Technical Data - Trotec PC 200 Operating Manual

9
No. Designation
9 Measuring funnel
10 Temperature and humidity sensor
11 Camera
12 USB port
13 Electrical connection
14 Tripod thread
15 Battery compartment

Technical data

Parameter
Model
Dimensions (H x W x D)
Weight
Light source
PC interfaces
Tripod thread
Storage conditions
EN
10
11
12
13
14
15
Value
PC200
240 mm x 75 mm x 57 mm
570 g
Laser class 1 (class 3R laser
enclosed in a way to prevent
tampering, 780 nm, 1.5-3 mW,
classified according to
DIN EN 60285-1 and the
Technical Regulations of the
Occupational Health and Safety
Ordinance on Artificial Optical
Radiation (TROS))
USB connection
1/4 inch – 20 UNC
-10 °C to +50 °C at
< 95 % RH
(non-condensing)
Operating manual – particle counter PC 200
Parameter
Display
Functions
Image format, resolution
Video format, resolution
Data storage
Energy
Battery
Operating time
Charging time
Automatic switch-off
Automatic screen switch-off
Temperature measurement
Temperature range
Temperature accuracy
Dew point temperature range
Dew point temperature
accuracy
Wet-bulb temperature range
Wet-bulb temperature
accuracy
Value
2.8 inch colour LCD display
with background illumination,
320 x 240 pixels
Maximum, minimum and
average value display,
measured value hold function,
alarm function, language
selection, °C/°F switch, photo
or video recording
JPEG, 640 x 480 pixels
3GP, 320 x 240 pixels
5000 data records on the
internal flash memory (optional
memory expansion with a
microSD card: up to 16 GB)
Polymer LI-ION battery
approx. 4 hours of continuous
operation
approx. 2 hours with an
alternating current adapter
3 minutes, 15 minutes or 60
minutes
90 seconds, 2 minutes or 4
minutes
0 °C to 50 °C (32 °F to 122 °F)
±0.5 °C (0.9 °F) at 10 °C to 40
°C
(50 °F to 104 °F) ±1.0 °C (1.8
°F) in other temperature
ranges
0 °C to 50 °C (32 °F to 122 °F)
±0.5 °C (0.9 °F) at 10 °C to 40
°C
(50 °F to 104 °F) ±1.0 °C (1.8
°F) at other temperature
ranges
0 °C to 80 °C (32 °F to 176 °F)
±1,0 °C (1,8 °F)
4
