SPECIFICATIONS - MLT4200ICAN

MAGNUM MODEL MLT4200ICAN
Engine
Make/Brand..........................................................................................................................Isuzu
Model ...................................................................................................................................4LE1NYGV-03G
EPA Tier ...............................................................................................................................4f
Horsepower - prime hp (kW) ...............................................................................................31.5 (23.5)
Horsepower - standby hp (kW)............................................................................................34.5 (25.7)
Operating Speed rpm ..........................................................................................................1800
Displacement in 3 (L) ............................................................................................................134.25 (2.20)
Cylinders - qty ......................................................................................................................4
Fuel Consumption - 100% prime gph (Lph) ........................................................................1.80 (6.81)
Battery Type - Group Number ..............................................................................................24
Battery Voltage (Quantity per Unit) ......................................................................................12V (1)
Battery Rating ......................................................................................................................720 CCA
Generator
Make/Brand..........................................................................................................................Marathon Electric
Model ...................................................................................................................................334CSA3028
Type, Insulation ....................................................................................................................Brushless, F
Generator Set (Engine/Generator)
Output - Standby kW (kVA) ..................................................................................................20.0 (20.0)
Output Voltage V ..................................................................................................................120/240, single phase
Output Amperes 120V (240V) A ...........................................................................................167 (83)
Frequency Hz.......................................................................................................................60
Power Factor........................................................................................................................1 (1Ø)
Weights
Dry Weight lbs (kg)..............................................................................................................2122 (963)
Operating Weight lbs (kg) ...................................................................................................2520 (1143)
Capacities
Fuel Tank Volume gal (L).....................................................................................................56 (212)
Usable Fuel Volume gal (L) .................................................................................................56 (212)
Coolant (incl. engine) qt (L) .................................................................................................11.6 (11.0)
Oil (incl. filter) qt (L) .............................................................................................................8.6 (8.1)
Maximum Run Time hrs ......................................................................................................31
AC Distribution
Circuit Breaker Size .............................................................................................................100
Voltage Regulation...............................................................................................................+/-1%
Voltages Available 1Ø ..........................................................................................................120, 240
Lighting
Lighting Type, Ballast Type ...................................................................................................Metal Halide, Coil & Core
Lumens .................................................................................................................................440,000
2 ) ............................................................................................................5 - 7 (20,234 - 28,328)
Coverage acres (m
Trailer
Number of Axles...................................................................................................................1
Capacity - Axle Rating lbs (kg) ............................................................................................3000 (1361)
Tire Size in ...........................................................................................................................15
Hitch - Standard ...................................................................................................................2" Ball
Maximum Tire Pressure psi .................................................................................................50
Specifications are subject to change without notice.
