Please keep the original box, packaging and receipt.
Before operating this unit, please read this manual thoroughly and retain it for future
reference.
Part No. 1.423-602.0
High Pressure Washer
Operator Manual
Overview .......................................... 2
Precautions ................................ 3 - 4
Assembly Instructions ..................... 4
Operating Instructions ..................... 5
Using the accessories ..................... 6
Working with Detergents ................. 7
Shut Down and Clean-Up ............... 8
Taking a Break ................................ 8
Storage ....................................... 8 - 9
Cleaning Tips ........................... 9 - 10
Troubleshooting ....................... 11-12
Specifications
Working Pressure ............... 9000 kPa
........................................ 1300 PSI
Max. Pressure .................... 1650 PSI
Max. Water volume ............. 1.6 GPM
Voltage ..................................... 120 V
Amp draw ........................... 13 AMPS
Manual Part No. 5.961-168.0 11/03EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Binford 1650 and is the answer not in the manual?

Questions and answers

Related Manuals for Kärcher Binford 1650

Summary of Contents for Kärcher Binford 1650

  • Page 1: Table Of Contents

    High Pressure Washer Operator Manual Overview .......... 2 Precautions ........ 3 - 4 Assembly Instructions ..... 4 Operating Instructions ..... 5 Using the accessories ..... 6 Working with Detergents ....7 Shut Down and Clean-Up ....8 Taking a Break ........ 8 Winterizing and Long-Term Storage ........

  • Page 2: Overview

    OVERVIEW For household use only! 1. Power cord 7. Accessory compartment 2. Trigger gun 8a. Detergent tank 1 3. Trigger gun safety lock 8b. Detergent tank 2 4. High pressure hose 9. High pressure outlet 5. Water inlet with filter 10.

  • Page 3: Precautions

    IMPORTANT PRECAUTIONS – Read First! Extension Cords Safety Warnings When using this product basic precautions Use a sufficient gauge: should always be followed: Up to 25 ft. = 12/3 AWG. • Read all the instructions before using the 25 to 50 ft. =10/3 AWG. product.

  • Page 4: Assembly Instructions

    IMPORTANT PRECAUTIONS – continued • Never use the pressure washer to draw in Water Supply (Cold Water Only) water contaminated with solvents, e.g. • Water hose must be at least 1/2 inch or paint thinner, gasoline, oil, etc. 5/8 inch in diameter. NOTE: Dirt in the feed water will •...

  • Page 5: Operating Instructions

    OPERATING INSTRUCTIONS Step 2 Insert the quattro nozzle to the trigger gun. Press in against the spring tension and twist into the locked position. Step 1 Connect the high pressure hose to the high pressure outlet. Step 4 Step 3 Connect garden hose to the cold water Connect the garden hose to the water inlet.

  • Page 6: Using The Accessories

    USING THE ACCESSORIES Quattro Nozzle Selecting the jet Release the trigger of the handgun. Rotate the nozzle head until the symbol is Warning aligned with the marking on the spray lance. TO AVOID SERIOUS INJURY, NEVER Note: The marking on the spray lance must POINT SPRAY NOZZLE AT YOUR- be up during operation.

  • Page 7: Working With Detergents

    WORKING WITH DETERGENTS Step 1 Step 2 Turn Quattro Nozzle to Low pressure a) Fill the Detergent Tanks (No.8a,No.8b) position. Rotate the spray lance in the with the selected detergent, ensuring it is direction of “ ” until reaching the stop. the correct concentration (read recom- mended dosage on label) or Note: No detergent in high-pressure mode...

  • Page 8: Shut Down And Clean-Up

    SHUTTING DOWN & CLEAN-UP OFF / OFF / Step 1 Step 2 Step 3 Turn the switch to off (O) Turn off the water source. Press trigger to release position and unplug cord from water pressure. outlet. Step 4 Step 6 Step 5 Disconnect the garden hose from Pull trigger down...

  • Page 9: Cleaning Tips

    WINTERIZING AND LONG-TERM STORAGE – continued 6) Cleaning the 5) Cleaning the detergent inlet filter water inlet filter Pull it out and rinse out Pull out the water in- in warm water. let filter with flat-nose pliers and rinse out in Maintenance warm water.

  • Page 10: Optional Cleaning Accessories

    CLEANING TIPS – continued Barbecue Grills, Outdoor apply to surface at low pressure. Allow Pressure Wash to remain on surface 1-3 Power Equipment & Gardening minutes. Do not allow detergent to dry on Tools surface. If needed use special Wash Brush (with or without detergent) Attachment (not included) to remove Pre-rinse cleaning surface with fresh water.

  • Page 11: Troubleshooting

    TROUBLESHOOTING Disconnect the machine from the power source before making any repair. Symptom Cause Solution Motor will not start. On/Off switch is in the “OFF” (O) Turn switch to the “ON” (I) position position. Power cord is not plugged in. Plug in power cord.
  • Page 12 TROUBLESHOOTING – continued Symptom Symptom Symptom Symptom Symptom Cause Solution No detergent. No detergent. No detergent. No detergent. No detergent. Detergent is too thick. Dilute detergent. Spray wand is in high pressure Turn spray wand tip to low position. pressure position. Discharge nozzle is obstructed.
