stellar labs 108-14-32 Owner's Manual

Shuttle hooklift
Hide thumbs Also See for 108-14-32:
Table of Contents

Advertisement

Quick Links

Download this manual
Safety • Operation • Installation • Maintenance
Subject to Change without Notification.
© 2019 Stellar Industries, Inc.
S
HUTTLE
Models
108-14-32
138-18-32
138-18-34
108-14-40
138-18-40
174-20-40
190-24-40
Stellar Industries, Inc.
190 State Street
PO Box 169
Garner, IA 50438
800-321-3741
Fax: 641-923-2811
www.stellarindustries.com
H
OOKLIFT
O
' M
WNERS
ANUAL
Manual Part No. 43501
Last Revision: 09/01/15
