HOW TO DO AN AUTOTAKE?

HOME MENU
(extract)
CONTROL
The Autotake function performs a TAKE automatically each time an input is selected.
HOW TO RECORD & DISPLAY A QUICK FRAME?
HOME MENU
(extract)
LOGOS/FRAME
RECORD FRAMES
QUICK FRAME: full and individual frame that can be displayed on top of every layer.
It is possible to store up to 8 frames in the device non volatile memory.
- Select RECORD FRAMES in the frames menu.
- A white rectangle will appear on your Program display, indicating the frame which will be captured and saved. (The Frame can be
captured in Preview too.)
- To select the Quick frame, please go into the SCREEN menu, select QUICK FRAME menu and then choose a Frame slot. The
selected frame will be your QUICK FRAME.
Now to display it, simply press the front panel button
- To remove the QUICK FRAME, press the
TIP: a long press on the BLACK

HOW TO DISABLE THE HDCP ENCRYPTION?

HOME MENU
(extract)
INPUTS
HOME MENU
(extract)
OUTPUT #1
HDCP DETECTION
PREVIEW OUT
The HDCP Encryption can be disabled on HDMI/DVI inputs or/and Program Output #1 / Program Output #2. This can be useful
when your computer detects the HDCP compliance of your switcher and protects the content by encrypting the signal from this
computer. This feature will disable the HDCP compliance on this specific HDMI/DVI input only.
If you want to use HDCP content from your sources, be sure to use only HDCP compliant screens or projector. If it's not the case,
the output image could be disabled.
Screen will go to black without displaying the HDCP input image, or concerned layers will output to grey.
The output status can provide you all information about the output in real time. This feature is particularly useful when HDCP is
used with long cable to be sure the communication is well handled.

HOW TO USE THE AUTO-LOCK FUNCTION?

HOME MENU
(extract)
CONTROL
FUNCTIONS
AUTO-LOCK allows to select an input only if a valid signal is detected on its current plug.

WARRANTY AND SERVICE

This Analog Way product has a 3 year warranty on parts and labor, back to factory. This warranty does not include faults resulting
from user negligence, special modifications, electrical surges, abuse (drop/crush), and/or other unusual damage. In the unlikely
event of a malfunction, please contact your local Analog Way office for service.
GOING FURTHER WITH THE PULSE² - H
For complete details and operations procedures, please refer to the Pulse² - H User's Manual and our website for further
information: www.analogway.com
