Tsunami MP.11-R Installation and Management Guide
Model 2454-R
Model 4954-R
Model 5054-R
Model 5054-R-LR
Version 5.0.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tsunami MP.11-R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Proxim Tsunami MP.11-R

Summary of Contents for Proxim Tsunami MP.11-R

  • Page 1 Tsunami MP.11-R Installation and Management Guide Model 2454-R Model 4954-R Model 5054-R Model 5054-R-LR Version 5.0.0...
  • Page 2 Safety and Regulatory Compliance Guide located on the product CD. Copyright ©2010 Proxim Wireless Corporation, San Jose, CA. All rights reserved. Covered by one or more of the following U.S. patents: 5,231,634; 5,875,179; 6,006,090; 5,809,060; 6,075,812; 5,077,753. This manual and the software described herein are copyrighted with all rights reserved.

  • Page 3: Table Of Contents

    MP.11-R Installation and Management Contents Introduction ..............10 Products Covered in this Guide .
  • Page 4 MP.11-R Installation and Management SU Registration ..............39 Dynamic Data Rate Selection (DDRS) .
  • Page 5 MP.11-R Installation and Management Ethernet ................. 90 SNMP Parameters .
  • Page 6 MP.11-R Installation and Management NAT (SU Only; Routing Mode Only) ........... . . 142 NAT Static Port Mapping Table .
  • Page 7 MP.11-R Installation and Management Procedures ..............169 TFTP Server Setup .
  • Page 8 MP.11-R Installation and Management B Technical Specifications ........... . . 207 Part Numbers .
  • Page 9 Proxim eService Web Site Support ........

  • Page 10: Introduction

    NOTE: Unless otherwise noted, screen captures in this User Guide are from the 5054-R. About This Book Before installing and using the unit, Proxim recommends you review the following chapters of this manual: • Chapter 1 “Introduction” (this chapter): Provides an overview of the content of this manual as well as wireless network topologies and combinations that can be built with the unit.

  • Page 11: Reference Manual

    Introduction MP.11-R Installation and Management Reference Manual • Chapter 4 “Basic Management”: Explains how to navigate the user interface, and discusses the most common settings used to manage the unit. • Chapter 5 “System Status”: Depicts the Web Interface’s “Status” options, including System Status and Event Logs. •...

  • Page 12: Wireless Network Topologies

    Introduction MP.11-R Installation and Management Wireless Network Topologies Wireless Network Topologies The unit can be used in various network topologies and combinations. The required equipment depends upon the wireless network topology you want to build. Make sure all required equipment is available before installing the unit. The unit is designed for outdoor placement.

  • Page 13: Management And Monitoring Capabilities

    Introduction MP.11-R Installation and Management Management and Monitoring Capabilities Up to 250 SUs can be connected to a BSU. If a BSU already has 250 SU, a new SU cannot be connected to the BSU. In this figure, the system is designed as follows: •...
  • Page 14 Proxim provides these MIB files on the CD included with your unit. You must compile one or more of these MIB files into your SNMP program’s database before you can manage your unit using SNMP. See the documentation that came with your SNMP manager for instructions about how to compile MIBs.

  • Page 15: Installation And Initialization

    MP.11-R Installation and Management Installation and Initialization This chapter describes the steps required to install and mount the unit, and to align the antenna. An antenna cable is required only when you use the external antenna option. Note that the unit must have either the integrated antenna or must be connected to an external antenna for its operation.

  • Page 16: Hardware Overview

    Installation and Initialization MP.11-R Installation and Management Hardware Overview Hardware Overview The unit contains a state-of-the-art wireless radio, an optional high-gain performance flat-panel antenna, and Power- over-Ethernet (the sole means of power for the unit). For further protection, the unit has internal, built-in surge protection. Power-over-Ethernet The unit is equipped with a Power-over-Ethernet (PoE) module.

  • Page 17: External Antenna Connection

    Installation and Initialization MP.11-R Installation and Management Hardware Overview The connections are as follows: D-Shell RJ11 1 + 3 + 5 External Antenna Connection One model of the SU has an integrated antenna; all other models have an external antenna connector (N-type) and no integrated antenna.

  • Page 18: Product Package

    Installation and Initialization MP.11-R Installation and Management Product Package Product Package Each shipment includes the items in the following table. Verify that you have received all parts of the shipment. NOTE: Unless noted in this table, cables are not supplied with the unit. SU with integrated antenna or BSU / SU with external antenna connector...
  • Page 19 Installation and Initialization MP.11-R Installation and Management Product Package Mounting Kit Kit includes the following: A. Mounting clamp for wall/pole B. Extension arm C. Mounting plate to enclosure D. Mounting clamp for pole mounting Mounting Hardware The following mounting hardware, included with the mounting kit: Quantity Description 6 ea.

  • Page 20: Hardware Installation

    IMPORTANT! There are no user-serviceable parts inside. All services must be performed by qualified personnel. CAUTION: For Regulatory Information and latest product updates, including firmware and the MIBs, Proxim recommends visiting the Proxim Support site at http://support.proxim.com. WARNING: To ensure proper grounding, use the hole at the designated ground point on the back of each unit and the provided grounding screws to attach a ground wire of at least 10 AWG stranded to each unit.
  • Page 21 Installation and Initialization MP.11-R Installation and Management Hardware Installation – Limited Power Source Output per UL/IEC 60950 – CE-marked – Approved for Power-over-Ethernet – Rated output, 48 Vdc/0.42 A – Pinout follows 802.3af standard for mid-span devices See the following sections for installation instructions: •...

  • Page 22: Step 1: Choose A Location

    2. Note the Ethernet and MAC addresses of the unit, as well as the serial number; these addresses may be used when configuring the unit. NOTE: The serial number is required to obtain support from Proxim. Keep this information in a safe place.

  • Page 23: Step 3: Assemble The Cable

    You will be attaching an outdoor-rated 24 AWG CAT5e/CAT6 cable to the Power-over-Ethernet port on the lower side of the unit. Proxim greatly simplifies this assembly process by offering pre-assembled RJ45 terminated, UV Rated, STP CAT5e/CAT6 cable kits in 25m, 50m, and 75m lengths (part numbers 76590, 76591, and 76592, respectively).

  • Page 24: Step 4: Determine Proper Mounting Orientation

    Installation and Initialization MP.11-R Installation and Management Hardware Installation Step 4: Determine Proper Mounting Orientation 1. Locate the arrow on the back of the unit and determine your desired mounting orientation. For vertical polarization using the integrated antenna, the arrow should be pointing up (perpendicular to the ground). For horizontal polarization using the integrated antenna, the arrow should be horizontal (parallel to the ground).

  • Page 25: Step 5: Assemble Mounting Hardware

    Installation and Initialization MP.11-R Installation and Management Hardware Installation Step 5: Assemble Mounting Hardware 1. Attach the mounting plate (A) using the provided screws and washers (Torque 9 N . m/75 in-lbs), such that the unit’s antenna will be vertically or horizontally polarized when mounted. Torque 9 N .

  • Page 26: Step 6: Mount The Unit

    Installation and Initialization MP.11-R Installation and Management Hardware Installation The following figure shows the full assembly attached to the unit. Note that this figure is for illustration only. The unit depicted is equipped with external antenna connectors, which allows rectangular mounting. Units with integrated antennas must always be mounted in diagonal position to achieve vertical or horizontal polarization as indicated by the arrow on the back of the unit.

  • Page 27: Step 7: Plug In The Cables

    Installation and Initialization MP.11-R Installation and Management Hardware Installation Step 7: Plug in the Cables 1. Plug one end of the CAT5e/CAT6 cable into the RJ45 jack of the unit. 2. Connect the free end of the CAT5e/CAT6 cable to the “Data and Power Out” port on the power injector. 3.

  • Page 28: Step 8: Power On The Unit

    Installation and Initialization MP.11-R Installation and Management Hardware Installation Step 8: Power on the Unit Once you have connected the power injector to the Ethernet cabling and plugged the power injector cord into an AC outlet, the unit is powered on. There is no ON/OFF switch on the unit. To remove power, unplug the AC cord from the AC outlet or disconnect the RJ45 connector from the “Data and Power Out”...

  • Page 29: Step 10: Align The Antenna

    Installation and Initialization MP.11-R Installation and Management Hardware Installation Step 10: Align the Antenna Antenna alignment is the process of physically aligning the antenna of the radio receiver and transmitter to have the best possible link established between them. The antenna alignment process is usually performed during installation and after major repairs.
  • Page 30 Installation and Initialization MP.11-R Installation and Management Hardware Installation • The Antenna Alignment Display (AAD) CLI command is disabled automatically 30 minutes after it is enabled to remove the load of extra messages on the wireless interface. The default telnet timeout is 900 seconds (15 minutes).

  • Page 31: Step 11: Install Documentation And Software

    Installation and Initialization MP.11-R Installation and Management Hardware Installation Step 11: Install Documentation and Software To install the documentation and software on a computer or network: 1. Place the CD in a CD-ROM drive. The installer normally starts automatically. (If the installation program does not start automatically, click setup.exe on the installation CD.) 2.

  • Page 32: Initialization

    10.0.0.1 configured. ScanTool lets you find the IP address of a Tsunami MP.11-R product by referencing the MAC address in a Scan List, or to assign an IP address if the correct one has not been assigned. The tool automatically detects the units installed on your network segment, regardless of IP address, and lets you configure each unit’s IP settings.
  • Page 33 Installation and Initialization MP.11-R Installation and Management Initialization 2. Select the unit for which you want to set the IP address and click Change. The Change dialog window is displayed, as shown below. 3. To set the IP address manually, ensure that Static is selected as the IP Address Type and fill in the IP Address and Subnet Mask suitable for the LAN subnet to which the unit is connected.

  • Page 34: Logging In To The Web Interface

    Installation and Initialization MP.11-R Installation and Management Logging in to the Web Interface Logging in to the Web Interface The Web Interface provides a graphical user interface through which you can easily configure and manage the unit. This section describes only how to access the Web Interface. To use the Web Interface, you need only the IP address of the unit.

