the left-hand stalk switch. on only the position lamps instead of other lighting. When the car's electrical system is in ignition Volvo recommends that mode is used position II, the following functions are availa- when the vehicle is driven.
  • Page 143 LIGHTING Adjusting light functions via the Using direction indicators (p. 145) • WARNING centre display Using main beam (p. 144) • The car's lighting system is not able to Several light functions can be adjusted and determine when daylight is too weak or Dipped beam (p.
  • Page 144 LIGHTING Position lamps Daytime running lights position from another position to switch on only the position lamps instead of other light- Position lamps can be used so that other road The car has sensors that detect the light con- ing. users can see the car if it stops or is parked.
  • Page 145 LIGHTING Dipped beam vated when the car's electrical system is in WARNING ignition position II. When driving with the stalk switch's rotating This system help to save energy - it cannot ring in the position, dipped beam is Tunnel detection determine in all situations when daylight is activated automatically in weak daylight or too weak or sufficiently strong, e.g.
  • Page 146 LIGHTING Using main beam Active main beam main beam by moving the stalk switch for- wards. Main beam is operated with the left-hand Active main beam is a function which uses a stalk switch. Main beam is the car's stron- camera sensor at the top edge of the wind- Deactivate by moving the stalk switch gest lighting and should be used when driv-...
  • Page 147 LIGHTING Using direction indicators Activate active main beam Active main beam may be temporarily unavail- able e.g. in situations with dense fog or heavy Active main beam is activated and deactivated The car's direction indicators are operated rain. When active main beam becomes availa- by turning the left-hand stalk switch to posi- with the left-hand stalk switch.
  • Page 148 LIGHTING Active bending lights* The function is only active in weak daylight or NOTE darkness and only when the car is moving and Active bending lights are designed to provide This automatic flashing sequence can • dipped beam is switched on. additional illumination in bends and junctions.
  • Page 149 LIGHTING Front fog lamps/cornering lights* The front fog lamps switch off automatically Related information when the car is switched off or when the Lighting control (p. 140) • The fog lights are activated manually when rotating ring on the stalk switch is set to the driving in fog and automatically when revers- Ignition positions (p.
  • Page 150 LIGHTING Rear fog lamp Brake lights Press the button to switch the lights on/off. symbol in the driver display illumi- The rear fog lamp is considerably stronger The brake light automatically comes on dur- nates when the rear fog lamp is switched on. than the normal rear lights and should only be ing braking.
  • Page 151 LIGHTING Emergency brake lights Hazard warning flashers NOTE Emergency brake lights are activated to alert Hazard warning flashers warn other road Regulations for the use of hazard warning vehicles behind about heavy braking. users by means of all of the car's direction flashers may vary between countries.
  • Page 152 LIGHTING Using home safe lighting Approach light duration Interior lighting Some of the exterior lighting can be kept Approach lighting is switched on when the The passenger compartment is equipped switched on to work as home safe lighting car is unlocked and is used to switch on the with several types of lighting, e.g.
  • Page 153 LIGHTING Auto function for passenger compartment The passenger compartment lighting goes off lighting when: Reading lamp, right-hand side The car is locked • The car is started • Reading lighting The reading lamps on the right and left-hand A side door is closed •...
  • Page 154 LIGHTING Adjusting interior lighting Lighting in the cargo area brightness can be precisely adjusted using the thumbwheel in the instrument panel. The lighting in the cargo area is switched on or The lamps inside the car come on differently off when the tailgate is opened or closed. depending on the ignition position used.
  • Page 155 LIGHTING Ignition positions (p. 398) Changing the brightness of the lights • Settings Press in the top view in the cen- tre display. 2. Press My Car Lights and Lighting Interior Lighting Interior Mood Lighting. 3. Under Interior Mood Light Intensity High select from Changing the colour of the light...
  • Page 157 WINDOWS, GLASS AND MIRRORS...
  • Page 158 WINDOWS, GLASS AND MIRRORS Windows, glass and mirrors Pinch protection for windows and Activating and deactivating the heated • sun blinds rear window and door mirrors (p. 203) The car contains several different windows, glass panes and mirrors. Some of the win- All power windows and sun blinds* have dows in the car are laminated.
  • Page 159 Controls for rear windows. Pinch protection for windows and sun • Reset sequence for pinch protection • Controls for front windows. blinds (p. 156) (p. 157) Operating power windows (p. 158) • An authorised Volvo workshop is recommended. * Option/accessory.
  • Page 160 WINDOWS, GLASS AND MIRRORS Operating power windows WARNING Using the driver's door control panel, all Check that children or other passengers power windows can be operated - using the are not at risk of crushing when all the win- control panels in the other doors operates the dows are closed with a remote control key power window in the individual door.
  • Page 161 WINDOWS, GLASS AND MIRRORS Rearview and door mirrors Keyless locking and unlocking* (p. 249) Angling adjustment of the door mirrors • • (p. 161) The rearview mirrors and door mirrors can be Locking and unlocking with the remote • used to give the driver better visibility to the control key (p.
  • Page 162 WINDOWS, GLASS AND MIRRORS Adjusting rearview mirror dimming Automatic dimming* For the door mirrors to be equipped with auto- matic dimming, the interior rearview mirror Bright light from behind is automatically Bright light from behind could be reflected in must also be equipped with automatic dim- dimmed by the interior rearview and door mir- the rearview mirrors and dazzle the driver.
  • Page 163 WINDOWS, GLASS AND MIRRORS Angling adjustment of the door 2. Adjust the position with the joystick in the 3. Repeat the above procedure as necessary. mirrors centre. The mirrors are returned to the original posi- To ensure better visibility to the rear, the door 3.
  • Page 164 WINDOWS, GLASS AND MIRRORS Panorama roof* 3. Under Exterior Mirror Tilt at Reverse WARNING Driver Passenger Both select The panorama roof is divided into two glass Children, other passengers or objects may activate/deactivate and to select which sections. The front section can be opened be trapped by the moving parts.
  • Page 165 WINDOWS, GLASS AND MIRRORS Operating the panorama roof* Keyless locking and unlocking* (p. 249) • IMPORTANT The panoramic roof and sun blind are oper- Locking and unlocking with the remote • Remove ice and snow before opening • ated with a control in the roof panel and both control key (p.
  • Page 166 WINDOWS, GLASS AND MIRRORS The movement of both panoramic roof and Open and close ventilation position IMPORTANT sun blind are also stopped if the roof control is Remove ice and snow before opening • operated again in the opposite direction to the the panoramic roof.
  • Page 167 WINDOWS, GLASS AND MIRRORS Fully open and close the panoramic downward to the manual closing position Related information instead. roof using the roof control Panorama roof* (p. 162) • Automatic operation Automatic closing of the panoramic roof's* • Open the sun blind to maximum position - sun blind (p.
  • Page 168 WINDOWS, GLASS AND MIRRORS Automatic closing of the Wiper blades and washer fluid Locking and unlocking with the remote • panoramic roof's* sun blind control key (p. 224) Together with the washer fluid, the wipers aim to improve visibility as well as headlamp With this function, the sun blind is closed pattern.
  • Page 169 WINDOWS, GLASS AND MIRRORS Using windscreen wipers Intermittent wiping Wiper blades and washer fluid (p. 166) • Move the lever up to switch the wipers The windscreen wipers are designed to clean Using the rain sensor's memory function • to intermittent wiping. Set the number the windscreen.
  • Page 170 WINDOWS, GLASS AND MIRRORS Using the rain sensor Activate the rain sensor by pressing the rain Related information Using windscreen and headlamp washers sensor button • The rain sensor automatically starts the wind- (p. 169) screen wipers based on how much water it Move the lever down to make the wipers detects on the windscreen.
  • Page 171 WINDOWS, GLASS AND MIRRORS Using the rain sensor's memory Using windscreen and headlamp Set the wiper blades in service position • function washers (p. 623) The rain sensor automatically starts the wind- Replacing windscreen wiper blades Windscreen and headlamp washers are •...
  • Page 172 WINDOWS, GLASS AND MIRRORS Using the rear window wiper and Filling washer fluid (p. 624) • IMPORTANT washer Set the wiper blades in service position • Avoid activating the washer system when (p. 623) The rear windscreen washer and wiper are it is frozen or the washer reservoir is designed to clean the rear window.
  • Page 173 WINDOWS, GLASS AND MIRRORS Using automatic rear windscreen Set the wiper blades in service position • wiping when reversing (p. 623) Replacing windscreen wiper blades Engaging reverse gear while the windscreen • wipers are switched on initiates rear window (p. 622) wiping.
  • Page 174 WINDOWS, GLASS AND MIRRORS Replacing the wiper blade, rear window • (p. 621) Using windscreen wipers (p. 167) •...
  • Page 175 SEATS AND STEERING WHEEL...
  • Page 176 SEATS AND STEERING WHEEL Manual front seat Raise/lower the seat by means of pump- Using a stored position for seat and door • ing the lever up/down. mirrors (p. 176) The car's front seats have a range of setting options in order to enhance comfort. Change the backrest inclination by turning Adjusting* the length of the seat cushion •...
  • Page 177 SEATS AND STEERING WHEEL Power* front seat Adjusting the power* front seat Adjusting the lumbar support* in the front • seat (p. 178) The car's front seats have a range of setting Set to desired sitting position using the con- options in order to enhance comfort.
  • Page 178 SEATS AND STEERING WHEEL Using a stored position for seat The backrests of the front seats cannot be Closed front door and door mirrors lowered fully forward. Hold one of the memory buttons 1 ( ) or – If the positions for the power* seat and the ) depressed until seat and door mir- door mirrors have been stored, they can be rors stop in the positions that are stored in...
  • Page 179 SEATS AND STEERING WHEEL Adjusting* the length of the seat Adjusting the lumbar support* in the front Adjusting the lumbar support* in the front • • cushion in the front seat seat (p. 178) seat (p. 178) Angling adjustment of the door mirrors For increased comfort, you can adjust the •...
  • Page 180 SEATS AND STEERING WHEEL Adjusting the lumbar support* in Lowering the backrests in the rear Adjusting the lumbar support the front seat seat The lumbar support is adjusted using a con- The rear seat's backrest is divided into two trol on the side of the seat cushion. parts.
  • Page 181 SEATS AND STEERING WHEEL Ensure that there are no occupants or objects 4. If necessary, raise the centre seat's head IMPORTANT in the rear seat. restraint. The armrest* for the centre seat must be Lower the centre seat's head restraint raised before lowering the seat.
  • Page 182 SEATS AND STEERING WHEEL Adjusting the head restraints in the rear seat Adjust the centre seat head restraint accord- ing to the height of the passenger. Fold down the outer seat head restraints* to improve rearward visibility. Adjust the head restraint for the centre seat To lower the head restraint, the button (see Press the...
  • Page 183 SEATS AND STEERING WHEEL Steering wheel controls and horn Related information Horn Lowering the backrests in the rear seat • The steering wheel houses the horn and con- (p. 178) trols for e.g. the driver support systems and voice recognition. The horn is located in the centre of the steering wheel.
  • Page 184 SEATS AND STEERING WHEEL Steering lock Adjusting the steering wheel The steering wheel lock makes it difficult to The steering wheel can be adjusted in differ- steer the car if it is stolen, for example. A ent positions. mechanical noise can be perceived when the steering lock is locked or unlocked.
  • Page 185 CLIMATE...
  • Page 186 CLIMATE Climate Climate zones 2-zone climate* The car is equipped with manual or elec- The number of climate zones that the car is tronic* climate control. The climate control divided into governs the options for setting system cools or heats as well as dehumidifies different temperatures for different parts of the air in the passenger compartment.
  • Page 187 CLIMATE Climate control - sensors Perceived temperature With the Interior Air Quality System* there is also an air quality sensor that is fitted into the The climate control system has a number of The climate control system regulates the cli- climate control system air intake.
  • Page 188 CLIMATE Controlling climate control with " Turn on auto " - activates automatic reg- " Raise seat heat "/" Lower seat heat " - • • ulation* of the climate control. raises/lowers the setting for the heated voice recognition seat* one step. Air condition on Air condition off Voice recognition commands for the climate...
  • Page 189 The indicator is visible in the climate row Use cleaning agents and car care products when the climate view is not open. recommended by Volvo to clean the interior. If the conditions have not been met then the Air cleaning system Clean Zone text is white.
  • Page 190 CLIMATE Clean Zone Interior Package* Interior Air Quality System* That the air quality system Interior Air • Quality System* is activated. Clean Zone Interior Package (CZIP) compri- Interior Air Quality System (IAQS) is a fully ses a series of modifications that keep the automatic air quality system that separates That the ventilation fan is activated.
  • Page 191 Settings Press in the top view in the cen- Follow the Volvo Service Programme for the tre display. recommended replacement intervals. If the car is used in a severely contaminated environ- 2. Press...
  • Page 192 CLIMATE Air distribution Table of air distribution options (p. 192) • The climate control system distributes the incoming air via a number of different vents in the passenger compartment. Automatic and manual air distribution With auto-regulated climate control running the air distribution takes place automatically. If necessary, the air distribution can be con- trolled manually.
  • Page 193 CLIMATE Changing air distribution Opening, closing and aiming the air vents The air distribution can be changed manually if required. Some air vents in the passenger compart- ment can be opened, closed and aimed indi- vidually. If the car's outer vents are aimed at the side windows then misting can be eliminated.
  • Page 194 CLIMATE Table of air distribution options The air distribution can be changed manually if required. The following options are available for setting. Air distribution Purpose If all air distribution buttons are deselected in manual mode, the climate control system returns to automatically regulated climate control.
  • Page 195 CLIMATE Air distribution Purpose Main air from the defroster vents and air vents in the instrument Provides good comfort in hot and dry climates. panel. Some air flows from other air vents. Main air flow from the defroster vents and air vents at the floor. Some Provides good comfort and good demisting in a cold or air flows from other air vents.
  • Page 196 CLIMATE Related information Air distribution (p. 190) • Opening, closing and aiming the air vents • (p. 191) Changing air distribution (p. 191) •...
  • Page 197 CLIMATE Climate controls Depending on equipment level, the climate view can be divided into several tabs. Change The climate control system's functions are between the tabs by swiping left/right or by controlled from physical buttons in the centre pressing the respective heading. console, the centre display and the climate controls at the rear of the tunnel console*.
  • Page 198 CLIMATE Controls for air distribution. Activating and deactivating the heated Main climate • windscreen* (p. 202) In addition to the climate row's functions, Fan control. other main climate functions can also be con- Activating and deactivating the heated • Main climate trolled in the tab.
  • Page 199 CLIMATE Activating and deactivating heated Activating and deactivating WARNING front seat* automatic start of heated front Heated seats must not be used by people seat* The seats can be heated in order to increase who find it difficult to perceive an increase comfort for driver and passengers when it is The seats can be heated in order to increase in temperature due to a lack of sensation or...
  • Page 200 CLIMATE Activating and deactivating heated Activating and deactivating the WARNING rear seat* heated steering wheel* Heated seats must not be used by people The seats can be heated in order to increase The steering wheel can be heated in order to who find it difficult to perceive an increase comfort for driver and passengers when it is increase comfort for the driver when it is...
  • Page 201 CLIMATE Activating and deactivating Activating auto climate control NOTE automatic start of heated steering With auto climate control activated, multiple Temperature and fan speed can be wheel* climate functions are controlled automati- changed without deactivating the automat- The steering wheel can be heated in order to cally.
  • Page 202 CLIMATE Activating and deactivating air Activating and deactivating time Related information recirculation setting for air recirculation Climate controls (p. 195) • Air recirculation shuts out bad air, exhaust Air recirculation shuts out bad air, exhaust Activating and deactivating time setting •...
  • Page 203 CLIMATE Activating and deactivating max NOTE defroster Max defroster starts with a certain delay in Max defroster is used to quickly remove mist order to avoid a short increase in fan level if and ice from windows. the heated windscreen is deactivated by Max defroster deactivates auto-regulation of two quick presses of the button.
  • Page 204 CLIMATE Activating and deactivating the Activating and deactivating heated NOTE heated windscreen* windscreen from centre display If the heated windscreen is activated when A heated windscreen is used to quickly the Start/Stop function has auto-stopped remove mist and ice from the window. the engine then the engine will be restar- ted.
  • Page 205 CLIMATE Activating and deactivating Activating and deactivating the Activating and deactivating heated automatic start of heated heated rear window and door rear window and door mirrors from windscreen* mirrors centre display A heated windscreen is used to quickly The heated rear window and door mirrors are remove mist and ice from the window.
  • Page 206 CLIMATE Activating and deactivating Regulating fan level for front seat IMPORTANT automatic starting of the heated The fan can be set to several different auto- If the fan is fully switched off then the air rear window and door mirrors matically controlled fan speeds for the front conditioning is not engaged, which results...
  • Page 207 CLIMATE Regulating temperature for front Related information seat Climate controls (p. 195) • The temperature can be set to the desired number of degrees for the front seat's cli- mate zones. 13, 11 Temperature control 2. Regulate the temperature by either of the following: drag the control to the desired tem- •...
  • Page 208 CLIMATE Activating and deactivating air Synchronising temperature by means of changing the temperature set- conditioning tings for a climate zone other than the driver's. The temperature in the car's different climate The air conditioning cools and dehumidifies zones can be synchronised with the tempera- Related information ture set on the driver's side.
  • Page 209 CLIMATE Parking climate* Preconditioning* NOTE Parking climate control is a generic term for Preconditioning is a climate function which, if It is not possible to activate the air condi- various functions that improve the passenger possible, attempts to reach comfort tempera- tioning when the fan control is in posi- compartment climate when the car is parked,...
  • Page 210 Starting from the app* guished. Start of preconditioning and information about the selected settings can be managed from a device that has the Volvo On Call* app. Pre- NOTE conditioning heats* the passenger compart- The car's doors and windows should be...
  • Page 211 CLIMATE Preconditioning time setting* Adding and editing time setting for 3. Press Add timer preconditioning* The timer can be set so that the precondition- > A pop-up window is shown. ing is finished at a predetermined time. The timer for preconditioning can manage up to 8 time settings.
