Polycom VSX 5000

Specifications

H.323, SIP and H.320 compliant
VSX 5000 Bundled Packages
• VSX 5000 VTX: VSX 5000 system with
SoundStation VTX 1000 instead of the
microphone array
• VSX 5400 Presenter: VSX 5000 system,
Visual Concert™ VSX, People+Content IP
• VSX 5400 Presenter VTX: VSX 5000 system,
Visual Concert VSX, People+Content IP,
SoundStation VTX 1000 instead of
microphone array
Bandwidth
• Maximum Data Rate IP: 768Kbps
• Maximum Data Rate ISDN: 512Kbps
Video Standards & Protocols
• H.261
• H.263+ Annexes: F, I, J, L, N, T
• H.263++ Annexes: W (receive-only)
• H.264
Frame Rates (Point-to-Point)
• Intelligently selects frame rate for best
performance video
• 30 fps from 56 kbps up to 768 Kbps
Video Inputs:
• Main Camera + 1
Connectors
• Integrated main camera
• 1 x S-Video; 4-pin mini DIN Document camera,
VCR/DVD or second camera)
• RS-232 Data Port: 1 x 8-pin mini DIN
- Control port for custom integration with
® ®
remote devices such as Crestron and AMX
control systems
- Connectivity for closed captioning
teletype device
- Communication port for transmission
of serial data (i.e. medical devices) over
ISDN or IP calls
Video Outputs: 3 Connectors
• 2 x S-Video 4-pin mini DIN
• 1 x VGA HD15
Video Formats
• NTSC/PAL
• Graphics: XGA, SVGA, VGA
Integrated Main Camera
• Noiseless, ultra-fast action electronic
pan/tilt/zoom (PTZ)
• 65° field of view
• Electronic Tilt Range: +/- 24° (Up/Down)
• Electronic Pan Range: +/- 42.5° (Left/Right)
• 85° Total Field of View
• 2x Zoom
• Lens F#: 2.8mm
• Focal length: 4.9mm
• Fixed focus
• Automatic white balance
• Camera presets – local and far-end (up to 99)
• Standards-based, far-end camera control (FECC)
People Video Resolution
• 4SIF (704 x 480), 4CIF (704 x 576) *2nd video only
• SIF (352 x 240), CIF (352 x 288)
• QSIF (176 x 120), QCIF (176 x 144)
• Choice of 4:3 or 16:9 display aspect ratios
Content Video Resolution
• XGA (1024 x 768), SVGA (800 x 600),
VGA (640 x 480) for graphic displays
• People video support for 4CIF and 4SIF on
second VGA display
• Up to 4CIF for NTSC/PAL displays
Audio Standards & Protocols
• Polycom StereoSurround ready
• 14 kHz bandwidth with Polycom Siren ™ 14
(G.722.1 Annex C)
• 7 kHz bandwidth with G.722, G.722.1
• 3.4 kHz bandwidth with G.711, G.728, G.729A
Audio Features
• Audio only add-in over ISDN
• Full-duplex digital audio
Polycom Headquarters:
www.polycom.com
Polycom EMEA:
Polycom Asia Pacific:
• Instant Adaptation Echo Cancellation
• Automatic Gain Control (AGC) – Voice activated
• Automatic Noise Suppression (ANS)
• Audio Mixer (Mic, VCR, line-in)
• Real-time audio level meter
• Microphone and VCR input audio mixing
• Ability to talk over VCR audio
Audio Inputs: 3 Connectors
• 1 x Conference Link
- Supports 1 microphone
- Supports SoundStation VTX 1000
conference phone
• 1 x RCA input for stereo or mono input from
external mixer
Audio Outputs: 2 Connectors
• Main Audio Out (RCA Stereo)
Polycom Digital Tabletop Microphone
• 360° voice pick up
• Three cardioid elements per microphone
• Flotation feet reduce transmission of
tabletop noise
• Integrated mute button
• Optional Polycom Ceiling Microphone Array
is available
Other ITU-Supported Standards
• H.221 communications
• H.224/H.281 far-end camera control
• H.323 Annex Q far-end camera control
• H.225, H.245, H.241, H.331
• H.239 People+Content
• H.231 in multipoint calls
• H.243 MCU password
• H.233, H.234, H.235V3 encryption standards
• H.460 NAT/firewall traversal
• Bonding, Mode 1
SIP Support (Sessions Initiation Protocol)
• Register and authenticate with:
®
- Microsoft LCS
- Nortel ® MCS
- Standards-based SIP servers
• FECC
• H.261, H.263, H.264
• G.711, G.722, G.722.1, G.728, G.729A, Siren 14
(G.722.1 Annex C)
