GETTING STARTED GUIDE
NI PXIe-5630
6 GHz T/R Two-Port Vector Network Analyzer
Note
Before you begin, install and configure your chassis and controller.
This document explains how to install, configure, and test the NI PXIe-5630 (NI 5630). The
NI 5630 is a 6 GHz, 2-port vector network analyzer (VNA) with support for vector
measurements of transmission and reflection (T/R) coefficients. The NI 5630 ships with the
NI-VNA instrument driver, which you can use to program the device.
To access NI 5630 documentation, navigate to Start»All Programs»National Instruments»
NI-VNA»Documentation.
The specifications document for your device is installed with the driver software. Refer to
ni.com/manuals
for the most recent specifications for your device.
Caution
manner not described in this document.
Contents
Electromagnetic Compatibility Guidelines...............................................................................2
Verifying the System Requirements......................................................................................... 2
Unpacking the Kit..................................................................................................................... 2
Verifying the Kit Contents................................................................................................ 3
Preparing the Environment....................................................................................................... 4
Installing the Software.............................................................................................................. 5
Installing the NI 5630............................................................................................................... 5
Connecting Signals........................................................................................................... 7
Configuring the NI 5630 in MAX...........................................................................................11
Programming the NI 5630...................................................................................................... 12
NI-VNA Examples......................................................................................................... 12
Making Uncalibrated Measurements with the NI 5630..........................................................13
Calibrating the NI 5630.......................................................................................................... 13
Making Calibrated Measurements with the NI 5630..............................................................14
Troubleshooting...................................................................................................................... 15
What Should I Do if the Module Fails the Self-Test?.....................................................15
Why Is the ACCESS LED Off When the Chassis is On?...............................................15
What Should I Do if the NI 5630 Doesn't Appear in MAX?..........................................15
Where to Go Next................................................................................................................... 17
Worldwide Support and Services............................................................................................17
The protection provided by this product may be impaired if it is used in a
Advertisement
Table of Contents
Related Manuals for National Instruments PXIe-5630
Summary of Contents for National Instruments PXIe-5630
-
Page 1: Table Of Contents
Before you begin, install and configure your chassis and controller. This document explains how to install, configure, and test the NI PXIe-5630 (NI 5630). The NI 5630 is a 6 GHz, 2-port vector network analyzer (VNA) with support for vector measurements of transmission and reflection (T/R) coefficients. -
Page 2: Electromagnetic Compatibility Guidelines
Furthermore, any modifications to the product not expressly approved by National Instruments could void your authority to operate it under your local regulatory rules. -
Page 3: Verifying The Kit Contents
PXI Chassis Slot Blocker kit (NI part number 199198-01) • NI 2598 Dual 26 GHz Transfer Switch module (NI part number 778572-98) • The following accessories available on the NI 5630 product page at ni.com/products: NI PXIe-5630 Getting Started Guide | © National Instruments | 3... -
Page 4: Preparing The Environment
Clean the hardware with a soft, nonmetallic brush. Make sure that the hardware is completely dry and free from contaminants before returning it to service. Note Refer to the NI PXIe-5630 Specifications at ni.com/manuals for complete specifications. 4 | ni.com | NI PXIe-5630 Getting Started Guide... -
Page 5: Installing The Software
2. PXI Peripheral Slot 5. PXI Express Peripheral Slot 3. PXI Express Hybrid Peripheral Slot The NI 5630 can be placed in PXI Express peripheral slots or PXI Express Hybrid peripheral slots. NI PXIe-5630 Getting Started Guide | © National Instruments | 5... - Page 6 11. Cover all empty slots using filler panels or slot blockers to maximize cooling air flow. 12. Power on the chassis. Related Information Installing the Software on page 5 6 | ni.com | NI PXIe-5630 Getting Started Guide...
-
Page 7: Connecting Signals
The NI 5630 is a precision RF instrument that is sensitive to ESD and transients. Ensure you take the following precautions when making direct connections to the NI 5630 to avoid damaging the device. NI PXIe-5630 Getting Started Guide | © National Instruments | 7... - Page 8 PORT 1 +23 dBm MAX 50 VDC Ω REF IN 10 MHz REFLECTION -10 dBm to +3 dBm Ω TRANSMISSION PFI 0 PORT 2 +23 dBm MAX 50 VDC Ω SENSITIVE 8 | ni.com | NI PXIe-5630 Getting Started Guide...
- Page 9 RED—The device has detected a spurious error, such as when the PLL becomes unlocked. The LED remains red until the error condition is removed. NI PXIe-5630 Getting Started Guide | © National Instruments | 9...
- Page 10 Do not use excessive amounts of alcohol, as this prolongs drying time. Apply the alcohol with a foam-tipped swab instead of cotton swabs, because the cotton can become lodged in the connector. 10 | ni.com | NI PXIe-5630 Getting Started Guide...
-
Page 11: Configuring The Ni 5630 In Max
Related Information What Should I Do if the Module Fails the Self-Test? on page 15 What Should I Do if the NI 5630 Doesn't Appear in MAX? on page 15 NI PXIe-5630 Getting Started Guide | © National Instruments | 11... -
Page 12: Programming The Ni 5630
Network Analyzers Help to manually add all required include and library files to the project. NI-VNA Examples Examples demonstrate the functionality of the device and serve as programming models and building blocks for your own applications. The NI Example Finder is a utility available for 12 | ni.com | NI PXIe-5630 Getting Started Guide... -
Page 13: Making Uncalibrated Measurements With The Ni 5630
Calibrating the NI 5630 Frequent calibration is particularly important for the NI 5630 because it allows you to remove certain errors from the actual measurements. Calibration removes errors caused by NI PXIe-5630 Getting Started Guide | © National Instruments | 13... -
Page 14: Making Calibrated Measurements With The Ni 5630
Measure the DUT. Ensure you are applying the proper correction from the Calibrating the NI 5630 section. Measure and save the DUT parameters. Verify that the calibrated measurement falls within your expected range. 14 | ni.com | NI PXIe-5630 Getting Started Guide... -
Page 15: Troubleshooting
Expand the Chassis tree to see the list of installed devices, and press <F5> to refresh the list. If the module is still not listed, power off the system, ensure that all hardware is correctly installed, and restart the system. NI PXIe-5630 Getting Started Guide | © National Instruments | 15... - Page 16 If you are using a PXI controller, verify that a National Instruments entry appears in the system device list and that the NI PXIe-5630 is enabled. If the device is disabled, right- click NI PXIe-5630, and select Enable from the shortcut menu. If you are using a MXI controller, right-click PCI-to-PCI Bridge, and select Properties from the shortcut menu to verify that the bridge is enabled.
-
Page 17: Where To Go Next
RF fundamentals, device features, and programming with NI-VNA. Worldwide Support and Services The National Instruments website is your complete resource for technical support. At ni.com/ support, you have access to everything from troubleshooting and application development self-help resources to email and phone assistance from NI Application Engineers. - Page 18 NI product. Refer to the Export Compliance Information at ni.com/legal/export-compliance the National Instruments global trade compliance policy and how to obtain relevant HTS codes, ECCNs, and other import/export data. NI MAKES NO EXPRESS OR IMPLIED WARRANTIES AS TO THE ACCURACY OF THE INFORMATION CONTAINED HEREIN AND SHALL NOT BE LIABLE FOR ANY ERRORS.