  • Page 212 CLIMATE Activating and deactivating time 7. Tap on Confirm in order to add the time 3. Press the time setting that is to be setting for preconditioning* setting. changed. > A pop-up window is shown. > The time setting is added to the list and A time setting in the timer for preconditioning is activated.
  • Page 213 CLIMATE Removing time setting for Related information WARNING preconditioning* Preconditioning* (p. 207) • Do not use preconditioning if the car is A time setting for preconditioning that is no Preconditioning time setting* (p. 209) • equipped with a heater*: longer required can be deleted. Adding and editing time setting for pre- •...
  • Page 214 CLIMATE Climate comfort when parking* Starting and switching off climate Related information comfort when parking* Parking climate* (p. 207) • The climate in the car's passenger compart- ment can be maintained while the car is Climate comfort retention maintains the cli- Starting and switching off climate comfort •...
  • Page 215 CLIMATE NOTE Climate comfort retention is switched off when the car is locked from the outside to avoid using residual heat unnecessarily. Use of the function is intended to maintain climate comfort when driver or passengers remain inside the car. There is a limit to how long climate com- fort can be maintained in a cold climate, which depends on the amount of residual...
  • Page 216 The running time for parking climate control is limited when the state of charge in the starter bat- tery is low. Start the car. Limited Charge level too low An authorised Volvo workshop is recommended. Related information Parking climate* (p. 207) •...
  • Page 217 CLIMATE Heater* NOTE WARNING The heater has two subfunctions that help to Fuel which spills out could be ignited. Make sure that there is enough charge in heat the passenger compartment or engine in Switch off the fuel-driven heater before the battery if the heater needs to be used.
  • Page 218 Volvo recommends that an authorised Volvo workshop should be contacted for Depending on factors such as fuel availability, repair. battery level, passenger compartment tem-...
  • Page 219 NOTE The additional heater starts and is controlled automatically when heating is required while Volvo recommends that the automatic the car is being driven. start for the additional heater should be switched off for short driving distances.
  • Page 221 KEY, LOCKS AND ALARM...
  • Page 222 KEY, LOCKS AND ALARM Lock confirmation Lock and alarm indicator on the Indication in lock buttons instrument panel The car indicates with hazard warning flash- Front door ers when the car is locked or unlocked. Exterior indication Locking The car's hazard warning flashers indicate •...
  • Page 223 KEY, LOCKS AND ALARM Lock indication setting Remote control key Rear door* It is possible to select various options for how The remote control key locks and unlocks the the car confirms locking and unlocking in the doors, tailgate and fuel filler flap. The remote settings menu in the centre display.
  • Page 224 KEY, LOCKS AND ALARM Remote control key buttons automatically when the button is held WARNING depressed. The tailgate is also closed with The remote control key contains a button a long press – acoustic warning signals cell battery. Keep new and used batteries sound.
  • Page 225 KEY, LOCKS AND ALARM Detachable key blade (p. 231) • NOTE NOTE Immobiliser (p. 234) • Avoid storing the remote control key close Be aware of the risk of locking the remote Linking remote control key to driver profile • to metal objects or electronic apparatus, control key in the car.
  • Page 226 KEY, LOCKS AND ALARM Locking and unlocking with the activated when all the doors and the tailgate Automatic relocking remote control key are closed and locked. If none of the doors or the tailgate is opened within 2 minutes of unlocking, they are locked The buttons on the remote control key can be NOTE automatically.
  • Page 227 KEY, LOCKS AND ALARM Settings for remotely controlled Unlocking the tailgate with the 2. With the power operated tailgate option* - and inside unlocking remote control key Long press (approx. 1.5 seconds) on the It is possible to select different sequences for It is possible to unlock just the tailgate by remote control key's button...
  • Page 228 KEY, LOCKS AND ALARM Remote control key range Replacing the battery in the NOTE remote control key In order for the remote control key to work The remote control key functions may be properly it needs to be within a certain dis- The battery in the remote control key needs disrupted by surrounding radio waves, tance from the car.
  • Page 229 Hold the remote control key with the front visible and the Volvo logo facing the The shell will then come free and can right way - slide the button at bottom be lifted off the key.
  • Page 230 KEY, LOCKS AND ALARM Use a screwdriver or similar to turn the The battery (+) side is facing upwards. Install a new battery with the (+) side up. battery cover anticlockwise until the mark- Then carefully prize loose the battery as Avoid touching the remote control key's ings meet at the OPEN text.
  • Page 231 KEY, LOCKS AND ALARM NOTE Volvo recommends that the batteries to be used in the remote control key fulfil UN Manual of Test and Criteria, Part III, sub- section 38.3. Batteries fitted in the factory or replaced by an authorised Volvo work- shop fulfil the above criteria.
  • Page 232 If you lose a remote control key then a new since they can be swallowed by chil- one can be ordered at a workshop - an author- dren or pets. ised Volvo workshop is recommended. The Batteries must not: be dismantled, • remaining remote control keys must be taken short-circuited or thrown into open to the workshop.
  • Page 233 Detach the key blade by angling it up. Using the remote control key's detachable key blade Hold the remote control key with the front visible and the Volvo logo facing the the left-hand front door can be opened • right way - slide the button at bottom manually if central locking cannot be acti- edge by the key ring to the right.
  • Page 234 KEY, LOCKS AND ALARM Locking and unlocking with the Related information 5. Pull out the handle. detachable key blade Locking and unlocking with the detacha- • > The door opens. ble key blade (p. 232) Amongst other things, the detachable key Locking will be performed in the same way, blade can be used to unlock the car from the Remote control key (p.
  • Page 235 Volvo On 2. Press the start button. Call*. Manual locking of the door. Not to be mixed up with >...
  • Page 236 KEY, LOCKS AND ALARM Immobiliser Related information Starting the car (p. 396) • The electronic immobiliser is a theft protec- tion system that prevents an unauthorised Detachable key blade (p. 231) • person from starting the car. Activating and deactivating alarms* •...
  • Page 237 KEY, LOCKS AND ALARM Type approval for the remote Lock system keyless start (Passive control key system Start) and keyless locking/unlocking (Passive Entry*) Type approval for the car's remote key sys- tem can be seen in the following tables. For detailed information on type approval, go to www.volvocars.com/intl/support.
  • Page 238 KEY, LOCKS AND ALARM Country/Area Type approval Brazil MT-3245/2015 Indonesia Nomor: 38301/SDPPI/2015 Malaysia RDBV/25A/1118/S(18-4228), RDBV/26A/1118/S(18-4229) Mexico IFETEL: RLVDEVO15-0396 Russia The United Arab Emi- ER37847/15 rates DA0062437/11...
  • Page 239 KEY, LOCKS AND ALARM Country/Area Type approval Namibia TA-2016-02 South Africa TA-2014-1868...
  • Page 240 KEY, LOCKS AND ALARM Remote control key Country/ Type approval Area Europe Huf Hülsbeck & Fürst GmbH & Co. KG hereby declares that this type of radio equipment HUF8423 conforms to directive 2014/53/EU. The full text of the EU declaration of conformity can be found at www.volvocars.com/intl/support Wavelength: 433.92 MHz Maximum radiated transmission power: 10 mW...
  • Page 241 KEY, LOCKS AND ALARM Country/ Type approval Area (Customs Union) Belarus, Kazakhstan, Russia Indonesia [41005/SDPPI/2015] [5149] Jordan TRC/LPD/2015/104 Morocco AGREE PAR L'ANRT MAROC Numéro d’agrément: MR 10668 ANRT 2015 Date d’agrément: 24/07/2015 Moldova...
  • Page 242 KEY, LOCKS AND ALARM Country/ Type approval Area Mexico IFETEL Marca: HUF Modelo (s): HUF8423 NOM-121-SCT1-2009 La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es posible que este equipo o dispositivo no cause interferencia perjudicial y (2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su operación no deseada.
  • Page 243 KEY, LOCKS AND ALARM Country/ Type approval Area Philippines Serbia Singapore Complies with IMDA Standards DA103787 South Africa TA-2015-432...
  • Page 244 KEY, LOCKS AND ALARM Country/ Type approval Area 本產品符合低 率電波輻射性電機管理辦法 第十二條 第十四條等條文規定 1. 經 Taiwan 型式認證合格之低 率射頻電機,非經許可,公司 商號或使用者均不得擅自變更 頻 率 大 率或變更原設計之特性及 能 2. 低 率射頻電機之使用不得影響 飛航安全及干擾合法通信;經發現有干擾現象時,應立即停用,並改善至無干擾時 方得繼續使用 前項合法通信,指依電信法規定作業之無線電通信 低 率射頻 電機須忍受合法通信或工業 科學及醫療用電波輻射性電機設備之干擾 The United Arab Emi- rates...
  • Page 245 KEY, LOCKS AND ALARM Key Tag Country/ Type approval Area Europe Huf Hülsbeck & Fürst GmbH & Co. KG hereby declares that this type of radio equipment HUF8432 conforms to directive 2014/53/EU. The full text of the EU declaration of conformity can be found at www.volvocars.com/intl/support.
  • Page 246 KEY, LOCKS AND ALARM Country/ Type approval Area (Customs Union) Belarus, Kazakhstan, Russia Indonesia [41006/SDPPI/2015] [5149] Jordan TRC/LPD/2015/107 Morocco AGREE PAR L'ANRT MAROC Numéro d’agrément: MR 10667 ANRT 2015 Date d’agrément: 24/07/2015 Mexico IFETEL Marca: HUF Modelo (s): HUF8432 NOM-121-SCT1-2009 IFT: RLVHUHU15-0972 La operación de este equipo está...
  • Page 247 KEY, LOCKS AND ALARM Country/ Type approval Area Moldova Nigeria Connection and use of this communications equipment is permitted by the Nigerian Communications Commission Oman Philippines ESD-1511501C...
  • Page 248 KEY, LOCKS AND ALARM Country/ Type approval Area Serbia Singapore Complies with IMDA Standards DA103787 South Africa TA-2015-414...
  • Page 249 KEY, LOCKS AND ALARM Country/ Type approval Area 本產品符合低 率電波輻射性電機管理辦法 第十二條 第十四條等條文規定 1. 經 Taiwan 型式認證合格之低 率射頻電機,非經許可,公司 商號或使用者均不得擅自變更 頻 率 大 率或變更原設計之特性及 能 2. 低 率射頻電機之使用不得影響 飛航安全及干擾合法通信;經發現有干擾現象時,應立即停用,並改善至無干擾時 方得繼續使用 前項合法通信,指依電信法規定作業之無線電通信 低 率射頻 電機須忍受合法通信或工業 科學及醫療用電波輻射性電機設備之干擾 The United Arab Emi- rates Related information Remote control key (p.
  • Page 250 KEY, LOCKS AND ALARM Keyless and touch-sensitive Related information NOTE surfaces* Keyless locking and unlocking* (p. 249) • It is important that only one touch-sensi- With the keyless locking and unlocking func- Keyless unlocking of the tailgate* (p. 250) • tive surface is activated at a time.
  • Page 251 KEY, LOCKS AND ALARM Keyless locking and unlocking* Keyless locking Keyless unlocking All side doors must be closed to be able to Grasp a door handle or gently press the With keyless locking and unlocking, it is suffi- – lock the car. The tailgate, on the other hand, rubberised pressure plate beneath the tail- cient to touch the door handle's touch-sensi- can be open when locking the car with a side...
  • Page 252 KEY, LOCKS AND ALARM Settings for Keyless entry* Keyless unlocking of the tailgate* Related information Settings for Keyless entry* (p. 250) • It is possible to select different sequences for With keyless locking and unlocking, it is suffi- Keyless entry. cient to touch the touch-sensitive surface on Keyless unlocking of the tailgate* (p.
  • Page 253 KEY, LOCKS AND ALARM Antenna locations for the start and 2. Lift by the outside handle in order to open WARNING lock systems the tailgate. People with pacemaker operations should An antenna for the keyless starting system not come closer than 22 cm (9 inches) to IMPORTANT and antennas for the keyless locking system* the keyless system's antennas with their...
  • Page 254 KEY, LOCKS AND ALARM Locking and unlocking from inside Locking using a button in the front Alternative unlocking method the car door The doors and tailgate can be locked and Press the button - both front doors – unlocked from inside using the central lock- must be closed.
  • Page 255 KEY, LOCKS AND ALARM Unlocking the tailgate from the Related information Related information inside of the car Settings for remotely controlled and inside Locking and unlocking from inside the car • • unlocking (p. 225) (p. 252) The tailgate can be unlocked from inside by pressing the button on the instrument panel.
  • Page 256 KEY, LOCKS AND ALARM Activating and deactivating child 2. Press the button in the driver's door con- NOTE safety locks trol panel. A door's knob control only blocks that • > The driver display shows the message The child safety locks prevent the rear doors particular door - not both rear doors Rear child lock Activated and the but-...
  • Page 257 KEY, LOCKS AND ALARM Automatic locking when driving Opening and closing the power*- Symbol Message Specification operated tailgate The doors and tailgate are locked automati- Rear child Child safety cally when the car starts to move. Function where the tailgate can be opened locks are acti- lock Acti- To change this setting:...
  • Page 258 KEY, LOCKS AND ALARM Foot movement* under the rear bumper. Long press on the instrument panel's – Press the button on the underside of – – button. Keep it depressed until the tailgate the tailgate to close. Closing starts to open. >...
  • Page 259 KEY, LOCKS AND ALARM Closing and locking detected sufficiently close to the tail- Long press on the button on the – gate. remote control key. > The tailgate closes automatically and acoustic signals sound – the tailgate remains unlocked. IMPORTANT Long press on the button on the During manual tailgate operation, open or...
  • Page 260 KEY, LOCKS AND ALARM Programming maximum opening Pinch protection Pre-tensioned springs for power operated tailgate* If something with sufficient resistance pre- vents the tailgate from opening or closing then Adapt the tailgate's opening position to low the pinch protection is activated. roof height.
  • Page 261 KEY, LOCKS AND ALARM Operating the tailgate with foot NOTE movement* If the system has been operating con- • A function which allows the tailgate to open tinuously for a long time, it is switched and close by moving a foot under the rear off to avoid overload.
  • Page 262 KEY, LOCKS AND ALARM Private locking Opening and closing with foot Cancelling opening or closing with foot movement movement The tailgate can be locked with the private Make one forward kicking motion while locking function which prevents it from being –...
  • Page 263 KEY, LOCKS AND ALARM Activating and deactivating private To create a security code: 2. Enter the code to be used in order to locking unlock the tailgate after locking and tap on Press the button for private locking in the Confirm Private locking is activated with a function function view.
  • Page 264 KEY, LOCKS AND ALARM Alarm* If the car is unlocked via Volvo On Call* or the Alarm indicator Volvo On Call app, private locking will be The alarm provides audible and visual warn- deactivated automatically. ings if anyone enters the car without a valid...
  • Page 265 Lock and arm the car alarm as follows case, contact a workshop - an authorised The movement sensor triggers an alarm in the Volvo workshop is recommended. event of movement in the passenger compart- press the remote control key's lock button •...
  • Page 266 KEY, LOCKS AND ALARM Open the driver's door with the detacha- Automatic arming and rearming of the ble key blade. alarm > The alarm is triggered. Automatic rearming of the alarm prevents the car being left with the alarm disarmed unin- tentionally.
  • Page 267 The car can only be unlocked with a remote ing the car. control key, keyless unlocking* or the Volvo On Call* app when double lock is activated. At the same time, the double lock function is The front left door can also be unlocked with deactivated, i.e.
  • Page 268 KEY, LOCKS AND ALARM Temporarily* deactivating double If the car is unlocked and then locked again, locks the double lock function must be deactivated again. If someone is going to stay in the car but the doors must be locked from the outside, then The system is reset the next time the engine is the double lock function should be deacti- started.
  • Page 269 DRIVER SUPPORT...
  • Page 270 DRIVER SUPPORT Driving support systems Speed-dependent steering force Pilot Assist* (p. 312) • The car is equipped with different driver sup- Speed related power steering causes the Overtaking Assistance* (p. 323) • port systems which can assist the driver in steering wheel force to increase with the Lane assistance (p.
  • Page 271 DRIVER SUPPORT Electronic stability control General speed warning WARNING Electronic Stability Control (ESC ) helps the At speeds between 80-120 km/h If the temperature increases too much, the driver to avoid skidding and improves the (50-75 mph) the driver is warned by an acous- servo may be forced to switch off com- tic signal every other minute.
  • Page 272 Trailer Stability Assist is deactivated if • bilise the car. Sport Mode is activated. Also known as Active Yaw Control. Engine Drag Control Trailer stability assist is included when the Volvo genuine towbar is installed. Trailer Stability Assist * Option/accessory.
  • Page 273 DRIVER SUPPORT Electronic Stability Control in sport Activating or deactivating sport Related information mode mode for electronic stability Electronic stability control (p. 269) • control The stability system (ESC ) is always acti- Activating or deactivating sport mode for • vated –...
  • Page 274 DRIVER SUPPORT ESC Sport Mode function cannot be selected when one of the following functions is activated: Speed limiter • Cruise control • Adaptive cruise control* • Pilot Assist* • Related information Electronic Stability Control in sport mode • (p. 271) Electronic stability control (p.
  • Page 275 The system is disengaged. Stop the car in a safe place, switch off the engine and start it again. Service required A text message can be cleared by briefly If a message remains: Contact a workshop – Related information an authorised Volvo workshop is recom- Electronic stability control (p. 269) pressing the button, located in the centre •...
  • Page 276 DRIVER SUPPORT City Safety™ and the car normally stops just behind the WARNING vehicle in front. City Safety can use lights, sound and a The function is supplementary driver • brake pulse warning to alert the driver to The function helps the driver by automatically support intended to facilitate driving pedestrians, cyclists, larger animals and vehi- braking the car in the event of an imminent...
  • Page 277 DRIVER SUPPORT Subfunctions for City Safety Detection of obstacles with City Safety The steps of City Safety • (p. 278) City Safety carries out three steps in the fol- City Safety can help to prevent a collision or lowing order: City Safety brakes for oncoming vehicles reduce the collision speed.
  • Page 278 DRIVER SUPPORT City Safety brakes for oncoming vehicles 2 - Brake support • NOTE (p. 282) If the risk of collision has increased further On cars with manual gearbox, the engine after the collision warning then the brake sup- Limitations of City Safety (p. 283) •...
  • Page 279 DRIVER SUPPORT Setting the warning distance for When warnings are perceived as being too WARNING City Safety frequent or disturbing, the warning distance No automatic system can guarantee • can be reduced, which reduces the total num- City Safety is always activated but the 100% correct function in all situations.
  • Page 280 DRIVER SUPPORT Detection of obstacles with City Cyclists NOTE Safety The warning with direction indicators for City Safety can help the driver to detect Rear Collision Warning* is deactivated if vehicles, cyclists, large animals and pedes- the warning distance for collision warning trians.
  • Page 281 DRIVER SUPPORT Good performance requires that the system WARNING WARNING function that detects a pedestrian must City Safety is supplementary driver sup- City Safety is supplementary driver sup- receive the clearest possible information about port, but it cannot detect all cyclists in all port, but it cannot detect all pedestrians in the body outline, requiring the ability to iden- situations and, for example, cannot see:...
  • Page 282 DRIVER SUPPORT City Safety in cross traffic Large animals WARNING City Safety can help the driver when turning City Safety is supplementary driver sup- and crossing the path of another oncoming port, but it cannot detect all large animals vehicle at an intersection. in all situations and, for example, cannot see: partially obscured large animals.
  • Page 283 DRIVER SUPPORT Limitations for City Safety in cross The following further criteria must also be ful- NOTE traffic filled: This function uses the car's camera and In some cases City Safety may have difficulty your car must be travelling at no less than •...
  • Page 284 DRIVER SUPPORT Automatic braking in the event of City Safety brakes for oncoming City Safety does not intervene with the auto- an impeded evasive manoeuvre vehicles brake function as long as the driver him/ with City Safety herself has the opportunity to avoid a collision City Safety can assist the driver to use emer- via a steering manoeuvre.
