• Program audio – including both stereo and monaural consumer and
professional playback devices such as DVD players and VCRs
• SoundStation VTX 1000™ for wideband telephony
• PSTN Telephone line interfaces for narrowband telephony interfaces
• Video codecs – including Polycom VSX™ 7000, VSX 8000, ViewStation
and iPower™
Select the types of input, such as Microphone and Table, choose the quantity,
adjust the text label, and then click Add Input. This will add the selected items to
the Selected Inputs text box as shown in Figure 4.
Figure 4. Polycom InstantDesigner Step 1 – Select Inputs.
In this application note, we will design a system that includes 12 table
microphones, a lectern microphone, two wireless microphones, a VSX 8000 video
codec, an analog phone line, stereo program audio, a monaural recorder, and an
assistive listening device. This room might look like the room in Figure 5.
®,