  • Page 35: System Overview

    MP.11-R Installation and Management System Overview This chapter provides an overview of the system. See the following sections: • Changing Basic Configuration Information – Country and Related Settings – Dynamic Frequency Selection (DFS) – Transmit Power Control • SU Registration •...

  • Page 36: Dynamic Frequency Selection (Dfs)

    NOTE: Dynamic Frequency Selection (DFS) only applies to the Tsunami MP.11 5054-R. The Tsunami MP.11-R supports Dynamic Frequency Selection (DFS) for FCC, IC, and ETSI regulatory domains per FCC Part 15 Rules for U-NII devices, IC RSS-210, and ETSI EN 301-893 and 302-502 regulations, respectively. These rules and regulations require that 802.11a devices use DFS to prevent interference with radar systems and other devices that...

  • Page 37: Transmit Power Control

    System Overview MP.11-R Installation and Management Changing Basic Configuration Information Startup time is within four minutes if no radar is detected, but up to one minute is added for every selected channel that results in radar detection. DFS is required for three purposes: 1.
  • Page 38 System Overview MP.11-R Installation and Management Changing Basic Configuration Information dBm or less. For 4954-R models that have an integrated flat-panel antenna, a TPC of -9 dB must be used to comply with FCC Part 90 regulations. CAUTION: To ensure proper operation on 4954-R models, the maximum TPC attenuation is -9 db. Values from -10 dB to -18 dB are not usable.

  • Page 39: Su Registration

    System Overview MP.11-R Installation and Management SU Registration SU Registration The list of parameters you must configure for registration of the SU on a BSU are: • Network Name • Base Station System Name (when used; otherwise, leave blank) • Network Secret •...

  • Page 40: Dynamic Data Rate Selection (Ddrs)

    System Overview MP.11-R Installation and Management Dynamic Data Rate Selection (DDRS) Dynamic Data Rate Selection (DDRS) The WORP Dynamic Data Rate Selection (DDRS) lets the BSU and SUs monitor the remote average signal-to-noise ratio (SNR) and the number of retransmissions between the BSU and SUs and adjust the transmission data rate to an optimal value to provide the best possible throughput according to the current communication conditions and link quality.

  • Page 41: Virtual Local Area Networks (Vlans)

    VLAN configuration. Tsunami MP.11-R units are fully VLAN-ready; however, by default, VLAN support is disabled. Before enabling VLAN support, certain network settings should be configured and network resources such as VLAN-aware switches should be available, dependent upon the type of configuration.

  • Page 42: Quality Of Service (Qos)

    System Overview MP.11-R Installation and Management Quality of Service (QoS) Quality of Service (QoS) The Quality of Service (QoS) feature is based on the 802.16 standard and defines the classes, service flows, and packet identification rules for specific types of traffic. QoS main priority is to guarantee a reliable and adequate transmission quality for selected types of traffic under conditions of high congestion and bandwidth over-subscription.
  • Page 43 System Overview MP.11-R Installation and Management Quality of Service (QoS) b. IP Protocol List (17 = UDP) 6. TCP a. IP Protocol List (6) 7. UDP a. IP Protocol List (17) 8. PPPoE Control a. Ethertype (type 1, 0x8863) 9. PPPoE Data a.
  • Page 44 System Overview MP.11-R Installation and Management Quality of Service (QoS) Type: BE or RtPS. Best Effort (BE) is the default scheduler which follows the FIFO queuing. Real time Polling Scheduler (RtPS) is the advanced scheduler for time sensitive traffic like VoIP, Video traffic. •...
  • Page 45 System Overview MP.11-R Installation and Management Quality of Service (QoS) e. Minimum Reserved Traffic Rate = 2 Mbps Maximum Latency = 20 milliseconds g. Maximum Jitter = 20 milliseconds h. Traffic Priority = 1 Note that two different VoIP Service Flow classes for each direction of traffic have been defined (index numbers 3 to 6) which follow the ITU-T standard nomenclatures: G.711 refers to a type of audio companding and encoding that produces a 64 Kbps bitstream, suitable for all types of audio signals.
  • Page 46 System Overview MP.11-R Installation and Management Quality of Service (QoS) a. SF class: DL-2Mbps Video PIR: Streaming Video (IP/TV); PIR Priority: 1...

  • Page 47: Basic Management

    NOTE: If you have your Security Internet Options set to High, you may not be able to access the Web interface successfully; a high security setting disables JavaScript, which is required for running Proxim’s Web browser interface. Adding the radio’s IP address as a Trusted site should fix this problem.

  • Page 48: Rebooting And Resetting

    Save command, a power outage would wipe out all changes since the last reboot. For example, entering static routes takes effect immediately; however, the routes are not saved until the unit has gone through a controlled reboot. Proxim strongly recommends saving your settings immediately when you finish making changes. Rebooting When you reboot, the changes you have made become effective and the unit is restarted.
  • Page 49 Basic Management MP.11-R Installation and Management Rebooting and Resetting If you do not have access to the unit, you can use the procedure described in Hard Reset to Factory Default as an alternative.

  • Page 50: General Configuration Settings

    Basic Management MP.11-R Installation and Management General Configuration Settings General Configuration Settings • System Status: The Status tab showing the system status is displayed automatically when you log into the Web interface. It is also the default window displayed when you click Status on the left side of the window. See System Status.

  • Page 51: Monitoring Settings

    Basic Management MP.11-R Installation and Management Monitoring Settings Monitoring Settings The unit offers various facilities to monitor its operation and interfaces. Only the most significant monitoring categories are mentioned here. • Wireless: To monitor the wireless interfaces, click Monitor > Wireless. This tab lets you monitor the general performance of the radio and the performance of the WORP Base or WORP Satellite interfaces.

  • Page 52: Security Settings

    CCM protocol is now also supported. Proxim highly recommends you change the Network Name, Encryption Key, and Shared Secret as soon as possible. To do so, click Configure > Interfaces > Wireless. The encryption key is set using the Security tab. For systems that will use roaming features, the Network Name, Encryption Key, and the Shared Secret should each be the same for all SUs that are allowed to roam as well as for all BSUs to which these SUs are allowed to roam.

  • Page 53: Default Settings

    Basic Management MP.11-R Installation and Management Default Settings Default Settings Feature Default System Name Tsunami MP.11 [Model Name] Mode of Operation Bridge Routing Disabled IP Address Assignment Type Static IP Address 10.0.0.1 Subnet Mask 255.255.255.0 Default Router IP Address 10.0.0.1 Default TTL RIPv2 Enabled.
  • Page 54 Basic Management MP.11-R Installation and Management Default Settings Feature Default DFS Priority Frequency Disabled Channel DFS Antenna Gain 17 dB Announcement Period (when 100 ms roaming enabled) Multi-Frame Bursting Enabled Storm Threshold Broadcast/Multicast Unlimited Broadcast Protocol Filtering All Protocols Allowed Dynamic Data Rate Selection Disabled Roaming...

  • Page 55: Upgrading The Unit

    Documentation and Software CD; the server is required to transfer the downloaded file to the unit. See TFTP Server Setup. To access all resolved problems in our solution database, or to search by product, category, keywords, or phrases, go to http://support.proxim.com. You can also find links to drivers, documentation, and downloads at this link.

  • Page 56: System Status

    MP.11-R Installation and Management System Status This chapter describes viewing system status and event log information from the unit’s Web Interface. Click Status to access system and event log information. See the following sections: • Status • Event Log Help and Exit buttons also appear on each page of the Web interface; click Help to access online help; click Exit to exit the application.

  • Page 57: Systems Traps

    System Status MP.11-R Installation and Management Status Systems Traps This section also displays the status of system traps. System traps occur when the unit encounters irregularities. Deleting system traps has no effect on the operation of the unit. System traps are also sent to an SNMP manager station (if so configured).

  • Page 58: Event Log

    System Status MP.11-R Installation and Management Event Log Event Log Click Status > Event Log to view the contents of your Event Log. The Event Log keeps track of events that occur during the operation of the unit. The Event Log displays messages that may not be captured by System Traps, such as the Transmit Power for the Frequency Channel selected.

  • Page 59: Configuration

    MP.11-R Installation and Management Configuration This chapter describes configuring the unit’s settings using the unit’s Web Interface. Click Configure to access configuration settings. The following topics are discussed in this section: • System Parameters • Network Parameters • Interface Parameters •...
  • Page 60 Configuration MP.11-R Installation and Management System Parameters You can enter the following details: • System Name: This is the system name for easy identification of the BSU or SU. The System Name field is limited to a length of 32 characters. Use the system name of a BSU to configure the Base Station System Name parameter on an SU if you want the SU to register only with this BSU.

  • Page 61: Bridge And Routing Modes

    Configuration MP.11-R Installation and Management System Parameters • ObjectID: This field shows the OID of the product name in the MIB. • Ethernet MAC Address: The MAC address of the Ethernet interface of the device. • Descriptor: Shows the product name and firmware build version. •...
  • Page 62 Configuration MP.11-R Installation and Management System Parameters The use of Routing mode requires more attention to the configuration of the unit and thorough planning of the network topology of your outdoor network. The unit can use Routing mode in any combination of BSU and SUs. For example, you may have the BSU in Routing mode and the SU in Bridge mode, or vice versa.
  • Page 63 Configuration MP.11-R Installation and Management System Parameters Notes: • One of the most important details to pay attention to in Routing mode are the unit’s and the PC’s default gateways. It is a common mistake to set up the PC’s gateway to point to the SU when the SU is in Bridge mode and the BSU is in Routing mode.

  • Page 64: Network Parameters

    Configuration MP.11-R Installation and Management Network Parameters Network Parameters The Network tab contains the following sub-tabs. Note that the availability of some sub-tabs depends on whether the unit is in Bridge or Routing Mode. • IP Configuration • Roaming • DHCP Server •...