  • Page 285 Maintenance of driver support components straight ahead. must only be performed at a workshop – Heat an authorised Volvo workshop is recom- Related information In the event of high passenger compartment mended. City Safety™ (p. 274) •...
  • Page 286 DRIVER SUPPORT Driver intervention Important warnings WARNING Reversing Warnings and brake interventions • WARNING When your own car is reversing, City Safety is could be implemented late or not at all temporarily deactivated. Driver supports only warn of obstacles if a traffic situation or external influ- which their radar unit has detected –...
  • Page 287 DRIVER SUPPORT may be disengaged due to darkness or Search path in the top view of the centre dis- WARNING poor visibility. play: The City Safety auto-brake function • Warnings and brake interventions for • • Settings My Car IntelliSafe can prevent a collision or reduce colli- pedestrians and cyclists are deacti- sion speed, but to ensure full brake...
  • Page 288 City Safety The system does not function as it should. A workshop should be contacted Reduced functionality Service required An authorised Volvo workshop is recommended. A text message can be cleared by briefly pressing the button, located in the centre of the steering wheel's right-hand keypad.
  • Page 289 DRIVER SUPPORT Road Sign Information* Related information NOTE Driving support systems (p. 268) • The Road Sign Information function (RSI In certain markets, the Road Sign Informa- can help the driver to observe speed-related Activating or deactivating road sign infor- •...
  • Page 290 DRIVER SUPPORT Activating or deactivating road Display mode for road sign NOTE sign information* information* If the automatic speed limiter function • The Road Sign Information function (RSI ) is The Road Sign Information function (RSI is activated, road sign information is optional –...
  • Page 291 DRIVER SUPPORT An additional sign, such as if map data has no information on the speed The driver display symbol extinguishes after "no overtaking", may be limit for the road section in question. about 5 minutes until the next speed-related shown together with the sign is passed.
  • Page 292 DRIVER SUPPORT Road Sign Information and Sensus An additional sign relating to rain is displayed Sign for "School" and "Children at Navigation* only if the windscreen wipers are in use. play" If a warning sign for "School" If the car is equipped with Sensus Navigation*, If a trailer is connected to the car's electrical or "Children at play"...
  • Page 293 DRIVER SUPPORT Warning for speed limitation and A speed warning is always given if the speed Warning for speed camera speed camera from road sign limit is exceeded in connection with speed A car equipped with road information* camera information. sign information and Sensus Navigation can provide infor- Road sign information (RSI...
  • Page 294 DRIVER SUPPORT Activating or deactivating Note that the function does 2. Select/deselect Speed Camera Audio warnings from road sign not give any consideration to Warning to activate/switch off the audi- information* selected limit adjustment ble speed camera warning. when the driver display The subfunction Speed Limit Warning Related information...
  • Page 295 DRIVER SUPPORT Limitations of Road Sign Speed limiter NOTE Information* A speed limiter (SL ) can be likened to a The RSI function may interpret some types reverse cruise control - the driver regulates The Road Sign Information (RSI ) function of bicycle rack, connected to the electrical the speed using the accelerator pedal but is may have limitations in certain situations.
  • Page 296 DRIVER SUPPORT Set the stored speed for driver support • : From active mode – deactivates/ WARNING (p. 325) changes the speed limiter to standby The function is supplementary driver • mode Automatic speed limiter (p. 297) • support intended to facilitate driving : Reduces stored maximum speed and make it safer –...
  • Page 297 DRIVER SUPPORT Selecting and activating speed Deactivating the speed limiter 2. When speed limiter is selected – press the limiter steering wheel button (2) to activate. The speed limiter (SL ) can be deactivated and switched off. The speed limiter function (SL ) must first >...
  • Page 298 DRIVER SUPPORT Temporary deactivation of speed Limitations for speed limiter Related information limiter Speed limiter (p. 293) • Speed limiter (SL ) has certain general limi- tations. Selecting and activating speed limiter The speed limiter (SL ) can be temporarily •...
  • Page 299 DRIVER SUPPORT Automatic speed limiter Symbol for automatic speed limiter WARNING The sign symbol (displayed along- The Automatic Speed Limiter (ASL ) func- The function is supplementary driver • side the stored speed, "70", in the tion helps the driver to adapt the car's maxi- support intended to facilitate driving centre of the speedometer) can be mum speed to the speed shown on the road...
  • Page 300 DRIVER SUPPORT Activating or deactivating the Symbol NOTE automatic speed limiter If the automatic speed limiter function • The automatic speed limiter function (ASL is activated, road sign information can be activated and deactivated as a supple- (RSI ) is shown in the driver display ✓...
  • Page 301 DRIVER SUPPORT Changing the tolerance for the Deactivating the automatic speed Press the steering wheel button – automatic speed limiter limiter until 70 km/h (43 mph) in the centre of To deactivate the automatic speed limiter: the speedometer (2) changes to 75 km/h The Automatic Speed Limiter function (47 mph).
  • Page 302 DRIVER SUPPORT Limitations for automatic speed Cruise control Marker for stored speed limiter The cruise control (CC ) helps the driver The car's current speed maintain an even speed, which can result in Automatic speed limitation (ASL ) takes more relaxed driving on motorways and long, place using speed information from the Road Stored speed straight roads in regular traffic flows.
  • Page 303 DRIVER SUPPORT Selecting and activating cruise To do so, proceed as follows: WARNING control Depress the accelerator pedal about half- – The function is supplementary driver • The cruise control function (CC ) must first way down and release. support intended to facilitate driving be selected and activated in order to be able >...
  • Page 304 DRIVER SUPPORT Deactivating cruise control 2. When cruise control is selected – press Related information Cruise control (p. 300) the steering wheel button (2) to acti- • Cruise control (CC ) can be deactivated and vate. switched off. Change between cruise control and adap- •...
  • Page 305 DRIVER SUPPORT Standby mode for cruise control Automatic standby mode Adaptive cruise control* Activation of automatic standby mode can be Cruise control (CC ) can be deactivated and The adaptive cruise control (ACC ) can help due to one of the following: set in standby mode.
  • Page 306 (p. 328) ulations. Change of target with driver support • (p. 325) IMPORTANT Overtaking Assistance* (p. 323) • Maintenance of driver support components must only be performed at a workshop – an authorised Volvo workshop is recom- mended. * Option/accessory.
  • Page 307 DRIVER SUPPORT Controls for adaptive cruise Display mode for adaptive cruise Increases the time interval to vehicles ahead control* control* Reduces the time interval to vehicles A summary of how adaptive cruise control The following image example shows how ahead (ACC ) is controlled using the left-hand key- Adaptive cruise control (ACC...
  • Page 308 DRIVER SUPPORT Selecting and activating adaptive Time interval The time interval is only cruise control* adjusted to the vehicle ahead Adaptive cruise control (ACC ) must first be by the Adaptive cruise control selected and then activated to enable it to when the distance symbol control speed and distance.
  • Page 309 DRIVER SUPPORT Deactivating adaptive cruise the car, or the current speed must be at WARNING least 15 km/h (9 mph). control* A significant increase in speed may follow For cars with manual gearbox. Speed • The adaptive cruise control (ACC ) can be when the speed is resumed with the must be at the lowest 30 km/h (20 mph).
  • Page 310 DRIVER SUPPORT 2. Press the steering wheel button ◀ (1) or ▶ Standby mode for adaptive cruise WARNING (3) to change to another function. control* With the adaptive cruise control is in • > The driver display's symbol and indica- Adaptive cruise control (ACC ) can be deac- standby mode, the driver must inter-...
  • Page 311 DRIVER SUPPORT Limitations for adaptive cruise Automatic standby mode may be engaged in Related information the event of one of the following: control* Adaptive cruise control* (p. 303) • Selecting and activating adaptive cruise One of the systems that Adaptive cruise •...
  • Page 312 DRIVER SUPPORT Change between cruise control Related information WARNING and adaptive cruise control* Adaptive cruise control* (p. 303) • This is not a collision avoidance sys- • the centre display Cruise control (p. 300) • tem. The driver is always responsible When the normal cruise control (CC ) is and must intervene if the system does...
  • Page 313 Clean the windscreen in front of the camera and radar unit's detectors. Sensor blocked, see Owner's manual A text message can be cleared by briefly If a message remains: Contact a workshop – an authorised Volvo workshop is recom- pressing the button, located in the centre mended.
  • Page 314 DRIVER SUPPORT Pilot Assist* about all of the function's applications and lim- braking may come unexpectedly or not at itations in order to safely use all of the advan- all. Pilot Assist can help the driver to drive the tages. follow the vehicle ahead in the same lane car between the lane's side markings as well •...
  • Page 315 DRIVER SUPPORT Steering assistance If Pilot Assist detects that the WARNING driver does not keep his/her The current status of steering Pilot Assist steering assistance is automati- hands on the steering wheel, assistance is indicated by the cally deactivated and is resumed without the system gives a warning colour of the steering wheel's prior warning.
  • Page 316 Maintenance of driver support components : Activates Pilot Assist from standby must only be performed at a workshop – mode and resumes the stored speed and an authorised Volvo workshop is recom- time interval mended. : Increases the stored speed This function can be either standard or optional, depending on market.
  • Page 317 DRIVER SUPPORT Display mode for Pilot Assist* Time interval : Reduces stored speed Pilot Assist only regulates the The following image example shows how Increases the time interval to vehicles time interval to the vehicle Pilot Assist can be shown in the display in dif- ahead ahead when the distance ferent contexts.
  • Page 318 DRIVER SUPPORT The previous illustration shows that Pilot The previous illustration shows that Pilot Assist is set to maintain 110 km/h (68 mph) Assist is set to maintain 110 km/h (68 mph) and that there is no vehicle ahead to follow. and that there is no vehicle ahead to follow.
  • Page 319 DRIVER SUPPORT Selecting and activating Pilot The speed must not exceed 140 km/h (87 Reactivating Pilot Assist to last stored • mph). Assist* speed When Pilot Assist is selected – press the The driver must keep his/her hands on the Pilot Assist must first be selected and then •...
  • Page 320 DRIVER SUPPORT Deactivate Pilot Assist* Standby mode for Pilot Assist* WARNING Pilot Assist can be deactivated and switched Pilot Assist can be deactivated and set in With Pilot Assist in standby mode, the • off. standby mode. This can take place due to driver must intervene and steer, regu- driver intervention or automatically.
  • Page 321 DRIVER SUPPORT Temporary disabling of steering Automatic standby mode The speed is below 5 km/h (3 mph) and • Pilot Assist is uncertain whether the vehi- assistance with Pilot Assist* cle ahead is a stationary vehicle or an WARNING Pilot Assist steering assistance can be tem- object, such as a speed bump.
  • Page 322 DRIVER SUPPORT Limitations of Pilot Assist* with poor light conditions, back-light- WARNING ing, wet road surface etc. The Pilot Assist function may have limitations In certain situations, Pilot Assist steering The driver should also note that Pilot Assist in certain situations. assistance may have difficulty helping the has the following limitations: The Pilot Assist function is an aid which can...
  • Page 323 DRIVER SUPPORT data, which may result in varied per- Do not use Pilot Assist if the car has a heavy WARNING formance. load or a trailer is connected to the car. This is not a collision avoidance sys- • Pilot Assist is switched off if the power •...
  • Page 324 Sensor blocked, see Owner's man- Related information A text message can be cleared by briefly If a message remains: Contact a workshop – an authorised Volvo workshop is recom- Pilot Assist* (p. 312) pressing the button, located in the centre •...
  • Page 325 DRIVER SUPPORT Overtaking Assistance* Use Overtaking Assistance WARNING Overtaking Assistance can help the driver Overtaking assistance can be used with The function is supplementary driver • when overtaking other vehicles. The function adaptive cruise control* or Pilot Assist*. There support intended to facilitate driving can be used with adaptive cruise control* or are a number of criteria if Overtaking Assis- and make it safer –...
  • Page 326 DRIVER SUPPORT Warning from driver support in the acoustic warning are activated to alert the WARNING event of a collision risk driver that immediate intervention is required. When using the Overtaking Assistance The driver support systems of adaptive cruise System, the driver should be aware that WARNING control* and Pilot Assist* can warn the driver there may be undesired acceleration if the...
  • Page 327 DRIVER SUPPORT Change of target with driver Set the stored speed for driver WARNING support support When the driver supports are following The driver supports of adaptive cruise con- It is possible to set stored speed for the another vehicle at speeds in excess of trol* and Pilot Assist*, in combination with speed limiter, cruise control, adaptive cruise approx.
  • Page 328 DRIVER SUPPORT Set time interval to vehicle ahead Change a set speed with short presses on Pilot Assist can give steering assistance from – almost stationary up to 140 km/h (87 mph). the steering wheel buttons (1) or It is possible to set the time interval to the (2) or by pressing and holding them.
  • Page 329 DRIVER SUPPORT The adaptive cruise control allows the time Related information NOTE interval to vary significantly in certain situa- Drive modes when using time interval to • When the symbol in the driver display tions in order to allow the car to follow the vehicles (p.
  • Page 330 DRIVER SUPPORT Drive modes when using time Automatic braking with driver WARNING interval to vehicles support Driver supports only warn of obstacles The driver can select different driving styles The driver supports of adaptive cruise con- which their radar unit has detected – for how driver support should maintain the trol* and Pilot Assist* have a special brake hence a warning may not be given, or it...
  • Page 331 DRIVER SUPPORT Lane assistance Related information Cessation of automatic braking In some situations, automatic braking ceases Driving support systems (p. 268) • The function of the Lane Keeping Aid (LKA on coming to a standstill and the function is is to help the driver to reduce the risk of the Adaptive cruise control* (p.
  • Page 332 DRIVER SUPPORT applying a slight torque to the steering WARNING wheel. The function is supplementary driver • Warning activated: If the car is about to • support intended to facilitate driving cross a lane line, the driver is warned by and make it safer –...
  • Page 333 DRIVER SUPPORT Activating or deactivating lane Lane assistance does not intervene Lane Keeping Aid Apply steering • assistance If the driver follows the prompt to start steer- ing, the function is set in standby mode and The Lane Keeping Aid (LKA) function (LKA this message is shown: is optional –...
  • Page 334 DRIVER SUPPORT Selecting assistance option for Limitations of Lane assistance NOTE lane assistance In certain demanding conditions lane assis- This function uses the car's camera and The driver can select how the Lane Keeping tance (LKA ) may have difficulty helping the radar units, which have certain general lim- driver correctly.
  • Page 335 DRIVER SUPPORT Symbols and messages for lane on the driver display. Here are some exam- assistance ples. A number of symbols and messages regar- ding lane assistance (LKA ) can be shown Symbol Message Specification Driver support system The system does not function as it should. A workshop should be contacted Reduced functionality Service required Windscreen sensor The ability of the camera to scan the roadway in front of the car is reduced.
  • Page 336 Lane Keeping Aid LKA is set in standby mode until the driver starts to steer the car again. Standby until steering applied An authorised Volvo workshop is recommended. A text message can be cleared by briefly pressing the button, located in the centre of the steering wheel's right-hand keypad.
  • Page 337 DRIVER SUPPORT Display mode for lane assistance Related information Unavailable Lane assistance (p. 329) • Lane assistance (LKA ) is visualised by sym- bols in the driver display depending on the Limitations of Lane assistance (p. 332) • situation. Here are some examples of symbols and the situations in which they are shown: Unavailable —...
  • Page 338 DRIVER SUPPORT Steering assistance at risk of Related information WARNING collision Driving support systems (p. 268) • The function is supplementary driver • The function Collision avoidance assistance Activating or deactivating steering assis- • support intended to facilitate driving can help the driver reduce the risk of the car tance in the event of a collision risk and make it safer –...
  • Page 339 DRIVER SUPPORT Activating or deactivating steering Steering assistance upon risk of NOTE assistance in the event of a run-off Collision avoidance When the collision risk Steering assistance has a number of subfunc- assistance function is deactivated, all sub- The steering assistance function is optional – tions.
  • Page 340 DRIVER SUPPORT Steering assistance upon risk of driving the car, activation of the function will Steering assistance with brake intervention head-on collision be delayed. Steering assistance has a number of subfunc- Related information tions. Steering assistance upon risk of head- Steering assistance at risk of collision •...
  • Page 341 DRIVER SUPPORT Steering assistance upon risk of The function is active within the speed range the driver to steer the car back into its own rear-end collision* 60-140 km/h (37-87 mph) on roads with lane. clearly visible lane markings/lines. Steering assistance has a number of subfunc- The function can even assist if the driver inten- tions.
  • Page 342 DRIVER SUPPORT Limitations for steering assistance NOTE at risk of collision This function uses the car's camera and In certain situations the function may have radar units, which have certain general lim- limited functionality and fail to intervene in itations. the following cases, for example: for small vehicles, such as motorcycles •...
  • Page 343 A text message can be cleared by briefly pressing the button, located in the centre of the steering wheel's right-hand keypad. If a message remains: Contact a workshop – an authorised Volvo workshop is recom- mended. Related information Steering assistance at risk of collision •...
  • Page 344 DRIVER SUPPORT Limitations of Rear Collision Rear Collision Warning* WARNING Warning* The Rear Collision Warning (RCW) function The function is supplementary driver • In certain cases the Rear Collision Warning can help the driver to avoid being hit by a support intended to facilitate driving (RCW) may have difficulty helping the driver vehicle approaching from behind.
  • Page 345 DRIVER SUPPORT BLIS* NOTE The BLIS function is intended to help the The warning with direction indicators for driver detect vehicles diagonally behind and Rear Collision Warning* is deactivated if to the side of the car so as to provide assis- the warning distance for collision warning tance in heavy traffic on roads with several in the City Safety function is set at the low-...
  • Page 346 DRIVER SUPPORT Activating or deactivating BLIS BLIS is active when the driver's vehicle is trav- WARNING elling at a speed above 10 km/h (6 mph). The BLIS function can be activated or deac- The function is supplementary driver • tivated. If passing vehicles drive more than 15 km/h support intended to facilitate driving Activate or deactivate the...
  • Page 347 DRIVER SUPPORT Limitations of BLIS WARNING The BLIS function may have limitations in BLIS does not work on sharp bends. • certain situations. BLIS does not work when the car is • reversing. NOTE This function uses the car's radar units, which have certain general limitations.
