DEMO MANUAL DC2814A-A
TEST RESULTS
V
OUT
100mV/DIV
SW1
10V/DIV
SW2
10V/DIV
Figure 22. DC2814A-A Load Transients at 30V
16V , 0.3A to 2.7A Load Current
OUT
8
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
Figure 21. DC2814A-A Thermal Performance at 30V
2ms/DIV
IN
(Buck), 16V
IN
V
OUT
50mV/DIV
DC2814aa F22
(Buck), Figure 23. DC2814A-A Output Voltage Ripple at 30V
(Buck), 16V
, 3A Load Current
OUT
2µs/DIV
, 3A Load Current
OUT
DC2814aa F23
IN
Rev. 0
