- Page 1 Quick Install Guide Tsunami MP.11 5012-SUI and 5054-SUI Version 4.0.0 Part Number 73883 (Print version) Part Number 73881 (CD version)
- Page 2 Proxim Wireless Corporation. trademarks Tsunami, Proxim, and the Proxim logo are trademarks of Proxim Wireless Corporation. All other trademarks mentioned herein are the property of their respective owners.
-
Page 3: Table Of Contents
coNteNts iNtroductioN..............4 Key Features ....................4 Package.coNteNts............5 Hardware.aNd.software.iNstallatioN....7 Step 1: Choose a Location ................8 Step 2: Unpack Shipping Box ................. 9 Step 3: Attach Cables ..................10 Step 4: Install the Security Cover (Optional) ..........12 Step 5: Mount the Unit ................... -
Page 4: Introduction
The Tsunami MP.11 5012-SUI and 5054-SUI are a flexible wireless indoor client that let you design solutions for point-to-point links and point-to-multipoint networks. It is the client or satellite side in a wireless link. The 5012-SUI and 5054-SUI are parts of the Tsunami MP.11 product family, which is comprised of several additional products, including: ▪... -
Page 5: Package.contents
Each 5012/5054-SUI shipment includes the items in the following table. Verify that you have received all parts of the shipment. Note: Unless listed here, cables are not included with the unit. Tsunami MP.11 5012-SUI or 5054-SUI unit N-type Male Terminated Pigtail (for external antenna... - Page 6 Outdoor Mounting Configuration Flyer Indoor Antenna Qty. Description Mounting Hardware and 2 ea. Screw Documentation (included with 5012-SUI-WA-xx and 2 ea. Washer 5054-SUI-WA-xx) 2 ea. Suction Cup/Rotation Bar 1 ea. Indoor Mounting Configuration Flyer Page Copyright © 007 Proxim Wireless...
-
Page 7: Hardware.and.software.installation
Hardware.aNd.software.iNstallatioN IMPORTANT! IMPORTANT! Before installing this product, see Safety and Regulatory Compliance Before installing this product, see Safety and Regulatory Compliance Information on the product CD for important information. Information on the product CD for important information. IMPORTANT! IMPORTANT! All units must be installed by a suitably trained professional installation All units must be installed by a suitably trained professional installation technician or by a qualified installation service. -
Page 8: Step 1: Choose A Location
To make optimal use of the 5012/5054-SUI, you must find a suitable location for the hardware. The range of the unit largely depends upon the position of the antenna. Proxim recommends you do a site survey, observing the following requirements, before mounting the 5012/5054-SUI hardware. -
Page 9: Step 2: Unpack Shipping Box
Note the Ethernet and MAC addresses of the unit, as well as the serial number. The addresses may be used when configuring the unit. The serial number is required to obtain support from Proxim. Keep this information in a safe place. -
Page 10: Step 3: Attach Cables
Use a straight-through Ethernet cable if you intend to connect the 5012/5054-SUI to a switch, hub, or patch panel. º Use a cross-over Ethernet cable or adapter if you intend to connect the 5012/5054-SUI to a single computer. Page 10 Copyright © 007 Proxim Wireless... - Page 11 Continue with “Install the Security Cover”. All rights reserved Page 11...
-
Page 12: Step 4: Install The Security Cover (Optional)
Use the two attached screws to fasten the security cover onto the rear panel of the unit. Page 1 Copyright © 007 Proxim Wireless... -
Page 13: Step 5: Mount The Unit
step.5:.Mount.the.unit The following are the mounting options: ▪ Wall Mount ▪ Ceiling Mount wall.Mounting Follow these steps to mount the unit on a wall: If the unit’s power supply is plugged in, unplug it. Identify the location at which you intend to mount the unit.Use a Phillips screwdriver to remove the metal base from the underside of the unit (if you have not already done so). - Page 14 Carefully slide the unit to your right until the tabs snap securely onto the narrow holes of the unit. If the 5012/5054-SUI is mounted correctly no portion of the mounting plate should protrude from any of the sides of the unit. Page 1 Copyright © 007 Proxim Wireless...