  • Page 348 Blind spot system off BLIS and CTA have been deactivated as a trailer has been connected to the car's electrical system. Trailer attached An authorised Volvo workshop is recommended. Cross Traffic Alert* A text message can be cleared by briefly pressing the button, located in the centre of the steering wheel's right-hand keypad.
  • Page 349 DRIVER SUPPORT Driver Alert Control WARNING The Driver Alert Control (DAC) function is Driver Alert Control should not be used to intended to help make the driver aware that extend a period of driving. The driver he or she is starting to drive less consistently, should instead plan for breaks at regular e.g.
  • Page 350 DRIVER SUPPORT Activating or deactivating Driver Select rest stop guidance in the WARNING Alert Control event of a warning from Driver The function is supplementary driver • Alert Control The Driver Alert Control (DAC) function can support intended to facilitate driving be activated or deactivated.
  • Page 351 DRIVER SUPPORT Limitations of Driver Alert Control Cross Traffic Alert* If CTA senses that something is approaching from the side, this is also indicated with: The Driver Alert Control (DAC) function may Cross Traffic Alert (CTA) is a driver support have limitations in certain situations.
  • Page 352 DRIVER SUPPORT Activating or deactivating Cross explanatory text message on why the car was Limitations of Cross Traffic Alert* (p. 351) • braked. Traffic Alert* Messages for Cross Traffic Alert* (p. 352) • The driver can choose to switch off the Cross BLIS* (p.
  • Page 353 DRIVER SUPPORT Limitations of Cross Traffic However, as your car slowly reverses, the angle it makes with the obstructing vehicle/ Alert* object changes and the blind sector rapidly The Cross Traffic Alert (CTA) function with decreases. auto-brake may have limited functionality in certain situations.
  • Page 354 Blind spot system off BLIS and CTA have been deactivated as a trailer has been connected to the car's electrical system. Trailer attached An authorised Volvo workshop is recommended. Blind Spot Information System A text message can be cleared by briefly pressing the button, located in the centre of the steering wheel's right-hand keypad.
  • Page 355 DRIVER SUPPORT Park Assist* The side sectors change colour as the distance NOTE between the car and an object is reduced. The Parking Assistance System (PAS ) uses Except in the sector nearest to the car sensors to assist the driver when manoeu- The shorter the distance to the obstacle, the symbol, audible warnings are only given for vring in tight spaces by indicating the dis-...
  • Page 356 DRIVER SUPPORT Park Assist Pilot front, rear and Related information NOTE along the sides* Driving support systems (p. 268) • Parking assistance is deactivated when the Park Assist Pilot front, rear and along the Parking Assistance System (PAS ) has dif- •...
  • Page 357 When reversing with e.g. a trailer or bike view. The warning signal pulses intensively at less than carrier on the towbar - without Volvo genu- approx. 25 cm (0.8 ft) from an obstacle. ine trailer wiring - parking assistance may...
  • Page 358 DRIVER SUPPORT Limitations of Parking assistance WARNING IMPORTANT The Parking Assistance System (PAS ) can- Pay additional attention Objects e.g. chains, thin glossy poles or not detect everything in all situations and while reversing when this low barriers may be in the "signal shadow" may therefore have limited functionality in symbol is shown if a and are then temporarily not detected by...
  • Page 359 DRIVER SUPPORT IMPORTANT In certain conditions the parking assistance system may produce incorrect warning signals that are caused by external sound sources with the same ultrasonic frequen- cies that the system works with. Examples of such sources include horns, wet tyres on asphalt, pneumatic brakes, exhaust noises from motorcycles, etc.
  • Page 360 Park Assist System The system does not function as it should. A workshop should be contacted Unavailable Service required An authorised Volvo workshop is recommended. A text message can be cleared by briefly pressing the button, located in the centre of the steering wheel's right-hand keypad.
  • Page 361 DRIVER SUPPORT Park assist camera* Lines - activates/deactivates park assist lines Park assist camera (PAC ) can assist the driver when manoeuvring in tight spaces by Towbar* - activates/deactivates the tow- indicating obstacles with a camera image and bar park assist line* graphics in the centre display.
  • Page 362 DRIVER SUPPORT Park assist camera locations and Activate park assist camera (p. 366) • WARNING surveillance areas* Symbols and messages for Park assist • The function is supplementary driver • camera (p. 367) The Park assist cameras (PAC ) can display support intended to facilitate driving a composite 360°...
  • Page 363 DRIVER SUPPORT A camera symbol on the cen- Objects shown in the centre display may 360° view* tre display's car symbol indi- appear slightly tilted — this is normal. cates which of the cameras is Forwards active. If the car is also equipped with Park Assist System then distance to detected obstacles is illus-...
  • Page 364 DRIVER SUPPORT Park assist lines for park assist lel parking, reversing into tight spaces and The sides camera* when connecting a trailer. The Park assist cameras (PAC ) indicate the The lines on the screen are projected as if they position of the car in relation to its surround- were at ground level behind the car and ings by displaying lines on the screen.
  • Page 365 DRIVER SUPPORT Park assist lines in 360° view* Towbar assist line* IMPORTANT Remember, that with the rear camera • view selected, the monitor only dis- plays the area behind the car. Be aware of the sides and front of the car when manoeuvring in reverse.
  • Page 366 DRIVER SUPPORT Sensor fields for parking Press Towbar (1). Sensor fields backwards and forwards assistance system > The park assist lines for the towbar's intended "path" appear - the car's park If the car is equipped with the Parking Assis- assist lines disappear simultaneously.
  • Page 367 DRIVER SUPPORT obstacle decreases – from AMBER through The colour of the side fields changes with ORANGE to RED. reduced distance to the obstacle – from AMBER to RED. Field colour Distance in metres reverse (feet) Colour of side Distance in metres fields (feet) Yellow...
  • Page 368 DRIVER SUPPORT Activate park assist camera Automatic deactivation of camera The front view extinguishes at 25 km/h The park assist camera (PAC ) is activated (16 mph) to avoid distracting the driver – it automatically when reverse gear is engaged reactivates automatically if the speed drops to or manually with one of the centre display's 22 km/h (14 mph) within 1 minute, on the con-...
  • Page 369 One or more of the function's sensors are blocked - check and correct as soon as possible. Sensors blocked, cleaning nee- Park Assist System The system does not function as it should. A workshop should be contacted Unavailable Service required An authorised Volvo workshop is recommended. Park Assist Camera...
  • Page 370 DRIVER SUPPORT A text message can be cleared by briefly pressing the button, located in the centre of the steering wheel's right-hand keypad. If a message persists, contact a workshop Related information Park assist camera* (p. 359) • Limitations for camera and radar unit •...
  • Page 371 DRIVER SUPPORT Park Assist Pilot* Leaving parallel parking with Park Assist • WARNING Pilot* (p. 374) Park Assist Pilot (PAP ) can assist the driver The function is supplementary driver • to manoeuvre the car while parking. The Limitations of Park Assist Pilot* (p. 374) •...
  • Page 372 DRIVER SUPPORT Parking variants with Park Assist Related information Perpendicular parking Pilot* Park Assist Pilot* (p. 369) • Park Assist Pilot (PAP ) can be used for Leaving parallel parking with Park Assist • both parallel and perpendicular parking. Pilot* (p. 374) Parallel parking Principle for perpendicular parking.
  • Page 373 DRIVER SUPPORT Using Park Assist Pilot* NOTE Park Assist Pilot (PAP ) helps the driver The distance between the car and parking park via three steps. The function can also spaces should be 0.5–1.5 metres help the driver to leave a parking space. (1.6–5.0 ft) while the function is searching This function measures space and steers the for a parking space.
  • Page 374 DRIVER SUPPORT Tap on the Park In button in the function 2. Reverse slowly and carefully without Reversing in to the parking space view or in the camera view. touching the steering wheel - and no faster than 7 km/h (4 mph). >...
  • Page 375 DRIVER SUPPORT Move the gear selector to the gear posi- or behind the car during a parking manoeuvre, Positioning the car in the parking space tion as instructed by the system, wait until the car is auto-braked to stationary. the steering wheel has been turned and The driver display then shows a pop-up mes- drive forward slowly.
  • Page 376 DRIVER SUPPORT Leaving parallel parking with Park Limitations of Park Assist Pilot* 3. Be prepared to stop the car when instruc- Assist Pilot* ted by the graphic and message on the The Park Assist Pilot (PAP ) function cannot centre display - follow the instructions in Park Out function can help the driver to detect everything in all situations and may...
  • Page 377 DRIVER SUPPORT Parking is discontinued There are also a few details to bear in mind IMPORTANT while parking, e.g.: A parking sequence will be discontinued: Under certain circumstances, the function The driver is always responsible for deter- if the driver moves the steering wheel •...
  • Page 378 DRIVER SUPPORT parked car is protruding more than other parked cars. The function is designed for parking on • straight streets – not sharp curves or bends. For this reason, make sure the car is parallel to the potential parking spaces when the function measures the space.
  • Page 379 Park Assist System The system does not function as it should. A workshop should be contacted Unavailable Service required An authorised Volvo workshop is recommended. A text message can be cleared by briefly pressing the button, located in the centre of the steering wheel's right-hand keypad.
  • Page 380 DRIVER SUPPORT Radar unit Related information Driving support systems (p. 268) • The radar unit is used by several driver sup- port systems and has the task of sensing Limitations for camera and radar unit • other vehicles. (p. 387) Recommended maintenance for camera •...
  • Page 381 DRIVER SUPPORT Type approval for radar device Here you can find type approval for the car's radar units for adaptive cruise control* (ACC ), Pilot Assist* and BLIS* Market BLIS Symbol Type approval & PA ✓ Botswana Este equipamento opera em caráter secundário, isto é, não tem direito à proteção contra interferência prejudicial, mesmo de estações do mesmo tipo, e não pode causar interferência a sistemas operando em caráter primário.
  • Page 382 DRIVER SUPPORT Market BLIS Symbol Type approval & PA Hereby, Delphi Electronics and Safety declares that L2C0054TR / L2C0055TR are in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU (RED). The original declaration of conformity can be accessed at the following link www.delphi.com/automotive-homologation.
  • Page 383 DRIVER SUPPORT Market BLIS Symbol Type approval & PA 37295/POSTEL/2014 ✓ 4927 Certificate number: 50459/SDPPI/2017 Indonesia Country of origin Germany ✓ Certificate number: 53578/SDPPI/2017 Country of origin China PLG ID: 6051 ✓ Jamaica This product contains a Type Approved Module by Jamaica: SMA – “RS4”. Type Approval No.: TRC/LPD/2014/255 ✓...
  • Page 384 DRIVER SUPPORT Market BLIS Symbol Type approval & PA ✓ IFETEL: RLVDEL215-0299 Radar de corto alcance Hella KGaA Hueck & Co Mexico ✓ IFETEL: RLVHERS17-0286 La operación de este equipo esta sujeta a las siguientes dos condiciones: (1) es posible que este equipo o dispositivo no cause interferencia perjudicial y (2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su operación no deseada.
  • Page 385 DRIVER SUPPORT Market BLIS Symbol Type approval & PA ✓ Russia ✓ И011 14 Serbia ✓ И011 17 ✓ DA 105753 Singapore ✓ DA 103238 ✓ TA-2014/1824 South Africa ✓ TA-2016/3407...
  • Page 386 DRIVER SUPPORT Market BLIS Symbol Type approval & PA Certification No. ✓ MSIP-CMI- DPH-L2C0054TR South Korea R-CMM-HLA-RS4 ✓ 이 기기는 무용(A급) 전자파 적합기기로서 판 매자 또는 사용 자는 이 점을 주의하시기 바 라 며, 가정외의 지역에서 사용 하는 것을 적으 로 합니다 ✓...
  • Page 387 DRIVER SUPPORT Market BLIS Symbol Type approval & PA є, є Delphi RACAM/SRR2 ь КМ № 679 2009 .) ✓ ь Delphi : Delphi. : 24,05 – 24,25 ь : 20 .) EIRP Ukraine є, HELLA GmbH & Co. KGaA є...
  • Page 388 DRIVER SUPPORT Type approval for radio equipment Market Symbol Type approval Hereby, Volvo cars, declares that all radio equipment's are in compliance with the essential requirements and other Europe relevant provisions of Directive 2014/53/EU. R 204-750001 Japan This device is granted pursuant to the Japanese Radio Law and the Japanese Telecommunications Business Law. This device should not be modified (otherwise the granted designation number will become invalid).
  • Page 389 DRIVER SUPPORT Camera unit Limitations for camera and radar Related information unit Driving support systems (p. 268) • The camera unit is used by several driver sup- port systems and has the task of for example The camera and radar unit has certain limita- Limitations for camera and radar unit •...
  • Page 390 – the High temperature entire windscreen should be replaced At very high temperatures the camera and instead. radar unit can temporarily be switched off for An authorised Volvo workshop is recommended.
  • Page 391 DRIVER SUPPORT vehicle that drives in between your car and dust storms and snow flurries. Under such Limited field of vision the vehicle ahead. conditions, the functions of camera-depend- The radar unit has a limited field of vision. In ent systems could be significantly reduced or some situations another vehicle is not Small vehicles, such as motorcycles, or temporarily disengaged.
  • Page 392 Park assist camera* (p. 359) • There are "blind" sectors between the cameras' fields of vision. Volvo Cars support site (p. 21) • In the park assist camera's 360° view* obsta- cles/objects may "vanish" in the gaps between the individual cameras.
  • Page 393 Clean camera lenses regularly with luke- • warm water and car shampoo - be careful not to scratch the lenses. IMPORTANT Maintenance of driver support components must only be performed at a workshop – an authorised Volvo workshop is recom- mended. * Option/accessory.
  • Page 394 Dirt has appeared between the inside of the windscreen and the Visit a workshop to have the windscreen inside the unit's cover cleaned - an camera and radar unit. authorised Volvo workshop is recommended. Strong oncoming light No action. The camera unit is reset automatically in more favourable light con-...
  • Page 395 Limitations for camera and radar unit • (p. 387) The car's left-hand camera is out of order. Volvo Cars support site (p. 21) • A black camera sector is also shown in the fol- lowing instances, but then without the sym-...
  • Page 397 STARTING AND DRIVING...
  • Page 398 STARTING AND DRIVING Starting the car To start the car: The car is started using the start button The remote control key must be inside the beside the steering wheel when the remote car. For cars with Passive Start, the key control key is in the passenger compartment.
  • Page 399 STARTING AND DRIVING Switching off the car Adjusting the steering wheel (p. 182) • IMPORTANT The car is switched off using the start button Using jump starting with another battery • If the engine fails to start after 3 attempts - beside the steering wheel.
  • Page 400 STARTING AND DRIVING Ignition positions Using jump starting with another battery • Level Functions (p. 446) The car's electrical system can be set in dif- Odometer, clock and tempera- • ferent levels/positions and in this way make Selecting ignition mode (p. 399) •...
  • Page 401 STARTING AND DRIVING Selecting ignition mode Ignition position I – Depress the start • Level Functions button and release. The car's electrical system can be set in dif- The headlamps come on. • ferent levels/positions and in this way make Ignition position II –...
  • Page 402 The car has an interface for the electrical con- nection of the different makes and models of Before starting the engine with the alcohol • alcohol lock recommended by Volvo. The lock* (p. 401) interface facilitates alcohol lock connection, Starting the car (p. 396) •...
  • Page 403 STARTING AND DRIVING Before starting the engine with the Brake functions Foot brake alcohol lock* The car's brakes are used to reduce the The foot brake is part of the brake system. speed or prevent the car from rolling. The car is equipped with two brake circuits. If The alcohol lock is activated automatically In addition to the foot brake and parking a brake circuit is damaged, the brake pedal...
  • Page 404 The test may be felt as pulses in brake system checked - an authorised The function is suspended when the pressure the brake pedal. Volvo workshop is recommended. on the brake pedal decreases. Symbols in the driver display If the brake fluid is below the MIN level •...
  • Page 405 To keep the car as safe and reliable as possi- using the brakes. This may extend braking distance. You should ble, follow the Volvo service intervals as speci- This may also be the case after a car wash. It therefore maintain a greater safety distance to fied in the Service and Warranty Booklet.
  • Page 406 STARTING AND DRIVING Parking brake Activating and deactivating the Related information parking brake Activating and deactivating the parking • The parking brake prevents the car from roll- brake (p. 404) ing away from stationary by means of Use the parking brake to prevent the car from mechanically locking/blocking two wheels.
  • Page 407 STARTING AND DRIVING 2. With automatic gearbox: Symbol in the driver display NOTE Symbol Specification Depress the brake pedal firmly. Select An acoustic signal sounds while emer- gear position D or R and depress the gency braking is active at high speeds. The symbol is illuminated when accelerator pedal.
  • Page 408 Always use the parking brake when parking on a hill. Choose whether the parking brake is to be Contact an authorised Volvo workshop if it is activated automatically when the car is not possible to deactivate or activate the WARNING switched off.
  • Page 409 Parking on a hill (p. 406) • released to ensure the car does not roll. Starter battery (p. 585) • Volvo service programme (p. 570) • The parking brake is activated if the car is switched off • the driver's door is opened •...
  • Page 410 STARTING AND DRIVING Activating and deactivating the Help when starting on a hill The function remains deactivated until it is • automatic brake at a standstill reactivated. Hill start assist (HSA ) prevents the car from The automatic brake function at a standstill is When the function is deactivated, hill start rolling backwards when starting on an uphill •...
  • Page 411 STARTING AND DRIVING Auto braking after a collision Regenerative braking* Gearbox In the event of a collision in which the activa- The car recovers kinetic energy during brak- The gearbox is part of the car's powertrain tion level is reached for the pyrotechnic seat- ing in order to reduce fuel consumption and (power transmission) between engine and belt tensioners or airbags, or if a collision...
  • Page 412 STARTING AND DRIVING Manual gearbox Automatic gearbox Follow the shifting pattern on the gear • lever and start from neutral position before With a manual gearbox, the driver selects a Gears are selected automatically so that you moving it to the R position. suitable gear manually, according to speed can drive as energy-efficiently as possible.
  • Page 413 STARTING AND DRIVING Changing gear with automatic Gear positions Manual gearbox (p. 410) • gearbox Symbols and messages for automatic • Parking – P gearbox (p. 415) Change gear position by pressing the spring- loaded gear selector forwards or backwards, or sideways for manual shifting.
  • Page 414 STARTING AND DRIVING In M position, it is possible to change gear Neutral – N WARNING manually. The car engine-brakes when the Select N position when the car shall be Always use the parking brake when park- accelerator pedal is released. started.
  • Page 415 STARTING AND DRIVING Changing gear with steering wheel In M position the steering wheel paddles are paddles* automatically activated. The steering wheel paddles are a comple- ment to the gear selector and make it possi- ble to change gear manually without releas- ing hands from the steering wheel.
  • Page 416 STARTING AND DRIVING Gear selector inhibitor Kick-down function Related information Automatic gearbox (p. 410) • The gear selector inhibitor prevents acciden- Kick-down can be used when maximum tal changing between different gear positions acceleration is needed such as for overtaking. Changing gear with automatic gearbox •...
