DEMO MANUAL DC2814A-A
TEST RESULTS
V
OUT
200mV/DIV
SW1
5V/DIV
SW2
5V/DIV
Figure 16. DC2814A-A Load Transients at 12V
12V , 0.3A to 2.7A Load Current
OUT
6
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
Figure 15. DC2814A-A Thermal Performance at 12V
2ms/DIV
(Pass-Thru),
IN
(Pass-Thru), 12V
IN
V
OUT
50mV/DIV
DC2814aa F16
Figure 17. DC2814A-A Output Voltage Ripple at 12V
(Pass-Thru), 12V
, 3A Load Current
OUT
2µs/DIV
, 3A Load Current
OUT
DC2814aa F17
IN
Rev. 0