  • Page 65: Ip Configuration

    Configuration MP.11-R Installation and Management Network Parameters • Default TTL: The default time-to-live value. Routing Mode If the device is configured in Routing mode, both Ethernet and Wireless interfaces require an IP address. The following screen is displayed: IP Configuration Configure or view the following parameters: •...
  • Page 66 Configuration MP.11-R Installation and Management Network Parameters • The slow scanning procedure starts when the average local SNR for the current BSU is less than or equal to the slow scanning threshold and the number of retransmitted frames is greater than the slow scanning threshold given in percentage.
  • Page 67 Configuration MP.11-R Installation and Management Network Parameters BSU Roaming Configuration View or set the following parameters: • Enable Roaming Status: Enable or disable the Roaming feature by selecting or de-selecting the checkbox. The default value is disabled (clear). • Announcement Period: If you enable roaming, you may set the Announcement Period for a value between 25 to 100 ms.
  • Page 68 Configuration MP.11-R Installation and Management Network Parameters Note that an SU may roam from one BSU with a bandwidth setting to another BSU with a different bandwidth setting. Since in this case more channels need to be scanned than with only one channel bandwidth setting, it is important that the channel priority list mentioned above is properly used to limit scanning time.

  • Page 69: Dhcp Server

    Configuration MP.11-R Installation and Management Network Parameters DHCP Server When enabled, the DHCP server allows allocation of IP addresses to hosts on the Ethernet side of the SU or BSU (or) to the connected SU's (in case, the DHCP server is enabled in BSU). Specifically, the DHCP Server feature lets the SU or BSU respond to DHCP requests from Ethernet hosts/connected SU's (in case, the DHCP server is enabled in BSU) with the following information: •...
  • Page 70 Configuration MP.11-R Installation and Management Network Parameters Add Entries to the DHCP Server IP Pool Table You can add up to 20 entries in the IP Pool Table. An IP address can be added if the entry’s network ID is the same as the network ID of the device.

  • Page 71: Spanning Tree (Bridge Mode Only)

    WDS link between two units connected to the same Ethernet network creates a network loop (if spanning tree is disabled). The Spanning Tree configuration options are advanced settings. Proxim recommends that you leave these parameters at their default values unless you are familiar with the Spanning Tree protocol.

  • Page 72: Sntp-Dns

    Configuration MP.11-R Installation and Management Network Parameters SNTP-DNS SNTP-DNS Overview The Simple Network Time Protocol (SNTP) allows for a network entity to communicate with time servers in the network/ internet to retrieve and synchronize time of day information. If SNTP feature is enabled, the device will attempt to retrieve the time of day from the configured time servers (primary or secondary).

  • Page 73: Configuring Sntp-Dns

    Configuration MP.11-R Installation and Management Network Parameters Synchronizing Time of Day If the SNTP client is successful in retrieving the time of day information, then it resends time of day requests to the server it is communicating with every ten minutes. This is a fixed value and is not configurable. This is done in order to synchronize the time.

  • Page 74: Ip Routes (Routing Mode Only)

    Configuration MP.11-R Installation and Management Network Parameters IP Routes (Routing Mode only) NOTE: The unit must be in Routing mode to configure IP Routes. Click Configure > Network > IP Routes to configure. Add IP Routes 1. Click Add to add entries; the following screen is displayed.
  • Page 75 Configuration MP.11-R Installation and Management Network Parameters 2. Enter the route information 3. Click Add. The IP Address and Subnet Mask combination is validated for a proper combination. NOTE: When adding a new entry, the IP address of the Route Destination must be in either the Ethernet subnet or in the wireless subnet of the unit.

  • Page 76: Dhcp Relay Agent (Routing Mode Only)

    Configuration MP.11-R Installation and Management Network Parameters DHCP Relay Agent (Routing Mode Only) NOTE: The unit must be in Routing mode to configure DHCP Relay Agent. Click Configure > Network > DHCP RA to enable the unit’s DHCP Relay Agent. When enabled, the DHCP relay agent forwards DHCP requests to the set DHCP server.
  • Page 77 Configuration MP.11-R Installation and Management Network Parameters 2. Enter your changes, and click OK.

  • Page 78: Interface Parameters

    Configuration MP.11-R Installation and Management Interface Parameters Interface Parameters The Interface tab contains the following sub-tabs. • Wireless Interface – Base Mode – Satellite Mode • Ethernet Wireless Interface To configure the wireless interface, click Configure > Interfaces > Wireless. For Base Station units, the wireless interface can be placed in either WORP Base or WORP Satellite mode (selected from the Interface Type drop-down box).
  • Page 79 Configuration MP.11-R Installation and Management Interface Parameters • MAC Address: The factory-assigned MAC address of the unit. This is a read-only field. • Network Name: A Network Name is a name given to a network so that multiple networks can reuse the same frequency without problems.
  • Page 80 Configuration MP.11-R Installation and Management Interface Parameters NOTE: The additional sensitivity is provided with the impact of using twice as much spectrum and thus increasing the opportunity of interference and decreased ability for system collocation. Generally, Turbo mode is not recommended except when the extra sensitivity is absolutely required.
  • Page 81 Configuration MP.11-R Installation and Management Interface Parameters • DFS Antenna Gain You can modify the sensitivity of the radio card when detecting radar signals in accordance with ETSI, FCC, and IC Dynamic Frequency Selection (DFS) requirements. Given the radar detection threshold is fixed by ETSI, the FCC, and IC and that a variety of antennas with different gains may be attached to the unit, you must adjust this threshold to account for higher than expected antenna gains and avoid false radar detection events.
  • Page 82 Configuration MP.11-R Installation and Management Interface Parameters – No Multi-Frame Burst Support –To disable Multi-Frame burst support, click Configure > Network > Roaming, and select “Disable” on the drop-down box (see BSU Roaming Configuration). In this case, each active SFC is limited to send a single data message.
  • Page 83 Configuration MP.11-R Installation and Management Interface Parameters • WORP Error Percentage Threshold: This parameter is used to configure WORP Error Percentage Threshold for the generation of Trap. The device calculates the WORP errors percentage every second. If the error percentage is more than the configured threshold, trap is generated.
  • Page 84 Configuration MP.11-R Installation and Management Interface Parameters Additionally, the BSU screen for countries that require DFS contains the sections described below. • DFS Preferred Channel: A single DFS preferred frequency channel on the BSU is provided so that when the DFS process starts the BSU will first try the DFS preferred channel before scanning all the other active channels in the DFS channel list.
  • Page 85 Configuration MP.11-R Installation and Management Interface Parameters Edit Entries to the Channel Blacklist Table In accordance with ETSI, IC, and FCC non-occupancy rules, when interference is detected on any active channel, that channel will be blacklisted. The channel will not be used for a period of 30 minutes after the interference has been detected.
  • Page 86 Configuration MP.11-R Installation and Management Interface Parameters Satellite Mode The mandatory parameters to configure for registration of the SU on a Base Station are: • Network Name • Base Station System Name (when used) • Channel Frequency • Encryption (when used) •...
  • Page 87 Configuration MP.11-R Installation and Management Interface Parameters • Network Name: A Network Name is a name given to a network so that multiple networks can reuse the same frequency without problems. An SU can only register to its base if it has the same Network Name. The Network Name is one of the parameters that allow a Subscriber Unit to register on a Base Station.
  • Page 88 Configuration MP.11-R Installation and Management Interface Parameters NOTE: The additional sensitivity is provided with the impact of using twice as much spectrum and thus increasing the opportunity of interference and decreased ability for system collocation. Generally, Turbo mode is not recommended except when the extra sensitivity is absolutely required.
  • Page 89 Configuration MP.11-R Installation and Management Interface Parameters • Satellite Density: The Satellite Density setting is a valuable feature for achieving maximum bandwidth in a wireless network. It influences the receive sensitivity of the radio interface and improves operation in environments with a high noise level.

  • Page 90: Ethernet

    Configuration MP.11-R Installation and Management Interface Parameters Model Name Parameter Value Input Bandwidth limit (Kbps) Output Bandwidth limit (Kbps) 5054-R(BSU Mode) 36032 36032 5054-R(SU Mode) 108032 108032 SU Bandwidth Limit Configuration via Radius Server SU Bandwidth Limit Configuration via Radius Server is used for centralized management of SU’s Input and Output Bandwidth throttling limits configuration.
  • Page 91 Configuration MP.11-R Installation and Management Interface Parameters You can set the desired speed and transmission mode by clicking on Configuration. The recommended setting is auto-speed-auto-duplex, but you may select from these settings for the type of Ethernet transmission: • Half-duplex means that only one side can transmit at a time. •...

  • Page 92: Snmp Parameters

    Configuration MP.11-R Installation and Management SNMP Parameters SNMP Parameters Click Configure > SNMP to enable or disable trap groups, and to configure the SNMP management stations to which the unit sends system traps. See “Trap Groups” in the Tsunami MP.11/QB.11 Reference Manual for a list of the system traps. •...
  • Page 93 Configuration MP.11-R Installation and Management SNMP Parameters...

  • Page 94: Management Parameters

    Configuration MP.11-R Installation and Management Management Parameters Management Parameters Use the Management tab to configure passwords and other service parameters. Passwords The Password tab lets you configure the SNMP, Telnet, and HTTP (Web Interface) passwords. For all password fields, the passwords must be between 6 and 32 characters. Changes take effect immediately after you click OK.
  • Page 95 Configuration MP.11-R Installation and Management Management Parameters SNMP Configuration Settings • SNMP Interface Bitmask: Configure the interface or interfaces (Ethernet, Wireless, All Interfaces) from which you will manage the unit using SNMP. You also can select Disabled to prevent a user from accessing the unit through SNMP.
  • Page 96 Serial Flow Control: Select either None (default) or Xon/Xoff (software controlled) data flow control. To avoid potential problems when communicating with the unit through the serial port, Proxim recommends that you leave the Flow Control setting at None (the default value).