  • Page 417 STARTING AND DRIVING Symbols and messages for Gear shift indicator Related information automatic gearbox Automatic gearbox (p. 410) • The gear shift indicator in the driver display shows the current gear during manual gear- If a fault should occur in the gearbox, a sym- shifting and when it is appropriate to engage bol and a message are shown in the driver display.
  • Page 418 STARTING AND DRIVING All-wheel drive* Drive modes* With automatic gearbox Selection of drive mode affects the car's driv- All-wheel drive (AWD ) means that the car is ing characteristics in order to enhance the driving all four wheels at the same time, driving experience and facilitate driving in which improves traction.
  • Page 419 STARTING AND DRIVING When the Individual mode is selected, it is Dynamic mode is also available in the control (HDC ) are activated. Start/Stop func- possible to make adjustments for specific Polestar Engineered tion is deactivated. version*. preferences, e.g. to show the tachometer. The drive mode can only be activated at low Comfort speeds and the speedometer shows the range...
  • Page 420 STARTING AND DRIVING 3. In Presets , select a drive mode to start Individual Comfort Dynamic Adapting a drive mode according to indi- from: • vidual preferences. Polestar Engineered Select a drive mode to start from, and then Possible adjustments apply to settings for: adjust the settings according to the desired Driver Display •...
  • Page 421 STARTING AND DRIVING Changing drive mode* Drive mode Eco 2. Select the drive mode in one of two ways: Select the drive mode adapted for the current Drive mode can help you with more eco- Tap the desired drive mode directly on •...
  • Page 422 STARTING AND DRIVING engine whose speed is reduced to idling the road's downhill gradient is steeper Cruise control Eco Cruise • speed with reduced consumption. than approx. 6% When using the cruise control in the drive mode, the car's acceleration and deceleration Manual gear changing is performed with •...
  • Page 423 STARTING AND DRIVING Activating and deactivating drive Eco gauge in the driver display NOTE mode Eco with the function button When the drive mode is activated, There is a function button for drive mode several parameters in the climate control in the centre display's function view unless system's settings are changed, and several the car was equipped with a drive mode but-...
  • Page 424 STARTING AND DRIVING Start/stop function Driving with start/stop function With manual gearbox With the start/stop function, the engine The start/stop function temporarily switches Declutch, set the gear lever in neutral • switches off temporarily when the car has off the engine when stationary and then position and release the clutch pedal - the stopped e.g.
  • Page 425 STARTING AND DRIVING With automatic gearbox begins to roll - the engine will auto-start after a slight speed increase. Release the brake pedal - the engine will • autostart and you can continue driving. On Symbols in the driver display an uphill gradient hill start assist (HSA engages, which prevents the car from roll- ing backwards.
  • Page 426 STARTING AND DRIVING Deactivating the start/stop Conditions for the Start/Stop The bonnet is opened. • function function When driving at high altitudes when the • In certain situations it may be desirable to For the Start/Stop function to work requires engine has not reached operating tem- deactivate the start/stop function.
  • Page 427 STARTING AND DRIVING With manual gearbox: The following applies to automatic gearbox: The driver is unrestrained. The driver's seatbelt buckle is opened with • • the gear selector in D or N position. A gear is engaged without declutching. • The gear selector is moved from D to R or •...
  • Page 428 On a car equipped with Four-C the shock absorption is adapted according to the drive Symbol Message Specification Suspension A fault has occurred. Visit a workshop as soon as possible. Service required An authorised Volvo workshop is recommended. Related information Drive modes* (p. 416) • * Option/accessory.
  • Page 429 STARTING AND DRIVING Low speed control* Activating and deactivating low- NOTE speed driving* using a function The low speed control function (LSC ) facili- When LSC with HDC is activated, the feel button tates and improves traction for driving off- of the accelerator pedal and engine road and on slippery surfaces, such as with a response are changed.
  • Page 430 STARTING AND DRIVING Hill descent control* Related information regardless of the gradient of the hill and with- out the need for the foot brake to be used. The Low speed control* (p. 427) • Hill descent control (HDC ) is a low speed brake lights are switched on when the func- function with enhanced engine braking.
  • Page 431 STARTING AND DRIVING Activating and deactivating hill Points to remember when driving with NOTE descent control* with the function The function is deactivated when driving at button If the function is disabled while driving on • higher speeds and must be reactivated at a a steep downhill gradient, the braking There is a function button for hill descent lower speed, if required.
  • Page 432 STARTING AND DRIVING Economical driving Related information Do not run the engine to operating tem- • perature at idling speed, but rather drive Hill descent control* (p. 428) • Drive economically and in a more eco-friendly with a normal load right after starting – a way by driving gently and anticipating situa- Changing drive mode* (p.
  • Page 433 STARTING AND DRIVING Preparations for a long trip Recommendations for loading (p. 558) • WARNING Before a driving holiday or some other type of Driving with a trailer (p. 453) • Never switch off the engine while moving, long journey, it is important to check the car's such as downhill, this deactivates impor- Pilot Assist* (p.
  • Page 434 STARTING AND DRIVING Winter driving Driving in water Slippery driving conditions To achieve optimum roadholding Volvo recom- For winter driving it is important to perform Wading means the car being driven through mends using winter tyres on all wheels if there certain checks of the car in order to ensure water e.g.
  • Page 435 2. Choose fuel that is approved for use in the car. See information on approved fuels in the sections on "Petrol" and "Diesel" respectively. Only locking and unlocking with the remote control key, keyless* or via Volvo On Call affects the status of the fuel filler flap. * Option/accessory.
  • Page 436 The filler pipe has two opening Do not use fuel with a lower quality than that caps. The pump nozzle must be pushed recommended by Volvo, as this will nega- past both caps before refuelling is started. tively affect engine power and fuel consump- tion.
  • Page 437 Petrol is available with different fuels which are not recommended will aging the catalytic converter. octane ratings that are adapted for different invalidate Volvo's guarantees and any sup- Fuel containing metallic additives must • types of driving. plementary service agreements; this is not be used.
  • Page 438 STARTING AND DRIVING Diesel Petrol particle filter traffic, it is important to regularly drive at higher speeds to allow the emissions system It is important to use the correct fuel during Petrol cars are fitted with particle filters for to regenerate. refuelling.
  • Page 439 Stop the car on as flat/level ground as • damage that is not covered by the Volvo possible - if the car is tilting there is a warranty. risk of air pockets in the fuel supply.
  • Page 440 STARTING AND DRIVING Diesel particulate filter area. Make sure you insert the funnel's pipe IMPORTANT firmly into the filler pipe. The filler pipe has two Diesel cars are fitted with particle filters for If the filter is completely filled with parti- opening caps.
  • Page 441 STARTING AND DRIVING ®23 Related information Emission control with AdBlue AdBlue. If something is wrong, a message is shown in the driver display. Diesel (p. 436) • AdBlue is an additive used in the SCR sys- ® Emission control with AdBlue (p.
  • Page 442 STARTING AND DRIVING ®26 Related information Handling AdBlue Storage ® AdBlue must be stored in tightly sealing origi- • Handling AdBlue (p. 440) AdBlue consists primarily of water (approx. nal packaging at a temperature above -11 °C ® 67.5% water and 32.5% urea). The fluid is •...
  • Page 443 STARTING AND DRIVING ® Checking and filling with AdBlue Checking AdBlue level Check the AdBlue level regularly and top up if the message for low AdBlue level is shown in the driver display. The AdBlue consumption is dependent on driving style, if the AdBlue tank is allowed to drain completely then it will no longer be pos- sible to start the car.
  • Page 444 STARTING AND DRIVING Filling 3. Fill with AdBlue of the correct quality When the AdBlue level starts Do not overfill the tank. The amount of to become low, a symbol illu- AdBlue that can be filled is shown in the minates in the driver display Car Status AdBlue level low...
  • Page 445 STARTING AND DRIVING Symbols and messages for ®28 AdBlue The emission control system continuously monitors the level, quality and dosage of AdBlue. If something is wrong, a message is shown in the driver display. Symbol Message Specification AdBlue level low The AdBlue level is low and the tank needs to be topped up.
  • Page 446 Engine start prohibited The system does not function as it should. Contact a workshop to check the function. Service of AdBlue system nee- ded to allow restart An authorised Volvo workshop is recommended. Related information ® • Checking and filling with AdBlue (p.
  • Page 447 STARTING AND DRIVING Overheating in the engine and lower temperature Transmission hot Symbols in the driver display drive system Stop safely, wait for cooling . Follow the Symbol Specification recommendation given, reduce speed or Under certain conditions, e.g. hard driving in stop the car in a safe way and allow the High engine temperature.
  • Page 448 STARTING AND DRIVING Overloading the starter battery Using jump starting with another 4. Connect one of the red jump lead's battery clamps to the donor battery's positive ter- The electrical functions in the car load the minal (1). starter battery to varying degrees. Avoid If the starter battery is discharged then the using the ignition position II when the car is car can be started with current from another...
  • Page 449 – an lead's clamps comes into contact with the If sulphuric acid comes into contact • authorised Volvo workshop is recom- car's positive jump-starting point/donor with eyes, skin or clothing, flush with mended. battery's positive terminal or the clamp large quantities of water.
  • Page 450 There may be different towbar variants availa- started with an external battery or a battery ble for the car. Contact a Volvo dealer for more charger, the Start/stop function may con- information.
  • Page 451 STARTING AND DRIVING Specifications for towbar* Related information Dimensions, mounting points in mm Extendable and retractable towbar* • Dimensions and mounting points for towbar. (inches) (p. 450) 939 (37) Driving with a trailer (p. 453) • 72 (2.8) Towbar-mounted bicycle rack* (p. 456) •...
  • Page 452 STARTING AND DRIVING Extendable and retractable 2. Press and release the button – extension towbar* might not start if the button is pressed for too long. The retractable tow hook is easy to retract or extend as required. In the retracted position, the towbar is completely concealed.
  • Page 453 STARTING AND DRIVING NOTE Power save mode activates after a while and the indicator lamp goes out. The sys- tem is reactivated by closing and opening the tailgate. This applies when retracting or extending the towbar. If the car detects a connected trailer elec- trically, the indicator lamp stops illuminat- ing with a constant glow.
  • Page 454 Removable towbar* Install the ball holder Store the ball holder If necessary, remove the split pin from the Volvo recommends use of Volvo's towbars, locking bolt and slide the lock bolt out of which are specifically designed for the car. WARNING the towbar unit.
  • Page 455 The brakes are loaded much more than • load (up to the maximum permissible weight). connector. Use an adapter approved by Volvo. usual on long and steep downhill slopes. When the car is stationary the rear of the car Make sure the cable does not drag on the Downshift to a lower gear when shifting lowers slightly, which is normal.
  • Page 456 STARTING AND DRIVING Trailer stability assist* When driving in hilly terrain and hot 4. Release the brake pedal and start driving off. climates The function of trailer stability assist (TSA Under certain circumstances, there may be a is to stabilise cars towing trailers in situations Related information risk of overheating when towing a trailer.
  • Page 457 STARTING AND DRIVING Checking trailer lamps serves to stabilise the car/trailer combination. When Trailer Stability Assist This is often enough to help the driver regain (TSA) is operating, the ESC When connecting a trailer - check that all the control of the car. symbol flashes in the driver trailer lamps work before departure.
  • Page 458 The automatic checking function can be therefore that the trailer is equipped with a safety during a journey. Volvo's bicycle racks switched off in the centre display. rear fog lamp to travel safely.
  • Page 459 P unless the engine is The larger the distance between the load's running. Contact an authorised Volvo centre of gravity and the towball, the greater workshop for assistance when towing, or the load on the towbar.
  • Page 460 STARTING AND DRIVING 5. Move the gear selector to neutral position Using jump starting with another battery • WARNING and release the parking brake. (p. 446) Check that the steering lock is • Selecting ignition mode (p. 399) • If the battery voltage is too low, the park- unlocked before towing.
  • Page 461 STARTING AND DRIVING Fitting and removing the towing Use the towing eye for towing. The towing eye is screwed into a threaded socket behind a cover on the right-hand side of the bumper, front or rear. Fitting the towing eye Front: Remove the cover - press on the Rear: Remove the cover –...
  • Page 462 STARTING AND DRIVING Recovery 4. Screw in the towing eye until it reaches its may be damaged if you try to pull it up end stop. using the towing eye. For recovery, the car is taken away with the help of another vehicle. If necessary, raise the car by using the •...
  • Page 463 STARTING AND DRIVING ® ® HomeLink HomeLink is supplied built-in to the interior IMPORTANT ® rearview mirror. The HomeLink panel con- ®33 HomeLink is a programmable remote con- Note that the car must always be transpor- sists of three programmable buttons and one trol, integrated in the car's electrical system, ted with the wheels rolling forward.
  • Page 464 STARTING AND DRIVING ® Programming HomeLink Aim the remote control towards the 3. Do not release the buttons until the indica- ® tor lamp has switched from flashing HomeLink button to be programmed and Follow these instructions to program slowly (approx. once per second) to either hold it approx.
  • Page 465 STARTING AND DRIVING call 00 8000 466 354 65 (or the toll number Related information ® +49 6838 907 277) • Using HomeLink * (p. 464) ® • HomeLink * (p. 461) Reprogramming individual buttons ® ® To reprogram an individual HomeLink button, •...
  • Page 466 STARTING AND DRIVING ® ® Using HomeLink Type approval for HomeLink WARNING ® When HomeLink is fully programmed it can ® • If HomeLink is used to control a Type approval for EU be used in place of the separate original garage door or gate, ensure that Gentex Corporation hereby declares that remote controls.
  • Page 467 STARTING AND DRIVING Compass* Activating and deactivating the Calibrating the compass* compass* The upper right-hand corner of the rearview The earth is divided into 15 magnetic zones. mirror has an integrated display that shows The upper right-hand corner of the rearview The compass should be calibrated if the car the compass direction...
  • Page 468 STARTING AND DRIVING 7. Cars with heated windscreen*: If the character is shown in the display when the heated windscreen is activated, per- form the calibration in accordance with point 6 above with the heated windscreen activated. 8. Repeat the above procedure as necessary. Related information Compass* (p.
  • Page 469 SOUND, MEDIA AND INTERNET...
  • Page 470 SOUND, MEDIA AND INTERNET Sound, media and Internet Audio settings Related information Media player (p. 478) • The audio and media system consists of The sound reproduction quality is preset, but media player and radio. You can also connect it can be adjusted as well. Radio (p.
  • Page 471 SOUND, MEDIA AND INTERNET Sound experience* Apps Control Park Assist Phone Ringtone Sound experience is an app that provides The app view contains apps that give access access to further audio settings. to some of the car's services. High Performance* Sound Experience is opened from the app Swipe from right to left...
  • Page 472 SOUND, MEDIA AND INTERNET Downloading apps Some basic apps are always available. More 3. Tap on the row for an app in order to apps such as web radio and music services expand in the list and get more informa- New apps can be downloaded when the car can be downloaded when the car is connected tion about the app.
  • Page 473 SOUND, MEDIA AND INTERNET Updating apps Deleting apps Update some Download Centre Open the app in the The apps can be updated when the car is Apps can be uninstalled when the car is con- app view. connected to the Internet. nected to the Internet.
  • Page 474 SOUND, MEDIA AND INTERNET Radio Start radio Settings for radio (p. 475) • The radio is started from the centre display It is possible to listen to the AM and FM Digital radio* (p. 477) • app view. radio frequency bands and to digital radio RDS radio (p.
  • Page 475 SOUND, MEDIA AND INTERNET Changing radio band and radio Related information 2. Select playback from Stations station Radio (p. 472) Favourites Genres Ensembles • There are instructions here for changing the Searching for radio stations (p. 474) • 3. Tap on the desired station from the list. radio band, the list in the radio band and the Changing radio band and radio station •...
  • Page 476 SOUND, MEDIA AND INTERNET Searching for radio stations Manual tuning Related information Radio (p. 472) • The radio automatically compiles a station list of the radio stations within the area that are Start radio (p. 472) • transmitting the strongest signals. Changing radio band and radio station •...
  • Page 477 SOUND, MEDIA AND INTERNET Save radio channels in the Radio Settings for radio from a manual station search, the radio does Favourites app not automatically change to a stronger fre- There are various radio functions to activate quency. and deactivate. It is possible to add a radio channel to the Radio favourites app and the favourites list...
  • Page 478 SOUND, MEDIA AND INTERNET Traffic Announcements : interrupts the the message. Playback of previous media AM/FM Radio current media playback and broadcasts source is resumed when the message is Show Broadcast Information : shows • information about traffic disruptions. Play- finished.
  • Page 479 SOUND, MEDIA AND INTERNET RDS radio Digital radio* Related information Radio (p. 472) • RDS (Radio Data System) means that the Digital radio (DAB ) is a digital broadcasting radio automatically changes to the strongest system for radio. The radio supports DAB, Settings for radio (p.
  • Page 480 SOUND, MEDIA AND INTERNET Link between FM and digital radio* Media player DAB subchannel Secondary components are usually named The function enables the digital radio (DAB) The media player can play back audio from subchannels. These are temporary and can to switch from a channel with poor or no external audio sources connected via the contain e.g.
  • Page 481 SOUND, MEDIA AND INTERNET Media playback Related information USB memory Media playback (p. 479) Insert the USB memory. • The media player is controlled from the cen- tre display. Several functions can also be Controlling and changing media (p. 480) •...
  • Page 482 SOUND, MEDIA AND INTERNET Controlling and changing media Related information Bluetooth connected device Activate Bluetooth in the media source. Managing the app menu in the driver dis- • The playback of media can be controlled with play (p. 94) voice control, steering wheel keypad or the 2.
  • Page 483 SOUND, MEDIA AND INTERNET Searching media Change track/song - tap on the desired track Similar - tap on the button in order to use Gracenote to in the centre display, press on It is possible to search by artist, composer, search for similar music on under the centre display or on the steering song titles, album, video, audio book, playlist...
  • Page 484 SOUND, MEDIA AND INTERNET ® Media playback (p. 479) Gracenote Updating Gracenote • The content of the Gracenote database is Enter the characters, letters and words Gracenote identifies artist, album, song titles • updated continuously. Download the latest manually in the centre display (p. 119) and associated images, which are shown dur- update to take advantage of improvements.
  • Page 485: Playing Back Divx