• Microsoft LCS contact list support
• Microsoft LCS presence support
®
• Interoperable with Microsoft Office
Communicator
Network Interfaces Supported
• Single 10/100 Ethernet port
(10Mbps/100Mbps/Auto)
• Optional ISDN BRI (Basic Rate Interface) Module
• Optional wireless LAN support via customer
provided wireless bridge
Network Features
®
• Integration with Cisco Systems CallManager
Version 4.0
• Down speeding over IP and ISDN
• Audio & Video Error Concealment over IP, ISDN
and mixed calls
• IP address conflict warning
• Maximum call length digital timer
• Auto SPID detection and line number
configuration
• MGC™ Click&View™ for individual screen
layouts
• Polycom OneDial™ intelligent call management
attempts call on preferred network (IP or ISDN)
and automatically rolls over to secondary
network if needed
• Polycom PathNavigator™ support for easy call
placement and network cost optimization
• TCP/IP, UDP/IP, RTP, DNS, WINS, DHCP, ARP,
HTTP, FTP, Telnet
• Chair control through API command or Integrated
Web Interface.
• Software Upgradeable Inverse Multiplexer (IMUX)
Conference on Demand
• Initiates unscheduled MGC calls from
the endpoint
• Utilizes Polycom Office™ (PathNavigator
and MGC)
©2006 Polycom, Inc. All rights reserved.
Polycom, the Polycom logo, ReadiManager and SoundStation VTX 1000 are registered trademarks and VSX, StereoSurround, Siren, MGC, Click&View, Polycom PathNavigator,
Polycom OneDial, Visual Concert, Polycom Office, Global Management System, People+Content, Polycom Conference Suite and iPriority are trademarks of Polycom, Inc.
All other trademarks are the property of their respective owners. Information in this document is subject to change without notice.
4750 Willow Road, Pleasanton, CA 94588 (T) 1.800.POLYCOM (765.9266) for North America only.
For North America, Latin America and Caribbean (T) +1.925.924.6000, (F) +1.925.924.6100
270 Bath Road, Slough, Berkshire SL1 4DX, (T) +44 (0)1753 723000, (F) +44 (0)1753 723010
Polycom Hong Kong Ltd., Rm 1101 MassMutual Tower, 38 Gloucester Road, Wanchai, Hong Kong, (T) +852.2861.3113, (F)+852.2866.8028
Part No. 3726-17347-001 Rev. 03/06
• Auto selects an external bridge
• Dials all participants simultaneously
Security
• Account validation number entry
• SNMP trap notification of all failed login
attempts from HTTP, FTP or Telnet
• FIPS 140-2 (Pre-validation List)
- Secure web (HTTPS)
- Secure Telnet, FTP
- Security mode
• Secure password authentication
• Administrator password – in-room and
remote access
• Dial-in meeting password
• Encrypted password for VSX Web access
• Ability to disable remote interfaces (FTP,
Telnet, HTTP, SNMP)
• Auto-Answer (On/Off)
• Allow access to user settings (On/Off)
Embedded Encryption
• Advanced Encryption Standard (AES)
• FIPS 197 validated by National Institute of
Standards & Technology (NIST) certified agency
• 128-bit key length
• AES software encryption on ISDN and IP
• Standards-based H.235V3 (IP)
• Standards-based H.233/H.234 (ISDN/Serial)
• Automatic key generation and exchange
• Supported in People+Content
User Interface
• User-friendly graphical interface
• Customizable home screen and color themes
• Kiosk mode with scrolling marquee
• User-selectable camera icons and ring tones
• Speed Dial List on home page
• Persistent Preview (Far-site PIP) on all screens
• Picture In Picture (PIP) (On/Off, Moveable)
• Dual Monitor Emulation
• Calendar and Conference scheduling
• Alert Signal on home page
• Do Not Disturb (On/Off)
• Closed captioning support
Directory Services
• 4,000 number global directory
• 1,000+ number local directory
• Speed dial list displaying video buddy list
• Live address book with Polycom Global Directory
Services automatically and quickly updates