  • Page 97: Security Parameters

    Configuration MP.11-R Installation and Management Security Parameters Security Parameters MAC Authentication (BSU Only) Click Configure > Security > MAC Auth to build a list of authorized wireless stations that can register at the unit and access the network. MAC Authentication is supported on the wireless interface and only wireless MAC addresses should be entered in the list.

  • Page 98: Encryption

    Configuration MP.11-R Installation and Management Security Parameters Encryption NOTE: Be sure to set the encryption parameters and change the default passwords. You can protect the wireless data link by using encryption. In addition to Wired Equivalent Privacy (WEP), the unit supports Advanced Encryption Standard (AES) 128-bit encryption.
  • Page 99 Configuration MP.11-R Installation and Management Security Parameters...

  • Page 100: Filtering Parameters

    LAN data from being bridged to an untrusted remote network or the Internet. To prevent blocking your own access (administrator) to the unit, Proxim recommends that IP (0x800) and ARP (0x806) protocols are always passed through.

  • Page 101: Ethernet Protocol

    Configuration MP.11-R Installation and Management Filtering Parameters consume valuable wireless bandwidth. On some networks, there are so many ARP broadcasts that the performance of the wireless network will degrade due to the amount of bandwidth being consumed by these messages. To reduce the number of ARP broadcasts that are forwarded to the wireless nodes, you can enable ARP filtering.

  • Page 102: Static Mac Address Filtering

    Configuration MP.11-R Installation and Management Filtering Parameters • To add a new filter to the filter table: – Enter the Protocol Number. See http://www.iana.org/assignments/ethernet-numbers for a list of protocol numbers. – Enter the Protocol Name. – Click Add. Edit/Delete Entries in the Filter Table 1.
  • Page 103 Configuration MP.11-R Installation and Management Filtering Parameters Static MAC Filter Examples Consider a network that contains a wired server and three wireless clients. The MAC address for each unit is as follows: • Wired Server: 00:40:F4:1C:DB:6A • Wireless Client 1: 00:02:2D:51:94:E4 •...
  • Page 104 Configuration MP.11-R Installation and Management Filtering Parameters Prevent Messages Destined for a Specific Multicast Group from Being Forwarded to the Wireless LAN If devices on your Ethernet network use multicast packets to communicate and these packets are not required by your wireless clients, you can set up a Static MAC filter to preserve wireless bandwidth.

  • Page 105: Storm Threshold

    Configuration MP.11-R Installation and Management Filtering Parameters The following fields are may be configured or viewed: • Wired MAC Address: Enter the MAC address of the device on the Ethernet network that you want to prevent from communicating with a device on the wireless network. •...

  • Page 106: Broadcast Protocol Filtering

    Configuration MP.11-R Installation and Management Filtering Parameters Broadcast Protocol Filtering Click Configure > Filtering > Broadcast Protocol to deny specific IP broadcast, IPX broadcast, and multicast traffic. Click Edit Table Entries to display an editable window such as the following. You can configure whether this traffic must be blocked for Ethernet to wireless, wireless to Ethernet, or both.
  • Page 107 Configuration MP.11-R Installation and Management Filtering Parameters Add Entries to the IP Access Table To add an entry, click Add Table Entries, specify the IP address and mask of the wireless stations to which you want to grant access, and click Add. CAUTION: Ensure that the IP address of the management PC you use to manage the unit is within the first entry in the table, as this filter takes effect immediately.
  • Page 108 Configuration MP.11-R Installation and Management Filtering Parameters...

  • Page 109: Intra-Cell Blocking (Bsu Only; Bridge Mode Only)

    Configuration MP.11-R Installation and Management Intra-Cell Blocking (BSU Only; Bridge Mode Only) Intra-Cell Blocking (BSU Only; Bridge Mode Only) Overview The Intra-Cell Blocking feature lets traffic be blocked between two SUs registered to the same Base Station. There are two potential reasons to isolate traffic among wireless subscribers: •...
  • Page 110 Configuration MP.11-R Installation and Management Intra-Cell Blocking (BSU Only; Bridge Mode Only) The following items are configurable: • Intra-Cell Blocking Status: Enables or disables the Intra-Cell Blocking feature. • Group Table: Entries in this table show the Intra-Cell Blocking filter groups that have been configured. When Intra- Cell Blocking is enabled, the Base Station Unit discards all packets coming from one SU to another SU, if both SUs do not belong to the same filter group.

  • Page 111: Mac Table

    Configuration MP.11-R Installation and Management Intra-Cell Blocking (BSU Only; Bridge Mode Only) MAC Table After configuring the Intra-Cell Blocking Groups on the Group Table tab, use the MAC Table tab to assign specific MAC addresses to an Intra-Cell Blocking Group. Adding Entries Click Add Table Entries.

  • Page 112: Security Gateway

    Configuration MP.11-R Installation and Management Intra-Cell Blocking (BSU Only; Bridge Mode Only) Enter the MAC address of the SU. Select Enable from the drop-down menu for the Group Index. Click Add. The MAC address is assigned to the groups. Additions to the MAC Table take effect immediately after clicking Add.
  • Page 113 Configuration MP.11-R Installation and Management Intra-Cell Blocking (BSU Only; Bridge Mode Only) • Security Gateway Status: Enables or disables packet forwarding to the external Security Gateway. • Security Gateway MAC Address: Lets you configure the MAC address of the external Security Gateway.

  • Page 114: Vlan Parameters

    Configuration MP.11-R Installation and Management VLAN Parameters VLAN Parameters Overview For an introduction to VLAN principles, see Virtual Local Area Networks (VLANs). NOTE: VLANs are configurable only in Bridge mode. VLAN Modes Transparent Mode Transparent mode is available on both the SU and the BSU. This mode is equivalent to NO VLAN support and is the default mode.
  • Page 115 Configuration MP.11-R Installation and Management VLAN Parameters...
  • Page 116 Configuration MP.11-R Installation and Management VLAN Parameters SU Function SU Function SU Function SU Function –Transparent Mode –Trunk Mode –Access Mode –Mixed Mode • SU forwards both • Up to 16 VLAN IDs can be • SU discards all tagged •...

  • Page 117: Bsu Vlan Configuration

    Configuration MP.11-R Installation and Management VLAN Parameters BSU VLAN Configuration The HTTP Interface to configure BSU VLAN parameters is shown in the following figure. Configure the following parameters: • BSU VLAN Mode: The BSU VLAN mode can be either Transparent, Trunk, or Mixed. By default, the BSU is in Transparent mode.

  • Page 118: Su Vlan Configuration

    Configuration MP.11-R Installation and Management VLAN Parameters Edit or Delete BSU VLAN Table Entries To edit or delete entries in the BSU VLAN Table, click Edit/Delete Table Entries, make your changes, then click OK for your changes to take effect. Restricting Unit Management Management access to the unit can be easily secured by making management stations or hosts and the unit itself members of a common VLAN.
  • Page 119 Configuration MP.11-R Installation and Management VLAN Parameters Add SU Table Entries To add entries to the SU VLAN Table, click Add Table Entries. Enter the desired parameters in the corresponding fields, then click Add to add and save the entry. The following parameters are configurable: •...
  • Page 120 Configuration MP.11-R Installation and Management VLAN Parameters • Access VLAN ID: The Access VLAN ID is configurable in any mode, but applies only when the SU is in Access mode. The Access VLAN ID values range from 1 to 4094; the default value is 1. •...

  • Page 121: Su Vlan Functionality

    Configuration MP.11-R Installation and Management VLAN Parameters SU VLAN Functionality To change SU VLAN Status, select Enable/Disable from the drop-down menu. Make your changes on the window displayed, then click OK to save your changes. SU VLAN status is a user-defined parameter. When SU VLAN status is enabled, SU operates with the VLAN parameters configured on SU.

  • Page 122: Su Vlan Configuration Via Radius Server

    Configuration MP.11-R Installation and Management VLAN Parameters When SU VLAN status is disabled, user cannot modify the other VLAN parameters on SU. To modify the VLAN parameters, user has to do changes in SU VLAN table on BSU as SU VLAN is disabled. During SU registration with BSU, SU accepts VLAN configuration from BSU and operates with those values.
  • Page 123 Configuration MP.11-R Installation and Management VLAN Parameters For example, consider the above diagram which has a Radius Server at its back-end with two different BSU’s: BSU1 and BSU2 and one SU in roaming. Let's assume that user has pre-configured SU VLAN configuration on Radius Server as: SU in Access Mode &...

  • Page 124: Qos (Quality Of Service) Parameters (Bsu Only)

    Configuration MP.11-R Installation and Management QoS (Quality of Service) Parameters (BSU Only) QoS (Quality of Service) Parameters (BSU Only) The Quality of Service (QoS) feature is based on 802.16 standard and defines the classes, service flows (SFCs), and packet identification rules (PIRs) for specific types of traffic. The main priority of QoS is to guarantee a reliable and adequate transmission quality for all traffic types under conditions of high congestion and bandwidth over-subscription (for a complete discussion on QoS see Quality of Service...

  • Page 125: Qos Sfc Configuration

    Configuration MP.11-R Installation and Management QoS (Quality of Service) Parameters (BSU Only) To add entries to the PIR Table, click Add Table Entries. Enter the Rule Name and select Enable or Disable from the Entry Status drop-down box, then click Add to add the entry. Once the new entry appears in the QoS PIR Table on this page, click Details to view/edit its parameters.
  • Page 126 Configuration MP.11-R Installation and Management QoS (Quality of Service) Parameters (BSU Only) To add entries to the SFC Table, click Add Table Entries. The following parameters are configurable: • SF Name: Enter the name of the SF class you want to add. •...

