QUICK SETUP Menu

Label Length

In most applications, the user-selected Label Length will match the
physical label length. Physical label length is the actual label length
of the media installed. Following is a list of different media types:
•
•
•
•

Label Width

This menu item specifies the label width. The allowable range in
inches is 00.1 to the maximum print width of the printer. The
allowable range in millimeters is 2.5 to the maximum width of the
printer.
Ver Image Shift
This menu item specifies the amount to shift an image up (–) or
down (+) for precise positioning on the label. The actual height of
the image is not affected by this parameter. The allowable range is
–1.00 inches to the current Label Length value setting, up to a
maximum of 12.80 inches, in 0.01 inch increments.
The default value is 0.00 inches.
30
Die cut labels: measurable length of the removable label
(leading edge to trailing edge). This does not include the
liner material or gap.
Tag stock with notches or holes: measurable length from
the trailing edge of one notch or hole to the trailing edge of
the next notch or hole.
Tag stock with black marks on the underside: measurable
length from the leading edge of one black mark to the
leading edge of the next black mark.
Continuous media (no label length indicators): measurable
length should be within + 1 to 2% of the Label Length value
entered.