directory with address changes or new endpoints
• Polycom Global Directory Services integrates
with Active Directory/LDAP
• Directory Server backup in the event Polycom
Global Directory is not accessible
• Automatic ISDN localization of calls
System Management
• SNMP for enterprise management
• Baseline mode setting for legacy system
interoperability
• Diagnostics and software upgrades via PC, LAN
• Integrated VSX Web management tool
• Web Director: Remote administrator video
monitoring and control from VSX Web
(enabled/disabled from endpoint for security)
• Out-of-box setup from VSX Web
• Place a call from VSX Web
• Language independence between set-top
interface and VSX Web
• System configuration from VSX Web
• Recent Calls Log – last 99 incoming and
outgoing calls
• Call Detail Record (CDR) – Reports all incoming
and outgoing calls along with call statistics
• CDR Feature On/Off
• Downloadable CDR data for processing requires
no external management system
• Account number validation at call initiation
integrated with Polycom Global Management™
System for billing purposes
• Administrator-configurable dialing speeds
iPriority ™ – Quality of Service Features
• Video Error Concealment
• Audio Error Concealment
• Universal Plug and Play (UPnP)
• IP Precedence (ToS)
- Configurable video/audio/FECC service value
• DiffServ (DSCP) (COS)
• RSVP
• Dynamic Bandwidth Allocation
• Proactive Network Monitoring
• Adjustable Packet Size
• NAT/firewall traversal (H.460)
• Packet and jitter control
• Network Address Translation (NAT) support
• Automatic NAT discovery
• Asymmetric speed control
• Alternate Gatekeeper Support
• TCP/UDP fixed-port firewall support
• Lip synchronization
• Echo cancellation
• Echo suppression
• Auto gatekeeper discovery
• Automatic gateway dialing profiles
• Specify outbound call routing for gateway/ ISDN
Collaboration Solutions
• Visual Concert VSX (Audio and video input from
®
PC or Macintosh ) (Optional)
- 1 x audio input for laptop
- 1 x VGA output for projector
- 3 x 10/100 Ethernet hub
- Content Input: 1280 x 1024, 60 Hz
- Content Output: Up to 1024 x 768
• People+Content IP (Optional)
- Show content from laptop/PC over IP network
connection
- Content shown in native resolution
®
- Supports Windows 2000 and Windows XP
• QSX (Optional)
- Connect to Visual Concert to show content
from laptop/PC
- Content shown in native resolution
- Up to 10 voice participants can view content
being shared
• Adjustable bandwidth for content
- 10% Content, 90% People
- 50% Content, 50% People
- 90% Content, 10% People
• Web Streaming in and out of a call, RTP-based,
®
suitable with QuickTime Players
Furniture solutions
• Media Center with audio system
• Media Center
• Media Cart
• Video Cart
• Wall Mount Solution
Language Support (15 languages)
Chinese (Simplified), Chinese (Traditional),
English (American), English (British), French,
German, Hungarian, Italian, Japanese, Korean,
Norwegian, Polish, Portuguese, Russian, Spanish
• Translated items include:
- Documentation (not Hungarian/Polish)
- User interface
- Audio dialing confirmation
- VSX web
- Remote control (not Hungarian/Polish)
Electrical
• Auto sensing power supply
• Operating voltage/power 90-260 VAC,
47-63 Hz/80 watts
• Max 75 VA@115v60Hz, 85 VA@220v50Hz
• Max Heat Dissipation: 273 BTU/hour
Environmental Specifications
• Operating Temperature: 0-40° C
• Operating Humidity: 15-80%
• Non-Operating Temperature: -40-70° C
• Non-Operating Humidity (Non-condensing):
10-90%
Physical Characteristics
• Video Base Unit (W/H/D): 11.83"/5.25"/10.02",
300.5mm/133.26mm/254.5mm
• Video Base Unit Weight: 4.4 lbs/1.94Kg
Warranty
• One-year return to factory parts and labor
• 90-day Software Warranty