  • Page 127: Qos Class Configuration

    Configuration MP.11-R Installation and Management QoS (Quality of Service) Parameters (BSU Only) • CIR (Committed Information Rate): The minimum reserved traffic rate specified in units of 1 Kbps from 0 Kbps up to the maximum rate of 10000 Kbps per SU. •...
  • Page 128 Configuration MP.11-R Installation and Management QoS (Quality of Service) Parameters (BSU Only) Create a New QoS Class On the QoS Class screen, click Add Table Entries. The following parameters are configurable: • Class Name: Enter the name of the QoS class you want to add.
  • Page 129 Configuration MP.11-R Installation and Management QoS (Quality of Service) Parameters (BSU Only) • SF Table Reference Index: Select one of the possible SFCs that have been previously configured from the drop- down box to associate to this QoS Class. • PIR Table Reference Index: Select one of the possible PIRs that have been previously configured from the drop- down box to associate to this SFC.
  • Page 130 Configuration MP.11-R Installation and Management QoS (Quality of Service) Parameters (BSU Only) You may enable, disable or delete this SFC entry by clicking on the Status drop-down box and then clicking OK. To add more PIRs to this SFC click Add Table Entries.
  • Page 131 Configuration MP.11-R Installation and Management QoS (Quality of Service) Parameters (BSU Only) Configure the following parameters: • PIR Table Reference Index: Select one of the possible PIRs that have been previously configured from the drop- down box. • PIR Priority: This priority per rule defines the order of execution of PIRs during packet identification process. The PIR priority is a number in the range 0-63, with priority 63 being executed first, and priority 0 being executed last.

  • Page 132: Qos Su Configuration

    Configuration MP.11-R Installation and Management QoS (Quality of Service) Parameters (BSU Only) • PIR Priority: This priority per rule defines the order of execution of PIRs during packet identification process. The PIR priority is a number in the range 0-63, with priority 63 being executed first, and priority 0 being executed last. The PIR priority is defined within a QoS class, and can be different for the same PIR in some other QoS class.

  • Page 133: Qos Configuration For A Management Station

    Configuration MP.11-R Installation and Management QoS (Quality of Service) Parameters (BSU Only) • SU QOSC Index: Select one of the possible QoS Classes that have been previously configured from the drop-down box to associate to this SU. • SU QOSC State: This field can be set to Enable, Disable, or Delete. Click Add to add the entry.
  • Page 134 Configuration MP.11-R Installation and Management QoS (Quality of Service) Parameters (BSU Only) Step 1: Add Packet Identification Rules To recognize management traffic, the system needs to recognize ARP requests/responses and any traffic coming from or going to the management station. A.
  • Page 135 Configuration MP.11-R Installation and Management QoS (Quality of Service) Parameters (BSU Only) • IP Address or MAC Address: IP address or MAC Address of management station • IP Mask or MAC Mask: 255.255.255.255 (for IP Mask) or FF:FF:FF:FF:FF:FF (for MAC mask) 17.

  • Page 136: Qos Configuration Via Radius Server

    Configuration MP.11-R Installation and Management QoS (Quality of Service) Parameters (BSU Only) Step 3: Configure QoS Classes Finally, the DL-Management SFC and UL-Management SFCs created in Step 2 must be added to each QoS Class used by the TMP.11 network. Additionally, within the QoS class, these SFC must have the three PIRs mentioned in Step 1 associated with them.
  • Page 137 Configuration MP.11-R Installation and Management QoS (Quality of Service) Parameters (BSU Only) For example, consider the above diagram which has a Radius Server at its back-end with two different BSU’s: BSU1 and BSU2 and one SU in roaming. Let's assume that user has pre-configured the QoS configuration on Radius Server as: QoS class index - 3 and QoS class entry status - enable.

  • Page 138: Syslog Parameters

    Configuration MP.11-R Installation and Management Syslog Parameters Syslog Parameters Overview System log messages are generated by the system by sending requests at various instances to the system log server. Every message in the system carries a priority of that message. This priority indicates the importance of the message. The messages which have a priority higher than the configured syslog priority are sent to Syslog Server.

  • Page 139: Syslog Host Table

    Configuration MP.11-R Installation and Management Syslog Parameters Syslog Host Table To add entries to the Syslog Host Table, click Add Table Entries. Enter the IP Address of the syslog server in the IP Address field. Enter a Port Number (between 1 - 65535) in the Port Number field and enter an optional comment in the Comment field.

  • Page 140: Rip Parameters (Routing Mode Only)

    Configuration MP.11-R Installation and Management RIP Parameters (Routing Mode Only) RIP Parameters (Routing Mode Only) Routing Internet Protocol (RIP) is a dynamic routing protocol you can use to help automatically propagate routing table information between routers. The unit can be configured as RIPv1, RIPv2, RIPv1 Compatible, or a combination of the three versions while operating in Routing mode.

  • Page 141: Rip Example

    Configuration MP.11-R Installation and Management RIP Parameters (Routing Mode Only) RIPv1 RIPv2 RIPv1 Compatible Distance-vector protocol Distance-vector protocol Distance-vector protocol Metric-Hops Metric-Hops Metric-Hops Maximum Distance 15 Maximum Distance 15 Maximum Distance 15 RIP Example In the following example, assume that both the BSU and the SUs all are configured in Routing mode with RIP enabled to send and receive on both the Ethernet and Wireless interfaces.

  • Page 142: Nat (Su Only; Routing Mode Only)

    Configuration MP.11-R Installation and Management NAT (SU Only; Routing Mode Only) NAT (SU Only; Routing Mode Only) The NAT (Network Address Translation) feature lets hosts on the Ethernet side of the SU transparently access the public network through the BSU. All hosts in the private network can have simultaneous access to the public network. NOTE: The SU supports NAPT (Network Address Port Translation) where all private IP addresses are mapped to a single public IP address, and does not support Basic NAT (where private IP addresses are mapped to a pool of public IP addresses).

  • Page 143: Nat Static Port Mapping Table

    Configuration MP.11-R Installation and Management NAT (SU Only; Routing Mode Only) NAT Static Port Mapping Table Adding entries to the NAT Static Mapping Table lets configured hosts in a private address realm on the Ethernet side of the SU access hosts in the public network using Network Address Port Translation (NAPT). At the most, 1000 ports can be configured (500 UDP ports and 500 TCP ports).
  • Page 144 Configuration MP.11-R Installation and Management NAT (SU Only; Routing Mode Only) No more than one server of a particular type is supported within the private network behind the SU. These VPN protocols are supported with their corresponding ALGs: IPsec, PPTP, L2TP. The following session protocols are supported: Protocol Support...
  • Page 145 Configuration MP.11-R Installation and Management NAT (SU Only; Routing Mode Only)

  • Page 146: Monitoring

    MP.11-R Installation and Management Monitoring This chapter describes using the Web interface to obtain detailed information about the settings and performance of the unit. Click Monitor to access this information. The following tabs appear in the Monitor section: • Wireless •...

  • Page 147: Wireless

    Monitoring MP.11-R Installation and Management Wireless Wireless General Performance Click Monitor > Wireless > General to monitor the general performance of the wireless interface. WORP Interface Performance Click Monitor > Wireless > WORP tab to monitor the performance of the WORP Base or WORP SU interfaces. The Registration Last Reason field indicates either a successful registration (a value of 1) or it indicates the reason why the last registration failed.
  • Page 148 Monitoring MP.11-R Installation and Management Wireless • None (successful registration) • Maximum number of SUs reached • Authentication failure • Roaming • No response from SU within the Registration Timeout Period • Low Signal Quality...

  • Page 149: Icmp

    Monitoring MP.11-R Installation and Management ICMP ICMP Click Monitor > ICMP to view the number of ICMP messages sent and received by the unit. It includes ping, route, and host unreachable messages.

  • Page 150: Per Station

    Monitoring MP.11-R Installation and Management Per Station Per Station Click Monitor > Per Station to view Station Statistics. On the BSU, this page shows statistics of all the SU’s connected to the BSU. The page’s statistics refresh every 4 seconds. To start or stop the page refreshing, click Stop Refresh and Start Refresh.

  • Page 151: Features

    Monitoring MP.11-R Installation and Management Features Features Click Monitor > Features to view the following information. NOTE: A BSU shows how many WORP SUs it can support; the SU shows how many Ethernet hosts it supports on its Ethernet port as the “Max Users on Satellite” parameter.

  • Page 152: Link Test

    Monitoring MP.11-R Installation and Management Link Test Link Test Click Monitor > Link Test to find out which wireless stations are in range and to check their link quality. NOTE: Link Test requires Internet Explorer version 6.0 or later. Earlier versions do not support Link Test. Link Test for the unit reports the Signal-to-Noise Ratio (SNR) value in dB;...

  • Page 153: Interfaces

    Monitoring MP.11-R Installation and Management Interfaces Interfaces Click Monitor > Interfaces to view detailed information about the IP-layer performance of the unit’s interfaces. There are two sub-tabs: Wireless and Ethernet. The following figures show both interfaces.

  • Page 154: Ip Arp Table

    Monitoring MP.11-R Installation and Management IP ARP Table IP ARP Table Click Monitor > IP ARP Table to view the mapping of the IP and MAC addresses of all entities which communicate with the device directly. This information is based upon the Address Resolution Protocol (ARP).

  • Page 155: Ip Routes

    Monitoring MP.11-R Installation and Management IP Routes IP Routes Click Monitor > IP Routes to view all active IP routes of the unit. These can be either static or dynamic (obtained through RIP).

  • Page 156: Learn Table

    Monitoring MP.11-R Installation and Management Learn Table Learn Table Click Monitor > Learn Table to view all MAC addresses the unit has detected on an interface. The Learn Table displays information relating to network bridging. It reports the MAC address for each node that the device has learned on the network and the interface on which the node was detected.

  • Page 157: Rip

    Monitoring MP.11-R Installation and Management Click Monitor > RIP to view Routing Internet Protocol data for the Ethernet and Wireless interfaces.

