Summary of Contents for SELVAS Healthcare ACCUNIQ BP500
- Page 1 User Manual BP500 English. 06/2021. V3.02...
- Page 2 The device bears the CE label in accordance with the provisions of Medical Device Directive 93/42/EEC. THE PERSONS RESPONSIBLE FOR PLACING DEVICES ON THE EC MARKET UNDER MDD 93/42/EEC SELVAS Healthcare, Inc. 155, Sinseong-ro, Yuseong-gu, Daejeon, 34109 Republic of Korea TEL: 82-42-879-3000, FAX: 82-42-864-4462 Obelis s.a.
-
Page 3: Table Of Contents
How to insert thermal paper ..........21 Applying for A/S ..............40 How to connect the communication port ....22 How to contact SELVAS Healthcare ..... 40 How to set basic functions ..........22 PACKING AND TRANSPORT ..........40 How to enter basic function setting mode ..23 How to check the cumulative count .... -
Page 5: Introduction
User Manual BP500 INTRODUCTION We highly appreciate that you chose SELVAS Healthcare’s product. You are kindly requested to be familiar with these directions before using this product and always keep it together with the product. In case you are not sure about any directions or problems arising while using the product, please contact our service center. -
Page 6: Classification And Compliance
This device is designed and manufactured with consideration of safety of the operator and subject and also to the reliability of the unit. The following precautions must be observed for additional safety; The unit must be operated only by, or under supervision of a qualified person with SELVAS Healthcare or our distributors. Medical Electrical Equipment. - Page 7 Pressurization of the CUFF can temporarily cause loss of function of simultaneously used monitoring ME EQUIPMENT on the same limb; Do not modify the unit. If any modification is needed, ask SELVAS Healthcare or its authorized dealer for service. The unit has previously been adjusted in the factory for optimum performance.
- Page 8 SELVAS Healthcare Where the unit is exposed to explosive gas. Where the unit is exposed to excessive shocks or vibrations. Where the angle of inclination of mounting surface exceeds 10 degrees. Where the unit is exposed to direct sunlight.
-
Page 9: Safety Symbols And Information
If you have or suspect that you have a medical problem, consult with your physician promptly. Defective unit or accessories must be packed in the replacement cartons to be shipped off from you to SELVAS Healthcare. Shipping and insurance costs for return of defective unit must be prepaid by the users. - Page 10 SELVAS Healthcare SYMBOL INFORMATION "ON" (only for a part of equipment) This symbol is used inside system. Identifies the point where the safety ground of the system is fastened to the chassis. Do not open. This is for factory only.
-
Page 11: (Emc)
User Manual BP500 Guidance for Electromagnetic compatibility (EMC) Details about the electromagnetic compatibility (EMC) of the BP500 are given below. Before using the BP500, be sure to read and understand the following information. Guidance and manufacturer’s declaration – electromagnetic emissions The BP500 is intended for use in the electromagnetic environment specified below. - Page 12 SELVAS Healthcare IEC 60601 test Electromagnetic environment- Immunity test Compliance level level guidance ±1 kV ±1 kV differential differential Mains power quality should be that of Surge mode mode a typical commercial or hospital IEC 61000-4-5 2 kV ±2 kV environment.
- Page 13 User Manual BP500 IEC 60601 test Immunity test Compliance level Electromagnetic environment-guidance level IEC 61000-4-3 80 MHz to 2,5 GHz distance calculated from the equation applicable to the frequency of the transmitter. Recommended separation distance d =1.2 d =1.2 80 MHz to 900 MHz d =2.3 900 MHz to 2,5 GHz Where P is the maximum output power...
- Page 14 SELVAS Healthcare normal operation. If abnormal performance is observed, additional measures may be necessary, such as reorienting or relocating the BP500. Over the frequency range 150 kHz to 80 MHz, field strengths should be less than 3 V/m. Recommended separation distances between portable and mobile RF communications...
