DEMO MANUAL DC2814A-A
PARTS LIST
ITEM QTY REFERENCE
30 4 MP1, MP2, MP3, MP4 STANDOFF , NYLON, SNAP-ON, 0.50"
31 1 PCB1
32 1 R1A1
33 2 R1B1, R2B1
34 8 R1C1, R2C1, R12,
R13, R33, R34, RBG1,
RBG2
35 1 R2A1
36 2 R23, R24
37 4 R35, RBST1,
RBST2, ROUT1
38 1 RC1
39 1 RC2
40 1 REN1
41 1 REN2
42 1 RIMON1
43 1 RIN1
44 1 RPWGD1
45 1 RSNS1
46 1 RSNS2
47 1 RT1
48 1 STNCL1
49 1 U1
50 3 XJP1, XJP2, XJP3
10
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
PART DESCRIPTION
PCB, DC2814A
RES, 69.8kΩ, 1%, 1/16W, 0402
RES, 10kΩ, 1%, 1/16W, 0402, AEC-Q200
RES, 0Ω, 1/16W, 0402
RES, 150kΩ, 1%, 1/16W, 0402
RES, 10Ω, 1%, 1/16W, 0402, AEC-Q200
RES, 1Ω, 1%, 1/16W, 0402
RES, AEC-Q200, 38.3kΩ, 1%, 1/16W, 0402
RES, 60.4kΩ, 1%, 1/16W, 0402
RES, 287kΩ, 1%, 1/16W, 0402, AEC-Q200
RES, 165kΩ, 1%, 1/16W, 0402, AEC-Q200
RES, 27.4kΩ, 1%, 1/16W, 0402, AEC-Q200
RES, 0Ω, 1/8W, 0805
RES, 100kΩ, 1%, 1/16W, 0402, AEC-Q200
RES, 0.004Ω, 1%, 1W, 1206, 4-TERM, SENSE,
AEC-Q200
RES, 0.01Ω, 1%, 1W ,1206 , 4-TERM, SENSE,
AEC-Q200
RES, 16.9kΩ, 1%, 1/10W, 0603, AEC-Q200
TOOL, STENCIL, 700-DC2814A
IC, 100V, BUCK-BOOST CONTROLLER, QFN-40 (6x6)
CONN, SHUNT, FEMALE, 2-POS, 2mm
MANUFACTURER/PART NUMBER
KEYSTONE 8833
PHASE 3 600-DC2814A
VISHAY CRCW040269K8FKED
VISHAY CRCW040210K0FKED
NIC NRC04F1002TRF
ROHM MCR01MZPJ000
VISHAY CRCW04020000Z0ED
NIC NRC04ZOTRF
YAGEO RC0402JR-070RL
VISHAY CRCW0402150KFKED
NIC NRC04F10R0TRF
VISHAY CRCW040210R0FKED
VISHAY CRCW04021R00FKED
VISHAY CRCW040238K3FKED
NIC NRC04F6042TRF
VISHAY CRCW040260K4FKED
VISHAY CRCW0402287KFKED
VISHAY CRCW0402165KFKED
VISHAY CRCW040227K4FKED
VISHAY CRCW08050000Z0EA
YAGEO RC0805JR-070RL
NIC NRC04F1003TRF
VISHAY CRCW0402100KFKED
SUSUMU KRL3216T4-M-R004-F-T1
SUSUMU KRL3216T4-M-R010-F-T5
NIC NRC06F1692TRF
PANASONIC ERJ3EKF1692V
VISHAY CRCW060316K9FKEA
ANALOG DEVICES 830-DC2814A
ANALOG DEVICES LT8210EUJ#PBF
ANALOG DEVICES LT8210EUJ#TRPBF
SAMTEC 2SN-BK-G
