- Page 1 DucoBox Reno ENGLISH Installation guide L2003342 (Revision A | 17.05.2023)
-
Page 2: Table Of Contents
Installation, connection, maintenance and repairs are to be carried out by an accredited installer� The electronic components of this product may be live� Avoid contact with water� DUCO, HANDELSSTRAAT 19 VEURNE, B-8630 Vero DUCO - Handelsstraat 19 - 8630 Veurne - Belgium tel +32 58 33 00 33 - info@duco.eu - www.duco.eu L2003342 Installation guide for DucoBox Reno (Revision A | 17.05.2023) -
Page 3: Introduction
DUCO advises against connecting the DucoBox (via a duct or directly) to an extractor hood, regardless of the type� This usually causes excessive fouling in the DucoBox, which affects its operation or has a more direct effect on output�... -
Page 4: Mounting
Figure 3: You can also mount the box vertically or horizontally� figure 2: Against a wall, you can position the Box in any possible direction� If you place the DucoBox Reno in a damp room with a water connection, avoid placing it on the floor� 02.B Mounting Figure 4: Mounting: adapt the mounting material to the surface L2003342 Installation guide for DucoBox Reno (Revision A | 17.05.2023) -
Page 5: 02�C Air Duct Connections
10 UNMISSABLE TIPS The smooth running of your Duco ventilation system is totally dependent on the choice and the quality of implementation of the duct system! Has the duct system been optimized? Ask professional advice from your duct supplier. -
Page 6: Communication
‘HIGH’ 24 VDC INST / ENTER DOWN DUCO NETWORK TOOL LED INDICATOR PERILEX INST / CALIB BOXSENSOR Figure 8: Connections and buttons on the circuit board of the DucoBox Reno L2003342 Installation guide for DucoBox Reno (Revision A | 17.05.2023) - Page 7 ENGLISH Wireless communication The DucoBox Reno is able to communicate with DUCO slave components via a wireless (RF) connection� 230 VAC 230 VAC 230 VAC DucoBox Reno ≥ 30 cm Remote control Switch Sensor Max. of 25 RF components RF obstacle-free zone...
-
Page 8: Additional Control Option
04.B CO Box sensor A CO Box sensor can be integrated into a duct port of the DucoBox Reno and provide measurement in an air duct� A DucoBox Reno can contain a maximum of one CO Box sensor� BOX SENSOR MOUNTING + CONNECTING 1�... - Page 9 Figure 14: snap the CO box sensor into the duct port Figure 16: Note the recess in the lid Figure 15: Four options for cabling up to one CO Box sensor to circuit board L2003342 Installation guide for DucoBox Reno (Revision A | 17.05.2023)
-
Page 10: Electronical Installation
(see table at 05�C in the next section)� Installer mode can be activated by pressing the INST button of the DucoBox Reno (see drawing in chapter "03�A Connection & but- tons")� When the LED on the master unit starts flashing green, Installer mode is active� Press ‘INST’ again to return to ‘User mode’... -
Page 11: 05�D Pairing Components
RF connection with the DucoBox� 3� Once all components have been paired, ‘Installer mode’ can be deactivated by tapping ‘INST’ on the DucoBox Reno� The LEDs on all components will stop flashing�... -
Page 12: 05�E Removing / Replacing Components
Restore factory settings of the DucoBox and all registered components: Long press INST + when not in Installer mode� The network will be preserved� Use the DUCO Network Tool to read out information from components� L2003342 Installation guide for DucoBox Reno (Revision A | 17.05.2023) -
Page 13: Air Calibration
Ensure that the lid of the DucoBox is properly closed� Remove the front cover with a screwdriver� Figure 19: Remove the front cover of the lid with Figure 20: Removing the front cover a screwdriver to gain access to the adjustment buttons� L2003342 Installation guide for DucoBox Reno (Revision A | 17.05.2023) - Page 14 Repeat steps until the desired flow rate has been obtained at each vent� INST Exit configuration mode� To do so, press 'INST' in the DucoBox Reno� L2003342 Installation guide for DucoBox Reno (Revision A | 17.05.2023)
-
Page 15: 06�B Option: Installation Of Control On The Ducobox
Figure 26: Snap the control onto the provided snap- Figure 27: mounted control on pieces of the front cover� L2003342 Installation guide for DucoBox Reno (Revision A | 17.05.2023) -
Page 16: 06�C Checking
After the check, the system can be reset to the desired ventilation mode� If you do not do so, the system will revert automatically to the AUTO mode after 15 minutes� L2003342 Installation guide for DucoBox Reno (Revision A | 17.05.2023) -
Page 17: Maintenance & Service
Please contact your installer� Keep the serial number of your product to hand� For service problems as an installer: Please contact your retailer of DUCO products� Keep the serial number of your product to hand� L2003342 Installation guide for DucoBox Reno (Revision A | 17.05.2023) -
Page 18: Warranty
All warranty conditions concerning the DucoBox and DUCO's ventilation systems can be found on the DUCO website� All complaints are to be reported to DUCO by the DUCO distributor with a clear description and the order/invoice number under which the products were delivered� To do so, please fill out the complaint registration form, found on the DUCO website, mentioning the serial number and send it to service@duco�eu�... - Page 19 ENGLISH L2003342 Installation guide for DucoBox Reno (Revision A | 17.05.2023)