-
Page 15: Function
User Manual BP500 FUNCTION The front of the main unit ① Time display Displays the current date and time. ② Systolic Pressure display Displays measured systolic pressure. ③ Diastolic Pressure display Displays measured diastolic pressure. ④ Pulse display Displays the measured pulse. ⑤... -
Page 16: Printing Section
SELVAS Healthcare Printing Section When you open the printer cover, you will see four buttons under the printer. [FEED] button: If you press and hold the button, paper will be ejected and cut automatically. [SET] button, [▲(UP)] button, [▼(DOWN)] button: These buttons are used to change the product settings. -
Page 17: Rear Of The Main Unit
User Manual BP500 Rear of the main unit ① Power switch Turns the power on/off. ② Power port Connect the adapter here. ③ Rear monitor port Connect the dedicated cable for the rear monitor (optional) to the main unit here. If you input your ID, weight, and height when you use the rear monitor, you can check your systolic, diastolic, blood pressure measured value of the pulse, and body mass index (BMI). -
Page 18: Accessories
SELVAS Healthcare Accessories User Manual Power adapter and power Measurement guide plate cable Options Dedicated cart and height Thermal printer and thermal Rear monitor adjustable chair paper _FUNCTION... -
Page 19: Installation
User Manual BP500 INSTALLATION Installing on the Table Install the device by pulling it to the end of the table so that user can measure blood pressure in the correct position. Recommend that you use a chair or desk with adjustable height to allow measurements in the most comfortable postion. -
Page 20: How To Connect The Power
SELVAS Healthcare How to connect the power Connect the enclosed adapter to the power port installed on the rear side of the device. Connect the power and turn on the Power switch on the left side of the input section. -
Page 21: How To Insert Thermal Paper
User Manual BP500 How to insert thermal paper Check whether the device is turned on. Press the bottom of the printer cover. The printer cover will move up. Open the cover at this time. Place the printing paper in a proper position as shown in the figure. If you insert the end of the paper deep under the black roll, it will automatically come out on the cutter. -
Page 22: How To Connect The Communication Port
SELVAS Healthcare How to connect the communication port Connect the main unit and a computer or other device using a USB cable (optional) and transfer the measured data to the computer or other device. Connect a USB cable to the USB port at the rear side of the device and to the computer's communication port. -
Page 23: How To Enter Basic Function Setting Mode
User Manual BP500 How to enter basic function setting mode Press the printer cover to release the cover in measurement standby mode. Press the [SET] button for 3 seconds to enter basic function setting mode. When basic function setting mode is entered, the Cnt character is displayed and blinks in the Systolic Pressure display section. -
Page 24: How To Check The Cumulative Count
SELVAS Healthcare How to check the cumulative count Enter basic function setting mode. Press the [SET] button while CnT (cumulative count check mode) is blinking. You can check dAy (daily cumulative measurement count), ALL (cumulative measurement count), and Prn (printer printing count) by pressing the [▲(UP)]... -
Page 25: How To Set The Voice Guide Volume
User Manual BP500 How to set the voice guide volume Enter basic function setting mode. Press the [▲(UP)] button to move to printer and volume setting mode. Press the [SET] button to enter printer and volume setting mode. Select the volume icon using the [SET] button. -
Page 26: How To Set Up Additional Functions
SELVAS Healthcare How to set up additional functions You can check the product version, set the USB and RS-232C communication port, and set whether the cuff sensor is enabled or not in additional function setting mode. How to enter additional function setting mode Press the printer cover to release the cover in measurement standby mode. -
Page 27: How To Set The Communication Port
User Manual BP500 mmHg mmHg mmHg mmHg PULSE PULSE How to set the communication port (RS-232C) The communication port is used to connect a computer, Bluetooth, or body composition analyzer. The protocol may vary depending on the software version. Therefore, it is recommended to contact the vendor or manufacturer before setting the protocol. -
Page 28: How To Install The Measurement Guide Plate
SELVAS Healthcare mmHg mmHg mmHg mmHg PULSE PULSE How to install the measurement guide plate Insert the Measurement Guide Plate to the Guide Plate Fixing Section on back side of the display. How to install the rear monitor Composition and description ①... -
Page 29: How To Connect The Port
User Manual BP500 ⑧ Weight button Used to input the weight of the user. ⑨ Height button Used to input the height of the user. ⑩ STOP button If pressed while entering the information, the input information will be reset. If you press the button, measurement will stop and the cuff will return to its original state. -
Page 30: Measurement Method
SELVAS Healthcare Caution Make sure to use the enclosed cable to to the device. When connecting the rear monitor and the main unit, connect it to the rear monitor port on the back of the main unit accurately in such a way that the arrow on the cable section faces upwards as shown in the figure below. - Page 31 User Manual BP500 Note If you input data on the rear monitor, you should press the “START” button on the rear monitor screen to print or display height, weight, and BMI on the rear monitor screen. Input the weight and height correctly because the data is reflected in the BMI. Result When measurement is complete, the BMI based on the entered weight and height is displayed on the LCD.