  • Page 158: Radius (Bsu Only)

    Monitoring MP.11-R Installation and Management RADIUS (BSU Only) RADIUS (BSU Only) Click Monitor > Radius to view information about the traffic exchanged with a RADIUS server.

  • Page 159: Qos (Bsu Only)

    Monitoring MP.11-R Installation and Management QoS (BSU Only) QoS (BSU Only) Click Monitor > QoS to view summary information about the Quality of Service per BSU and for each SU registered with that BSU.

  • Page 160: Temperature

    Monitoring MP.11-R Installation and Management Temperature Temperature The feature for reporting and logging internal unit temperature observes and reports the internal temperature of the unit. Temperature is logged and an SNMP trap sent when the internal temperature crosses the limit of 0ºC to 55ºC (at 5 degrees before the limit, the unit issues a warning trap).

  • Page 161: Spectrum Analyser

    Monitoring MP.11-R Installation and Management Spectrum Analyser Spectrum Analyser Spectrum Analyser scans the spectrum to compute Max and Min Received Signal Strength Indication (RSSI) on each channel. RSSI is a measurement of the power present in a received radio signal. The Max and Min RSSI on each channel is calculated by considering the background noise.

  • Page 162: Index

    Monitoring MP.11-R Installation and Management Spectrum Analyser Index It indicates the serial number of each channel. Channel Number and Channel Frequency This field displays the channel number and frequency of scanned channels. Recognised Frames This field displays the total number of recognised frames received on a channel while scanning. Unrecognised Frames This field displays the total number of unrecognised frames in a channel while scanning.

  • Page 163: Commands

    MP.11-R Installation and Management Commands This chapter describes the commands that you can issue with the Web Interface. Click Commands to access available commands. See the following: • Download • Upload • Reboot • Reset • Help Link • Downgrade Help and Exit buttons also appear on each page of the Web interface;...

  • Page 164: Upload

    Commands MP.11-R Installation and Management Upload Upload Click Commands > Upload to upload a configuration or log file from the unit to a TFTP server (see TFTP Server Setup for information about the SolarWinds TFTP server software located on your product installation CD). Enter the following information: •...

  • Page 165: Reboot

    Commands MP.11-R Installation and Management Reboot Reboot Click Commands > Reboot to reboot the unit’s embedded software. Configuration changes are saved and the unit is reset. CAUTION: Rebooting the unit causes all users currently connected to lose their connection to the network until the unit has completed the reboot process and resumed operation.

  • Page 166: Reset

    Commands MP.11-R Installation and Management Reset Reset Click Commands > Reset to restore the configuration of the unit to the factory default values. You can also reset the unit by pressing the RELOAD button located on the side of the power brick. See Hard Reset to Factory Default for more information.

  • Page 167: Help Link

    Commands MP.11-R Installation and Management Help Link Help Link Click Commands > Help Link to set the location of the help files of the Web Interface. Upon installation, the help files are installed in the C:\Program Files\Tsunami\MP.11 [Product Name]\Help folder. If you want to place these files on a shared drive, copy the Help folder to the new location and specify the new path in the Help Link box.

  • Page 168: Downgrade

    Commands MP.11-R Installation and Management Downgrade Downgrade Click Commands > Downgrade to downgrade to a previous release. Downgrade currently is supported only to release 2.0.1 and later. Once you enter this command, the unit is downgraded to the specified release and is automatically rebooted.

  • Page 169: Procedures

    MP.11-R Installation and Management Procedures This chapter describes the following procedures: • TFTP Server Setup: Prepares the TFTP server for transferring files to and from the unit. This procedure is used by the other procedures that transfer files. • Web Interface Image File Download: Upgrades the embedded software.

  • Page 170: Tftp Server Setup

    The SolarWinds TFTP server software is located on the product installation CD, or can be downloaded from http://support.proxim.com. You can also download the latest TFTP software from SolarWind’s Web site at http://www.solarwinds.net. The instructions that follow assume that you are using the SolarWinds TFTP server software;...

  • Page 171: Web Interface Image File Download

    Procedures MP.11-R Installation and Management Web Interface Image File Download Web Interface Image File Download In some cases, it may be necessary to upgrade the embedded software of the unit by downloading an image file. To download an image file through the Web Interface: 1.

  • Page 172: Configuration Backup

    Procedures MP.11-R Installation and Management Configuration Backup Configuration Backup You can back up the unit’s configuration by uploading the configuration file. You can use this file to restore the configuration or to configure another unit (see Configuration Restore). To upload a configuration file through the Web Interface: 1.

  • Page 173: Configuration Restore

    Procedures MP.11-R Installation and Management Configuration Restore Configuration Restore You can restore the configuration of the unit by downloading a configuration file. The configuration file contains the configuration information of a unit. To download a configuration file through the Web Interface: 1.

  • Page 174: Soft Reset To Factory Default

    Procedures MP.11-R Installation and Management Soft Reset to Factory Default Soft Reset to Factory Default If necessary, you can reset the unit to the factory default settings. Resetting to default settings means that you must configure the unit anew. To reset to factory default settings using the Web Interface: 1.

  • Page 175: Hard Reset To Factory Default

    Procedures MP.11-R Installation and Management Hard Reset to Factory Default Hard Reset to Factory Default If you cannot access the unit or you have lost its password, you can reset the unit to the factory default settings. Resetting to default settings means you must configure the unit anew. To reset to factory default settings, press and hold the RELOAD button on the side of the unit’s power supply for a minimum of 5 seconds but no more than 10 seconds.

  • Page 176: Forced Reload

    Procedures MP.11-R Installation and Management Forced Reload Forced Reload With Forced Reload, you erase the embedded software. Use this procedure only as a last resort if the unit does not boot and the “Reset to Factory Defaults” procedure did not help. If you perform a Forced Reload, you must download a new image file with the Bootloader (see “Image File Download with the Bootloader”...

  • Page 177: Image File Download With The Bootloader

    ScanTool, or the Command Line Interface through the unit’s serial port. In both cases, the file is transferred through Ethernet with TFTP. Because the CLI serial port option requires a serial RS-232C cable, Proxim recommends the ScanTool option.
  • Page 178 Procedures MP.11-R Installation and Management Image File Download with the Bootloader • Parity: None 5. Disconnect and reconnect power to reset the unit; the terminal program displays Power On Self Test (POST) messages. 6. When the “Sending Traps to SNMP manager periodically” message is displayed (after about 30 seconds), press the ENTER key.

  • Page 179: Troubleshooting

    This chapter helps you to isolate and solve problems with your unit. In the event this chapter does not provide a solution, or the solution does not solve your problem, check our support website at http://support.proxim.com. Before you start troubleshooting, it is important that you have checked the details in the product documentation. For details about RADIUS, TFTP, terminal and telnet programs, and Web browsers, refer to the appropriate documentation.

  • Page 180: Hyperterminal Connection Problems

    Troubleshooting MP.11-R Installation and Management Connectivity Issues HyperTerminal Connection Problems The serial connection properties can be found in HyperTerminal as follows: 1. Start HyperTerminal and select Properties from the File menu. 2. Select Direct to Com 1 in the Connect using: drop-down list (depending upon the COM port you use); then click Configure.

  • Page 181: Communication Issues

    Troubleshooting MP.11-R Installation and Management Communication Issues Communication Issues Two Units Are Unable to Communicate Wirelessly If a wireless link is possible after testing two units within close distance of each other, then there are two possible reasons why wireless connectivity is not possible while the MP.11 units are at their desired locations: 1.

  • Page 182: Setup And Configuration Issues

    Troubleshooting MP.11-R Installation and Management Setup and Configuration Issues Setup and Configuration Issues The following issues relate to setup and configuration problems. Lost Password If you lost your password, you must reset the unit to the default settings. See Hard Reset to Factory Default.

  • Page 183: Online Help Is Not Available

    Troubleshooting MP.11-R Installation and Management Setup and Configuration Issues • Can be situated either local or remote • Must have a valid IP address • Must be set for send and receive without time-out • Must be running only during file upload and download If the TFTP server does not upload or download files, it could mean: •...

  • Page 184: Vlan Operation Issues

    Troubleshooting MP.11-R Installation and Management VLAN Operation Issues VLAN Operation Issues The correct VLAN configuration can be verified by “pinging” wired hosts from both sides of the device and the network switch. Traffic can be “sniffed” on the wired (Ethernet) network. Packets generated by hosts and viewed on one of the backbones should contain IEEE 802.1Q compliant VLAN headers when in Transparent mode.

  • Page 185: Link Problems

    Troubleshooting MP.11-R Installation and Management Link Problems Link Problems While wireless networking emerges more and more, the number of wireless connections to networks grows every day. The Tsunami MP.11 unit is one of the successful product families used by customers today who enjoy the day after day high-speed, cost-effective connections.

  • Page 186: Analyzing The Spectrum

    By turning the antenna 360 degrees, one can check from which direction the interference is coming. The analyzer will also display the frequencies and the level of signal is detected. Proxim recommends performing the test at various locations to find the most ideal location for the equipment. Avoiding Interference When a source of interference is identified and when the level and frequencies are known, the next step is to avoid the interference.

