Triplex diaphragm automatic water system pump

Advertisement

Quick Links

FEATURES

• Self–Priming
• Dry Running
• Soft Noise Absorbing Mounts
• Snap–in Port Fittings
• Built-in Bypass
Less Pulsation
• Corrosion Resistant Materials
• Meets ISO 8846

SPECIFICATIONS

Motor: Permanent Magnet, Ball Bearing
Totally Enclosed. CE Models are
fully suppressed.
Pump: Three chamber diaphragm design
Self-priming up to 9 feet suction lift;
Pump able to run dry without damage
MODEL*
03526 - 144
R3626 - 344
R3426 - 144
R3426 - 344
R3426 - 148
R3426 - 348
*CE fully suppressed models are identified by a prefix "R" and a CE mark on the label.(i.e. R3626 - 344).
Self Declaration Of Conformance (SDOC) is available upon request.

OPERATION

With pump switch off and battery fully charged, fill water
tank, open all faucets, then turn pump switch on. Water
will begin to flow. When the water is free of air, turn
faucets off. Remember, you are filling the water heater

DIMENSIONAL DRAWING

4.75"
(12.07 cm)
AMP DRAW
VOLTS
@10 psi (0.7 bar)
12V dc
24V dc
12V dc
24V dc
12V dc
24V dc
3.18"
(8.00 cm)
4.24"
(10.77 cm)
3426 / 3526 / 3626 Series
Automatic Water System Pump
Pump
Height
Series
inches (cm)
3X26 - XXX
4.75 (12.07)
FLOW
GPM (LPM)
4.4
2.9 (11.0)
2.2
2.9 (11.0)
4.4
2.9 (11.0)
2.2
2.9 (11.0)
3.5
2.0 (8.0)
1.7
2.0 (8.0)
and the toilet and shower lines. When all valves are
shut-off, pump will stop. Should pump fail to stop, turn
switch off and see the trouble shooting guide.
"Triplex Diaphragm"
Dimensions English (SI)
Length
inches (cm)
inches (cm)
9.00 (22.86)
6.00 (15.24)
PRESSURE SWITCH
Max psi (bar)
50 (3.4)
40 (2.6)
25 (1.6)
25 (1.6)
25 (1.6)
25 (1.6)
9.04"
(22.86 cm)
3.12"
2.25"
(6.50 cm)
(8.00 cm)
Width
Weight
Lb (Kg)
3.50 (1.59)
BYPASS
Yes
Yes
No
No
No
No