-
Page 32: Measurement
SELVAS Healthcare MEASUREMENT Operations Operation principles The cuff pressure is raised to approximately 40 mmHg higher than the PATIENT's systolic pressure and then gradually depressurized. The oscillations of pressure in a cuff are recorded during gradual deflation. By analyzing the recorded data, the systolic is estimated at the oscillations begin, and the diastolic is estimated at oscillations disappear. - Page 33 User Manual BP500 Spilled water may flow into the product and cause problems. Please remove thick Take a rest before Do not move or speak Do not take a coats or sweaters taking a measurements during measurement. measurement if you’re before taking a and measure in a standing, sitting down...
-
Page 34: Operating Steps
SELVAS Healthcare Operating steps Check the voltage, connect the power plug, and turn on the power. When the power is turned on, the LCD screen is ready for measurement. Put your right arm in the cuff. When placing your arm, make the palm of your hand face upward and put your arm deep inside the elbow support. - Page 35 User Manual BP500 The measurement results are printed on three results sheets, and the type of result paper can be changed in the settings. Note If it is not the results you expect, Please rest 1 minute then mesurment again. If the measured results do not differ then please consult with your doctor.
-
Page 36: Storage & Maintenance
If foreign substances are introduced, or if the device is exposed to harmful environments, the unit must be examined by a qualified technician before use. Use only the power cable, adapter, and fuses provided by SELVAS Healthcare. Please confirm the covering of the cable, the state of the adapter connection, and other safety checks... - Page 37 Please refer to and abide by the “SAFETY PRECAUTIONS.” Caution Users must be sure to use sterile safety equipment such as gloves when in contact with or cleaning electrodes. SELVAS Healthcare is not responsible for safety accidents caused by users’ carelessness. STORAGE & MAINTENANCE_...
-
Page 38: Error & Repair
SELVAS Healthcare ERROR & REPAIR Error code Cause Repair A small number of pulse waves Take off your coat and take a measurement were acquired after resting enough Please check the measurement posture If the same error is repeated, please ... - Page 39 User Manual BP500 If the same error is repeated, please contact the manufacturer or authorized dealer Inner cuff pressure does not rise Please contact the manufacturer or authorized dealer It has generated more than It is installed where vibration occurs during ...
-
Page 40: After Service
SELVAS Healthcare or local distributor will make available on-request circuit diagrams, component part list, descriptions, calibration or other information which will assist your appropriately qualified technical personnel to repair those parts of the unit which are designated by SELVAS Healthcare as repairable. How to contact SELVAS Healthcare Write us at: SELVAS Healthcare, Inc. - Page 41 User Manual BP500 Disassemble the device in reverse order of assembly. Pack the device using the original packing materials. Transport it carefully. AFTER SERVICE_...
-
Page 42: Specification
SELVAS Healthcare SPECIFICATION This medical device complies with IEC 80601-2-30:2017 DIVISION SPECIFICATION Model BP500 Measuring method Oscillometric Display mode Mono LCD (130 X 90mm) Systolic/Diastolic/Mean blood pressure, Pulse pressure, Pulse, Blood pressure assessment, Pulse wave pattern Result Contents Rear Monitor(Optional): Systolic and diastolic pressures, pulse, ID Number and B.M.I. -
Page 43: Warranty
User Manual BP500 WARRANTY Item Automatic Blood Pressure Monitor Warranty period Model BP500 1 year (main unit only) Serial NO. Date of purchase Month Year Name Tel. Dealer Address: Name Tel. Customer Address: Date Defection Confirmation Note When you receive this warranty, make sure that the name of the dealer and the month, day and year of purchase are all completed. - Page 44 SELVAS Healthcare, Inc. HEADQUARTERS 155, Sinseong-ro, Yuseong-gu, Daejeon, 34109 Republic of Korea Tel 82 42 879 3000 Fax 82 42 864 4462 If the problems continue, call the service center. When you ask for service, the manufacturer’s label, serial number, date of original purchase and explanation of malfunction will be required.
