Summary of Contents for stellar labs NXT18
- Page 1 NXT Hooklift Options Manual Options Stellar Industries, Inc. 190 State Street PO Box 169 Garner, IA 50438 800-321-3741 Fax: 641-923-2811 Subject to Change without Notification. REV1 www.stellarindustries.com © 2023 Stellar Industries, Inc. PN: 127721...
- Page 3 -40° F / C, the operator should pull the unit into a climate-controlled area and allow the weldments to warm up to and then maintain a temperature above this level. Page ii | Stellar NXT18 Options Manual 127721 ®...
-
Page 4: Table Of Contents
Bumper Asm Pintle w/Folding Bumper - PN 31920 ................42 Bumper Asm Pintle w/Folding Bumper - PN 31920 Parts ..............43 Bumper Asm Pintle w/Folding Bumper - PN 31920 (Cont.) ..............44 Bumper Asm Pintle w/Folding Bumper - PN 31920 Parts ..............45 Stellar NXT18 Options Manual 127721 | Page iii ®... -
Page 5: Introduction
For Technical Questions, Information, Parts, or Warranty, Call Toll-Free at 800-321-3741 Hours: Monday - Friday, 8:00 a.m. - 5:00 p.m. CST Or email at the following addresses: Technical Questions, and Information service@stellarindustries.com Order Parts parts@stellarindustries.com Warranty Information warranty@stellarindustries.com Page iv | Stellar NXT18 Options Manual 127721 ®... -
Page 6: Serial Tag Location
CANADIAN PATENTS Proudly Designed 6,749,389 6,558,104 5,427,495 6,749,389 ® 5,108,247 6,065,942 5,082,417 5,108,247 and Manufactured 4214 MADE IN THE U.S.A. BY STELLAR INDUSTRIES, INC. PN C5942 in the USA by 35234 Stellar NXT18 Options Manual 127721 | Page v ®... - Page 7 This Page Intentionally Left Blank. Page vi | Stellar NXT18 Options Manual 127721 ®...
-
Page 8: Chapter 1 - Options
BUMPER ASSEMBLY, 16K PINTLE FLEX (81300) ................30 BUMPER, MANUAL FOLD OUT W/LIGHTS (5348) ................32 BUMPER ASSEMBLY HD 94.00 (5407) ....................34 BUMPER ASSEMBLY, BOLT ON 30K PINTLE (17441) ................38 BUMPER ASSEMBLY PINGTLE W/FOLDING BUMPER (31920) ............44 Stellar NXT18 Options Manual 127721 | Page 1 ®... -
Page 9: Toolbox Assembly - Pn 10401
Toolbox Assembly - PN 10401 UTB ASM OH 18X36X18 W / MOUNTS Page 2 | Stellar NXT18 Options Manual 127721 ®... -
Page 10: Toolbox Assembly - Pn 10401 Parts List
5468 NUT 0.50-13 HHGR8 NYLOC 8833 CAP SCR 0.50-13X2.00 HHGR8 D0790 WASHER 0.50 SAE FLAT YELLOW GR8 ITEMS NOT SHOWN PART DESCRIPTION C5976 WEATHERSTRIP 5 FT 70174 OH DOOR STOP KIT Stellar NXT18 Options Manual 127721 | Page 3 ®... -
