Included in this Package

Included in this Package
Included in this package you should find the following items:
IO-R-16 module with quick disconnect female connectors.
•
Remote I/O Module (IO-R-16) Mounting and Wiring Guide.
•
Hardware bag containing the following items:
•
One (1) grounding wire, with quick-disconnect 0.187" female connector.
–
Eight (8) 499-ohm resistors, used for 4–20mA inputs.
–

Material and Tools Required

The following supplies and tools are required for installation:
IO-R-34 or other 13.5 -15.75 Vdc power supply source (see
•
page 1).
If DIN mounting, a DIN rail, type NS35/7.5 (35mm x 7.5mm) and DIN rail end-clips (stop clips), and screws for
•
mounting. Low- profile end clips are preferred to avoid contacting module connectors. See
If DIN rail is not used, suitable screws for mounting base of Remote I/O Module module.
Suitable tools and supplies for making all wiring terminations.
•
Precautions
This document uses the following warning and caution conventions:
Cautions remind the reader to be careful. They alert readers to situations where there is a chance that
Caution
the reader might perform an action that cannot be undone, might receive unexpected results, or might
lose data. Cautions contain an explanation of why the action is potentially problematic.
Warnings alert the reader to proceed with extreme care. They alert readers to situations where
Warning
there is a chance that the reader might do something that can result in personal injury or
equipment damage. Warnings contain an explanation of why the action is potentially dangerous.

Safety Precautions

The following items are warnings of a general nature relating to the installation and start-up of a compatible EC-BOS.
Be sure to heed these warnings to prevent personal injury or equipment damage.
Warning • A 15Vdc circuit powers the IO-R-16 module. Disconnect power before installation or servicing to
prevent electrical shock or equipment damage.
• Make all connections in accordance with national and local electrical codes. Use copper conductors
only.
• To reduce the risk of fire or electrical shock, install in a controlled environment relatively free of
contaminants.
• EC-BOS and I/O modules are only intended for use as monitoring and control devices. To prevent data
loss or equipment damage, do not use them for any other purposes.
4
"Power Supply Options and
Remote IO-R-16 Module Mounting and Wiring Guide
August 2, 2017
Precautions
Considerations"on
Figure 1 on page 7.
