Pro-Form PFEVEX79911.0 User Manual page 7

2. While a second person lifts the rear of the Base
(1), attach the Rear Stabilizer (23) to the Base
with two 3/8" x 2 1/4" Screws (74).
3. Orient the Seat Post (3) as shown.
Loosen the indicated Post Knob (47) and pull it
outward. Then, insert the Seat Post (3) into the
Frame (2).
Move the Seat Post (3) upward or downward to
the desired position, release the Post Knob (47)
into an adjustment hole in the Seat Post, and
then tighten the Post Knob. Make sure that the
Post Knob is engaged in an adjustment hole.
2
3
Holes
2
47
7
74
1
23
3
