DucoBox Reno
ENGLISH
Installation manual
Video instructions
www.duco.tv
L2003340 (Revision C | 07.03.2025)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DucoBox Reno and is the answer not in the manual?

Questions and answers

Summary of Contents for Duco DucoBox Reno

  • Page 1 DucoBox Reno ENGLISH Installation manual Video instructions www.duco.tv L2003340 (Revision C | 07.03.2025)
  • Page 2: Table Of Contents

    Installation, connection, maintenance and repairs are to be carried out by an accredited installer� The electronic components of this product may be live� Avoid contact with water� DUCO, HANDELSSTRAAT 19 VEURNE, B-8630 Vero DUCO - Handelsstraat 19 - 8630 Veurne - Belgium tel +32 58 33 00 33 - info@duco.eu - www.duco.eu L2003340 Installation manual for DucoBox Reno (Revision C | 07.03.2025)
  • Page 3: Introduction

    DUCO advises against connecting the DucoBox (via a duct or directly) to an extractor hood, regardless of the type� This usually causes excessive fouling in the DucoBox, which affects its operation or has a more direct effect on output�...
  • Page 4: Regulations And Safety Instructions

    • Bends in the ducts immediately upstream of the fan unit. • The DucoBox Reno must not be connected to a (motorless) extractor hood or tumble dryer. Take care to ensure that the electrical power supply is a 230 V, single- It must not be possible to touch the fan by hand�...
  • Page 5: Mounting

    2: Against a wall, you can position the Box in any possible direction� Figure 3: You can mount the box vertically or horizontally� If you place the DucoBox Reno in a damp room with a water connection, avoid placing it on the floor� 03.B Fixing Figure 4: Mounting: adapt the mounting material to the surface L2003340 Installation manual for DucoBox Reno (Revision C | 07.03.2025)
  • Page 6: 03�C Air Duct Connections

    10 UNMISSABLE TIPS The smooth running of your DUCO ventilation system is totally dependent on the choice and the quality of implementation of the duct system! Has the duct system been optimized? Ask professional advice from your duct supplier.
  • Page 7: Communication

    ‘HIGH’ 24 VDC INST / ENTER DOWN DUCO NETWORK TOOL LED INDICATOR PERILEX INST / CALIB BOXSENSOR Figure 8: Connections and buttons on the circuit board of the DucoBox Reno L2003340 Installation manual for DucoBox Reno (Revision C | 07.03.2025)
  • Page 8 ENGLISH Wireless communication The DucoBox Reno is able to communicate with DUCO components via a wireless (RF) connection� 230 VAC 230 VAC 230 VAC DucoBox Reno ≥ 30 cm Remote control Switch Sensor Max. of 25 RF components RF obstacle-free zone...
  • Page 9: Additional Control Option

    BOX SENSOR MOUNTING + CONNECTING 1� Disconnect the DucoBox Reno from the mains and remove the lid of the DucoBox Reno� To do this, first remove the screw located behind the cover plate� (Figure 11: Remove the cover plate and unscrew the lid)�...
  • Page 10 Figure 14: snap the CO box sensor into the duct port Figure 16: Note the recess in the lid Figure 15: Four options for cabling up to one CO Box sensor to circuit board L2003340 Installation manual for DucoBox Reno (Revision C | 07.03.2025)
  • Page 11: Electronical Installation

    (see table at 05�C in the next section)� Installer mode can be activated by pressing the INST button of the DucoBox Reno (see drawing in chapter "03�A Connection & buttons")� When the LED on the controller starts flashing green, Installer mode is active� Press INST again to return to User mode (LED fully on or off)�...
  • Page 12: 06�D Pairing Components

    RF connection with the DucoBox� 3� Once all components have been paired, ‘Installer mode’ can be deactivated by tapping ‘INST’ on the DucoBox Reno� The LEDs on all components will stop flashing�...
  • Page 13: 06�E Removing / Replacing Components

    Remove all components from the network (for example in case of problems): Activate Installer mode and long press INST until the LED starts flashing red� The DucoBox will reboot (around 15 seconds) and the LED will stop flashing� L2003340 Installation manual for DucoBox Reno (Revision C | 07.03.2025)
  • Page 14: Air Calibration

    Ensure that the lid of the DucoBox is properly closed� Remove the front cover with a screwdriver� Figure 19: Remove the front cover of the lid with Figure 20: Removing the front cover a screwdriver to gain access to the adjustment buttons� L2003340 Installation manual for DucoBox Reno (Revision C | 07.03.2025)
  • Page 15 Repeat steps until the desired flow rate has been obtained at each vent� INST Exit configuration mode� To do so, press 'INST' in the DucoBox Reno� L2003340 Installation manual for DucoBox Reno (Revision C | 07.03.2025)
  • Page 16: 07�B Option: Installation Of User Controller On The Ducobox

    Figure 26: Snap the user controller onto the provided Figure 27: mounted user controller snap-on pieces of the front cover� L2003340 Installation manual for DucoBox Reno (Revision C | 07.03.2025)
  • Page 17: 07�C Checking

    After the check, the system can be reset to the desired ventilation mode� If you do not do so, the system will automatically revert to the AUTO mode after 15 minutes� L2003340 Installation manual for DucoBox Reno (Revision C | 07.03.2025)
  • Page 18: Maintenance & Service

    Please contact your installer� Keep the serial number of your product to hand� For service problems as an installer: Please contact your retailer of DUCO products� Keep the serial number of your product to hand� L2003340 Installation manual for DucoBox Reno (Revision C | 07.03.2025)
  • Page 19: Warranty

    All warranty conditions concerning the DucoBox and DUCO's ventilation systems can be found on the DUCO website� All complaints are to be reported to DUCO by the DUCO distributor with a clear description and the order/invoice number under which the products were delivered� To do so, please fill out the complaint registration form, found on the DUCO website, mentioning the serial number and send it to service@duco�eu�...
  • Page 20 Installed by: L2003340 Document last modified on 07.03.2025 (revision C)