  • Page 187: A Country Codes And Channels

    MP.11-R Installation and Management Country Codes and Channels In the CLI and MIB browser, the country code is set using the string code, as shown in the following example. Example: To set Taiwan as the country: set syscountrycode TW NOTE: The country code must be entered in capital letters. NOTE: Country is not configurable for the 4954-R.
  • Page 188 Country Codes and Channels MP.11-R Installation and Management 2.4 GHz Channels/Frequencies by Country Country Code Frequency Band Allowed Channels (Center Frequency) for 5 MHz, 10 MHz, and 20 MHz Belize (BZ) 2.4 GHz 1 (2412), 2 (2417), 3 (2422), 4 (2427), 5 (2432), 6 (2437), 7 (2442), 8 (2447), 9 (2452), 10 (2457), 11 (2462), 12 (2467), 13 (2472) Bolivia (BO) 2.4 GHz...
  • Page 189 Country Codes and Channels MP.11-R Installation and Management 2.4 GHz Channels/Frequencies by Country Country Code Frequency Band Allowed Channels (Center Frequency) for 5 MHz, 10 MHz, and 20 MHz Iceland (IS) 2.4 GHz 1 (2412), 2 (2417), 3 (2422), 4 (2427), 5 (2432), 6 (2437), 7 (2442), 8 (2447), 9 (2452), 10 (2457), 11 (2462), 12 (2467), 13 (2472) India (IN) 2.4 GHz...
  • Page 190 Country Codes and Channels MP.11-R Installation and Management 2.4 GHz Channels/Frequencies by Country Country Code Frequency Band Allowed Channels (Center Frequency) for 5 MHz, 10 MHz, and 20 MHz New Zealand (NZ) 2.4 GHz 1 (2412), 2 (2417), 3 (2422), 4 (2427), 5 (2432), 6 (2437), 7 (2442), 8 (2447), 9 (2452), 10 (2457), 11 (2462), 12 (2467), 13 (2472) North Korea (KP) 2.4 GHz...
  • Page 191 Country Codes and Channels MP.11-R Installation and Management 2.4 GHz Channels/Frequencies by Country Country Code Frequency Band Allowed Channels (Center Frequency) for 5 MHz, 10 MHz, and 20 MHz Trinidad and Tobago (TT) 2.4 GHz 1 (2412), 2 (2417), 3 (2422), 4 (2427), 5 (2432), 6 (2437), 7 (2442), 8 (2447), 9 (2452), 10 (2457), 11 (2462), 12 (2467), 13 (2472) Tunisia (TN) 2.4 GHz...

  • Page 192: 4.9 Ghz Channels/Frequencies

    Country Codes and Channels MP.11-R Installation and Management 4.9 GHz Channels/Frequencies 4.9 GHz Channels/Frequencies Frequency Bands Allowed Channels (Center Frequency) 5 MHz 10 MHz 20 MHz 4.940 - 4.990 GHz 5 (4942.5), 15 (4947.5), 25 (4952.5), 10 (4945), 20 (4950), 30 (4955), 20 (4950), 30 (4955), 40 (4960), 35 (4957.5), 45 (4962), 55 (4967.5), 40 (4960), 50 (4965), 60 (4970),...

  • Page 193: Ghz Channels/Frequencies By Country

    Country Codes and Channels MP.11-R Installation and Management 5 GHz Channels/Frequencies by Country 5 GHz Channels/Frequencies by Country Country (Code) Frequency Allowed Channels (Center Freq) 20 MHz 10 MHz 5 MHz Bands All Channels - 5 All 5 GHz bands All 20 MHz channels.
  • Page 194 Country Codes and Channels MP.11-R Installation and Management 5 GHz Channels/Frequencies by Country Country (Code) Frequency Allowed Channels (Center Freq) 20 MHz 10 MHz 5 MHz Bands Brazil (BR) 5.47 - 5.6 GHz and 100 (5500), 104 (5520), 98 (5490), 100 (5500), 97 (5485), 98 (5490), 99 (5495), 100 (5500), 108 (5540), 112 (5560), 102 (5510), 104 (5520),...
  • Page 195 Country Codes and Channels MP.11-R Installation and Management 5 GHz Channels/Frequencies by Country Country (Code) Frequency Allowed Channels (Center Freq) 20 MHz 10 MHz 5 MHz Bands China (CN) 5.725 - 5.85 GHz 149 (5745), 153 (5765), 149 (5745), 151 (5755), 149 (5745), 150 (5750), 151 (5755), 152 (5760), 157 (5785), 161 (5805), 153 (5765), 155 (5775),...
  • Page 196 Country Codes and Channels MP.11-R Installation and Management 5 GHz Channels/Frequencies by Country Country (Code) Frequency Allowed Channels (Center Freq) 20 MHz 10 MHz 5 MHz Bands Dominican 5.25 - 5.35 GHz and 56 (5280), 60 (5300), 54 (5270), 56 (5280), 53 (5265), 54 (5270), 55 (5275), 56 (5280), Republic (DO) 5.725 - 5.85 GHz...
  • Page 197 Country Codes and Channels MP.11-R Installation and Management 5 GHz Channels/Frequencies by Country Country (Code) Frequency Allowed Channels (Center Freq) 20 MHz 10 MHz 5 MHz Bands Greece (GR) 5.47 - 5.6 GHz and 100 (5500), 104 (5520), 98 (5490), 100 (5500), 97 (5485), 98 (5490), 99 (5495), 100 (5500), 108 (5540), 112 (5560), 102 (5510), 104 (5520),...
  • Page 198 Country Codes and Channels MP.11-R Installation and Management 5 GHz Channels/Frequencies by Country Country (Code) Frequency Allowed Channels (Center Freq) 20 MHz 10 MHz 5 MHz Bands Iran (IR) 5.725 - 5.85 GHz 149 (5745), 153 (5765), 149 (5745), 151 (5755), 149 (5745), 150 (5750), 151 (5755), 152 (5760), 157 (5785), 161 (5805), 153 (5765), 155 (5775),...
  • Page 199 Country Codes and Channels MP.11-R Installation and Management 5 GHz Channels/Frequencies by Country Country (Code) Frequency Allowed Channels (Center Freq) 20 MHz 10 MHz 5 MHz Bands Latvia (LV) 5.47 - 5.6 GHz and 100 (5500), 104 (5520), 98 (5490), 100 (5500), 97 (5485), 98 (5490), 99 (5495), 100 (5500), 108 (5540), 112 (5560), 102 (5510), 104 (5520),...
  • Page 200 Country Codes and Channels MP.11-R Installation and Management 5 GHz Channels/Frequencies by Country Country (Code) Frequency Allowed Channels (Center Freq) 20 MHz 10 MHz 5 MHz Bands Malaysia (MY) 5.25 - 5.35 GHz and 56 (5280), 60 (5300), 54 (5270), 56 (5280), 53 (5265), 54 (5270), 55 (5275), 56 (5280), 5.725 - 5.85 GHz 64 (5320), 149 (5745),...
  • Page 201 Country Codes and Channels MP.11-R Installation and Management 5 GHz Channels/Frequencies by Country Country (Code) Frequency Allowed Channels (Center Freq) 20 MHz 10 MHz 5 MHz Bands Norway (NO) 5.47 - 5.6 GHz and 100 (5500), 104 (5520), 98 (5490), 100 (5500), 97 (5485), 98 (5490), 99 (5495), 100 (5500), 108 (5540), 112 (5560), 102 (5510), 104 (5520),...
  • Page 202 Country Codes and Channels MP.11-R Installation and Management 5 GHz Channels/Frequencies by Country Country (Code) Frequency Allowed Channels (Center Freq) 20 MHz 10 MHz 5 MHz Bands Puerto Rico (PR) 5.25 - 5.35 GHz and 56 (5280), 60 (5300), 54 (5270), 56 (5280), 53 (5265), 54 (5270), 55 (5275), 56 (5280), 5.725 - 5.85 GHz 64 (5320), 149 (5745),...
  • Page 203 Country Codes and Channels MP.11-R Installation and Management 5 GHz Channels/Frequencies by Country Country (Code) Frequency Allowed Channels (Center Freq) 20 MHz 10 MHz 5 MHz Bands 30 (5150), 32 (5160), Russia (RU) 5.15 - 6.08 GHz 30 (5150), 34 (5170), 30 (5150), 31 (5155), 32 (5160), 33 (5165), 34 (5170), 36 (5180) 38 (5190), 42 (5210),...
  • Page 204 Country Codes and Channels MP.11-R Installation and Management 5 GHz Channels/Frequencies by Country Country (Code) Frequency Allowed Channels (Center Freq) 20 MHz 10 MHz 5 MHz Bands Saudi Arabia (SA) 5.15 - 5.35 GHz and 36 (5180), 40 (5200), 36 (5180), 38 (5190), 36 (5180), 37 (5185), 38 (5190), 39 (5195), 5.725 - 5.825 GHz 44 (5220), 48 (5240),...
  • Page 205 Country Codes and Channels MP.11-R Installation and Management 5 GHz Channels/Frequencies by Country Country (Code) Frequency Allowed Channels (Center Freq) 20 MHz 10 MHz 5 MHz Bands Spain (ES) 5.47 - 5.6 GHz and 100 (5500), 104 (5520), 98 (5490), 100 (5500), 97 (5485), 98 (5490), 99 (5495), 100 (5500), 108 (5540), 112 (5560), 102 (5510), 104 (5520),...
  • Page 206 Country Codes and Channels MP.11-R Installation and Management 5 GHz Channels/Frequencies by Country Country (Code) Frequency Allowed Channels (Center Freq) 20 MHz 10 MHz 5 MHz Bands United Kingdom 5.8 5.725 - 5.85 GHz 147 (5735), 151 (5755), 145 (5725), 147 (5735), 145 (5725), 146 (5730), 147 (5735), 148 (5740), GHz (G1) 155 (5775), 167 (5835)

  • Page 207: B Technical Specifications

    MP.11-R Installation and Management Technical Specifications Please see the following sections: • Part Numbers • Regulatory Approvals and Frequency Ranges • Integrated Antenna Specifications • OFDM Modulation Rates • Wireless Protocol • Interfaces • Receive Sensitivity • Maximum Throughput • Latency •...

