- Page 1 WAFER GSM-RELAY REMOTE CONTROL UNIT GSM-RELAY6 MANUAL V1.1 From 2018 SHANGHAI WAFER MICROELECTRONICS CO.,LTD http://www.waferlife.com...
-
Page 2: Product Description
GSM-RELAY6 OPERATING INSTRUCTIONS PRODUCT DESCRIPTION WAFER GSM-RELAY6 is an electronic board with an on-board GSM modem.The purpose of this device is to do the real time and interactive GSM remote control by means of a GSM phone.GSM-RELAY6 has 6 Relay switch output and 6 alarm input port. -
Page 3: Installation
ˇ Support main power supply failure alarm with battery on board INSTALLATION To install the GSM-RELAY6, you need to power on the board with DC12V. and also connect the relay output according to your project. The relay contacts can stand 230V 10A maximum, this is enough for its operation but don't try to switch higher voltages or currents. - Page 4 WAFER GSM-RELAY REMOTE CONTROL UNIT The following compand is used in the GSM-RELAY6 : #PWD: Password #CAP: Change password #WHL: White List (add or remove numbers) #ACM: Safety control mode or free control mode #REPLY: When send the SMS to control,if need to reply the SMS...
- Page 5 WAFER GSM-RELAY REMOTE CONTROL UNIT #REPLY SMS reply enable or disable for relay output control command This command is used to save the cost for SMS reply when no need the SMS reply back #PWD123456#REPLY=ON or #PWD123456#REPLY=OFF When REPLY=OFF,then any relay output control text command would no confirmed SMS reply from controller,including the OUT, RLY and the Customized Text Command #WHL White List.
- Page 6 WAFER GSM-RELAY REMOTE CONTROL UNIT #QUERY White List. If you are not sure a number in the position of the device,you can use the SMS #PWD123456#QUERY=132324242 The device would answer the SMS with: QUERY RESULT: 132324242 AT WHL121 Or QUERY RESULT: 132324242 NOT EXIT #GOT Relay working output delay time.
- Page 7 #CSQ Check GSM signal quality. (PC$PHONE) This command is useful to see what is the GSM network signal level your GSM-RELAY6 is receiving. It ranges from 0 to 32 (if it is 0 we doubt it will never answer...). You should have a signal above 12 to be sure of being able to control the relay sets in any condition.
- Page 8 WAFER GSM-RELAY REMOTE CONTROL UNIT control the relay6 to ON) ( Press the Number and end with “**” to control separate relay, For example,press “6**” to control the relay6 to OFF ) ( Press the Number and end with “*#” to control separate relay, For example,press “6*#” to...
- Page 9 With this command,we can check the inside config and control Log information #PWD123456#LOG=ALL? Reply would be as following data: ……… LOGS015:201501072143:18017370819:PHONE LOGS016:201501072143:18017370819:PHONE LOGS017:201501072141:18017370819:PHONE LOGS018:201501071937:+8613564121668:WSDRLY2=13 LOGS019:201501071937:+8613564121668:WSDRLY6=6 LOGS020:201501071937:+8613564121668:RLY3=8………. ………. #ALARM Alarm setup In GSM-RELAY6, that Alarm01 is very important position,not only act as a alarm number,but also working http://www.waferlife.com...
- Page 10 WAFER GSM-RELAY REMOTE CONTROL UNIT as the REPORT phone number, that means if you enable the REPORT function,then every report event happen,then would send the REPORT SMS to this number (1)You can setup the alarm phone number when have the alarm information input...
-
Page 11: Troubleshooting
· GSM Signal is not good and cann’t register to GSM,try to move to another place to test. · If still cann’t registered to the GSM net, try to contact wafer to get the technical support · When LED D6 is flashing slowly,try to call the SIM card,the calling status would be in busy. - Page 12 Power supply for the each load mustn’t exceed 30VDC/10A or 230VAC/10A Warning: GSM-RELAY6 device only work as a high power switch, don’t power the LOAD directly. This brochure provides an overview of the products and services of WEIFU GSM Modules, For further information and queries kindly contact: Email: wafer@waferstar.com...