Page 11: Toolbox Assembly - Pn 8480
Toolbox Assembly - PN 8480 UBTB OH 20X45X22 W / MOUNTS Page 4 | Stellar NXT18 Options Manual 127721 ®... -
Page 12: Toolbox Assembly - Pn 8480 Parts List
7193 DOOR AL OH 17.13X40.00 10638 HARDWARE ASM OH DOOR NOT SHOWN (NOT SHOWN) 5468 NUT 0.50-13 HHGR8 NYLOC 8833 CAP SCR 0.50-13X2.00 HHGR8 D0790 WASHER 0.50 SAE FLAT YELLOW GR8 Stellar NXT18 Options Manual 127721 | Page 5 ®... -
Page 13: Toolbox Assembly - Pn 10402
Toolbox Assembly - PN 10402 UBTB ASM OH 20X58X22 W / MOUNTS Page 6 | Stellar NXT18 Options Manual 127721 ®... -
Page 14: Toolbox Assembly - Pn 10402
5468 NUT 0.50-13 HHGR8 NYLOC 8833 CAP SCR 0.50-13X2.00 HHGR8 D0790 WASHER 0.50 SAE FLAT YELLOW GR8 ITEMS NOT SHOWN PART DESCRIPTION C5976 WEATHERSTRIP 8 FT 70174 OH DOOR STOP KIT Stellar NXT18 Options Manual 127721 | Page 7 ®... -
Page 15: Fender Kit Low Pro Plastic - Pn 127888
Fender Kit Low Pro Plastic - PN 127888 NOTE: BASE SHOWN AS REFERENCE ONLY Page 8 | Stellar NXT18 Options Manual 127721 ®... -
Page 16: Fender Kit Low Pro Plastic - Pn 127888 Parts List
Fender Kit Low Pro Plastic - PN 127888 Parts List PN 127888 ITEM PART DESCRIPTION 96896 FENDER SINGLE LOW PRO PLASTIC BLACK - MIN1900 5733 MTG KIT OFFSET POLY FENDER (FLEET) 7633 FENDER MOUNT ASM KIT Stellar NXT18 Options Manual 127721 | Page 9 ®... -
Page 17: Fender Asm Single Steel - Pn 127890
Fender Asm Single Steel - PN 127890 Page 10 | Stellar NXT18 Options Manual 127721 ®... -
Page 18: Fender Asm Single Steel - Pn 127890 Parts List
46590 CAP SCR 0.50X1.50 SQ HD CP SS 127891 FENDER SUPPORT WELDMENT FOR NXT18 C1025 CAP SCR 0.63-11X2.00 HHGR8 C5902 WASHER 0.63 SAE FLAT YELLOW GR8 24868 NUT 0.63-11 HHGR8 NYLOC Stellar NXT18 Options Manual 127721 | Page 11 ®... -
Page 19: Fender Asm 2-Ton Plastic - Pn 107101
Fender Asm 2-Ton Plastic - PN 107101 Page 12 | Stellar NXT18 Options Manual 127721 ®... -
Page 20: Fender Asm 2-Ton Plastic - Pn 107101 Parts List
Fender Asm 2-Ton Plastic - PN 107101 Parts List PN 107101 ITEM PART DESCRIPTION 4467 FENDER SINGLE 2 TON PLASTIC 5733 MTG KIT OFFSET POLY FENDER (FLEET) 7633 FENDER MOUNT ASM KIT Stellar NXT18 Options Manual 127721 | Page 13 ®... -
Page 21: Fender Kit Tandem Poly - Pn 58217
Fender Kit Tandem Poly - PN 58217 POLY SET MIN 900 Page 14 | Stellar NXT18 Options Manual 127721 ®... -
Page 22: Fender Kit Tandem Poly - Pn 58217 Parts List
PN 58217 ITEM PART DESCRIPTION 64060 FENDER POLY MIN 900 FRONT/REAR 102205 MNT KIT FENDER MID SUPPORT TANDEM POLY 5733 MTG KIT OFFSET POLY FENDER (FLEET) 7633 FENDER MOUNT ASM KIT Stellar NXT18 Options Manual 127721 | Page 15 ®... -
