Original instructions
18L Baffle
1. Place the baffle into the collector chamber.
2. Position the baffle so that the arrow points directly toward the front.
18L Baffle
Product Service 816-333-8811 or 1-800-522-7658
Chapter 3: Getting Started
6 & 12L Baffle
Align hole in baffle channel
with rear vacuum port
Properly Installed
Top View
13