    SOUND, MEDIA AND INTERNET ® Video Playing a video Playing back DivX Videos on USB-connected devices can be Videos are played using the app in the ® This DivX Certified device must be regis- played back using the media player. app view.
  • Page 486: Settings For Video

    SOUND, MEDIA AND INTERNET ® ® Settings for video Media via Bluetooth Connecting a device via Bluetooth Certain language settings can be changed for ® The car's media player is equipped with Connect a Bluetooth device to the car for video playback.
  • Page 487: Media Via Usb Port

    SOUND, MEDIA AND INTERNET Media via USB port Connecting a device via USB port ® An external audio source, e.g. an iPod® or An external audio source, e.g. an iPod MP3 player, can be connected to the audio MP3 player, can be connected to the audio system via the car's USB port.
  • Page 488: Technical Specifications For Usb

    SOUND, MEDIA AND INTERNET Technical specifications for USB Compatible media formats Voltage supply 5 V • devices The following file formats must be used for Current supply max. 3.0 A • media playback. The following specifications must be met to Related information allow the contents of the USB devices to be Audio files...
  • Page 489: Apple ® Carplay

    ® • Playing back DivX (p. 483) broken. Please note that Volvo is not responsi- When you see the DivX logo, you have the ble for the content in CarPlay. freedom to play DivX films. When using map navigation via CarPlay no...
  • Page 490: Using Apple ® Carplay

    Bluetooth will there- (including its position) is transferred to fore not be available when CarPlay is your iPhone. In relation to Volvo Cars, you active. An alternative Internet source must are fully responsible for your and any be used to connect to the Internet for the others person’s use of Apple CarPlay.
  • Page 491 SOUND, MEDIA AND INTERNET Switch the connection between Connect the car to the Internet via a Starting CarPlay • phone (Wi-Fi) (p. 506) To start CarPlay from an iOS device that has CarPlay and iPod been connected previously: Connect the car to the Internet via car •...
  • Page 492: Settings For Apple ® Carplay

    SOUND, MEDIA AND INTERNET ® ® ® ® Settings for Apple CarPlay Tips for using Apple CarPlay 2. Tap on Sound System Volumes make the settings for the following: ® Settings for iOS device connected with Here are some useful tips for using CarPlay Update your iOS device with the latest CarPlay •...
  • Page 493: Android Auto

    When you use auto/. For third-party apps, see Google Play. NOTE Android Auto, your car transfers certain Please note that Volvo is not responsible for information (including its location) to your Availability and functionality may vary the content in Android Auto.
  • Page 494: Using Android Auto

    SOUND, MEDIA AND INTERNET Using Android Auto* Settings for Android Auto* Previously connected Android Connect your device to the USB input To use the Android Auto app, the app must Settings for an Android device that has been with a white frame. be installed on your Android device and the connected the first time with Android Auto.
  • Page 495: Tips For Using Android Auto

    SOUND, MEDIA AND INTERNET Tips for using Android Auto* Related information Related information Android Auto* (p. 491) Android Auto* (p. 491) • • Here are some useful tips for using Android Auto. Using Android Auto* (p. 492) Connect the car to the Internet via a •...
  • Page 496: Phone

    SOUND, MEDIA AND INTERNET Phone Overview Connecting a phone to the car via Blue- • tooth automatically (p. 496) A phone with Bluetooth can be connected wirelessly to the car's built-in hands-free sys- Connecting a phone to the car via Blue- •...
  • Page 497 SOUND, MEDIA AND INTERNET Connecting a phone to the car via 2. Open the phone tile in the centre display. Option 2 - search car from phone Bluetooth for the first time Open the phone tile in the centre display. If there is no phone connected to the •...
  • Page 498: Connecting A Phone To The Car Via Bluetooth Automatically

    SOUND, MEDIA AND INTERNET Connecting a phone to the car via Removing devices connected to Bluetooth • NOTE Bluetooth automatically (p. 498) The message function must be acti- • Settings for Bluetooth devices (p. 502) It is possible to connect a phone to the car •...
  • Page 499: Connecting A Phone To The Car Via Bluetooth Manually

    SOUND, MEDIA AND INTERNET Connecting a phone to the car via Disconnecting a Bluetooth- Connect the car to the Internet via a Blue- • Bluetooth manually connected phone tooth-enabled phone (p. 506) Ignition positions (p. 398) It is possible to connect a phone to the car It is possible to disconnect a phone con- •...
  • Page 500: Switch Between Bluetooth- Connected Phones

    SOUND, MEDIA AND INTERNET Switch between Bluetooth- Removing devices connected to Managing phone calls connected phones Bluetooth Call handling in the car for a Bluetooth-con- nected phone. It is possible to switch between a number of It is possible to remove phones from the list Bluetooth-connected phones.
  • Page 501: Managing Text Messages

    SOUND, MEDIA AND INTERNET Private call Managing text messages Making multi-party calls During a call: Privacy During the current call, press – Message handling in the car for a Bluetooth- select setting: connected phone. Add call Press In some phones, the message function must Switch to mobile phone - the hands- •...
  • Page 502: Settings For Text Messages

    – keypad. A dictation dialogue starts. Valid in certain markets only. Contact a Volvo dealer for more information. Only certain phones can send messages via the car. The connected phone must support the Bluetooth Message Access Profile (MAP). * Option/accessory.
  • Page 503: Managing The Phone Book

    SOUND, MEDIA AND INTERNET Managing the phone book Settings for phone sorted under . It is possible to sort by first name or surname, and this setting is adjusted When a phone is connected to the car with When the telephone is connected to the car, in the telephone setup.
  • Page 504: Wireless Phone Charger

    SOUND, MEDIA AND INTERNET Settings for Bluetooth devices Wireless phone charger* Using the wireless telephone charger* Settings for Bluetooth-connected devices. There is a charging plate for wireless phone Press Settings in the top view. charging located under the centre display. The rubber plate under the centre display A condition for being able to charge makes it possible to charge phones without...
  • Page 505 SOUND, MEDIA AND INTERNET If the phone does not charge: Check that the charging plate is free from • other objects. Check that the phone supports wireless • charging (Qi). Remove the case from the phone if one is • fitted.
  • Page 506: Certificate For Wireless Charger

    SOUND, MEDIA AND INTERNET Certificate for wireless charger Country/Area Mexico: RCPVAPVO 18-1919 Paraguay: 2018-11-1-000541 Ukraine: : 107 - 115 М ь ь є ь ) ), 63 К є : N / A М : 13,56 М +/- 0,01% М ь...
  • Page 507: Internet-Connected Car

    Remove Wi-Fi network (p. 510) • Wi-Fi technologies and security (p. 510) • NOTE Volvo ID (p. 26) • When using Android Auto, it is possible to User terms and conditions and data shar- • connect the car to the Internet using Wi-Fi, ing (p.
  • Page 508: Connect The Car To The Internet Via A Bluetooth-Enabled Phone

    SOUND, MEDIA AND INTERNET Connect the car to the Internet via Connect the car to the Internet via 6. If another connection source has been a Bluetooth-enabled phone a phone (Wi-Fi) used, confirm the option to change con- nection. Create an Internet connection via Bluetooth Create an Internet connection via Wi-Fi by >...
  • Page 509: Connect The Car To The Internet Via

    To show a list of saved used, confirm the option to change con- card (P-SIM)*. networks or manually delete saved networks, nection. Cars equipped with Volvo On Call will use the go to Settings Communication Wi-Fi 6.
  • Page 510: Settings For Car Modem

    SOUND, MEDIA AND INTERNET Settings for car modem* Sharing Internet access from the Change PIN - a maximum of 4 digits can car via a Wi-Fi hotspot be entered. The car is equipped with a modem that can be used to connect the car to the Internet. It Disable PIN - select whether the PIN When the car is online, its Internet connec-...
  • Page 511: No Or Poor Internet Connection

    SOUND, MEDIA AND INTERNET No or poor Internet connection The network operator (SIM card) must sup- NOTE port tethering (sharing of the Internet connec- Factors that affect the Internet connection. Activation of Wi-Fi-hotspot can result in tion). The amount of data transferred is dependent further charges from your network opera- on the services or apps in use in the car.
  • Page 512: Remove Wi-Fi Network

    SOUND, MEDIA AND INTERNET Remove Wi-Fi network Wi-Fi technologies and security Related information Internet-connected car* (p. 505) • Removing a network that is not to be used. Possible network types to connect to. Press Settings in the top view. It is only possible to connect to the following Wi-Fi technologies and security (p.
  • Page 513: User Terms And Conditions And

    With the software update made available NOTE November 2017, privacy and data sharing set- After a visit to a Volvo workshop, you may tings were introduced for online services and need to reactivate data sharing so that the downloaded apps. The settings can be found online services and apps shall work again.
  • Page 514: Data Sharing For Services

    Volvo's terms and con- To approve data sharing for an app that needs first need to approve Volvo's terms and ditions for online services.
  • Page 515: Storage Space On Hard Disk

    SOUND, MEDIA AND INTERNET Storage space on hard disk It is possible to view how much free space there is on the car's hard disk. Storage information for the car's hard disk, including total capacity, available capacity and how much space is used for installed apps can be shown.
  • Page 516: License Agreement For Audio And

    A license is an agreement for the right to operate a certain activity or the right to use someone else's entitlement according to the terms and conditions in the agreement. The following texts are Volvo's agreements with manufacturers/developers. ® Dirac Unison Parts of the content are copyright ©...
  • Page 517 SOUND, MEDIA AND INTERNET Gracenote servers, including all ownership and the company reserves the right to discon- Gracenote End User License Agreement ® rights. Gracenote will under no circumstances tinue its services at any time. This program or device contains software from have any obligation to pay you for any informa- Gracenote, Inc.
  • Page 518 SOUND, MEDIA AND INTERNET permitted provided that the following OTHERWISE) ARISING IN ANY WAY OUT WITHOUT WARRANTY OF ANY KIND, conditions are met: Redistributions of source OF THE USE OF THIS SOFTWARE, EVEN IF EXPRESS OR IMPLIED, INCLUDING BUT code must retain the above copyright notice, ADVISED OF THE POSSIBILITY OF SUCH NOT LIMITED TO THE WARRANTIES OF this list of conditions and the following...
  • Page 519 SOUND, MEDIA AND INTERNET You have the right of acquisition, modification, conditions and the following disclaimer as Copyright c 1991-2013 Unicode, Inc. All rights and distribution of the source code of the the first lines of this file unmodified. reserved. Distributed under the Terms of Use GPL/LGPL software.
  • Page 520 SOUND, MEDIA AND INTERNET COPYRIGHT HOLDER OR HOLDERS use or other dealings in these Data Files or Declaration of Conformity INCLUDED IN THIS NOTICE BE LIABLE FOR Software without prior written authorization of ANY CLAIM, OR ANY SPECIAL INDIRECT OR the copyright holder.
  • Page 521 SOUND, MEDIA AND INTERNET Country/ Area Brazil: Este equipamento opera em caráter secundário isto e, náo tem direito a protecão contra interferéncia prejudicial, mesmo tipo, e não pode causar interferéncia a sistemas operando em caráter primário. Para consultas, visite: www.anatel.gov.br Manufacturer: Mitsubishi Electric Corporation Sanda Works 2-3-33, Miwa, Sanda-city.
  • Page 522 SOUND, MEDIA AND INTERNET Country/ Area Kazakh- stan: Model name: NR 0V Manufacturer: Mitsubishi Electric Corporation Exporting country: Japan...
  • Page 523 SOUND, MEDIA AND INTERNET Country/ Area China: ■ 使用频率 2.4 - 2.4835 GHz ■ 等效全向辐射 率(EIRP) 天线增益 10dBi 时 ≤100 mW 或≤20 dBm ① ■ 最大 率谱密度 天线增益 10dBi 时 ≤20 dBm / MHz(EIRP) ① ■ 载频容限 20 ppm ■ 帯外发射 率(在 2.4-2.4835GHz 頻段以外) ≤-80 dBm / Hz (EIRP) ■...
  • Page 524 SOUND, MEDIA AND INTERNET Country/ Area B 급 기기 (가정용 방송통신기자재) Korea: 이 기기는 가정용(B 급) 전자파적합기기로서 주로 가정에서 사용하는 것을 적으로 하며, 든 지역에서 사용할 수 있습니다. 해당 무선설비는 전파혼신 가능성이 있으므로 인명안전과 관련된 서비스는 할 수 습니다. Malaysia: This device has been certified under the Communications &...
  • Page 525 SOUND, MEDIA AND INTERNET Country/ Area Mexico: 低 率電波輻射性電機管理辦法 Taiwan: 第十二條 經型式認證合格之低功率射頻電機,非經許可,公司 商號或使用者均不得擅自 變更頻率 加大功率或變更原設計之特性及功能 第十四條 低 率射頻電機之使用不得影響飛航安全及干擾合法通信;經發現有干擾現象時,應 立停用,改善至無干擾時方得繼續使用 前項合法通信,指依電信法規定作業之無線 電通信 低 率射頻電機須忍受合法通信或工業 科學及醫療用電波輻射性電機設備 之干擾 Related information Sound, media and Internet (p. 468) • Internet-connected car* (p. 505) • Media player (p. 478) •...
  • Page 527: Wheels And Tyres

    WHEELS AND TYRES...
  • Page 528 Recommended tyres best tread must be fitted on the rear especially important with regard to winter On delivery, the car is equipped with Volvo wheels to reduce the risk of oversteer dur- tyres. The last four digits in the sequence...
  • Page 529 Volvo accepts no lia- than having the rear end skidding to one side, bility for death, personal injury or any resulting in possible complete loss of control costs caused by such installations.
  • Page 530: Dimension Designation For Tyre

    WHEELS AND TYRES Dimension designation for tyre Speed rating 270 km/h (168 mph) Each tyre can withstand a certain maximum Designations for tyre dimension, load index 300 km/h (186 mph) speed. Tyre speed rating, SS (Speed Symbol), and speed rating. must at least correspond with the car's top The car has an approval for the complete vehi- speed.
  • Page 531: Dimension Designation For Wheel Rim

    WHEELS AND TYRES Dimension designation for wheel Tyres' rotation direction NOTE Tyres with a tread pattern which are designed Make sure that both pairs of wheels have to only turn in one direction have the direc- Wheel and rim dimensions are designated in the same type and dimension, and also the tion of rotation marked with an arrow.
  • Page 532: Tread Wear Indicators On The Tyres

    WHEELS AND TYRES Tread wear indicators on the tyres Checking tyre pressure Cold tyres The tyre pressure must be checked when the Tread wear indicators show the status of the Correct tyre pressure helps to improve driv- tyres are cold. Tyres are considered cold when tyre's tread depth.
  • Page 533: Adjusting Tyre Pressure

    WHEELS AND TYRES Adjusting tyre pressure Related information 3. Refit the dust cap. Adjusting tyre pressure (p. 531) • Tyre pressure decreases over time, this is a NOTE natural phenomenon. The tyre pressure must Recommended tyre pressure (p. 532) • therefore sometimes be adjusted in order to After a tyre has been inflated, always Tyre pressure monitoring system*...
  • Page 534: Recommended Tyre Pressure

    WHEELS AND TYRES Recommended tyre pressure Related information Improved fuel economy with ECO pressure Recommended tyre pressure (p. 532) For a light load (max. 3 people) and a speed of • The tyre pressure label on the driver's side up to 160 km/h (100 mph), the ECO pres- door pillar (between frame and rear door) Checking tyre pressure (p.
  • Page 535: Tyre Pressure Monitoring System

    WHEELS AND TYRES Tyre pressure monitoring system* Each tyre, including the spare tyre*, should be system fault indicator is combined with the checked once a month. When checking, the indicator symbol for low tyre pressure. When The tyre pressure monitoring system gives a tyre should be cold and have the air pressure the system detects a fault, the symbol in the...
  • Page 536: Saving A New Tyre Pressure In The Monitoring System