Page 23: Fender Asm Single Steel 22.5 - Pn 128015
Fender Asm Single Steel 22.5 - PN 128015 Page 16 | Stellar NXT18 Options Manual 127721 ®... -
Page 24: Fender Asm Single Steel 22.5 - Pn 128015 Parts List
46590 CAP SCR 0.50X1.50 SQ HD CP SS 127891 FENDER SUPPORT WELDMENT FOR NXT18 C1025 CAP SCR 0.63-11X2.00 HHGR8 C5902 WASHER 0.63 SAE FLAT YELLOW GR8 24868 NUT 0.63-11 HHGR8 NYLOC Stellar NXT18 Options Manual 127721 | Page 17 ®... -
Page 25: Fender Asm Al Smooth Low-Pro - Pn 66325
Fender Asm AL Smooth Low-Pro - PN 66325 Page 18 | Stellar NXT18 Options Manual 127721 ®... -
Page 26: Fender Asm Al Smooth Low-Pro - Pn 66325 Parts List
Fender Asm AL Smooth Low-Pro - PN 66325 Parts List PN 66325 ITEM PART DESCRIPTION 66324 FENDER SINGLE AL SMOOTH LOW-PRO 5733 MTG KIT OFFSET POLY FENDER (FLEET) 7633 FENDER MOUNT ASM KIT Stellar NXT18 Options Manual 127721 | Page 19 ®... -
Page 27: Fender Asm Single Al Dps - Pn 127889
Fender Asm Single AL DPS - PN 127889 Page 20 | Stellar NXT18 Options Manual 127721 ®... -
Page 28: Fender Asm Single Al Dps - Pn 127889 Parts List
Fender Asm Single AL DPS - PN 127889 Parts List PN 127889 ITEM PART DESCRIPTION 116165 FENDER SINGLE AL DPS CNE 5733 MTG KIT OFFSET POLY FENDER (FLEET) 7633 FENDER MOUNT ASM KIT Stellar NXT18 Options Manual 127721 | Page 21 ®... -
Page 29: Kit Bumper Threshold Single Fender 30" - Pn 119066
Kit Bumper Threshold Single Fender 30” - PN 119066 NOTE: FENDERS SHOWN AS REFERENCE ONLY NOTE: BUMPER SHOWN AS REFERENCE ONLY TYP 2 Page 22 | Stellar NXT18 Options Manual 127721 ®... -
Page 30: Kit Bumper Threshold Single Fender 30" - Pn 119066
Kit Bumper Threshold Single Fender 30” - PN 119066 PN 119066 ITEM PART DESCRIPTION 0347 NUT 0.38-16 HHGR5 NYLOC 0346 WASHER 0.38 USS FLAT 0335 CAP SCR 0.38-16X1.25 HHGR5 116166 ANGLE FORMED 10GAX8.50X33.28X20.38 Stellar NXT18 Options Manual 127721 | Page 23 ®... -
Page 31: Mtg Kit Pioneer Tarper - Pn 128210
Mtg Kit Pioneer Tarper - PN 128210 SINGLE AXLE TYP 8 TYP 2 TYP 8 Page 24 | Stellar NXT18 Options Manual 127721 ®... -
Page 32: Mtg Kit Pioneer Tarper - Pn 128210 Parts List
PART DESCRIPTION 128208 PLATE 0.50X7.19X10.25 HOLES 47209 BRKT FENDER KP60 C1026 CAP SCR 0.63-11X2.50 HHGR8 C5902 WASHER 0.63 SAE FLAT YELLOW GR8 24868 NUT 0.63-11 HHGR8 NYLOC 99676 TUBE 3.00X3.00X0.25WX35.59 W/HOLE Stellar NXT18 Options Manual 127721 | Page 25 ®... -
