Polycom SoundPoint IP 670 Quick Start Manual page 2

Connect Cables
1. Connect handset and headset, as shown below.
(Note: Headset is an optional accessory, and is not included with this package.)
2. Connect network and power, as shown below.
Note: Choose either AC Power Option, or PoE (Power over Ethernet).
AC Power Option
Attach Base Stand
Deskmount Method
Ensure all cables are
secured (as shown).
SoundPoint IP 670 Quick Start Guide
PoE Option
IEEE802.3af compliant
Hub/Switch
Align base stand tabs
with their correspond-
ing insertion points on
the phone (as shown).
Snap base stand into
place (as shown).