-
Page 15: Step 6: Power On The Unit
step.6:.Power.on.the.unit The unit can be powered by a power supply (just plug the power cord of the power supply into an AC power outlet), or by Active Ethernet (connect an Active Ethernet splitter to the Ethernet cabling). step.7:.view.leds. When the unit is powered on, it performs startup diagnostics. When startup is completed, the LEDs show the operational state of the unit (see the following figure). - Page 16 “Solid green or yellow” indicates that the LED displays either solid green or solid yellow, depending on the hardware variant. ▪ “Blinking green or yellow” indicates that the LED blinks either green or yellow, depending on the hardware variant. Page 1 Copyright © 007 Proxim Wireless...
-
Page 17: Step 8: Connect The Pigtail Cable
step.8:.connect.the.Pigtail.cable The pigtail cable has a sub-miniature A-type (SMA) connector on one end and an N-type connector on the other. It is used to connect an external antenna to the 5012/5054-SUI (see figure). To install the pigtail cable: Place the 5012/5054-SUI on a table. The compartment cover closer to the LED panel contains the antenna connector. - Page 18 Refer to the Tsunami MP.11 Antenna Installation Guide for information on how to cable the pigtail to the antenna, as well as for the mounting and connection of antennas. Page 18 Copyright © 007 Proxim Wireless...
-
Page 19: Step 9: Align The Antenna
step.9:.align.the.antenna Antenna Alignment Display (AAD) provides a measurement of signal quality in an easy-to-interpret manner—a numeric printed signal value at the CLI and serial ports. The SNR is numerically displayed on the CLI or serial port by two decimal characters representing a number from 00 to 99. On the serial port, AAD is enabled by default after booting. -
Page 20: Step 10: Install Documentation And Software
Available from C:\Program Files\Tsunami\MP.11 [Model]: – Documentation (in Docs folder): See list above – Help files (in Help folder; click on index.htm to access) – MIB files (in MIBs folder) – TFTP Server (in Extras folder) Page 0 Copyright © 007 Proxim Wireless... -
Page 21: Initialization
iNitializatioN Connecting to the unit requires either: ▪ A direct physical connection with an Ethernet cable or with a serial RS-232 cable ▪ A network connection Connecting with the Ethernet cable allows you to use of the Web Interface and SNMP in addition to the CLI. -
Page 22: Accessing The Web Browser
Run; enter cmd. In the DOS window displayed, enter telnet and the IP address (for example, telnet 10.0.0.1) and type <enter>. You will be prompted for your password. Enter the password (the default is public). Page Copyright © 007 Proxim Wireless... -
Page 23: Basic.configuration
Basic.coNfiguratioN System Configuration The System configuration page lets you change the unit’s System Name, Location, and so on. In addition, this page provides a selectable Country field that automatically provides the allowed bandwidth and frequencies for the selected country/band. Units sold only in the United States are pre-configured to scan and display only the outdoor frequencies permitted by the FCC. -
Page 24: Ip Configuration
Name, Network Secret, and Base Station System Name, as well as the TPC setting. VLAN Configuration VLAN implementation in the Tsunami MP.11 products includes: ▪ Letting the BSU and SU be used in a VLAN-aware network ▪ Processing IEEE 802.1Q VLAN-tagged packets Page Copyright © 007 Proxim Wireless... -
Page 25: Security Settings
Proxim Web site. Note: Not all software releases support all Tsunami MP.11 products. Proxim recommends that you always refer to the Release Notes to determine whether the version of software to which you want to upgrade is supported on your product. -
Page 26: Default.settings
System Name Tsunami MP.11 5012-SUI or 5054-SUI Mode of Operation Bridge Routing Disabled IP Address Assignment Type Static IP Address 10.0.0.1 Subnet Mask 255.255.255.0 Default Router IP Address 10.0.0.1 Default TTL RIPv2 Enabled when in Routing Mode Base Station System Name <empty string>... - Page 27 DFS Priority Frequency Channel Disabled Announcement Period (when 100 ms roaming enabled) Multi Frame Bursting Enabled Storm Threshold Broadcast/Multicast Unlimited Broadcast Protocol Filtering All Protocols Allowed Dynamic Data Rate Selection Disabled Roaming Disabled Disabled Intra-Cell Blocking Disabled Antenna Alignment Disabled Country Selection US-only device –...
-
Page 28: Technical.services.and.support
If you are having trouble utilizing your Proxim product, please review the Installation and Management manual and the additional documentation provided with your product. If you require additional support, please refer to the “Technical Services and Support” chapter in the Installation and Management manual for details about the information you will need to gather before using the Support Options listed below.