Page 33: Mtg Kit Donovan Tarper - Pn 128211
Mtg Kit Donovan Tarper - PN 128211 SINGLE AXLE TYP 2 TYP 8 TYP 8 Page 26 | Stellar NXT18 Options Manual 127721 ®... -
Page 34: Mtg Kit Donovan Tarper - Pn 128211 Parts List
ITEM PART DESCRIPTION C1026 CAP SCR 0.63-11X2.50 HHGR8 C5902 WASHER 0.63 SAE FLAT YELLOW GR8 24868 NUT 0.63-11 HHGR8 NYLOC 128208 PLATE 0.50X7.19X10.25 HOLES 128212 TUBE 3.00X3.00X0.25WX12.00 47209 BRKT FENDER KP60 Stellar NXT18 Options Manual 127721 | Page 27 ®... -
Page 35: Mud Flap Mnt Kit - Pn 96895
Mud Flap MNT Kit - PN 96895 24X24 STELLAR WITH SPRING NOTE: MUD FLAPS AND HRDW SHOWN AS REFERENCE ONLY Page 28 | Stellar NXT18 Options Manual 127721 ®... -
Page 36: Mud Flap Mnt Kit - Pn 96895 Parts List
Mud Flap MNT Kit - PN 96895 Parts List PN 96895 ITEM PART DESCRIPTION D0790 WASHER 0.50 SAE FLAT YELLOW GR8 5468 NUT 0.50-13 HHGR8 NYLOC 96574 MUD FLAP MNT KIT W/SPRING (INCLUDES 2 MNTS) Stellar NXT18 Options Manual 127721 | Page 29 ®... -
Page 37: Bumper Asm - 16K Pintle Flex - Pn 81300
Bumper Asm - 16K Pintle Flex - PN 81300 NOTE: LICENSE PLATE SHOWN AS REFERENCE ONLY NOTE: (PN 56795 - LIGHT CLEARANCE RED .75IN MC L-11RKB) IS PART OF WIRE HARNESS (PN 82429) TYP 5 Page 30 | Stellar NXT18 Options Manual 127721 ®... -
Page 38: Bumper Asm - 16K Pintle Flex - Pn 81300
WIRE HARNESS FMVSS108 CHASSIS GEN2 0540 REFLECTOR 3.00 AMBER 0541 REFLECTOR 3.00 RED NOTES: P / N 123761, LIGHT & INSTALL KIT BUMPER ASM 30K, INCLUDES ALL ITEMS EXCEPT BUMPER WELDMENT. Stellar NXT18 Options Manual 127721 | Page 31 ®... -
Page 39: Bumper - Manual Fold Out W/Lights - Pn 5348
Bumper - Manual Fold Out w/Lights - PN 5348 NOTE: INSTALL (PN 56795) FROM LIGHT KIT IN END OF MNT NOTE: MUD FLAPS SHOWN AS REFERENCE ONLY Page 32 | Stellar NXT18 Options Manual 127721 ®... -
Page 40: Bumper - Manual Fold Out W/Lights Pn 5348 Parts List
MUD FLAP MNT KIT 24X24 STELLAR W/SPRING C5902 WASHER 0.63 SAE FLAT YELLOW GR8 24868 NUT 0.63-11 HHGR8 NYLOC C1026 CAP SCR 0.63-11X2.50 HHGR8 NOTES: ITEMS NOT SHOWN: 61732 - LIGHT KIT ICC BUMPER W/TARPER (QTY 1). Stellar NXT18 Options Manual 127721 | Page 33 ®... -
Page 41: Bumper Asm Hd 94.00 - Pn 5407
Bumper Asm HD 94.00 - PN 5407 Page 34 | Stellar NXT18 Options Manual 127721 ®... -
Page 42: Bumper Asm Hd 94.00 - Pn 5407 Parts List
65956 PLUG PLASTIC 0.56 HOLE 119007 KIT MUD FLAP BACKING PLATES ITEMS NOT SHOWN PART DESCRIPTION 45889 LIGHT KIT FMVSS108 CABLE HOIST NOTE: LIGHT KIT ASSEMBLY (45889) SHOWN ON NEXT PAGE Stellar NXT18 Options Manual 127721 | Page 35 ®... -