    The new tyre pressure is losing control of the car. the tyre pressure should be adjusted in stored when the car is driven at a speed accordance with Volvo's recommended tyre The system cannot indicate sudden • above 35 km/h (22 mph).
  • Page 537: See Tyre Pressure Status In The Centre Display

    WHEELS AND TYRES See tyre pressure status in the Related information WARNING centre display* Saving a new tyre pressure in the monitor- • The exhaust gases contain carbon monox- ing system* (p. 534) With the system for tyre pressure monitor- ide, which is invisible and odourless, but , tyre pressure status can be viewed in Action in the event of warning for low tyre...
  • Page 538: Action In The Event Of Warning For Low Tyre Pressure

    WHEELS AND TYRES Action in the event of warning for Related information NOTE low tyre pressure Recommended tyre pressure (p. 532) • To avoid incorrect tyre pressure, the pres- When the system for tyre pressure warns Adjusting tyre pressure (p. 531) •...
  • Page 539: Messages For Tyre Pressure Monitoring

    Car status (p. 572) • WARNING low Check Car that there is low tyre Volvo Cars support site (p. 21) • Status app in pressure in one or more If a wheel must be changed in a traf- •...
  • Page 540 WHEELS AND TYRES 2. Screw together the towing eye with the 2. Put on the wheel. Tighten the wheel bolts IMPORTANT wheel wrench to the stop position. thoroughly. When the jack* is not in use it must be • Do not use lubricant on the threads of the stored in its storage space under the wheel bolts.
  • Page 541: Tool Kit

    WHEELS AND TYRES Tool kit Emergency puncture repair kit (p. 544) • WARNING Tools that can be useful during towing, wheel Fitting and removing the towing eye • The wheel bolts may need to be re-tight- changes or similar are found in the car's (p.
  • Page 542: Jack

    Only use rims that are tested and approved by cargo area floor. Volvo and which are Volvo genuine accesso- The jack included with the car is only • ries. designed for occasional, short-term...
  • Page 543: Spare Wheel

    Look out for high wrench, contact your Volvo dealer. If the spare wheel is damaged, a new one can kerbs and do not machine-wash the be purchased from a Volvo dealer. Related information car. Changing wheel (p. 537) •...
  • Page 544: Handling The Spare Wheel

    WHEELS AND TYRES Handling the spare wheel* Storing the punctured tyre IMPORTANT Screw back the mounting screw that held Follow these instructions for handling the The car must not be driven with tyres of the spare wheel in place. spare wheel. different sizes or with a spare wheel other than the one supplied with the car.
  • Page 545: Winter Tyres

    In the event of uncertainty about the show Contact a Volvo dealer for advice about which chain, Volvo recommends that an author- wheel rim and tyre types are most suitable. ised Volvo workshop should be contacted.
  • Page 546: Emergency Puncture Repair Kit

    • works as a temporary repair. front wheels (also applies to all-wheel You can obtain more information on snow drive cars). chains from a Volvo dealer. NOTE In some cases, snow chains must NOT • Related information The sealing fluid is effective at sealing tyres be used, such as if accessory, after- Winter driving (p.
  • Page 547 WHEELS AND TYRES Using a puncture repair kit Sealing fluid bottle The emergency puncture repair kit (TMK Bottle opening can be used to seal a puncture. Read through all instructions before use. Connection for bottle Overview Air hose Connection valve Connecting Sealing fluid expiry date The bottle of sealing fluid must be replaced if...
  • Page 548 WHEELS AND TYRES Inhalation: Move the exposed person 2. Detach the decal for maximum permitted • WARNING to fresh air. If irritation persists, get speed that is affixed on one side of the Please keep the following points in mind medical attention.
  • Page 549 Do not leave children in the car without 2. Remove the air hose from the bottle. assistance for recovery to a tyre centre. supervision when the engine is running. Volvo recommends an authorised tyre cen- 3. Remove the bottle from the compres- tre. sor.
  • Page 550 WARNING check. Check the tyre pressure regularly. WARNING Volvo recommends that the car is driven to the Sealant will spurt out of the puncture dur- nearest authorised Volvo workshop for the ing the first few rotations of the tyre. Make replacement/repair of the damaged tyre.
  • Page 551 WHEELS AND TYRES Inflating tyres with the compressor 4. Connect the electrical cable to the closest 8. Refit the dust cap on the tyre. from the puncture repair kit 12 V socket and start the car. NOTE The car's original tyres can be inflated using WARNING the compressor in the emergency puncture After a tyre has been inflated, always...
  • Page 553: Loading, Storage And Passenger Compartment

    LOADING, STORAGE AND PASSENGER COMPARTMENT...
  • Page 554: Passenger Compartment Interior

    LOADING, STORAGE AND PASSENGER COMPARTMENT Passenger compartment interior front seat backrest and also USB ports* in the tunnel console. Overview of the passenger compartment's interior and storage locations. WARNING Front seat Keep loose objects such as mobile phones, cameras, remote controls for accessories, etc.
  • Page 555: Tunnel Console

    LOADING, STORAGE AND PASSENGER COMPARTMENT Tunnel console Related information WARNING Emptying the ashtray* (p. 554) • The tunnel console is located between the Keep loose objects such as mobile phones, front seats. Using the cigarette lighter* (p. 554) • cameras, remote controls for accessories, etc.
  • Page 556: Using The Cigarette Lighter

    LOADING, STORAGE AND PASSENGER COMPARTMENT Using the cigarette lighter* Emptying the ashtray* Related information Passenger compartment interior (p. 552) • The cigarette lighter can be a complement to When there is a cigarette lighter fitted in the the 12 V socket in the front section of the tun- car there is a detachable ashtray in the tunnel Emptying the ashtray* (p.
  • Page 557: Electrical Sockets

    For the sockets to supply current, the car's If a problem occurs with an electrical socket, electrical system must be set in the lowest contact a workshop - an authorised Volvo ignition position I. The sockets are then active workshop is recommended.
  • Page 558: Using The Glovebox

    LOADING, STORAGE AND PASSENGER COMPARTMENT Using the glovebox Related information WARNING Electrical sockets (p. 555) • The glovebox is located on the passenger Do not use accessories with large or • side. The printed owner's manual and maps Passenger compartment interior (p. 552) •...
  • Page 559 LOADING, STORAGE AND PASSENGER COMPARTMENT The key's designated storage space. The figure is The figure is schematic - the design may vary. The figure is schematic - the design may vary. schematic - the design may vary. Locking the glovebox: Activating cooling.
  • Page 560: Sun Visors

    LOADING, STORAGE AND PASSENGER COMPARTMENT Sun visors Cargo area Recommendations for loading There are sun visors in the roof in front of the The car has a flexible cargo area that makes it There are a number of things that are impor- driver seat and the front seat passenger seat possible to transport and secure large tant to bear in mind when loading the car.
  • Page 561: Roof Load And Loading On Load Carriers

    (p. 561) in the headlining, may be compromised. safety during a journey. Volvo's load carriers Roof load and loading on load carriers • are available for purchase at authorised Volvo (p.
  • Page 562: Bag Hooks

    LOADING, STORAGE AND PASSENGER COMPARTMENT Bag hooks Under the floor hatch* WARNING Bag hooks keep carrier bags in place and pre- The car's centre of gravity and driving cha- vent them from overturning and spreading racteristics are altered by roof loads. their contents across the cargo area.
  • Page 563: Load Retaining Eyelets

    LOADING, STORAGE AND PASSENGER COMPARTMENT Load retaining eyelets Through-load hatch in the rear Folding up the cargo area floor seat* Use the load retaining eyelets to attach The cargo area floor can be secured in raised straps in order to anchor items in the cargo position using the support arm.
  • Page 564: Release Folding Cargo Area Floor

    LOADING, STORAGE AND PASSENGER COMPARTMENT Release folding cargo area floor* With folding cargo area floor* The folding cargo area floor can be released to facilitate access to e.g. the SIM card holder or the lower storage area. Lift the handle in the middle of the folding –...
  • Page 565: Fitting And Removing The Safety Net

    For reasons of safety, the safety net must Volvo recommends leaving the cargo area always be fastened and anchored as descri- floor in its front hinges. bed below.
  • Page 566 LOADING, STORAGE AND PASSENGER COMPARTMENT 2. Hook one retaining hook of the net into the WARNING front or rear roof mounting with the Loads in the luggage compartment must anchoring strap locks turned towards you. be anchored well, and also using a cor- Remove any clothing hooks from the roof rectly fitted safety net.
  • Page 567: Remove And Store The Parcel Shelf

    LOADING, STORAGE AND PASSENGER COMPARTMENT Remove and store the parcel shelf 5. Tension the safety net with the anchoring straps. The parcel shelf can be removed to increase the size of the cargo area. Removing the safety net The safety net can be easily removed and Removing parcel shelf folded up.
  • Page 568: First Aid Kit

    LOADING, STORAGE AND PASSENGER COMPARTMENT First aid kit* Parcel shelf storage beneath the cargo With folding cargo area floor*: area floor The first aid kit contains first aid equipment. Store the first aid kit behind the elastic strap, if the car is equipped with one of these. The removed parcel shelf can be stored under Fold up the folding cargo area floor for- the cargo area floor.
  • Page 569: Warning Triangle

    LOADING, STORAGE AND PASSENGER COMPARTMENT Warning triangle Use the warning triangle to warn other road users if the car is stationary in traffic. Also activate the hazard warning flashers. Storage spaces The warning triangle is located in the compart- ment on the inside of the tailgate. Folding up the warning triangle Open the hatch by first turning the knob a quarter turn and then pulling the hatch...
  • Page 571: Maintenance And Service

    MAINTENANCE AND SERVICE...
  • Page 572: Volvo Service Programme

    For this IMPORTANT type of communication, the car only connects For the Volvo warranty to apply, check and to a workshop's network. It is not possible to follow the instructions in the Service and connect the car to another Wi-Fi network, Warranty Booklet.
  • Page 573: Download Center

    MAINTENANCE AND SERVICE Download Center Managing system updates via the NOTE Download Centre Several of the car's systems can be updated Data download may affect other services from the centre display with an online car Functions for online car and infotainment can that transmit data, e.g.
  • Page 574: Car Status

    MAINTENANCE AND SERVICE Car status ® Cancelling software download • Emission control with AdBlue (p. 439) Tap on X in the activity indicator that has – The general status of the car can be shown in Install replaced at the start of the down- the centre display.
  • Page 575: Book Service And Repair

    Before the service can be used Tap the message. Create a Volvo ID and register it to the car. • 7. Press Send appointment request 2. If the suggested booking is acceptable, Select the Volvo retailer you would like to •...
  • Page 576: Sending Car Information To A Workshop

    (p. 105) workshop The data sent is the last information saved (the last time the car was running) and includes Volvo ID (p. 26) • It is possible to send information for the car information in the following areas: at any time, e.g. if you book a workshop Internet-connected car* (p.
  • Page 577: Raise The Car

    MAINTENANCE AND SERVICE Raise the car When raising the car, it is important that the jack is fitted in the intended points on the car's underbody. The triangles in the plastic cover indicate the locations of the lifting points (marked in red).
  • Page 578 NOTE WARNING WARNING If the car is raised using a workshop jack, Volvo recommends only using the jack that Apply the parking brake and set the • this must be placed beneath one of the belongs to the car model in question. If a gear selector in Park position (P).
  • Page 579 MAINTENANCE AND SERVICE 4. Position the jack or the lift arms at the 7. Turn the jack so that the crank is as far designated spots of the car's undercar- away from the side of the car as possible, riage. The triangle markings in the plastic at which point the jack's arms are perpen- cover indicate the locations of the jacking/ dicular to the direction of the car.
  • Page 580: Servicing The Climate Control System

    Volvo recommends that an authorised Volvo the system. workshop is contacted. Cars with R134a refrigerant Related information Volvo service programme (p.
  • Page 581 Engine compartment overview (p. 580) • If the warning symbol is lit or the warning Door and seatbelt reminder (p. 48) • signal is heard despite the bonnet being closed properly, contact an authorised Volvo workshop. Bonnet not completely closed.
  • Page 582: Engine Compartment Overview

    6 minutes after the engine has been switched off. Always have the engine cleaned by a work- shop - an authorised Volvo workshop is recommended. There is a risk of fire if the engine is hot. Location of warning decal for the engine compart- WARNING ment.
  • Page 583: Engine Oil

    Volvo dis- claims any liability for any such damage. Volvo recommends that oil changes are carried out at an authorised Volvo work- shop. Symbols for low oil level Volvo uses different systems to warn about the oil level if it is too low/high, or in the event of low oil pressure.
  • Page 584: Checking And Filling With Engine Oil

    Car Status app from the app the car as quickly as possible and view in the centre display. have the car recovered to a work- 2. Press Status to show the oil level. shop – an authorised Volvo workshop is recommended.
  • Page 585: Topping Up Coolant

    Engine oil level Service required is required, unscrew the expansion tank message is shown, visit a workshop – an cap slowly to allow any overpressure to authorised Volvo workshop is recom- disappear. mended. The oil level may be too high. WARNING Do not spill oil onto the hot exhaust mani- fold due to the risk of fire.
  • Page 586 • (kidney) damage. Use ready-mixed coolant as recom- • mended by Volvo. If concentrated liq- uid is used, make sure that the ratio is 50 % coolant to 50 % water of an approved quality. Do not mix different coolants.
  • Page 587: Starter Battery

    MAINTENANCE AND SERVICE Starter battery battery is discharged a large number of times, WARNING it will negatively affect the service life. The starter battery is used to start up the The battery can generate oxyhydrogen • electrical system and drive the starter motor In order to maintain the starter battery in good gas, which is highly explosive.
  • Page 588 Capacity (Ah) According to EN standard. Cold Cranking Amperes. Volvo recommends entrusting battery replace- Using jump starting with another battery • ment to an authorised Volvo workshop. (p. 446) Reset sequence for pinch protection • IMPORTANT (p. 157) If the battery is replaced, make sure you Battery recycle (p.
  • Page 589: Support Battery

    If the Start/stop workshop should be contacted in the event of function then auto-stops the engine shortly questions or problems - an authorised Volvo afterwards, there is a great risk that engine workshop is recommended. auto-start will fail due to insufficient bat- tery capacity, because the battery has not had the time to recharge.
  • Page 590: Symbols On The Batteries

    MAINTENANCE AND SERVICE Symbols on the batteries Cold start capacity There are information and warning symbols Avoid sparks and naked on the batteries. 150×90×130 mm flames. Size, L×B×H (5.9×3.5×5.1 inches) Use protective goggles. Capacity (Ah) According to EN standard. Risk of explosion. Cold Cranking Amperes.
  • Page 591: Battery Recycle

    Replacing a fuse (p. 590) • WARNING carded - an authorised Volvo workshop is rec- Fuses in engine compartment (p. 591) • Never use a foreign object or a fuse with an ommended.
  • Page 592: Replacing A Fuse

    This could cause signifi- cant damage to the electrical system and possibly lead to fire. WARNING Contact an authorised Volvo workshop about the fuses not mentioned in the owner's manual. If replacing the fuse is not performed correctly, it can cause serious damage to the electrical systems.
  • Page 593: Fuses In Engine Compartment

    MAINTENANCE AND SERVICE Fuses in engine compartment Fuses in the engine compartment protect engine and brake functions, amongst other things.
  • Page 594 MAINTENANCE AND SERVICE On the inside of the cover there are tweezers The fuse box also provides space for several Positions that facilitate the procedure for the removal spare fuses. On the inside of the cover is a label that shows and fitting of fuses.
  • Page 595 MAINTENANCE AND SERVICE Function Ampere Type Airbags Micro Accelerator pedal sensor Micro Supplied when the ignition is switched on: Engine control module; Transmission components; Electric steering servo; Micro Central electronic module; Control module for brake system Electric additional heater*; OBD II firewall Micro Alcohol lock* Micro...
  • Page 596 MAINTENANCE AND SERVICE Function Ampere Type Horn Micro Siren* Micro Windscreen wipers MCase Control module for brake system (valves, parking brake) MCase Brake control with 48V battery MCase Control unit for brake system (ABS pump) MCase – – MCase Actuator for transmission MCase Actuator for transmission MCase...
  • Page 597 Control function for support battery Micro Left-hand headlamp Micro Right-hand headlamp Micro This type of fuse should be replaced by a workshop. An authorised Volvo workshop is recommended. Related information Fuses and central electrical units (p. 589) • Replacing a fuse (p. 590) •...
  • Page 598: Fuses Under The Left-Hand Front Seat

    MAINTENANCE AND SERVICE Fuses under the left-hand front seat Fuses under the left-hand front seat protect, amongst other things, electrical sockets, dis- plays and door modules.
  • Page 599 MAINTENANCE AND SERVICE The fuse box in the engine compartment facilitate the procedure for the removal and fit- Positions provides space for several spare fuses. On the ting of fuses. On the inside of the cover is a label that shows inside of the cover there are tweezers that the location of the fuses.
  • Page 600 MAINTENANCE AND SERVICE Function Ampere Type Audio control device (amplifier) MCase Central Electric Module A: Sensors, radar units, power seats* MCase Central Electric Module B: Sensors, radar units, power seats* MCase Fan module for climate control system, front MCase Power operated tailgate* MCase Power seat*, right MCase...
  • Page 601 Steering wheel module Micro Module for start knob; Electronic shifting module; Electronic parking brake Micro Centre display Micro Control module for online car; Control module for Volvo On Call Micro Module for multi-band antenna Micro Relay coils Micro Module for detecting foot movement* (for opening the power operated tailgate)
  • Page 602 MAINTENANCE AND SERVICE Function Ampere Type Lock motor for head restraint on rear left-hand side Micro Lock motor for head restraint on rear right-hand side Micro Rear window defroster MCase Seatbelt pretensioner module, left-hand side MCase Seatbelt pretensioner module, right-hand side MCase Humidity sensor Micro...
  • Page 603 MAINTENANCE AND SERVICE Function Ampere Type – – Micro Seatbelt pretensioner module Micro Blind Spot Information (BLIS)*: control module, exterior reversing sound Micro – – Micro – – Micro All Wheel Drive (AWD) control module* Micro – – Micro Parking camera* Micro –...
  • Page 604 Micro – – Micro Applicable to certain variants. This type of fuse should be replaced by a workshop. An authorised Volvo workshop is recommended. Applies to certain markets. Related information Fuses and central electrical units (p. 589) • Replacing a fuse (p. 590) •...
  • Page 605: Bulb Replacement