  • Page 208: Part Numbers

    Technical Specifications MP.11-R Installation and Management Part Numbers Part Numbers Radio Units North America Region Model 2454-R Base Station Unit Part Number Description 2454-BSUR-US-WORLD Tsunami MP.11 Model 2454-R Base Station Unit with Type-N Connector – US PSU -WORLD Subscriber Unit Part Number Description 2454-SUA-US-WORLD...
  • Page 209 Technical Specifications MP.11-R Installation and Management Part Numbers Part Number Description 5054-BSUR-LR-US- Tsunami MP.11 Model 5054-R-LR Base Station Unit with Type-N Connector – World WORLD Subscriber Unit Part Number Description 5054-SUA-LR-US Tsunami MP.11 Model 5054-R Subscriber Unit with Type-N Connector – US PSU 5054-SUA-LR-WORLD Tsunami MP.11 Model 5054-R Subscriber Unit with Type-N Connector –...
  • Page 210 Technical Specifications MP.11-R Installation and Management Part Numbers Asia Pacific Region Model 2454-R Base Station Unit Part Number Description 2454-BSUR-AU Tsunami MP.11 Model 2454-R Base Station Unit with Type-N Connector – Australia 2454-BSUR-UK Tsunami MP.11 Model 2454-R Base Station Unit with Type-N Connector – UK PSU 2454-BSUR-US Tsunami MP.11 Model 2454-R Base Station Unit with Type-N Connector –...
  • Page 211 Technical Specifications MP.11-R Installation and Management Part Numbers Model 5054-R Base Station Unit Part Number Description 5054-BSUR-AU Tsunami MP.11 Model 5054-R Base Station Unit with Type-N Connector – Australia 5054-BSUR-UK Tsunami MP.11 Model 5054-R Base Station Unit with Type-N Connector – UK PSU 5054-BSUR-US Tsunami MP.11 Model 5054-R Base Station Unit with Type-N Connector –...

  • Page 212: Accessories

    Technical Specifications MP.11-R Installation and Management Part Numbers Part Number Description 2454-SUR-US Tsunami MP.11 Model 2454-R Subscriber Unit with Integrated 23-dBi Antenna – US PSU 2454-SUR-US-WORLD Tsunami MP.11 Model 2454-R Subscriber Unit with Type-N Connector – US/CAN PSU - WORLD Model 5054-R Base Station Unit Part Number...
  • Page 213 Technical Specifications MP.11-R Installation and Management Part Numbers External Antennas 900 MHz Antennas Please see the Tsunami MP.11 Recommended Antennas guide on the product CD. 2.4 GHz Antennas Part Number Description 848 515 722 5 dBi Omni-Directional Vehicle Antenna w/Integrated 250 cm cable 848 312 591 7 dBi Omni-Directional Base Station Antenna - St-N Female 848 515 698...

  • Page 214: Regulatory Approvals And Frequency Ranges

    Technical Specifications MP.11-R Installation and Management Regulatory Approvals and Frequency Ranges Regulatory Approvals and Frequency Ranges Model 2454-R Regulatory Approval and Frequency Ranges Region/Country Country Number of Channels Certification 5 MHz 10 MHz 20 MHz North America 2.40 - 2.4835 Up to 11 Up to 11 2.40 - 2.472...

  • Page 215: Model 4954-R Regulatory Approval And Frequency Ranges

    Technical Specifications MP.11-R Installation and Management Regulatory Approvals and Frequency Ranges Model 2454-R Regulatory Approval and Frequency Ranges (continued) Region/Country Country Number of Channels Certification 5 MHz 10 MHz 20 MHz APAC New Zealand 2.40 - 2.4835 Up to 13 Up to 13 Japan 2.40 - 2.4835...

  • Page 216: Model 5054-R Regulatory Approval And Frequency Ranges

    Technical Specifications MP.11-R Installation and Management Regulatory Approvals and Frequency Ranges Model 5054-R Regulatory Approval and Frequency Ranges Region/Country Country Number of Channels Certification 5 MHz 10 MHz 20 MHz North America 5.25 - 5.35 Up to 30 Up to 14 Yes* 5.47 - 5.725 Up to 30...

  • Page 217: Model 5054-R-Lr Regulatory Approval And Frequency Ranges

    Technical Specifications MP.11-R Installation and Management Integrated Antenna Specifications Model 5054-R Regulatory Approval and Frequency Ranges (continued) Region/Country Country Number of Channels Certification 5 MHz 10 MHz 20 MHz South America Argentina 5.25 - 5.35 Up to 9 Up to 5 Up to 3 5.725 - 5.85 Up to 19...

  • Page 218: Model 4954-R Subscriber Unit With Integrated 21-Dbi Antenna

    Technical Specifications MP.11-R Installation and Management Integrated Antenna Specifications Feature Specification VSWR 1.5 : 1 Max Model 4954-R Subscriber Unit with Integrated 21-dBi Antenna Feature Specification Part Number 4954-SUR-xx Frequency range 4900 - 5100 MHz Nominal Impedance 50 ohms Gain 21 dBi Front-to-Back Ratio 35 dB...

  • Page 219: Ofdm Modulation Rates

    Technical Specifications MP.11-R Installation and Management OFDM Modulation Rates OFDM Modulation Rates NOTE: Maximum packet size: 1526 Bytes Modulation Rate 20 MHz Channels 10 MHz Channels 5 MHz Channels BPSK 6 and 9 Mbps 3 and 4.5 Mbps 2.25 and 1.5 Mbps QPSK 12 and 18 Mbps 6 and 9 Mbps...

  • Page 220: Model 5054-R

    Technical Specifications MP.11-R Installation and Management Maximum Throughput 20 MHz Channels 10 MHz Channels 5 MHz Channels Modulation 16QAM ¾ -79.3 dBm @ 36 Mbps -83.3 dBm @ 18 Mbps -86.3 dBm @ 9 Mbps 16QAM ½ -82.4 dBm @ 24 Mbps -87 dBm @ 12 Mbps -90 dBm @ 6 Mbps QPSK ¾...

  • Page 221: Model 4954-R

    Technical Specifications MP.11-R Installation and Management Maximum Throughput Data Rate 20 MHz Channels 10 MHz Channels 5 MHz Channels 48 Mbps 32 Mbps — — 36 Mbps 27 Mbps — — 24 Mbps 19 Mbps 18 Mbps — 18 Mbps 14 Mbps 14 Mbps —...

  • Page 222: Latency

    Technical Specifications MP.11-R Installation and Management Latency Data Rate 40 MHz Channels 20 MHz Channels 10 MHz Channels 5 MHz Channels Turbo Mode Standard Mode Standard Mode Standard Mode (US Non-DFS and All Channel 5 GHz Only) 18 Mbps — 14 Mbps 14 Mbps —...

  • Page 223: Model 5054-R-Lr

    Technical Specifications MP.11-R Installation and Management Transmit Power Settings Model 5054-R-LR Frequency 6-24 Mbps @ 20 MHz 36 Mbps @ 20 MHz 48 Mbps @ 20 MHz 54 Mbps @ 20 MHz 16QAM ½; QPSK ¾; 16QAM ¾ 64QAM ½ 64QAM ¾...

  • Page 224: Range Information

    Technical Specifications MP.11-R Installation and Management Range Information Range Information Model 2454-R NOTE: Minimum fade margin; 99.995% or better availability; average terrain/climate; no unusual mulitpath; proper path clearance (0.6F1). Note that these calculations are done using 17 dBi antenna gain. Frequency 54 Mbps 36 Mbps...

  • Page 225: Hardware Specifications

    Technical Specifications MP.11-R Installation and Management Hardware Specifications Hardware Specifications Category Specification Processor 166 MHz Motorola 8241 processor Memory Flash: 8 MB; RAM: 16 MB Software Features Category Specification Key Features • WORP protocol • Dynamic Data Rate Selection (Configured on BSU) •...

  • Page 226: Management

    Technical Specifications MP.11-R Installation and Management Management Management Category Specification Local RS-232 Serial port (RJ11 port built-into the unit; DB9 female via a converter, included) Remote HTTP Server (RFC 2616); Telnet (RFC 855), TFTP Client (RFC 783), Link Test, SU/BSU Statistics, temperature logging, remote reboot/reset SNMP SNMPv1/v2 (RFC 1157);...

  • Page 227: Mtbf And Warranty

    Technical Specifications MP.11-R Installation and Management MTBF and Warranty Category Specification Environmental Storage Temperature -55° to 80°C (-41° to 176° Fahrenheit) Operating Temperature -33° to 60°C (-27.5° to 140° Fahrenheit) Humidity 100% Wind Loading 125 m.p.h MTBF and Warranty Category Specification MTBF >100,000 hours...

  • Page 228: C Lightning Protection

    The surge arrestor (sometimes referred to as a lightning protector) can protect your sensitive electronic equipment from high-voltage surges caused by discharges and transients at the PoE. Proxim Wireless offers superior lightning and surge protection for Tsunami MP.11 and Tsunami QuickBridge.11 products. Contact your reseller or distributor for more information.

  • Page 229: D Technical Services And Support

    Obtaining Technical Services and Support If you are having trouble using the Proxim product, please read this manual and the additional documentation provided with your product. If you require additional support to resolve your issue, please be ready to provide the following information before you contact Proxim’s Technical Services:...

  • Page 230: Support Options

    Extended Warranty: Extend the life of your networking investment by adding 1, 2, or 3 years to your products standard warranty. This service coverage provides unlimited repair of your Proxim hardware for the life of the service contract. The cost of an extended warranty is far less than the cost of a repair providing a sensible return on your...
  • Page 231 Replacement Depot Repair To purchase ServPak support services, please contact your authorized Proxim distributor. To receive more information or for questions on any of the available ServPak support options, call Proxim Support at 408-383-7700 or send an email to servpak@proxim.com.

  • Page 232: E Statement Of Warranty

    The express warranties set forth in this Agreement will not apply to defects in a Product caused; (i) through no fault of Proxim Wireless during shipment to or from Buyer, (ii) by the use of software other than that provided with or installed in...

  • Page 233: Hours Of Operation

    In the event the Customer Service Center determines that the problem can be corrected with a software update, Buyer might be instructed to download the update from Proxim Wireless’s web site or, if that’s not possible, the update will be sent to Buyer.

This manual is also suitable for:

Tsunami mp.11 5054-r-lrTsunami mp.11 5054-rTsunami mp.11 4954-rTsunami mp.11 2454-r

Table of Contents