Page 43: Bumper Asm Hd 94.00 - Pn 5407 (Continued)
Bumper Asm HD 94.00 - PN 5407 (continued) Page 36 | Stellar NXT18 Options Manual 127721 ®... -
Page 44: Bumper Asm Hd 94.00 - Pn 5407 Parts List (2)
GROMMET FOR 2 CLEARANCE 30700 ITEMS NOT SHOWN PART DESCRIPTION 0540 REFLECTOR 3.00 AMBER 0541 REFLECTOR 3.00 RED 9464 PLUG MARKER LIGHT PL10 FEMALE 38056 WIRE HARNESS FMV108 HOOK LOADER 40310 WIRE HARNESS FMVSS108 CHASSIS Stellar NXT18 Options Manual 127721 | Page 37 ®... -
Page 45: Bumper Asm Bolt On 30K Pintle - Pn 17441
Bumper Asm Bolt On 30K Pintle - PN 17441 Page 38 | Stellar NXT18 Options Manual 127721 ®... -
Page 46: Bumper Asm Bolt On 30K Pintle - Pn 17441 Parts List
WASHER 0.63 SAE FLAT YELLOW GR8 119007 KIT MUD FLAP BACKING PLATES ITEMS NOT SHOWN PART DESCRIPTION 45889 LIGHT KIT FMVSS108 CABLE HOIST NOTE: LIGHT KIT ASSEMBLY (45889) SHOWN ON NEXT PAGE Stellar NXT18 Options Manual 127721 | Page 39 ®... -
Page 47: Bumper Asm Bolt On 30K Pintle - Pn 17441 (Continued)
Bumper Asm Bolt On 30K Pintle - PN 17441 (continued) Page 40 | Stellar NXT18 Options Manual 127721 ®... -
Page 48: Bumper Asm Bolt On 30K Pintle - Pn 17441 Parts List (2)
C4862 GROMMET FOR 2 CLEARANCE 30700 ITEMS NOT SHOWN PART DESCRIPTION 0540 REFLECTOR 3.00 AMBER 0541 REFLECTOR 3.00 RED 9464 PLUG MARKER LIGHT PL10 FEMALE 38056 WIRE HARNESS FMV108 HOOK LOADER 40310 WIRE HARNESS FMVSS108 CHASSIS Stellar NXT18 Options Manual 127721 | Page 41 ®... -
Page 49: Bumper Asm Pintle W/Folding Bumper - Pn 31920
Bumper Asm Pintle w/Folding Bumper - PN 31920 Page 42 | Stellar NXT18 Options Manual 127721 ®... -
Page 50: Bumper Asm Pintle W/Folding Bumper - Pn 31920 Parts
WASHER 0.63 SAE FLAT YELLOW GR8 119007 KIT MUD FLAP BACKING PLATES ITEMS NOT SHOWN PART DESCRIPTION 45889 LIGHT KIT FMVSS108 CABLE HOIST NOTE: LIGHT KIT ASSEMBLY (45889) SHOWN ON NEXT PAGE Stellar NXT18 Options Manual 127721 | Page 43 ®... -
Page 51: Bumper Asm Pintle W/Folding Bumper - Pn 31920 (Cont.)
Bumper Asm Pintle w/Folding Bumper - PN 31920 (Cont.) Page 44 | Stellar NXT18 Options Manual 127721 ®... -
Page 52: Bumper Asm Pintle W/Folding Bumper - Pn 31920 Parts
C4862 GROMMET FOR 2 CLEARANCE 30700 ITEMS NOT SHOWN PART DESCRIPTION 0540 REFLECTOR 3.00 AMBER 0541 REFLECTOR 3.00 RED 9464 PLUG MARKER LIGHT PL10 FEMALE 38056 WIRE HARNESS FMV108 HOOK LOADER 40310 WIRE HARNESS FMVSS108 CHASSIS Stellar NXT18 Options Manual 127721 | Page 45 ®... - Page 55 Subject to Change without Notification. © 2023 Stellar Industries, Inc.