    Outside lighting such as headlamps and For information about bulbs not covered in rear lamps may temporarily have conden- this Owner's Manual, contact a Volvo sation on the inside of the lens. This is nor- dealer or an authorised Volvo workshop.
  • Page 606: Replacing The Rear Direction Indicator Bulb

    MAINTENANCE AND SERVICE Replacing the rear direction Lamps, rear indicator bulb Bulbs for rear direction indicators are located behind the panel in the side of the cargo area. 3. Unscrew and remove the spring bolt anti- clockwise, press the clips into the sides Brake light - central, high-level (LED) and remove the supporting bridge.
  • Page 607: Changing Brake Light Bulb

    MAINTENANCE AND SERVICE Changing brake light bulb IMPORTANT Bulbs for brake lights are located behind the Never touch the glass part of the bulbs panel in the side of the cargo area. with your fingers. Grease from your fingers is vaporised by the heat, coating the reflec- tor and then causing damage.
  • Page 608: Replacing The Rear Fog Lamp Bulb

    MAINTENANCE AND SERVICE Replacing the rear fog lamp bulb Related information Exterior lamp positions (p. 603) • The rear foglight is fitted in the rear bumper on the driver's side. Bulb specifications (p. 607) • 3. Undo the black bulb holder by turning it anticlockwise and pulling it out.
  • Page 609: Bulb Specifications

    Specifications for replaceable bulbs. Use cleaning agents and car care products 8. Insert the hook on the wide part of the recommended by Volvo. Clean regularly, and foglight unit in the rear bumper and rotate Contact a workshop if faults occur in lamps deal with stains straight away.
  • Page 610: Cleaning The Centre Display

    MAINTENANCE AND SERVICE Cleaning the centre display Related information IMPORTANT Cleaning the centre display (p. 608) • Dirt, stains and grease from fingers can affect The microfibre cloth used to clean the cen- the centre display's performance and reada- Cleaning fabric upholstery and headlining •...
  • Page 611: Cleaning Fabric Upholstery And Headlining

    MAINTENANCE AND SERVICE Cleaning fabric upholstery and Cleaning the leather steering wheel • IMPORTANT headlining (p. 612) Always clean the entire upholstery, even Cleaning interior plastic, metal and wood It is recommended to use a fabric cleaning • there are only individual stains. This is to parts (p.
  • Page 612: Cleaning The Seatbelts

    Use water and a synthetic detergent. A special Remove inlaid carpets for separate cleaning of textile cleaning agent is available from Volvo the floor carpet and the inlaid carpets. Each retailers. Ensure that the seatbelt is dry before inlay mat is secured with pins.
  • Page 613: Cleaning Leather Upholstery

    • required in order that the properties and col- > Protecting the leather upholstery (p. 609) ours of the leather shall be preserved. Volvo makes it more resistant to the stresses Cleaning the seatbelts (p. 610) • offers a comprehensive product, Volvo Leather from the sun's UV radiation.
  • Page 614: Cleaning The Leather Steering Wheel

    • Use cleaning agents and car care products Use cleaning agents and car care products (p. 610) recommended by Volvo. Clean regularly, and recommended by Volvo. Clean regularly, and Cleaning leather upholstery* (p. 611) • deal with stains straight away. Vacuuming is deal with stains straight away.
  • Page 615: Cleaning The Exterior

    Use a soft washing sponge. in a car wash with oil separator. Use car the car in direct sunlight, the surface being shampoo that is recommended by Volvo. polished should be a maximum of 45 °C Polishing glossy trim mouldings could (113 °F).
  • Page 616: Handwashing

    After the car has been washed, tar from • and have an abrasive effect. asphalt may remain. Use tar remover that is recommended by Volvo to get rid of the Remove bird droppings from the paint- • last spots. work as soon as possible. They contain substances that damage and discolour paintwork very quickly.
  • Page 617: Automatic Car Wash

    NOTE Never use polishing agent with abra- • Volvo recommends that the car is not sive properties on the panoramic roof. washed in an automatic car wash during Never use wax on the rubber mould- •...
  • Page 618 MAINTENANCE AND SERVICE Keyless and touch-sensitive surfaces* • IMPORTANT IMPORTANT (p. 248) For car washes where the car is pulled for- The system will automatically switch to P ward with rolling wheels, the following mode unless the above step is followed. applies: The wheels are locked in P mode, which they should not be when putting the car...
  • Page 619: High-Pressure Washing

    Wash the car in a car wash with oil separator. Use car shampoo that is with oil separator. Use car shampoo that is recommended by Volvo. recommended by Volvo. When using high-pressure washing, use Asphalt, dust and salt residue on wiper blades, sweeping movements and make sure that the as well as insects, ice etc.
  • Page 620: Cleaning Exterior Plastic, Rubber And Trim Components

    Use car shampoo that is rec- Never use metal polishing agent on ano- ommended by Volvo. dised aluminium parts, this can result in A special cleaning agent available from Volvo discolouration and destroy the surface dealers is recommended for the cleaning and treatment.
  • Page 621: Cleaning Wheel Rims

    Use car shampoo and shielding plastic components, abrasion the edges of wings, doors and bumpers. To that is recommended by Volvo. protection and supplemental rust inhibitor on avoid the onset of rust, damaged paintwork exposed areas. In the chassis, exposed com- should be rectified immediately.
  • Page 622: Touching Up Minor Paintwork Damage

    Touch-up pens and spray paints for touching clean and dry. The temperature of the sur- up paintwork are available from Volvo dealers. If the damage has not reached down to the face should be at least 15 °C (59 °F).
  • Page 623: Colour Codes

    MAINTENANCE AND SERVICE Colour codes Replacing the wiper blade, rear Replacing the wiper blade, rear window window Colour code The wiper blades sweep water away from the The decal for the colour code is positioned on windscreen and rear window. Together with the car's right-hand door pillar between the washer fluid, they aim to clean the windows front and rear door and will be visible when...
  • Page 624: Replacing Windscreen Wiper Blades

    MAINTENANCE AND SERVICE Replacing windscreen wiper 3. Press the new wiper blade into place. You Fold up the wiper arm when it is in service blades should hear a click. Check that it is firmly position. Service position is activated/ installed.
  • Page 625: Set The Wiper Blades In Service Position

    MAINTENANCE AND SERVICE Set the wiper blades in service wipers are not on. Service mode is activated/ NOTE position deactivated via the function view in the centre When replacing the wiper blades, note that display: In some situations, the windscreen's wiper they have different lengths.
  • Page 626: Filling Washer Fluid

    MAINTENANCE AND SERVICE Filling washer fluid Related information Prescribed grade: Washer fluid recom- mended by Volvo – with frost protection dur- Using the rain sensor (p. 168) • Washer fluid is used for cleaning the head- ing cold weather and for temperatures below...
  • Page 627 MAINTENANCE AND SERVICE Using the rain sensor's memory function • (p. 169) Using the rear window wiper and washer • (p. 170) Set the wiper blades in service position • (p. 623) Replacing windscreen wiper blades • (p. 622) Replacing the wiper blade, rear window •...
  • Page 629 SPECIFICATIONS...
  • Page 630 The illustration is schematic - details may vary depending on market and model. Knowing the car's type designation, vehicle identification and engine numbers can facili- tate all contact with an authorised Volvo dealer regarding the car and when ordering spare parts and accessories.
  • Page 631 SPECIFICATIONS Decal for type designation, vehicle identifi- Decal A/C system for cars with refrigerant Decal for engine code and the engine's cation number, permissible maximum weights R134a. serial number. and code designation for exterior colour and date of manufacture. The decal is positioned on the door pillar, and will be visible when the right-hand rear door is opened.
  • Page 632 SPECIFICATIONS NOTE It is not intended that the decals illustrated in the owner's manual should be exact rep- licas of those in the car. They are included to show their approximate appearance and locations in the car. The information that applies to your particular car can be found on the decal on the car.
  • Page 633 SPECIFICATIONS Dimensions Measurement of car length, height, etc. can be read in the table. Dimensions inches Dimensions inches Dimensions inches Ground clear- Load length, 34.9 Width 1873 73.7 floor ance (1863 (73.3 1658 65.3 Wheelbase 2702 106.4 Height Length 4425 174.2 Load height 28.9...
  • Page 634 SPECIFICATIONS Dimensions inches Width includ- 2034 80.1 ing door mir- rors Width includ- 1910 75.2 ing folded-in door mirrors At kerb weight + 1 person. (Varies slightly depending on tyre dimension, chassis option, etc.) Including roof antenna, for kerb weight. Body width.
  • Page 635 SPECIFICATIONS Weights NOTE Max. gross vehicle weight, etc. can be read The documented kerb weight applies to on a label in the car. cars in the standard version - i.e. a car Kerb weight includes the driver, the fuel tank without extra equipment or accessories.
  • Page 636 SPECIFICATIONS Towing capacity and towball load Max. weight braked trailer Towing capacity and towball load for driving NOTE with a trailer can be read in the tables. Use of vibration dampers on the towbar is recommended for trailers heavier than 1800 kg.
  • Page 637 SPECIFICATIONS Engine Gearbox Max. weight braked trailer (kg) Max. towball load (kg) Engine code D3 AWD D4204T16 Automatic 2000 110 (160 D4 AWD D4204T12 Automatic 2100 110 (160 The engine code, component number and serial number can be found on the engine. 160 kg only applies to Australia.
  • Page 638 SPECIFICATIONS Engine specifications NOTE NOTE Engine specifications (power, etc.) for each Not all engines are available in all markets. If there is no engine data in the table, this respective engine alternative can be found in is available in an enclosed supplement. the table below.
  • Page 639: T2 B3154T9

    SPECIFICATIONS Engine oil – specifications Engine oil grade and volume for each respec- tive engine alternative can be read in the table. Volvo recommends: Engine Oil grade Volume, incl. oil filter Engine code (litres, approx.) B3154T9 Castrol Edge Professional V 0W-20 or VCC RBS0-2AE 0W-20...
  • Page 640: D3 / D3 Awd D4204T16

    SPECIFICATIONS Engine Oil grade Volume, incl. oil filter Engine code (litres, approx.) D3 / D3 AWD D4204T16 Castrol Edge Professional V 0W-20 or VCC RBS0-2AE 0W-20 D4 AWD D4204T12 The engine code, component number and serial number can be found on the engine. Related information Type designations (p.
  • Page 641: Engine Oil - Specifications

    Volvo dis- claims any liability for any such damage. Volvo recommends: Volvo recommends that oil changes are carried out at an authorised Volvo work- shop. Related information Engine oil – specifications (p. 637) •...
  • Page 642 Prescribed grade: Ready-mixed coolant Under normal driving conditions, the trans- Brake fluid is the medium in a hydraulic brake approved by Volvo. If concentrated coolant is mission fluid does not need to be changed system that is used to transfer pressure from used, mix with 50% water (of approved during the service life of the gearbox.
  • Page 643 SPECIFICATIONS ®1 Fuel tank - volume Air conditioning – specifications Tank capacity for AdBlue The fuel tank's filling capacity can be read in The car's climate control system uses a freon- The tank capacity for the additive AdBlue is the table below. free refrigerant either R1234yf or R134a approx.
  • Page 644 SPECIFICATIONS Decal for R1234yf Cars with R1234yf refrigerant Symbol Meaning A trained and certified technician is required in order to service the mobile air conditioning system (MAC) Flammable refrigerants Symbol explanation R1234yf Refrigerant Refrigerant amount. Refrigerant amount is printed on the decal Symbol Meaning located on the inside of the bonnet.
  • Page 645 SPECIFICATIONS Fuel consumption and CO Evaporator Related information emissions Type designations (p. 628) • IMPORTANT Weights (p. 633) Fuel consumption and CO emissions can be • negatively impacted by a number of factors. Economical driving (p. 430) The A/C system's evaporator must never •...
  • Page 646 SPECIFICATIONS Approved tyre pressures NOTE Approved tyre pressures for each engine All engines, tyres or combinations of these alternative can be found in the table. are not always available in all markets. Engine Tyre size Speed Load, 1-3 persons Max. load ECO pressure Front Rear...
  • Page 647 SPECIFICATIONS Performance Top speed can be read in the table below. Engine Top speed Engine code (km/h) (mph) B3154T4 B4204T47 T4 AWD B4204T47 T5 AWD B4204T18 The engine code, component number and serial number can be found on the engine. NOTE If there is no performance data in the table, this is available in an enclosed supplement.
  • Page 649 ALPHABETICAL INDEX ALPHABETICAL INDEX Limitations change 1, 2, 3 ... overtaking defrosting setting the time interval Recirculation standby mode table of options stored speed Air quality 187, 188 Symbols and messages allergies and asthma WARNING passenger compartment filter A/C (Air conditioning) AdBlue Air recirculation filling...
  • Page 650 ALPHABETICAL INDEX upon risk of head-on collision Limitations Bluetooth upon risk of rear-end collision tolerance connect upon risk of run-off connect car to Internet Auxiliary heater phone Audio and media AWD, All Wheel Drive settings Audio settings 468, 500 Bonnet, opening phone play media 479, 480...
  • Page 651 ALPHABETICAL INDEX Bulbs Car holiday Checking the engine oil level change Car key battery low Child safety specifications Car modem Child safety locks Bypass alcohol lock connect car to Internet Child seat 58, 61, 62 settings i-Size/ISOFIX mounting points Car status lower mounting points Tyre pressure overview table...
  • Page 652 ALPHABETICAL INDEX Fabric upholstery 607, 609, 611 Collision warning Corner Traction Control rims from behind Crash, see Collision Seatbelts with adaptive cruise control Cross Traffic Alert upholstery 607, 609, 610, 611, 612 with Pilot Assist activate/deactivate Cleaning wheel rims Collision warning system Limitations cross traffic rear Cleaning wiper blades...
  • Page 653 ALPHABETICAL INDEX Diagnosis Drive-E Driving with a trailer via the workshop's Wi-Fi Environmental philosophy towball load towing capacity Diesel Driver Alert Control run out of fuel activate/deactivate guide to rest stops Diesel particle filter Limitations Digital radio (DAB) Driver display Dimensions ECO climate app menu...
  • Page 654 ALPHABETICAL INDEX Engine Front seat, power deactivate adjusting seat overheating Lumbar support start Air distribution massage Start/Stopfunction Air vents multi-function control 177, 178 Control store position Engine braking 401, 428 Fault tracing FSC, ecolabelling Engine compartment Adaptive Cruise Control coolant Fuel 434, 435, 436 City Safety...
  • Page 655 Heated washer nozzles Gearbox IAQS (Interior Air Quality System) Heater automatic 410, 411, 415 IC (Inflatable Curtain) auxiliary heater manual parking heater ID, Volvo Gear positions Heating Identification number automatic gearbox seats 197, 198 Ignition position 398, 399 Gear selector inhibitor...
  • Page 656 ALPHABETICAL INDEX Interior lighting Keyless Leather upholstery, washing instruc- adapt Locking/unlocking tions settings Interior rearview mirror Level control touch-sensitive surfaces Dipping damping Keypad in the steering wheel Intermittent wiping License agreement 88, 514 Key tag Internet, see Internet-connected car Lifting tool Internet-connected car Lighting book service and repair...
  • Page 657 ALPHABETICAL INDEX bulbs, specifications Meters direction indicator, rear fuel gauge rear fog lamp Main beam Mileage Limp home Maintained climate comfort Misting start/shut-off Load carriers condensation in headlamps 613, 615 maintenance Loading Mobile phone, see Phone Rustproofing General Mood lighting load retaining eyelets Manual gearbox Motion sensor...
  • Page 658 ALPHABETICAL INDEX Output Parcel shelf Parking heater outside temperature gauge Park Assist Passenger Airbag Cut Off Switch activate/deactivate Overheating 445, 453 Passenger compartment filter forward, backward and along the Overtaking Assistance Passenger compartment heater (Parking sides activate heater) Limitations Owner's information Passenger compartment interior Symbols and messages ashtray...
  • Page 659 ALPHABETICAL INDEX Phone charger Power windows 157, 158 Radio favourites opening and closing Pilot Assist Rain sensor 168, 169 pinch protection activate Rain sensor memory function Auto brake Preconditioning Raising the car change of target start/shut-off Rear Collision Warning controls Timer Limitations deactivate...
  • Page 660 ALPHABETICAL INDEX Refrigerant Road sign information seatbelt reminder climate control system Limitations seatbelt tensioner Refuelling Road Sign Information Seatbelt, see Seatbelts AdBlue activate/deactivate Seatbelt reminder activating / deactivating warnings Regeneration 436, 438 seatbelt tensioner display mode Remote control, HomeLink® Resetting Sensus Navigation programmable Seatbelt tensioner...
  • Page 661 ALPHABETICAL INDEX Settings Speed ratings, tyres Stickers Categories location Speed warning, general contextual Stone chips and scratches 619, 620, 621 Spin control Resetting Stop/start function Stabiliser Side airbag trailer Storage spaces Side Impact Protection System glovebox Stability and traction control system SIM card Sun visor sport mode...
  • Page 662 ALPHABETICAL INDEX foldable Trip meter specifications Trip meter, resetting Tailgate Towing 457, 460 Trip statistics Locking/unlocking 225, 250 Towing a trailer settings opening/closing with foot move- Towbar TSA - trailer stability assist ment Towing bracket power Tunnel console unlock from inside Towing capacity and towball load Tunnel detection Target vehicle change...
  • Page 663 Warning triangle speed rating using 133, 135, 136 Storage Washer fluid 166, 624 VOL marking tread wear indicators Washer nozzles, heated Volvo ID tyre pressure table Washers create and register winter tyres Headlamps rear window 170, 171 washer fluid, filling windscreen...
  • Page 664 ALPHABETICAL INDEX Wi-Fi connect car to Internet delete network share internet connection, hotspot technology and security Windows and glass Windscreen heating Windscreen washing Windscreen wiper rain sensor 168, 169 Winter driving snow chains winter tyres Wiper blades changing 621, 622 Service position Wiper blades and washer fluid...
  • Page 666 TP 31200 (English Int.), AT 1946, MY20, Copyright © 2000-2019 Volvo Car Corporation...

Table of Contents

Save PDF
